Bolin Technology VCC-BR-M-11132017 User manual
1
HDBaseT Receiver
USER MANUAL
VERSION: VCC-BR-M-11132017
© 2017 Bolin Technology
2
Contents
IMPORTANT INFORMATION ..................................................................................................................................................... 3
WHAT’S IN THE BOX ................................................................................................................................................................. 5
OVERVIEW................................................................................................................................................................................ 6
CAMERA VERSION.............................................................................................................................................................................. 6
MODEL NUMBERS ............................................................................................................................................................................. 6
FEATURES ................................................................................................................................................................................. 6
HDBASET ADAPTER................................................................................................................................................................... 7
SYSTEM CONFIGURATION......................................................................................................................................................... 8
CONNECTION .................................................................................................................................................................................... 8
OBTAIN VIDEO SIGNAL ....................................................................................................................................................................... 8
CAMERA CONTROL METHODS AND SYSTEM CONFIGURATIONS ................................................................................................................... 9
DIMENSION ............................................................................................................................................................................ 12
INSTALLATION ........................................................................................................................................................................ 12
SPECIFICATIONS...................................................................................................................................................................... 13
3
Operating Instructions
Thank you for purchasing our product. If there are any questions, please contact the authorized dealer.
Before operating the unit, please read this manualthoroughly and retain it for futurereference.
Copyright
Copyright 2015-2016 Bolin Technology all rights reserved. No part of this manual may be copied, reproduced,
translated, or distributed in any form or by any means without prior consent in writing from our company.
Trademark Acknowledgement
and other Bolin's trademarks and logos are the property of Bolin Technology Other trademarks,
company names and product names contained in this manual are the property of their respective owners.
IMPORTANT INFORMATION
Legal Notice
Attention:
To ensure account security, please change the password after your first login. You are recommended to set a strong
password (no less than eightcharacters). Password login does not apply to some models that do not need password login.
The contents of this document are subject to change without prior notice. Updates will be added to the new version of this
manual. We will readily improve or update the products or procedures described in the manual.
Best effort has been made to verify the integrity and correctness of the contents in this document, but no statement, information,
or recommendation in this manual shall constitute formal guarantee of any kind, expressed or implied. We shall not be held
responsible for any technical or typographical errors in this manual.
The product appearance shown in this manual is for reference only and may be different from the actual appearance of your
device.
This manual is a guide for multiple product models and so it is not intended for any specific product.
In this manual, the illustrations of displayed interface, parameters displayed, drawings and value ranges may vary with
models. Please see the actual product for details.
Due to uncertainties such as physical environment, discrepancy may exist between the actual values and reference values
provided in this manual.
Use of this document and the subsequent results shall be entirely on the user’s own responsibility.
Safety Information
WARNING!
Installation and removal of the unit and its accessories must be carried out by qualified personnel. You must read all of
the Safety Instructions supplied with your equipment before installation andoperation.
Warnings:
•If the product does not work properly, please contact your dealer. Never attempt to disassemble the camera yourself.
(We will not assume any responsibility for problems caused by unauthorized repair or maintenance.)
•This installation should be made by a qualified service person and should conform to all the local codes.
•When shipping, the camera should be packed in its originalpackaging.
•Make sure the power supply voltage is correct before using the camera.
•Do not drop the camera or subject it to physicalshock.
•Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period of time, put on the lens cap to protect the sensor from dirt.
•Do not aim the camera lens at the strong light such as sun or incandescent lamp. The strong light can cause fatal
damage to the camera.
4
Maintenance Precautions:
•If there is dust on the front glass surface, remove the dust gently using an oil-free brush or a rubber dust blowing
ball.
•If there is grease or a dust stain on the front glass surface, clean the glass surface gently from the center outward
using anti-static gloves or an oil-free cloth. If the grease or the stain still cannot be removed, use anti-static
gloves or an oil-free cloth dipped with detergent and clean the glass surface gently until it is removed.
•Do not use organic solvents, such as benzene or ethanol when cleaning the front glass surface.
Regulatory Compliance
FCC Part 15
This equipment has been tested and found to comply with the limits for digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his ownexpense.
This product complies with Part 15 of the FCC Rules. Operation is subject to the following twoconditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired operation.
LVD/EMC Directive
This product complies with the European Low Voltage Directive 2006/95/EC and EMC Directive
2004/108/EC.
WEEE Directive–2002/96/EC
The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE)
Directive and must be disposed of in a responsible manner.
5
WHAT’S IN THE BOX
6
Overview
Camera Version
HDBaseT Version: HV:V.D.0000cdjk.14.001.01.A02
Model Numbers
This user guide is suitable for the following models:
•VCC-4K-BR
Features
•HDBaseT SingleWire Technology
•Uses One Cat5e/6 Ethernet cable (up to 100meters) to deliver camera power, up to 4K resolution
video output, RJ45 to RS232/RS422/RS485 control and Audio.
•Transmit up to HD/Ultra-HD 4K resolution video output
•HDMI 1.4b video features supported
•Supports 3rd party IR receiving controller input and built-in IR receiver in HDBaseT box for use of IR
remote controls
•25W 802.3at PoE+ Power supply from HDbaseT box
•RS-232,RS-422/485 control over Ethernet port and IR remote control supported
•Power: DC 12V Power Supply
•Supports IP control and IP streaming Pass-Thru (HDBaseT receiver is not an IP video enoder,the
LAN Port is IP Pass-Thru for the camera with IP control or IP streaming functionality. Do not sue it
as an IP video encoder, The IP Pass-Thru function does not apply to model VCC-8-4K12S-SMB)
7
HDBaseT Adapter
1. LAN Port(RJ45)
Connect network switch or router to this port for Ethernet. (Not an IP encoder)
2. IR Remote Controller Indicator
These are sensors to receive commands from infrared remote controller, distance up to 10 meters.
