Barbieri TracMow 95 EVO User manual

BHV
Barbieri Hybrid Vehicle
REMOTE CONTROLLED
GRASSLAND MOWER
BARBIERI GROUPBARBIERI GROUP
MADE IN ITALY
Operator’s Manual
MODEL:
95 evo
ENGLISH

1
THANK YOU FOR CHOOSING OUR PRODUCT
With this product you have chosen unique features, the value of which you can immediately
appreciate and evaluate over time:
- The lightness of the machine allows it to work on slopes
that are impossible for other machines
- The available accessories increase the work opportunities
- WiththeCOMPASSServoDriveyoucanworkmoreefciently
and safely
- The BeaConNet is a beacon on the machine that changes
color to inform you of all dangerous situations and the status
of the vehicle
- The vibration of the radio control warns the operator of
dangerous situations and alarms on the machine
- The telematic connection of the machine to the web enables
remote control of the machine parameters, fast remote
diagnosis and automatic software updates.
HAVE A GOOD WORK !
PRODUCTIVITY
PRODUCTIVITY
PRODUCTIVITY
PRODUCTIVITY
PRODUCTIVITY
PRODUCTIVITY

2
SAFETY HIGHLIGHTS
SAFETY QUICK REMIND
SAFE AND DANGER AREA
SLOPE LIMITATION REPLACE SAFETY PARTS
SAFE AREA
DANGER
50m
1m
Operator with
PPE only
Operator with
PPE only
N
o
p
e
o
p
l
e
o
r
a
n
i
m
a
l
s
a
l
l
o
w
e
d
i
n
s
i
d
e
t
h
i
s
p
e
r
i
m
e
t
e
r
N
o
p
e
o
p
l
e
o
r
a
n
i
m
a
l
s
a
l
l
o
w
e
d
i
n
s
i
d
e
t
h
i
s
p
e
r
i
m
e
t
e
r
Gefahr
Peligro
Danger
Pericolo
Gefahr
Peligro
Danger
Pericolo
6201855
6202543
6202542
314813 TORQUE 130 Nm
30°
45°

3
A - INTRODUCTION
A - INTRODUCTION
INTRODUCTION
This handbook must be considered as part of the machine. The seller of new and se-
cond-hand machines must record in the selling document that this booklet has been gi-
ven along with the machine..
PICTURES USED IN THE HANDBOOK
Before starting use this machine, it is necessary to read carefully this hand-book, learn
and observe all the safety rules indicated with the following symbols.
DANGER:
This symbol is used to highlight an important safety information. If this information is
ignored, people are in danger either of possible injures - even serious ones - or death.
In these messages are also described the normal precautions which have to be taken to
avoid the danger. Ignoring these precautions can cause serious damages to the machine.
ATTENTION:
This warning is used in the handbook safety messages when the danger can cause mi-
nor or moderate damages and injuries.
The message can be used also for dangers which can cause damages to the machine or
its components.
IMPORTANT:
It is used for precautions which have to be taken to avoid operations which can shorten
the life of the machine or of its component.
NOTE: This word is used to highlight information which refers to operations in progress.
Any time you see these symbols, whether on the machine or on the following of this ma-
nual you must pay attention to avoid danger to yourself and to other people.
Following some rules suggested by the common sense, you will avoid any break risk and
yourmachinewillfunctionlongerandmoreefciently.

4
B - CONDITIONS AND USE RESTRICTION
B - CONDITIONS AND PROPER USE
DEFINITION OF PROPER USE
• This machine have been designed for grass cutting and weed control in agriculture
andpublicgreen,atandslopedareas.
• The exact observance of use conditions, maintenance and reparation are the essential
element for a correct use.
• The machine should be used, maintained and repaired only by people who have
knowledge of the security rules.
• The general rules about accident prevention and public road circulation rules should be
respected
IMPROPER USES
• Any other use is not allowed. The manufacturer is not responsible for damages caused
by any use than the intended one. The user is fully responsible for any possible risk.
• Each arbitrary modification carried out on the machine could release the manu-
facturer from the responsibility for any damage or accident derived by the machine.
ONLY ONE OPERATOR
The machine was designed to be used by one operator only. The presence of other
people in the closeness could be dangerous for the safety of both user and people.
(see danger area in paragraph 5.12)
ACCESSORIES ON THE MARKET (ONLY IF AUTHORIZED)
Any use of accessories different from the authorized ones by the manufacturer is not al-
lowed. For further applications different from the authorized one or in case of misunder-
standing of this handbook, please contact the technical department of the manufacturer.
BARBIERI s.r.l. - Technical assistance service
36040 SOSSANO - (Vl) - ITALY
Tel: [phone] - Fax: [phone]
e-mail [email protected]
Descriptions, gures and technical features mentioned herein are non-binding for the
Manufacturer. These are mentioned as mere information. The Manufacturer reserves the
right to make any change at any time without notice, to improve the quality of the products
without being bound to update this publication.

