Azeyou AT1011U User manual

User Manual
Please read this manual before operating your device
and keep it for future reference.
Tablet PC
Model No.: AT1011U

-1-
We would like you to have a safe and enjoyable experience, please read the
following instructions and notices before using your tablet.
1. Please fully charge the tablet before the first use.
2. The tablet is not moisture/water-resistant, please don’t use it around sources of
water.
3. Avoid using the tablet in extremely hot, cold, dusty, damp or wet environments.
4. Do not use alcohol, thinner or benzene to clean the surface of the tablet. Use only
cleaning products designed for computer tablet devices.
5. Do not drop or hit the tablet against a hard surface or the screen may be
damaged or cracked.
6. Do not use the tablet while driving or walking.
7. While using earphones, if the volume is excessively high it may cause hearing
damage. Please adjust the volume to a safe level and moderate use.
8. Do not disconnect the tablet suddenly when updating, uploading or downloading
data, this may lead to program errors.
9. Do not dismantle the tablet.
10. Do not use other accessories except specified or provided by the manufacturer
(such as the power adapter, battery etc).
What’s In The Box
Since the tablet software updates regularly, the user manual may not
cover all aspects of new features.
Tablet Instruction
manual
IM
USB cableCharger Pin

-2-
Open the SIM/microSD card tray with the pin.
Place the SIM card and microSD card into the tray, then close the tray.
Warning: The SIM card and microSD card can be easily damaged by scratching or
bending, so be careful when handling, inserting, or removing the card. Keep all cards
out of reach of small children.
1. POWER/LOCK
2. RESET
3. VOLUME +
4. VOLUME
7. EARPHONE JACK
8. FRONT CAMERA
9. FLASH
10. REAR CAMERA
6. TYPE-C
5. SIM/microSD CARD TRAY 11. SPEAKER
Function Overview
Getting Started
Prior to use, it is recommended to install a SIM card (not included, to connect mobile
network through 2G/3G cellular network), microSD memory card(not included, to
expand storage capacity) and charge the battery.
Note: A SIM card and memory card can be installed at any time, it’s not necessary to
install them prior to using the tablet. The card tray supports 2pcs SIM card or 1 SIM
card and 1 microSD card.
Install The SIM/microSD Card
1
2
3
4
5
6
7
89
10
11 11
12
12. MIC

-3-
Press and hold the Power/Lock button until the device option menu displays, tap
Emergency to make an emergency call, tap Restart to restart the tablet, tap
Screenshot to capture a screenshot.
Tips: You can also capture a screenshot by pressing and holding the Power/Lock
button and Volume - button at the same time for 1 second.
Charge The Battery
The tablet comes partially charged, it is recommended to fully charge it before the
first use. Connect the USB cable to the adapter, and insert the other end to the
charging port of tablet, then plug the AC adapter into a wall outlet. It will take up to 4
hours to fully charge the battery.
Warning: Use only Azeyou-approved charging adapters and batteries. Azeyou accessories
are designed to maximize battery life, using other accessories may invalidate your
warranty and may cause damage.
Turning On
Turning Off
Emergency, Restart and Screenshot
Note: Please leave the tablet in well ventilated area while charging.
Press and hold the Power/Lock button until the tablet starts up, the Azeyou logo
indicates that the tablet is loading, then choose your language and tap START to set
up the tablet following the guide and prompts.
Press and hold the Power/Lock button until the device option menu displays, tap
Power off to turn off the tablet.

