Bellini BFC609W Installation instructions

GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven
INSTALLATION & OPERATION
INSTRUCTIONS
60cm Freestanding Ceramic Oven
Model No.
BFC609W
BFC609W-F FINELINE: 5104013 AUS Only
V.5DEC17

GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven
Thank you
Thank you for choosing Bellini Appliances.
Bellini prides itself on ‘affordable living’ making sure there is
no compromise in your favourite room … The Kitchen
All Bellini appliances carry a 3 year In Home warranty,
be sure to retain your installation and user manual and
receipt.
For all warranty and technical queries please contact
1300 373 199

GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven
Content
Safety instructions------------------------------2
Installation----------------------------------------5
Product description-----------------------------9
Operation Instructions-------------------------10
Maintenance and cleaning -------------------16
Warranty------------------------------------------20

Important Safety Instructions
This manual explains the proper installation and use of your oven, please read it carefully before
using even if you are familiar with the product. The manual should be kept in a safe place for future
reference. In case of failure, only the Authorised Technical Service may repair this oven.
Otherwise the guarantee will be null and void. All Bellini Appliances are for domestic use only.
General Warnings
If the supply cord is damaged, the cord must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a
hazard.
This product has not been designed for any uses
other than those specified in this booklet.
This appliance must not be used as a space
heater.
In order to avoid fire, the appliance must be kept
clean and vents kept unobstructed.
Do not spray aerosols within the vicinity of the
appliance during operation.
Do not store flammable materials in or under the
appliance, e.g. aerosols.
Do not line the bottom of the oven with foil or
cookware.
Always use gloves when handling hot items inside
the oven.
Always turn the grill off immediately after use as
fat left behind may catch fire.
Do not leave the appliance unattended when
cooking. Oils and fats may catch fire due to
overheating or boiling over.
Do not put pans weighing over 15Kgs on the
opened door of the oven.
Do not use the appliance in the event of a
technical fault. Any faults must be fixed by an
appropriately qualified and authorised person.
In the event of any incident caused by a technical
fault, disconnect the power and report the fault to
the service centre to be repaired.
The rules and provisions contained in this
instruction manual should be strictly observed.
Do not allow anybody who is not familiar with the
contents of this instruction manual to operate the
appliance.
Child Safety
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they’ve been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
During use this appliance becomes hot. Care
should be taken to avoid touching hot surfaces, e.g.
oven door, heating elements.
Accessible parts will also become hot when in use.
To avoid burns and scalds children should be kept
away.
Installation, Cleaning & Servicing
The appliance must be installed only by an
authorised person in compliance with the
instructions provided. Incorrect installation may
cause harm to persons, animals or may damage
property.
Before using the appliance, ensure that all packing
materials are removed from the appliance.
In order to avoid any potential hazard, the
enclosed installation instructions must be followed.
Ensure that all specified vents, openings and air
spaces are not blocked.
The panels adjacent to the oven must be made of
heat-resistant material.
Cabinet with a veneer exterior must be assembled
with glues which can withstand temperature of up
to 120C.
2
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

To reduce the risk of fire, do not place or install
this unit in areas where the ventilation or
circulation ducts may become blocked. Make sure
there are at least 10mm of space between the
back of your oven and the wall. Keep some
distance on each side of your oven that you can
use that distance flowing installing instructions.
The unit's power cord must be connected to a
properly grounded and protected, 220-240V
electrical outlet. Always use ground fault
protection where required by the electrical code.
When transporting or storing the unit, keep it in a
dry location, free from dust, excessive vibration or
other factors, which may damage the unit.
Do not operate oven with a damaged cord, plug or
if the oven has malfunctioned or has been
dropped or damaged in any manner. Return
oven to authorised service facility for repair.
Only authorised personnel should carry out
servicing. (Certificate of Compliance to be
retained)
Always ensure the appliance is switched off
before cleaning or replacing parts.
Do not use steam cleaners, as this may cause
moisture build-up.
Always clean the appliance immediately after any
food spills.
THIS APPLIANCE MUST BE EARTHED.
To maintain safe operation, it is recommended
that the product be inspected every five years by
an authorised service person.
