Beko MCB 25433 BG User manual

www.beko.com
Mcrowave Oven
User Manual
MCB 25433 BG MCB 25433 X
EN DE FR ES PL
SL CS NL TR
01M-8849573200-2016-08

Please read this manual first!
Dear Customer,
Thank you for preferring a Beko product. We hope that you get the best results from
your product which has been manufactured with high quality and state-of-the-art
technology. Therefore, please read this entire user manual and all other accompanying
documents carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well. Follow all
warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this user manual:
C
Important information and useful
hints about usage.
A
Warnings for dangerous situations
concerning the safety of life and
property.
Warning for hot surfaces.
This product has been manufactured in environmental friendly modern plants without giving any harm to the nature.
This appliance conforms to the WEEE regulation. It does not contain PCB.

Microwave Oven / User Manual
3 / 233 EN
CONTENTS
1 Important safety and
environmental instructions 4
1.1 General safety..........................................................4
1.1.1 Electrical safety....................................................6
1.1.2 Product safety......................................................7
1.2 Intended use ............................................................8
1.3 Children’s safety......................................................9
1.4 Compliance with the WEEE Directive and
disposal of waste products ......................................10
1.5 Package information ............................................10
2 Your microwave oven 11
2.1 Overview....................................................................11
2.2 Technical data.........................................................11
2.3 Installing the turntable .......................................12
3 Installation and connection 13
3.1 Installation and connection...............................13
3.2 Built-in installation................................................14
3.2.1 Furniture dimensions for built-in
installation .......................................................................14
3.2.2 Preparing the cabinet.......................................15
3.2.3 Fixing the oven....................................................16
3.3 Radio interference.................................................17
3.4 Microwave cooking principles...........................17
3.5 Grounding instructions........................................17
3.6 Utensil test...............................................................17
4Operation 19
4.1 Control panel............................................................19
4.2 Operating instructions ........................................19
4.2.1 Setting the time..................................................19
4.2.2 Cooking with microwave oven......................19
4.2.3 Microwave keypad instructions...................20
4. 3 Cooking with grill or combination mode......20
4.3.1 (Grill/Combination) Keypad instructions..21
4.4 Convection ...............................................................21
4.4.1 Convection Cooking(With preheating
funtion)..............................................................................21
4.4.2 Convection Cooking( Without pre-heating
function)...........................................................................21
4.5 Quick start ................................................................22
4.6 Defrost.......................................................................22
4.6.1 Defrost by weight..............................................22
4.6.2 Defrost by time...................................................22
4.7 Kitchen timer (counter).......................................22
4.8 Auto menu................................................................23
4.8.1 Auto cooking menu...........................................24
4.9 Multi-step cooking................................................25
4.10 Query function.....................................................25
4.11 Child lock..................................................................25
4.12 Opening the oven door.....................................25
5 Cleaning and maintenance 26
5.1 Cleaning......................................................................26
5.2 Storage.......................................................................26
6 Troubleshooting 27

Microwave Oven / User Manual
4 / 233 EN
1 Important safety and environmental
instructions
Important Safety
Instructions Read
Carefully And Keep For
Future Reference
Thissectioncontainssafetyinstruc-
tions that will help protect from risk
of fire, electric shock, exposure to
leak microwave energy, personal in-
jury or property damage. Failure to
follow these instructions shall void
any warranty.
1.1 General safety
•The microwave oven is intended
for heating food and beverages.
Drying of food or clothing and
heating of warming pads, slippers,
sponges, damp cloth and similar
may lead to risk of injury, ignition
or fire.
This appliance is intended to be
used in household and similar appli-
cations such as:
•Staff kitchen areas in shops, of-
fices and other working environ-
ments;
•Farm houses
•By clients in hotels, motels and other
residential type environments;
•Bed and Breakfast type environ-
ments.
•Do not attempt to start the oven
when its door is open; otherwise
you may be exposed to harmful
microwave energy. Safety locks
should not be disabled or tam-
pered with.
•Do not place any object between
the front side and the door of the
oven. Do not allow dirt or cleaning
agent remnants built-up on the
closure surfaces.
•Any service works involving re-
moval of the cover that provides
protection against exposure to
microwave energy must be per-
formed by authorized persons/
service. Any other approach is
dangerous.
•Your product is intended for
cooking, heating and defrost
food at home. It must not be
used for commercial purposes.
Manufacturer shall not be held li-
able for damages that have arisen
from misuse.
•Do not use this appliance out-
doors, bathrooms, humid environ-
ments or in places where the it can
get wet.

