Austin-Healey Sprite User manual

97H 1S83A
AUSTIN-HEALEY
SPRITE
DRIVER'8 HANDBOOK

AUSTIN-HENLEY
SPRITE
DRIVER'S
HANDBOOK
A copy of this Driver's Handbook is sent out
with every Austin-Healey Sprite. Additional
copies are obtainable only from your Austin
Dealer and Part No. 97H1583A should be quoted
when ordering.
JULY 1958
THE AUSTIN MOTOR CO. LTD.
LONGBRIDGE, BIRMINGH A M
BOX 41 G.P.O.

THE information contained in: this Operation
Manual has been confined to the essentials
necessary for the proper running and driving. of
the car. Nevertheless, the owner will find all the
information required to maintain the car in first-
class condition and to enable him to give it those
.all-important items of attention which go so far to-
ensure trouble-free and satisfactory service.
Every car leaving the Works is capable of
giving absolute satisfaction if attention is given
to the essential maintenance operations detailed
in this book. Remember that Austin Distributors/
Dealers are better equipped to provide routine
and repair service than the owner-driver; therefore, '
if you encounter trouble consult the Distributor
or Dealer or the Service Department of Austin
Motors Limited — they are at your- service.
An exchange scheme for many major items and
assemblies is run by B.M.C. Service Limited; ask
your Distributor or Dealer for details.
For those requiring information of a more detailed
and technical nature than is contained in the
Operation Manual, a Workshop Manual is available
at a reasonable price from your Distributor or
Dealer.
INDEX
FOREWORD
SPECIFICATION
REGULAR ATTENTIONS
DRIVING INSTRUCTIONS
PROPRIETARY EQUIPMENT
GENERAL MAINTENANCE ..
RECOMMENDED LUBRICANTS
INSTRUMENTS AND CONTROLS
36-57
20-35
33
16
10
Page
6
59
IDENTIFICATION
When communicating with the Company or your
Distributor/Dealer always quote the car and
engine numbers; the registration number is of no
use and is not required.

pp
C

GENERAL SPECIFICATION
AUSTIN-HKALKY SPRITE
SPECIFICATION
the vehicle, which is addressed to the Austin Motor Co. Ltd. or its
Dealers. The number will be found on a plate attached to the left-
hand valance inside the engine compartment.
In addition, the engine number is located oh the right side of the
cylinder block, adjacent to the cylinder head.
ENGINE
Bore
Stroke
Capacity
B.H.P.
Maximum Torque
Compression ratio
Firing Order
Valves
Valve Timing: Inlet opens
Inlet closes
Exhaust opens
Exhaust closes
Valve Clearance (hot or cold)
Number of cylinders
A LWAYS quote the car number in any correspondence,relating to
4
2.48 in. (62.9 mm.)
3.00 in. (76.2 mm.)
.. 57.87 cu. in. (948 c.c.)
43 at 5,200 r.p.m.
52 lbs. ft. at 3,300 r.p.m.
83to 1
1, 3, 4, 2
.. Overhead push rod operation
5' B.T.D.C.
45' A.B.D.C.
40' B.B.D.C.
10' A.T.D.C.
.012 in. (.305 mm.)
IGNITION
Type
Coil
Distributor
Contact breaker gap
Timing
Sparking Plugs
Plug Gap
CLUTCH
Make
Type
Diameter
Method of operation
GEARBOX
Type
. Gear ratios: 1st
2nd
3rd
Top
Reverse
4 speed synchromesh (on 2nd, 3rd k top)
Lucas 12 volt
Lucas type LA12
Lucas type DM2 PH4
.014 to .016 in. (.356 to .406mm.)
5' before T.D.C. (Premimn Fuel)
Champion N.5. Long reach
.025 in. (.64 mm.)
.. Borg and Beck
.. Single dry plate
6z in. (15.88 cm.)
Hydraulic
3.627 to 1
2.374 to 1
1.412 to 1
1 to 1
4.664 to 1
2$ Imp. pints (1.33 litres)
Oil 'capacity
LUBRICATION
Type
Pump
Pressure (Normal)
Filter
Sump capacity
Filter capacity
FUEL SYSTEM
Carburetters
Model
Needle
Tank capacity
Pump
Wet sump
Hobourn Eaton or Burman Rotor type
Running , . 60lbs./sq. in. (4.2 kg./cm.')
Idling . . 15lbs./sq. in. (1.05 kg./cm.')
6 Imp. pints (3.41litres)
1 Imp. pint (0.57 litres)
A.C. Sphinx 'Y'
Two S.U. semi-downdraught
GG
., 6 Imp. galls. (27 litres)
Full flow
Type
Make
Type
PROPELLER SHAFT
REAR AXLE
Oil capacity
Overall ratios: 1st
2nd
3rd
Top
Reverse
.. Hypoid three-quarter floating
le Imp. pints (1.0 litre)
15.32 to 1
10.02 to 1
5.96 to 1
4.22 to 1
19.69 to 1
Hardy Spicer
Open shaft
Hl
COOLING SYSTEM Pressurised
Pump, fan and thermostat
164'F. (73'C.)
10 Imp. pints (5.68 litres)
STEERING
Type
Ratio
Track toe-in
Adjustment
Rack and pinion
2~ turns lock to lock
Parallel to $ in. (0 —3.18mm.)
Shims
Type
Circulation
Normal operating temperature
Capacity

