Bryant 331JAV User manual

Form No. PDS 331J.60.4
PLUS 80t with Perfect Heat™
DOWNFLOW
INDUCED-COMBUSTION FURNACE
331JAV
California Approved
Sizes 060 thru 100
Series C
The Plus 80t Downflow Furnace achieves 80 percent Annual
Fuel Utilization Efficiency (AFUE) rating. The benefits of Perfect
Heat operation in reducing sound and improving comfort put it in
a class well ahead of the competition. The Plus 80t has the kind
of overall performance needed in today’s homes. All models are
GAMA efficiency rating certified and certified for use in California
Air Quality Management Districts.
FEATURES
EFFICIENCY — The Plus 80t Induced-Combustion Gas Fur-
nace provides the efficiency customers want with 80.0% AFUE.
HOT SURFACE IGNITION — No pilot to waste gas with this
field-proven ignition system.
ALUMINIZED HEAT EXCHANGER — The patented 4-pass
heat exchanger is made of aluminized steel and backed by a
20-year Limited Warranty.
INTELLIGENT CONTROL — The Plus 80t has an intelligent
control that monitors the operation of the furnace. This control
also has a component-test feature that enables the servicing
technician to verify operation of the control; the high and low in-
ducer; the hot surface ignitor; and high-, medium-, and low-
speed blower operation. The control features a 3-amp fuse that
protects the transformer and control. We guarantee the reliability
of the control with a 3-year Limited Warranty.
40-IN. HEIGHT — The Plus 80t cabinet height is only 40 in.
This simplifies installation in alcoves, attics, basements (ideal
for short basement), closets, and utility rooms, especially with
a taller high-efficiency cooling coil.
PREPAINTED CABINET — The Plus 80t uses prepainted sheet
metal for the cabinet. This is the same high-quality finish found
on refrigerators and other appliances today. We ensure its dura-
bility by using a galvanized steel substrate to provide superior
rust protection.
PATENTED BLOCKED VENT SAFEGUARD — Our induced-
combustion furnace has a patented blocked vent safeguard. The
safeguard switch will stop furnace operation if the vent system
becomes blocked or is not operating properly. An exclusive with
the Plus 80t furnace.
EASY INSTALLATION — The Plus 80t has many features that
make installation easier: left or right gas and electrical connec-
tions, heating and cooling blower speed selector, matching coil
sizes, accessory low-voltage connections, and many more.
QUIET OPERATION — A soft mount inducer assembly and 2-
stage slow-opening gas valve reduce sound level. The Perfect
Heat operation capability minimizes furnace and air noise for
total home comfort.

—2—
A99109
DIMENSIONS (In.)
UNIT SIZE A D E VENT CONN (Dia) SHIPPING WEIGHT (Lb)
036060 14-3/16 12-9/16 12-11/16 4 145
048080 17-1/2 15-7/8 16 4 154
060100 21 19-3/8 19-1/2 4 181
4 3⁄16″2″
2 15⁄16″
13⁄16″
11⁄16″
9 1⁄8″
10 1⁄4″
1 1⁄16″
2 1⁄8″
8 1⁄4″10 1⁄4″1 1⁄16″
2 1⁄8″
16 1⁄16″
13 5 ⁄16″
19″11⁄16″
13⁄16″
11⁄16″
20″
28 1⁄2″
39 7⁄8″
D
5⁄8″ TYP
1″ TYP
E
A
AIRFLOW
OUTLET
INLET
1⁄2″ DIA
THERMOSTAT
WIRE ENTRY
7⁄8″ DIA
ACCESSORY
7⁄8″ DIA
ACCESSORY
DIMPLES TO DRILL HOLES
FOR HANGER BOLTS (4 PLACES)
IN HORIZONTAL POSITION
ADDITIONAL 7⁄8″ DIA K.O. ARE
LOCATED IN THE TOP PLATE
AND BOTTOM PLATE
NOTE:
7⁄8″ DIA HOLE
POWER ENTRY
1 1⁄2″ DIA
R.H. GAS ENTRY
7⁄8″ DIA
ACCESSORY
1 3⁄4″ DIA HOLE
GAS ENTRY
VENT CONNECTION
1. Two additional 7⁄8 - in. dia holes are located in the top plate.
2. Minimum return-air openings at furnace, based on metal duct. If flex duct is used,
see flex duct manufacturer's recommendations for equivalent diameters.
a. For 800 CFM–16-in. round or 141⁄2x 12-in. rectangle.
b. For 1200 CFM–20-in. round or 141⁄2x 191⁄2-in. rectangle.
c. For 1600 CFM–22-in. round or 141⁄2x 231⁄4-in. rectangle.
d. For airflow requirements above 1800 CFM, must use entire return air opening.
NOTES:
ACCESSORY DOWNFLOW SUBBASE
A88207
Disassembled
A88206
Assembled
LOCATING
TAB
LOCATING
TAB
1234
4321
B
D


