USER MANUAL
BOILERS PELLET-OLIVE STONE
Electronic regulation of boilers and installation elements
(heating circuits and Sanitary Hot Water

INDEX
1 Index ...........................................................................................................................................................................................................................2
2 Symbol Description..................................................................................................................................................................................................4
3 Safety Recommendations.......................................................................................................................................................................................4
3.1 Safety Devices ................................................................................................................................................................................................................ 4
4 Technical Features ...................................................................................................................................................................................................7
5 Fuels............................................................................................................................................................................................................................9
5.1 Pellet.................................................................................................................................................................................................................................. 9
5.2 Olive Stone....................................................................................................................................................................................................................10
6 Start-up .................................................................................................................................................................................................................... 10
7Display ..................................................................................................................................................................................................................... 12
7.1 Display General Information ...................................................................................................................................................................................12
7.2 Functions of the Display's Buttons ........................................................................................................................................................................13
7.3 Menu...............................................................................................................................................................................................................................14
7.3.1 User Menu ..........................................................................................................................................................................................................14
7.3.2 Menu 1. Choosing Fuel..................................................................................................................................................................................15
7.3.3 Menu 2. Summer/Winter Mode. .................................................................................................................................................................16
7.3.4 Menu 3. Set up Clock ......................................................................................................................................................................................16
7.3.5 Menu 4. Programme Setting ........................................................................................................................................................................17
7.3.5.1 Sub-menu 04.01. Set up Chrono .........................................................................................................................................................17
7.3.5.2 Sub-menu 04.02. Daily Programme....................................................................................................................................................18
7.3.5.3 Sub-menu 04.03. Weekly Programme ...............................................................................................................................................21
7.3.5.4 Sub-menu 04.04. Weekend Programme...........................................................................................................................................23
7.3.6 Menu 5. Select Language..............................................................................................................................................................................24
7.3.7 Menu 6. Stand-by Mode.................................................................................................................................................................................24
7.3.8 Menu 7. Sound Mode .....................................................................................................................................................................................25
7.3.9 Menu 8. Initial Load.........................................................................................................................................................................................25
7.3.10 Menu 9. Boiler State......................................................................................................................................................................................26
7.4 User Mode.....................................................................................................................................................................................................................27
7.4.1 Boiler's Ignition..................................................................................................................................................................................................27
7.4.2 Boiler in Operation ..........................................................................................................................................................................................27
7.4.3 Change Water Temperature Set..................................................................................................................................................................28
7.4.4 Water Temperature Reaches Temperature Fixed by the User ..........................................................................................................28
7.4.5 Burner Cleaning................................................................................................................................................................................................29
7.4.6 Turning off the Boiler......................................................................................................................................................................................29
7.4.7 Boiler Turned off...............................................................................................................................................................................................30
7.4.8 Re-ignition of the Boiler..................................................................................................................................................................................30
7.5 What happens if…?.....................................................................................................................................................................................................30
7.5.1 The Fuel Does not Light.................................................................................................................................................................................30
7.5.2 Power Supply Failure (Black Out) ...............................................................................................................................................................31
7.6 Alarms.............................................................................................................................................................................................................................31
7.6.1 Smoke Temperature Probe Alarm...............................................................................................................................................................31
7.6.2 Smoke Temperature Excess Alarm..............................................................................................................................................................32
7.6.3 Ignition Failure Alarm .....................................................................................................................................................................................32

7.6.4 Switching-off Failure during Working Phase ..........................................................................................................................................32
7.6.5 Pressure Alarm ..................................................................................................................................................................................................33
7.6.6 Damaged Smoke Extraction Fan Alarm....................................................................................................................................................33
7.6.7 Worm Gear Failure Alarm .............................................................................................................................................................................34
8Maintenance and Care......................................................................................................................................................................................... 36
8.1 Burner Cleaning...........................................................................................................................................................................................................36
8.2 Scraper Use ...................................................................................................................................................................................................................36
8.3 Ash Pan Cleaning........................................................................................................................................................................................................36
8.4 Joints of the Ash Pan Door and the Burner.......................................................................................................................................................37
8.5 Smoke Pipes Cleaning ...............................................................................................................................................................................................37
8.6 Glass Cleaning..............................................................................................................................................................................................................37
8.7 External Cleaning........................................................................................................................................................................................................37
8.8 Seasonal Stoppages ...................................................................................................................................................................................................37
9Sanitary Hot Water Tank...................................................................................................................................................................................... 38
10 General Measurements........................................................................................................................................................................................ 40
11 Maintenance .......................................................................................................................................................................................................... 42