Oven
During use the appliance becomes hot. Care
should be taken to avoid touching the hot surfaces
inside the oven.
Switch the appliance off before removing the oven
light glass for globe replacement.
To avoid an accident, ensure that oven shelves
and fittings are always inserted into the appliance
in accordance with the instructions.
Do not use the door as a shelf.
Do not push down when the oven door is open.
Grill
Do not cover the grill insert with foil, as fat built up
may catch on fire.
Always keep the grill dish clean as any build up
may catch on fire.
Do not leave the grill on unattended.
To avoid fire, ensure that grill trays and fittings are
always inserted into the appliance in accordance
with the instructions.
Do not place thick portions of food under the grill.
Foods may curl, catch and ignite.
Accessible parts may become hot when grill is in
use. Children should be kept away.
Environmental Hints
Use the oven efficiently, by cooking many trays of
food at the same time.
Cook 2 trays of scones, small cakes or sausage
rolls at the same time.
Select the correct shelf location for food being
cooked.
Do not open the oven door more than necessary.
After the oven is turned off it retains heat for some
time.
This product must not be disposed together
with domestic waste. This product has to be
disposed at an authorised place for recycling
of electrical and electronic appliances.
By collecting and recycling waste, you help save natural
resources, and make sure the product is disposed in an
environmental friendly and healthy way.
3
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Bellini
INSTALLATION &
OPERATION INSTRUCTIONS
Freestanding Oven
Septv2
BFC609W
Anti-tilt Bracket
To prevent tipping
of the cooker.
Legs
Installation &
Operation Instruction
4
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Installation
The following instructions should be read by a qualified technician to ensure that the appliance
is installed, regulated and technically serviced correctly in compliance with current regulations.
Important: remember to disconnect the appliance from electricity by turn off the mains
before regulating the appliance or carrying out any maintenance work.
Positioning
Important: The hob should never be installed in proximity of a door access. People opening
and closing the door could come into contact with pots or pans cooking on the hob.
This unit may be installed and used only in permanently ventilated rooms:
Unpacking
a) Be careful when unpacking and installing the appliance. Sharp edges might cause accidents.
b) The oven is heavy and care must be taken when moving it. Ensure that all packing, both
inside and outside the cooker, has been removed before the oven is used.
c) Unpack the oven from the carton, check and make sure it has not been damaged in any way.
If you have any doubts, do not use it, contact the service center or where you bought the oven.
Installation
The cooker is desig ned to fit between kitchen cabinets. The space either side need only be
sufficient to allow withdrawal of the cooker for servicing. It can be used with cabinet one side or
both as well as in a corner setting. It can also be used free-standing.
The appliances can be installed next to furniture units which are no taller than the top of the
cooker ho bs. If the cooker is p laced touching walls or sides of neighboring cabinets, these
musst be capablee of withstanding a temperature rise of 50°C above room temperature. For a
correct installatioon of the coooker the following precautions must be followed:
a) The cooker mmay be located in a kitchen, a diner or bed sitting room, but not in a bathroom or
shower room.
b)
c) Hoods must be installed according to the requirements in the installation manual for the
hoods themselves and in any case at a minimum distance of 65cm.
d)
indicated in figurre 1.
e) The hoods muust be installed according to the requuirements in the hood handbook.
f) Should the coooker be installed beneath a wall cabbinet, the latter should be situated at least
70cm away fromm the hobs as indicated in figure 1.
g) The cut-out foor the cooker cabinet should have the dimensions indicated in the figure 1.
h) The wall in coontact with the back of the cooker muust be of flameproof material.
Kitchen cabinet s installed next to the cooker that are taller than the top of the cooker hobs
must be situatedd at least 20cm from the edge of the hobs.
