Breville BMO734XL User manual

BMO734XL
the Quick Touch™
Instruction Booklet - Livret d’instructions
BMO734XL_IB_B13.indd 2 8/11/2013 1:32 pm

CONGRATULATIONS
on the purchase of your Breville product
*Registering is not a substitute for proof of purchase when submitting a Warranty Claim.
USA Consumers: www.brevilleusa.com
Canadian Consumers: www.breville.ca
Register online for product support
and exclusive offers.*
BMO734XL_IB_B13.indd 2 8/11/2013 1:32 pm

3
CONTENTS
4Breville recommends safety first
13 Know your Breville product
15 Assembling your Breville product
17 Operating your Breville product
– Smart Cook setting 24
– Smart Reheat setting 32
– Smart Defrost setting 36
– A Bit More™ 39
– Shortcuts Panel 41
49 Hints & Tips
52 Care & Cleaning
54 Troubleshooting
56 French
BMO734XL_IB_B13.indd 3 8/11/2013 1:32 pm

4
BREVILLE RECOMMENDS SAFETY FIRST
At Breville we are very safety conscious. We design and manufacture consumer
products with the safety of you, our valued customer, foremost in mind. In addition
we ask that you exercise a degree of care when using any electrical appliance and
adhere to the following precautions.
When using electrical appliances basic
safety precautions shall be followed,
including the following:
WARNING
To reduce the risk of burns, electric
shock, fire injury to persons, or exposure
to excessive microwave energy:
READ ALL INSTRUCTIONS
BEFORE USE AND SAVE FOR
FUTURE REFERENCE
• Remove and safely discard
any packaging material and
promotional labels before using the
Breville microwave oven for the
first time.
• Read and follow the specific
“PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY” found on page 9.
• This appliance must be grounded.
Connect only to properly grounded
outlet. See “Grounding Instructions"
found on page 11.
• Install and locate this appliance
only in accordance with the
supplied installation instructions
on page 16.
• Some products such as whole
eggs and sealed containers – for
example, closed glass jars – have
the potential to explode and shall
not be heated in this oven.
• Use this appliance only for its
intended use as described in the
manual. Do not use corrosive
chemicals or vapors in this
appliance. This type of oven is
specifically designed to heat, cook,
or dry food. It is not designed for
industrial or laboratory use.
• As with any appliance, close
supervision is required when used
by children.
• Do not operate this appliance
when it has a damaged cord
or plug, when it is not working
properly, or when it has been
damaged or dropped.
• This appliance shall be serviced
only by qualified personnel.
Contact nearest authorized service
facility for examination, repair,
or adjustment.
• Do not cover or block any
openings on the appliance.
• Do not store this appliance
outdoors.
IMPORTANT SAFETY INSTRUCTION
BMO734XL_IB_B13.indd 4 8/11/2013 1:32 pm

5
BREVILLE RECOMMENDS SAFETY FIRST
• Do not use this product near water-
for example, near a kitchen sink,
in a wet basement, or near a
swimming pool, and similar areas.
• Do not immerse power cord, power
plug, or appliance in water or any
other liquid.
• Keep cord away from heated
surfaces.
• Do not let cord hang over edge of
table or counter, touch hot surfaces
or become knotted.
• When cleaning surfaces of door
and oven that come together on
closing the door, use only mild,
nonabrasive soaps, or detergents
applied with a sponge or soft cloth.
The use of corrosive chemicals in
cleaning will damage the appliance
and may result in radiation leaks.
• To reduce the risk of fire in the
oven CAVITY:
i) Do not overcook food.
Carefully attend appliance
when paper, plastic, or other
combustible materials are
placed inside the oven to
facilitate cooking.
ii) Remove wire twist-ties from
paper or plastic bags before
placing bag in oven.
iii) In the event materials inside
the oven ignite, keep oven
door closed, turn oven off, and
disconnect the power cord, or
shut off power at the fuse or
circuit breaker panel.
iv) Do not use the CAVITY for
storage purpose. Do not leave
paper products, cooking
utensils, or food in the CAVITY
when not in use.
• To eliminate a choking hazard for
young children, remove and safely
discard the protective cover that
is fitted to the power plug of the
Breville microwave oven.
• Do not place the microwave oven
near the edge of a bench or table
during operation. Ensure all
surfaces are level, clean and free of
water or any other substances.
• Do not place the microwave oven
on or near a hot gas or electric
burner, or where it could touch a
heated oven.
• Ensure the microwave is installed
and operated with adequate
space above and around the
unit as recommended within the
Installation section on page 16.
• Do not build in or enclose
microwave in a cabinet or confined
space as it will cause overheating.
(Refer to Installation section on
page 16)
• Always operate the microwave
oven on a heat-resistant surface.
Do not use on a cloth-covered
surface, near curtains or other
flammable materials.
• Do not use the microwave oven on
a metal surface.
BMO734XL_IB_B13.indd 5 8/11/2013 1:32 pm

