Ayaneo Next User manual

AYANEO NEXT &

AYANEO NEXT Pro User Manual

For model of AYANEO NEXT &

AYANEO NEXT Pro

AYANEO NEXT

产品说明书User Manual

AYANEO NEXT &

AYANEO NEXT Pro 说明书适用于AYANEO NEXT &

AYANEO NEXT Pro

机型说明

手柄 LB 键手柄LT 键手柄RB 键手柄RT 键开机 / 睡眠 / 唤醒 / 指纹关机状态下，长按开关按钮 2 秒将 AYANEO 开机。开机状态下，点按电源按钮使其进入休眠状态,休眠状态下点按将其唤醒。支持指纹识别，使用微软账号登录进入，设置>账户>登录选项>指纹识别 (Windows Hello) ，录入启用指纹安全登录。Windows Hello 已配置指纹安全登录的，休眠状态下用已录入指纹手指轻触电源按钮约 2 秒直接唤醒进入 OS 界面，或者点按电源按钮唤醒屏幕后再轻触识别指纹后进入 OS 界面，无需输入 PIN 及密码登录。长按 8 秒强制关机。音量－ / 音量＋开机状态下，点按音量＋音量逐级增加，长按则连续增加音量。点按音量－音量减小。音量＋全功能 TYPE-C 接口音量－音频接口开机 / 指纹音频接口3.5mm 标准耳机插孔。全功能 TYPE-C 接口DP 1.4 视频输出 PD 3.0 快充USB 3.2

全功能 TYPE-C 接口右扬声器左扬声器手柄左操纵杆十字键视窗键手柄 LB/LT 键手柄右操纵杆手柄按键 ABXY

AYA 键自定义键手柄 RB/RT 键菜单键AYANEO NEXT &

AYANEO NEXT Pro 说明书适用于AYANEO NEXT &

AYANEO NEXT Pro

机型说明AYANEO NEXT &

AYANEO NEXT Pro

User Manual

For model of AYANEO NEXT &

AYANEO NEXT Pro

Power on / Sleep / Wake up / Fingerprint

USB 3.2

View

LB/LT

ABXY

AYA Key

Custom Key

RB/RT

Right stick

Le stick

Directional pad

Volume－/ Volume＋Full-featured TYPE-C Inteace

PD 3.0 fast charge

DP 1.4 video output

RB Buon RT Buon Audio

Inteace

Volume＋Volume－Power on /

Fingerprint

Le Speaker

LB Buon

LT Buon

Right Speaker

When the machine is turned on, tap

Volume＋to increase the volume step

by step, long press to continuously

increase the volume. Tap Volume－to

decrease the volume.

Full-featured

TYPE-C Inteace

Full-featured

TYPE-C Inteace

Audio Inteace

3.5 mm headphone jack.

In the shutdown state, press and hold the

switch buon for 2 seconds to turn on

AYANEO.

In the power-on state, click the power

buon to put it into sleep state, and in the

sleep state, click to wake it up.

Suppo ngerprint recognition, log in with a

Microso account, Seings > Account >

(Windows Hello), enter and enable

ngerprint security login.

Windows Hello users who have congured

ngerprint security to log in can wake up

directly to the OS inteace by tapping the

power buon with their registered

ngerprints for about 2 seconds, or tap the

power buon to wake up the screen and

then tap to identify the ngerprint to enter

the OS inteace , No need to enter PIN and

password to log in.

Long press for 8 seconds to force

shutdown.

