Blue Pod Easy Touch User manual

TECHNICAL DATA
Model: Easy Touch Operating Voltage: 240V AC
Frequency: 50 Hz Power con, MAX : 1500W
Water tank cap.: 700ml (0.7L) Weight: 5.0 kg
Size: L 350 * W 155 * H 245 mm
This appliance has been tested and certified according toAustralian electrical safety and
EMC requirements.
WARNING
Obey the following instructions when cleaning and caring for the machine:
- Disconnect the machine from the power supply before cleaning.
- Allow the machine to cool down before cleaning.
- Do not use any abrasive cleaning agents or solvents.
- Never immerse the machine, power plug or plug in water or other liquids.
- Do not clean the machine or any parts thereof in the dishwasher.
CONGRATULATIONS! You have selected the new and innovative Easy Touch.
Building on Italian heritage, this unique appliance has been designed to prepare
delicious coffeesusingLavazzaBluecoffeecapsules, convenientlyandautomatically
with the touch of a button.
USER MANUAL

SAFETY WARNINGS
Read this user manual carefully before using your new Easy Touch for the
first time. Please keep the manual where you can easily find it, and refer to
it in the future. It is very important to keep the box safe in case it is needed
to return the machine for repair.
INTENDED USE
DANGER FROM ELECTROCUTION
RISK OF BURNING
WARNINGS
Danger from unintended use. If the machine is not used as intended and/or
used differently than intended, this may result in danger to the user:
- Use the machine only as intended.
- Follow the warnings and instructions outlined in this user manual.
WARNINGS
Parts of the machine may become very hot during operation. Heating
element surface is subject to residual heat after use. Obey the following
safety instructions to prevent scalding or burning yourself and/ or others:
- Do not touch the hot parts (coffee nozzle) after using the machine.
- Whilst brewing coffee, be aware that hot coffee may splash.
- Do not open main lever while making coffee.
- Do not move the machine whilst it is switched on. During movement, hot
liquid may spill out of the machine.
- Avoid spillage on the connector.
DANGER
Obey the following safety instructions
to prevent danger of electrocution.
- If the appliance is damaged,
immediately cease use and contact
our Authorised Service Centre.
- Do not use if the power cord or plug
is damaged. These must be replaced
by the manufacturer, its service agent
or similarly qualified persons in order
to avoid a hazard.
- Never open the machine to
diagnose a problem or attempt
GENERAL SAFETY INSTRUCTIONS
GENERAL SAFETY INSTRUCTIONS (continue)
This appliance is intended to be used in household and similar applications such as:
staff kitchen areas in shops, offices and other working environments; farm houses; by
clients in hotels, motels and other residential type environments; bed and breakfast type
environments. Any other or additional use is not intended. The machine is designed to
make coffee using LAVAZZA Blue capsules. Other capsules will not fit.
CAUTION:
Only operate the machine on a flat,
stable and heat resistant surface away
from water splashes. Do not move
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
Children should be supervised to ensure
that they do not play with the appliance.
Before using the machine inspect it for
visible damage to the housing, lever,
water tank, power cord and plug.
Donotusethemachineifitisdamaged-call
our Customer Support Line immediately.
Repairs of this machine must only be
done through authorised service centre.
PH: 1800 800 255
bluepod.com.au
Please contact our Customer Support
Line to arrange. To avoid damage to the
power cord unwind the cord fully before
use, always remove the product from
the power supply by pulling on the plug
itself, not the cable, and do not carry the
machine by the cord. Unwind the cord fully
before use, always remove the product
from the power supply by pulling on the
plug itself, not the cable, and do not carry
the machine by the cord.
Do not place the machine on hot surfaces
such as stove-tops.
while the machine is switched on or
working. Never immerse the machine,
power plug in liquids.
a repair. There is a danger of
electrocution, if voltage carrying
contacts are touched and/or the
electrical and mechanical construction
is modified. In the case of an
emergency:
- immediately remove the plug from
the power socket.
- Always remove the plug from the
power socket prior to cleaning the
machine.
- Do not use the machine with bare
feet and wet hands.
PH: 1800 800 255
bluepod.com.au

