1 2 3 4 5 6
7- 90 °C V(temp. ºC) Select the temperature (7= cold)
1 - 24 h (Ready in) End of programme af ter ...
- 1400* (rpm) Select the spin speed (* dependin g on the model) or c(without final spin,
laundry soaks in the last rinsing water, disp lay panel- - - )
Status displays Programme sequence displays:
1üü2üücü-¯-Wash, rinse, spin, programme duration or en d (-0-)
(Childproof lock apage 5
,Open the washing machine door, rel oad laundry apages 4, 5
End of programme when ...
... $Start/Reload flashes and -¯-appears on the display panel.
Note: If display panel lighting is switched off, press any button aEnergy
saving mode, page 5.
Interrupting the programme
Programmes at high temperatures:
 Cool washing: Select Rinse /Spin .
 Press $Start/Reload.
Programmes at lower temperatures:
 SelectR inse /Spin (deactivate Aqua Plus =button) or
Drain >.
 Press $Start/Reload.
Changing the programme if ...
... you have selected the wrong progr amme by mistake:
 Reselect the programme.
 Press $Start/Reload. The new programme starts from the begi nning.
Reloading laundry if ... apage 5
... Press $Start/Reload;both the symbols §+,are displayed on
the display panel. If ǯis lit, the washing machine door cannot be opened.
Press $Start/Reload.
Correct installation according to the separate
installations actions.
Checking the machine
 Never usea damaged machine!
 Contact customer service!
Connecting the mains plug
Make sure your hands are dry!
Handle the plug only!
Turning on the tap
Compartment II: detergent for the m ain wash, water softener,
bleach, stain remover
Sorting and loading laundry
Follow the manufacturer's care in formation!
Sort laundry according to the label's indications.
And according to type, colour, soiling and temperatu re.
Do not exceed the max imum load aPage 7.
Observe important information! aPage 6
Wash laundry of different siz es in the same wash programme.
Close the door. Take care not to tra p items of laundry between the washing machine door and
seal.
Add detergent and care products
Measure detergent according:
amount of laundry, soiling, wa ter hardness (ask your water supply company) and
manufacturer's instructions.
For models without insert for liq uid detergent:
Pour liquid detergent into the appropria te dispenser and place in the drum.
Your washing machine
Congratulations on having opted for a modern, high-quali tyd omestic appliance
manufactured by Bosch. This washing machine is distinguished by its economical
energy consumption.
Each machine that leaves our fa ctory has been inspected thoroughly to ensure that it
functions properly and is i n perfect condition.
For further information on our products, accessories, spares and serv ices, consult our
website www.bosch-home.com or contact any of our cus tomerser vice centres.
You can find the contact detai lsf or your nearest after-sales service here or in the after-
sales service directory (depending on model) .
GB 0844 8928979 (calls from a BT landli new ill be charged at up to 3 pence
per minute. A call set-up fee of up to 6 pence may apply)
IE 01450 2655
Environmentally friendly waste disposa l All packaging must be disposed of in accord ance with environmental guidelines.
This appliance is certified in accordance with European Directive 2002/96/CE on the
waste electrical and electronic eq uipment (WEEE).
This directive provides the framework for t he EU-wide collection and reuse of used
appliances.
Intended use
Contents Page
ʋIntended use ....................................................................................... 1
ʋProgrammes ........................................................................................ 1
ʋSetting and adjusting the programme ................... ........................3
ʋWashing ........................................................................................... 3/4
ʋAfter washing ...................................................................................... 4
ʋIndividual settings .................................... ......................................5/6
ʋImportant information .............................. ......................................... 6
ʋOverview of programmes ................................................... .............7
ʋSafety instructions ............................. ................................................8
ʋConsumption values . ........................................................................ 8
ʋCare and cleaning ............................................................................. 9
ʋInformation on the display pan el .................................................... 9
ʋMaintenance ............................................. ....................................... 10
ʋWhat to do if ... ................................................................................ 11
Protection of the environment/Conservation tips
 Always fill the washing machine with a maximum amount of
laundry for the relevant pr ogramme.
 Wash normally s oiled laundry without a pre-w ash.
 Instead of Cottons LF90 °C, choose the programme
Cottons LF60 °C with the additional function E coPerfect ć.
Comparable cleaning result was significantly lower e nergy
consumption.
 Measure the detergen t according to the manufacturer's
instructions and water hardnes s.
 If th e laundry is then dried in th e tumble dryer, select spin speed
according to instructions of dryer manufacturer.
Preparation Before the first wash,
run a wash cycle with no laun dry in the machine aPage 9.
Setting** and adjusting programmes
Display panel /
option buttons
Programme selector Start /
Reload
Programme selector for
switching the machine on
and off and for selecting the
programme. Can be turned
in either direction.
Programmes
Detailed overview of programmes apa ge 7.
Temperature and spin speed can be selected individually,
irrespective of the selecte d programme and programme
progress.
Cottons LFhard-wearing fabrics
+ Prewash 7hard-wearing fabric s,p rewash
Easy-Care Isynthetic fabrics
+ Prewash 7synthetic fabrics, prewash
Mixed Load /Different types of la undry
Delicate/Silk Delicate washable fa brics
ÿWool Hand/machine washab le wool
Rinse / Spin Laundry washed by ha nd, Aqua Plus =button acti-
vated; if only using the sp in cycle, deactivate the but-
ton
Drain >Drain rinsing water with c(wi thout final spin)
Gentle Spin Laundry washed by hand with a r educed spin speed
Super Quick 15 6Short programme
Dark Wash Dark laundry
Super delicate +Lingery programme
Sportswear $microfibre fabrics
Allergy+ āhard-wearing fabrics
**If the (symbol flashes in th e
display panel, the childproof lock is
active aDeactivate childproof lock,
page 5.
Additional functions and opti on
buttons aIndividual settings,
page 5.
Press $Start/Reload
Washing
1
2
Removing the washing
Open the washing machine door and remove the washing.
If (without final spin) i s active: turn the p rogramme selector to Drain >or select the spin speed.
Choose $Start/Reload.
 Remove any foreign ob jects.R isk of rusting.
 Leave the washing mach ine door and detergent door open
so that any resid ual water can evaporate.
Turn the tap off
Not required for Aqua-Stop m odels aRefer to Installation instructions.
Switching off
Turn the programme selector to Off .
Washing
Compartment ~: Fabric softener, bleach
Compartment I: Detergent for pre wash
ʋfor domestic use only,
ʋfor washing machine-washab le fabrics and
hand-washable wool in dete rgent solution,
ʋto be operated with cold or cold and hot (max. 60 ºC)
drinking water, depending on model, and commercially
available detergents and ca re products which are suita-
ble for use in washing machines.
