Brother S-7180A User manual

S-7180A
Please read this manual before using the product.
Please k
eep this manual in a place where it can be easily removed whenever necessary.
SINGLE NEEDLE DIRECT DRIVE LOCK STITCHER
WITH
THREAD TRIMMER, ELECTRIC FEEDING
SYSTEM AND PRESSER FOOT LIFTER
Instruction Manual

Aiming for a more affluent environment.
Thank you for your cooperation.
Thank you very much for your patronage of Brother products.
Brother Industries, Ltd. has established an environmental policy based
on "environmentally conscious manufacturing, from product
development to disposal," so that this earth will be a green land forever.
As a good corporate citizen who can coexist with the local community
and the environment, Brother Industries, Ltd. will contribute to
environmental conservation activities in a minor way.
Therefore, we ask that everyone agree with this concept and give
special consideration to the disposal of waste as part of our
environmental conservation activities.
Ask a collection company to dispose of used packing materials as
much as possible in order to recycle them as much as possible.
The disposal method of used lubricating oil is mandatory by law.
Dispose of the product properly according to the laws and
regulations. If in doubt, consult your dealer for further assistance.
During maintenance, dispose of unnecessary electronic boards and
electronic components generated as industrial waste.
We retain performance parts for repair of this product for a minimum of eight years after
discontinuation of production.
Performance parts are parts required to maintain the functions of this product.
1.
2.
3.
1.
2.
3.

S-7180A
i
Thank you for purchasing our Brother Industrial Sewing Machine.
Before use, thoroughly read [Safety Precautions] and the instruction manual.
Due to its nature, industrial sewing machines are operated immediately before moving parts, such as
needles and thread take-up lever, which always pose a risk of injury in these areas. Obtain the knowledge
of safety work and instruction of operation by a skilled person/instructor to use the product correctly.
SAFETY PRECAUTIONS
[1] Indication of safety labeling and meaning.
The symbols used in this instruction manual and on the product are intended to ensure safe and correct use of the
product and to prevent harm to the user and other persons as well as damage to the product.
Its display and meaning are as follows.
Display
DANGER Failure to abide by the information in a warning may result in serious injury
and can be life threatening.
Warning Indicates a potentially hazardous situation which, if ignored, could result in
death or serious injury.
Note Indicates a potentially hazardous situation which, if ignored, could result in
minor or moderate injury.
Graphical symbols
･･････ The symbol means "what you should be aware of."
The illustrations in this symbol indicate the contents of caution.
(In the example on the left, be careful not to injure yourself.)
･･････ The symbol means "Do not do it".
･･････ Symbol means "Must do."
The illustrations in this symbol represent the contents of the instructions.
(In the example on the left, ground connection shall be made.)

S-7180A
ii
[2] Safety Instructions
DANGER
When opening the cover of the control box, be sure to turn off the power switch, unplug the power
cord, wait for 5 minutes, and then open the cover. Touching high voltage parts may cause serious
injuries.
Warning
Do not wet the machine with liquid.
Fire, electric shock or malfunction may occur.
In the unlikely event that liquid enters the machine (sewing machine head/control box),
immediately turn off the power switch, unplug it, and contact your dealer or a trained technician.
Note
Operating environment
Use the product in an environment that is not
affected by strong electrical noise, such as
power line noise or static electricity noise.
Strong electrical noise may cause malfunction
of the sewing machine.
Use the product in an environment where the
fluctuation of the power supply voltage is
within ±10% of the rated voltage.
Large voltage fluctuations may cause
malfunction of the sewing machine.
Use the product in an environment where the
power supply capacity is more than the power
consumption of the product.
Insufficient power supply capacity may cause
malfunction of the sewing machine.
The ambient temperature should be between
5°C and 35°C.
Low or high temperatures may cause the
machine to malfunction.
The relative humidity should be between 45%
and 85% and should be used in a non-
condensing environment.
Drying, high humidity, or condensation on the
device may cause the machine to malfunction.
Turn off the power and unplug the power cord
during a lightning storm.
Lightning can cause the machine to
malfunction.
Do not connect any media other than USB
media to the USB port. This may cause
damage.
Installation
The machine may only be installed by trained
personnel.
Have electrical wiring done by your dealer or an
electrician.
The sewing machine weighs approximately
37kg. Install the product by two or more
persons.
Do not connect the power plug until installation
is complete.
If the treadle is depressed by mistake
, the
sewing machine may operate and cause injury.
Turn off the power switch before inserting or
removing the plug.
Doing so may cause the control box to
malfunction.
Please connect to the Earth.
Incomplete ground connection may cause
electric shock or malfunction.
When fixing the cord, do not forcibly bend the
cord or press it too much with a staple.
This may cause a fire and electrical shock.
For the table with casters, fix the casters so
that they do not move.
When tilting the sewing machine head, fix it so
that the table does not move.
Movement of the table may cause injuries such
as pinching the foot.
Use both hands to tilt or pull back the machine.
If you do so with one hand, your hand may slip
due to the
weight of the sewing machine and
cause injuries such as injuries.
When handling lubricating oil or grease, use
protective goggles or gloves to avoid contact
with your eyes or skin. Doing so may cause
irritation.
Do not swallow or eat lubricating oil or grease.
Diarrhea and vomiting may occur.
Keep it out of the reach of children.

