ALLIANCE UW60AV Quick setup guide

Parts
www.comlaundry.com
Washer-Extractor
Pocket Hardmount
Refer to Page 5 for Model Numbers
PHM1410C_F232167
UW60PV
UW60AV and UW60VV
WARNING
MACHINEMAYBEHOT
ANDCAUSEBURNS
ATTEMPTNOENTRY UNTIL
BASKETH
ASSTOPPED
SERIOUSINJURYMAYRESULT
Part No. F232167R14
April 2011

F232167 1
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2011, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
Table of Contents
Title Page
Parts Ordering Information........................................................................................................................................ 3
Nameplate Location .................................................................................................................................................. 3
Model Identification ................................................................................................................................................... 5
Pocket Hardmount Washer-Extractor Product Overview .......................................................................................... 6
Product Info - Ordering AC Drives for Models UW60PVQ ........................................................................................ 8
Product Info - Ordering AC Drives for Models UW60PVN or UW60PVP.................................................................. 9
Product Info - Ordering AC Drives for Models UW60PVT....................................................................................... 10
Decals ..................................................................................................................................................................... 12
Control Module - Model UW60PV (Drawing 1 of 4) ................................................................................................ 14
Control Module - Model UW60VV (Drawing 1 of 4) ................................................................................................ 16
Control Module - Model UW60AV (Drawing 1 of 4) ................................................................................................ 18
Control Module - Model UW60PV (Drawing 2 of 4) ................................................................................................ 20
Control Module - Models UW60AV and UW60VV (Drawing 2 of 4)........................................................................ 22
Control Module (Drawing 3of 4) ............................................................................................................................. 24
Control Module (Drawing 4 of 4) ............................................................................................................................. 26
AC Drive - Model UW60PV (Drawing 1 of 2) .......................................................................................................... 28
AC Drive - Model UW60PV (Drawing 2 of 2) .......................................................................................................... 30
AC Drive PowerFlex 40 Drive Kits .......................................................................................................................... 32
Balance Switch, Temperature Probe and Rotation Sensor .................................................................................... 34
Supply Dispenser.................................................................................................................................................... 36
Hoses to Supply Dispenser..................................................................................................................................... 38
Spray Plumbing - Design 5 and 6 UW60PV Models ............................................................................................... 40
Spray Plumbing - Design 7 and 8 UW60PV Models ............................................................................................... 42
Fill Plumbing - Design 5 and 6 UW60PV Models Through 2/29/02 ........................................................................ 44
Fill Plumbing - Design 5 and 6 UW60PV Models Starting 3/1/02 ........................................................................... 46
Fill Plumbing - Design 7 and 8 UW60PV Models.................................................................................................... 48
Fill Plumbing - Models UW60AV and UW60VV ...................................................................................................... 50
Drain System, Overflow and Vent Pipes ................................................................................................................. 52
Basket, Shell and Frame (Drawing 1 of 2) .............................................................................................................. 54
Basket, Shell and Frame (Drawing 2 of 2) .............................................................................................................. 56
Door and Spray Tube.............................................................................................................................................. 58
Door Lock................................................................................................................................................................ 60
Front, Side and Rear Panels................................................................................................................................... 62
Motor and Pulley - Model UW60PV ........................................................................................................................ 64
Motor and Pulley - Models UW60AV and UW60VV................................................................................................ 66
Electric Heat Option ................................................................................................................................................ 68
Steam Heat Option and Transformers .................................................................................................................... 70
Water-Saving System Main View - Design 5 and 6 UW60PV Models .................................................................... 72
Water-Saving System Main View - Design 7 and 8 UW60PV Models .................................................................... 74
Water-Saving System Pump Sub-Assembly - Model UW60PV.............................................................................. 76
Water-Saving System Control Module Sub-Assembly - Model UW60PV............................................................... 78

2F232167
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Auxiliary Water Reuse Inlet - Model UW60PV........................................................................................................ 80
Wet-Clean Assembly Main View - Model UW60PV ................................................................................................ 82
Wet-Clean Assembly Control Module - Model UW60PV ........................................................................................ 84
Security Fasteners .................................................................................................................................................. 86
Special Tools .......................................................................................................................................................... 88
Motor Manufacturer Part Number Location on the Motor’s Nameplate...................................................................90
Parts Index.............................................................................................................................................................. 93