Bronpi boilers have several safety systems that guarantee a safe and an appropriate operation and
protect both the boiler and the user. Some of them are described below. If in doubt, see sections 7.5 and
7.6.
2. Symbol Description
This symbol highlights those parts of the text that try to avoid mistakes when handling the boiler. The
omission of these instructions could cause material damages and harm your health in case of wrong
handling.
This symbol highlights those parts of the text that try to help with a better understanding of the boiler
regulation or the heating circuit.
3. Safety Recommendations
 Do not open the combustion chamber or the ash pan door during the working process.
 Do not allow making operations with the boiler to people who are not familiar with it or do not have training
related to the installation and to the Bronpi boilers.
 Prevent children from being alone in the heating room without any supervision!
 Keep animals away!
 If you notice visible damages (e.g. water leaks, thermal deformations, smoke or fire traces, mechanical
imperfections, etc.) you should neither continue with the service nor restart it. The faults need to be
repaired. In case of any doubt, please contact a specialized technician or the technical service.
 If the installation remains stopped during a long period of time you should guarantee an absolute antifreeze
protection in every part where the water is stored in.
 Bronpi boilers should not be submitted to any external mechanical load (e.g. tray, rise means, support, or
similar.) This remark also applies to its individual components (door, cover, etc.)
 During the working process you can only touch the door handles. The temperature could reach very high
values in some other parts (smoke pipe, ash pan door, etc.)
 Use fireproof gloves when restocking the combustible material.
 Bronpi boilers will exclusively be used under prescriptions given by the planning, installation, rules, laws,
and instructions related to the product. Either the manufacturer or distributor is not responsible for the
damages or the consequences attributable to an incorrect installation, application, or handling or to an
insufficient maintenance or cleaning.
 Regarding the legionnaire’s disease, current general technical rules must be respected.
3.1. Safety Devices

Ignition Failure
If it does not appear a flame during the ignition process, the equipment will show in the display the message
“IGNITION FAILURE.” If you try again to ignite the machine, the display will show the message “WAITING
COOLING.”
This function serves to remind that before carrying out the starting up it is necessary to check that the burner is
completely clear and clean.
 Smoke Pipe Breakdown
If the extractor stops, the electronic card automatically blocks the pellet or the olive stone supply.
 Fuel Load Motor Breakdown
If the geared motor stops, the boiler keeps on working (only the smoke extractor) until the minimum working
smoke temperature goes down and stops.
In the case that the geared motor spins continuously, the boiler will cut its electrical supply. In the event of this
happening, the boiler will go into an alarm state.
 Electricity Temporary Failure
After a short lack of electricity, the equipment restarts up automatically. In the event of a lack of electricity
the boiler could give off a reduced amount of smoke during a period of time of 3-5 minutes. THIS DOES NOT
ENTAIL ANY SAFETY RISK. This is why Bronpi advises, whenever possible, to connect the primary air inlet pipe
with the exterior of the house in order to assure that the boiler cannot give off smokes after the mentioned lack of
electricity.
 Electrical Protection
The boiler is protected against abrupt electricity oscillations through a general fuse placed in the back part of
the boiler. (4A250V Retarded) (Picture 1).
 Exhaust Stack Protection
An electronic pressure switch blocks the operation of the boiler in the event of an abrupt change in the
pressure inside the combustion chamber (door opening, smoke extraction motor breakdown…). In the event of this
happening, the boiler will go into an alarm state. (Picture 2).
 Protection for High Temperature Inside the Fuel Storage Tank (Hopper -80 ºC)

