3.4 INSTALLATION
The user is fully responsible for the work carried out or still to be carried out in
the installation area.
Before starting assembly operations, the installer must adhere to the safety
precautions required by law and, in particular:
must ensure that the provisions for the system comply with local, national and European
laws
Must check if specific authorisation is required because of urban, architectural and fire
prevention regulations ;
Must scrupulously follow the instructions given in this manual, above all paragraphs (3.1) on
page 10 and (3.2 - 3.3) on page 11
Must always use the personal protective devices and all the protective means required in
compliance with current legislation in force.
3.5 ELECTRICAL CONNECTION
The BMax boiler does not need any electrical connection, but the burner does (SEE THE
BURNER MANUAL). These electrical connections must be carried out by a specialised,
qualified technician who is authorised to work, in line with current legislation in force.
3.6 CONNECTION TO THE HEATING PLANT
Choice of the correct size of the boiler and the heating plant, as well as the choice of the type of
plant to be realised, are the responsibility of the installer and/or the designer.
It is advisable to connect the machinery to the heating system by means of a three-piece joint, in
order to be able to remove it without causing damage in the event of malfunctioning, in particular, to
the return flow connection. In fact, it could be useful to install a T-junction with a stop cock to be able
to drain the plant for maintenance work.
For correct functioning of the plant it is advisable to use a mixing valve set at 55 °C as a way to
regulate the temperature both of the plant and the boiler, and to be able to increase the temperature
of the return flow into the boiler, in order to protect the parts from dangerous temperature drops
caused by condensation in the flues.
After having completed the connections to the hydraulic system, the heating plant and the boiler
must be filled. Before this operation, it is necessary to check the hardness of the water and of water
residue, and if needed, install (for example, if there is water with a fixed residue greater than 300 mg/
l at 180°C) a water softener before the entry point of the water supply pipe. This will ensure optimal
conservation of the inside surfaces of the boiler body, but also of the whole heating plant. Briefly, the
following operations are necessary for filling: open any sectioning valves on the plant; completely
open all the bleeder valves on all the radiators, so that all the air can escape without leaving air
bubbles; fill the system very slowly using the Drainage Connection (4) of the boiler (see Pg. 7)
keeping the bleeder valves of the radiators open even when a trickle of water starts to run, again to
ensure that no air bubbles are created. When the installation is completed, it is a good rule to keep
checking the seals of the hydraulic connections for at least 2 or 3 days for any leakage.