F232167 3
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Parts Ordering Information
If literature or replacement parts are required, con-
tact the source from whom the machine was pur-
chased or contact Alliance Laundry Systems at
[phone] for the name and address of the
nearest authorized parts distributor.
For technical assistance, call either of the num-
bers listed below:
[phone] Ripon, Wisconsin
[phone] Wevelgem, Belgium
Nameplate Location
When calling or writing about your product, be
sure to mention model and serial numbers. Model
and serial numbers are located on nameplate(s)
as shown.
PHM2462P_F232167
Model No.
Serial No.
Voltage Amps
Required Circuit Breaker Amps.
Hz Wire Phase
Max. LoadKGMax. Speed RPMLB
Elec. Heating
Product No. Date Code
KW Steam Press PSI BAR
P
U
S
H

Notes
4F232167
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

F232167 5
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Model Identification
Information in this manual is applicable to these washer-extractor models:
UW60AV
UW60PV
UW60VV
NOTE: This manual applies to models with either 5, 6, 7 or 8 in the 9th position in the model number (e.g. UW60PVQU50001).

6F232167
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Pocket Hardmount Washer-Extractor Product Overview
<
<
12
34
56
A-Control
NORMAL
LIGHT SOIL
UNIFORMS
HEAVY SOIL
STAINED
DELICATE
HOT
HOT
HOT HOT
HOT
HOT
WARM
COLD
START
PERM PRESS
VISA
TM
WASH
ADD
BLEACH
RINSE
SPIN
DOOR
B-Control (Domestic)
60C 60C
40C 40C
95C 95C
<
<
30C
B-Control (International)
Mechanical Timer S-Computer
V-Computer UniLinc Control
WE-6 Control
PHM2979P_F232167
UW60AVXU80001
00000000000
200 – 240
50 – 60 2/3 S3
15
60 27 594
N/A N/A 0.0
10
ETL Listed
ConformsTo ANSI/UL Std. 1206, 3rd Ed
Certified To CAN/CSA Std. C22.2 No.53-1968
Drawings:

F232167 7
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Pocket Hardmount Washer-Extractor Product Overview
REF PART NO. DESCRIPTION COMMENTS
1-ProductFamily UW
2- Capacity (Pounds) 35
60
80
100
125
150
3- Control A (A-Control)
B (B-Control)
M (Mechanical Timer)
P (WE-6 Control)
S(S-Computer)
V (V-Computer)
T (UniLinc Control)
4-Speed 2 (2-Speed)
3(3-Speed)
4 (4-Speed)
V (Variable-Speed)
5- Voltage F (440-480/60/3/3)
N (440-480/50-60/3/3)
O (208-240/60/3/3)
P (380-415/60-60/3/3)
Q (200-208/220-240/50/60/3ph)
R (380-415/440-480/50/60/3ph)
X (200-220/220-240/50/60/1-3)
Y (208-240/60/1/2)
6-OEM U(Standard Specs)
7-DesignSeries 1-8