GENERAL SPECIFICATION
AUSTIN-HEAI,EY SPRITE
SUSPENSION GENERAL DIMENSIONS
Make
Type
Rear: Type
SHOCK ABSORBERS
Front: Type . . Independent
Castor Angle
Camber Angle
Swivel pin inclination
by coil springs and wishbones,
30
10
6p
Quarter-elliptic leaf springs
Overall Length
Overall Width
Overall Height
Wheelbase
Track (front)
Track (rear)
Turning Circle
Approx. Weight
11 ft. 0$ m. (3.37m.)
4 ft. 5 in. (1.35 m.)
4 ft. 1( in. (1.26 m.)
6 ft. 8 in. (2.32 m.)
3 ft. 94' in. (1.16.m.)
3 ft. 8—,'in.(1.14m.)
32 ft. approx. (9.7 m.)'
13 cwt. (660 kg;)
Armstrong
Double acting hydraulic piston
BRAKES
Make
Frontbrake: Type
Front
Rear
Handbrake: Type
Drum Diameter
Lockheed
Hydraulic with two leading shoes
Hydraulic
Pull-up operating mechanically
on rear wheels
7 in. (17.8 cm.)
WHEELS
Type 13 x 3.50D pressed steel disc with
ventilation holes
TYRES
Type
Pressures: Durilop 5.20-13 E.L.P. Tubeless 18 lbs./sq. in. (1.27 kg. cm.') front
20 lbs./sq. in. (1.41 kg./cm.') rear
JACKING SYSTEM Smith's 'Steady-lift'
Ratchet spanner
Type
Operation
ELECTRICAL EQUIPMENT Lucas 12 volt
Lucas B.T. 7A
43 amp. hrs at 20 hr. rate
Lucas type LA 12
Lucas type C39PV2
Lucas type M3561
Lucas type RB106/2
Lucas type SF6
Lucas type HF 1849
Lucas type DR2
Type
Battery
Capacity
Coil
Dynamo
Startermotor
Cut-out and Regulator
Fuse Unit
Horn
Windscreen Wipers

INSTRUMENTS 4 CONTROLS
AUSTIN-HEALKY SPRITE
INSTRUMENTS AND CONTROLS
INSTRUMENTS
Speedometer: Indicates the vehicle speed and total mileage.
The trip figures at the top of the speedometer face can be reset
to zero by pushing up the knob at the bottom of the speedometer
and tmning it to the right.
Tachometer: This instrument indicates the revolutions per
minute of the engine and thus assists the driver in determining
the most effective engine speed range for maximum performance
in any gear.
Oil Pressure Gauge: Indicates the engine oil pressure. The
pressure may rise to over 60 lb. per sq. in. (4.2 kg./cmP) when the
engine is started up from cold, but after the oil has circulated and
becomewarm the pressureshould drop to approximately 60 lb.
per sq. in. (4.2 kg./cm.') with a proportionately lower idling
pressure. Should the gauge fail to register any pressure at all,
stop the engine immediately and investigate the cause.
Ignition Warning Light: Should glow red when ignition is
switched on and fade out when the generator starts charging the
battery. Failure to do so should be investigated immediately.
Main Beam Warning Light: A red glow appears when the head-,
lights are switched on, with the two beams straight ahead. The
light goes out when the headlights are dipped.
Fuel Gauge: The fuel gauge indicates the contents of the tank
when the ignition switch is 'On'.
Always ascertain that the ignition is switched off before
replenishing the fuel tank.
Water Temperature Gauge: This records the temperature of
the cooling water circulating in the cylinder block and radiator.
Under normal operating conditions thisshould be 164'F. (73'C.).
Instruments and Controls
1.
2.
3.
4
Windscreen washer control.
Choke control.
Windscreenwiper control.
Ignition and lights switch.
5. Flashing direction indicator
switch.
6. Heating and demisting control.
7. Oil pressure gauge.
8. Water temperature gauge.
Starter control.
Tachometer.
Headlight beam warning light.
light.
12. Direction indicator warning
13. Speedometer.
14. Ignition warning light.
15. Fuel gauge.
16. Handbrake.
17. Gear lever.
18. Dip switch.
19. Clutch pedal.
20. Horn button.
21. Brake pedal.
22. Accelerator pedal.
23. Panel light switch.
- 9.
10.
11,
10

A.USTIN-HKALEY SPRITE INSTRUMENTS 4 CONTROLS
FOOT CONTROLS
Accelerator: The small right-hand pedal which operates the
carburetter throttle.
Brake: The centre pedal which operates the brakes on all
four wheels.
Clutch: The left-hand pedal. The foot should be kept clear of
the pedal except when engagement or disengagement of any gear
is intended, or when in heavy traffic. Press to the floor for
complete disengagement.
Dip Switch: This is located in the floor to the left of the clutch
pedal. To dip the headlight beams depress the switch. Depress
again to return them to the straight ahead position.
8'indscreen 8'iper Switch: To start the windscreenwiperspull
out the switch marked "W" on the fascia panel. To park, push
in the switch; when the wiper arms will automatically return to
the parkedposition,-
Pane/ Light Switch: Situated on the lower edge of the fascia
panel. No light will be obtained unless the sidelights are also on.
Horn Button: Mounted at the centre of the steering wheel
and can be operated when the ignition switch is 'off'.
Seats: The driver's seat is mounted on slides and is instantly
adjustable by means of the lever located at the front of the seat..
The passenger's seat is not adjustable. The backs of the seats
can be folded forward.
Crankcase Oil Fillert Incorporated in the valve rocker cover.
Bayonet fitting cap, with anchor cable to prevent loss.
HAND CONTROLS
Hand Brake: Pull-up lever type, situated between the driver' s
and passenger's seat. Operates mechanically on the rear wheels
only.
Gear Lever: Should always be in neutral when starting the
engine. The gear positions are indicated on the top of the lever
knob. Move the lever hard right (to overcome pressure of spring-
loaded stop) and then back to engagereversegear.
Choke Control: Pull the control out to its limit when starting
the engine from cold. Push in the choke control completely as
soon as the engine will run evenly without its use.
Ignition Switch: Turn the key in a clockwise direction to switch
on. Do not leave the switch 'on' when the vehicle is stationary-
the red warning light is a reminder.
Lights Switch: The cehtral moulding which surrounds the
ignition switch. Turn clockwise to the first notch.to switch on the
sidelights and to the second to switch on the headlights.
Starter Switch Knob: Pull out the control knob to start, and
release as soon as the engine fires. If the engine fails to start
after a few revolutions, do not operate the starter again until the
engine is stationary.
' Direction Indicators: To operate, move the switch to the left
. or right, according to whichever indicator is required. A warning
light on the instrument panel flashes green for as long. as the
indicators are in use.
Heater and' Demister Control: This is situated centrally
on the fascia and provides the means for regulating the heating
and demisting system. Full operating instructions are given on
page 47.
Release the extra bonnet
prop from its securing clip
'A' and insert the endin the
hole 'B' on the undersideof
the bonnet.
Bonnet lock: To release the bonnet turn the plated locking
. handle, situated behind the front number plate, in a clockwise
direction. Lift the safety catch lever (see illustration on page 46)
at the same time raising the bonnet. The bonnet is held open by
two telescopic prop rods which lock automatically in the fully ex-
tended position.
As a safety measure an extra prop is provided and should
always be used toprevent any possibility of an accident. Release
the prop from the clip at the side of the radiator and insert the
13
12