.
 F ollow the safety instruct ions on page 8!
 D o not leave children un attended near the
washing machine.
 T he washing machine is not to be used by
children or persons no t familiar with the
operating instructions.
 K eep pets away from th e washing machine.
Dilute viscous fabric softener and fabric conditioner with water.
This prevents blockages.
Individual settings
ʑOption buttons
You can change the spin speed and the tem perature before the selected programme starts and while it is runnin g.Th e
effects depend on the progra mme progress.
ʑV(Temperature °C)
You can change the display ed washing temperature. The maximum selectable temperature d epends on the current
programme.
ʑ(Ready in)
When you select the programme, the r elevant programme duration is displayed. You can delay th e end of the
programme before it begins. The ready in-time can be set in increments of one hour up to a maximum of 24 hours.
Press the (Ready in) button un til the required number of hours is display ed (h = hour). Choose $Start/Reload.
ʑ(spin speed in rpm/ (without final spin))
You can change the displayed spin speed. The maximum selectable spin speed depends on the model an dwhi ch
programme is currently selected.
ʑAdditional functions aOverview of programmes, p age 7
SpeedPerfect iFor washing in a shorter time with a washing o utcomec omparable to that of the
standard programme. Maximum load aO verview of programmes, page 7.
EcoPerfect ćFor saving energy with a w ashing performance comparable to that of the standard
programme.
Reduced Ironing SSpecial spin sequence with subsequent fluffing. Gentle final spin: residual moisture in
the laundry slightly increased.
Aqua Plus =Increased water level and additional rinse cyc le, extended washing time. For areas
with very soft water or for further enhancing the spin result.
ʑChildproof lock
(in the display panel You c an lock the washing machine to prevent the functions you have set from being
changed inadvertently.
ON/OFF: after the start/end of the programme, press and hold $Start/Reload for
approx. 5 seconds.
Note: The childlock can remain activated until you wish to start the next programme,
even after switching off the machine.
Then you can deactivate the childlock before starting the programme an d activate it
again as necessary once the programme has started.
Note:
The (symbolis lit: Childlock acti ve.
The (symbolflashes: Childlock active and then the programme select or is altered.
To prevent the programme from sto pping, move the programme selector back to
the original programme, the (symb ol is lit again.
ʑReloading
§+o,in the display panel Press $Start/Reload if you want to add additional items of laundry after the
programme has started. The mac hine checks whether reloading is possible.
§+,are lit: reloading is possible.
ǯflashes: wait until §+,are lit.
Note: do not open the door until both the §+,symb olsa relit .
ǯ: it is not possible to re load.
Note: for safety reasons, the wash ing machine door remains locked when the water
level and/or temperature is high, or during spinning.
To continue the programme, p ress the $Start/Reload button.
ʑEnergy saving mode
The display panel lighting goes out after a few minutes, $St art/Reload flashes. Press any button to switch on the
lighting.
ʑ$Start/Reload
To start the programme or to subsequently load additi onal laundry, and to activate/deactivate th e childproof lock.
Individual settings z
ʑSignal
Important information
Protecting the laundr y and the machine
 When determining the dosage o f all washing powders, additives and cleaning agents, y ou must follow the
manufacturer's instructions..
 Empty all pockets
 Check for metal items (paper -clips, etc.).
 Wash delicates in a laund ryb ag (tights, curtains, underwired bras).
 Fasten zips, do up any butto ns.
 Brush sand out of pockets and collars.
 Remove curtain fittings or place in the laundry bag.
Laundry with varying degrees of soiling
Wash new items of clothing separately.
light Do not prewash. If required, cho ose the additional function SpeedPerfect.iPre-treat any stains as necessary.
intense wash Load less laundry. Choose a programme with a prewash.
Soaking Load laund ry of the same colour .
Pour soaking agent/detergent i nto compartment II in accordance with the manufacturer's i nstructions. Turn the
programme selector to Cottons LF30 °C and press $Start/Reload. After approx . 10 minutes, press $Start/
Reload to pause the programme. On ceth e required soaking time has elapsed, press $Start/Reloa d again to
continue the programme, or select a different programme.
Starch Laundry should n ot be treated with fab ric softener.
Starching is possible in all wash programmes if liquid starch is used. Pour the starch in accordance with the
manufacturer's instructions into fabric softener compartment ~(rinse first if necessary).
Dyeing / Bleaching
Dye should only be used in nor mal household quantities. Salt may damage stainless steel. A lways follow the dye
manufacturer's instructions. Do not use th e washing machine for bleaching clothes.
Insert for liquid detergent depending o n model
Position the insert for dispensin g liquid detergent:
 Remove the detergent drawer com pletely apage 9
 Slide the insert forwards and clic k into place.
Do not use the insert (slide upwards): f or gel detergents and washing powder,
for programmes with + Prewash 7and end time op tion.
Set to Â1 step, the
display panel
lights up
press and
hold +1 step, release
set to Âsetting the
volume*
setting the
volume*
1 step
* if necessary, select the
function several times
1. Activating the mode
for setting the signal
volume
2. Setting the volume
for...
direct
Button signals Information signals jj
All buttons are sensitive an d need
only to be touched ligh tly. Press and
hold the (Ready in) option b utton
for an automatic run through all
setting options.
Additional
functions
3
Detergent drawer with
compartments I,II,~Door
Drum
Control panel
Service door
1 2 3 4 5 6
Insert for liquid detergent (depending on model) ap age 6
Do not switch on the washing machine until you have read these
instructions and the separate Ins tallation instructions!

7
Overview of programmes aRefer to the table of consumption values on pag e 8, and advice and warnings on page 6.
