AVMATRIX PVS0613U User manual

PORTABLE 6 CHANNEL MULTI-FORMAT
STREAMING VIDEO SWITCHER

USING THE UNIT SAFELY
Before using this unit, please read below warning and precautions which provide important information
concerning the proper operation of the unit. Besides, to assure that you have gained a good grasp of
every feature of your new unit, read below manual. This manual should be saved and kept on hand for
further convenient reference.
Warning And Cautions
※To avoid falling or damage, please do not place this unit on an unstable cart, stand, or table.
※Operate unit only on the specified supply voltage.
※Disconnect power cord by connector only. Do not pull on cable portion.
※Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord can cause fire or
electrical shock hazards. Regularly check power cord for excessive wear or damage to avoid possible fire
/ electrical hazards.
※Ensure unit is properly grounded at all times to prevent electrical shock hazard.
※Do not operate unit in hazardous or potentially explosive atmospheres. Doing so could result in fire,
explosion, or other dangerous results.
※Do not use this unit in or near water.
※Do not allow liquids, metal pieces, or other foreign materials to enter the unit.
※Handle with care to avoid shocks in transit. Shocks may cause malfunction. When you need to
transport the unit, use the original packing materials or alternate adequate packing.
※Do not remove covers, panels, casing, or access circuitry with power applied to the unit! Turn power off
and disconnect power cord prior to removal. Internal servicing / adjustment of unit should only be
performed by qualified personnel.
※Turn off the unit if an abnormality or malfunction occurs. Disconnect everything before moving the unit.
Note: due to constant effort to improve products and product features, specifications may change without
notice.

1
CONTENTS
1. BRIEF INTRODUCTION...............................................................................................................................2
1.1. Overview...................................................................................................................................................... 2
1.2. Main Features............................................................................................................................................. 2
2. INTERFACES................................................................................................................................................. 2
2.1. Rear Interfaces............................................................................................................................................3
2.2. Tally PIN Definition.....................................................................................................................................3
3. SPECIFICATION............................................................................................................................................4
4. FRONT CONTROL PANEL..........................................................................................................................5
5. OPERATION INSTRUCTION...................................................................................................................... 6
5.1. Multiview Output Layout............................................................................................................................ 6
5.2. PGM PVW Switching................................................................................................................................. 7
5.2.1. PGM, PVW Channel Selection..............................................................................................................7
5.3. Transition Control....................................................................................................................................... 8
5.3.1. FTB (Fade to Black)................................................................................................................................8
5.4. Transition Effects........................................................................................................................................ 8
5.4.1. MIX Transition..........................................................................................................................................8
5.4.2. WIPE Transition.......................................................................................................................................9
5.4.3. FADE Transition...................................................................................................................................... 9
5.5. Audio Mixer Setting.................................................................................................................................... 9
5.5.1. Audio Description.................................................................................................................................... 9
5.6. UVC Live Streaming...................................................................................................................................9
6. MENU SETTING.......................................................................................................................................... 10
6.1. SDI PGM/ AUX and Multiview Output Format..................................................................................... 10
6.2. Audio Setting............................................................................................................................................. 10
6.2.1. Mixing Mode...........................................................................................................................................10
6.2.2. AFV Mode...............................................................................................................................................10
6.3. PIP Mode................................................................................................................................................... 11
6.4. Main Menu Setting....................................................................................................................................11
6.4.1. System Settings.....................................................................................................................................11
6.5. Network Settings.......................................................................................................................................12
6.5.1. Network...................................................................................................................................................12
6.5.2. NetMask..................................................................................................................................................12
6.5.3. GateWay.................................................................................................................................................12

2
1. BRIEF INTRODUCTION
1.1. Overview
PVS0613U is an all-in-one 6-channel video switcher that allows video switching, audio mixing, and
different transition effects. Inputs signal is auto-detected while for PGM output can be scaled, which can
be compatible with more different equipment for more flexible application. The unit also allows stream
performances and presentations easily through a computer’s USB3.0 port. And it integrated a 13.3-inch
Full HD LCD monitor which can be used in wide variety of venues for events, seminars, etc.
1.2. Main Features
Portable All-In-One design with 13.3 inch FHD LCD display
6 channel inputs:4×SDI & 2×HDMI inputs
2×SDI & 1×HDMI PGM outputs, 1×SDI & 1×HDMI multiview output
1×SDI AUX output, can be selected as PGM or PVW
UVC live streaming via USB 3.0 port.
Multi-format support, input format auto-detected and PGM outputs select-able
T-Bar/ AUTO/ CUT transitions
Mix/ Fade/ Wipe transition effects
PIP mode size and position adjustable
Audio mixing
GPIO for Tally, LAN for update
FTB for emergency
2. INTERFACES