OBEY THE FOLLOWING INSTRUCTIONS TO PREVENT
DANGEROUS SITUATIONS
- Always allow the machine to cool down before cleaning.
- Do not allow the cord to hang over the side of the bench whilst the machine
is in use. This presents a risk that the machine could be pulled off the
bench, possibly causing burn injuries, particularly to small children.
GETTING TO KNOW THE ONE TOUCH BARISTA
ELECTRICAL CONNECTION (continued)
- Packaging material must not be used
for playing. There is a risk of suffocation.
- Packaging materials can cut/cause
injury if not handled carefully or if used
incorrectly.
-Notetheinformation onthe setuplocation
as well as on the electrical connection of
the machine to prevent personal injuries
and property damage.
- Beware that potential injury may occur
from misuse of appliance.
OBEY THE FOLLOWING SAFETY INSTRUCTIONS TO
PREVENT PERSONAL INJURY & PROPERTY DAMAGE:
- Before using the machine inspect it for
visible damage to the housing, lever,
water tank, milk container, power cord
and plug. Do not use the machine if it is
damaged - call our Customer Support
Line immediately.
- Make sure the machine is turned off
before plugging it into the socket outlet.
- Do not stick any objects or body parts
into the machine during operation.
- Do not leave the machine unattended
during operation.
- Do not move the machine during
operation.
- Do not place anything on top of, or cover
the machine during use.
- Always unplug the machine from the
power socket after using it.
- Do not leave the machine without water
in the tank.
SAVE THESE INSTRUCTIONS
Technical Data: Model ‘Easy Touch’,
Type IDMP17S, 240 Vac ~ 50 Hz - 1500 W, Made in China.
ELECTRICAL CONNECTION
To ensure the safe and correct operation
ofthemachine, the following instructions
must be observed when connecting it to
the power supply:
- This machine is rated at 220-240V,
1500W. Prior to connecting ensure that
this is compatible with your power sup-
ply. Make sure that the power cord is not
damaged prior to use, and that it cannot
come in contact with hot surfaces or sharp
edges.
- The machine may not be connected
using an extension cable, double adaptor
or outlet strip.
- The power cord should not be pulled taut.
- The electrical safety of the machine is
only ensured if it is connected to a proper-
ly installed protective ground system.
- Operating the device from an outlet with-
out an earth conductor is forbidden. If in
doubt, have the home wiring checked by a
licensed electrician. We do not asume any
liability for damages caused by a missing
or interrupted earth conductor.
A| Lever for opening and closing the lid
B| Rotary knob
C| Brew-Button, Espresso & Lungo
D| Brew-Button, Cappuccino
E| Brew-Button, Café Latte
F| Removable milktank
G| Milk nozzle
H| Capsule container
I| Drip tray grid / Upper Cup Platform for small cups
J| Lower Cup Platform for large cups
K | ON/OFF Button
L| Espresso nozzle
M| Removable Watertank
N| LCD Display Screen
A B C
D
E
F
G
H
I
J
K
L
M
N
PH: 1800 800 255
bluepod.com.au
PH: 1800 800 255
bluepod.com.au

BEFORE FIRST USE
The product should contain all of the
following components at the time of
purchase:
- Coffee machine, including water tank
and drain tray
- User manual
- Milk canister
DAILY USE
FOLLOW INSTRUCTIONS ON NEXT PAGE FOR
COFFEE PREPARATION
HOW TO CLEAN COFFEE MACHINE
BEFORE FIRST USE
It is important you clean the unit before first use. Please note: the first time the machine
is used there may be an odour caused. This is entirely normal and will disappear after
a few minutes.
The Easy Touch Machine is pre-programmed with three default settings. Before making
a coffee the following instructions must be followed:
Rinse removable water tank (M) and milk tank (F) with warm water.
Rinse thoroughly. Fill water tank (M) and milk tank (F) with cold water.
Fill the water tank (M) with water and the milk tank (F) with fresh, cold
milk.
Place a container or a large cup under the espresso nozzle (G).
Plug in the connection plug.
Plug in the connection plug.
Ensure that the espresso machine has been switched on or in standby
mode.
Turn the ON/OFF switch to ON position (K) and wait until the LCD
displays ‘Please Select’.
Exit standby mode by opening the lever (A). Your espresso machine is
ready to be used when the LCD displays ‘Please Select’.
NOTE! The device is intended for normal household use. The machine
can be overheated if you prepare directly more than 10 espresso‘s
repeatedly.
When the control LCD displays ‘Please Select’ (approx. 70 seconds),
press brew button and release (E) to flush system.
If the machine is turned off, switch the ON/OFF button (K) and wait
until the LCD displays ‘Please Select’.
The capsule container tray (H) and drip tray (I) must be emptied and
rinsed out regularly.
Open the lever (A) fully and insert an espresso capsule. Then, close
the lever (A) fully.
WARNING: Using the machine when the water tank is empty is not
recommended!
Wait until the water cycle finishes. Repeat the process twice before
use. WARNING: Steam will be dispensed from (G).
Inspect the delivery for completeness
and visible damage. If the product is
incomplete or damaged, please call:
1800 800 255 or email sales@bluepod.
com.au immediately, and do not use the
machine. Before using the machine for
the first time, clean it as described
under the heading ‘“How to clean coffee
machine before first use.”
PH: 1800 800 255
bluepod.com.au
PH: 1800 800 255
bluepod.com.au