Programmes °C max. Type of laundry Additional functions; Information
Cottons LF7- 90 °C
8 kg/ 4 kg*
hard-wearing fabrics, co ttons or linen that can be washed at 90°C SpeedPerfect i*, EcoPerfect ć,Reduced Iro ningS,A qua Plus =+ Prewash 7Allergy+ ā7- 60 °C colour fast cottons or linen
SpeedPerfect i*, EcoPerfect ć,Reduced Iro ningS,A qua Plus =; for particularly sensitive skin; lon ger wash programme at selected tem- perature, higher water level, additi onal rinse cycle
Easy-Care I7- 60 °C
3.5 kg
easy-care cotton, linen, synthetic or blended fabrics SpeedPer fect i,EcoPerfect ć,Reduced Ironing S,Aqua Plus =+ Prewash 7Mixed Load /7- 40 °C cotton or syntheti c fabrics SpeedPerfect i,EcoPerfect ć,Reduced Ironing S,Aq ua Plus =;
different types of laundry can be washed together
Dark Wash 7- 40 °C dark cotton and dark synthetic fabrics SpeedPerfect i,EcoPerfect ć,Reduced Ironing S,Aq ua Plus =;
reduced rinse and final spin cycle
Delicate/Silk 7- 40 °C
2 kg
for delicate fabrics, e.g., silk, sati n, synthetic fibres or blended fabrics (e.g. curtains)
SpeedPerfect i,EcoPerfect ć,Reduced Iron ing S,Aqua Plus =: no spin between rinse cycles
ÿWool 7- 40 °C hand/machine washab le wool particularly delicate wash programme to avoid shrinkage of laundry;
longer programme breaks (fabrics r est in the detergent solution)
Super Quick 15 67- 40 °C syn theticc otton, linen, synthetic fibres or blended fab-
rics
Short programme of approx. 15 mi nutes, suitable for lightly soiled laundry
Sportswear $7- 40 °C microfib refa brics SpeedPerfect i,EcoPerfect ć,Reduced Iron ing S,Aqua Plus =Super delicate +7- 40 °C 1 kg lingery SpeedPerfect i,EcoPerfect ć,Reduced Iron ing S,Aqua Plus =Additional programmes Rinse / Spin , Drain >, Gentle Spin *reduced load with additional fun ction SpeedPerfect i.
For programmes without prewash , add detergent to compartment II. For prewash programmes, distribute the detergent between compartments Iand II.
9201 / 9000737235
9000737235 WAQ28461GB /...
Robert Bosch Hausgeräte Gm bH
CarläWery Str. 34
81739 Munich / Germany
8
Safety instructions
 Carefully read the instruction man ual and the information enclosed, and act accordingly.
 Keep the machine's documentation for future reference.
Risk of electric shoc k!  Never pull the cable to disconnect the mains plug!
 Never insert/disconnect the mains plug wi th damp hands.
Danger to life! For worn-out appliances:
 Disconnect the mains plu g.
 Sever the mains cable and discard along with the plug.
 Destroy the lock on the w ashing machine door. This will prevent children from
locking themselves in and risking their lives.
Danger of suffocation!  Keep packaging, film and packaging par tso uto f the reach of children.
Risk of poisoning!  Keep detergents and car e products out of the reach of children.
Risk of explosion!  Items of laundry pretreated with cleaning agents contai ning solvents, e.g. stain
remover/cleaning solvent may lead to an explosion af ter being loaded into the
washing machine.
Rinse items of laundry thoroughly by hand beforehand.
Risk of injury!  The wash ing machine door may become very hot.
 Be careful when draining h ot detergent solution.
 Do not climb onto th e washing machine.
 Do not lean on the open w ashing machine door.
 Do not reach into the d rum if it is still rotating.
 Be careful when opening th e detergent drawer while the machine is in operation.
Consumption values depending on model
Programme Load Electricity*** Water*** Programme
duration***
Cottons 30 °C* 8 kg 0.40 kWh 68 l 145 min
Cottons 40 °C* 8 kg 1.05 kWh 68 l 155 min
Cottons60 °C* 8 kg 1.15 kWh 68 l 165 min
Cottons 90 °C 8 kg 2.30 kWh 80 l 155 min
Easy-Care 40 °C* 3.5 kg 0 .64k Wh 55 l 103 min
Mixed Load 40 °C 3.5 kg 0.54 kWh 47 l 60mi n
Delicate/Silk 30 °C 2 kg 0.19 kWh 34 l 41 min
Wool 30 °C* 2 kg 0.17 kWh 39 l 40 min
* Programme setting for testing i nac cordance with valid standard EN60456.
Note on comparative tests: For testing the test programmes, was h the specified load using the maximum spin speed.
Programme Additional
function Load Annual energy consumption
Annual water
consumption
Cottons40/60 °C EcoPerfect ć** 8/4 kg 179 kWh 8700 l
** Pro grammes etting for testing and energy labelling in accordance with EU directive 2010/30/EU with cold wa ter (15ºC) .
*** The values deviate from the indicated values d epending on water pressure, hardness, and inlet temperature, a mbient tem-
perature, type, amount and soiling o f the laundry, detergent used, fluctuations in the p ower supply and selected additional
functions.
9
Care and cleaning
Before the first wash
Do not put laun dry in the machine! Turn on the tap. Put into c ompartment II:
 approx. 2 litres of water
 detergent (mea sure according to the manufacturer's instructio ns for lightly soiled laundry and water hardness)
Turn the programme sel ector to Easy-Care I60 °C an d press $Start/Reload. At the end of the programme, turn the
programme selector to Off.
Machine housing, control panel
 Remove detergent and cleaning agent residue.
 Wipe with a soft, damp cloth.
 Do not wash the machine with a jet of water!
Cleaning the detergent drawer ...
... if it contains detergent or fabric softener residues.
1. Pull out, press insert down a nd remove drawer completely.
2. To remove the insert: press upwards fro mb elow with your finger.
3. For models with insert for liqu idd etergent:Slide the insert upwards and remove it from the back.
4. Clean the detergen t dispenser tray and inserts with water a nd a brush and dry them.
5. Attach the insert and engage (connect the cylinder to the guide pin ).
6. Push in th e detergent drawer.
Leave the detergent drawer open so that any residual water can evaporate.
Drum
Leave the washing machine door open so that thedrum can dry out.
Forrust stains, usechlorine-free cleaningagent,not steel wool.
Descaling Ensure there is no laundry in the machine!
This will not be necessary if the correctdos ageof detergent is used. If it is, descale the appliance according to the
manufacturer's instructions. Descaling products can be acquired on the website or from customer services aInstallation
instructions.
Emergency release e.g. in the event of a power cu t
The programme continues to run when the power has been restored. However, if the laundry has to be removed, th e
washing machine door can be opened as follows:
Risk of scalding!
The detergent solution and laundry may be hot. Let it cool.
Do not reach into the drum if it is still rotating.
Do not open the washing machine door if water can be seen through the glass.
1. Turn the progr amme selector to Off and disc onnect the mains plug.
2. Drain the detergent solution apage 10.
3. Pull the emerge ncy release downwards with a tool and rel ease.
The washing machi ne door can then be opened.
Information on the display panel depending on model
,flashes Close the washing machine door proper ly; laundry may be caught.
§:³Å,
§:ÉTurn on the (cold water )tap f ully, supply hose kinked or trapped;
Clean the filter apage 10, water pressure too lo w.
§:³µ Detergent solution pump blocked; Clean th ed etergent solution pumpapage 10.
 Drainage hose / waste pipe blocked; Clean the drain agehos e at the siphon apage 10.