3
2.1. Rear Interfaces
1
GPIO (for tally)
8
HDMI PGM OUT
2
AUDIO IN
9
HDMI & SDI MULTIVEW OUT
3
3.5mm AUDIO IN/ OUT
10
SDI PGM OUT
4
SDI AUX OUT
11
SDI IN
5
Power Switch
12
HDMI IN
6
LAN (for update)
13
DC 12V
7
AUDIO OUT
14
USB OUT (for live streaming)
2.2. Tally PIN Definition
PIN
Definition
PIN
Definition
PIN
Definition
11
PGM-IN1
12
PGM-IN2
13
PGM-IN3
14
PGM-IN4
15
PGM-IN5
3
PGM-IN6
6
PVW-IN1
7
PVW-IN2
8
PVW-IN3
9
PVW-IN4
10
PVW-IN5
4
PVW-IN6
5
GND

4
3. SPECIFICATION
LCD Display
Size
13.3 inch
Resolution
1920×1080
Inputs
Video Inputs
4×3G/HD/SD-SDI, 2×HDMI
SDI Input Format
1080p 60/59.94/50/30/29.97/25/24/23.98
1080psF 30/29.97/25/24/23.98
1080i 60/59.94/50
720p 60/59.94/50/30/29.97/25/24/23.98
HDMI Input Format
1080p 60/59.94/50/30/29.97/25/24/23.98/23.976
1080i 50/59.94/60
720p 60/59.94/50/30/29.97/25/24/23.98
576i 50, 576p 50
SDI Video Rate
Automatic detection, SD/HD/3G-SDI
SDI Compliance
SMPTE 259M/ SMPTE 292M/ SMPTE 424M
Color Space and Precision
SDI: YUV 4:2:2, 10-bit;
HDMI: RGB 444 8/10/12bit; YUV 444 8/10/12bit;
YUV 422 8/10/12bit
Outputs
PGM Outputs
2×3G/HD/SD-SDI; 1×HDMI Type A
PGM Output Format
1080p 60/50/30/25/24; 1080i 50/60
Multiview Output
1×3G-SDI; 1×HDMI Type A
Multiview Output Format
1080p 60
USB CAM
Output
USB interface
1×USB Type-C USB 3.1 Gen1(up to 200MB/s)
Output Format
1920×1200, 1920×1080, 1680×1050, 1600×1200,
1440×900, 1368×768,1280×1024, 1280×960,
1280×800, 1280×720, 1024×768, 1024×576,
960×540,856×480, 800×600, 768×576, 720×576,
720×480, 640×480, 640×360
Supports OS
Windows 7/8/10, Linux (Kernel version 2.6.38 and
above), Mac OS (10.8 and above)
Software compatibility
OBS studio, Skype, ZOOM, Teams, Google Meet,
Youtube Live, QuikcTime Player, Face time,
Wirecast, CAMTASIA, Ecamm.live, Twitch.tv, etc.
(Windows) etc.
Audio
Audio Input
1×3.5mm Stereo audio; 1×RCA(L/R)
Audio Output
1×3.5mm Stereo audio; 1×RCA(L/R)
Others
GPIO
Tally

5
4. FRONT CONTROL PANEL
LAN
RJ45
Power
DC 12V, 2A
Consumption
≤ 25W
Operation Temperature
-20℃~60℃
Storage Temperature
-30℃~70℃
Operation Humidity
20%~70%RH
Dimension
330×243.5×67mm
Weight
4kg
Warranty
2-Year Limited
Accessories
Accessories
1×Power Supply (DC12V 3A),
1×USB3.0 Cable Type-C to Type-A
1
MIXER
Support 2-Ch audio mixing
AFV
Audio follow video mode
2
FADE
Fade transition effect
MIX
Mix transition effect

6
5. OPERATION INSTRUCTION
5.1. Multiview Output Layout
PGM and PVW as Preview and Program displayed as following image. The level meter of PGM audio is
shown in multiview only. SDI/HDMI PGM out is without any overlays.
The following 6 windows come from the 6 input signals.
Wipe transition effect
3
PIP
Picture in Picture
FTB
Fade to Black, used for emergency
4
RATE
The transition rate
5
PVW:1-6
Selecting the signal source for Preview
PGM:1-6
Selecting the signal source for Program
6
T-BAR
T-bar Manual Transition
7
MENU
Menu Setting
8
AUTO
Performs an automated switch between Program and Preview.
CUT
Performs a simple immediate switch between Program and Preview.

7
The lower right corner display of the menu and status information. The CH1, CH2 are the channel
selection of the 2 audio sources for audio mixer. There is a real-time Digital clock/Analog clock displayed
beside the menu.
5.2. PGM PVW Switching
5.2.1. PGM, PVW Channel Selection
Below 1-6 buttons from PGM and PVW are corresponding with the 6 windows in the below of multiview
layout. The selected button from PGM turns on to red LED, and the selected button from PVW turns on to
green LED.
The selected PGM source will be circled in red border, while the selected PVW source will be circled in
green border.
For example, switching the PGM source to SDI 1 and PVW source to SDI 2. The button selection as
below.

