Beko EV 5801+ User manual

2820523774 / 02-01-14.(20:27)
Document Number
EV 5801+
Washing Machine
User’s Manual

2/ EN
Washing Machine / User’s Manual
1 Important instructions for safety and environment
This section contains safety instructions that will help protect from risk of personal injury
or property damage. Failure to follow these instructions shall void any warranty.
1.1 General safety
• This product can be used by children at and above 8 years old and by persons whose
physical, sensory or mental capabilities were not fully developed or who lack expe-
rience and knowledge provided that they are supervised or trained on the safe usage
of the product and the risks it brings out. Children must not play with the product.
Cleaning and maintenance works should not be performed by children unless they are
supervised by someone.
• Never place the product on a carpet-covered floor. Otherwise, lack of airflow beneath
the machine will cause electrical parts to overheat. This will cause problems with your
product.
• If the product has a failure, it should not be operated unless it is repaired by the
Authorized Service Agent. There is the risk of electric shock!
• This product is designed to resume operating in the event of powering on after a
power interruption. If you wish to cancel the programme, see "Cancelling the pro-
gramme" section.
• Connect the product to a grounded outlet protected by a 16 A fuse. Do not neglect to
have the grounding installation made by a qualified electrician. Our company shall not
be liable for any damages that will arise when the product is used without grounding
in accordance with the local regulations.
• The water supply and draining hoses must be securely fastened and remain undama-
ged. Otherwise, there is the risk of water leakage.
• Never open the loading door or remove the filter while there is still water in the drum.
Otherwise, risk of flooding and injury from hot water will occur.
• Do not force open the locked loading door. The loading door will be ready to open just
a few minutes after the washing cycle comes to an end. In case of forcing the loading
door to open, the door and the lock mechanism may get damaged.
• Unplug the product when not in use.
• Never wash the product by spreading or pouring water onto it! There is the risk of
electric shock!
• Never touch the plug with wet hands! Never unplug by pulling on the cable, always
pull out by grabbing the plug.
• Use detergents, softeners and supplements suitable for automatic washing machines
only.
• Follow the instructions on the textile tags and on the detergent package.
• The product must be unplugged during installation, maintenance, cleaning and repai-
ring procedures.
• Always have the installation and repairing procedures carried out by the Authorized
Service Agent. Manufacturer shall not be held liable for damages that may arise from
procedures carried out by unauthorized persons.
• If the power cable is damaged, it must be replaced by the manufacturer, after sales
service or a similarly qualified person (preferably an electrician) or someone designa-
ted by the importer in order to avoid possible risks.

3/ EN
Washing Machine / User’s Manual
• Place the product on a rigid, flat and level surface.
• Do not place it on a long-pile rug or similar surfaces.
• Do not place the product on a high platform or near the edge on a cascaded surface.
• Do not place the product on the power cable.
• Never use sponge or scrub materials. These will damage the painted, chrome plated
and plastic surfaces.
1.2 Intended use
• This product has been designed for domestic use. It is not suitable for commercial
use and it must not be used out of its intended use.
• The product must only be used for washing and rinsing of laundry that are marked
accordingly.
• The manufacturer waives any responsibility arisen from incorrect usage or transporta-
tion.
1.3 Children's safety
• Packaging materials are dangerous to children. Keep packaging materials in a safe
place away from reach of the children.
• Electrical products are dangerous for the children. Keep children away from the pro-
duct when it is in use. Do not let them to tamper with the product. Use child lock to
prevent children from intervening with the product.
• Do not forget to close the loading door when leaving the room where the product is
located.
• Store all detergents and additives in a safe place away from the reach of the children
by closing the cover of the detergent container or sealing the detergent package.
While washing the laundry at high temperatures, the loading door glass
becomes hot. Therefore, keep especially the children away from the
loading door of the machine while the washing operation is in progress.
1.4 Package information
• Packaging materials of the product are manufactured from recyclable materials in ac-
cordance with our National Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes. Take them to the packaging
material collection points designated by the local authorities.
1.5 Disposing of the waste product
• This product has been manufactured with high quality parts and materials which can
be reused and are suitable for recycling. Therefore, do not dispose the product with
normal domestic waste at the end of its service life. Take it to a collection point for the
recycling of electrical and electronic equipment. Please consult your local authorities
to learn the nearest collection point. Help protect the environment and natural resour-
ces by recycling used products. For children's safety, cut the power cable and break
the locking mechanism of the loading door so that it will be non-functional before dis-
posing of the product.