 Heavy fo am build-up apage 11, status indicator 1flash es.
§:´Water in the base tub, appliance leaking. Call customer services!
©:³¯ Open the (hot water) tap fully .
 Inlet h ose kinked/trapped.
 Water pressure too low. Clean the filter apage 10.
 Hot water hose not connected ;ap pliance will operate using cold water only. Ignore information, only for first
wash cycle.
(Childproof lock activated: to d eactivate apage 5.
Risk of electric shock! Disconnect the mains plug.
Risk of explosion! Do not use solvents.
9
10
Maintenance
Detergent solution pump
Turn the programme selector to Off and disconnect the mains plug.
1. Using a screwdriver or the insert f orli quid detergent
(depending on model), open a nd remove the service flap.
2. Remove the folding gutt er and place a large enough container underneath.
3. For models with a drainage hose: Remove the dr ainage hose from the retainer an d pull it
from the housing.
Remove the sealing c ap, allow the detergent solu tion to flow out into the c ontainer. Replace
the sealing cap and place t hed rainage hose in the retainer.
3* For models without a drainage hose: Carefully unscrew the pump c over 180° oru ntil the
detergent solution begi ns to flow out on the folding g utter. When the container is full, close
the pump cover and empty the c ontainer. Repeat the above steps until all the detergent
solution has completely drained out.
4. Carefully unscrew the pump cover (there may be residual water).
5. Clean the interior, pump cover threa d and pump housing (the impeller in the detergent
solution pump must r otate).
6. Replace the pump cover an d screw it tightly.
7. Return the dra inage hose (depending on model) and the folding gutter to their start position.
8. Place the service flap back on and close.
To prevent unused detergent from flowing straight into the drain during the next wash:
Pour 2 litres of water into compartment II and then sta rt theDrain >programme.
Drainage hos e at the siphon
Turn the programme selector to Off and disconnect the mains plug.
1. Loosen the hose c lamp, carefully remove the drainage hose (residual water).
2. Clean the drainage hose and siph on connecting piece.
3. Reattach the drainage h ose and secure the connection with the hose clamp.
Filter in the water supply
Risk of electric shock!
Do not immerse the A qua-Stop safety device in water (c ontains an electric valve).
Reduce the water pressure in the supply hose:
1. Turn off the tap.
2. Select any programme ( except Rinse / Spin // Drain >).
3. Choose $Start/Reload. Let the pr ogramme run for approximately 40 seconds.
4. Turn the programme selecto r to Off. Disconnect the mains plug.
Clean the filter:
5. Disconnect the hose fro m the tap.
Clean the filter using a small b rush.
and/or for Standard and Aqua-Sec ure models:
Remove the hose on the rear of the appliance.
Remove the filter with pliers an d clean.
6. Connect the hose an d check for leaks.
Risk of burning!
Allow the detergent s olution to cool.
 T urn off the tap.
11
What to do if...
ʑWater is leaking out  Attach/replace the drainage hose correctly.
 Tighten the screw connection of the supply hose.
ʑNo water supply.
Detergent not dispensed.
$Start/Reload not selected?
 Tap not turned on?
 Filter blocked? Clean the filter apage 10.
 Supply hose kinked or trapped?
ʑThe appliance door will not
open.
 Safety function active. Programme stopped? apage 4.
(without final spin) selected? ap age 3, 4.
 Can be opened by emergency releas e only? apage 9.
 Door locked after the wash ing machine is switched off: Switch on the washing
machine and wait for 5 seconds .
ʑThe selected programme does
not start.
$Start/Reload or (Ready in) time selected?
 Washing machine door closed?
 Childproof lock active? Dea ctivate apage 5.
ʑDetergent solution is not
drained.
(without final spin) selected? ap age 3, 4.
 Clean the detergent solution pump apage 10.
 Clean the waste pipe and/or dra inage hose.
ʑNo water can be seen in the
drum.
 Not a fault. Water r emains inside below the visible area.
ʑSpin result not satisfactory.
Laundry wet/too damp.
 Not a fault. Spin control system has stopped the sp inc ycle.U nevend istribution of
laundry.
Distribute large and small items of laundry evenly in the drum.
Reduced Ironing Sselected? apage 5.
 Selected speed too low? apage 5.
ʑProgramme duration changes
suddenly during operation.
 Not a fault. The program timecan vary according to the distribution of laundry, w ith
it therefore being possible for the di splay panel to show adjustments in the
duration.
ʑSpin cycle performed several
times.
 Not a fault. The balance con trol system has detected an imbalance and is
attempting to redress this by repeating the spin.
ʑResidual water in the
compartment for care products.
 Not a fault: the action of th e care product is not affected.
 Clean the compartment if necessary apage 9.
ʑOdour formation in th e washing
machine.
 Run programme Cottons LF90 °C without laundry. Use standard detergent.
ʑStatus display 1flashing.
Appliance has detected a
detergent overload.
 Too much detergent used?
If foam is escaping from the detergent drawer: mix 1 tablespoon of fabric softener
with ½ litre of water and pour into compartment II (not with outdoor or down
fabrics).
 Reduce the detergent dosage for the next wash cycle.
ʑIntense noise formation,
vibrations and "wandering"
during the spin cycle.
 Are the appliance feet fixed?
Secure the appliance feet aInstalla tion instructions.
 Transportation safety devices r emoved?
Remove transportation safety devices aInstallation instructions.
ʑDisplay panel/indicator lamps
remain turned off while the
machine is working.
 Energy-saving mode apage 5.
 Power cut?
 Fuses triggered? Reset/change th e fuse.
 If the fault occurs repeatedly, ca ll customer services.
ʑProgramme sequence longer
than usual.
 Not a fault. Unbalanced load detection system adjusts imbalance b y repeatedly
distributing the laundry.
 Not a fault: foam detection s ystem active; adds an additional rinse cycle.
ʑDetergent residues on t he
laundry.
 Occasionally, phosphate-free deterg ents contain water-insoluble residues.
 Select Rinse / Spin or brush out the laundry after washing.
If you cannot correct a fa ult yourself or if a repair is necessary:
 Turn the programme selector to Off and remove the mains plu g from the socket.
 Turn off the water supply and c all customer services aInstallation instructions.
Washing machine
en Instruction manu al

1 2
7- 90 °C V(temp. ºC) Select the temperature (7= co
1 - 24 h (Ready in) End of programme after ...
- 1400* (rpm) Select the spin speed (* depend claundry soaks in the last rinsing
Status displays Programme sequence displays
1üü2üücü-¯-Wash, rinse, spin, programme d
(Childproof lock apage 5
,Open the washing machine doo a$¯a$=>$$a$§,ǯ$Correct installation according to the separate
installations actions.