5
NOTES

6
C - INDEX
C - INDEX OF CONTENTS
MACHINE IDENTIFICATION
o Serial number
o Type and serial n. engine
o Dimensions
SECTION 1 - TECHNICAL DATA
1.1 Technical data
1.2 Noise
1.3 Vibrations
SECTION 2 - SAFETY NORMS
2.1 Safety devices
2.2 Safety norms
SECTION 3 - MACHINE PREPARATION
3.1 Endownment and unpacking
3.2 Preliminary tests
SECTION 4 - CONTROL COMPONENTS
4.1 Name of main components
4.2 Engine
4.2.1 Airlter
4.2.2 Fuel tank
4.3 Cutting system
4.4 Electric system
4.5 Beacon net
4.6 Transmission
4.7 Radio controller
SECTION 5 - SAFE USE INSTRUCTIONS
5.1 Connection to Radio controller
5.2 Starting the engine
5.3 Stopping the engine
5.4 How to drive
5.5 Drive on slope
5.6 Braking system and parking
5.7 PTO (Starting cutting blades)
5.8 Cutting height adjustment
5.9 Auxiliary socket
5.10 Checks during use
5.11 Access to working area
5.11.1 Loading/unloading on/from truck
5.12 Safety on working area
5.13 Use of Compass Drive (optional)
SECTION 6 - TROUBLESHOOTING
6.1 List of Radiocontroller errors
SECTION 7 - MAINTENANCE
Major maintenance components
Lubrication points
7.1 Test before use
7.1.1 Engine oil check
7.1.2 Engineairlter
7.1.3 Fuel tank
7.1.4 Check track and their tension
7.1.5 Radiocontroller battery replacement
7.1.6 Cutting blade check
7.2 Maintenance and adjustment
7.2.1 Lubrication program
7.2.2 Engineoilandlterreplacement
7.2.3 Reductors oil check and replacement
7.2.4 Lubrication joints
7.2.5 Cleantheairlter
7.2.6 Adjustment belt tension PTO
7.2.7 Sharpening and replacement of blade
7.2.8 Track replacement
7.2.9 Tensioner use
7.2.10 Protective chain and rubber
7.2.11 Radiocontroller battery
7.3 Disposal advices
SECTION 8 - CLAIM AND WARRANTY
8.1 Denition
8.2 Warranty start
8.3 Warranty duration
8.4 Engine warranty
8.5 Warranty form
SECTION 9 - DECLARATION OF CONFORMITY

7
D - IDENTIFICATION NUMBER
D - IDENTIFICATION NUMBER
In the event of a problem, before contacting the dealer for repairs or to order spare parts,
thefollowingidenticationnumbersofthemachinemustbenoted:
• Model and chassis number
• Engine type and serial number
Chassis number Type
Fig. 1
number of the engine (Kawasaki engine)
Fig. 2
DIMENSIONS (mm)
Fig. 3
13751450
844
995