S-7180A
iii
Note
Sewing
This machine may only be used by trained
personnel for safe operation.
Do not use this sewing machine for purposes
other than as a sewing machine.
Use protective goggles when operating the
machine.
A broken needle may get into your eyes and
cause injury.
Turn off the power switch in the following
cases.
If the treadle is depressed by mistake, the
sewing machine may operate and cause injury.
・Threading
・Replacing the bobbin or needle
・When not using the machine or leaving the
machine unattended
For the table with casters, fix the casters so that
they do not move.
Install and use protective equipment for safety.
Using the product with these devices removed
may result in injury.
Do not touch or press against moving parts
during sewing.
Failure to do so may result in injury or damage
to the machine.
When tilting the sewing machine head, fix it so
that the table does not move.
Movement of the table may cause injuries such
as pinching the foot.
Use both hands to tilt or pull back the machine.
If you do so with one hand, your hand may slip
due to the weight of the sewing machine and
cause injuries such as injuries.
If you notice any malfunction or unusual noise
or smell during use, turn off the power switch
immediately. Then contact your dealer or a
trained technician.
If the machine malfunctions, contact your
dealer or a trained technician.
Care
Turn off the power switch before starting work.
If the treadle is depressed by mistake, the
sewing machine may operate and cause injury.
When tilting the sewing machine head, fix it so
that the table does not move.
Movement of the table may cause injuries such
as pinching the foot.
Use both hands to tilt or pull back the machine.
If you do so with one hand, your hand may slip
due to the weight of the sewing machine and
cause injuries such as injuries.
When handling lubricating oil or grease, use
protective goggles or gloves to avoid contact
with your eyes or skin. Doing so may cause
irritation.
Do not swallow or eat lubricating oil or grease.
Diarrhea and vomiting may occur.
Keep it out of the reach of children.
Maintenance and inspection
The machine must be serviced by a trained
technician.
Have electrical maintenance and inspection
performed by your dealer or an electrician.
Turn off the power switch and unplug the
power cord in the following cases:
If the treadle is depressed by mistake, the
sewing machine may operate and cause injury.
・
Inspection, adjustment or repair
・
Replacement of consumable parts such as a
hook and knife
When opening the motor cover, be sure to turn
off the power switch, and then wait for one
minute before opening the cover.
Touching the motor surface may cause burns.
If you need to make adjustments while the
power switch is turned on, use extreme safety
precautions.
When tilting the sewing machine head, fix it so
that the table does not move.
Movement of the table may cause injuries such
as pinching the foot.
Use both hands to tilt or pull back the machine.
If you do so with one hand, your hand may slip
due to the weight of the sewing machine and
cause injuries such as injuries.
When replacing parts or install
ing optional
parts, use our genuine parts.
We are not responsible for accidents or failures
caused by the use of non-genuine parts.
If the safety guard is removed, be sure to install
it in its original position and check that it
functions properly.
Modification
To prevent accidents and malfunctions, do not modify the sewing machine (including the control unit).
We are not responsible for accidents or failures caused by modification.