-4-
Tap the screen once to activate or open something.
Touch and hold to move an app by dragging.
Zooming: Double tap quickly to zoom into a webpage, picture, or map. Some apps
allow you to zoom in and out by touching the screen with two fingers, and pinching
them together.
Tap a specific location on the screen where you would like to enter text, the on-screen
keyboard will pop up.
Tap and hold your finger on blank space of the home screen, a pop-up menu will
be displayed.
Home Screen
Back
Sleep Mode, Lock/Unlock Tablet
When the tablet is on, you can turn off the screen to save power, press the
Power/Lock button once to turn off the screen and lock the tablet, press it again to
turn on the screen, and swipe up to open.
Touch Screen Basics
Home settings and Wallpapers
Tap Home settings to enable/disable Notification dots, At A Glance, Add app icons
to Home screen, Show Google App, Home screen loop, set Pull down action option,
Show notification dots number, Home screen, Desktop grid and Dynamic icon.
Home Recent Apps

-5-
Quick Settings
Slide down to reveal notifications and quick settings
Tap Wallpapers to change current wallpaper from default wallpapers or photos.

-6-

Slide down to show more quick settings
Enable/Disable Wi-Fi network connection.
Enable/Disable Bluetooth connection.
Do Not Disturb:Only get notified by important people
and apps.
Auto-rotate: Turn on/off screen auto-rotate.
Nearby Share: Turn on/off nearby share.
Battery Saver: Turn on/off battery saver.

-7-
Screen Brightness: To adjust the screen brightness.
Flashlight.
Mobile Data: Turn on/off mobile data.
Airplane Mode: Turn on/off all wireless network connection.
Screen Record: Turn on/off screen record.
Edit: To edit quick setting options.
Detailed Setting: To enter detailed settings.
Flashlight.

-8-
Tips: You can also slide up to open the app list on home screen, then tap Settings to
enter detailed settings.
Detailed Settings
Slide up to open the app list

-9-
Wi-Fi: Enable/Disable Wi-Fi connection, tap to connect to Wi-Fi network, select
your Wi-Fi name and enter password to connect it.
Mobile network: Enable/Disable mobile network (SIM card shall be installed in
advance).
Airplane mode: Turn on/off all wireless network connection.
Mobile plan: To set mobile plan.
Hotspot & tethering: To set Wi-Fi hotspot, USB tethering, Bluetooth tethering and
Ethernet tethering.
Advanced: To Data Saver, VPN and Private DNS.
USB: To set USB computer connection: charge only, file transfer, camera, MIDI,
USB virtual drive.
Network & internet
Connected devices
Pair new device: To check all available Bluetooth devices, and tap the device name
to pair it with the tablet.
Connection preference: Enable/Disable Bluetooth connection, check or add print
service, check files received via Bluetooth, share files with nearby devices.

-10-






Tips: Charge only: To charge the tablet only.
Media device (MTP): For file transfer between tablet and computer.
Camera (PTP): Only for photo transfer between tablet and computer.
MIDI: Play MIDI instrument on the tablet.
USB virtual drive: Enable USB virtual drive.

-11-
Apps & notifications
Check the list of recently opened apps.
Conversations: Priority and modified conversations will appear here.
Notifications: To check the notification history, bubbles and recently sent.
Screen time: To check the dashboard of screen time, notification received and times
opened.
Advanced: To set default apps of browser, caller ID & spam, digital assistant, home
app, phone app, SMS app and opening links, set permission manager, wireless
emergency alerts, special app access.
Battery
Battery Saver: Turn on/off battery saver, set a schedule, turn off when charged.
Battery Manager: Turn on/off detecting when apps drain battery.
Ultra saving mode: Enable/Disable ultra power saving mode.
Battery percentage: Enable/Disable to show battery percentage in status bar.
App battery setting: App standby optimizer, Close app after screen lock, auto launch
management, Power intensive apps.
Display
Brightness level: Adjust the brightness level of screen
Dark theme: Turn on/off dark theme
Wallpaper: Change the wallpaper
Screen timeout: Set the screen timeout
Auto-rotate screen: Turn on/off auto-rotate screen
Advanced: Set the font size, display size, screen saver and lock screen.

-12-

Location
Turn on/off location service for certain apps.
Security
Check security status, set screen lock mode (swipe/pattern/pin/password) , face unlock,
smart lock, device admin apps ( Turn on/off find my device).
Scheduled power on/off
Sound
Storage
Privacy
Set the time and repeat days of scheduled power on/off.
Set the volumes of media, call, ring & notifications and alarm, Do Not Disturb, default sounds.
View and manager storage.
Set app permissions, show passwords, notifications on lock screen, autofill service
from Google.