8
SECTION 1 - TECHNICAL DATA
1 - TECHNICAL DATA
1.1 Technical data
Manufacturer KAWASAKI Generator 1 3 phases 34VAC - 80A
Model
FS730V EFI Electric start Generator 2 --
Engine type Air cooling 4S OHV petrol
Forced lubrication Type Mulching rear discharge
Net power
17.2 kW (23 HP) / 3600 rpm Blades 2 swinging - 2600 rpm
Max. torque 50.4 Nm / @ 2.400 rpm Working width 95 cm Displacement 726 (2 cylinders) cm3 Hight regulation 30-150 mm da Radio Coman. Diameter x stroke 78 x 76 mm Transmission By belt EM-Clutch Spark control Electric ignition Start system Electric START
Air filter
Sponge Radio Technology AFA (Autom. Frequency Agility)
Fuel capacity 32 Lt Joystick Optic Fuel consumption 3.5 L/h - 3000 rpm Reach 200 m Engine oil capacity 2 Lt Norms Comm. Protocol CAN SAE J1939
Alternator
12V - 30A Weight 1,3 Kg.
Type
Hybrid engine 48V Overall dimensions 1375 x 1450 x 844 w/ reductors and brakes Weight 480 Kg
Control
Electric Soil pressure 171 g/cm2
Speed
0-8 Km/h Soil contact area (17,5x80x2) = 2800 cm2
Slope
35° Front. - Later. 45°
Degree/Gravity centre 65° / 15cm E-Motor type Brushless Magnete perm.
3 phases
E-Motor power
4 kW
Electronic control BHV - 48V 100A Servodrive Compass Servo Drive
RADIOCONTROLER 2,4 GHz
GENERATOR
ENGINE
TRANSMISSION
DIMENSIONS
CUTTING SYSTEM
Direttive R&TTE 1999/5/CE
2006/42/CE PLe categoria 4 /SIL 3
ISO 13849-1:2008 / EN62061:2005”

9
SECTION 1 - TECHNICAL DATA
1.2 Noise
The noise level was obtained during the equipment in action, in neutral position and the
results are the following:
Kawasaki Motor FS730V (4 strokes) with original mufer
- Acoustic pressure level (LpAm) .... 94,6 dB(A)
- Acoustic power level (LwA)...........107,5 dB(A)
1.3 Vibrations
The vibrations level was obtained with the machine at work at 3060 rpm (85% of the no-
minal condition of 3600 rpm) and the results are the following:
- Not applicable
LABELS AND WARNINGS POSITION
Fig. 4

10
SECTION 2 - SAFETY NORMS
2 - SAFETY NORMS
2.1 SAFETY DEVICES
The terms “FRONT” - “REAR” - “RIGHT” - “LEFT” used in this handbook and in the spare
parts catalogue, are referred to the machine as shown in Fig. 5
SAFETY PARTS
The machine is equipped with a series of safety devices to comply with the Machinery
Directive. All safety devices are necessary for the safe use of the machine and in case
same of them are of missing, damaged or weared it is mandatory to replace them with
genuine spare part. Do not attempt to repair a safety component.
DANGER:
Do not use for any reason the machine with a wear, damaged, or missing safety ele-
ment. Replace the safety component with genuine parts before to use the machine.
The use of the machine without efcient safety element can cause injure or death.
In detail, the following devices are provided for safety:
1 - Engine-Stop devices (A) (B) and (C)(Fig.5)
2 - Automatic brake system in case of engine stop
3 - Front and rear shield to stop the objects throwed by the blade (Fig. 5)
4 - Blade and blade fasteners (Fig. 5)
5 - Engine stop in case of loss of the RadioControl signal
6 - Transmission belt’s cover
7 - Warning labels
8- Transmission belt protection
Motor STOP
Fig. 5
C
Blade fasteners
Blade supp.
Blade
Front Flap-Guard
Rear debris Chain
&
rubber guard Belt cover bonnet
Left
Front
Back
Right
BA

11
2 - SAFETY NORMS
SECTION 2 - SAFETY NORMS
2.2 WARNING LABELS AND SAFETY ADVICES
The most important warning labels are placed near to the danger around the machine.
Be sure to understand the meaning of the lables in order to use a proper behavior to
avoid any danger action. These labels are very important for the safe use of the machine
along the time. Keep these lable clean and in a good condition. In case of damage or lack
of such a lables it is mandatory to replace them with original ones.
CAUTION LABEL AND WARNINGS
Besides CE mark, safety pictures and indications are applied on
themachineandmentionedintheg.4.
WARNING: BEFORE SERVICING
Read the technical instructions in the operation
manual before servicing the machine.
WARNING: RISK OF INJURY
Stay away of the discharge opening of the mower deck because
stones or other hard objects ejected from the mower may hit you.
Usevisortoprotectfromyingobject
DANGER FOR HANDS AND FEET:
Cutting blade: keep hands and feet away.
WARNING:
Radio controlled machine.
Keep yourself at safe distance.
WARNING:
Danger of crushing hands.
WARNING:
Exhaust gas is poisonous!
Do not start the engine in a not ventilated room.
WARNING:
Petrol vapors are explosive.
Donotrefuelnearfreeames,sparksorsmokingperson.