In the event of an overheating of the internal part of the tank, this device blocks the operation of the boiler.
The restart needs to be done manually, dismantling its black protection and pressing the white switch. This manual
restoration needs to be done by an authorised technician (Picture 3.)
The restoration of the 80 ºC safety device is not included in the warranty unless the support service
demonstrates a faulty component.
 Water Over Temperature Protection (90 ºC)
When the water temperature inside the boiler circuit is near about 100ºC, the fuel loading is blocked.If the
temperature gauge goes off, the restart needs to be done manually, dismantling its black protection and
pressing the white switch. This manual restoration needs to be done by an authorised technician.
The restoration of the 90 ºC safety device is not included in the warranty unless the support service
demonstrates a faulty component.
 Hydraulic Pressure Transducer
If the pressure inside the hydraulic installation is lower than 0.4 bars, the fuel loading motor electricity supply
gets blocked. If the pressure inside the installation exceeds 2.5 bars, the display will show the alarm “WATER
PRESSURE FAILURE”. The restoration of the safety device will be done by pressing button no. 4 (On/Off) during, at
least, 3 or 4 seconds (Picture 4.)
Warning: the occasional presence of air in the installation can provoke the intervention of
the pressure transducer. If the device intervenes blocking the fuel load in the machine, the alarms
related to the lack of fuel may activates.
In order to get a proper performance of the product, the ideal pressure of the installation should be tared in,
approximately, 1.0 bars when the installation is cold; furthermore, it is necessary the absolute absence of air. Bronpi
Calefacción advises to have an adequate air purged circuit inside the installation. The occasional operation
of air purging inside the installation or the product is not included in the warranty.

 Installation Safety Devices
It is COMPULSORY to have a pressure gauge to visualize the water pressure during the installation.
Warning!!!
The closed expansion tank of the installation should have a dimension between 4 and 6% of
the total volume of installation; this is why the standard closed expansion tank could be
inadequate in case of higher water volumes.
Picture 1 Picture 2 Picture 3 Picture 4
4. Technical Features
Characteristics
HYDROPOLAR-21
HYDROARTICA-27
HYDROARTICA-34
Pellet
Olive
Stone
Pellet
Olive
Stone
Pellet
Olive
Stone
Weight (Kg.)
225
293
310
Height (mm)
1228
1420
1420
Width (mm)
576
679
680
Depth (mm)
758
878
855
Smoke outlet pipe diameter (mm)
80
100
100
Air inlet pipe diameter (mm)
60
60
80
Performance at nominal power (%)
91
92
93
94
92
92
Performance at reduced power (%)
96
-
96
-
96
-
Maximum global thermal power (Kw)
21,2
23,3
27,6
27,6
34,3
34,5
Maximum usable thermal power (Kw)
21,2
23,3
27,6
27,6
34,3
34,5
- Power transferred to the air (Kw)
0,9
3,3
1,9
2,2
2,9
3,2
- Power transferred to the water (Kw)
20,3
20
25,7
25,4
31,4
31,3
Minimum usable thermal power (Kw)
7,2
-
9
-
12
-
- Power transferred to the air (Kw)
0,3
-
1
-
1,6
-
- Power transferred to the water ( Kw)
6,9
-
8
-
10,4
-

Minimum fuel consumption Kg/h
1,5
-
1,9
-
2,5
-
Maximum fuel consumption Kg/h
4,9
5,6
6
6,5
7,6
8,3
Tank capacity (Kg)
48
54
100
110
100
110
Minimum/maximum power autonomy (h)
32 / 9,8
9,6
53 / 16
17
40 / 13
32
Recommended draw at maximum usable power
(Pa)
± 12
± 12
± 12
± 12
± 12
± 12
Recommended draw at minimum usable power
(Pa)
± 12
-
± 12
-
± 12
-
Power consumption (W)
150-250
150-250
150-250
Power consumption during ignition (W)
500
500
500
Water inlet/outlet connection diameter
1"
1"
1"
Maximum working hydrological pressure (bar)
2,5
2,5
2,5
Working hydrological pressure (bar)
1,5
1,5
1,5
Volume of the closed expansion vessel (l)
8l
8l
8l
Maximum service temperature (ºC)
80
80
80
Heating circulating pump
SI
SI
SI
Cast-iron interior
NO
NO
NO
Automatic ignition
SI
SI
SI
Fuel safety thermostat
SI
SI
SI
Water safety thermostat
SI
SI
SI
Pressure switch (maximum/minimum pressure)
SI
SI
SI
Safety valve 3 bar
SI
SI
SI
Drain valve
SI
SI
SI
Weekly programmer
SI
SI
SI
Heat exchangers automatic cleaning
SI
SI
SI
Automatic burner cleaning
SI
SI
SI
Heating management and Sanitary Hot Water
SI
SI
SI
OASYS System
SI
SI
SI