Microwave Oven / User Manual
5 / 233 EN
1 Important safety and environmental
instructions
•No responsibility or warranty claim
shall be assumed for damages
arising from misuse or improper
handling of the appliance.
•Never attempt to dismantle the
appliance. No warranty claims are
accepted for damage caused by
improper handling.
•Only use the original parts or parts
recommended by the manufac-
turer.
•Do not leave this appliance unat-
tended while it is in use.
•Always use the appliance on a
stable, flat, clean dry, and non-slip
surface.
•The appliance should not be oper-
ated with an external clock timer
or separate remote control sys-
tem.
•Before using the appliance for the
first time, clean all parts. Please
see the details given in the "Clean-
ing and Maintenance" section.
•Operate the appliance for its in-
tended purpose only as described
in this manual. Do not use abrasive
chemicals or steam on this appli-
ance. This oven is particularly in-
tended for heating and cooking
the food.
It is not intended for industrial or
laboratory use.
•Do not use your appliance to dry
clothes or kitchen towels.
•Appliance becomes very hot while
it is in use. Pay attention not to
touch the hot parts inside the
oven.
•Your oven is not designed to dry
any living being.
•Do not operate the oven empty.
•Only use utensils that are suitable
for use in microwave ovens.
•Cooking utensil may get hot due
to the heat transferred from the
heated food to the utensil. You
may need oven gloves to hold the
utensil.
•Utensils shall be checked to en-
sure that they are suitable for use
in microwave ovens.
•Do not place the oven on stoves or
other heat generating appliances.
Otherwise, it may be damaged and
the warranty becomes void.
•Microwave oven must not be
placed in a cabinet that is not in
compliance with the installation
instructions.

Microwave Oven / User Manual
6 / 233 EN
•Steam may come out while open-
ing the covers or the foil after
cooking the food.
•Use gloves while taking any kind
of heated food out.
•The appliance and its accessible
surfaces may be very hot when
the appliance is in use.
•Door and outer glass may be very
hot when the appliance is in use.
1.1.1 Electrical safety
•If the supply cord is damaged, it
must be replaced by the manu-
facturer or its service agent or a
similarly qualified person in order
to avoid a hazard.
•Beko Microwave Ovens comply
with the applicable safety stan-
dards; therefore, in case of any
damage on the appliance or power
cable, it should be repaired or re-
placed by the dealer, service cen-
ter or a specialist and authorized
service alike to avoid any danger.
Faulty or unqualified repair work
may be dangerous and cause risk
to the user.
•Make sure that your mains power
supply complies with the informa-
tion supplied on the rating plate of
the appliance.
The only way to disconnect the
appliance from the power supply
is to remove the power plug from
the power outlet.
•Use the appliance with a grounded
outlet only.
•Never use the appliance if the
power cable or the appliance itself
is damaged.
•Do not use this appliance with an
extension cord.
•Never touch the appliance or its
plug with damp or wet hands.
•Place the appliance in a way so
that the plug is always accessible.
•Prevent damage to the power
cable by not squeezing, bending,
or rubbing it on sharp edges. Keep
the power cable away from hot
surfaces and naked flame.
•Make sure that there is no danger
that the power cable could be ac-
cidentally pulled or that someone
could trip over it when the appli-
ance is in use.
•Unplug the appliance before each
cleaning and when the appliance
is not in use.
•Do not pull the power cable of the
appliance to disconnect it from its
power supply and never wrap its
power cable around the appliance.
1 Important safety and environmental
instructions

