BRK electronic CO910B User manual

CAT. CO910B
10-YEAR
LITHIUM POWER
10 years of continuous protection.
No battery change required. Provides
audible notice when alarm has reached
its end of life.
TAMPERPROOF
SEALED ALARM
Powercell cannot be removed.
ELECTROCHEMICAL CO
SENSOR
Most accurate technology available for
detecting carbon monoxide as com-
pared to other sensing technologies.
SILENCE FEATURE
Silences nuisance alarms.
TAMPER RESISTANT
Locks alarm to mounting bracket. Per-
fect for apartment, dormitory or hotel
applications.
Description:
BRK Model CO910 is a battery operated, 3V lithium power cell single station CO
alarm specifically designed for residential and institutional applications includ-
ing sleeping rooms of hospitals, hotels, motels, dormitories, and other multifamily
dwellings as defined in standard NFPA 101. Model CO910 has been fully tested
and complies with, UL2034 CSFM, NFPA 720, NFPA 101 and other agencies that
model their codes after the above agencies. It meets building codes where tam-
perproof 10-year sealed lithium battery operated CO alarms are required and with
model building codes published by the ICC.
BRK Model CO910 is a state of the art CO alarm designed to provide early warn-
ing of a carbon monoxide danger. It features an electrochemical CO sensor, an
85dB horn, a sealed 10-year lithium power cell power supply that is permanently
installed, a full function test switch, a silence feature to silence unwanted nuisance
alarms, a red LED light that indicates DC power or alarm. The tamperproof design
will not allow the powercell to be removed. The low power warning indicator will
cause the alarm to “chirp” when it reaches the end of its service life and needs
to be replaced. Upon end of life, the unit meets UL requirements for disabling
the alarm and non-reinstallation of unit to mounting bracket. It also features a
tamper resistant locking pin that locks alarm to the mounting bracket. Perfect
for apartment, dormitory or hotel applications. The compact, low profile design
complements any décor. Designed for wall or ceiling mounting. Includes mounting
anchors and screws.
Sealed 3V Lithium Power Cell
10-YEAR SEALED
CARBON
ALARM
MONOXIDE
CO

CAT. CO910B
ARCHITECTURAL AND ENGINEERING SPEC
TECHNICAL SPECS
SHIPPING SPECS
INSTALLATION OF ALARM
The CO alarm shall be a BRK Model CO910 and shall provide at a minimum the
following features and functions:
1. An electrochemical CO sensor.
2. The unit shall be capable of self restoring.
3. Powered by a sealed 10-year lithium powercell with a tamperproof design. The
tamperproof design shall not allow the powercell to be removed. A low power
warning indicator shall cause the alarm to “chirp” when it reaches the end of
its service life and needs to be replaced. Upon end of life, the unit shall meet UL
requirements for disabling the alarm and the non-reinstallation of unit to
mounting bracket.
4. A visual LED power-on indicator to confirm unit is receiving power or is in alarm.
5. A full function test button. The test button should check all alarm functions by
stimulating the chamber to simulate a CO condition, causing the unit to alarm.
6. Two Silence features - Low Battery Silence: Silence low battery chirp for up to 8
hours. Alarm Silence: Temporarily silence unwanted nuisance alarms.
7. A tamper resistant locking pin that locks alarm to the mounting bracket.
8. The unit shall be capable of operating between 40°F (4°C) and 100°F (38°C) and
relative humidity between 10% and 90%.
9. The unit shall contain mounting hardware and shall be listed for wall or ceiling
mounting.
10. The unit shall at a minimum meet the requirements of UL2034, CSFM, NFPA 720,
NFPA 101, ICC.
Alarm Dimensions: 4.92”L x 4.92”W x 0.96”H
Weight: 4.8 oz
Operating Voltage: 3V Lithium Power Cell
Temperature Range: 40°F (4°C) to 100°F (38°C)
Humidity Range: 10% to 95% relative humidity (RH)
Audio Alarm: 85dB at 10 feet
Test/Silence: Electronically simulates CO condition, causing the unit
to alarm. Press and hold test/silence button.
Alarm Reset: Automatic when CO clears
CO Sensor: Electrochemical
Indicator Lights/Sounds:
DC Power: Intermittent Red LED
Local Alarm: Audio Alarm, rapidly flashing red LED
Listing: Listed to UL2034 Standard
Individual Carton Dimensions 4.94 ”L x 1.31”D x 6.63”H
Weight 0.4 lbs.
Cube 0.03 ft3
UPC 0 29054 01334 7
Master Carton Dimensions 10.50 ”L x 8.13”W x 6.38”H
Master Pack 12
Weight 5.3 lbs.
Cube: 0.32 ft3
I2of5: 200 29054 01334 1
Pallet Information
Cases per Layer 19
Number of Layers: 8
Cases per Pallet: 152
Units per Pallet: 1,824
Cube: 62.2 ft3
Weight: 869 lbs.
©2013 BRK Brands, Inc. a Jarden Corporation
Company (NYSE: JAH)
3901 Liberty Street Road
Aurora, IL 60504-8122
All rights reserved
First Alert is a registered trademark of the First Alert Trust
BRK is a registered trademark of BRK Brands, Inc.
CM3183
brkelectronics.com
Installation of this smoke alarm must conform to NFPA 720. Always check your local
building codes. Follow all instructions for placement as outlined in the user’s manual in
sections titled “Recommended Locations for CO Alarms” and “Locations to Avoid for CO
Alarms”.
THE PARTS OF THIS CO ALARM
1. Test/Silence button
2. LED alarm light
3. Activate/Deactivate Switch
4. Locking tab slot (Break out Tab)
5. Locking tab
6. Mounting bracket
7. “This way up” Arrow
8. Mounting Slots
MOUNTING
BRACKET
TOP VIEW SIDE VIEW
4.9” 4.3”
4.9”
1”
4.3”
1
2
3
4
5
6
7
8
8
Activate/Deactivate
Switch-Detail
Break and remove tab then
slide switch to deactivate
OFF - ON - DISCHARGE