HOW TO OPERATE
AUTOMATIC
Before output: Fill water tank (M) with fresh cold water and if making a cafe latte or
cappuccino fill the milk tank (F) with fresh cold milk. Turn the espresso machine on (K) -
open the lever fully (A) - insert the Lavazza Blue espresso capsule - close the lever (A)
fully - wait until the LCD Screen displays ‘Please Select’ (approx. 70 seconds). NOTE:
There may be slight deviations in the set brew times due to different coffee varieties or
water hardness.
ESPRESSO (SHORT BLACK)
CAPPUCCINO
LUNGO (LONG BLACK)
CAFÉ LATTE
Place a cup on the drip tray grid (I).
Place a cup on the drip tray grid (I) or lover platform (J).
Press the brew button once (C). The espresso machine is already
programmed for a 40 ml espresso.
Press the brew button (D) once. The espresso machine is already
programmed for the perfect cappuccino.
Place a cup on the lower platform (J).
Remove upper cup platform (I). Place a cup on the lower platform (J).
Press brew button (C) twice within 2 seconds. The espresso machine
is programmed for a 180 ml lungo.
Press the brew button (E) once. The espresso machine is already
programmed for a perfect cafe latte.
DISCARD LEFT OVER MILK IN CONTAINDER AFTER 2 DAYS.
ALWAYS PLACE MILK CONTAINER IN FRIDGE WHEN NOT IN USE.
ALWAYS STORE MILK AT OR BELOW 4OC.
13cm
8cm
ADJUSTABLE CUP PLATFORM
The cup platform is adjustable to accommodate various cup sizes.
Remove the upper cup
platform (I) and grid and
set aside.
Remove the grid on the
lower cup platform to
accomodate a larger cup.
PH: 1800 800 255
bluepod.com.au
PH: 1800 800 255
bluepod.com.au

STAND-BY MODE
Stand-by mode extends the life of your Easy Touch.
For a longer lifetime of your Easy Touch it will automatically switch into
the stand-by mode after 9 minutes of inactivity.
The espresso machine is turned on and one or more espressos are
generated.
Switch the Power switch (I) to turn the unit OFF “o”.
To make sure there are no capsules in the capsule compartment,
open and close capsule lever (A). Make sure the lever is lowered (A).
Please cup or container under nozzle (G).
If you do not use the machine within 9 minutes, it automatically starts
the stand-by mode. LCD will display ‘Stand by’
Remove the water tank (M) and the milk tank (F). Fill the water tank
and milk tank with cold water and place on machine.
Press the Power switch (o) to turn the unit ON “I”. Wait for LCD screen
to display ‘Please Select’.
Exit standby mode by opening the lever (A). Your espresso machine is
ready to be used when the LCD displays ‘Please Select’.
Empty and rinse out the used capsule container (H), drip tray (I), upper
cup and the lower cup (J). Replace parts back into the machine.
Press and release brew button (E). Please note that the machine will
only dispence 300 ml approx at one time, so press and release brew
button again and repeat 3 times. Beware of steam & hot water exiting
milk & espresso nozzle (G) and (L).
If you want to switch off the espresso machine completely, then switch
the ON / OFF button (K) to the OFF position.
Pull out the frother pin (B) and clean it carefully with a wet sponge and
warm water and then replace Frother Pin back into unit. Please note:
the Frother Pin (B) is only for cleaning purposes.
Standby
9min
On
HOW TO CLEAN THE UNIT - DAILY ROUTINE
To be done daily when machine is in use
WARNING
Easy Touch Espresso Capsule System is designed to be used ONLY with
Lavazza Blue capsules.
It is recommended on a regular basis you dissassemble the milk tank
and lid into 4 parts and wash them carefully with warm water.
DISCARD LEFT OVER MILK IN CONTAINDER AFTER 2 DAYS.
ALWAYS PLACE MILK CONTAINER IN FRIDGE WHEN NOT IN USE.
ALWAYS STORE MILK AT OR BELOW 4OC.
PH: 1800 800 255
bluepod.com.au
PH: 1800 800 255
bluepod.com.au

