QUICK START
GUIDE
LED COLOR AIRBORNE DEVICE STATE
POWER
Off Adapter is not powered.
Red Adapter failed Power On Self Test (“POST”).
Amber Adapter passed POST but is not congured for wireless network
communication.
Green Adapter passed POST and is congured for wireless communication.
LINK
Off Adapter is not powered.
Red / Off (Periodic Blinking) Adapter is searching for a valid network (Access
Point) that matches device’s conguration.
Green Adapter has successfully associated with an Access Point.
COMM
Off
If Power LED is also Off, then Adapter is not powered.
If Power LED is On, then either:
• A physical connection detected on Serial/Ethernet cable.
• No TCP session from wireless interface has been established.
Red No physical Ethernet connection has been detected.
Red / Off
(Blinking – OFF/Red) A physical Ethernet connection has been
detected and there is trafc across the interface. No TCP connection
to the adapter has been established on the wireless interface.
D oc um en t N um be r: 71 0 -11219 - 0 0 _ R 0 _ A BD N - ER - DP 551 x _1117q s g
More AirborneM2M Products
Embedded Dual-band M2M
Access Point Module
# APMN-Q551 Before you begin, be
sure you have the following:
ABDN-ER-DP551 &
ABDN-ER-DP551U
Wireless Ethernet Adapter
+ ABDN-ER-DP551 or ABDN-ER-DP551U
+ (ABDN-ER-DP551) 5 VDC power supply,
with 2.1 mm barrel jack
OR
(ABDN-ER-DP551U) Dual (Y) USB power cable,
with 2.1 mm barrel jack
+ 50 Ohm, omni-directional antenna
+ CD with Airborne Management Center Software
If your device is connected and congured correctly, you
will see the following LED Status:
POWER: Green
LINK: Green
COMM: Red / Flashing Red
(Continued)
Check Your Setup
7
802.11 Wireless Bridge,
Router & Serial Server
# ABDN-ER-IN5010
Troubleshooting
8

Product Overview
Attach the Antenna
1
Connect the Antenna to the antenna connector located on
the side of the device.
Connect Ethernet
2
Connect the Ethernet cable to an Ethernet port on a host
computer or network router/switch.
Connect Power Supply
3
(ABDN-ER-DP551) Connect the power supply to an AC
power outlet. Plug the barrel connector from the AC power
supply into the ABDN-ER-DP551’s power port.
(ABDN-ER-DP551U) Plug the Dual (Y) USB cable’s two USB
connectors into two USB ports. Plug the Dual (Y) USB cable’s
barrel connector into the ABDN-ER-DP551U’s power port.
Connect To The Device
4
Run the Airborne Management Center (AMC) application.
If you don’t currently have AMC installed, you can install
it from the included CD or download and install it from
the B+B SmartWorx website. Just search for the model
number and follow the links to download software from the
Downloads section of the product page.
Note: You may be required to wait up to 180 seconds before
the device is discovered and displayed.
When AMC starts, it will request a login:
Select Group Name: “manuf” and enter Group Password:
“dpac”
AMC will load and discover the attached device:
Manage The Device
5
AMC will ask if you want to manage the new device,
select ‘Yes’:
Select ‘Yes’ to indicate device is using Factory Default
settings:
AMC will display the found Airborne device(s):
Right click the device’s name. Under “Connectivity Tools”
choose “launch Web browser for OEM-Cfg1.” This will
open the device’s browser-based management window.
Login to web interface:
Username “dpac”
Password: “dpac”
Continue conguration via the Web interface. Start with
the Conguration -> Express Setup page.
(Continued)
Congure Your Device
6
Note: Use the Help features of the interface to help you
congure the device. When you are done conguring the
device, press ‘Commit’ to save the changes, then ‘Restart’ to
restart the device. You can optionally press ‘Reload’ if you have
further conguration changes to make.
Tip: To easily convert a Direct Ethernet device to a bridge, use
the Bridge Templates in AMC. For additional information, search
the B&B Knowledge base for “bridge templates”.
LAN
Cable
Power
Port
Antenna
LEDs
