TwinMOS TwinTAB-T102D1 User manual

TABLET PC
User Guide TwinTAB-T102D1
T102D1
10.1
Navigation Dual Camera
1280x800
3G Ready
USB Dongle

CONTENTS
1
SPECIFICATION.................................................................................2
QUICK GUIDE ...............................................……………………………………3
ICON INDICATOR...........................................................................................4
GETTING STARTED……….…...............…………….......................................5
POWER BUTTON USAGE.............................................................................7
DESKTOP............................................................................................8
LOADED APPLICATIONS..............................................................................9
STATUS AND NOTIFICATION AREA..........................................................11
CAMERA..................................................................................................12
FILE BROWSER...........................................................................................13
WI-FI & 3G NETWORK..................................................................................14
IMPORTANT SAFETY PRECAUTIONS........................................................16
TROUBLE SHOOTING..................................................................................16
- T102D1 www.twinmos.com

2
1.SPECIFICATION
Product Module
Brief Introduction
TwinTAB-T102D1
10.1〞Tablet PC
Chipset
Built-In OS
Dual-core ARM Cortex-A9 up to 1.6GHz
Android 4.1
RAM Density 1GB DDR3
Memory 8GB/16GB
LCM 1280*800
Touch Panel Multi Capacitive Touch (5 Points)
Support Wi-Fi、GPS、Bluetooth
Camera Front: 0.3M Pixel ; Rear: 2.0M Pixel
Battery Li-Polymer 6000mAh/3.7V
Connection Slot Micro SD Card、Micro USB、Mini HDMI、
DC IN、Earphone Jack
- T102D1 www.twinmos.com

3
2 QUICK GUIDE
INTERFACE INTRODUTION
6
1
2
3
4
5
78
10
11
1212
9
- T102D1 www.twinmos.com
www.twinmos.com Made in PRC
T102D1 16GB

1. MIC: Used for recording
2. Earphone Jack: The built-in speaker will shut down automatically when plug in
the earphone.
3. DC IN: Connect to power adapter provided by TwinMOS.
4. Mini HDMI: Connect to external display device.
5. Micro USB: Connect to external USB device or other mobile device.
6. Power Button: Press power button for 3 seconds to power on/off your tablet.
7. Reset: Poke the reset hole to reset the system.
8. Volume Button: To control the volume for +/-.
9. Card slot: use for TF-card.
10. Front Camera: 0.3 MP.
11. Rear Camera: 2.0 MP.
12. Speaker: Left speaker and right speaker
3 ICON INDICATOR
4
ICON FUNCTION
Return
Go to the opening screen
Check the running applications
WLAN connected
Auto-rotate screen
- T102D1 www.twinmos.com

4 GETTING STARTED
5
Notification
Adjust screen brightness
Setting up
New text or multimedia message
Alarm activated
Error occurred or caution required
Battery power level
Connected to PC
Charge the device
☆It is not recommended to use the device while charging.
Plug the power adapter into an electrical outlet, and then connect to the
device to fully charge the battery before use (A full charge takes about 6
hours in the off status).
Turn the device on
Press the power button briefly.
Bluetooth activated
- T102D1 www.twinmos.com

HDMI video play
This feature is supported through a Mini HDMI cable which connects and
synchronizes your device to a TV, for using this feature, insert the Mini HDMI
cable into the HDMI slot located on the right side of the device and connect
the other end to your TV.
6
Wi-Fi Network Setup
Since many features require a Wi-Fi connection, we recommend you set up
your Wi-Fi network before exploring your device.
1.Tap on → Settings.
2.Slide Wi-Fi switch to turn on.
The device automatically scans and lists all available local Wi-Fi Networks
found. A lock sign indicates a secured Wi-Fi network that requires a password
to connect.
3.Tap on the desired network to which you want to connect to → enter the
Network Password if applicable → tap Connect.
4.Tap on to return to the Desktop screen.
☆If your Wi-Fi network is set as “Hidden”, it won’t be found by the auto scan.
Tap on Add Wi-Fi network option and follow the prompts to add your desired
network.
- T102D1 www.twinmos.com