4/ EN
Washing Machine / User’s Manual
1.6 Compliance with WEEE Directive
This product complies with EU WEEE Directive (2012/19/EU). This product
bears a classification symbol for waste electrical and electronic equipment
(WEEE).
This product has been manufactured with high quality parts and materials
which can be reused and are suitable for recycling. Do not dispose of the
waste product with normal domestic and other wastes at the end of its servi-
ce life. Take it to the collection center for the recycling of electrical and elec-
tronic equipment. Please consult your local authorities to learn about these
collection centers.
Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited materials specified in the Directive.

5/ EN
Washing Machine / User’s Manual
2 Installation
Refer to the nearest Authorised Service Agent for installation
of the product. To make the product ready for use, review
the information in the user manual and make sure that the
electricity, tap water supply and water drainage systems are
appropriate before calling the Authorized Service Agent. If they
are not, call a qualified technician and plumber to have any
necessary arrangements carried out.
CINFORMATIONS
Preparation of the location and electrical, tap water and waste
water installations at the place of installation is under customer’s
responsibility.
Make sure that the water inlet and discharge hoses as well as the
power cable are not folded, pinched or crushed while pushing the
product into its place after installation or cleaning procedures.
BWARNING
Installation and electrical connections of the product must be
carried out by the Authorized Service Agent. Manufacturer shall not
be held liable for damages that may arise from procedures carried
out by unauthorized persons.
AWARNING
Prior to installation, visually check if the product has any defects on
it. If so, do not have it installed. Damaged products cause risks for
your safety.
2.1 Appropriate installation location
• Place the machine on a rigid floor. Do not place it on a long
pile rug or similar surfaces.
• Total weight of the washing machine and the dryer -with
full load- when they are placed on top of each other
reaches to approx. 180 kilograms. Place the product on a
solid and flat floor that has sufficient load carrying capacity!
• Do not place the product on the power cable.
• Do not install the product at places where temperature may
fall below 0ºC.
• Place the product at least 1 cm away from the edges of
other furniture.
2.2 Removing packaging reinforcement
Tilt the machine backwards to remove the packaging
reinforcement. Remove the packaging reinforcement by
pulling the ribbon.
2.3 Removing the transportation locks
AWARNING
Do not remove the transportation locks before taking out the
packaging reinforcement.
Remove the transportation safety bolts before operating the
washing machine! Otherwise, the product will be damaged.
Loosen all the bolts with a suitable spanner until they rotate
freely (C). Remove transportation safety bolts by turning them
gently. Attach the plastic covers supplied in the User Manual
bag into the holes on the rear panel. (P)
CINFORMATIONS
Keep the transportation safety bolts in a safe place to reuse when
the washing machine needs to be moved again in the future.
Never move the product without the transportation safety bolts
properly fixed in place!
2.4 Connecting water supply
CINFORMATIONS
The water supply pressure required to run the product is between
1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters
of water flowing from the fully open tap in one minute to have your
machine run smoothly. Attach a pressure reducing valve if water
pressure is higher.
If you are going to use the double water-inlet product as a single
(cold) water-inlet unit, you must install the supplied stopper to
the hot water valve before operating the product. (Applies for the
products supplied with a blind stopper group.)
If you want to use both water inlets of the product, connect the
hot water hose after removing the stopper and gasket group from
the hot water valve. (Applies for the products supplied with a blind
stopper group.)
AWARNING
Models with a single water inlet should not be connected to the
hot water tap. In such a case the laundry will get damaged or the
product will switch to protection mode and will not operate.
Do not use old or used water inlet hoses on the new product. It may
cause stains on your laundry.
Connect the special hoses supplied with the product to the
water inlets on the product. Red hose (left) (max. 90 ºC) is for
hot water inlet, blue hose (right) (max. 25 ºC) is for cold water
inlet.
AWARNING
Ensure that the cold and hot water connections are made correctly
when installing the product. Otherwise, your laundry will come out
hot at the end of the washing process and wear out.
Tighten all hose nuts by hand. Never use a wrench when
tightening the nuts. Open the taps completely after making the
hose connection to check for water leaks at the connection
points. If any leaks occur, turn off the tap and remove the nut.
Retighten the nut carefully after checking the seal. To prevent
water leakages and damages caused by them, keep the taps
closed when the machine is not in use.