8F232167
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Product Info - Ordering AC Drives for Models UW60PVQ
MOTOR
(MANUFACTURER
PART NO.)** DRIVE KIT (PART NO.) APPLICATION
F220236
(F-391994-61)
160-Series AC Drive Kit (F0370853-792) Used with machines that have previously been updated from
the 1305-series drive to the 160-series drive using either
F079892911, F079893110, F079892911 or F079893110
1305 to 160-series AC drive retrofit kit; Requires a 3.2-inch
motor pulley. NOTE: If the washer-extractor was updated
from the 1305-series drive to the 160-series drive using
F079893110 1305 to 160-series AC Drive Retrofit Kit,
also order F330284 EMI Filter
F220236
(F-391994-61)
160-Series AC Drive Kit (N/A) Used with design 5 machines; Requires a 3.4-inch motor
pulley; Replaces AC drive F370853
F220236
(F-391994-61)
160-Series AC Drive Kit (N/A) Used with design 6, 7 or 8 machines; Replaces AC drive
F370853
F220214U
(G68094)
160-Series AC Drive Kit (N/A) Used with machines that have previously been updated from
the 1305-series drive to the 160-series drive using either
F079893800 or F079894600 1305 to 160-series AC drive
retrofit kit; Requires a 3.2-inch motor pulley
F220214 (H309) 160-Series AC Drive Kit (N/A) Used with machines that have previously been updated from
the 1305-series drive to the 160-series drive using either
F079894000 or F079894800 1305 to 160-series AC drive
retrofit kit; Requires a 3.2-inch motor pulley
F220214 (A431) 160-Series AC Drive Kit (N/A) Used with machines that have previously been updated from
the 1305-series drive to the 160-series drive using either
F079894200 or F079895000 1305 to 160-series AC drive
retrofit kit; Requires a 3.2-inch motor pulley
F220434 (7695) 160-Series AC Drive Kit (N/A) Used with machines that have previously been updated from
the 1305-series drive to the 160-series drive using either
F079894400 or F079895200 1305 to 160-series AC drive
retrofit kit; Requires a 3.2-inch motor pulley
F220214M
(9-391718-60)
160-Series AC Drive Kit (N/A) Used with design 5 machines; Requires a 3.2-inch motor
pulley
F220214U
(G68094)
Mitsubishi to PowerFlex 40 Drive Kit
(F8171607)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103604
F220214M
(9-391718-60)
Mitsubishi to PowerFlex 40 Drive Kit
(F8171608)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103607
F220236
(F-391994-61)
Mitsubishi to PowerFlex 40 Drive Kit
(F8171609)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103607
F220214U
(G68094)
1305-Series to PowerFlex 40 AC Drive
Kit (F8171601)
Used with machines with a 1305-series AC drive; Includes
AC Drive F8103604
F220214M
(9-391718-60)
1305-Series to PowerFlex 40 AC Drive
Kit (F8171606)
Used with machines with a 1305-series AC drive; Includes
AC Drive F8103607
F220236
(F-391994-61)
1305-Series to PowerFlex 40 AC Drive
Kit (F8171610)
Used with machines with a 1305-series AC drive; Includes
AC Drive F8103608
** NOTE: Refer to Motor Manufacturer’s Part Number on the Motor’s Nameplate for help with determining your motor’s part number.
N/A = Part no longer available

F232167 9
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Product Info - Ordering AC Drives for Models
UW60PVN or UW60PVP
MOTOR
(MANUFACTURER
PART NO.)** DRIVE KIT (PART NO.) APPLICATION
F220236 (F-391994-61) 160-Series AC Drive Kit (N/A) Used with machines that have previously been
updated from the 1305-series drive to the 160-series
drive using either F079893010, F079893210,
F079893010 or F079893210 1305 to 160-series AC
drive retrofit kit; Requires a 3.2-inch motor pulley.
NOTE: If the washer-extractor was updated from
the 1305-series drive to the 160-series drive using
F079893210 1305 to 160-series AC Drive Retrofit
Kit, also order F330283EMI Filter
F220236 (F-391994-61) 160-Series AC Drive Kit (N/A) Used with design 5 machines; Requires a 3.4-inch
motor pulley; Replaces AC drive F370844
F220236 (F-391994-61) 160-Series AC Drive Kit (N/A) Used with design 6, 7 or 8 machines; Replaces AC
drive F370844
F220214U (G68094) 160-Series AC Drive Kit (N/A) Used with machines that have previously been
updated from the 1305-series drive to the 160-series
drive using either F079893900 or F079894700 1305 to
160-series AC drive retrofit kit; Requires a 3.2-inch
motor pulley
F220214 (H309) 160-Series AC Drive Kit (N/A) Used with machines that have previously been
updated from the 1305-series drive to the 160-series
drive using either F079894100 or F079894900 1305 to
160-series AC drive retrofit kit; Requires a 3.2-inch
motor pulley
F220214 (A431) 160-Series AC Drive Kit (N/A) Used with machines that have previously been
updated from the 1305-series drive to the 160-series
drive using either F079894300 or F079895100 1305 to
160-series AC drive retrofit kit; Requires a 3.2-inch
motor pulley
F220434 (7695) 160-Series AC Drive Kit (N/A) Used with machines that have previously been
updated from the 1305-series drive to the 160-series
drive using either F079894300 or F079895100 1305 to
160-series AC drive retrofit kit; Requires a 3.2-inch
motor pulley
F220214M
(9-391718-60)
160-Series AC Drive Kit (N/A) Used with design 5 machines; Requires a 3.4-inch
motor pulley
F220214U (G68094) Mitsubishi to PowerFlex 40 Drive Kit
(F8171706)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103704
F220214M
(9-391718-60)
Mitsubishi to PowerFlex 40 Drive Kit
(F8171710)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103705
F220236 (F-391994-61) Mitsubishi to PowerFlex 40 Drive Kit
(F8171707)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103706
F220214U (G68094) 1305-Series to PowerFlex 40 AC Drive
Kit (F8171708)
Used with machines with a 1305-series AC drive;
Includes AC Drive F8103704
F220214M
(9-391718-60)
1305-Series to PowerFlex 40 AC Drive
Kit (F8171711)
Used with machines with a 1305-series AC drive;
Includes AC Drive F8103705
F220236 (F-391994-61) 1305-Series to PowerFlex 40 AC Drive
Kit (F8171709)
Used with machines with a 1305-series AC drive;
Includes AC Drive F8103706
** NOTE: Refer to Motor Manufacturer’s Part Number on the Motor’s Nameplate for help with determining your motor’s part number.
N/A = Part no longer available