Place the wall cabinets adjacent to the hood at a minimum height of 42cm from the hobs as
5
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Level
Tak
and
when necessaryy. The height
plinth. Adjust thee feet by tilting the cooker from the side. Then install the product into position. It
is essential that the cooker b
War
ing Your Appliance
e out of the 4 cooker fee
then screw them into th
Install Anti-tilt Bracket
ning: In order to preven
t from oven
e 4 plinth i
of the cooke
e standing le
t tipping of t
Figure
1
cavity, whic
n lower part
r can be ad
vel before i
he cooker, the anti-tilt bracket must be installed with
1
of cooker. T
justed by m
nstallation.
h are packed together w
hese feet le
eans of adjus
ith baking rack,
vel off the oven
table feet in the
cook
scre
er. To insta
ws (2) to the
Figur
ll Anti-tilt b
ground, as
e 2
racket, use
shows in Fig
screwdriver to mount the
ure 3.
anti-tilt
Figure 3
bracket (1) with
Cooker Hood
Min.65cm.(With Hood)
Min.70cm.(Withot Hood)
Min.42cm.
Min.42cm.
Cabinet side
50mm
50mm
Back Wall
B
A
6
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Afte
corr
Ele
WAR
Pow
The
elec
can
scre
Note:
insta
1. O
cove
r fix anti-til
ect installatio
ctrical conn
NING – T
wer supply vo
electric coo
tricity supply
be connected
wdriver.
the followin
llation of the
pen the term
r. Use the s
t bracket, pu
n, the rear a
ection
HIS APPLIAN
oltage and fre
ker without a
which confo
to the mai
g installatio
feeding cab
inal board b
crewdriver a
sh the elec
nd right foo
CE MUST BE
quency: 220
power supp
rms to the e
ns only after
n procedure
le carry out
y inserting a
s a lever by
tric cooker
t of cooker w
Figure
4
EARTHE
0-240V A.C.
ly cable. Th
lectrical dat
removing t
must be ca
the following
screwdrive
pushing it do
inside cabin
ould be clip
4
D.
50/60 Hz.
e cooker is d
a shown on t
he back pane
rried out by a
operations
r into the sid
wn to open
et as show
ped by the a
esigned to o
he Rating lab
l of the cook
qualified el
:
e tabs of the
the cover as below:
in Figure 4
nti-tilt brac
perate on an
el. The coo
er itself with
ectrician. For
power code
. For
ket.
ker
a
the
3. Fasten the supply cable in place with the clamp and close the cover of the terminal board.
Note: The red electricity indicator on conntrol panel will illuminate once connected to electricity.
2. Connect the electricity following the diagram as printed on the surface of power cord cover.
Push
7
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Sa
_ Stand back when opening an oven doo
_ Use dry good qquality oven gloves when
_ Place pans centrally over the hotplate m
the hob and cannot become heated by o
_ Take care to aavoid heat/steam burns w
_ Turn off the eleectricity supply before cle
_ Make sure thee shelves are in the correc
_ Take care when removing items from t
be hot.
_ Keep the appliiance clean, as a build up of grease or fat from cooking can cause a fire.
_ Follow the bassic principles
growth.
_ Keep ventilation slots clear of
_ Refer servicingg to a qualifie
_ Take care to avoid touchin
becomes hot.
Never
_ Never line the
_ Never leave children unsupervised where a cooking appliance is installed as all surfaces will
be hot during and after its use.
afety Inform
interior of th
mation
of food handling and hygiene to prevent the possibility of bacterial
obstructions.
d appliance service engineer.
g heating elements inside the oven, as during use the oven
e oven with foil as this may cause the appliance
When usedproperly your appliance is completely safe but as with any electrical product
there are certain precautions that must be observed.
PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE.
Always
_ Turn controls OFF when you have finished cookingg and when not in use.
r to allow any build up of steam or heat to disperse.
removing items from the oven/grill.
aking sure handles are kept away from the edge of
ther hot plate/pans.
hen operatinng the controls.
aning and allow the appliance to cool.
t position beefore switching on the oven.
he grill when the lower oven is on as the contents will
to overheat.
_ Do not allow children or persons who are not familiar with the appliance to use it, without
supervision.
_ Never allow anyone to sit or stand on any part of the appliance.
_ Never store items above the appliance that children may attempt to reach.
_ Never leave anything on the hob surface when unattended and not in use.
_ Never remove the oven shelves whilst the oven is hot.
_ Never heat up unopened food containers as pressure can build up causing the container to
burst.
_ Never store chemicals/food stuffs, pressurized container in or on the appliance, or in
cabinets immediately above or next to the appliance.
_ Never place flammable or plastic items on or near the hob.