C
A
1
1
⁄
4
″ TYP
PLENUM
OPENING
FACTORY-SUPPLIED
FIELD-INSTALLED
INSULATION
MEETS DOE RESIDENTIAL CONSERVATION
SERVICES PROGRAM STANDARDS.
Before purchasing this appliance, read important
energy cost and efficiency information available
from your retailer.
CERTIFIED
DIMENSIONAL DATA (In.)
* The plenum should be constructed 1/4 in. smaller in width and depth than the plenum dimensions shown above.
FURNACE WIDTH PLENUM OPENING
* FRAMED FLOOR HOLE HOLE NO. FOR
WIDTH ADJUSTMENTABCD
14-3/16 11-13/16 19 13-7/16 20-3/8 4
17-1/2 15-1/8 19 16-3/4 20-3/8 3
21 18-5/8 19 20-1/4 20-3/8 2
ama

—3—
SPECIFICATIONS
* Gas input ratings are certified for elevations to 2000 ft.For elevations above 2000 ft, reduce ratings 4% for each 1000 ft above sea level.Refer to National
Fuel Gas Code Table F4.In Canada, derate the unit 10% for elevations 2000 ft to 4500 ft above sea level.
† Capacity in accordance with U.S. Government DOE test procedures.
‡ 5500 ft and higher above sea level.
** Required for installation on combustible floors when no coil box is used, or when any coil box other than a Bryant cased coil is used.
ICS—Isolated Combustion System
CONTROLS—THERMOSTATS AND ZONING
UNIT SIZE 036060 048080 060100
RATINGS AND PERFORMANCE
Gas Input (Btuh) * High Stage 63,000 84,000 105,000
Low Stage 40,500 54,000 67,500
Output Capacity (Btuh)† High Stage 51,000 69,000 86,000
Nonweatherized ICS Low Stage 33,000 44,000 55,000
AFUE† Nonweatherized ICS 80.0 80.0 80.0
Certified Temperature Rise High Stage 30—60 30—60 35—65
Range (°F) Low Stage 15—45 15—45 20—50
Certified External Static Pressure Heat/Cool 0.10/0.50 0.15/0.50 0.20/0.50
Airflow CFM Heating High/Low 1195/1030 1355/1170 1735/1500
Cooling 1195 1580 1950
ELECTRICAL
Unit Volts— Hertz— Phase 115—60—1
Operating Voltage Range Min—Max 104—127
Maximum Unit Amps 10.5 14.2 17.9
Maximum Wire Length (Measured 1 Way) Ft 35 26 32
Minimum Wire Size 14 12
Maximum Fuse Size 15 20
Transformer (24v) 40va
External Control Heating 19va
Power Available Cooling 35va
Air Conditioning Blower Relay Standard
CONTROLS
Limit Control SPST (Auto-Reset)
Heating Blower Control Solid-State Time Operation
Inducer 2-Speed
Burners (Monoport) 3 4 5
Gas Connection Size 1/2-in. NPT
GAS CONTROLS
2-Stage Redundant Gas Valve White-Rodgers
Min Inlet Pressure (In. wc) 4.5 (Natural Gas)
Max Inlet Pressure (In. wc) 13.6 (Natural Gas)
Ignition Device Hot Surface
BLOWER DATA
Direct-Drive Motor HP (PSC) 1/3 1/2 3/4
Motor Full Load Amps 5.1 7.4 11.0
RPM (Nominal)—Speeds 1075—5
Blower Wheel Diameter x Width (In.) 10 x 6 10 x 8 10 x 6
Filter Size (In.)—Permanent Washable (Supplied) (2) 14 x 20 x 1 (2) 16 x 20 x 1
DEALER-INSTALLED ACCESSORIES
Downflow Subbase ** KGASB0201ALL
High-Altitude Pressure Switch Kit‡ KGAH5601PSW
Gas Conversion Kit—Natural-to-Propane KGANP26012SP
Gas Conversion Kit—Propane-to-Natural KGAPN21012SP
THERMOSTAT—NON-PROGRAMMABLE
Auto Changeover, °F/°C, 1-Stage Heat/1-Stage cool — TSTATBBNAC01-B
Auto Changeover, °F/°C, 2-Stage Heat/1-Stage Cool — TSTATBBNHP01-B
Auto Changeover, °F/°C, 2-Stage Heat/2-Stage cool — TSTATBBN2S01-B
in AC Mode, 3-Stage Heat/2-Stage Cool in HP Mode
Air Conditioner, 1-Stage Heat/1-Stage Cool, Manual Changeover, °F/°C — TSTATBBBAC01
Heat Pump, 2-Stage Heat/1-Stage Cool. Manual Changeover, °F/°C — TSTATBBBHP01*
THERMOSTAT-PROGRAMMABLE
Auto Changeover, 7-Day Programmable, °F/°C, 1-Stage heat/1-Stage cool —TSTATBBPAC01-B
Auto Changeover, 7-Day Programmable, °F/°C, 2-Stage Heat/1-Stage Cool —TSTATBBPHP01-B
Auto Changeover, 7-Day Programmable, °F/°C, —TSTATBBP2S01-B
2-Stage Heat/2-Stage Cool in AC Mode, 3-Stage Heat/2-Stage Cool in HP Mode
Dual Fuel Thermostat. Includes Outdoor AirTemperature Sensor — TSTATBBPDF01-B*
Thermidistat™ Control — Non-Programmable/Programmable — TSTATBBPRH01-B*
Thermostat with Humidity Control (For use in Dual Fuel, AC, HP, and 2S applications.
Includes Outdoor Air Temperature Sensor.)
ZONING—2-ZONE ZONEBB2KIT01, ZONEKIT2ZBDP
ZONING—4-ZONE ZONEBB4KIT01
ZONING—8-ZONE ZONEBB8KIT01