10 F232167
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Product Info - Ordering AC Drives for Models UW60PVT
MOTOR
(MANUFACTURER
PART NO.)** DRIVE KIT (PART NO.) APPLICATION
F220214M
(9-391718-60)
160-Series AC Drive Kit (N/A) Used with design 5 machines; Replaced by F8171608
Mitsubishi to Power Flex 40 Drive Kit
F220214M
(9-391718-60)
160-Series AC Drive Kit (N/A) Used with design 6, 7 or 8 machines
F220236 (F-391994-61) 160-Series AC Drive Kit (F391994-61) Used with design 5 machines; Replaces AC drive
F370853
F220236 (F-391994-61) 160-Series AC Drive Kit (N/A) Used with design 6, 7 or 8 machines; Replaces AC
drive F370853
F220214U (G68094) Mitsubishi to PowerFlex 40 Drive Kit
(F8171607)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103604
F220214M
(9-391718-60)
Mitsubishi to PowerFlex 40 Drive Kit
(F8171608)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103607
F220236 (F-391994-61) Mitsubishi to PowerFlex 40 Drive Kit
(F8171609)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103607
F220214U (G68094) 1305-Series to PowerFlex 40 AC Drive
Kit (F8171601)
Used with machines with a 1305-series AC drive;
Includes AC Drive F8103604
F220214M
(9-391718-60)
1305-Series to PowerFlex 40 AC Drive
Kit (F8171606)
Used with machines with a 1305-series AC drive;
Includes AC Drive F8103607
F220236 (F-391994-61) 1305-Series to PowerFlex 40 AC Drive
Kit (F8171610)
Used with machines with a Mitsubishi A-series drive;
Includes AC Drive F8103608
** NOTE: Refer to Motor Manufacturer’s Part Number on the Motor’s Nameplate for help with determining your motor’s part number.
N/A = Part no longer available

F232167 11
Notes
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

12 F232167
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Decals
123
456
789
0
STOP
START
COLD
LOW
HOT
MED./FILL
WARM
HIGH
WASH
FLUSH
HEAT
RINSE
SUPPLY
OVER
SOAK
MANUAL
MEDIUM
SPEED
HIGH
SPEED
CLEAR DRAIN
AUXILIARYENTER
____
EDIT
CYCLE
ADD
STEP
ADD
CYCLE
ADVANCE
DISPLAY
TEMP
ERASE
CYCLE
NO
REVERSE
R
DoorUnlock
PressandH
old
EmergencyStop
PHM2896P_F232167
CONDUCTORS ONLY
COPPER
P/N 231146

F232167 13
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Decals
REF PART NO. DESCRIPTION COMMENTS
1505281 Disconnect Power Warning Label
2F230301 This Machine Must Be Protected Decal
3F231146 Conductor Decal
4F231345-4 External Supply Caution Decal
5F231380 Hot Surface Warning Decal
6F231368 Cold Water Valve Decal
7F231367 Hot Water Valve Decal
8F230302 Do Not Push Decal
9F231436Supply Dispenser Hazard Caution Decal
10 F0230112-00 Plug Removal Warning Decal Model UW60PV
11 F230501 Before Power Is Connected Tag
12 F230652 Clockwise Spin Rotation Decal
13F200085000 Hot Surface Warning Decal
14 F231065 Personal Injury Warning Decal