_ Never fill a deep fat frying pan more than 1/3 full of oil, or use a lid.
DO NOT LEAVE UNATTENDED WHILE COOKING.
_ Never use the appliance as a room heater.
_ Never use the grill to warm plates.
_ Never dry any items on either the hob or oven doors.
_ Never install the appliance next to curtains or other soft furnishings.
_ Never use steam cleaners.
8
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

SAFETY ADVICE IN CASE OF A CHIP-PAN FIRE
In the event of a chip pan fire or any other pan fire.
1. TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH.
2. COVER THE PAN WITH A FIRE BLANKET OR DAMP CLOTH, this will smother the flames
and extinguish the fire.
3. LEAVE THE PAN TO COOL FOR AT LEAST 60 MINUTES BEFORE MOVING IT. Injuries
are often caused by picking up a hot pan and rushing outside with it.
NEVER USE A FIRE EXTINGUISHER TO PUT OUT A PAN FIRE as the force of the
extinguisher is likely to tip the pan over!
Never use water to extinguish oil or fat fires!
P
r
A. C
B. Vi
C. C
D.
B
E. B
F.
r
oduc
t
ooktop
tro Ceram
ontrol Panel
aking Pan
aking Rack
Adjustable F
t
Des
c
eet
c
ription
A
BB
C
D
E
F
9
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Wire shelf : For grill, dishes, cake pan with items for
roasting and grilling.
Universal pan: For cooking large quantities of food
such as moist cakes, pastries, frozen food etc,or for
collecting fat/spillage and meat juices.
ACCESSORIES
Slider bracket : These shelf support rails on the
right and left sides of the oven can be removed for
cleaning oven walls. (only for specific models)
Telescopic runner: Some models might with
telescopic runners to facilitate the use of oven.
These telescopic runners could be disassembled
for cleaning by unscrewing the screws use to fix it.
(only for specific models)
SHELF PLACEMENT WARNING:
To ensure the oven shelves operate safely, correct
placement of the shelves between the side rail is
imperative. Shelves and the pan only can be used
between the first and fifth layers.
The shelves should be used with the right direction, it
will ensure that during careful removal of the shelf or
tray, hot food items should not slide out.
10
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Opperation Instructions
Hob control knobs Hob control knobsTimer
Oven Function knob Oven Temperature
Setting knob
Cooktop
power
indicator
Oven
power
indicator
Baking
Broil
Oven controls - the function and temperature controls
To use an oven function, first select the function with the left hand dial and then
set the temperature of the function with the right hand dial. Set the timer in the
middle.The indicator light will illuminate. When the temperature inside your oven
reaches the temperature you set, the thermostat will cut off the heating element
and the indicator light will go off. When the temperature falls below the set
temperature, the heating element will again be turned on and the indicator light
will illuminate again.
The
cook
cooker coul
er you bought.
d be with different functions as below, please refer to the functions for the
11
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Sy
ymbol
Ove
the d
optio
Defr
froze
the d
Botto
conc
Conv
cook
Conv
more
brow
Rad
This
Dou
func
Dou
with
Conv
heat
on to
n Lamp: Ena
oor. Oven la
nal function
rost: The circ
en food, (with
defrosting tim
om heat: A c
centrative he
ventional coo
king.
vention with
e even heat
wned on the o
iant grilling: T
function can
ble grilling: T
tion can be w
ble grilling w
fan. This fun
vection: An e
t for convecti
o improve air
bles the use
mp will light
.
ulation of air
out the use
e and thawi
concealed ele
at to the bas
king: The to
fan: Combi
penetration,
utside and
he inner gri
be work wit
The inside ra
ork with op
ith fan: The
ction can be
lement arou
on style coo
circulation w
Function d
r to observe
ing for all c
at room tem
of any heat)
ng of ready-
ment in the
e of food wit
p and botto
nation of the
saving up to
still moist on
ll element sw
h optional ro
diant elemen
tional rotisse
inside radian
work with o
nd the conv
king. In conv
ithin the ov
description
the progres
ooking functio
perature en
). It's a gentle
-made dishes
bottom of th
hout blowing
m work toge
fan and both
30-40% of e
n the inside.
itches on an
tisserie func
t and top el
rie function.
t element an
ptional rotis
vection fan pr
ection mode
en and crea
s of cooking
ns, for the
ables quicke
but quick w
and cream
e oven prov
.
ther to provi
heating ele
nergy. Dish
d off to main
tion.
ement are w
d top eleme
serie functio
ovides an ad
the fan aut
tes an even
without ope
cooker with t
r thawing of
ay to speed
filled produc
ides a more
de conventi
ment provide
es are lightly
tain temper
orking. This
nt are worki
n.
ditional sou
omatically co
heat for coo
ning
his
up
e etc.
onal
s
ature.
ng
rce of
mes
king.