8
5.3. Transition Control
There are two transition control types for this video switcher: Transition without effects and Transition with
effects.
1) Transition without Effects
CUT performs a simple immediate switch between Preview and Program views. This is no delay
seamless switching and the selected transition effect WIPE, MIX or FADE is not used.
2) Transition with Effects
AUTO performs an automated switch between Preview and Program views. The timing of the transition is
set by the chosen speed button. The selected transition WIPE, MIX or FADE will also be used.
T-Bar manual transition performs like AUTO, but it is more flexible that the timing of the transition depends
on the speed of the manual switch.
5.3.1. FTB (Fade to Black)
Pr
ess FTB button it will fade the current video Program source to black. The button will flash to indicate that
it’s active. When press the button again it acts in reverse from complete black to the currently selected
Program video source, and button stop flashing. FTB is usually used for emergency condition.
Note: When the PGM window display black and keep black even after transition, please check if the FTB
button flashing. Press the button again when it is flashing to stop black.
5.4. Transition Effects
5.4.1. MIX Transition
Pressing the MIX button selects a basic A/B Dissolve for the next transition. When button LED turns on it
is active. Then use T-Bar or AUTO to operate the transition. The MIX transition effect as below

9
5.4.2. WIPE Transition
WIPE is a transition from one source to another and is achieved by replacing the current source by
another source. Press the WIPE button and the LED turns on then it is active. There are total 8 WIPE
selections wiping start from different directions. Such as if choosing , then use T-Bar or AUTO to
operate the transition, the WIPE effect as following:
INV button is an alternative button. Press it first and then press a Direction button, the WIPE will start from
an inverse direction.
5.4.3. FADE Transition
Fade is a transition from one source to another with fade gradually transition effect. Press the FADE
button and use T-Bar or AUTO to operate the FADE transition.
5.5. Audio Mixer Setting
5.5.1. Audio Description
This video switcher is coming with 1 channel 3.5mm Stereo audio & 1 channel RCA(L/R) analog audio
input & output and 4 channel SDI embedded audio.
5.6. UVC Live Streaming
The USB3.0 streaming output transmits the PGM as an uncompressed Video and Audio signal. The
USB3.0 streaming output is based on UVC (USB video class) and UAC (USB audio class) standard. No
additional drivers need be installed. After installation in operating system, the relevant video and audio
devices will be added in the Windows Device Manager. There will appear two new devices:
• Under Imaging Devices: AVMATRIX USB Capture Video
• Under Audio inputs and outputs: AVMATRIX USB Capture Audio
Use a third party Video Media Player like PotPlayer, OBS, Windows Media Player to play and store the
captured video content.

10
6. MENU SETTING
6.1. SDI PGM/ AUX and Multiview Output Format
The output format of multiview is fixed at 1080p60, and for PGM output can be set by the knob. Except
PVW and PGM output, there is a AUX for choice, you can quickly select the auxiliary output between
PVW and PGM via Menu knob. The default setting is PGM after reset. There are resolution 1080P
50/60/30/25/24Hz, 1080I 50/60Hz selectable for SDI/HDMI PGM and AUX outputs.
6.2. Audio Setting
This video switcher is coming with 1 channel L/R analog audio input & output and 1 channel 3.5mm
stereo audio input and output, support both audio following video mode and audio mixing mode.
6.2.1. Mixing Mode
Press button MIXER to set audio mode as mixing. Press menu and choose audio for 2 channel audio
mixing, each channel, users can select audio source from IN1/ IN2/ IN3/ IN4/ IN5 / IN6/ Phone/ RCA IN.
6.2.2. AFV Mode
Press AFV button to enable the audio follow video mode. When the audio is in follow mode the audio is
coming from the embedded audio of Program video source. User can control the audio volume by
adjusting the master fader (the left one).

11
6.3. PIP Mode
When press PIP, there will be a small image display on the top left corner of PVW window as following
image. And the menu will enter an interface as below image. The window size, position and border of PIP
can be set from menu.
6.4. Main Menu Setting
When STATUS menu is not selected, press the MENU button to enter main menu directly. In case one of
the item is selected (see below), rotate the MENU button rotate anticlockwise to exit the choice, then
press the MENU button to enter into main menu.
6.4.1. System Settings
Entering system settings from the menu to switch the system language between English and Chinese.
Entering system settings from the menu to switch the real-time clock shown in Analog or Digital.

12
Connect video switcher to a PC and download a time control software from AVMATRIX official website
www.avmatrix.net/download/ Open the software and click Scan to search and connect the device, then
the clock time will be changed to same time to the PC’s time.
6.5. Network Settings
6.5.1. Network
There are two ways to acquire the IP: Dynamic (IP configured by router) and Static (set IP freely by
yourself). Select the method you need by knob menu. The default setting is Dynamic.
Dynamic: Connecting the video switcher with a router with DHCP features, then it will auto obtain an IP
address automatically. Make sure that the video switcher and PC are in the same local area network.
Static: Select static IP acquire method when the PC is without DHCP. Connect the video switcher with PC
via network cable, set the PC’s IP address to the same IP range as video switcher (the video switcher’s
default IP address 192.168.1.215), or set the video switcher’s IP address to the same IP range as PC’s IP
address.
6.5.2. NetMask
Set the NetMask. The default setting is 255.255.255.0.
6.5.3. GateWay
Set the GateWay according to current IP address. Save the configuration when network setting finish.