5 POWER BUTTON USAGE
Turn On: Press the power button and hold for 2 seconds.
Turn Off: Press the power button and hold for 2 seconds →tap Power off→tap
OK.
Reboot: Press the power button and hold for 2 seconds →Tap reboot.
Quickly Hibernate/wake-up: Press the power button and hold for 2 seconds →
tap Hibernate enable the device to hibernate，or press the power button
briefly again to make the hibernated device to wake-up.
Force Off: If device does not respond, press and hold the power button for 5
seconds.
(Warning: Force off could lead to unpredictable system errors!)
Reset: Press the reset button could be reset the device. It’s will clear the all
data, Please careful with the function. (Note: After the current reset function
can’t restart, can only be turned off, so you need to press the power button
restart the device after reset.)
7
- T102D1 www.twinmos.com

8
1. Back
2. Home
3. Recent Apps
4. Current time
5. Wireless network
6. Battery Status
9 DESKTOP
1 2 3 4 5 6
- T102D1 www.twinmos.com

9
Through add icon you can personalized some of the operations, such as,
adding widgets, creating application shortcuts, set wallpaper, add bookmarks,
set-up email accounts and etc…
☆Tap on any application icon to launch it.
☆Touch, hold and then slide any icon to reposition it on the screen.
☆Touch, hold and slide any icon onto to remove it from the Desktop
screen.
-LOADED APPLICATIONS
Clock Set the time and/or alarm
App Market Download applications
quickly & easily.
Browser Access internet.
Calendar Calendar. Organize your daily
schedule
Camera Take normal photos, panoramic
photos and record videos.
Calculator Calculate simple math equations.
Email Send/Receive emails using your
existing email addresses.
- T102D1 www.twinmos.com

10
My Video Play and manage video files.
My Photo View and manage photo files.
Gallery Play, view, and manage both
video and photo files.
Picture Capture Capture screen image.
Task Manager Manage applications and processes.
Voice search Search through the voice
recognition technology.
Flash player
settings Manage the Flash Player’s settings.
Downloads View the downloaded/downloading
files/Apps/Programs/etc. and their
download progress.
File Browser View and manage files, folders and
Apps such as: Installing Apps,backing
up files to a SD Card and etc.
My Music Play and manage audio files.
- T102D1 www.twinmos.com

11
Play Store Download android games and Apps.
Search Local and online searches.
Settings Settings for personalizing and
enhancing your Device.
☆To move an icon to the Desktop screen, touch & hold the icon, and release
it when it appears on the Desktop screen.
☆Touch, hold and then slide any icon to reposition it on the screen.
☆Touch, hold and slide any icon onto to remove it from the Desktop screen.
On the Desktop screen, tap on any of the icons located on the Status bar to
view the notifications and updates.
10 STATUS AND NOTIFICATION AREA
- T102D1 www.twinmos.com

12
Wi-Fi Access the Wi-Fi setting
Auto-rotate screen Automatically rotate screen with
gravity induction.
Brightness Screen brightness setting.
Notifications View all notifications.
Settings Access the general settings.
Tap on the Camera application icon.
Take Pictures
1.Tap on switch to camera
2.Tap on to take a picture.
3.The pictures will be automatically saved.
4.Tap on the picture thumbnail to enter My Photo to view the pictures.
5.Press Back to return to the Camera.
6.Tap on to exit the Camera and return back to the Desktop.
11 CAMERA
- T102D1 www.twinmos.com

13
12 FILE BROWSER
Tap on the File Browser application icon, to view the files on all
storage devices (Internal memory, SD card, USB device), or install Android
application on your axpad.
The icons across the top of the screen:
Internal Flash (ROM) USB Storage SD Card
Paste
SD
USB
ROM
Back to the
previous folder Menu
Switch folder
display mode.
Copy Media between Computer and Tablet
You can use the File Browser to copy files between external storage devices
and your computer. You can first copy the desired files onto a SD card or a
USB device.
☆The internal device storage is titled “ROM”, a memory card “SD”, and a USB
storage device is titled “USB”.
☆The instructions below are about copying files from a SD card or a USB
storage device into your device. You can use the same method to copy from
your device to a SD card or a USB storage device, and then connect the
storage device to your computer to transfer the files into the desired folder on
your computer.
- T102D1 www.twinmos.com