S-7180A
iv
[3] WARNING LABEL
The warning labels shown below are displayed on the sewing machine.
Be sure to observe the precautions on the warning labels.
Also, if the label is peeled off or becomes unreadable, contact the retailer from whom the watch was
purchased.
1
3
4
Be careful not to pinch
your hands when
returning the overturned
sewing machine head.
Be careful not to injure
yourself with a moving
thread take-up.
2
5
High temperature caution
display
6
Please connect to the
Earth.
Incomplete ground
connection may cause
electric shock or
malfunction.
7
Display of rotation
direction
8
* Safety protection
device:
(A)Finger guard
(B)Balance cover
(C) Motor cover

S-7180A
v
1
6
7
4
2
(B)
(A)
5
3
3
(C)
8
Oil tank

S-7180A
TABLE OF CONTENTS
1. Specifications of the sewing
machine ........................................... 1
2. How to install................................. 2
2-1. Table process drawing............................................3
2-2. How to install .........................................................3
2-3. Lubrication method ................................................6
2-4. Connecting the cord................................................7
2-4-1. Connecting the cord......................................7
3. Operation panel ............................ 8
3-1. Name and Function ................................................8
3-1-1. Key Names and Functions............................8
3-1-2. Icon Functions............................................10
3-2. How to set the memory switch .............................12
3-2-1. Memory switch setting mode for operator. 12
3-2-2. Mechanic memory switch setting mode .... 13
3-3. How to set the sewing pattern ..............................15
3-3-1. Normal sewing ...........................................15
3-3-2. Fixed stitch .................................................16
3-3-3. Continuous backtack stitching....................17
3-3-4. Step sewing with common pitch.................19
3-3-4-1. Step sewing setting of common pitch
..............................................................19
3-3-4-2. Common pitch step editing mode
..............................................................20
3-3-5. Step stitching with arbitrary pitch...............22
3-3-5-1. Step sewing setting of arbitrary pitch
..............................................................22
3-3-5-2. Step edit mode with arbitrary pitch
(number of stitches)
..............................................................23
3-3-5-3. Step edit mode with arbitrary pitch
..............................................................24
3-4. How to set the sewing speed ................................25
3-5. How to set the front/rear and backtack stitches ....26
3-6. How to set up condensation sewing .....................28
3-6-1. Additional setting of condensation sewing.28
3-6-2. Condense edit mode ...................................29
3-7. How to set the main part design stitch..................30
3-7-1. Design stitching of main section.................30
3-7-2. Design stitch editing mode in the main
section ........................................................... 31
3-8. How to set the stitch for the sewing stop design .. 33
3-8-1. Design stitching of sewing stops................ 33
3-8-2. Design stitch editing mode for sewing stops
.................................................................... 34
3-9. Checking method of the production counter ........ 36
3-10. How to set up the handy switch ......................... 36
3-11. How to confirm the software version................. 36
3-12. How to set head specifications........................... 36
3-13. Data initialization method.................................. 37
3-14. Memory Switch ................................................. 38
3-15. List of Error Codes ............................................ 51
3-16. About USB Ports ............................................... 55
4. Care..................................................56
5. Standard adjustment...................57
5-1. Arm thread guide R.............................................. 57
5-2. Height of presser foot........................................... 58
5-3. Feed dog height.................................................... 59
5-4. Inclination of the feed dog ................................... 59
5-5. Height of the needle bar....................................... 60
5-6. Timing of needle and feed ................................... 60
5-7. Timing of the needle and the hook....................... 61
5-8. Adjusting the amount of oil supply to the hook ... 62
5-9. Adjusting the Upper Shaft Lubrication Amount .. 63
5-10. Thread trimmer.................................................. 64
6. In the following cases .................67
6-1. Sewing-related ..................................................... 67

S-7180A

S-7180A
1. Specifications of the sewing machine
1
1.Specifications of the sewing machine
S-7180A-81■P
-813P
-815P
Maximum sewing
5,000sti/min
4,000sti/min
Sewing speed End backtack.
3,200sti/min
Max. stitch length
5mm
5mm*
Thread trimming method
Double action thread trimming mechanism
Thread holder
Standard equipment
Handy switch
Standard equipment
LED light
Standard equipment
Solenoid press lift
Standard equipment
Height of presser foot
Knee lift: 10 to 15 mm/Automatic: 12 mm
Needle to be used (DB×1/DP×5)
#11-#18
#19-#22
Feed dog height
0.9mm
1.2mm
Motor
AC servo motor
Weight
37kg
Power supply
Single-phase: 200 to 240V
Maximum power consumption: 400 VA
*If you need 7mm specification, please contact our sales representative.
Applications
3
For medium
5
Thick material