A.USTIN-HEALKY SPRITE DRIVING INSTRUCTIONS
DRIVING INSTRUCTIONS
highly stressed. Beyond all doubt the owner or operator will
find that careful, considerate treatment during the vital running-in
period will be fully compensated by the resulting dependability
and efficiency that will be obtained throughout its life.
T HE importance of running-in the new vehicle canfiot be too
Fuel Pump Priming Lever
'A' is the priming lever of
the fuel pump located on
the left side of the cylinder
block.
RUNNING-IN
The following-speedsshould not be exceeded in the gears for the
first 500 miles (800 kilometres):
1st 2nd 3rd top
715 25 40 m.p.h.
10 24 40 , 64 k.p.li.
It is most import'ant to remember that at no time during the running-
in period must the engine be overloaded, as in attempting to ascend
hills in top gear at low vehicle speed. The load should be eased by
changing down to a lower gear.
Fierce acceleration must also be avoided, and remember that the
engine should never be raced in neutral.
On completion of the first 500 miles (800 km.) the running-in speed
may be progressively increased, but full power should not be used
until at least 1,500miles (2,400 km.)havebeencovered,andeventhen
only for short periods at a time. During this mileage a slight falling-
oft in engine power may develop, in which case it is beneficial to
lightly grind-in the valves and re-set the valve clearances. No engine
or complete vehicle can be considered fully run-in until it achieves
2-3,000 miles (4-5,000 km.).
The use of upper cylinder lubricant is recommended at all times,
but most particularly during the running-in period. See page 33
for recommended brands.
STARTING
the water level in the radiator. Ensure that the gear lever is in
- neutral and the handbrake is applied. If the engine is cold pull out
the choke control.
-Switch on the ignition, ensure that the ignition warning light glows
and that the fuel gauge registers, then pull the starter control firmly.
Release it if the engine fails to start within five or six seconds, wait
for the engine to stop rotating and then pull the starter again.
Should the engine not start after a reasonable number of attempts,
check up on possible causes. Do not persist in operating the starter,
as a great strain is imposed on the battery by so doing.
As soon as the engine starts, release the starter control and warm
up the engineat a fairly fast idling speed. Should the oil gauge fail
to register any pressure or if the pressure isvery low, stop the engine
8 EFORE starting the engine check the oil level in the sump and
immediately and investigate the cause. Failure to do so may result in
serious damage to the engine. Also check that the ignition warning
light goes out when the engine is running above idling speed, as this
indicates that the dynamo is charging the battery.
A thermostat is incorporated in the cooling system to assist the
engine in warming up from cold, but do not, under any circumstances,
race the engine in an attempt to speed up the process.
Push in the choke control completely as soon as the engirie will
run evenly without its use.
When the vehicle has been out of action for several days the fuel in
the carburetter may have evaporated. In these circumstances, before
attempting to start the engine, refill the carburetter by operating the
priming lever on the fuel pump, this being located low down on the
left side of the engine.
DRIVING
pedal and moving the gear lever into the appropriate position.
Should the gear not readily engage, momentarily release the clutch
pedal, after which, with the clutch again depressed, it should be
possible to engage the gear. Gradually release the clutch pedal, at
the same time gently depressing the accelerator and releasing the
handbrake. The vehicle will move forward, gathering speed in
accordance with the amount the accelerator is depressed.
Second gear is engaged by depressing the clutch pedal, moving the
gear lever out of first into the next higher gear and then releasing
the clutch pedal. Ease up the accelerator whilst changing to a higher
gear, and gradually depress the accelerator when the higher gear is
engaged.
S TART only in first gear, which is engaged by depressing the clutch
16 17