AYANEO NEXT &

AYANEO NEXT Pro 说明书适用于AYANEO NEXT &

AYANEO NEXT Pro

机型说明AYANEO NEXT &

AYANEO NEXT Pro

User Manual

For model of AYANEO NEXT &

AYANEO NEXT Pro

AYANEO 商品三包凭证商品名称商品商标商品序列号商品产地销售单位名称销售单位地址销售单位邮政编码销售发票号码销售日期消费者姓名消费者地址消费者邮政编码消费者联系电话修理单位名称修理单位地址修理单位邮政编码修理单位联系电话AYANEO严格按照《微型计算机商品修理更换退货责任规定》，为购买 AYANEO 商品的消费者实行三包。若服务条款与三包规定有不符之处，以三包规定及三包凭证内容为准。对于执行特别三包目录的地区，AYANEO 承诺遵守当地的相关规定。一、请妥善保存本三包凭证，本三包凭证和购机发票一起作为保修凭证，在保修期内享受免费保修。二、“三包”有效凭证在“三包”有效期内产品出现故障，消费者需凭购机发票和此三包凭证享受免费维修服务，所修理产品机身号码同三包凭证上的产品机身号码必须一致。如无购机发票，则以产品机身号码的生产出厂日期作为消费者产品“三包”有效期的起始时间。如两者全无的消费者，则不能享受免费维修服务，我司将实行收费维修服务。三、根据《部分商品修理更换退货责任规定》，属下列情况之一者，不实行“三包”，但可实行收费维修：1. 超出本公司产品保修期范围内的；2. 无法同时出示购机发票和填写保修凭证，或保修凭证上与维修产品的型号、机身号码不符或涂改；3. 非承担三包的修理者进行修理或者拆动、改装等引起的故障和损坏；4. 未按照产品使用说明的要求使用、维护、保管而造成的故障和损坏；5. 使用非本公司所制造的产品配件引起的产品故障和损坏；6. 由于跌落、移动、运输等非产品质量原因引起的故障和损坏；7. 油烟、灰尘、受潮、直射阳光等恶劣条件下使用产生的故障和损坏；8. 由于雷击、水灾、火灾、地震、风灾等自然灾害及异常电压、公害、化学物质的侵蚀而造成的故障和损坏；9. 使用盗版软件造成损坏的；10. 使用过程中感染病毒造成损坏的。四、超过“三包”有效期或“三包”责任范围的，按照 AYANEO 规定的收费标准实施收费服务。在线自助服务： www.ayaneo.com.cn

技术支持热线： 400-039-8088 维修记录项目送修日期使用配件交验日期修理单位名称维修人员签字故障描述故障原因处理结果产品标签销售单位印章说明干扰医疗设备、心脏起搏器、除颤器或其他医疗设备。请在医疗设备和AYANEO 之间保持一定的安全距离。请咨询您的医师和医疗设备制造商以获得医疗设备信息。如怀疑AYANEO干扰您的心脏起搏器、除颤器或者其他医疗设备，请停止使用 AYANEO 。AYANEO保证所附硬件产品和配件，从原先零售购入的日期起一年内， AYANEO 对正常磨损不作担保，对事故或滥用造成的损坏也不做担保。若要获取服务，请访问 AYANEO 商城或者 AYA 授权服务提供商，可用的服务选项取决于请求的服务所在的国家或地区，并且可能限制为销售的原始国家和地区。可能需要支付通话费用和国际运费，这取决于您的位置。当您根据保修服务政策提交有效的索赔时，AYA NEO 将为您的AYANEO 酌情进行维修，更换或退款。您享有的保修权益是附加在本地消费者法律所提供的权力以外的。当您根据本保修政策提出索赔时，可能需要提供购买凭证的详细信息。支持有关支持和故障排除信息、驱动软件、及最新的AYASpace下载，请访问 www.ayaneo.com.cn。FCC合规此设备符合 FCC 规则第十五部分中的规范标准。操作设备须符合以下两个条件；（1）此设备不会导致有害干扰；（2）此设备可承受任何外来干扰，包括可能导致非预期操作的干扰。欧盟合规AYANEO 特此声明本无线设备符合指令。 2014/53/EU 规范。Read the manual at hps://www.ayaneo.com/manual before using AYANEO .

You can also read the paper manual that comes with the package.

Boot and shut down

Press the power buon for 2 seconds to sta AYANEO . During the boot

process, the indicator light between the two Type-C at the top is always on.

The fan will work at the maximum speed. Aer the self-check, it will return to

normal speed and the indicator light will go out. Press and hold the power

buon for two seconds in the power-on state, and a pull-down shutdown

menu will pop up at the top of the screen. Press and hold the power buon,

touch and slide down (slide to turn o the computer) to complete the AYANEO

shutdown operation. Or click on the lower le corner of the screen: Window

buon> Power> Shut down to turn o AYANEO. Press and hold the power

buon for 8 seconds in the power-on state to forcibly shut down AYANEO. It is

not recommended to force this operation in normal use scenarios.

Sleep and Wake

Press the power buon in the power-on state to quickly enter the sleep state,

or click the window buon in the lower le corner of the screen>Power>Sleep

to put AYANEO into the sleep state. In the sleep state, the indicator light

between the two Type-Cs at the top is in a regular breathing state. The cooling

fan will stop rotating. Click the power buon in sleep state to wake up

AYANEO, Windows Hello has been congured for ngerprint security login. In

the sleep state, touch the power buon with the registered ngerprint nger

for about 2 seconds to wake up directly, or touch the power buon to wake up

the screen and then touch the ngerprint to enter the OS inteace without

entering the PIN and password to log in. Aer successfully recognizing and

waking up, the indicator light between the two Type-Cs on the top goes o,

and the cooling fan rotates normally. It takes 1~3 seconds to wake up under

dierent inteaces to complete the wake-up.

Baery and Charging

Do not try to replace the AYANEO baery by yourself, you may damage the

baery, resulting in overheating, re and personal injury. The lithium-ion

baery of AYANEO should be operated or recycled under the instructions

provided by AYANEO. It must be recycled separately from household waste.