Microwave Oven / User Manual
7 / 233 EN
•Do not immerse the appliance,
power cable, or power plug in
water or any other liquids. Do not
hold it under running water.
•When heating food in plastic or
paper containers, keep an eye on
the oven due to the possibility of
ignition.
•Remove the wire strings and/or
metal handles of paper or plastic
bags before placing bags suitable
for use in microwave oven to the
oven.
•If smoke is observed, switch off
or unplug the appliance and keep
the door closed in order to stifle
any flames.
•Do not use inside of the oven to
store something. Do not leave
paper items, cooking material or
food inside the oven when it is not
being used.
•The contents of feeding bottles
and baby food jars shall be stirred
or shaken and the temperature
shall be checked before consump-
tion, in order to avoid burns.
•This appliance is a Group 2 Class B
ISM equipment. Group 2 contains
all ISM (Industrial, Scientific and
Medical) equipment in which ra-
dio-frequency energy is intention-
ally generated and/or used in the
form of electromagnetic radiation
for the treatment of material, and
spark erosion equipment.
•Class B equipment is suitable for
use in domestic establishments
and establishments directly con-
nected to a low voltage power
supply network.
•Door or outer surface of the appli-
ance may become hot when it is in
use.
1.1.2 Product safety
•Heating the beverages with mi-
crowave may cause them to boil by
splashing around after they have
been taken out of the oven; so be
careful when you are holding the
containers.
•Do not roast anything in the oven.
Hot oil may damage the compo-
nents and materials of the oven,
and it may even cause skin burns.
•Pierce food with thick crust such
as potatoes, zucchinis, apples and
chestnuts.
1 Important safety and environmental
instructions

Microwave Oven / User Manual
8 / 233 EN
•Appliance must be placed so that
the rear side is facing the wall.
•Before moving the appliance,
please secure the turntable to
prevent damage to it.
•Eggs in their shell and whole hard-
boiled eggs must not be heated in
microwave ovens since they may
explode, even after microwave
heating has ended.
•Never remove the parts at the rear
and sides of the appliance, which
protect the minimum distances
between the cabinet walls and the
appliance in order to allow for the
required air circulation.
1.2 Intended use
•The oven should be cleaned reg-
ularly and any food deposits re-
moved.
•Failure to maintain the oven in a
clean condition could lead to dete-
rioration of the surface that could
adversely affect the life of the
appliance and possibly result in a
hazardous situation.
•Cleaning the door seals and adja-
cent parts: Use hot soapy water.
Clean with a dish cloth, do not
scour. Do not use a metal or glass
scraper for cleaning.
• WARNING: If the door or door
seals are damaged, the oven must
not be operated until it has been
repaired by a competent person.
• WARNING: It is hazardous for
anyone other than a competent
person to carry out any service or
repair operation which involves
the removal of a cover which gives
protection against exposure to mi-
crowave energy.
• WARNING: Liquids and other
foods must not be heated in
sealed containers since they are
liable to explode.
•Microwave oven is intended for
built-in use only.
•Do not use the appliance for any-
thing other than its intended use.
•Do not use the appliance as a heat
source.
•Microwave oven is intended to
thaw, cook and stew food only.
•Do not over-cook foods; other-
wise, you may cause a fire.
•Do not use steam assisted clean-
ers to clean the appliance.
1 Important safety and environmental
instructions

Microwave Oven / User Manual
9 / 233 EN
1.3 Children’s safety
•Extreme caution is advised when
being used near children and per-
sons who are restricted in their
physical, sensory or mental abili-
ties.
•This appliance can be used by the
children who are at the age of 8 or
over and by the people who have
limited physical, sensory or men-
tal capacity or who do not have
knowledge and experience, as
long as they are supervised with
regard to safe use of the product
or they are instructed accordingly
or understand the risks of using
the product. Children should not
play with the appliance. Cleaning
and user maintenance procedures
should not be performed by chil-
dren unless they are controlled by
their elders.
•Danger of choking! Keep all the
packaging materials away from
children.
•Only allow children to use the
oven without supervision when
adequate instructions have been
given so that the child is able to
use the microwave oven in a safe
way and understands the hazards
of improper use.
•Due to excessive heat that arises
in grill and combination modes,
children should only be allowed to
use these modes under supervi-
sion of an adult.
•Keep the product and its power
cable so that they are inaccessible
by children under 8 years old.
•The appliance and its accessible
surfaces may be very hot when
the appliance is in use. Keep chil-
dren away.
•The appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of ex-
perience and knowledge, unless
they have been given supervised
or instruction concerning use of
the appliance by a responsible
person for their safely.
•Young children should be super-
vised to ensure that they do not
play with the appliance.
• WARNING: Only allow children
to use the oven without supervi-
sion when adequate instructions
have been given so that the child
is able to use the oven in a safe
way and understands the hazards
of improper use.
1 Important safety and environmental
instructions