6
BREVILLE RECOMMENDS SAFETY FIRST
• Always ensure the microwave
oven is properly assembled before
connecting to the power outlet and
operating. Do not use the oven
without the turntable roller and
glass turntable in place. Ensure
the glass turntable is positioned
correctly into the indents on the
turntable roller.
• The microwave oven is not
intended to be operated by means
of an external timer or separate
remote control system.
• Never use the microwave oven
without food or water in the oven
cavity. Operating the microwave
oven when empty could cause
damage to the appliance.
• Do not leave the microwave oven
unattended when in use.
• Do not touch hot surfaces. Allow
the microwave oven to cool before
moving or cleaning any parts.
• Always ensure the microwave oven
power cord is unplugged from the
power outlet before attempting to
move the appliance, when not in
use, if left unattended and before
disassembling, cleaning or storing.
• Keep the appliance clean. Follow
the cleaning instructions provided
in this book (page 53).
• Always turn the microwave oven
off by pressing the STOP/CLEAR
button and unplug at the power
outlet when it is not in use.
• Before cleaning, always press the
STOP/CLEAR button and unplug
at the power outlet.
• Liquids, such as water, coffee or tea
are able to become heated above
their boiling points without the
appearance of boiling or bubbling.
THIS COULD RESULT IN VERY
HOT LIQUIDS SUDDENLY
BOILING OVER WHEN THE
CONTAINER OR LIQUID
SURFACE IS DISTURBED
OR WHEN A SPOON OR
UTENSIL IS INSERTED INTO
THE LIQUID.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
BMO734XL_IB_B13.indd 6 8/11/2013 1:32 pm

7
BREVILLE RECOMMENDS SAFETY FIRST
IMPORTANT SAFEGUARDS
FOR ALL ELECTRICAL
APPLIANCES
• Fully unwind the power cord
before use.
• It is recommended to regularly
inspect the appliance. To avoid a
hazard do not use the appliance
if power cord, power plug or
appliance becomes damaged
in any way. Immediately cease
use and call Breville Consumer
Support for examination, repair
or adjustment.
• For any maintenance other
than cleaning, contact Breville
Consumer Support.
• This appliance is for household use
only. Do not use this appliance for
anything other than its intended
use. Do not use in moving vehicles
or boatmeal. Do not use outdoors.
Misuse may cause injury.
• A 120 volt, 60 Hz, AC only,
15–20 amp electrical supply with a
fuse or circuit breaker is required in
accordance with all Federal,
State and Local governing codes
and ordinances.
• We also recommend a separate
circuit dedicated to serving only
this microwave oven.
• A short power-supply cord is
supplied to reduce the risks
resulting from becoming
entangled in or tripping over a
longer cord.
• Extension cords may be used when
care is exercised in using them.
• When an extension cord is used:
i) The marked electrical rating of
the extension cord shall be at
least as great as the electrical
rating of the appliance.
ii) The extension cord must be
a grounding type 3-wire cord
and it must be plugged into a
properly grounded outlet.
iii) The longer cord shall be
arranged so that it does not
drape over the counter top or
tabletop where it is capable of
being pulled on by children or
tipped over unintentionally.
BMO734XL_IB_B13.indd 7 8/11/2013 1:32 pm