5. Fuels
In order to guarantee a proper combustion, it is necessary to fulfill all quality standards in all fuels.
The use of fuels in disagreement with the specifications mentioned below implies the cancellation of
the warranty and the responsibility bounded to the product.
If you use fuels according to the present specification, we guarantee an impeccable working and good
performance values of the installation. In the event of not knowing any distributor who meet these criteria, we would
kindly inform you about the distributors that you may be interested in.
5.1. Pellet
- Quality standard
Only wood pellet certified under the standards Ö-Norm M7135 or DINplus should be used.
Besides these rules, BRONPI CALEFACCIÓN, S.L. stipulates the following requirements for wood pellet:
o Diameter: The pellet diameter should not be either lower than 6 mm or higher than 8 mm.
o Minimum length: The weight proportion corresponding to those wood pellets with a length
lower than 10 mm should not exceed 20% of the total combustible mass.
o Additional requirements to fuels:
 Ashes sintering point: The ashes sintering point should be higher than 1100°C.
 Ashes fusion point: The ashes fusion point should be higher than 1200°C.
 Ashes softening point: The ashes softening point should be higher than 1150°C.
- Transport and storage
However, the really important thing is to fulfill the transportation rules, since it is possible to damage good quality
pellets just by handling them in the wrong way during the transportation or the pouring in the hopper. The pellets
transportation to the final customer, or to the intermediate distributor, and the subsequent distribution are ruled by the
“ÖNorm 7136 pellets transportation and storage.” Based on this rule, it is the symbol “DIN approved pellets
logistics specialised company”. Please, only choose suppliers who transport and storage pellets according to the
“ÖNorm 7136 Transport” or certified with the symbol “DIN approved pellets logistics specialised company.”

5.2. Olive stone
- Humidity: The level of humidity in the pit should be between 6 and 8%. If the fuel does not have the
appropriate humidity it could generate some oils during the combustion. This will make the chambers of
the stove get dirty and it generates corrosion.
- Dimensions: The grain size of the pit should be between 3 and 4 mm. The combustion burner has to
be the right one for the olive stone combustion. Normally, the olive stone generates a bigger waste of
ashes and non-burnt pieces than the pellet. This is why it is so important to clean the burner daily and
to do a deep cleaning of the stove every 6 months rather than once a year.
6. Start-up
Configuration of the electronic regulation is very important regarding energy saving. During the starting-up,
it is convenient to have the first configuration done by a specialised technician. At the same time, in order to
guarantee an optimal output, the boiler and its components have to be received in situ by an authorised
specialised technician.
Before connecting the boiler to the voltage, you need to check every point of the following list:
- Assembly instructions observation:
Has every assembly step been properly done according to the instructions?
- Ash pan control:
Check there are not foreign bodies inside both the chamber where the ash pan is placed and the interior.
Also, check the vermiculite parts placed on the door and inside have not moved during the shipment.
While the boiler is working, none of its parts or instruments should be inside the ash pan or the loading
compartment. Close the door and check that you can close it perfectly.
Ash pan door
Ash pan
Ash pan chamber

- Combustion chamber control
Please check that there are no objects inside the combustion chamber and place inside the appropriate
burner for the chosen working mode of the boiler as it is shown in the following pictures. Note that the
incorrect placement of the burner may cause problems in the combustion.
- Burner
- Plug in
Once all these points have been checked, please connect the socket with a grounded socket base of
~230V/ 10A retarded.
It is important to take into account the following points:
o The system should have been run according to the rule VDE 0100.
o The connection with the electric power network should not be done through an
extension lead (fire risk!)
Combustion chamber door
Combustion chamber

o It is advisable to install an automatic switch.
o Compare the machine nameplate data with the data calculated from your power
network.
7. Display
7.1. Display General Information
The display shows information about the boiler performance. Once you access the menu, you can get
different types of screen and adjust the available configuration according to the level of access. Depending
on the working mode, the display may has different meanings depending on the position of the screen.
Picture 1 shows an example of a boiler turned on or turned off.
Picture 1
OFF
DIALOGUE
VALUE
14:24
STATE