14
Connected to the local area network shared folders
You can view all of the LAN shared folders.
1.Connect to LAN.
2.Tap on Net share →Add new sharing point →Choose the mode used of
sharing → Editor of network folder sharing.
3.After you are connected successfully enter the network sharing settings and
open the list of shared folder directly.
Delete files
Tap and hold a folder/file and enter into the multi-select mode, select the
folder/file you wish to delete → tap on Delete → OK to confirm the deletion. →
tap on Delete → Tap OK to confirm the deletion.
1.Tap on GoTo, select or to display the contents of your
storage device.
2.Tap and hold a folder/file and enter into the multi-select mode, select the
desired folder/file → tap on Copy.
3.Tap on GoTo, select Internal Memory → tap on the folder into which
you want to copy the file → tap on .
13 WI-FI
Tap on Settings → Wi-Fi to enter into the Wi-Fi Settings.
1.Slide the Wi-Fi switch to turn on Wi-Fi.
2.All the available AP within the vicinity will be listed, select the desired network
3.If the AP is not encrypted, select Connect to start. Once you are connected
successfully the AP information will be saved on your device. You may choose
"Forget" to remove the AP’s information;
- T102D1 www.twinmos.com

15
4.If the AP is encrypted, you must enter the network’s password in the pop-up
window, and click "Connect" Start Connection;
5.Once you are successfully connected, the wireless connection icon will
appear on the bottom status bar.
14 3G NETWORK
15 BATTERY MANAGEMENT
It is highly recommended that you charge the battery for at least 6 hours
before you start to use the device.
The rechargeable battery is designed and manufactured to be used and
recharged frequently. As with all batteries, the capacity of the battery reduces
each time it is charged/depleted. However, you can still try to prolong the
battery’s lifetime by following the suggestions below:
● Use your Tablet at least once a week.
● Charge the battery regularly and fully.
● Never leave the battery fully discharged for a long period of time.
● Always keep the device and the battery away from heat.
Charge battery
Plug the power adapter into an electrical outlet, and connect it to the device to
fully charge the battery before use (A full charge takes about 6 hours in the off
status).
☆ You cannot charge the battery using the USB cable.
When fully charged, the battery icon will be displayed on the status bar
This only for 3G model
you need to purchase a 3G dongle which is compatible to your country of
residence in order to be able to use the 3G network.
- T102D1 www.twinmos.com

16
32 IMPORTANT SAFETY PRECAUTIONS
Always follow these basic safety precautions when using your Tablet. This
reduces the risk of fire, electric shock, and injury.
●Do not expose this product to rain or moisture.
●Keep the device out of direct sunlight and heat sources.
●Protect the power cord. Route power cords so that they are not likely to be
walked on or pinched by items placed on or against them. Pay particular
attention to the point where the cord attaches to the device.
●Only use the AC adapter included with the device. Using any other power
adapter voids your warranty.
●Do not remove the back cover.
Cleaning your device
Treat the screen gently. To clean fingerprints or dust from the screen, we
recommend to using supplied cleaning cloth or a soft, non-abrasive cloth such
as a camera lens cloth.
Android
Q: What Android OS version is on my Device?
A: 4.1
Basic Device Functionary
Q: Do I have to charge the battery before use?
A: You should charge the battery for at least 6 hours, but you can use the
device while it’s charging. Please use the power adapter which is included in
the box to charge your device; this device cannot be charged via the USB
cable.
33 Trouble Shooting
- T102D1 www.twinmos.com

17
Email
Q: Can I use any of my personal email addresses to send/receive
email?
A: The device supports POP3 and SMTP accounts. Check with your email
provider to see if your account is supported.
Media Cards
Q: Which media cards are compatible with my Device?
A: micro SD / microSDHC cards
Music
Q: What type of music files can I play on my device?
A: MP2, MP3, WAV, AAC, WMA
Q: How do I add music files to my device?
A: Copy the music files from your computer onto a SD card or USB storage
device, and use the File Browser application to copy the files into the device.
Photos
Q: What type of photo files can I view on my device?
A: JPG, JPEG, BMP and PNG.
Q: How do I add photo files to my device?
A: Copy the photo files from your computer onto a SD card or USB storage
device, and use the File Browser application to copy the files into the device.
Video
Q: What type of video files can I play on my device?
A: Video file formats supported: MPEG1/2/4、H263、H264、VC1、Real
Video、Motion JPEG.. The largest supported video format is 1080P
(1920×1080) resolution.
- T102D1 www.twinmos.com

18
Q: What type of video files can I play on my device?
A: Video file formats supported: MPEG1/2/4、H263、H264、VC1、Real
Video、Motion JPEG.. The largest supported video format is 1080P
(1920×1080) resolution.
Q: How do I add video files to my device?
A: Copy the video files from your computer onto a SD card or USB storage
device, and use the File Browser application to copy the files into the device.
Wi-Fi
Q: Do I need a Wi-Fi adapter to connect to the Internet?
A: No. The Wi-Fi adapter is built-in to the device.
- T102D1 www.twinmos.com

T102D1