Microwave Oven / User Manual
10 / 233 EN
1.4 Compliance with the WEEE
Directive and disposal of
waste products
This product does not include harmful
and prohibited materials specified in the
“Regulation for Supervision of the
Waste Electric and Electronic
Appliances” issued by the Ministry of
Environment and Urban Planning. Complies with
the WEEE Directive. This product has been manu-
factured with high quality parts and materials
which can be reused and are suitable for recy-
cling.
Therefore, do not dispose the product with normal
domestic waste at the end of its service life. Take
it to a collection point for the recycling of electrical
and electronic equipment. Ask the local authority
in your area for these collection points. Help pro-
tect the environment and natural resources by re-
cycling used products.
1.5 Package information
Package of the product is made of re-
cyclable materials in accordance with
our National Legislation. Do not dis-
pose of the packaging materials to-
gether with the domestic or other wastes. Take
them to the packaging material collection points
designated by the local authorities.
1 Important safety and environmental
instructions

11 / 233 EN
Microwave Oven / User Manual
Markings on the product or the values stated in other documents supplied with the product are values obtained
under laboratory conditions as per relevant standards. These values may vary according to the usage of the
appliance and ambient conditions. Power values are tested at 230V.
2 Your microwave oven
2.1 Overview
1. Control panel
2. Turntable shaft
3. Turntable support
4. Glass tray
5. Oven window
6. Door group
7. Door safety interlock system
8. Grill rack (only to be used in grill function and
placed on the glass tray)
9. Vacuum lifter for manual door opening
2.2 Technical data
Power con-
sumption
230 V~50 Hz,
1450 W (Microwave)
2500 W (Convection)
1100 W (Grill)
Output
900 W
Operating
frequency
2450 MHz
Ampere value
11.5 A
External
dimensions
595 x 470 x 388 mm
Internal
dimensions of
the oven
266 x 328 x 346 mm
Oven
Capacity
25 Liters
Net weight
21.0 kg
6
7
1
235 4
8
9

Microwave Oven / User Manual
12 / 233 EN
2.3 Installing the turntable
Göbek (alt kısım)
Cam tabla
Döner tabla desteği
Döner tabla mili
•Never place the glass tray upside down. The
glass tray should never be restricted.
•Both glass tray and turntable support must
always be used during cooking.
•All food and containers of food must always
place on the glass tray for cooking.
•If glass tray or turntable support crack or break,
contact your nearest authorized service center.
2 Your microwave oven
Hub (underside)
Glass tray
Turntable shaft
Turntable support

13 / 233 EN
Microwave Oven / User Manual
3 Installation and connection
3.1 Installation and
connection
•Remove all packing material and accessories.
Examine the oven for any damage such as dents
or broken door. Do not install if oven is damaged.
•Remove any protective film found on the
microwave oven cabinet surface.
•Do not remove the light brown Mica cover that
is attached to the oven cavity to protect the
magnetron.
•This appliance has been designed for domestic
use only.
•This oven is intended for built-in use only. It is
not intended for counter-top use or for use
inside a cabinet.
•Please observe the special installation
instructions.
•The appliance can be installed in a 60cm wide
wall-mounted cabinet (at least 55 cm deep and
85 cm off the floor).
•The appliance is fitted with a plug and must only
be connected to a properly installed grounded
socket.
•The mains voltage must correspond to the
voltage specified on the rating plate.
•If the plug is no longer accessible after
installation, an all-pole isolating switch must be
present on the installation side with a contact
gap of at least 3 mm.
•Adapters, multi-way sockets and extension
cords must not be used. Overloading can result
with a risk of fire.
The accessible surface may be hot
during operation.
C
Do not trap or bend the power ca-
ble.