Please dispose of the baery in accordance with local environmental

regulations. The baery can only be replaced by AYANEO or AYANEO

authorized service provider. Replacement with the wrong type of baery may

cause an explosion. When Type-C is plugged into the power supply, avoid

prolonged contact between the skin and the plug, otherwise it may cause

discomfo or injury. Please use the included adapter to charge AYANEO . Do

not use an adapter without safety ceication to charge AYANEO. It may

cause damage to internal components and unpredictable danger.

Cleaning

Please use a lint-free cloth to clean AYANEO . Do not let any opening get damp

or use aerosol sprays, solvents or abrasives.

Medical equipment inteerence

Some components inside AYANEO include magnets and radio emission

electromagnetic elds. These electromagnetic elds may inteere with

medical equipment, pacemakers, debrillators, or other medical equipment.

Please keep a safe distance between the medical equipment and AYANEO .

Please consult your physician and medical device manufacturer for medical

device information. If you suspect that AYANEO inteeres with your

pacemaker, debrillator or other medical equipment, please stop using

AYANEO .

AYANEO guarantees that all hardware products and accessories will be within

one year from the date of the original retail purchase. AYANEO does not

guarantee normal wear and tear, nor does it

guarantee damage caused by accidents or abuse. To obtain services, please

visit AYANEO mall or AYA

authorized service provider. The available service options depend on the

country or region where the requested service is located, and may be

restricted to the original country and region of sale. Depending on your

location, you may have to pay for phone calls and international shipping costs.

When you submit a valid claim according to the warranty service policy,

AYANEO will repair, replace or refund your AYANEO as appropriate. Your

warranty rights are in addition to the powers provided by local consumer laws.

When you make a claim under this warranty policy, you may need to provide

details of the proof of purchase.

Suppo

For suppo and troubleshooting information, driver soware, and the latest

AYA Space downloads, please visit www.ayaneo.com.

FCC compliance

This device complies with the specications in Pa 15 of the FCC Rules. The

operating device must meet the following two conditions; (1) This device will

not cause harmful inteerence; (2) This device can withstand any external

inteerence, including inteerence that may cause unintended operation.

EU compliance

AYANEO hereby declares that this wireless device complies with the directive

2014/53/EU.

使用 AYANEO 前先阅读 hps://www.ayaneo.com.cn/manual 的使用手册。您也可以阅读包装内自带的纸质使用手册。开机和关机按电源按钮2 秒启动AYANEO，开机过程中顶部两 Type-C 之间的指示灯处于常亮状态，风扇会以最大转速工作，自检过后回复正常转速，同时指示灯熄灭。开机状态下长按电源键两秒屏幕顶部弹出下拉关机菜单按住电源键不放向下触控滑动（滑动以关闭电脑）完成关闭AYANEO操作,或者点击屏幕左下角窗口按钮>电源>关机关闭 AYANEO。开机状态下长按电源键 8 秒则强制关闭AYANEO ，正常使用场景不推荐强制此操作。睡眠和唤醒开机状态下点按电源按钮则快速进入睡眠状态，或者点击屏幕左下角窗口按钮>电源>睡眠将 AYANEO 睡眠状态，睡眠状态下顶部两 Type-C 之间的指示灯处于有规律呼吸状态，散热风扇将停止转动。睡眠状态下点按电源按钮将 AYANEO 唤醒，Windows Hello 已配置指纹安全登录的，休眠状态下用已录入指纹手指轻触电源按钮约 2 秒直接唤醒，或者点按电源按钮唤醒屏幕后再轻触识别指纹后进入 OS 界面，无需输入 PIN 及密码登录。成功识别唤醒后顶部两 Type-C 之间的指示灯熄灭，散热风扇正常转动，不同界面下唤醒需要等待 1~3 秒将亮屏完成唤醒。电池和充电请勿尝试自行更换AYANEO 电池，您可能会损坏电池，从而导致过热，火灾和人身伤害。 AYANEO 的锂离子电池应由 AYANEO 提供相关服务或进行回收，它必须和家庭垃圾分开回收处理。请按照当地的环保法规来处理电池。电池只能由 AYANEO 或者 AYANEO 授权服务提供商进行更换，用错误型号电池更换会有爆炸危险。当 Type-C 插入电源时，应当避免皮肤与插头长时间接触，否则可能会引起不适或受伤。请使用附带的适配器对AYANEO进行充电，切勿使用无安全认证适配器对AYANEO充电，可能会照成内部元件损坏和不可预知的危险。清洁请使用不起绒的布来清洁 AYAN EO，切勿使任何一个开口处受潮或使用气雾喷剂、溶剂或研磨剂。医疗设备干扰AYAN EO内部部分元件包含磁体及无线电发射电磁场，这些电磁场可能会AYANEO NEXT &