12
SECTION 2 - SAFETY NORMS
2 - SAFETY NORMS
WARNING:
Do not work in slopes over the limits Stability and engine lubric. can be lost
DANGER : RISK OF INJURY
On a slope, stay below never above the machine.
CONDITIONS AND PROPER USE
1) Before starting the engine, be sure that the SAFETY DEVICES are well working and
tting.Withoutthesecarestheoperatormightworkinadangersituation.
2) This machine has been designed and manufactured for being used by one operator
only who hold the Radiocontrol. Any other use is not permitted!
3) It is important to ensure a safe distance between the operator and the machine in the
Work Field (see cap.5.12)
4) Before the machine is operating, read the Use and Maintenance manual thoroughly,
so that you are fully aware of all the operating controls and safety aspects of the
machine.
5) Nomodicationtothemachineoruseofnotgenuinesparepartscanbedonewithout
the Manufacturer consent. This praxis can lead to very dangerous and unpredictable
situation and will anyway nullify the warranty.
6) Do not under any circumstances transport people or objects on the machine.
7) Before use, check that all the controls and safety components are assembled and in
good condition (see chapter 2.1)
8) Move the controls gradually; sudden engagement could cause the loose of stability
of the machine.
9) Checkanytimethatallthepartsallwellxed
10) This machine have not to be used by children or inexperienced persons. Operators
that are not duly trained of people that are under effect of alcohol or other substances.
11) Before operating the machine, check that the area is clear and free of debris and
that there are no people within the Work Field. The operator will be held responsible
for the safety of third parties, if these are found within the Work Field. Stop work in
these cases.
Pericolo
Sicuro

13
2 - SAFETY NORMS
SECTION 2 - SAFETY NORMS
12) Do not use the machine when you are tired
13) Keep away from cutting blades at all times while the machine is in operation. Observe
carefully to avoid the danger area (See chap. 5.12).
14) Use only genuine spare parts and accessories especially the safety parts (chap.2.1)
to guarantee the safety and the function of the machine.
15) Stop engine before refuelling
16) Handle the fuel with care to avoid spilling on the machine; clean any spillage
immediately.
17) Avoidoverllingthefueltank
18) Plan well your work before starting
19) The area next to the engine exhaust will most likely reach temperatures above 80°.
ATTENTION: Danger of scalding.
20) Keep the area of work clear and clean.
21) Only use the machine in clear visibility.
22) If you hit any objects during the work, stop the machine and check for any damage
immediately. For the blade and blade’s fasteners integrity refer to par.7.1.6
23) Itisadvisabletokeeparstaidkithandy.
24) The speed of the machine must be convenient to the environment conditions
25) Never do maintenance or cleaning works when the engine running.
26) When possible, avoid working up or down-hill. Always travel across the slope.
27) Do not work on very steep slopes more than 100% (max.45°).
28) During use, keep the hot sections of the engine (i.e. cylinder head, exhaust, etc.)
clean to avoid a stack-up of debris that will overheat the engine.