Picture 2 shows the layout of the messages during the programming or configuration of the working parameters.
Particularly:
1. The screen area saying “VALUE” shows the value that we introduce.
2. The screen area saying “MENU LEVEL” shows the current menu level. Check “menu” section.
Picture 2
Picture 3 shows the meaning of the symbols appearing on
the left hand side of the screen.
The screen lighting in the section “status”shows the
activation of the corresponding device according to the
following list.
Picture 3
7.2. Functions of the Display’s Buttons
Button
Description
Modality
Performance Description
1
Increases
Temperature
PROGRAMMING
Modifies/Increases the value of the selected menu.
ON/OFF
Increases the ambient thermostat temperature value.
2
Decreases
PROGRAMMING
Modifies/Decreases the value of the selected menu.
MENU LEVEL
VALUE
M - 4 - 3 - 01
START
PROG - 1
08:10
STATE
DIALOGUE
1
3
2
4
5
6
CLOCK
RESISTOR
ENDLESS
SMOKE
EXTRACTOR
HEAT EXCHANGER
NOT IN USE
ALARM

Temperature
ON/OFF
Decreases the ambient thermostat temperature value.
3
Menu (Set)
-
Access the menu.
MENU
Access the following level in the submenu.
PROGRAMMING
Confirms the selected value and move to the following option
in the menu.
4
ON/OFF
Unblocking
WORKING
It switches on or off the boiler during 2 seconds, as
appropriate.
UNBLOCKING
Unblocks the boiler and switches it off.
MENU / PROGRAMMING
Goes back to the previous level menu and saves the modified
data.
5
Decreases
Power
ON/OFF
Decreases the output value of the boiler.
MENU
Moves to the previous menu option.
PROGRAMMING
Goes back to the previous submenu value.
6
Increases
Power
ON/OFF
Increases the output value of the boiler.
MENU
Moves to the following menu option.
PROGRAMMING
Moves to the following submenu option.
(NOTE:) You can gain access to the water temperature adjustment by pressing button nº1 just once.
7.3. Menu
By pressing button no. 3 we can access the MENU. It is divided into several sections and levels that allow
accessing the configuration and programming of the boiler.
The elements of the menu that allow the access to the technical programming of the boiler are protected by
a password. These parameters should be modified only by an authorised technician. (The changes in these
parameters could cause a wrong running in the boiler and the subsequent lost of the warranty.)
7.3.1. User Menu
The following table briefly describes the menu structure in the boiler. In the attached table, only the options
available to the user are specified.
Level 1
Level 2
Level 3
Level 4
Value
01 –Choose fuel
See chapter 7.3.2. of this manual
02 –Season state
Summer/Winter
03 –Clock adjustments
01- Day
Week Day
02- Hour
Hour
03- Minute
Minute
04- Day
Month Day
05- Month
Month

06- Year
Year
04 –Programme adjustment
See chapter 7.3.5 of this manual
05 –Select language
01 - Italian
Set
02 - French
Set
03 - English
Set
04 - German
Set
05 - Portuguese
Set
06 - Spanish
Set
06 –Stand-by mode
On/Off
07 –Sound mode
On/Off
08 –Initial load
Set
09 –Boiler state
Provides information on the status of the boiler.
10 –Technical adjustment
Exclusive access to authorised personnel.
7.3.2 Menu 1. Choosing Fuel
It establishes the fuel that we are going to use, either pellet or olive pit. In the
event of using wood pellet we will select “TYPE 1” while if we are going to use
olive stone we will select the option “TYPE 2”. Due to the existence of several fuel
qualities, Bio-Bronpi boilers allow to choose a third type of fuel “TYPE 3”. With this option, we try to get
a good combustion although the fuel has lower quality. However, it is necessary to reach some
mínimum quality requirements. For this reason, in the case of using adulterated fuel, with high humidity,
low density, anomalous size or with presence of impurities… Bronpi Calefacción S.L. will not be
responsible for the damaged caused by this.

