Becken BWM5379WH User manual

Washing
Machine
Lavadora
Máquina de Lavar Roupa
BWM5379WH
BWM5379IX
BWM5380WH
BWM5381WH
BWM5381IX

Dear client,
Thank you for purchasing this product.
The quality of this appliance has been certified by several
laboratory tests. This instructions manual is provided to
simplify the use of the appliance as well as to guarantee a
safe use.
Please read carefully the instructions and safety measures
described in this manual.
We sincerely hope you will be satisfied when using your new
appliance.

3
EN
Washing Machine | Lavadora | Máquina de Lavar Roupa
INDEX
1. SAFETY INSTRUCTIONS 4
1.1. Power Supply 5
1.2. Power Cord and Other Cables 5
1.3. Humidity and Water 6
1.4. Cleaning 6
1.5. General Precautions 6
2. OPERATING INSTRUCTIONS 12
2.1. Product Description 12
2.2. Product usage 18
2.3. Maintenance 30
2.4. Troubleshooting 34
3. TECHNICAL SPECIFICATIONS 36
4. POST-SALE SERVICE 42
5. ENVIRONMENTAL PROTECTION 43

4
1. SAFETY INSTRUCTIONS
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning: to avoid the risk of electric shock, do not
remove the cover. The interior does not contain
any parts that can be repaired by the user. Ask for
assistance from the Customer Support Service.
Important Warnings
Before using your appliance read this instructions manual
carefully and keep it in a safe place as you may need to
consult it in the future.
Before turning on your appliance, and to ensure a safe and
correct operation, do not use if:
• It has fallen to the ground;
• You notice any evidence of damage;
• Any anomaly occurs during its operation.
To avoid hazards or deterioration of your appliance through
incorrect use it is advisable to read these instructions thoroughly.
Your appliance may not be used for other purposes than the
ones intended and solely for household use. Any damage
resulting from using the appliance outside this scope, any
incorrect use, as well as any manual modications to the product
will not be covered and automatically voids the warranty.

5
EN
Washing Machine | Lavadora | Máquina de Lavar Roupa
Assistance
In case of malfunction, take your appliance to the Customer
Support Service for assistance.
This appliance can be used by children aged from 8 years
and above if they have been given supervision or instruction
concerning use of the appliance in a safe way and if they
understand the hazards involved. Cleaning and user
maintenance shall not be made by children unless they are
older than 8 and supervised. Keep the appliance and its cord
out of reach of children aged less than 8 years. Appliances
can be used by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
These instructions are also available at
www.suporteworten.pt
1.1. Power Supply
Make sure the main voltage is compatible with the appliance’s. If this is
not the case please consult the Customer Support Service.
1.2. Power Cord and Other Cables
Do not tangle the cord or pull it to disconnect the appliance. Also, keep
the cord away from warm surfaces.
Never use the appliance if it has a damaged cable or socket.
Take it to the Customer Support Service for replacement.

6
1.3. Humidity and Water
Do not use your appliance in humid places. Do not allow the appliance
to become wet under any circumstances as this may be dangerous.
To avoid fire hazard or electric shock do not expose your appliance
to humidity or water. Furthermore, do not place your appliance under
water (e.g. for cleaning).
1.4. Cleaning
Before cleaning, be sure to switch o the appliance and remove the
plug from the main power supply. Always allow the unit to cool down
before cleaning.
To clean the exterior of the product use a dry soft cloth only.
1.5. General Precautions
• Please follow the instructions in the user manual which will help you
to properly install and operate this product and enjoy its advanced
features. Please keep the instructions for future reference.
• Read all instructions before using the product.
• Maintenance and service operations are only to be carried out by
authorized professionals.
• Any damage caused by manual modifications to the product is not
covered by the warranty.
• If this product is used for other purposes than the ones originally
intended, or if it is not correctly connected, the product may become
damaged and the warranty will be voided.
• For your safety, the information in this manual must be followed to
minimise the risk of fire or explosion, electric shock, or to prevent
property damage, personal injury or death.