Checking the machine
 Never use a damaged machine!
 Contact customer service!
Connecting the mains plug
Make sure your hands are dry!
Handle the plug only!
Turning on the tap
Compartment II: detergent for the main wash, water softener,
bleach, stain remover
aa
Clo
Your washing machine
Congratulations on having opted for a modern, high-quality domestic appliance
manufactured by Bosch. This washing machine is distinguished by its economical
energy consumption.
Each machine that leaves our factory has been inspected thoroughly to ensure that it
functions properly and is in perfect condition.
For further information on our products, accessories, spares and services, consult our
website www.bosch-home.com or contact any of our customer service centres.
You can find the contact details for your nearest after-sales service here or in the after-
sales service directory (depending on model).
GB 0844 8928979 (calls from a BT landline will be charged at up to 3 pence
per minute. A call set-up fee of up to 6 pence may apply)
IE 01450 2655
Environmentally friendly waste disposal All packaging must be disposed of in accordance with environmental guidelines.
This appliance is certified in accordance with European Directive 2002/96/CE on the
waste electrical and electronic equipment (WEEE).
This directive provides the framework for the EU-wide collection and reuse of used
appliances.
Intended use
Contents Page
ʋIntended use .......................................................................................1
ʋProgrammes ........................................................................................1
ʋSetting and adjusting the programme ...........................................3
ʋWashing ...........................................................................................3/4
ʋAfter washing ......................................................................................4
ʋIndividual settings ..........................................................................5/6
ʋImportant information ....................................................................... 6
ʋOverview of programmes ................................................................7
ʋSafety instructions ............................................................................. 8
ʋConsumption values .........................................................................8
ʋCare and cleaning .............................................................................9
ʋInformation on the display panel ....................................................9
ʋMaintenance .................................................................................... 10
ʋWhat to do if ... ................................................................................ 11
Protection of the environment/Conservation tips
 Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
 Wash normally soiled laundry without a pre-wash.
 Instead of Cottons LF90 °C, choose the programme
Cottons LF60 °C with the additional function EcoPerfect ć.
Comparable cleaning result was significantly lower energy
consumption.
 Measure the detergent according to the manufacturer's
instructions and water hardness.
 If the laundry is then dried in the tumble dryer, select spin speed
according to instructions of dryer manufacturer.
Preparation a
Display panel /
option buttons
Programme s
Programmes
Detailed overview of programmes apage 7.
Temperature and spin speed can be selected individually,
irrespective of the selected programme and programme
progress.
Cottons LFhard-wearing fabrics
+ Prewash 7hard-wearing fabrics, prewash
Easy-Care Isynthetic fabrics
+ Prewash 7synthetic fabrics, prewash
Mixed Load /Different types of laundry
Delicate/Silk Delicate washable fabrics
ÿWool Hand/machine washable wool
Rinse / Spin Laundry washed by hand, Aqua Plus =button acti-
vated; if only using the spin cycle, deactivate the but-
ton
Drain >Drain rinsing water with c(without final spin)
Gentle Spin Laundry washed by hand with a reduced spin speed
Super Quick 15 6Short programme
Dark Wash Dark laundry
Super delicate +Lingery programme
Sportswear $microfibre fabrics
Allergy+ āhard-wearing fabrics (aa$>$a
Compartment ~: Fabric softener, bleach
Compartment I: Detergent for prewash
ʋfor domestic use only,
ʋfor washing machine-washable fabrics and
hand-washable wool in detergent solution,
ʋto be operated with cold or cold and hot (max. 60 ºC)
drinking water, depending on model, and commercially
available detergents and care products which are suita-
ble for use in washing machines.
.
 Follow the safety instructions on page 8!
 Do not leave children unattended near the
washing machine.
 The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
 Keep pets away from the washing machine.
ʑʑVʑ$ʑʑaiaćS=ʑ($(((ʑ§o,$§,ǯ§,§,ǯ$ʑ$ʑ$
z
ʑiLF$$$~a7
ÂÂ
jj
Additional
functions ~1 2
Insert for liquid detergent (depending on model) apage 6
Do not switch on the washing machine until you have read these
instructions and the separate Installation instructions!

3 4
7V7= cold)
epending on the model) or c(without final spin,
t rinsing water, display panel - - - )
isplays:
1üü2üücü¯mme duration or end (-0-)
(a,ine door, reload laundry apages 4, 5
End of programme when ...
... $Start/Reload flashes and -¯-appears on the display panel.
Note: If display panel lighting is switched off, press any button aEnergy
saving mode, page 5.
Interrupting the programme
Programmes at high temperatures:
 Cool washing: Select Rinse /Spin .
 Press $Start/Reload.
Programmes at lower temperatures:
 Select Rinse /Spin (deactivate Aqua Plus =button) or
Drain >.
 Press $Start/Reload.
Changing the programme if ...
... you have selected the wrong programme by mistake:
 Reselect the programme.
 Press $Start/Reload. The new programme starts from the beginning.
Reloading laundry if ... apage 5
... Press $Start/Reload;both the symbols §+,are displayed on
the display panel. If ǯis lit, the washing machine door cannot be opened.
Press $Start/Reload.
Sorting and loading laundry
Follow the manufacturer's care information!
Sort laundry according to the label's indications.
And according to type, colour, soiling and temperature.
Do not exceed the maximum load aPage 7.
Observe important information! aPage 6
Wash laundry of different sizes in the same wash programme.
Close the door. Take care not to trap items of laundry between the washing machine door and
seal.
Add detergent and care products
Measure detergent according:
amount of laundry, soiling, water hardness (ask your water supply company) and
manufacturer's instructions.
For models without insert for liquid detergent:
Pour liquid detergent into the appropriate dispenser and place in the drum.
ʋʋʋʋʋʋʋʋʋʋʋʋʋʋLFLFćBefore the first wash,
run a wash cycle with no laundry in the machine aPage 9.
Setting** and adjusting programmes
amme selector Start /
Reload
Programme selector for
switching the machine on
and off and for selecting the
programme. Can be turned
in either direction.
aLF7I7/ÿ=>c6$ā**If the (symbol flashes in the
display panel, the childproof lock is
active aDeactivate childproof lock,
page 5.
Additional functions and option
buttons aIndividual settings,
page 5.
Press $Start/Reload
Washing
1
2
Removing the washing
Open the washing machine door and remove the washing.
If (without final spin) is active: turn the programme selector to Drain >or select the spin speed.
Choose $Start/Reload.
 Remove any foreign objects. Risk of rusting.