8
• All suitable glass or plastic food
containers should be used in strict
compliance with the cookware
manufacturer's recommendations.
• Containers or plates suitable for
use in the microwave oven should
not exceed the width of the glass
turntable as this may impede the
rotation of the turntable and result
in food being unevenly cooked or
may burn and catch on fire.
• Food and/or liquids should not be
heated or cooked directly on the
glass turntable. Food and/or liquids
must be placed into a suitable
microwave-proof container before
placing onto the glass turntable.
• Food and/or liquids should not
be heated or cooked in plastic or
paper containers or bags, unless
specified as suitable for use by the
manufacturer, due to the possibility
of containers exploding or igniting.
• Metal clips or twist ties should be
removed from the packaging as
these could cause sparking and/
or fire.
• Do not use recycled paper or paper
towels when cooking. Recycled
paper may contain small metal or
other impurities which could cause
sparking and/or fire.
BREVILLE RECOMMENDS SAFETY FIRST
SPECIAL SAFETY
INSTRUCTIONS FOR YOUR
MICROWAVE OVEN
• Wipe the oven cavity with a soft,
damp cloth after each use. Leaving
food residue, grease or fat in the
cavity could cause the microwave
oven cavity to overheat and may
cause the microwave oven to
smoke or catch fire.
• The microwave oven should be
cleaned regularly and any food
splattering inside the cavity
should be removed. Failure to
maintain the microwave oven
in a clean condition could lead
to deterioration of the surface,
adversely affecting the life of the
microwave oven and possibly
resulting in a hazardous situation.
• The microwave oven is intended
for heating food and beverages.
Drying of food or clothing and
heating or warming pads, slippers,
sponges, damp cloth and similar
may lead to risk of injury, ignition
or fire.
• Ensure all food containers and/
or plates are suitable for use in
the microwave oven. This should
be done prior to preparing food
for heating or cooking in the
microwave oven.
BMO734XL_IB_B13.indd 8 8/11/2013 1:32 pm

9
BREVILLE RECOMMENDS SAFETY FIRST
• Do not use metal containers or
utensils in the microwave oven as
these could cause sparking and/
or fire.
• Food grade foil should not be used
in the microwave oven as this
could cause sparking and/or fire.
• Ensure that lids and caps covering
containers are removed prior to
placing liquids and/or foods into
the microwave oven.
• Feeding bottles and baby food jars
should have lids and caps removed
before warming or heating in the
microwave oven. To avoid burns or
scalding after heating, the contents
should be stirred or shaken and
the temperature checked
before serving.
• Always ensure the temperature
of food or drink which has been
heated or cooked in the microwave
oven has been tested before eating,
drinking or serving.
WARNING
Liquids and other foods must not be
heated in sealed containers since they
are liable to explode.
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY
• Do not attempt to operate this
oven with the door open since
open-door operation can result in
harmful exposure to microwave
energy. It is important not to
defeat or tamper with the safety
interlocks.
• Do not place any object between
the oven front face and the door
or allow soil or cleaner residue to
accumulated on sealing surfaces.
• If the door or door seals are
damaged, the oven must not be
operated. Immediately cease
use and call Breville Consumer
Support for examination, repair
or adjustment. It is particularly
important that the oven door
close properly and that there is
no damage to the: (1) Door (bent),
(2) Hinges and latches (broken
or loosened), (3) Door seals and
sealing surfaces.
• Do not put any foreign material
between the door and door jamb of
the microwave oven.
• The oven should not be adjusted or
repaired by anyone except properly
qualified service personnel.
BMO734XL_IB_B13.indd 9 8/11/2013 1:32 pm

