PEUGEOT 106 2001 User manual

14151617
19
2022 2123
24
YOUR 106 AT A GLANCE
2
18
1 2 3 4 5 6 7 9 10 11 12 13
8
18
06-05-2002

YOUR 106 AT A GLANCE
3
1-Side windows demisting vents
2-Windscreen demisting vents
3-Passenger airbag
4-Adjustable centre vents
5-Radio cassette player or spare
6-Headlamp height adjustment
7-Interior alarm protection disarm button
8-Lights, fog lamps and horn stalk
9-Instrument panel lighting rheostat
10-Steering wheel with AIR BAG
11-Windscreen wash/wipe stalk
12-Ignition,ignition lock and engine immobiliser
13-Electric mirrors switch
14-Storage compartment
15-Controls for:
•Air conditioning or left-hand heated seat
•Lighter
•Hazard warning lights
•Rear screen and mirrors demisting
•Air recirculation or right-hand heated seat
16-Gear lever
17-Handbrake
18-Electric window switches
19-Passenger airbag disarming switch
20-Ashtray
21-Glove box
22-Adjustable side vent
23-Fuse box
24-Bonnet opening control
06-05-2002

YOUR 106 AT A GLANCE
4
The remote control
Asingle press on button Alocks the
doors and boot or tailgate.
Asingle press on button Bunlocks
the vehicle.
Key
The key switches on the ignition,
locks and unlocks the doors, tailga-
te, fuel filler flap and disarms the
passenger airbag.
Keep your key number
in a safe place.
This will enable you to
obtain a new key if it is lost or
stolen.
60 LOCKING AND
UNLOCKING
AB
06-05-2002

YOUR 106 AT A GLANCE
5
ENGINE
IMMOBILISER
This locks the engine control sys-
tem and therefore prevents starting
of the vehicle by anyone who does
not have the key.
Operation
Each key has a special code.
When the ignition is switched on
the key code is recognised by the
engine immobiliser system and
starting is possible.
The engine immobiliser automati-
cally locks the engine control sys-
tem a few moments after the igni-
tion has been switched off.
Confidential card
This shows the identification code
which is required if any work is car-
ried out on the system by your
PEUGEOT dealer. This code is hid-
den by a film which must not be
removed unless required.
Keep your card in a safe place,
never in your vehicle.
When buying a second-
hand car:
-Make sure that you are given
the confidential card.
-It is advisable to have the key
codes memorised by your
PEUGEOT dealer in order to
ensure that the keys in your
possession are the only ones
which can start the vehicle.
57
06-05-2002

SEATS WITH MANUAL
CONTROLS
1.Forwards-backwards adjustment.
2.Seat back angle adjustment.
3.Access to rear seats (3 door).
For models fitted with air conditio-
ning, the storage compartment for
the handbook and maintenance
guide is under the passenger seat.
FRONT AND SIDE
AIRBAGS
Disarming the passenger airbag.
Insert the ignition key in switch 1
and turn it:
–tothe «ON» position, the pas-
senger airbag is armed,
–to the «OFF» position, the pas-
senger airbag is not armed.
Operational Check
This is by means of the warning light
on the instrument panel.
If the passenger airbag is armed or
if your vehicle is not fitted with a
passenger airbag, the warning light
comes on for 6 seconds when the
ignition is switched on.
If the passenger airbag is not
armed, the warning light remains
on.
Always contact your PEUGEOT
dealer if the warning light flashes.
Passenger airbag precautions
For a vehicle fitted with a disarming
switch: -disarm the air-
bag if you ins-
tall a rear-
wards-facing
child seat,
-armthe airbag
when an adult
is in the seat.
For a vehicle not fitted with a disar-
ming switch: -do not install
rear-wards-
facing child
seats on the
front passen-
ger seat.
Never place your feet or any object
on the fascia.
YOUR 106 AT A GLANCE
6
50
2 3
13
1
71
06-05-2002

Off
Intermittent or continuous wipe
Windscreen wash
Fog lamps off
Front fog lamps on
Front/rear fog lamps on
LIGHTING - HORN
Ring A
Lighting controls
Lights off
Side lights
Rear fog lamp off
Rear fog lamp on
Dipped/
main beam lights
Ring B
Rear fog lamp control
Front/rear fog lamps control
FRONT AND REAR
WINDSCREEN WIPER
Front
3- High speed wipe
2- Normal speed wipe
1- Intermittent wipe
0- Stop
4- Single wipe
Pulling the stalk towards you
washes the windscreen with timed
sweep, and headlamp wash if
headlamps are on.
YOUR 106 AT A GLANCE
7
A
B
62 63
32
1
0
4
Rear
06-05-2002