AUSTIN-HKALEY SPRITE DRIVING INSTRUCTIONS
Third'and top gears are engaged by employing the sameprocedure
as that given for engaging second.
Changing down is an exact reversal of the method outlined for
changing up, except that the accelerator must be kept depressed
whilst the gear is being changed, in order to speed up the engine in
accordance with the lower gear.
Do not change gear rapidly or forcibly. Always move the lever
with a smooth deliberate action that will allow the synchromesh
mechanism to operate properly.
To stop the vehicle, release the accelerator, apply the footbrake
and depress the clutch pedal before the vehicle comes to a standstill.
After applying the handbrake and moving the gear lever into neutral,
release the clutch and footbrake.
%hen in reverse, which must only be engaged when the vehicle is
stationary, remember that the gearing is lower than first gear;
Consequently release the clutch slowly until the vehicle just begins to
move, and then gently depress the accelerator to give the speed
desired.
Do not slip the clutch instead of using the handbrake when tem-
porarily halted on an ascent and do not allow the weight of the foot
to be taken by the clutch pedal when it is not being used, as either
practice will result in excessive clutch wear.
Before descending a steep hill it is advisable to engage an inter-
mediate or low gear. The engine will then provide a useful braking
action.
DRIVING HINTS .
Never operate the starter control when the vehicle is in gear.
Remember to switch on the ignition before attempting to start the
engine.
Do not persist in pulling the starter control if the engine will not
fire.
Release the choke control as soon as the engine will run evenly
without its use.
Do not leave the ignition switched on when the engine is not
running.
Never leave the vehicle in gear with the handbrake unapplied.
Do not engage reverse gear when the vehicle is moving forwards
or forward gear when the vehicle is moving backwards. -,Serious
damage may result.
Avoid slipping the clutch in traffic or on an ascent.
Never coast the vehicle with a gear engaged and the clutch pedal
depressed.
A FTER the vehicle has been washed or driven through water the
results.
SKIDDING
Skidding is usually due to sudden acceleration, braking or change
of direction on an icy, greasy or loose road surface. If the rear
wheels skid, release the accelerator or brake pedal (as the case may be)
and turn the steering wheel towards the direction of the skid to regain
wheel grip on the road.
WET BRAKES
brake linings may become wet. To dry them, apply the brakes
several times with the vehicle moving slowly. Emergency braking
with wet brakes is extremely dangerous and is to be avoided at all
Do not race the engine in neutral at any time.
Never run the vehicle with the radiator completely blanked otf.
Avoid running the engine at high speeds for the first 500 miles
(800 km.).
Never fill the radiator with cold water when the engine is hot.
Do not, under any circumstances, run the engine in a closed garage
or similar restricted atmosphere. The exhaust fumes are highly
poisonous and if inhaled will quickly produce grave, if not fatal,
costs.
18 19

REGULAR A.TTENTIONSAUSTIN-HEALEY SPRITE
REGULAR ATTENTIONS
HE following is a summary of the regular attentions required to
T
necessary.
adjustment.
butor points.
necessary.
if necessary.
and the bonnet safety catch.
and manifold to recommended torque. settings.
up if necessary. Clean and tighten terminals.
springs, wheel nuts, universal joints, etc.
top-up if necessary.
maintain the Austin-Healey Sprite in perfect running order.
These instructions should be closely followed, whether the attentions
are undertaken by the operator or by the local Austin Dealer. Under
arduousconditions, as, for instance, very dusty or muddy roads and
tracks or high speeds, it vM be advisable to attend to the oiling
points more frequently than every 1,000.miles (1,600 km.).
POST DELIVERY CHECK
Dealers areunder agreement to carry out a 'Post Delivery Check'
on Austin vehicles purchased from them. This service is undertaken
once during the period of the first 500 miles or as soon as possible
afterwards. Except for materialsused, they will perform the following
operationsfreeofcharge:
(1) Change oil in the engine, gearbox and rear axle.
(2) Lubricate all chassispoints.
(3) Check and lubricate all door catches, hinges,striking plates
(4) Tighten nuts of cylinder head and valve rocker shaft brackets
(5) Check valve clearances and reset if necessary.
(6) Tighten fan' belt if necessary.
(7) Check all water pipe connections and tighten clips if necessary.
. (8) Examine and clean the carburetters and resetthe slow running
(9) Check all fuel pipe union nuts.
(10) Examine and adjust if necessary sparking plugs and distri-
(11) Check working of automatic ignition control and reset if
(12) Check front wheel alignment and steering connections, adjust
(13) Check braking system functionally, adjust and bleed if
(14) Check brake and clutch Auld reservoir and top-up if necessary.
(15) Check electrical system functionally, examine battery and top-'
(16) Check tightness of all nuts and bolts on shock absorbers,
(17) Inspect shock absorbers for leaks, examine oil levels and
(18) Check tyre pressures.
(19) Check operation of all instruments.
(20) Road test.
0
ga.
0
CJ
0
Co D
0 Q
2120

AUSTIN-HEALEY SPRITE REGULAR ATTENTIONS
DAILY
sary to the 'FULL' mark on the dipstick. The oil filler is in the
valve rocker cover and the dipstick is on the right side of the
engine.
After adding oil, allow a few seconds to elapse for the oil to
reach the sump from the valverocker cover before checking the
Radiator: Check the level of water in the radiator and top-up
if necessary. Fill to the bottom of the filler cap well, when the
engine is cold.
' X.B.— Do not remove the filler cap if the coolant temperature
is above boiling point or if the engine is running.
Engine: Check the level of oil in the sump and top-up if neces-
Gearbox Oil Filler Plug
1. Filler plug.
2. Rubber cover.
Access.
level.
WEEKLY
infiate, if necessary, to the recommended pressures. Ensure the
valves are fitted with screw caps and inspect the tyres for possible
damage and wipe off any oil or grease. See page 50 for correct
pressures.
EVERY 1,000 MILES (1,600 km.)
the filler plug, turn back the rubber fioor covering and remove
the rubber plug from the left side of the gearbox covering.
Remove the filler plug and fill up to the bottom of the threads.
This gives the correct level.
Tyrest Check all tyre pressures, using a tyre gauge and Rear Axle: Check the level and top-up if necessary. The
filler plug is located on the rear side of the axle and also serves
as an oil level indicator.
After topping-up allow time for any surplus oil to run out
should too much have been injected. This is most important
as if the axle is overfilled, the lubricant may leak through to the
brake linings and lessen their efficiency.
Brakes: Apply an oil gun to the brake balance lever nipple on the
rear axle, and to the handbrake cablenipple located just forward
of the rear axle.
Gearbox.'Check the level and top-up if'necessary. To reach
Rear Axle and Rear
Universal Joint.
Radiator Header Tank and
Theengine coolingsystemis
sealed and pressurised and
for this reason the radiator
jiller cap should never,
under any circumstances, be
removed when the coolant
is above boiling point or
the engine is running.
Filler Cap.
' "J
1. Combined oil filler and
level plug.
2. Drain plug.
3. Propeller shaft rear uni-
versal joint nipple.
!
' A'8.l A,
22