Microwave Oven / User Manual
14 / 233 EN
3.2 Built-in installation
3.2.1 Furniture dimensions for built-in installation
380+2
3 Installation and connection

15 / 233 EN
Microwave Oven / User Manual
3.2.2 Preparing the cabinet
1. Read the instruction on the bottom cabinet template and put the template on the bottom plane of
cabinet.
aa
CENTER LINE
FRONTEDGE
LEFTEDGE
T EDGERIGH
2. Make the marks on the bottom plane of cabinet according to marks "a" of the template.
aa
Vida A
Braket
Merkez çizgi
Screw A
Centre line
Bracket
3. Remove the bottom cabinet template and fix the bracket with screw A.
Braket
Vida A
Screw A
Bracket
3 Installation and connection

Microwave Oven / User Manual
16 / 233 EN
3.2.3 Fixing the oven
1. Install the oven into the cabinet.
- Make sure the back of the oven is locked by bracket.
- Do not trap or bend the power cable.
braket
bracket
2. Open the door, fix the oven to the cabinet with Screw B through the installation hole. Then fix the
trim-kit plastic cover to the installation hole.
Montaj deliği
Vida B
Screw B
Installation hole
3 Installation and connection

17 / 233 EN
Microwave Oven / User Manual
3.3 Radio interference
C
Operation of the microwave oven
may cause interference on radios,
TVs and similar appliances.
•Place the oven as far away from radios and TVs
as possible. Operation of microwave oven may
cause interference to your radio or TV reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the frequency is
the same as the voltage and the frequency on
the rating plate.
•In case of interference, it may be reduced or
eliminated by taking the precautions given
below:
•Clean the door and sealing surface of the oven.
•Set the antenna direction of the radio or TV
again.
•Reposition the oven based on the location of the
receiver.
•Place microwave oven away from the receiver.
•Plug the microwave oven to another outlet,
thus microwave oven and receiver shall be on
different lines.
3.4 Microwave cooking
principles
•Prepare the food carefully. Place the remaining
parts to the outside of the dish.
•Pay attention to the cooking time. Cook in the
shortest time specified and add some more time
if required. Overcooked food may cause smoke
or may be burnt.
•Cover the food while cooking. Covering the food
prevents any splashing and helps to ensure that
food is cooked evenly.
•Turn over food such as poultry and hamburgers
while cooking them in a microwave oven in order
to accelerate cooking of this kind of food. Larger
food such as roast must be turned over at least
once.
•Turn food such as meatballs upside down in the
middle of the cooking and replace them with
each other from the center of the dish to the
outside.
3.5 Grounding instructions
This appliance must be grounded. This oven has a
grounding cable with a grounded plug. Appliance
must be plugged to a wall outlet installed and
grounded correctly. Grounding system allows a
leak wire for the electrical current in case of a
short circuit and reduces the risk of electric shock.
We recommend using an electrical circuit dedi-
cated to the oven. Operating with high voltage is
dangerous and may cause fire or other accidents
that would cause damage to the oven.
AWARNING:
Misuse of grounding
plug may cause electric shock.
C
Ifyouhaveanyquestionson ground-
ing and electrical instructions,
please consult a qualified electric
technician or service personnel.
C
Manufacturer and/or dealer would
not accept any responsibility for in-
juries or damages on the oven that
may occur when electrical connec-
tion procedures are not followed.
3.6 Utensil test
Never operate the microwave oven empty. The
only exception is the utensil test described in the
following section. Some certain non-metal uten-
sils may not be suitable for using in microwave. If
you are not sure whether your utensil is suitable
for microwave, you can perform the following test.
1. Place the empty utensil to be tested into the
microwave oven together with a microwave-
compatible glass filled with 250 ml water.
3 Installation and connection