1 - Air flow adjustment
2 - Air distribution
To the central and
side vents
Footwells
Windscreens, side screens
and footwells
Windscreen and side
windows
3 -Temperature control
4 - Air conditioning
on/off
5 - Interior air
recirculation
YOUR 106 AT A GLANCE
8
EXTERIOR MIRRORS
Manual adjustment
-
Adjust the position using the lever 1.
Electric adjustment:
-Using the two-way switch 2,
select the left-hand or right-hand
mirror, then adjust its position
using button 3.
-Return the two-way switch 2to
the central position.
Demisting of the mirrors is
linked to the rear screen
demisting control.
HEATING/AIR CONDITIONING
65 47
3
24
1
1
2
3
5
06-05-2002

YOUR 106 AT A GLANCE
9
PEUGEOT SERVICING
Your vehicle benefits from extended service intervals:
• Every 20 000 miles (30 000km) or every 2 years for petrol engines.
• Every 10 000 miles (15 000km) or every 2 years for indirect injection diesel engines.
The extension of the service intervals means that the engine oil level must be checked regularly; topping up of
the oil between oil changes is normal.
It is for this reason, and for your complete peace of mind, that your Peugeot dealer will carry out a levels check
and top-up midway between each routine service, at the time or distance intervals specified. This will be
undertaken free of charge, provided that the maintenance of your vehicle has been carried out within the
Peugeot network. At the same time, your Peugeot dealer will offer you a Peugeot Safety Check, for a nominal
fee. A Peugeot professional will carry out a quick check and will top up the levels if necessary (oil up to 1 litre,
coolant and screen wash).
If the oil level is too low, there is a risk of serious damage to the engine: check the engine oil level at least every
1,500 miles (2,500km), depending on the conditions of use.
The date of the intermediate visit is not shown by the service indicator. It is to be carried out at least every
10 000 miles (15 000km) for petrol engines and every 5 000 miles (7 500km) for indirect injection diesel engines.
The extended service intervals have been made possible by technical modifications to the vehicles and lubricants:
THUS IT IS ESSENTIAL TO USE ONLY ENGINE LUBRICANTS WHICH ARE APPROVED AND RECOMMENDED BY
THE MANUFACTURER.
06-05-2002

PEUGEOT MAINTENANCE
10
SPECIAL FEATURES
Some of your vehicle’s vital components have specific servicing schedules.
The airbags and the pretensioning seat belts must be replaced every 10 years.
The brake fluid must be replaced every 40 000 miles (60 000 km) or every 2 years.
The pollen filter must be checked during each regular service at the PEUGEOT dealer.
Timing belt replacement: consult a PEUGEOT dealer.
Note: the coolant does not need to be changed.
Arduous conditions of use
If the vehicle is used in certain particularly arduous conditions:
•Continuous door-to-door use.
• Town use (e.g. taxi).
•Repeated short journeys, with the engine cold in low temperatures.
Or in long stays in the following conditions:
•Hot countries with temperatures often above 30° C.
•Cold countries with temperatures often below minus 15° C.
•Countries with a dusty atmosphere.
•Countries whose lubricants or fuels do not conform to our recommendations.
It is necessary to follow an ‘Arduous conditions’ service schedule, which includes special operations and shorter ser-
vice intervals:
•Every 12 000 miles (20 000 km) or every year for petrol vehicles.
•Every 6 000 miles (10 000 km) or every year for indirect injection diesel vehicles.
06-05-2002

PEUGEOT MAINTENANCE
11
SERVICE LEVELS
Each vehicle has its own servicing cycle, based upon the engine type.
This cycle consists in alternating 3 types of service A, B and C, intermediate visits, and a few additional operations
depending on your vehicle; these correspond to key stages in the life of your 106.
Your dealer will advise you of the type and content of the next service due, when the first service is carried out
and at each subsequent service.
1st service at
6 000 miles* (10 000 km)
or 6 months*
This is necessary
in order to benefit
from the warranty.
THE MAINTENANCE CYCLE FOR YOUR PETROL 106
Service every 20 000 miles (30 000 km) or 2 years
AA
CC
Intermediate top-up visit incorporated in the fixed services.
* Whichever comes first
Brake fluid replacement every 2 years or every 40 000 miles (60 000 km).
These services are carried out with synthetic based oil; Fuel Economy oil or synthetic oil may also be used.
20 000 (30 000)/ 40 000 (60 000)/ 60 000 (90 000)/ 80 000 (120 000)/
100 000 (150 000) 120 000 (180 000) 140 000 (210 000) 160 000 (240 000)
MILES (KM)
06-05-2002