2
1
3
5
4
6
1. 1800W zone
2. 1200W zone
3. 1800W zone
4. 1200W zone
5. Glass plate
6. Residual heat indicator
12
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

The temperature is set individually for each cooking zone, using the respective temperature
controls. The controls can be turned clockwise and back again.The desired temperature canbe
adjusted continuously.
The power control lamp indicates that it goes out when all Multi-stage cooking zones controls are off.
Control settings
LO
HI
=Location of the cooking zone
=Off
=lowest setting (Keep food warm)
=Middle setting of the central zone independently(cooking,roasting)
=Highest setting of the central zone independently(cooking,roasting)
=Highest setting of the both zones (quick heating up,quick cooking,
roasting)
When finished cooking, turn the control back to the Off position .
Residual heat indicator
After switching off the cooking zone, the residual heat indicator lights up.
The lit residual heat indicator warns the user not to touch the hot cooking surface.
WARNING: Risk of burning!
Do not touch the cooking zones as long as the residual heat indicator is on.
NOTe:
After having switched off the heating power, you may use the residual heat for different
purposes, such as heating up or keeping food warm without having to switch on the heating
power.
Safety requirements for deep fat frying
1. Use a deep pan, large enough to completely cover the appropriate heating area.
2. Never fill the pan more than one-third full of oil.
3. Never leave oil or fat unattended during the heating or cooking period.
4. Never try to fry too much food at a time, especially frozen food. This only lowers the
temperature of the oil or fat too much, resulting in greasy food.
5. Always dry food thoroughly before frying, and lower it slowly into the hot oil or fat. Frozen
foods, in particular, will cause frothing and spitting, if added to quickly.
6. Never heat fat, or fry, with a lid on the pan.
7. Keep the outside of the pan clean and free from streaks of oil or fat.
Control settings
LO
HI
=Location of the cooking zone
=Off
=lowest setting (Keep food warm)
=Middle setting of the central zone independently(cooking,roasting)
=Highest setting of the central zone independently(cooking,roasting)
13
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Hotplates General Information Notes
Always Never
Use good quality flat-based cookware on all
electric heat sources.
Use gauze, metal pan diffusers,
asbestos mats and stands e.g. Wok
stands - they can use overheating.
Always ensure pans have clean, dry bases
before use.
Use utensils with skirts or rims e.g.
buckets and some kettles.
Ensure pans match size of heating area. Use badly dented or distorted pans.
Remember good quality pans retain heat well,
so generally only a low or medium heat is
necessary.
Leave an element switched on when
not cooking.
Ensure pan handles are positioned safely and
away from heat sources.
Cook food directly on the ceramic
glass.
Always lift pans, do not drag. Drag or slide utensils, along the hob
surface.
Always use pan lids except when frying.
Deal with spillages immediately but with care.
Do Not
Do not cook directly on the hob surface without a cooking utensil, as this will result in damage
to the surface of the hob.
Do not use the hob as a worktop surface as damage may occur to the smooth surface of the
hob.
Do not drag or slide utensils on the hob surface, as this will cause scratches in the surface of
the hob.
Do not allow a cooking utensil to come into contact with the hob surround.
Do not leave any utensils, food or combustible items on the hob when it is not in use.
Do not place aluminum or plastic foil, or plastic containers on the hob.
Do not leave the hotplates or cooking areas switched ON unless they are being used. We
recommend not to place large preserving pans or fish kettles across two heating areas.
Do not leave utensils partly covering the heated areas. Always ensure that they are placed
centrally over the heated areas and have the same diameter as the heating area used.