AUSTIN-HKALEY SPRITE REGULAR ATTENTIONS
Oiling Points.
Rear Brake Balance Lever
Front Suspension and Tie
1.Shock absorberfiller
plug.
2. Swivel axle pin upper
bush.
3. Swivel axle pin lower
bush.~
4. Tie rod balljoint.
5. Suspension lowerfulcrum
pin.
Rod Oiling Points.
1.L.H. pull rodjoint pin.
2. Balance lever nipple.
3. R.H.pull rodjoint pin.
4. Balance lever arm joint
pin.
Front Suspension: Apply an oil gun to the lower arm joints
where they meet the swivel axle housing.
SwivelAxle Pins: Apply an oil gun to the two nipples on each
swivel axle. This is best done when the vehicle is partly jacked
up, as the oil is then able to penetrate properly around the
bushes.
Steering Connections: Apply an oil gun to the nipple on each
tie-rod ba!1 joint.
Propeller Shaft Universal Joints: Apply an oil gun to the uni-
versal joint nipple at each end of the propeller shaft. If necessary,
move the vehicle to obtain access to the nipples.
Propeller Shaft Front
Universal Joint Nipple.
Lift the fioor covering and
remove therabber plug tn
the propeller shaft tunnel to
gain access totheoil nipple
Brake and Clutch Fluid
1. Reservoir filler opening.
Top up to the bottom of
the filler plug threads.
2. Clutch pedal linkage oil-
ing point,
-3. Brake pedal linkage oil-
ing point.
Reservoir.
Handbrake Cable Nipple.
'A' indicates the position of
the cable grease nipple.
24 25

REGULAR ATTENTIONS
AUSTIN-HEALEY SPRITE
EVERY 3,000 MILES (4,800 km.)
Throttle Linkage.
Apply a few drops of oil to
each of the linkage joints
indicated.
Engine: Drain the oil in the engine smnp while it is warm
(i.e. immediately after using the vehicle) and refill with new oil
to the 'FULL' mark on the dipstick. The drain plug is located
at the rear right-hand extremity of the sump and care should
be taken to ensure that no dirt or grit enters the smnp when
replacing the plug. Capacity is 6 pints (3.41 litres).
Bonnet Lock: Apply a few drops of engine oil to the bonnet
locg and safety catch.
Fan Belt: Check the adjustment of the fan belt. It should be
sufliciently tight to prevent slip at the generator and water
pump, yet at the same time it should be possible to move it
laterally about 1 inch (2.54 cm.).
To make any necessary adjustment slacken the bolts and
raise or lower the generator until' the desired tension of the
belt is obtained. Then securely lock the generator in that
position.
Distributor Spindle: Lubricate the distributor bearings by
withdrawing the moulded rotating arm from the top of the
distributor spindle and carefully adding a few drops of oil round
the screwexposed toview. Seepage 33 for recommended oils.
Take care to refit the arm correctly by pushing it on to the shaft
and turning until the key is properly located.
Distributor Came Apply a trace of engine oil to the distributor
cam. Be careful not to let any oil or dirt reach the contact
breaker points.
- Distributor Automatic Advance: Remove the distributor cap
and add a few drops of engine oil through the hole in the contact
breaker base through which the cam passes.
8'jteelst Change over the wheels diagonally (including the
spare wheel) in order to obtain maximum service with even
wear from each tyre.
Shock Absorberst Ensure that there are no visible signs of
leakage and that the rubber bushes of the shock absorbers
arms are undamaged.
Control Linkages: With an oil can, oil all the brake, clutch
and throttle linkage joints.
Brakes: Inspect the hydraulic fluid lines and Qexible hoses.
Brake and Clutch Fluid Reservoir: Ascertain that the fluid
level in the supply reservoir, mounted on the steering side of the
engine compartment, is up to the bottom of the fiiier plug
threads. Top-up if necessary using only the recommended
Quid.
Carbttretterst Remove the suction chamber cap and 'damper
assembly on each carburetter and replenish the reservoir with
S.A.E. 20 oil as necessary.
Battery: Ascertain the state of charge of the battery by taking
hydrometer readings.
Check 'that the electrolyte in the cells is level with the top
of the separators. If necessaryadd a few drops of distilled water.
Never use tap water as it contains impurities detrimental to the
battery.
Never leave the battery in a discharged condition. If the
vehicle is to be out of use for any length of time, have the
battery removed and chargedonce a fortnight.
8"jteelst Check the security of the wheel nuts and tighten them
if necessary.
lan Belt Adjustment
I. Dynamo hinge bolts.
'2. Adjusting link nut.
3. Adj usting link setpin.
EVERY 2,000 MILES (3,200 km.)
Carry out the 1,000mile (1,600 km.) service.
26 27