7
EN
Washing Machine | Lavadora | Máquina de Lavar Roupa
Symbol explanation:
Warning!
This combination of symbol and signal word indicates a potentially
dangerous situation which may result in death or serious injuries
unless it is avoided.
Caution!
This combination of symbol and signal word indicates a potentially
dangerous situation which may result in slight or minor injuries or
damage to property and the environment.
Note!
This combination of symbol and signal word indicates a potentially
dangerous situation which may result in slight or minor injuries.
Warning!
Risk of electric shock
• The new hose-sets supplied with the appliance are to be used and
the old hose-sets should not be reused.
• Before performing any maintenance to the appliance, unplug it from
the mains.
• Always unplug the machine from the mains and turn o the water
supply after use. The max. and min. inlet water pressure is in pascals.
• For your own safety, the power plug must be inserted into an
earthed three-pole socket. Please check this carefully and make sure
that your socket is properly and reliably earthed.

8
• Please make sure that water and electrical devices are connected
by a qualified technician in accordance with the manufacturer’s
instructions and local safety regulations.
• Before cleaning or performing any maintenance to the appliance,
unplug it from the mains.
• Do not use any socket with a rated current below than that of the
appliance’s. Never pull the power plug out with your hands wet.
• Please remember to disconnect the water and power supply
immediately after your clothes are washed.
Risk to children
EN countries:
• Children under 3 years old should be supervised to ensure that they
do not play with appliance.
• Please be aware that animals and children may climb into the
machine, so check the machine before every operation.
• Please note that the glass door may be very hot during operation.
Keep children and pets far away from the machine during operation
in very humid rooms as well as in the rooms with explosive or
caustic gases.
• Remove all packaging materials and transport bolts before using the
appliance. Otherwise, it may result in serious damage.
Risk of explosion
• Do not wash or dry items that have been cleaned in, washed in,
soaked in, or dabbed with combustible or explosive substances
(such as wax, oil, paint, gasoline, degreasers, dry-cleaning solvents,
kerosene, etc.), as this may result in a risk of fire or explosion.

9
EN
Washing Machine | Lavadora | Máquina de Lavar Roupa
• The washer dryer is not to be used if industrial chemicals have been
used for cleaning.
• The exhaust air must not be discharged into a flue which is
designed for exhausting fumes from appliances burning gas or
other fuels.
• Thoroughly rinse any items washed by hand beforehand.
Caution!
• This appliance is for indoor use only, and not intended for built-in
use.
• Please make sure the openings are not obstructed by a carpet.
• This appliance shall not be installed in bathrooms or very humid
rooms as well as in rooms with explosive or caustic gases.
• A single inlet valve appliance can only be connected to the cold
water supply, whereas a double inlet valve appliance should be
correctly connected to the hot water and cold water supply.
• After installation, make sure the plug is easily accessible.
• Please be aware that this appliance must not be installed behind a
lockable door, a sliding door or a door with a hinge on the opposite
side to that of the washer dryer.
• Remove all packaging materials and transport bolts before using the
appliance. Otherwise, it may result in serious damage.
Risk of damaging the appliance
• The product is only intended for home use and is only designed for
textiles suitable for machine washing and drying.

10
• Do not climb up and sit on the top cover of the machine, nor lean
against the machine door.
Cautions when handling the machine:
• Transport bolts shall be reinstalled onto the machine by a qualified
technician.
• Any accumulated water shall be drained out of the machine.
• Please handle the machine carefully. Never hold any protruded part
on the machine while lifting it, nor use the door as a handle during
transport.
• Attention: This appliance is heavy. Please handle with care.
• Do not insert your hands shall into the running water extracting tub.
• Please do not use excessive force to close the door. If you find it
diicult to close the door, please check if all clothes are well put in or
distributed.
• Please not that it is forbidden to wash carpets in the appliance.
Operating the appliance
• Before using the washing machine, please make sure the unit is
calibrated.
• Before washing any clothes for the first time, the unit shall be fully
operated in one round without any clothes inside.
• Please not that flammable and explosive or toxic solvents are
forbidden. Gasoline and alcohol, etc. shall not be used as detergents.
Please only select detergents suitable for machine washing,
especially for drum machines.
• Please make sure that all pockets are emptied, as sharp and rigid