10
SUPERHEATED LIQUIDS
• To reduce this risk of injury
to persons:
i) Do not overheat the liquid.
ii) Stir the liquid both before and
halfway through heating it.
iii) Do not use straight-sided
containers with narrow necks.
iv) After heating, allow the
container to stand in the
microwave oven for a short
time before removing the
container.
v) Use extreme care when
inserting a spoon or other
utensil into the container.
• Do not heat popcorn in the
microwave oven unless it has
been commercially packaged for
microwave use. There may be a
number of un-popped kernels
that may overcook and burn when
popping popcorn. Do not use
oil unless recommended by the
manufacturer. Do not pop popcorn
longer than the manufacturer’s
instructions (popping time should
not exceed 3 minutes). Longer
cooking could cause scorching
or fire.
• Do not cook any food surrounded
by a membrane (such as potatoes,
chicken liver, egg yolks, oysters,
etc) without first piercing the
membrane several times helping to
allow for steam to escape.
• Eggs in the shell and whole hard
boiled eggs should not be cooked
or heated in the microwave oven
as they may explode during
cooking, at the end of cooking or
after removing from the
microwave oven.
• Do not heat oil or fat in the
microwave oven. Doing so may
cause the microwave oven and/or
the oil to overheat and/or ignite.
• If any smoke is observed, switch
off and unplug the microwave oven
at the power outlet. Keep the door
closed to stifle any flames.
• Do not attempt to operate the
microwave oven by any method
other than those described in this
instruction book.
• Utensils should be checked to
ensure that they are suitable for use
in microwave ovens.
• Do not disconnect or tamper with
the power cord or the power supply
outlet while the unit is operating.
BREVILLE RECOMMENDS SAFETY FIRST
BMO734XL_IB_B13.indd 10 8/11/2013 1:32 pm

11
BREVILLE RECOMMENDS SAFETY FIRST
• Loosely wind the cord when
storing the microwave oven.
Do not wrap the cord around
the microwave oven.
• When heating food in plastic or
paper containers, keep an eye on
the microwave oven due to the
possibility of ignition.
• The glass window has been
specially treated to make it
stronger, more durable and safer
than ordinary glass, however it
is not unbreakable. If dropped
or struck hard, it may break or
weaken, and could at a later time
shatter into many small pieces
without apparent cause.
• If you see any sparks, arcing or
flashing within the microwave
oven, press the STOP/CLEAR
button and correct the problem
or contact Breville Consumer
Support for assistance.
GROUNDING INSTRUCTIONS
• This appliance is equipped with
a power cord having a grounding
wire with a grounding plug. The
appliance must be grounded using
a 3-hole properly grounded outlet.
In the event of an electrical short
circuit, grounding reduces the risk
of electric shock.
• Improper use of the grounding
plug can result in risk of
electric shock.
• If the power outlet is a standard
2-prong wall outlet, it is your
personal responsibility and
obligation to have it replaced with
a properly grounded 3-prong
wall outlet.
• Do not, under any circumstances,
cut or remove the third (ground)
prong from the power cord or use
an adapter.
• Consult a qualified electrician if
the grounding instructions are not
completely understood, or if doubt
exists as to whether the appliance
is properly grounded.
• We do not recommend using an
extension cord with this appliance.
NOTE
Do not use an adapter plug with
this appliance.
BMO734XL_IB_B13.indd 11 8/11/2013 1:32 pm

12
BREVILLE RECOMMENDS SAFETY FIRST
SPECIFICATIONS
POWER
SOURCE 120V, 60Hz
POWER
CONSUMPTION 1500W
COOKING
POWER* 1100W
OUTSIDE
DIMENSIONS
(W x D x H)
20.5"x 18"x 12.5"(519mm
x 453mm x 314mm)
Overall
Oven Cavity
Dimensions
(W x D x H)
14"x 15"x 10" (351mm x
386mm x 248mm
NET WEIGHT Approx. 35lbs (16.15kg)
OVEN
CAPACITY 1.2 cu ft (34 Liters)
* IEC Test Procedure
These specifications may change
without notice.
This microwave is compliant with
Part 18 of the FCC regulations.
CALIFORNIA PROPOSITION 65:
(Applicable to California residents only).
This product contains chemicals
known to the State of California to
cause cancer, birth defects or other
reproductive harm.
BMO734XL_IB_B13.indd 12 8/11/2013 1:32 pm