—4—
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
UNIT MUST BE INSTALLED IN ACCORDANCE
WITH INSTALLATION INSTRUCTIONS
Cancels: PDS 331J.60.3
© 1999 Bryant Heating & Cooling Systems, 7310 W. Morris St. Indpls., IN 46231 PRINTED IN U.S.A. Catalog No. 5233-103 10-99
AIR DELIVERY— CFM (With Filter)
A97620
UNIT
SIZE BLOWER MOTOR HP SPEED EXTERNAL STATIC PRESSURE (IN. WC) 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
036060 1/3 PSC
High
Med-High
Med
Med-Low
Low
1435
1195
1030
900
705
1385
1165
1020
890
700
1320
1145
1010
875
690
1265
1105
985
855
675
1195
1070
955
835
655
1145
1015
915
795
625
1080
955
860
755
580
1000
885
790
690
525
048080 1/2 PSC
High
Med-High
Med
Med-Low
Low
1855
1595
1355
1170
880
1765
1570
1345
1170
865
1710
1530
1305
1140
855
1665
1485
1270
1110
830
1580
1410
1220
1075
805
1570
1355
1170
1025
755
1410
1280
1110
965
720
1310
1200
1025
890
655
060100 3/4 PSC
High
Med-High
Med
Med-Low
Low
2235
1995
1735
1510
1145
2185
1970
1735
1500
1140
2110
1915
1675
1485
1125
2030
1845
1625
1455
1115
1950
1765
1565
1400
1100
1835
1680
1480
1320
1085
1700
1545
1370
1230
1045
1540
1415
1265
1130
990
322567-101 REV. E (LIT)
MINIMUM INCHES CLEARANCE TO COMBUSTIBLE CONSTRUCTION
INSTALLATION
This unit is certified for downflow installation only. See Installation Manual for
important installation instructions.
This forced air furnace is equipped for
use with natural gas at altitudes 0 -
10,000 ft
(0-3,050m).
An accessory kit, supplied by the
manufacturer, shall be used to convert to
propane gas use or may be required for
some natural gas applications.
This furnace is for indoor installation in
a building constructed on site.
This furnace may be installed on
combustible flooring in alcove or closet at
minimum clearance from combustible
material.
This furnace may be used with a Type
B-1 Vent and may be vented in common
with other gas-fired appliances.
Clearance in inches.
BOTTOM
##
1" #
0"
1"
1"
30"
MIN
SIDE
FRONT
BCK
A
SERVIE
C
FRONT
SIE
U
FRNACE
#
Ø
TOP / PLENUM
D
1"
†
Ø
†
For installation on non-combustible
floors only. For installation on
combustible flooring only when
installed on special base, Part No.
KGASB0201ALL, Coil Assembly,
Part No. CD5 or CK5, or Coil
Casing, Part No. KCAKC.
For furnaces wider than 14.25
inches (362mm) may be 0 inches.
18 inches front clearance required
for alcove.
For single wall vent type 6 inches.
#
##
Vent Clearance to combustibles:
For Single Wall vents 6 inches (6 po).
For Type B-1 vent type 1 inch (1 po).
This furnace is approved for DOWNFLOW installations only.