11
EN
Washing Machine | Lavadora | Máquina de Lavar Roupa
items such as coins, brooches, nails, screws or stones, etc. may cause
serious damages to this machine.
• Please check whether the water inside the drum has been drained
before opening its door and do not open it if there is any visible water.
• Please be careful not to get burnt when the unit drains hot washing
water.
• After the programme is completed, please wait two minutes before
opening the door (for some models).
• Never refill the machine with water by hand during washing.
• Any fabrics that contain vegetable or cooking oil or have been
contaminated by hair care products must first be washed in hot
water with an extra amount of detergent before being placed in a
tumble dryer as this will reduce, but not eliminate, any hazards.
• Adequate ventilation must be provided to avoid the back flow of
gases into the room from appliances burning other fuels, including
open fires.
• Do not dry unwashed items in the appliance.
• Items that have been soiled with substances such as cooking oil,
acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes
and wax removers should be washed in hot water with an extra
amount of detergent before being dried in the appliance.
• Items such as foam rubber (latex foam), shower caps, water proof
textiles, rubber backed items and clothes or pillows fitted with foam
rubber pads should not be dried in the machine.
• Fabric softeners, or similar products, should be used as specified by
the fabric softener manufacturer’s instructions.

12
• Machine with a lid that can be open during the cycle for water
extraction can take 15s or more to come to a full stop or to empty
the water from the drum.
• The final part of a washer dryer cycle occurs without heat (cool
down cycle) to ensure that items are left at a temperature that does
not damage them.
• Remove any objects from pockets such as lighters and matches
before using the appliance.
• WARNING: Never stop a washer dryer before the end of the drying
cycle unless all items are quickly removed and spread out so that
the heat is dissipated.
2. OPERATING INSTRUCTIONS
2.1. Product Description
Top cover
Control panel
Power supply cord
Drum
Service filter
Drain hose
Door
Detergent
dispenser
Water supply
hose

13
EN
Washing Machine | Lavadora | Máquina de Lavar Roupa
Note!
The product line chart is for reference only. Please refer to the actual
product as standard.
Accessories
Transport
hole plug
Cold water
supply hose
Hot water
supply hose
(optional)
Outlet hose
support
(optional)
Owner’s
manual
Installation
Installation area
Warning!
• Please position the unit on a stable surface in order to prevent it
from wandering.
• Please make sure that the unit does not stand on the power cord.
Before installing the machine, please select a location as characterised
below:
1. Rigid, dry, and levelled surface
2. Avoiding direct sunlight
3. With suicient ventilation
4. With a room temperature above 0 ºC
5. Far away from heat resources such as coal or gas.

14
Unpacking the washing machine
Warning!
• Packaging materials (e.g. films, styrofoam) can be dangerous for
children as there is a risk of suocation.
• Please keep all packaging materials far away from children.
1. Remove the cardboard box and
styrofoam packing.
2. Lift the washing machine and remove
the base packing. Make sure the small
triangle foam is removed together with
the bottom one. If not, lay the unit down
on the surface on one of its sides and
then remove the small foam from the
unit’s bottom manually.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.