7.3.3 Menu 2. Summer/Winter Mode
This menu has two options: “SUMMER” and “WINTER.”
In the event of selecting the “winter” mode we need to take into account that the boiler will allow us to
use simultaneously the heating system together with the SHW (Sanitary Hot Water) heating system. We always need
to give priority to the SHW heating system and it needs to be directly installed to our Bronpi boiler. In the event of
having connected the boiler only with our heating circuit, the boiler will work, anyway, in the same way and it will only
regulate the performance with the values we want. It is advisable to use this working mode during the coldest
periods.
In the event of selecting the “summer” mode, a proper operation is only guaranteed when we have installed
an SHW heating system. This is due to the fact that during the summer season the boiler considers unnecessary the
use of heating systems, so it will be only work in the case of demanding hot sanitary water. When our installation
does not have the SHW heating system it is advisable to select the “winter” mode.
MENU LEVEL
Menu 01
TYPE 1
FUEL
DIALOGUE
MENU LEVEL
Menu 02
SUMMER
DIALOGUE

7.3.4 Menu 3. Set up Clock
It sets up the time and date. The card has a lithium battery that allows the clock to work during 3/5 years.
7.3.5 Menu 4. Programme Setting
IMPORTANT: Before proceeding to set up the boiler, please check that the time and the date
shown are correct; otherwise, the selected programming would be set up depending on the
time and date set by default and this could not satisfy your needs.
In order to set up our boiler, we need to access the programming menu by pressing button no.3 “SET” only
once. With buttons no.5 and no.6 we can move through the menu no.2 “Programme Setting”:
To confirm this option, press again button no. “SET”; this way, we have indicated the machine that
we want to access the programming menu.
To see the different submenus we need to press buttons no. 5 and no. 6.
7.3.5.1 Sub-menu 04.01. Set up Chrono
To inform the boiler that we need to set up the chrono, we need to go to submenu 3-1 “Set up
Chrono” and, by pressing button no.3 “SET”, it will show, by default, the following screen:
Menu 03
SET UP
CLOCK
Menu 04
PROGRAMME
SETTING

In the upper left margin it is shown, by default, the word “OFF”; however, by pressing buttons no.1
or no.2 we should be able to change it to “ON” mode in order to inform the boiler that we are trying to introduce some
of the three programmes: daily, weekly or weekend.
After this, we need to choose the programme that we want to introduce: daily, weekly or weekend. To do so,
from the previous screen, we need to press repeatedly buttons nº5 and nº6 until we reach the desired option.
7.3.5.2 Sub-menu 04.02. Daily Programme
Let’s consider, for example, that we want to set up the daily programme. In this case, we need to go
to the following screen:
M - 4 - 1 - 01
HABILITA
CRONO
OFF
ON
M - 4 - 1 - 01
SET UP
CHRONO
M - 4 - 2
DAILY
PROGRAMME

By pressing just once button no.3 we gain access to the daily programming submenu of the boiler
and, by default, it will show the following screen:
We need to change the option OFF to ON by pressing buttons no. 1 or no. 2 so that we confirm to the
machine that we have selected the daily programme:
Now we need to choose the hours that we would like the boiler to be switched ON. To do this, there are 2
available hours to start and other 2 hours to stop the boiler: START 1 and STOP 1, START 2 and STOP 2.
For example:
- Start at 09:00 hours / stop at 14:30 hours
- Start at 20:30 / stop at 23:00 hours
From the previous screen, we press button nº6 and it will show up:
DAILY
PROGRAMME
OFF
M - 4 - 2 - 01
ON
M - 4 - 2 - 01
DAILY
PROGRAMME
OFF
M - 4 - 2 - 02
START 1
DIA

By pressing buttons no. 1 and no. 2 we modify the value “OFF” and we set the time of the first start:
In this same way we can proceed to set the first time to stop:
09:00
M - 4 - 2 - 02
START 1
DIA
OFF
M - 4 - 2 - 03
STOP 1
DAY
14:30
M - 4 - 2 - 03
STOP 1
DAY
09:00
M - 4 - 2 - 02