AUSTIN-HKALKY SPRITE REGULAR ATTENTIONS
Brakes: Check the brakes and adjust if necessary.
Contact Breaker Points: Clean the contact breaker points.
Cleaning of the contacts is made easier if the contact breaker
lever carrying the moving contact is removed. Before replacing,
smear the pivot on which the contact breaker operates with
engine oil.
Check and reset the contact breaker points to the correct gap
of .014 to .016 in. (.36 to .41 mm.) (see page 43).
EVERY 4,000 MILES (6,400 km.)
EVERY 5,000 MILES (8,000 km.}
addition:
EVERY 6,000 MILES (9,600km.)
vehicle) and refill to the level of the filler plug with new oil.
Capacity 2$ pints (1.33 litres).
Rear Axle: Drain when the oil is warm, and refill to the level
of the filler plug opening with new oil. Capacity 1 f pints (1.00
litre).
Engine Oil Filter: At the same time as the engine oil is changed,
drain the full-flow filter and renew the filter element, not for-
getting to top-up the filter container with new oil before refitting
it to the head casting on the engine crankcase (see page 38).
N.B.: On no account must this attention be neglected as it is
essential that the oil filter does not become clogged with dirt.
Carry out the 1,000 mile (1,600 km.) service.
Carry out the 1,000 mile (1,600km.) service with the following
Sparking Plugs: Remove the plugs and clean off all carbon
deposit from the electrodes, insulators and plug threads.
Re-set the plug points to the correct gap of .025 in. (.64 mm.)
Shock Absorbers:Check the flmd level, andtop-up if necessary.
The correct level is just below the filler plug threads (seepage 33
for recommended fiuid). Carefully clear away all road dirt and
grit from the vicinity of the filler plugs before removal.
N.B.— Wheretherecommended fluid isnot available the follow-
ing are acceptable alternatives:-
Shell Donax A.2, Wakefields Castrolite, Mobiloil Arctic, Esso
Hydraulic (Medium), Duckham's N.P.20, B.P.EnergolS.A.E.20.
Fr'ont Wheel Alignment: Check the alignment of the front
wheels. This is correct when there is r's to 3 in. (1.6 to 3.2mm.)
toe-in.
Ignition Timing: Check the setting and adjust if necessary.
Water Pump:Remove the oiling plug on the water pump casing
and add a small quantity of SAE 140 oil. The oiling of the
pump must be doneverysparingly otherwiseoil will flow past the
bearings on to the face of the carbon sealing ring and impair
its efficiency.
Front Road Whee/ Hubs: Remove the wheel, lever out the
hub cap with a screw-driver, and recharge with grease. It is
important that the hubs are not overgreased, due to the fact that
any surplus may find itsways to the brake linings, thusreducing
their efficiency.
Air Cleaners: The air cleaners should be removed, cleaned and
re-oiled. Swill each cleaner in petrol, drain, immerse in engine
oil and again drain before refitting.
Valve Clearance Adjustment: Check the rocker clearances and
adjust if necessary. The correct clearance is .012 in. (.31 mm.)
with the engine hot.
Fuel Pump: Clean the fuel pump filter and sediment chamber.
See page 39.
Gearbox: Drain when the oil is warm (i.e. after using the
Valve.Clearance
Adj ustment
1.Screwdriver blade.
2. Adjusting screw.
3. Locknut.
4 .012in. (.31mm.)feeler
3~4
Water Pump Oiling Plug.
'A' indicates the position of
the plug on the water pump
body.
gauge.
H30.108.B.
29
28

RKGI.Z AR ATTENTIONSAI.JSTIN-HEALEY SPRITE
EVERY 7,000 MILES (11,200 km.)
EVERY 8,000 MILES (12,800 km.)
EVERY 9,000 MILES (14,400 km.)
EVERY 10,000 MILES (16,000 km.)
Carbtsretters: The flow of fuel at each carburetter inlet t
each float chamber should be checked and if necessary the filter
in the unions should be cleaned.
Remove the bowl of the carburetter for cleaning by disconnect
ing the fuel supply pipe and slackening the lid retaining nui
Unscrew the chamber holding-up bolt, being careful to note th
positions of the brassand fibre washers, and then take off the lid
Do not lose the float needle.
In addition, clean out each suction chamber assembly b
removing the three securing screws and lifting off the body it
the same planeto avoid damage to the needle.
Lift out the hydraulic damper and wash theassembly in petrol
Dry thoroughly, refit and replenish the damper with oil. Wher
fully re-assembled lift the piston to its fullest extent, thus ex.
pelling surplus oil which lubricates thepiston rod andeventuall>
finds its way into the induction pipe.
This is the only part which reqmres lubrication, the piston
itself and the inside of the suction chamber should be left dry.
Bodyworkt With an oil can, lubricate the door locks and
hinges, and other moving joints on the bodywork.
Genera/: Examine and tighten if necessary, all nuts, bolts,
unions, connections and linkage joints, especially after the
vehicle has completed its first 6,000 miles (9,600 km.).
Carry out the 1,000.mile (1,600 km.) service.
Carry out th: 1,000 mile (1,600 km.) s:rvice.
Carry out the 3,000 mile (2,800 km.) service.
Carry out the 1 000 mile (1,600 km.) service with the follow-
ing additions:
Sparking Plugs: Renew the sparking plugs. Use only Cham-
pion N5 Long Reach Plugs.
EVERY 11,000 MILES (17,600 km.)
EVERY 12,000 MILES (19,200 km.)
with the instructions given on page 45. Normally this operation
is carried out twice annually upon the addition and removal
of anti-freeze. In countries where- anti-freeze is not required,
however, the coolingsystemshould be flushed out every 12,000
miles (19,200km.).
grease.
Generator Bearing,
Unscrew the lab>icator cap
'A' and re~lenish with
Speedometer and Tachometer Drives: Disconnect the cable from
the instrument end and pull the inner member out of the casing.
This should be lubricated sparingly by smearing it with light
grease. It is important that the drive is not overlubricated, other-
wise damage will be caused to the instrument head should the
lubricant find its way in to the head.
To re-assemble, thread the cable with a twisting movement
into the casing, since this will help the cable to engageeasily
with its union at the drive end. When this engagement is felt
the cable can be pushed home so that the square end stands
out approximately s3inch (9.63mm.) from the casing.
Generator Bearing: Unscrew the cap of the lubricator on
the side of the bearing housing, lift out the felt pad and spring
Steering Rack Oil Nipple.
'A' indicates the position of
the rack oil nipple.
Carry out the 1,000 mile (1,600 km.) service,
Cooling System: Flush out the cooling system in accordance
30 31