KNOW
your Breville product
BMO734XL_IB_B13.indd 13 8/11/2013 1:32 pm

14
KNOW YOUR BREVILLE PRODUCT
A. VIEWING WINDOW
B. DOOR HANDLE
C. LARGE LCD
D. AMOUNT DIAL
Turn dial to adjust the power level,
weight & quantity that corresponds
with the food type selected.
E. +30 INSTANT START BUTTON &
TIME/FOOD TYPE DIAL
Each press adds 30 second increments
at 100% power. Turn dial to select food type
or time.
A B C
I
E
F
G
H
D
F. SMART COOK, REHEAT &
DEFROST BUTTONS
Allows you to choose from a range of
common food types with predetermined
times and power levels for selected weights.
G. STOP | CLEAR BUTTON
Press once to pause without cancelling the
program. Press twice to clear the display.
H. A BIT MORE™BUTTON & CHILD LOCK
Press once to add A BIT MORE™ time at
the end of the cooking cycle. Press and hold
for 3 seconds to set child lock.
I. SHORTCUTS PANEL
Refer to operation section for
detailed explanation.
BMO734XL_IB_B13.indd 14 8/11/2013 1:32 pm

ASSEMBLING
your Breville product
BMO734XL_IB_B13.indd 15 8/11/2013 1:32 pm

16
ASSEMBLING YOUR BREVILLE PRODUCT
BEFORE FIRST USE
Before first use remove all promotional
stickers and packaging material. Carefully
unpack the microwave oven and keep all
the packing material until all the parts of the
microwave oven have been accounted for
and the appliance has been assembled. It is
recommended to keep all the packing material
in a safe place in case you wish to repack the
product for shipping or moving purposes.
To remove any dust that may have
accumulated during packing, wash the
turntable roller and glass turntable in warm
soapy water, rinse with clean water then dry
thoroughly. Wipe the interior and exterior of
the microwave oven with a soft, damp cloth
then dry thoroughly.
ASSEMBLING THE GLASS
TURNTABLE AND TURNING ON
THE MICROWAVE OVEN
1. Insert the turntable roller into position in
the indented space in the oven cavity base.
2. Place the glass turntable on top of the
turntable roller, matching the indents of
turntable roller at the center area.
INSTALLATION
1. Select a level and clean surface that
provides enough clearance for proper
air circulation through the intake and
outlet vents as recommended below.
Blocking any of the vents can damage
the microwave.
2. The rear surface of the microwave oven
should be placed against a wall and there
must be at least 8 inches (20cm) clearance
from any side panels and 12 inches (30cm)
above the unit.
3. Plug in the power cord of the unit to an
appropriate and grounded power outlet.
4. Check the oven for any damage, such as
misaligned or bent door, damaged door
seals and sealing surface, broken or loose
door hinges and latches and dents inside
the cavity or on the door. If there is any
damage, do not operate the oven and
contact Breville Consumer Support.
NOTE
Do not remove the legs from the bottom
of the microwave.
Place the microwave as far away from
radios and TV as possible.
Operation of microwave may
cause interference to your radio or
TV reception.
The microwave oven may not be placed
in a cabinet or enclosure.
WARNING
Do not install oven over a range cooktop
or other heat-producing appliances.
BMO734XL_IB_B13.indd 16 8/11/2013 1:32 pm