14
SECTION 2 - SAFETY NORMS
2 - SAFETY NORMS
29) Wheneverpossible,stopthemachineonaatground.
30) Park the machine in an unaccessible place for children or unauthorized persons:
stop the machine and remove the Start key from the dashboard.
31) Donotstopandleavethemachinewiththeenginerunning.Reachaatground
and stop the engine.
32) Follow carefully the maintenance instruction and replace always the damaged and
worn parts with genuine spare part, if necessary.
33) Storage the machine after cleaning it, only.
34) If any, it is necessary to take heed of the specific safety norms in force in the
Country where the machine is operating.
35) Never refuel in confined places, in vicinity of open flames or near the source of
sparks. No smoking during fuel handling!
36) Never start the engine in a closed place. Exhaust fumes contain poisonous carbon
monoxide,sosufcientventilationshouldbeprovidedwhenstartingtheengine
indoors.
37) After storage of the machine for a long period, make a deep cleaning and lubricate
the machine according to the lubrication program.
38) Pay particular attention to all safety screens (front and rear bulkheads). Damage or
lack of them can cause serious accidents and even death.
DANGER:
Do not attempt to use the machine if some safety protections are missing or
damaged. Immediately restore these protections with original spare parts, before
starting work.

15
3 - MACHINE PREPARATION
SECTION 3 - MACHINE PREPARATION
3.1 Endownment and unpacking
The machine is supply with:
1 x Basic Unit X-Rot
1 x Radio Control
2 x Lithium battery for Radio control
1 x Battery charger
1 x Radio control’s hanging belt
1 x User Manual & Engine user manual
1 x Keys Kit
Before operating the machine, check the fuel and engine oil levels and carefully read the
operating instructions for safety regulations and procedures for starting and controlling
the machine.
3.2 PRELIMINARY TESTS
Beforetousethemachineforthersttime,itisnecessarytoverify:
• Engine oil level (see Cap. 7.1.1)
• Fuel level in the tank (see Cap. 7.1.3)
• Battery charge on the Radio receiver (see Cap. 7.1.5)
- The engine oil should be always on the mark of the upper level. Lack of oil will
decrease the engine performance on the slope.
- The fuel level should be near to the max but not reaching the collar of the tank. In
caseofslopethefuelcanspilloutandcreateadangerofre.
- The 2 battery set have to be charged before to start any work. One battery should be
enough for one day operation but the 2nd one is required in case of need.
Fig. 6

16
SECTION 4 - CONTROL COMPONENTS
4 - CONTROL COMPONENTS
4.1 NAME OF MAJOR COMPONENTS (Fig.7)
Basic Unit: Identication of the main components.
A) Tensor wheels H) Electric cabinet O) Servodrive
B) Crawler’s roller I) Power key P) Antenna
C) Drive wheel J) Engine - Air inlet Q) Remote control
D) Crawler Belt K) Oil deepstick R) Fron Flap-guard (*)
E) Rear Flap-guard (*) L) Emergency switch (*) S) Blade support
F) Drive motors M) Air lter T) Blade*
G) Fuel tank N) Battery U) Blade Fasteners (*)
V) Mower deck
Z) Belt cover bonnet
(*) Safety Parts
U
G
V
CA
J M
H
D
L
E
B
G
I
P
ST
K
Z
R
F
Fig. 7
N
O
Q

17
4 - CONTROL COMPONENTS
SECTION 4 - CONTROL COMPONENTS
4.2 ENGINE
The machine is equipped with a high-quality petrol engine
from the USA, which guarantees the product a long service
life. The engine is equipped with an innovative electronic
control system (ECU) that constantly monitors the envi-
ronmental conditions and engine performance in order to
always offer the best and most economical performance.
To start the engine, see chap. 5.2. Although the engine is
equipped with forced lubrication in order to work on slopes,
it is advisable not to exceed 35 °.
The working limit angles are displayed on the machine and in the lower part of the
remote control
IMPORTANT:
Do not leave the machine on a slope with the engine running. Lubrication without
shaking can be insufcient and cause the engine to break. Also, avoid parking the
machines on a slope to prevent engine uids from spilling. Always drive the
machine on level ground when parking and switching off the engine.
Therst50workinghoursrepresenttherun-inoftheengine.Duringthisrstperiodwe
recommend not to use the machine at the full power. It is also necessary to leave the
engine running for few minutes at the idle speed for warming after starting. A sudden use
at the max power just after starting cause a thermal shock to the engine components.
4.2.1 AIR FILTER
Theengineisequippedforalterfortheinletair.Inthecase
ofdrygrassandcongestedareas,theairltermustbeclea-
ned very often (every 2 hours). If dry blades of grass stick to
the automatic openings of the engine’s power generator (Fig.
7-J),itisverylikelythattheyarealsointheairlter,which
mustbecleaned.(seeSection7.1.2).Acloggingoftheairl-
tercanleadtoalossofengineperformance.Theltershould
be cleaned daily under normal conditions.
4.2.2 FUEL TANK
The double tank holds 32 liters of petrol, which should gua-
rantee 6 hours of work. Before starting work, remember to
refuel. The fuel level in the second tank is 3 liters and is indi-
cated by an indicator light on the remote control, which indi-
cates that it is time to refuel. Interrupt the work and bring the
machinetollonlevelground.
DANGER:
Be careful when refueling: Petrol is highly explosive. Do not attempt to refuel if
anyone is smoking or standing near sparks or open ames.

