GENERAL INFORMATION A
Section

A-1
Revision 1.1
04/2022
M0261 EN
A-1
GENERAL INFORMATION
Please read the following precautions carefully before using this equipment.
This unit contains high voltage circuits that may expose you to the danger
of electric shock.
Means for disconnection must be incorporated in accordance with the wiring
rules.
Do not open the enclosure without isolating the signal and supply sources.
Do not power the unit outside of the values stated on the rating label.
Do not use damaged or frayed cables.
Do not dismantle or modify this equipment.
Do not mount the unit to unstable, irregular or non-vertical surfaces.
Do not place heavy objects on top of the unit.
Do not attempt to place items (such as screwdrivers) into the moving parts of
the pump head.
Always ensure that care is taken when handling chemicals
Never insert fingers into mechanisms without turning the power supply
off first.
Do not discard manual; it must be retained.
!
!
!
!
!
SAFETY INFORMATION

A-2
Revision 1.1
04/2022
M0261 EN
A-2 GENERAL INFORMATION
SAFETY PRECAUTIONS
Please read the following precautions carefully before using this equipment.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Wear protective clothing, gloves and goggles when installing dispensers or handling chemicals. Observe the
guidelines from the chemical manufacturer regarding safety advice. Follow the instructions carefully to avoid
accidents.
• Do not open the enclosure without isolating the signal and supply sources. Ensure that these sources
have been isolated for a minimum of 5 minutes before entering the enclosure. Means of disconnection must
be incorporated in accordance with the wiring rules.
• Do not mount the unit to unstable, irregular or non-vertical surfaces.
• Do not place heavy objects on top of the unit.
• Do not attempt to place item (such as screwdrivers) into the moving parts of the pump.
• Do not power the unit outside of the values stated on the rating label.
• Do not use damaged or frayed cables.
• Do not dismantle or modify this equipment.
WARRANTY
Your product comes as standard with a 2 year warranty from the date of manufacture, against manufacturing fault or
defects and mechanical or electrical breakdown. Please visit our website for full terms and conditions.

A-3
Revision 1.1
04/2022
M0261 EN
A-3
GENERAL INFORMATION
OPERATION
The Nexus Laundry units, are automatic dosing systems designed for use with commercial washing machines. The
units are intended for indoor, xed installation only. The means of disconnection must be incorporated in the xed
wiring, with an air gap of at least 3mm in each pole. The pumps are initiated by applying signals of between 90V and
240V AC or DC across the corresponding Inputs of the A and B rails on the power board. Note: signals of between
12V and 240V AC or DC can be accepted by toggling the dip switches as shown on Page 9.
STANDARD MODE
Used with a standard host machine. The relevant pump will operate when a signal is present for the duration of the
signal acceptance time and is equal to the programmed pulse setting. The pump will then remain static for the period
of the delay time, before operating at the programmed speed, for the programmed run time or chemical dosage. The
pump will not operate again until the unit has reset. The unit can be selected to reset after the operation of the nal
pump(eg. pump 4 of a 4 pump unit) or on a signal to input 8.
RELAY MODE
Used with a computer controlled host machine. The pumps will operate for the duration that a signal is present across
the corresponding inputs. Input 1 operates pump 1, input 2/pump 2, etc. The data management, ush valve and
machine interrupt features will remain.
LEVELS MODE
Used with a standard host machine. The relevant pump will operate when a signal is present for the duration of
the signal acceptance time and is equal to the programmed pulse setting. The pump will then remain static for the
period of the delay time, before operating at the programmed speed, for the programmed run time or chemical
dosage. The pumps have three individual levels in which dosing can take place in each wash program and activat-
ed by the corresponding inputs. Input 1 operates pump 1, input 2/pump 2, etc.

TECHNICAL INFORMATION B
Section

B-1
Revision 1.1
04/2022
M0261 EN
B-1
TECHNICAL INFORMATION
BEFORE INSTALLATION
Ensure you have checked all parts required are present and inspect for any damage before installation. In the unlikely
event that your items are faulty, DO NOT install faulty or damaged parts as this is unsafe and will void any warranty.
Please return goods to your distributor in the original delivery condition including any packaging. This unit is ONLY to
be installed by a suitably qualied person complying with local regulations.
NEXUS 4 Pump to 8 Pump system
(Based on order)
Wall mounting pack
(Wall plug x 3)
(M5 screw x 3)
2 way connector x 1
3 way connector x 1
9 way connector x 2
Quick start Guide x 1
OPTIONAL (Based on order)
Formula Select 1-6
Nexus Quickstart
Instruction Manual
Installation and Information
Brightwell.co.uk
Revision1.0
02/2021
M0000
Nexus Quickstart
Manuale di istruzioni
Installazione e informazioni
Brightwell.co.uk
SOLUZIONI DI EROGAZIONE RIVOLUZIONARIE
Revisione1.0
02/2021
M0000