OPERATING
your Breville product
BMO734XL_IB_B13.indd 17 8/11/2013 1:32 pm

18
OPERATING YOUR BREVILLE PRODUCT
SETTING THE BEEP VOLUME
Press BEEP VOL on shortcuts panel.
The default beep volumes is LOW.
STOP
CLEAR
A Bit More
Turn AMOUNT dial or press BEEP VOL
on shortcuts panel to toggle between LOW,
MEDIUM and HIGH beep volume.
STOP
CLEAR
A Bit More
OR
x 1
Continue turning the AMOUNT dial or
press BEEP VOL on shortcuts panel until
the desired volume is reached. Press START
button to confirm.
NOTE
Each position will sound the BEEP VOL
selected.
NOTE
If you forget to press START to
confirm BEEP VOL, after 1 minute
the microwave will automatically
confirm your selection.
SETTING THE CLOCK –
12 HOUR CLOCK DISPLAY
Press SET CLOCK on shortcuts panel.
The default time is 01:00. The highlighted
digits flash to show it can be adjusted.
STOP
CLEAR
A Bit More
Turn START dial to adjust hours and press
START button to confirm.
STOP
CLEAR
A Bit More
STOP
CLEAR
A Bit More
Minutes now flash to show they can be
adjusted. Turn START dial to adjust minutes
and press START button to confirm.
STOP
CLEAR
A Bit More
STOP
CLEAR
A Bit More
NOTE
If you forget to press START to confirm
hours or minutes, after 1 minute the
microwave will automatically confirm
your selection.
BMO734XL_IB_B13.indd 18 8/11/2013 1:32 pm

19
OPERATING YOUR BREVILLE PRODUCT
SETTING CHILD LOCK
Press and hold A BIT MORE™ button
STOP
CLEAR
A Bit More
for 3 seconds. The CHILD LOCK symbol will
be displayed on the LCD screen. The clock will
still be shown if the clock is turned ON.
STOP
CLEAR
A Bit More
PRESS & HOLD
FOR 3 SECONDS
To deselect CHILD LOCK press and hold
A BIT MORE™ button for 3 seconds.
The CHILD LOCK symbol will disappear
from the LCD screen and you will have full
functionality of your microwave.
SETTING THE UNIT WEIGHT
CONVERSION MEASURE
Press UNITS on shortcuts panel.
You can change from kilograms (kg) to ounces
(oz). The default UNITS is kilograms (kg). The
highlighted kilograms (kg) will flash to show it
can be adjusted. Turn AMOUNT dial or press
UNITS on shortcuts panel to toggle between
kilograms (kg) and ounces (oz). Press START
button to confirm.
NOTE
When weight is displayed on the
screen, as seen below in the SMART
COOK POTATOES setting. E.g. 250g
then pressing the UNITS on shortcuts
panel will convert it to 8 oz.
x 1
BMO734XL_IB_B13.indd 19 8/11/2013 1:32 pm

20
OPERATING YOUR BREVILLE PRODUCT
STANDBY
When the microwave has been idle for
5 minutes, STANDBY mode will be activated.
The backlight of the LCD screen will turn off
and buttons will no longer be illuminated.
Stand-by mode when the time is not set.
When the time has been set STANDBY will not
be displayed on the LCD screen.
Stand-by mode when the time is set.
To “wake up” the microwave:
• Open the door
OR
• Press START, SMART REHEAT, COOK
or DEFROST button
OR
• Turn any dial
OR
• Press any button
INDEPENDENT KITCHEN TIMER
The independent kitchen timer can be used as
either a count down or count up timer.
Setting the count down timer
Press TIMER on shortcuts panel.
The default time is 00:00.
The highlighted digits flash to show it can be
adjusted. Turn START dial to adjust to your
desired time in seconds, minutes and hours.
Press START button to begin.
STOP
CLEAR
A Bit More
STOP
CLEAR
A Bit More
STOP
CLEAR
A Bit More
The timer begins to count down.
STOP
CLEAR
A Bit More
At the end of the timer function, the microwave
will beep 3 times and the word “End” will flash
on the screen.
BMO734XL_IB_B13.indd 20 8/11/2013 1:32 pm