AUSTIN-HKALKY SPRITE REGUI AR ATTENTIONS
and approximately half-fill the lubricator cap with a recom-
mended grease (seepage33). Replace the spring and felt pad
and screw the lubricator cap back into position.
Oil Sump: Drain the oil, remove the sump, and clean it
throughly in petrol. Also clean the oil pump strainer gauze.
Replace thesump and refill with new oil.
Front and Rear Hub Bearings: Check for signs of wear.
Starter Commutator: Clean and check condition and freedom
of brusheS in their holders.
Steering: An oil nipple provided at the left-hand side of the
rack housing (right-hand side on L.H.D. vehicles) is accessible
when the bonnet is raised. Replenish the rack housing via this
nipple with S.A.E. 90 hypoid oil. Give 10 strokes of the oil gun
only.
Decarbonising and Valve Grinding: This attention may not be
needed so frequently on vehicles used for long journeys. As a
general guide, a falling off in engine)power indicates when
decarbonizing is due.
Headlamp Beam Setting. The headlamp beam settings should
be checked andre-set if necessary,every12,000miles (19,200km.)
or at least once a year.
Checking and adjustment (see page 52) may well be under-
taken when the thinner engine oil and anti-freeze is introduced
in preparation for. winter service.
EVERY 24,000 MILES (38,400 km.)
0I
z
O~
Ao
Ãa
O
CI
l5
HM
cp
Q
Cl I
0 ca
a0
CI
0
v
ca
0 •
He
8A
Ao
Cl
CI at
O
0 CC
CC
CI
CI
C
NO™
v
Cl
I
ao
0
OO
MI
pO
Q Q
N4
O
0
v
0Iat
Cl
O~
Ao
CI
Cl
CI
0
0
Hot
g'o
'0 0
aaeo
H
O
O
v
8
0
00
Cl
QICI
Ao
+ O
Hat
ao
ca'It
5O
A00
cd
a
M Irc
aIlc
Ia
g4I
Ao
0 0
a o
CI
0 Q
O
0 tc
CI
ac
CI
CI
CI
0at
IQ
acp,
aO
I
at
Mg
CI 0
e H
H 0'
al Q
Q
4 0
00
a
I
v
0
O
a
Q
al
0
0
MO
V ad
O'Oa
a Cl 4
Q 0
0
Add
cc
General Check: The vehicle should be subjected to a thorough
examination for wear at; least every 24,000 miles. Particular
attention should be given lo the steering gear and tie rod ball
joints, front and rear suspensions, brake linkages, shoe linings,
fluid lines and flexible hoses, propeller shaft universals and wheel
hub bearings.
CI
a
0+
ad OO
claI
OO
00
pO
cl OI
CI
<M'
000OI
atM
Hoo
aI (
4)
CI
ZI
CI Cd
CI
o III
aI
K~
~sH
CI
0 0 Cl
HX pO
pal
e IHcc Io 0
e OO oH
III V
0
0 IHg
aI at ca
IC0Ie
v4
Q4cd
0 0
aC
o3
v
ICIIR
00
+
o ace
H o
a 4 'O M
acco
a
0ac tr
Qa
+O
0
0
OOV
CdCC O
0
Id>v
WCC
II
V
CO
ac
CI
CC 0
I
0v
041
al
0
0
0
I' g S gt
QQ4H
H g
00'4 V ac
H .al
4Q 4QI e
Cl 0
e 0 ca ~
HX..v
aa
Pl 4 aaae0
VcI
aa
R
00 Cl aa 0 0 rt.
32 - 33

REGULAR ATTENTIONSAUSTIN-HEALEY SPRITE
Page
No.
REGULAR ATTENTIONS
c
DAILY
Oil Engine sump. Check oil level and top-up
if necessary 22C
1,000 MILES (1,600 km.)
Oil B
I,C D
Oil
Oil Can
Oil Can
Oil Gun
Examine
D
Gearbox and rear axle. Check oil levels
and top-up if necessary
Propeller shaft universal joints
Swivel axles and suspension lower joints
Steering tie rod ball joints
Rear brake cable and balance lever
Brake, clutch and throttle linkage joints
Carburetter damper assembly reservoirs
with S.A.E.20 oil.
Brake and clutch 'Cud reservoir level.
Top-up if necessary
Shockabsorbers. Check for leakage
3,000 MILES (5,000 km.)
Engine sump. Drain and refill
Distributor
22 23
24
24
24
23
26
26
26
27
6,000 MILES (10,000 km.)
III Oil
Grease
Examine
K
HGearbox and rear axle. Drain and refill.
Water pump
Front hubs
Shock absorbers. Check levels and top-
up if necessary 29
28
29'
29
Ci( 12,000 MILES (20,000 km.)
Oil Gun
D
Grease
Lubricate steering rack with S.A.E. 90
Hypoid oil
Generator bearing. Replenish lubricator
cap with grease .. 31
32
AS.46.A.
35