3. RS-422 Control Port
Use RJ45 to RS-422 extension adapter cable to remotely control PTZ camera. (Extension cable detail view on
page 10)
4. RS232 Control Port
Use RJ45 to RS-232 extension adapter cable to remotely control PTZ camera (Extension cable detail view on
page 10)
5. 12V DC Power Port
Connect include 12V DC power adaptor and cord.
6. Power LED Indicator
Turns red when the device is connected to power outlet.
7. Heat-sink surface panel
All aluminum body for quick heat dissipation.
8. HDMI Upholder
To fixed male HDMI port in stabilization.
9. 3.5mm IR IN
Connect to an IR receiver, The IR signal received from this port can send out via HDBaseT receiver.
10. v1.4b HDMI Video Output
Connect to HDMI source display.
11. RJ45 Port for HDBaseT Input(802.3at PoE+)
Support One-Cable transmission of camera power (POE+), 4K video and control signal. Connects to the
HDBaseT camera via CAT5e/CAT6 cable. (Transmission distances of up to 100M/328ft)
12. 3.5mm jack Audio Out
13. HDBaseT Port signal Link indicator
The LED lit GREEN when the camera is powered on.
14. HDBaseT Port signal Link indicator
The LED flashed ORANGE when the camera transmits data with HDBaseT.
8
System Configuration
Connection
When the camera is connected to a computer and joystick keyboard with a VISCA cable (cross type, RS-232), you can
operate the camera with the computer and the joystick keyboard.
When the camera is connected to a joystick keyboard a control cable (cross type, RS-422/485), you can operate the
camera’s pan, tilt, zoom with the joystick keyboard.
Obtain Video Signal
Use HDBaseT Receiver to obtain HDMI 4K / HD Video signal
1. Use Cat5e/Cat 6 network cable to connect the camera to HDBaseT Receiver.
2. Connect HDBaseT Receiver to a 4K or HD monitor/TV using HDMI cable. For displaying 4K video, a HDMI
version 1.4 needs to be used.
3. Turn on the camera and the HDBaseT Receiver, video will display on the monitor after running initializing.
4. Information of the camera initial setting status will display for 5 seconds.
5. You can set the video format of the camera to the one you want to display.
9
Camera Control Methods and System Configurations
This unit has multiple ways of controlling the camera and various system configuration capabilities using optional
products. This section describes ways of controlling and typical system examples with the required components and usage
of each system.
1. Use the Infrared Remote Controller
2. Use HDBaseT Receiver to control.
Control the camera with using HDBaseT Receiver
Use the Infrared Remote Controller
To operate the camera from a short distance. For IR remote control details, refer to Operation Using the Infrared Remote
Controller.
System Configuration Diagram
Control the camera using HDBaseT Receiver
1. Set RS232 control method on Bottom Dip Switch.
2. Set Baud Rate on Bottom Dip Switch to the same as Baud Rate setting on the keyboard you are using.
3. Reboot the camera by turning it Off/On after the Bottom Dip Switch has been set up correctly.
4. Device supports RS232 and RS422/485 control.
5. RJ45 to RS232 on HDBaseT receiver does not support daisy chain control.
6. Use Cat 6 network cable to connect the camera to HDBaseT Receiver.
7. Control connection in between HDBaseT Receiver and keyboard refer to the camera control connection.
10
RS232 and RS422/RS485 Control Connection
There are two ways to make the RS232 and RS422/RS485 control cable connection:
1. Use Cat 6 network cable to make the RJ45 connectors to connect to the camera. Follow the pinout bellow to
make the RJ45 connectors.
2. Use extension cables included to connect the RS232/RS422 control cable:
a) RJ45 to RS232 extension adapter cable.
This extension cable does not support daisy chain control. Use connector “IN/OUT” for 8-Pin Mini Din Serial
RS232 Cable connection.
b) RJ45 to RS422 extension adapter cable.
You can use this extension cable to operate multiple cameras.
Important:
The baseline cable standard for HD/4K systems is Cat5e. Signal greater distances can be achieved
by using Cat6e or higher above as Cat7, which have thicker copper cores for easier signal
transfer.
Whichever network cable type you choose, ensure that the main wiring is ‘solid core’, not ‘patch’
cabling.
Terminate the cabling using RJ45 connectors to the 568B wiring standard, shown as below:
RJ45 cable connector is wired to the AT&T 258A/EIA 568B standard.
11
Note
For control details, refer to Operating Instructions of control keyboard/station software.
•You need to match the Baud Rate between the camera and the joystick controller.
•You cannot use the RS-232 connections when using the RS422/485 connection.
Operating Multiple Cameras Using RS-422/485
•Using RS-422 (VISCA), you can connect up to 7 cameras.
•Using RS-485 (PELCO), you can connect up to 255 cameras.
•Using RS-485 (PELCO), all camera addresses must be set up before the connection. You can set the camera
address by operating OSD menu, or by setting the Dip Switch on the bottom of the camera.
•In this case, you can use multiple control keyboards.
•The joystick of the remote keyboard controller allows comfortable pan/tilt and zoomoperations.
12
Dimension
Unit: mm
Installation
Screw up the rack mount on HDBaseT
Securing the HDMI cable on metal cable rack.
13
Specifications