Microwave Oven / User Manual
18 / 233 EN
2. Operate the microwave oven at max power for
1 minute.
3. Check carefully the temperature of the utensil
being tested. If it is warmed up, it is not suitable
for use in microwave.
4. Never exceed the operating time limit of 1
minute. If you notice arcing during 1 minute of
operation, stop the microwave. Utensils causing
arcing are not suitable for use in microwave.
Following list is a general guide that would help
you in selecting the right utensil.
Cooking utensil Microwave Grill Combination
Heat-resistant glass Yes Yes Yes
Non-heat-resistant glass No No No
Heat-resistant ceramics Yes Yes Yes
Plastic dish suitable for microwave oven Yes No No
Paper kitchenware Yes No No
Metal tray No Yes No
Metal rack No Yes No
Aluminum foil and foil covers No Yes No
Foam materials No No No
3 Installation and connection

19 / 233 EN
Microwave Oven / User Manual
4.2 Operating instructions
4.2.1 Setting the time
When the microwave oven is energized, "0:00”
will be displayed in LED screen and buzzer will ring
once.
1. Press (Kitchen Timer/Clock) twice and the
figures for hours will start flashing.
2. Turn to adjust the hour; the input value
should be between 0 and 23.
3. Press (Kitchen Timer/Clock) and the figures
for minutes will start flashing.
4. Turn to adjust the minutes; the input value
should be between 0 and 59.
5. Press (Kitchen Timer/Clock) to finish time
setting. ":" symbol will flash, and the time will
light.
C
If you press (Stop/Cancel) dur-
ing time setting, oven will auto-
matically return back to previous
mode.
4.2.2 Cooking with microwave
oven
1. Press (Microwave) and “P10” will be
displayed in LED screen.
2. Press (Microwave) again to select the
desired power. Each time you press the key,
“PL10”, “PL8”, ”PL5”, “PL3” or “PL1” will be
displayed respectively.
3. Turn to set the cooking time to a value
between 0:05 and 95:00.
4. Press (Start/+30 Sec./Confirm) again to
start cooking.
Microwave
Grill/Combination
Convection
Defrost
Kitchen Timer/Clock
Start/+30 sec./Confirm
Stop/Cancel
Door Open Key
4 Operation
4.1 Control panel

Microwave Oven / User Manual
20 / 233 EN
CExample:
If you want to use 80%
microwave power to cook for 20
minutes, you can operate the oven
with the following steps.
5. Press (Microwave) once and “P10” will be
displayed in the screen.
6. Press (Microwave) once again to set 80%
microwave power.
7. Press (Start/+30Sec./Confirm) to confirm
and "P 80” will be displayed in the screen.
8. Turn to adjust the cooking time until the
oven displays "20:00".
9. Press (Start/+30 Sec./Confirm) to start
cooking.
The steps for adjusting the time in coding button
are as below:
Setting the dura-
tion Increment amount
0-1 minute 5 seconds
1-5 minutes 10 seconds
5-10 minutes 30 seconds
10-30 minutes 1 minute
30-95 minutes 5 minutes
4.2.3 Microwave keypad
instructions
Order Screen Microwave
Power
1 PL10 100%
2 PL 8 80%
3 PL 5 50%
4 PL3 30%
5 PL 1 10%
4. 3 Cooking with grill or
combination mode
1. Press (Grill/Combination) and "G” will
be displayed in LED screen. Press (Grill/
Combination) repeatedly to select the desired
power. Each time you press the key, “C-1”,”C-
2”,”C-3” and “C-4” will be displayed respectively.
2. Turn to set the cooking time to a value
between 0:05 and 95:00.
3. Press (Start/+30 Sec./Confirm) again to
start cooking.
CExample:
If you want to use
Combi (MWO+Grill) (C-2) to cook for
10 minutes, you can operate the
oven with the following steps.
1. Press (Grill/Combination) once and "G” will
be displayed in the screen.
2. Press (Grill/Combination) twice again select
the Combination 2 mode.
3. Turn to adjust the cooking time until the
oven displays "10:00".
4. Press (Start/+30 Sec./Confirm) to start
cooking.
4 Operation