18
SECTION 4 - CONTROL COMPONENTS
4 - CONTROL COMPONENTS
4.3 MOWER DECK
The cutting deck has a special shape to reduce the power
requirement. The knife is driven directly from the motor
via a belt that is connected to an electromagnetic (EM)
clutch. The knives are activated with a button on the re-
mote control and electronically controlled depending on
the engine status. (see chapter 5.7). The blades used
are a compromise between cutting results and impact
resistance to enable heavier work. The knives and knife
fastening screws as well as the chains and rubber
guards on the mower deck are SAFETY COMPONEN-
TS and must be checked regularly (see maintenance
program in section 7.2.1.) The cutting height can be
set directly via the remote control and is indicated by the
display on the right-hand side of the machine (see Figure
8). For maintenance of EM coupling, knives and belts see
chapter 7.2.7.
4.4 ELECTRICAL SYSTEM
The machine is driven electrically. 4 microprocessors
control the functions of the machine to ensure maximum
safety at all times. A motor-driven alternator generates a
voltage of 48 V (Extra Low Voltage - ELV), which is safe
from electrical hazards for people. The caterpillars are
driven by 2 brushless motors that are electronically con-
trolled by 2 inverters that run sophisticated software that
makes the machine easy to use and flexible. The radio
receiver and the fuse and relay box are easily accessible
via the switch cabinet on the back of the machine (Fig. 9).
The electrical system has protection class IP 54.
4.5 BEACONNET
Themachineisequippedwithacoloredashinglightthat
can easily tell the operator the status of the machine: on,
off, alarm, danger, PTO on, power steering, etc.
This simple tool is very effective and convenient for the
operator who receives information simply by watching the
machine in motion. (See Section 5)
Fuse Box
Receiver
Fig. 8
Fig. 9

19
4 - REMOTE CONTROL FUNCTIONS
SECTION 4 - REMOTE CONTROL FUNCTIONS
4.6 TRANSMISSION
The power is transmitted to the tracks via two robust and low-noise spur gears. The por-
tal shape of the drive enables a very low center of gravity, which is only 15 cm from the
ground. The design technology of the motors ensures a high torque even at standstill.
These two properties make the machine suitable for steep inclines, and in the event of a
power failure, a passive braking system prevents the machine from being out of control
and descend uncontrollably
4.7 RADIO CONTROL
The remote control has robust and reliable electronics that allow the control of all move-
ments of the machine. It works with a frequency of 2.4 GHz and AFA technology (Auto-
matic Frequency Adjustment), which automatically searches for the freest transmission
frequency in the event of interference.
Special Functions
The radio control is equipped with a display that allows the visualization of alarm mes-
sages with a code indicating the type of anomaly. In the event of an alarm, vibration
attracts the operator’s attention.
RADIO TRANSMITTER CONTROLS
A Radio connect button I “Autopilot” ready
B Engine start button (with (A)) L Reception connected control light
C Auxiliary socket switch M Setting lever for the auxiliary cylinder
D D Button N Reference switch for the drive direction
E Max Speed limiter O Alarm switch (engine stop)
F Cutting height adjustment lever P PTO switch
G Drive control F./R. - L/R Q engine throttle
H Radio connection control light SHIFT 2° Function
K Low battery j Backlight
Fig. 10
C
SHIFT
O
GL
IK
H
F
PQ MN
A
B
E
D
Screen Selector