14 F232167
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Module - Model UW60PV (Drawing 1 of 4)
PHM2344P_F232167

F232167 15
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Module - Model UW60PV (Drawing 1 of 4)
REF PART NO. DESCRIPTION COMMENTS
1N/A Control Mounting Panel Assembly
2F430928 Screw
3F0637753-00 AC Drive Partition Assembly
4F0637748-00 Air Flow Ramp Assembly
5F170404 Trim Order 1 foot
6505281 Disconnect Power Warning Label
7F635456 Control Module Cover
870240301 Screw
9F635448 Electrical Access Panel Design 5 and 6
9F0637549-00 Electrical Access Panel Design 7 and 8
10 F431026 Nut
11 F635476 Cable Tray Cover
12 F431113Washer
13F430917 Screw
14 F635615-2 Cable Tray Assembly
15 F635468 External Supply Box
16 F635365 External Supply Box Cover
17 F431000 Nut
18 F606826 Computer Cover
19 F140606 Cable Tie 15 inch
20 F140605 Cable Tie 6 inch
21 F140602 Tie Wrap Mounting Clamp
22 F140218P Ribbon Cable 16 conductor; 12 inch; From interface cca to computer; J8
plug
23F140248P Ribbon Cable 16 conductor; 15 inch; From computer to interface cca; J1
plug; DIP socket
24 F191101 Battery 9 Volt; Backup
25 F140219P Ribbon Cable 26 conductor; 15 inch; From computer to output cca
26 F430231Nut
27 F431125 Washer
28 F037062441P WE-6 Computer
29 F340412 Momentary Switch Models through 5/26/04
29 F200120100 Momentary Switch Models starting 5/27/04
30F431123Washer
31F431108 Washer
32F8136401 Screw
33 N/A Emergency Stop Pushbutton 800E-series; Models through 9/30/07; Order F200233700P
Emergency Stop Button Kit
33 F200233700P Emergency Stop Button Kit Used to convert from 800E-series to 800F-series; Includes
F200233500 Emergency Stop Pushbutton and F200233401
Contact Block Switch
33 F200233500 Emergency Stop Pushbutton 800F-series; Models starting 10/1/07
34F230724P Keypad Decal
35F231562 Control Module Decal
36N/A Seal Order 1 foot; N, P and Q-voltage
36F170151 Seal Order 1 foot; T and X-voltage
37F340445 Contact Block Switch 800E-series; Models through 9/30/07; Includes mounting
base
37F200299500 Contact Block Switch 800E-series; Models through 9/30/07; Does not include
mounting base
37F200233401 Contact Block Switch 800F-series; Models starting 10/1/07
N/A = Part no longer available

16 F232167
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Module - Model UW60VV (Drawing 1 of 4)
PHM2441P_F232167

F232167 17
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Module - Model UW60VV (Drawing 1 of 4)
REF PART NO. DESCRIPTION COMMENTS
1F340445 Contact Block Switch 800E-series; Models through 9/30/07; Includes
mounting base
1F200299500 Contact Block Switch 800E-series; Models through 9/30/07; Does not include
mounting base
1F200233401 Contact Block Switch 800F-series; Models starting 10/1/07
2N/A Control Mounting Panel Assembly
3F430928 Screw
4F635366 AC Drive Partition
5F0637748-00 Air Flow Ramp Assembly
6F170404 Trim Order 1 foot
7505281 Disconnect Power Warning Label
8F634558 Control Module Cover
970240301 Screw
10 F0637549-00 Electrical Access Panel
11 F431026 Nut
12 F635476 Cable Tray Cover
13F431113Washer
14 F430917 Screw
15 F635615-2 Cable Tray Assembly
16 F635365 External Supply Box Cover
17 F635468 External Supply Box
18 F140606 Cable Tie 15 inch
19 F140605 Cable Tie 6 inch
20 F140602 Tie Wrap Mounting Clamp
21 F140219P Ribbon Cable 26 conductor; 15 inch; Connects the microcomputer to
the output board cca
22 F430231Nut
23F431125 Washer
24 F0370313-09P Microcomputer
25 F340412 Momentary Switch Models through 5/26/04
25 F200120100 Momentary Switch Models starting 5/27/04
26 F330217P RC Network Filter Includes F140627 Connector and F141022 Connector
27 F431123Washer
28 F431108 Washer
29 F8136401 Screw
30N/A Emergency Stop Pushbutton 800E-series; Models through 9/30/07; Order
F200233700P Emergency Stop Button Kit
30F200233700P Emergency Stop Button Kit Used to convert from 800E-series to 800F-series;
Includes F200233500 Emergency Stop Pushbutton and
F200233401 Contact Block Switch
30F200233500 Emergency Stop Pushbutton 800F-series; Models starting 10/1/07
31F370576P Keypad
32F231417 Control Module Decal
33 N/A Seal Order 1 foot
N/A = Part no longer available

18 F232167
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Control Module - Model UW60AV (Drawing 1 of 4)
PHM2519P_F232167