2. How to install
2
2.How to install
Note
The machine may only be installed by
trained personnel.
Have electrical wiring done by your dealer or
an electrician.
The sewing machine weighs approximately
37kg. Install the product by two or more
persons.
Do not connect the power plug until
installation is complete.
If the treadle is depressed by mistake, the
sewing machine may operate and cause
injury.
When tilting the sewing machine head, fix it
so that the table does not move.
Movement of the table may cause injuries
such as pinching the foot.
Use both hands to tilt or pull back the
machine.
If you do so with one hand, your hand may
slip due to the weight of the sewing machine
and cause injuries such as injuries.
Location of the sewing machine
・Do not install this equipment near a TV, radio or cordless
phone.
Noise may enter the TV, radio or cordless phone.
・Install this unit in a location where the power can be directly
removed from the AC outlet.
Use of an extension cord may cause malfunction of the sewing
machine.
How to carry the sewing machine
・Hold the arm body and motor cover as shown in the figure and
carry the sewing machine by two persons.
＊Do not hold other than the motor cover. Doing so may
damage the sewing machine.
Tilting the sewing machine head
・Hold the (A) part with your foot so that the table does not
move, and push the arm body with both hands to tilt the
sewing machine head.
How to return the sewing machine
1. Place a tool, etc., from near the table hole.
2. Slowly return the sewing machine head with your right hand
while holding the face plate part with your left hand.
0475D
1342D
1343D
S-7180A

S-7180A
2. How to install
3
2-1. Table machining drawing
・The table should be 40mm thick and strong enough to accommodate the weight and vibration of the sewing machine.
・Drill holes as shown in the illustration.
2-2. How to install
1.Connecting rod
(1) Connecting rod
(2) Nut

2. How to install
4
2.Oil pan
Tighten the oil pan with wood screws
from below.
3.Head hinge receiving
rubber
(1) Head hinge receiving rubber [2 pcs]
4.Sewing machine head
(1) Hinge [2 pcs]
(2) Sewing machine head
(3) Pillow
[Note]
・Bundle the cords and route them
through the cord holes.
・Place the pillow (3) firmly into the
table as far as it will go.
・If it is not inserted to the end, it is
dangerous because of poor
stability when the sewing machine
head is tilted.
1414D
Power cord and step on
Connecting the SI unit.
S-7180A

S-7180A
2. How to install
5
15mm
There is
(1)
(2)
5.Knee pad
<Adjusting knee lifting>
1. Turn the pulley to lower the feed dog from the top of the
needle plate.
2. Lower the presser foot (2) with the presser foot lifter (1).
3. Loosen the nut (3).
4. Adjust by turning the screw (5) so that there is a movement
amount (backlash) of the knee pad (4).
5. After this adjustment is made, tighten the nut (3) firmly.
6. Adjust so that the presser foot (7) is within 15mm of the
needle plate when the knee pad is pressed fully.

2. How to install
6
2-3. Lubrication method
Note
Do not connect the power plug until lubrication is complete.
If the treadle is depressed by mistake, the sewing machine may operate and cause injury.
When handling the lubricant, use protective goggles or gloves to avoid contact with your eyes or
skin.
Doing so may cause irritation.
Do not drink lubricating oil. Diarrhea and vomiting may occur.
Keep it out of the reach of children.
Hold the base of the nozzle firmly when cutting the nozzle of the oil tank.
Holding the nozzle by its tip may cause injury by scissors.
Be sure to lubricate the machine when using it for the first
time or when it has not been used for a long time.
1. Remove the rubber stopper (1) and pour lubricant to the
upper baseline (2) of the oil window.
2. Close the rubber stopper (1).
[Note]
In the following cases, the oil lubricant may leak if the
sewing machine head is tilted.
1) When lubricating oil is filled above the baseline (2)
above the oil window.
<When to Supply Lubricant>
When the oil level drops below the baseline (3) in the oil
window, be sure to supply oil.
(1)
(2)
(3)
S-7180A

S-7180A
2. How to install
7
2-4. Connecting the cord
Note
Have electrical wiring done by your dealer or an electrician.
Do not connect the power plug until the connection of the cord is complete.
If the treadle is depressed by mistake, the sewing machine may operate and cause injury.
When fixing the cord, do not forcibly bend the cord or press it too much with a staple.
This may cause a fire and electrical shock.
Please connect to the Earth.
Incomplete ground connection may cause electric shock or malfunction.
2-4-1. Connecting the cord
1.Code
(1) Power cord
(2) Tread unit
2.Ground wire
(1) Ground wire
(2) Tightening screw
[Note]
・For safety, be sure to connect the
ground wire securely.
Connecting the Power Cord and Step Unit
(1)
(2)