 Leave the washing machine door and detergent door open
so that any residual water can evaporate.
Turn the tap off
Not required for Aqua-Stop models aRefer to Installation instructions.
Switching off
Turn the programme selector to Off.
Washing
~ʋʋʋ
Dilute viscous fabric softener and fabric conditioner with water.
This prevents blockages.
ʑʑVʑ$ʑʑaiaćS=ʑ($(((ʑ§o,$§,ǯ§,§,ǯ$ʑ$ʑ$
z
ʑiLF$$$~a7
ÂÂ
jj
All buttons are sensitive and need
only to be touched lightly. Press and
hold the (Ready in) option button
for an automatic run through all
setting options.
3
Detergent drawer with
compartments I,II,~Door
Drum
Control panel
Service door
3 4
a

56
7V7c1üü2üücü¯(a,a$¯argy
$=>$$ing.
a$§,on
ǯed.
$aa
ʋʋʋʋʋʋʋʋʋʋʋʋʋʋLFLFćaaLF7I7/ÿ=>c6$ā(aa$>$a
~ʋʋʋIndividual settings
ʑOption buttons
You can change the spin speed and the temperature before the selected programme starts and while it is running. The
effects depend on the programme progress.
ʑV(Temperature °C)
You can change the displayed washing temperature. The maximum selectable temperature depends on the current
programme.
ʑ(Ready in)
When you select the programme, the relevant programme duration is displayed. You can delay the end of the
programme before it begins. The ready in-time can be set in increments of one hour up to a maximum of 24 hours.
Press the (Ready in) button until the required number of hours is displayed (h = hour). Choose $Start/Reload.
ʑ(spin speed in rpm/ (without final spin))
You can change the displayed spin speed. The maximum selectable spin speed depends on the model and which
programme is currently selected.
ʑAdditional functions aOverview of programmes, page 7
SpeedPerfect iFor washing in a shorter time with a washing outcome comparable to that of the
standard programme. Maximum load aOverview of programmes, page 7.
EcoPerfect ćFor saving energy with a washing performance comparable to that of the standard
programme.
Reduced Ironing SSpecial spin sequence with subsequent fluffing. Gentle final spin: residual moisture in
the laundry slightly increased.
Aqua Plus =Increased water level and additional rinse cycle, extended washing time. For areas
with very soft water or for further enhancing the spin result.
ʑChildproof lock
(in the display panel You can lock the washing machine to prevent the functions you have set from being
changed inadvertently.
ON/OFF: after the start/end of the programme, press and hold $Start/Reload for
approx. 5 seconds.
Note: The childlock can remain activated until you wish to start the next programme,
even after switching off the machine.
Then you can deactivate the childlock before starting the programme and activate it
again as necessary once the programme has started.
Note:
The (symbolis lit: Childlock active.
The (symbolflashes: Childlock active and then the programme selector is altered.
To prevent the programme from stopping, move the programme selector back to
the original programme, the (symbol is lit again.
ʑReloading
§+o,in the display panel Press $Start/Reload if you want to add additional items of laundry after the
programme has started. The machine checks whether reloading is possible.
§+,are lit: reloading is possible.
ǯflashes: wait until §+,are lit.
Note: do not open the door until both the §+,symbols are lit.
ǯ: it is not possible to reload.
Note: for safety reasons, the washing machine door remains locked when the water
level and/or temperature is high, or during spinning.
To continue the programme, press the $Start/Reload button.
ʑEnergy saving mode
The display panel lighting goes out after a few minutes, $Start/Reload flashes. Press any button to switch on the
lighting.
ʑ$Start/Reload
To start the programme or to subsequently load additional laundry, and to activate/deactivate the childproof lock.
Individual settings z
ʑSignal
Important information
Protecting the laundry and the machine
 When determining the dosage of all washing powders, additives and cleaning agents, you must follow the
manufacturer's instructions..
 Empty all pockets
 Check for metal items (paper-clips, etc.).
 Wash delicates in a laundry bag (tights, curtains, underwired bras).
 Fasten zips, do up any buttons.
 Brush sand out of pockets and collars.
 Remove curtain fittings or place in the laundry bag.
Laundry with varying degrees of soiling
Wash new items of clothing separately.
light Do not prewash. If required, choose the additional function SpeedPerfect.iPre-treat any stains as necessary.
intense wash Load less laundry. Choose a programme with a prewash.
Soaking Load laundry of the same colour.
Pour soaking agent/detergent into compartment II in accordance with the manufacturer's instructions. Turn the
programme selector to Cottons LF30 °C and press $Start/Reload. After approx. 10 minutes, press $Start/
Reload to pause the programme. Once the required soaking time has elapsed, press $Start/Reload again to
continue the programme, or select a different programme.
Starch Laundry should not be treated with fabric softener.
Starching is possible in all wash programmes if liquid starch is used. Pour the starch in accordance with the
manufacturer's instructions into fabric softener compartment ~(rinse first if necessary).
Dyeing / Bleaching
Dye should only be used in normal household quantities. Salt may damage stainless steel. Always follow the dye
manufacturer's instructions. Do not use the washing machine for bleaching clothes.
Insert for liquid detergent depending on model
Position the insert for dispensing liquid detergent:
 Remove the detergent drawer completely apage 9
 Slide the insert forwards and click into place.
Do not use the insert (slide upwards): for gel detergents and washing powder,
for programmes with + Prewash 7and end time option.
Set to Â1 step, the
display panel
lights up
press and
hold +1 step, release
set to Âsetting the
volume*
setting the
volume*
1 step
* if necessary, select the
function several times
1. Activating the mode
for setting the signal
volume
2. Setting the volume
for...
direct
Button signals Information signals jj
~56
a

7
Overview of programmes aRefer to the table of consumption values on page 8, and advice and warnings on page 6.