Pull out the frothing pin (B).
If you cannot prepare cappuccino or café latte because no milk frothing is possible.
Please use following instruction to clean the device and it parts thoroughly.
Seperate milk frothing device housing (Q) in upper and lower part (R).
Remove the main frother device by pressing in gently each side of the
unit and then pulling towards you.
Wash parts (S) (B) by hand with warm water.
Pull out frother part (S) of the milk frothing device housing.
Do not remove the silicone from part (R) tube. If blocked, rinse all of
part (R) thoroughly with warm water.
Assemble all parts in proper order and install housing assembly onto
the unit and gently insert frother pin (B) correctly for proper operation.
CLEANING IF MILK FROTHING DEVICE IS
BLOCKED (continued)
CLEANING IF MILK FROTHING DEVICE IS
BLOCKED
Q| Milk frothing device housing upper part
R| Milk frothing device housing lower part
B| Frothing pin
S | Frothing part
Q
R
B
S
PH: 1800 800 255
bluepod.com.au
PH: 1800 800 255
bluepod.com.au

DESCALING
IMPORTANT:Thecompanywillnotbe heldresponsibleforinterventioncovered
by a warranty for espresso machines that are broken or do not work correctly
due to the fact that the user has not carried out the descaling procedure.
Switch the Power button (K) to turn the unit OFF “o”.
Switch the Power button (K) to ON “—”.
Fill the water tank (M) with 0.8 L warm tap water and place back on the
espresso machine.
Pour ExpressoKleen 40g sachet (available on bluepod.com.au) into
water tank. Stir until disolved. Take care not to splash. Follow the
safety directions on the packet
Place a large cup on the drip tray grid (J). Press and release the brew-
button (C) twice.
Remove the water tank (M) and rinse thoroughly. Fill the water tank (M)
with 0.8 L warm tap water and place back onto the espresso machine.
After 10 minutes press and release the brew button ‘Long’ twice to
run the remainder of the water through the machine. Repeat with
remainder of water.
To rinse run this full tank of water through the espresso machine by
double pressing and releasing brew button (C) 2 times repeatedly.
WARNING
Any traces of lime scale (naturally present in the water) may seriously
compromise correct operation of the machine. The manufacturer
recommends descaling regularly, every 3 to 6 months.
TROUBLE SHOOTING
No function.
Little or no froth is being produced.
Coffee is not hot enough
The indicator light will illuminate,
but espresso does not flow.
Water under the machine.
The espresso machine is
whistling softly.
Produced little or no Crema.
The water does not flow through the
espresso dispensing nozzle (L).
The brew button (C+D+E) starts
flashing for a long time. When is the
espresso machine ready for use?
The espresso capsule does not fall
automatically into the capsule container
(H), when I open the lever (A).
The espresso capsule does not insert
correctly.
What are the espresso machine
default settings?
What happens if another key is
pressed during distribution of the
brew cycle.
Make sure the power cord is properly inserted into the unit and wall
outlet and the On/Off button (K) on the left of the machine is turned
“on”.
Remove pin (O), wipe clean and replace.
Heat your cup prior to use by filling with hot tap water. Let it rest for 10
seconds and then empty prior to making coffee.
The espresso dispensing nozzle (L) is clogged. The loaded espresso
capsule can be damaged. Wait for a short period of time, before
opening the lever and then try with a new capsule.
Make sure, that the lever (A) is closed.
The capsule container may be full and should removed from the
unit for at least 5 seconds to reset the counter and empty the used
capsules.
Make sure that the water tank (M) is installed correctly. CAUTION:
When refilling the water tank (M), always turn off the power, and then
remove the tank and fill it. Otherwise water may leak from the back
of the unit.
This is not a fault, but normal action of the pressure control valve.
Coffee has natural occurring oils which may clog the espresso nozzle.
To clean, regularly run a brew cycle with water only.
Coffee has natural occurring oils which may clog the espresso nozzle.
To clean, regularly run a brew cycle with water only.
The espresso machine takes approximately 70 seconds to heat up.
The capsule container (H) may be full. Please empty it or make sure
the capsule lever is fully open.
The capsule container (H) may be full. Please empty it or make sure
the capsule lever is fully open.
The One Touch Barista Capsule System is preprogrammed with four
default settings. A single press on brew button (C) will deliver a 40
ml espresso. A double press on brew button (C) will deliver a 180ml
lungo.A single button press for brew button (D) will deliver a delicious
cappuccino and a single button press for brew button (E) will delivery
a rich cafe latte.
Coffee distribution is interrupted in advance.
PH: 1800 800 255
bluepod.com.au PH: 1800 800 255 bluepod.com.au