-13-
Accounts
Add and manager user accounts on the tablet, turn on/off automatically sync app data.
Accessibility
Set screen reader, Display, interaction controls, audio & on-screen text, high contrast text
and advanced (color correction, color inversion, shortcut from lock screen).
Digital Wellbeing & parental controls
Set the ways to disconnect, reduce interruptions, add content restrictions and set other
limits to help child balance screen time.
Google
Sign in Google Account, set Google services on this tablet.
System
Set languages & input, Gestures, Date & time, Backup and Advanced.
(Reset options and system updated).
About tablet
Check the information about this tablet.

-14-


Tips: You can also tap and hold the app, tap App info, then tap uninstall to
uninstall the app.
APP Management
Download App
Move App
Tap and hold the app, then drag it to the desired place.
Create App folder
Tap and hold an app, drag it to another app, an app folder will be created, tap the
folder to edit folder name, then you can drag favourite apps to this folder.
Remove App from home screen
Tap and hold the app, then drag it to X Remove to remove it from home screen.
Uninstall App
Tap and hold the app, then drag it to Uninstall to uninstall it.
Sign in your Google Account, search and download the app you need.
Tap Play Store on home screen

-15-


 
Tips: You can also tap Settings -- Storage -- SD card to set up the microSD card.
Connecting to microSD memory card
Open the SIM/microSD card tray with the pin, place the microSD card into the tray,
then close the tray.
Slide down to open quick setting on home screen, tap to set up the microSD card.

-16-
Specification
Display
Resolution
Operation System
CPU
GPU
RAM
Storage
Battery
Housing Material
Front Camera
Rear Camera
Audio
Ports
Wi-Fi
Cellular Network
Bluetooth
Power Supply
Dimension
10.1"
1280 x 800 IPS HD
Android 11 Go
Quad-core, 4 x 1.3GHz
Mali-T820, up to 600MHz
2GB
32GB
6000mAh
Metal
2MP
5MP
Dual loudspeakers
Type C, SIM/microSD slot, Headphone jack
Support 2.4G
Support 2G/3G
BT 4.2
DC 5V/2A
9.5 x 6.3 x 0.35 inch

-17-
Compliance Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Caution: Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark
(Bluetooth word mark and “B Design”) are registered trademarks and are wholly
owned by the Bluetooth SIG.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
microSD™ and the microSD logo are Trademarks of the SD Card Association.
Google, the Google logo, Android, the Android logo, Google Play, Gmail, Google Mail,
Google Maps, Google Music, Google Hangouts, Picasa, Play Newsstand, YouTube
and other marks are trademarks of Google Inc.

Specific absorption rate (SAR):
This Tablet PC meets the government's requirements for exposure to
radio waves. The guidelines are based on standards developed by
independent scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a margin of safety
designed to ensure the safety of all people regardless of their age or
health.
The FCC Statement of Exposure to RF and the SAR limit for the United
States (FCC) is 1.6 W/kg average for each gram of tissue. This device was
tested for typical operations of use on the body, with the back of the
phone at 0mm from the body. To maintain compliance with FCC RF
exposure requirements, use accessories that maintain a distance of 0mm
between the user's body and the back of the Tablet PC. The use of belt
clips, covers and similar accessories must not contain metallic
components in their assembly. The use of accessories that do not meet
these requirements may not meet FCC RF exposure requirements and
should be avoided.
Functioning in the body
This device was tested for typical operations of use in the body. To
comply with RF exposure requirements, a minimum separation distance
of 0mm must be maintained between the user's body and the telephone,
including the antenna. Third-party accessories such as belt clips. covers
and similar accessories used with this device should not contain metallic
components, accessories that do not meet these RF exposure
requirements and should be avoided from use on the body. Use only the
supplied antenna or an approved antenna.