Programmes °C max. Type of laundry Additional functions; Information
Cottons LF7- 90 °C
8 kg/ 4 kg*
hard-wearing fabrics, cottons or linen that can be washed at 90°C SpeedPerfect i*, EcoPerfect ć,Reduced Ironing S,Aqua Plus =+ Prewash 7Allergy+ ā7- 60 °C colour fast cottons or linen
SpeedPerfect i*, EcoPerfect ć,Reduced Ironing S,Aqua Plus =; for particularly sensitive skin; longer wash programme at selected tem- perature, higher water level, additional rinse cycle
Easy-Care I7- 60 °C
3.5 kg
easy-care cotton, linen, synthetic or blended fabrics SpeedPerfect i,EcoPerfect ć,Reduced Ironing S,Aqua Plus =+ Prewash 7Mixed Load /7- 40 °C cotton or synthetic fabrics SpeedPerfect i,EcoPerfect ć,Reduced Ironing S,Aqua Plus =;
different types of laundry can be washed together
Dark Wash 7- 40 °C dark cotton and dark synthetic fabrics SpeedPerfect i,EcoPerfect ć,Reduced Ironing S,Aqua Plus =;
reduced rinse and final spin cycle
Delicate/Silk 7- 40 °C
2 kg
for delicate fabrics, e.g., silk, satin, synthetic fibres or blended fabrics (e.g. curtains)
SpeedPerfect i,EcoPerfect ć,Reduced Ironing S,Aqua Plus =:
no spin between rinse cycles
ÿWool 7- 40 °C hand/machine washable wool particularly delicate wash programme to avoid shrinkage of laundry;
longer programme breaks (fabrics rest in the detergent solution)
Super Quick 15 67- 40 °C synthetic cotton, linen, synthetic fibres or blended fab-
rics
Short programme of approx. 15 minutes, suitable for lightly soiled laundry
Sportswear $7- 40 °C microfibre fabrics SpeedPerfect i,EcoPerfect ć,Reduced Ironing S,Aqua Plus =Super delicate +7- 40 °C 1 kg lingery SpeedPerfect i,EcoPerfect ć,Reduced Ironing S,Aqua Plus =Additional programmes Rinse / Spin , Drain >, Gentle Spin *reduced load with additional function SpeedPerfect i.
For programmes without prewash, add detergent to compartment II. For prewash programmes, distribute the detergent between compartments Iand II.
9201 / 9000737235
9000737235 WAQ28461GB /...
Robert Bosch Hausgeräte GmbH
CarläWery Str. 34
81739 Munich / Germany
8
Safety instructions
 Carefully read the instruction manual and the information enclosed, and act accordingly.
 Keep the machine's documentation for future reference.
Risk of electric shock!  Never pull the cable to disconnect the mains plug!
 Never insert/disconnect the mains plug with damp hands.
Danger to life! For worn-out appliances:
 Disconnect the mains plug.
 Sever the mains cable and discard along with the plug.
 Destroy the lock on the washing machine door. This will prevent children from
locking themselves in and risking their lives.
Danger of suffocation!  Keep packaging, film and packaging parts out of the reach of children.
Risk of poisoning!  Keep detergents and care products out of the reach of children.
Risk of explosion!  Items of laundry pretreated with cleaning agents containing solvents, e.g. stain
remover/cleaning solvent may lead to an explosion after being loaded into the
washing machine.
Rinse items of laundry thoroughly by hand beforehand.
Risk of injury!  The washing machine door may become very hot.
 Be careful when draining hot detergent solution.
 Do not climb onto the washing machine.
 Do not lean on the open washing machine door.
 Do not reach into the drum if it is still rotating.
 Be careful when opening the detergent drawer while the machine is in operation.
Consumption values depending on model
Programme Load Electricity*** Water*** Programme
duration***
Cottons 30 °C* 8 kg 0.40 kWh 68 l 145 min
Cottons 40 °C* 8 kg 1.05 kWh 68 l 155 min
Cottons60 °C* 8 kg 1.15 kWh 68 l 165 min
Cottons 90 °C 8 kg 2.30 kWh 80 l 155 min
Easy-Care 40 °C* 3.5 kg 0.64 kWh 55 l 103 min
Mixed Load 40 °C 3.5 kg 0.54 kWh 47 l 60 min
Delicate/Silk 30 °C 2 kg 0.19 kWh 34 l 41 min
Wool 30 °C* 2 kg 0.17 kWh 39 l 40 min
* Programme setting for testing in accordance with valid standard EN60456.
Note on comparative tests: For testing the test programmes, wash the specified load using the maximum spin speed.
Programme Additional
function Load Annual energy consumption
Annual water
consumption
Cottons40/60 °C EcoPerfect ć** 8/4 kg 179 kWh 8700 l
** Programme setting for testing and energy labelling in accordance with EU directive 2010/30/EU with cold water (15 ºC).
*** The values deviate from the indicated values depending on water pressure, hardness, and inlet temperature, ambient tem-
perature, type, amount and soiling of the laundry, detergent used, fluctuations in the power supply and selected additional
functions.
I$aa,§³Å§Éa§³µaaa1§´©³¯a(a
>>$ʑʑ$aʑaaaʑ$aʑaaʑʑSaaʑʑʑaʑLFʑ1ʑaaʑaʑʑa

aLF7ićS=7ā7ićS=I7ićS=7/7ićS=7ićS=7ićS=ÿ767$7ićS=7ićS=>iä
ć
9
Care and cleaning
Before the first wash
Do not put laundry in the machine! Turn on the tap. Put into compartment II:
 approx. 2 litres of water
 detergent (measure according to the manufacturer's instructions for lightly soiled laundry and water hardness)
Turn the programme selector to Easy-Care I60 °C and press $Start/Reload. At the end of the programme, turn the
programme selector to Off.
Machine housing, control panel
 Remove detergent and cleaning agent residue.
 Wipe with a soft, damp cloth.
 Do not wash the machine with a jet of water!
Cleaning the detergent drawer ...
... if it contains detergent or fabric softener residues.
1. Pull out, press insert down and remove drawer completely.
2. To remove the insert: press upwards from below with your finger.
3. For models with insert for liquid detergent:Slide the insert upwards and remove it from the back.
4. Clean the detergent dispenser tray and inserts with water and a brush and dry them.
5. Attach the insert and engage (connect the cylinder to the guide pin).
6. Push in the detergent drawer.
Leave the detergent drawer open so that any residual water can evaporate.
Drum
Leave the washing machine door open so that the drum can dry out.
For rust stains, use chlorine-free cleaning agent, not steel wool.
Descaling Ensure there is no laundry in the machine!
This will not be necessary if the correct dosage of detergent is used. If it is, descale the appliance according to the
manufacturer's instructions. Descaling products can be acquired on the website or from customer services aInstallation
instructions.
Emergency release e.g. in the event of a power cut
The programme continues to run when the power has been restored. However, if the laundry has to be removed, the
washing machine door can be opened as follows:
Risk of scalding!
The detergent solution and laundry may be hot. Let it cool.
Do not reach into the drum if it is still rotating.
Do not open the washing machine door if water can be seen through the glass.
1. Turn the programme selector to Off and disconnect the mains plug.
2. Drain the detergent solution apage 10.
3. Pull the emergency release downwards with a tool and release.
The washing machine door can then be opened.
Information on the display panel depending on model
,flashes Close the washing machine door properly; laundry may be caught.