AUSTIN-HEALEY SPRITE GENERAL MAINTENANCE
GENERAL MAINTKNANCK
'/HE following information covers those attentions which are
should be used.
essential to the efficient operation of the vehicle, and is additional
to or more detailed than that given in 'Regular Attentions'.
ENGINE
to the engine, which may have to operate at sustained high
temperatures and speeds,and it is therefore essential that only
oils of the highest quality and correct grade are used. Inferior
oils will cause excessivewear in an unduly short time.
The colour or appearance of an oil at atmospheric tem-
peratures gives no indication as to its efficiency under operating
conditions and owners are advised to use the officially recom-
mended lubricants as listed on page 33. It is appreciated that
in some areas these oils are not available, in which case, only
good quality oils conforming with the S.A E. numbers listed
The letters S.A.E. followed by a number constitute a classifi-
cation of the lubricant in terms of viscosity or fluidity.
For instance, a low S.A.E. number indicates that the oil is of
low viscosity, which means that it flows more readily than oil
with a high viscosity rating.
lt will be appreciated, therefore, that oil with a low S.A.E.
number is essential if easy starting is to be obtained in cold
weather, whereas in hot weather a high viscosity oil is desirable
in order to keep oil consumption within normal limits.
The use of upper cylinder lubricant is recommended at all
times, but most particularly during the running-in period. See
page 33 for recommended brands.
Even the best oils in the engine become contaminated during
use, with unburnt fuel, carbon, metallic particles, and moisture,
and it is therefore most important that the oil is changed at the
recommended mileages.
Multigrade Motor Oils: In addition to the recommended
lubricants listed on page 33, we approve the use of multigrade
oils, as producedby the oil companiesshown on our list, for all
climatic temperatures unless the engine is old and in poor
mechanical condition. Some are more expensive than the recom-
mended motor oils because of their special properties and
greater fluidity at low temperatures.
Oil Level: The oil should never be allowed to fall more than
—',in. (12.7mm.) from the 'FULL' mark on the dipstick. It
is advisable to wipe the dipstick before taking the reading, which
must only be taken when the engine is stationary and the vehicle
on level ground if a true result is to be obtained.
Lubrication: Correct lubrication is of the utmost importance
R~
~%I L. gj
PJ
IS
1
~~R
CS ~ Cu
bp
00 0
CJ
8
Q ct pP
'Cl
37

GENERAL MAINTENANCE
AIJSTIN-HFALEY SPRITE
reaches the bearings at. a reduced pressure of approximately
35 lbs. per sq. in (2.46 kg./cm.'). Therefore, to ensure only
filtered oil is supplied to the bearings it is essential to renew the
filter element at 6,000 miles (10,000 km.) or when the oil pressure
gauge indicates the change is necessary by a fall in pressure.
Rertewing Filter Element: First drain the filter by removing the
centre fixing bolt from the base of the container. With the bolt
removed it will be necessary to support the container by hand
until all the oil has drained away. Withdraw the container com-
plete with the element. Slide out the filter element and, using a
non-fluffy cloth, thoroughly clean out the container internally and
externally. Insert a new element in the container, and holding
the centre fixing bolt in position against the bottom of the
container, fill with new oil. Now, still holding the bolt in this
position, locate it in the filter head casting and tighten just
sufficiently to make an oil tight joint.
This is the only attention likely to be required. The filter con-
tainer should not be removed or drained, once a new element has
been fitted, until element renewal is required.
Oil Pressure:The oil pressure gaugeindicates whetherthe oiling
system is working properly. It should be looked at occasionally
while the engine is running.
The engine oil pressure may rise to over 60 lbs. per sq. in. (4.2
kg./cm.') when the engineis first started up in cold weather, but
after theoil hascirculated and becomewarmthepressurewill drop
to 60 lbs. per sq. in. (4.2 kg./cm.') with a proportionately lower
idlingpressure.
Never run the engine if the gaugefails to register a pressure or
if the prbssure is very low. Switch off and investigate the causeof
the failure as otherwise serious damage might result.
Full Flow Filter: Before reaching the engine bearings the oil is
passed through a full flow filter at a controlled pressure of
approximately 60 lbs. per sq. in. (4.2 kg./cm.'). Some pressure
is lost in passing the oil through the filter element and this pressure
loss will become more pronounced as the element becomes
coated by foreign matter removed from the oil.
A balance valve is provided in the filter unit to guard against
the possibility of the filter becoming completely choked and
thereby preventing the oil from reaching the bearings. This
balance valve is set to open when there is a pressure difference
between the oil on the inside and the oil on the outside of the
filter element of 15 lbs. per sq. in. (1.06 kg./cm.'). When the
valve is open, un-filtered oil by-passes the filter element and
FUEL SYSTEM
FUEL is stored in a rear mounted tank of 6 gallons (27 litres)
capacity. An A.C. mechanical'Y' type fuel pump, operated by
the enginecamshaft, draws fuel from the tank and delivers it under
pressure to two S.U. type H.l carburetters. Twin 'pancake'
type air cleaners filter the air to the carburetter intakes.
Fuel Pump: This is bolted on the left-hand forward side of the
engine crankcase and has a suction pipe from the tank and an
outlet pipe to the carburetters. A priming lever is fitted to
enable the carburetters to be primed by hand, should the fioat
chambers become dry due to evaporation. If petrol appears to
be leaking from the edge of the pump diaphragm, tighten the
covers screws alternately. Sometimes such leakage may actually '
come from one of the pipe unions causing the fuel to run down
to the pump and collect around the diaphragm flange.
The pump filter should be examined and cleaned if necessary.
Access to it is gained by removing the dome cover, after un-
screwing the retaining screw, when the filter gauze itself may be
lifted off its seating. Clean out the sediment chamber and clean
the filter gauzeinan air jet or petrol. The gasketunder the filter
cover should be replaced if broken or if it has hardened.
When refitting the cover, make certain that the fibre washer is
replaced under the head of the screw. Tighten the filter cover
retaining screw just sufficiently to make a fuel tight joint.
Engine Details.
1. Oil level dipstick.
2. Oil Jilter securing bolt.
3. Distributor micrometer
adjuster.
39
38