We recommend not to use a utensil with a base diameter greater than 25cm.
Pressure cookers or other large pans should be used on the front cooking areas.
Always ensure that saucepan handles are positioned safely.
14
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Do n
Do n
Do n
Do n
Do n
perf
Do n
Do n
Ov
The
Turn
the m
cloc
imm
temp
Tim
For
minu
cloc
matc
soun
Turn
ot use light
ot use light
ot use cast
ot use uten
ot use a ute
formance of t
ot use a ute
ot use glas
ven Cont
oven tempe
oven functi
odel with ti
kwise to the
ediately illum
erature sett
er (only
the cooker w
utes. To use
kwise; then t
hes the refe
nds.
n the time co
tweight utens
tweight enam
t iron utensils
nsils with rece
ensil which h
the hob.
ensil with a c
ss ceramic ut
rol
rature settin
on control kn
imer) to set t
required ove
minate and w
ting.
availab
with hour m
the timer, th
turn it back t
erence mark
ontrol knobs t
sils with thin,
eled steel u
.
essed, scrol
as a base c
onvex base
tensils.
g knob can o
ob to select
he cooking
n temperatu
ill automatic
le on ce
echanical tim
e buzzer mu
o the desired
on the pane
to positio
, distorted or
tensils.
led or ridged
oncavity gre
.
nly be rotate
the cooking
time you wan
re. The red
ally go off w
rtain mo
er, you can
st be wound
time so tha
l. After set c
n, the timer w
uneven bas
d bases.
ater than 1m
d clockwise
function, me
nt.Then turn
oven tempe
hen oven te
dels)
use it to se
d up by turnin
t the numbe
cooking time
ill keep alw
es.
m as this wi
from the OF
anwhile tur
oven tempe
rature pilot li
mperature re
t cooking tim
g the knob
r of minutes
finish, timer
ays on.
ll reduce the
F position.
n the timer (f
rature contro
ght will
aches the
e from 1-120
one full turn
on the knob
buzzer woul
or
l
b
d
2
Choosing Your Utensils
Do not use utensils with rough bases.
Ro
Som
and
infra
To u
strin
moto
cook
otisserie
e of models
could have b
ared grill.
se rotisserie
ng the meat t
or. And then
ing.
function
s might have
better cookin
es cooking, y
to rotisseries
select cooki
n
rotisseries o
g for meat w
ou need to f
s fork, after th
ng function,
ptional funct
ith an appe
irst insert rot
at insert rot
temperature
tion. It is suit
tizing crisped
tisseries rack
isseries fork
e and cooking
able for big
outside if u
inside rack
to the sleeve
time to set
pieces of me
se together
support. Th
of rotisseri
rotisseries
at,
with
en
es
15
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Cl
Befo
cook
ean a
ore each ope
er, it shall b
nd Ma
eration, disco
be thoroughly
intena
onnect the co
cleaned fre
ance
oker from th
quently, kee
e electricity.
eping in mind
To assure t
that:
he long life of the
1. W
warm
2. W
3. Le
4. C
spla
5. D
whic
6. D
sinc
Wait until the
soapy wat
Wash the inte
eave the doo
Clean the ove
attered food d
o not use ab
ch will affect
o Not use h
ce they can s
oven has co
ter and dry th
erior of the ov
or open until
e
n after each u
debris burnin
brasive pads
the efficienc
harsh, abrasi
scratch the su
oled before
oroughly.
ven with hot
the interior h
se, espec
g and becom
to clean the
y of your ove
ve cleaners
rface, which
removing th
soapy water
as dried, be
ially after ro
ing difficult
interior of t
n.
or sharp me
may result
he wire shelv
and wipe do
efore replacin
asting or gr
to remove.
the oven as t
etal scrapers
shattering o
es, wash th
wn with a da
g the wire s
illing, this wi
his may re
to clean the
f the glass.
em separate
mp cloth.
helves.
ill prevent spilt or
move the enamel,
oven door g
ly in
lass
Clea
1. Y
cloth
2. W
non-
3. N
4. W
lette
ning the ou
ou should re
and mild liq
Wash ename
-abrasive de
ever use ab
hen using c
ring or symb
tside of the
gularly wipe
uid deterge
eled or chro
tergents.
rasive pads
commercially
ols, as they
oven
over the c
nt as spilt liq
ome plated
to clean ena
available s
can become
ontrol panel
uids may da
parts of the
meled, chrom
tainless ste
damaged.