§:³Å,
§:ÉTurn on the (cold water) tap fully, supply hose kinked or trapped; Clean the filter apage 10, water pressure too low.
§:³µ Detergent solution pump blocked; Clean the detergent solution pump apage 10.
 Drainage hose / waste pipe blocked; Clean the drainage hose at the siphon apage 10.
 Heavy foam build-up apage 11, status indicator 1flashes.
§:´Water in the base tub, appliance leaking. Call customer services!
©:³¯ Open the (hot water) tap fully.
 Inlet hose kinked/trapped.
 Water pressure too low. Clean the filter apage 10.
 Hot water hose not connected; appliance will operate using cold water only. Ignore information, only for first
wash cycle.
(Childproof lock activated: to deactivate apage 5.
Risk of electric shock! Disconnect the mains plug.
Risk of explosion! Do not use solvents.
9
10
Maintenance
Detergent solution pump
Turn the programme selector to Off and disconnect the mains plug.
1. Using a screwdriver or the insert for liquid detergent
(depending on model), open and remove the service flap.
2. Remove the folding gutter and place a large enough container underneath.
3. For models with a drainage hose: Remove the drainage hose from the retainer and pull it
from the housing.
Remove the sealing cap, allow the detergent solution to flow out into the container. Replace
the sealing cap and place the drainage hose in the retainer.
3* For models without a drainage hose: Carefully unscrew the pump cover 180° or until the
detergent solution begins to flow out on the folding gutter. When the container is full, close
the pump cover and empty the container. Repeat the above steps until all the detergent
solution has completely drained out.
4. Carefully unscrew the pump cover (there may be residual water).
5. Clean the interior, pump cover thread and pump housing (the impeller in the detergent
solution pump must rotate).
6. Replace the pump cover and screw it tightly.
7. Return the drainage hose (depending on model) and the folding gutter to their start position.
8. Place the service flap back on and close.
To prevent unused detergent from flowing straight into the drain during the next wash:
Pour 2 litres of water into compartment II and then start theDrain >programme.
Drainage hose at the siphon
Turn the programme selector to Off and disconnect the mains plug.
1. Loosen the hose clamp, carefully remove the drainage hose (residual water).
2. Clean the drainage hose and siphon connecting piece.
3. Reattach the drainage hose and secure the connection with the hose clamp.
Filter in the water supply
Risk of electric shock!
Do not immerse the Aqua-Stop safety device in water (contains an electric valve).
Reduce the water pressure in the supply hose:
1. Turn off the tap.
2. Select any programme (except Rinse / Spin // Drain >).
3. Choose $Start/Reload. Let the programme run for approximately 40 seconds.
4. Turn the programme selector to Off. Disconnect the mains plug.
Clean the filter:
5. Disconnect the hose from the tap.
Clean the filter using a small brush.
and/or for Standard and Aqua-Secure models:
Remove the hose on the rear of the appliance.
Remove the filter with pliers and clean.
6. Connect the hose and check for leaks.
Risk of burning!
Allow the detergent solution to cool.
 Turn off the tap.
ʑʑ$aʑaaaʑ$aʑaaʑʑSaaʑʑʑaʑLFʑ1ʑaaʑaʑʑa

aLF7ićS=7ā7ićS=I7ićS=7/7ićS=7ićS=7ićS=ÿ767$7ićS=7ićS=>iä
ćI$aa,§³Å§Éa§³µaaa1§´©³¯a(a>>$
11
What to do if...
ʑWater is leaking out  Attach/replace the drainage hose correctly.
 Tighten the screw connection of the supply hose.
ʑNo water supply.
Detergent not dispensed.
$Start/Reload not selected?
 Tap not turned on?
 Filter blocked? Clean the filter apage 10.
 Supply hose kinked or trapped?
ʑThe appliance door will not
open.
 Safety function active. Programme stopped? apage 4.
(without final spin) selected? apage 3, 4.
 Can be opened by emergency release only? apage 9.
 Door locked after the washing machine is switched off: Switch on the washing
machine and wait for 5 seconds.
ʑThe selected programme does
not start.
$Start/Reload or (Ready in) time selected?
 Washing machine door closed?
 Childproof lock active? Deactivate apage 5.
ʑDetergent solution is not
drained.
(without final spin) selected? apage 3, 4.
 Clean the detergent solution pump apage 10.
 Clean the waste pipe and/or drainage hose.
ʑNo water can be seen in the
drum.
 Not a fault. Water remains inside below the visible area.
ʑSpin result not satisfactory.
Laundry wet/too damp.
 Not a fault. Spin control system has stopped the spin cycle. Uneven distribution of
laundry.
Distribute large and small items of laundry evenly in the drum.
Reduced Ironing Sselected? apage 5.
 Selected speed too low? apage 5.
ʑProgramme duration changes
suddenly during operation.
 Not a fault. The program time can vary according to the distribution of laundry, with
it therefore being possible for the display panel to show adjustments in the
duration.
ʑSpin cycle performed several
times.
 Not a fault. The balance control system has detected an imbalance and is
attempting to redress this by repeating the spin.
ʑResidual water in the
compartment for care products.
 Not a fault: the action of the care product is not affected.
 Clean the compartment if necessary apage 9.
ʑOdour formation in the washing
machine.
 Run programme Cottons LF90 °C without laundry. Use standard detergent.
ʑStatus display 1flashing.
Appliance has detected a
detergent overload.
 Too much detergent used?
If foam is escaping from the detergent drawer: mix 1 tablespoon of fabric softener
with ½ litre of water and pour into compartment II (not with outdoor or down
fabrics).
 Reduce the detergent dosage for the next wash cycle.
ʑIntense noise formation,
vibrations and "wandering"
during the spin cycle.
 Are the appliance feet fixed?
Secure the appliance feet aInstallation instructions.
 Transportation safety devices removed?
Remove transportation safety devices aInstallation instructions.
ʑDisplay panel/indicator lamps
remain turned off while the
machine is working.
 Energy-saving mode apage 5.
 Power cut?
 Fuses triggered? Reset/change the fuse.
 If the fault occurs repeatedly, call customer services.
ʑProgramme sequence longer
than usual.
 Not a fault. Unbalanced load detection system adjusts imbalance by repeatedly
distributing the laundry.
 Not a fault: foam detection system active; adds an additional rinse cycle.
ʑDetergent residues on the
laundry.
 Occasionally, phosphate-free detergents contain water-insoluble residues.
 Select Rinse / Spin or brush out the laundry after washing.
If you cannot correct a fault yourself or if a repair is necessary:
 Turn the programme selector to Off and remove the mains plug from the socket.
 Turn off the water supply and call customer services aInstallation instructions.
Washing machine
en Instruction manual