15
EN
Washing Machine | Lavadora | Máquina de Lavar Roupa
Removing transport bolts
Warning!
• Transport bolts must be removed from the back before using the machine.
• Please make sure you keep the transport bolts in a safe place as you
will need them again if you move the unit.
To remove the bolts please proceed
as follows:
1. Loosen all 4 bolts with a spanner and
then remove them.
2. Stop the holes with transport hole plugs.
3. Keep the transport bolts properly for future use.
Levelling the washing machine
Warning!
• The lock nuts on all four feet must be screwed tightly against the housing.
1. Please check if the legs are closely attached to the cabinet. If not,
turn them to their original positions and tighten the nuts.
2. Loosen the lock nut and turn the feet until it closely contacts with
the floor.
3. Adjust the legs and lock them with a spanner, making sure the
machine is steady.
Raise Lower
Lock
nut
Foot

16
Connecting the water supply hose
Warning!
• To prevent any leakage or water damage, please follow the
instructions in this chapter.
• Do not kink, crush, modify or sever the water inlet hose.
• For models equipped with a hot valve, connect it to the hot water
tap with the hot water supply hose.
• Please note that energy consumption will decrease automatically for
some programmes.
There are two ways to connect the inlet pipe. To do it, proceed as
follows:
5mm clamp
nut
slide bushing
Loosen the clamp
nut and all four
bolts
Tighten the
clamp nut
The connection is
concluded
Press the slide
bushing, and insert
the inlet hose into the
connecting base
Connecting the water supply hose
slide bushing
Tap with threads and inlet hose Special tap for washing machines

17
EN
Washing Machine | Lavadora | Máquina de Lavar Roupa
Connect the other end of the inlet pipe to the inlet valve at the back of
the unit and tightly fasten the pipe clockwise.
water supply hose
water Inlet
valve
Drain hose
Warning!
• Do not kink or protract the drain hose.
• Position the drain hose properly, otherwise there is a risk of damage
due to water leaks.
There are two ways to place the end of the drain hose:
1. Insert it in the water trough.
2. Connect it to the branch drain pipe of the
trough.
Max.100cm
Min.60cm
Note!
• If the machine has a drain hose support, please install it as follows.

18
Trough Hose
Retainer
Bind
Max.100cm
Min.60cm
Min.60cm
Max.100cm
Warning!
• When installing the drain hose, fix it properly with a rope.
• If the drain hose is too long, do not force it into the washing machine
as this will cause abnormal noises.
2.2. Product usage
Quick Start
Caution!
• Before washing, please make sure the appliance is properly installed.
• Before washing any clothes for the first time, the unit shall be fully
operated in one round without any clothes inside, as follows.
Calibration
It is recommended to calibrate the washing machine so that it performs
better.
1. Empty the washing machine;
2. Plug it in;
3. Press “Power” on the washing machine and then “Delay” and “Spin”
at the same time for 10 seconds then “t19” is displayed;

19
EN
Washing Machine | Lavadora | Máquina de Lavar Roupa
4. Press to start the washing machine and wait until “****” is
displayed.
Before washing
Main
wash
Pre-wash
Softener
Plug the power
plug in
Add detergentOpen the tap Close the doorLoad your
clothes
Washing
Press “Power” Select the
Programme
Press “Start”Select the
function or use
the default one
Note!
• If default is selected, step 3 can be skipped.
• The function button line chart is for reference only. Please refer to
the actual product as standard.
After washing
The buzzer beeps or “End” appears on the display.

20
Before each washing
• The working temperature of the washing machine should be
(0-40) °C. If it is used under 0 °C, the inlet valve and draining
system may be damaged. If the machine is placed under 0°C or
less, then it should be transferred to normal ambient temperature
to ensure the water supply hose and drain hose do not get frozen
before use.
• Please check the labels and the explanation about how to use the
detergent before washing any items. Use non-foaming or less-
foaming detergent suitable for machine washing.
Check the label Take any items out of
pockets
Knot long strips, zip or
button
Put small clothes into the
pillow slip
Turn easy-pilling and
long-pile fabric inside out
Separate clothes with
dierent textures
Warning!
• When washing a single cloth item, it may easily cause great
eccentricity and trigger an alarm due to great unbalance. Therefore,
it is suggested to add one or two more items to be washed together
so that draining can be done smoothly.
• Do not wash clothes stained with kerosene, gasoline, alcohol and
other flammable materials..