, oven door
mage the en
oven with
ed or stain
el cleaning p
and oven s
amel.
warm soap
less steel su
roducts, av
ides using a soft
y water or with
rfaces.
oid clea ning any
Rem
We
1.O
2. T
3. L
from
4. To
back
oving the d
recommend
pen the doo
he door hing
ift the door s
the oven.
replace the
into place.
oor for eas
you have so
r completely
e has a sma
lightly as if c
door, hold t
Open and cl
ier cleaning
meone to as
.
ll latch. Lift t
closing, and
he door in a
ose the doo
sist you dur
he latch on b
then with bo
n open posit
r to make su
ing removal
oth hinges.
th hands sup
ion and inse
re that it has
of the door.
porting the
rt the latche
been fitted
door, pull it a
s on both hi
correctly.
way
nges
Latch
16
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Ove
1. S
befo
2. R
bulb
3. In
n Lamp Rep
witch off and
re touching
emove the l
b by turning it
sert the new
lacement
disconnect
internal parts
lamp cover by turning it counter-cloc
t counter-clo
bulb, which
the power
.
ckwise.
should be re
from the ove
sistant to 30
n. Ensure th
kwise (note, it may be stiff), remove the
0ºC. For re
at the intern
placement b
al parts are
ulbs contact
cool
your
loca
4. R
5. If
WAR
app
l service cen
e-fit the cove
in any doub
RNING: To
liance is sw
tre.
r.
t, consult a q
avoid electr
itched off a
ualified elec
ic shocks -
nd the appl
trician for he
please ensu
iance is full
lp.
re that the
y cold, befo
electricity su
re removin pply to th g the lamp l
e
ens.
17
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven

Tr
Cus
Befo
chec
Pr
o
Slig
wh
No
Ov
Ho
sim
Ma
cle
Gri
Co
the
rouble
stomer servi
re contactin
k the proble
o
blem
ht odour or
en using the
thing Works
en does not
tplates are s
mer
rks appearin
an hob / hotp
ll keeps turn
ndensation o
e cooker.
eshoot
ce
g the author
m guide bel
small amoun
e cooker for t
cook evenly
slow to boil o
ng on hotplat
plates.
ning on and o
on the wall a
ting
ized service
ow; there ma
t of smoke
he first time.
.
r will not
es. Can not
ff.
t the rear of
center in ca
y be nothing
This is
period.
Is the m
may be
Check t
allow su
the coo
Check t
recomm
The ho
soapy w
The sea
When t
than ma
not a fa
Steam
vent at
se of proble
g wrong with
normal and s
ain cooker w
no electrici
hat the cont
ufficient air fl
ker is level.
hat your pan
endations in
b surround c
ater and a c
aled hotplate
he grill cont
aximum, this
ult.
and/or conde
the rear of th
ms while us
your cooker.
hould cease
all switch t
ty supply.
ainers being
ow around t
s conform t
these instr
an be cleane
ream clean
s should be
rol is operate
is normal re
nsation ma
e appliance
ing your co
after a sho
urned on? Th
used in the
hem. Check
o the
uctions.
d with warm
er, such as C
cleaned reg
d at a setting
gulator oper
y appear fro
when using
oker,
rt
ere
oven
that
if.
ularly
less
ation,
m the
an
Ste
use
eam / Conde
.
nsation in the oven after
oven pa
content
is norm
Steam
high w
clean w
articularly fo
t e.g. frozen
al and any e
is a by-produ
ater content.
when regular
r foods with a
chips, roast
xcess shoul
ct of cookin
This is norm
cleaning of c
high water
chicken etc.
d be wiped o
g any food w
al and could
ooker.
This
ff.
ith
be
18
GSM Sales Pty Ltd ABN: 53 007 582 475
For Warranty and technical queries: 1300 373 199 Aust OR 0508123108 NZ www.belliniappliances.com.au
Model: BFC609W-F Fineline: 5104013 60cm Freestanding Ceramic Oven