3. Operation panel
S-7180A
8
3. Operation panel
3-1. Name and Function
3-1-1. Key Names and Functions
Name Key Function
Memory switch
key
Click this button to enter the memory switch setting mode for the operator.
Touch and hold to display the password entry screen.
Now enter the c
orrect password and press the key to enter the mechanic memory
switch setting mode.
Enter key Click to confirm the changed value or move to the lower (upper) mode.
Press and hold to enter adjustment mode.
Plus key
Click to increase the corresponding value.
Press and hold to continuously increase the corresponding value.
Minus key Click to decrease the corresponding value.
Press and hold to continuously decrease the corresponding value.
Reset button Press and hold to return to the factory default settings.
Pre-stop
sewing/slow start
key
Click to switch the pre-stop stitching operation in the following order.
AB → ABAB Without → → B →..
Press and hold to toggle the slow start function (yes/no).
Post-stop
sewing/needle
up/down key
Click to switch the stop stitching operation in the following order.
CD → CD → No → C →...
Press and hold to switch the needle stop position (needle up/needle down) after
sewing.
Normal
sewing/fixed
sewing key
Click to set the sewing pattern to normal sewing.
Press and hold to set the sewing pattern to inching fixed sewing.

3. Operation panel
S-7180A
9
Name Key Function
Continuous
sewing/step
sewing key
Click to set the sewing pattern to continuous stop sewing.
Press and hold to set the sewing pattern as a
step sewing with a common pitch. The
sewing pattern is switched in the order shown below.
15-step sewing → 4-step sewing → 7-step sewing → 8-step sewing → 15-step
sewing →..
Presser foot
lift/Auto key
Click to switch the presser foot lifting operation in the order shown below.
In → the presser foot is not raised automatically (the presser foot is raised by
pedaling)
→ for raising the presser foot after cutting the thread
→ for raising the presser foot immediately after the upper shaft stops
→to raise the presser foot after cutting the thread and immediately after the upper
shaft has stopped..
Press and hold to toggle the automatic sewing function (enable/disable).
※Valid only for inching, design stitching, and step stitching
Thread
trimmer/thread
holder key
Click to switch the thread trimming function (yes/no).
Press and hold to toggle thread hold function (yes/no).
Main part design
stitch key
Click this button to switch the design stitch function (enable/disable) of the main
part.
Press and hold to enter the design stitch editing mode in the main section.
Condensation
seam key
Click to switch the condensation sewing function in the order shown below.
Beginning sewing condensation sewing →
Final sewing condensation sewing →
First stitch End sewing condensation sewing →
No condensation sewing →..
Press and hold to enter the condensation editing mode.
Stitch key for
sewing stop
design
Click to toggle the design stitch function (enabled/disabled) for the stop sewing part.
Press and hold to enter the design stitch editing mode for the stop stitch.
Step sewing key
with arbitrary
pitch
When clicked, the sewing pattern is a step sewing with an arbitrary pitch.
Press and hold to enter the desired pitch editing mode for step sewing.
※Valid only when sewing pattern is step sewing (arbitrary/common)
Pitch key Click to increase or decrease the pitch.
Press and hold to continuously increase or decrease the pitch.
Acceleration key Click to increase the sewing speed.
Press and hold to increase sewing speed continuously.
Deceleration key Click to decrease the sewing speed.
Press and hold to continuously reduce the sewing speed.

3. Operation panel
S-7180A
10
3-1-2. Icon Functions
Icon Function
Indicates the start backtack (none/B/AB/ABAB).
Indicates the end backtack (none/C/CD/CDCD).
Indicates the needle stop position (up/down).
Indicates whether there is condensation sewing (no sewing/start sewing/end sewing/start sewing and end
sewing).
Lights when the pitch of the step sewing is set to a desired pitch.
Illuminates when the sewing stop is design stitched.
Lights up when the thread holder at the start of sewing.
Lights when the feeding frame lifting operation is available after cutting the thread.
Lights up when the feeding frame lifting operation is present immediately after the upper shaft stops.
Lights when the thread cutting function is enabled.
Lights when the automatic sewing function is enabled.
Lights when the slow start function is enabled.
Lights when the fixed sewing.
Lights when the sewing pattern is normal sewing.

3. Operation panel
S-7180A
11
Icon Function
Lights when the sewing pattern is continuous backtack sewing.
Lights up when the sewing pattern consists of up to 15 steps.
Lights up when the sewing pattern is a step sewing consisting of 4steps.
Lights up when the sewing pattern is a step sewing consisting of 7 steps.
Lights up when the sewing pattern consists of 8 steps.