B-2
Revision 1.1
04/2022
M0261 EN
B-2 TECHNICAL INFORMATION
TECHNICAL SPECIFICATIONS
POWER
SUPPLY
VOLTAGE 100–240V AC / 50–60Hz
FREQUENCY
1 - 4 Pump: 2.3A (240V)
5 Pump: 3.8A (240V)
6 Pump: 5.3A (240V)
7 Pump: 6.8A (240V)
8 Pump: 8.3A (240V)
CURRENT
1 Pump: 75W
5 Pump: 103W
6 Pump: 131W
7 Pump: 159W
8 Pump: 187W
TRIGGER
SIGNALS
12–240V AC or DC
MOTOR Flush Valve 24V DC, 1.25A (10W) max
Buzzer/Lamp 24V DC 500Ma, (10W) max
PUMP Membrane Pump - Brushless 24V DC, 400mA
ENCLOSURE LG Lupol GP 3156F. Grey RAL9003 IP55 Rated.
WEIGHT
(APPROX.) NM1 – 4: 3.0KG NM5: 4.2KG NM7: 6.5KG NM6: 5.3KG NM8: 7.6KG
ENCLOSURE
KEYPAD
MEMBRANE PUMP
DISPLAY SCREEN
NEXUS MAIN DOSING UNIT

B-3
Revision 1.1
04/2022
M0261 EN
B-3
TECHNICAL INFORMATION
ADDITIONAL PUMP MODULE
ENCLOSURE
MEMBRANE PUMP
ENCLOSURE
DISPLAY
KEYPAD
MAIN DISPLAY KEYPAD
FORMULA SELECT
ENCLOSURE
DISPLAY
KEYPAD

B-4
Revision 1.1
04/2022
M0261 EN
B-4 TECHNICAL INFORMATION
LAYOUT - MAIN UNIT SCREEN
L4
PUMP ------------
(MESSAGE)
FAULT MESSAGE
If there are any errors on the unit,
the message will show here
NUMBER OF PUMPS
Displays the number of connected
pumps to the unit
ANY RUNNING PUMPS
If any pumps are running, they will
display here

B-5
Revision 1.1
04/2022
M0261 EN
B-5
TECHNICAL INFORMATION
3. MOTOR
CONNECTORS
1. PAIR BUTTON
2. ETHERNET
LAYOUT - MAIN PCB
4. ADD ON PUMP
6. MULTIDOSE AND/OR
FLOW SENSOR MODULE
7. MANIFOLD & SAFETY
STOP SWITCHES
5. IOM
9. 24 VOLT POWER
8. FLOAT SWITCHES
2
3333
45
7
7
7
8
9
6
1

B-6
Revision 1.1
04/2022
M0261 EN
B-6 TECHNICAL INFORMATION
12 34 56 78 9
LAYOUT - IO BOARD
3. COMMON NEUTRAL
1. MAINS POWER IN
2. MAINS OUT
4. TRIGGER INPUT
5. ISOLATED GROUND
8. 24 VOLT OUT
6. CONNECTION TO
MDU/PREVIOUS IOM
7. OUTPUT TO IOM
9. FORMULA SELECT
MACHINE INTERRUPT
1
2
3
4
5
6 7
8
9
10

B-7
Revision 1.1
04/2022
M0261 EN
B-7
TECHNICAL INFORMATION
LAYOUT - FORMULA SELECT SCREEN
PROGRAM NAMEPROGRAM NUMBER PROGRAM RUN COUNT
PG01 000000
Program Name

B-8
Revision 1.1
04/2022
M0261 EN
B-8 TECHNICAL INFORMATION
UNIT VARIATIONS
4 PUMP VARIANT
5 PUMP VARIANT
6 PUMP VARIANT
7 PUMP VARIANT

B-9
Revision 1.1
04/2022
M0261 EN
B-9
TECHNICAL INFORMATION
8 PUMP VARIANT
UNIT VARIATIONS

MOUNTING & WIRING C
Section

C-1
Revision 1.1
04/2022
M0261 EN
C-1
MOUNTING & WIRING
STEP 3
Once you have conrmed the location for the unit take a
pencil or similar marker and place a dot in the top
mounting hole. (As illustrated).
STEP 2
Also conrm that the unit does not have any objects
within the following boundaries.
MOUNTING TO THE WALL - 4 PUMP SYSTEM
STEP 1
Place the unit against the wall where you would like to
install.
PLEASE NOTE - The unit should not be more than 2
metres from the chemical.
!
MAX
2 metres
STEP 4
Take a 6mm drill bit and drill (not provided) and drill a
hole deep enough for the wall plug provided in the kit.
6mm Ø
60 mm
2.4 in.
350 mm
13.8 in.
60 mm
2.4 in.
350 mm
13.8 in.
MAX
2 METRES
60 mm
2.4 in.
60 mm
2.4 in.
350 mm
13.8 in.
XX
X
X
350 mm
13.8 in.
!
