Product Data
A11264
Representative drawing only. Some product models may vary.
The 912SE Multipoise Legacy™ 92 Condensing Gas Furnace features a
single-stage gas valve and ECM blower motor. The fixed-speeds,
constant torque (MCT) ECM blower motor is at the heart of the
electrical efficiency provided by this furnace. With an Annual Fuel
Utilization Efficiency (AFUE) of 92.1% AFUE, the Legacy™
single-stage gas furnace provides added savings over standard,
non-condensing gas furnaces. Improved serviceability with the 3 digit
status display and NFC enabled board allowing setup via the service tech
app. This Legacy Gas Furnace features 4-way multipoise installation
flexibility, and is available in nine model sizes. The 912SE can be vented
for direct vent/two-pipe, ventilated combustion air, or single-pipe
applications. A Bryant Legacy thermostat and Legacy Air Conditioner
or Heat Pump, can be used to form a complete Legacy Series System.
All sizes are design certified in Canada. All sizes are design certified for
use in Manufactured Housing (Mobile Home) applications when used
with factory-approved MH accessory kit.
PERFORMANCE
• Multi 18-speed, constant torque (MCT) ECM blower motor for
electrically efficient operation all year long in heating, cooling and
continuous fan operation.
• Single-speed inducer motor, and single-stage gas valve.
• Silicon Nitride PerfectLight™ Robust Hot Surface Igniter.
• Adjustable blower speed for heating and cooling.
• Enhanced diagnostics with easy to read 3 digit display for faults and
status
• Aluminized-steel primary heat exchanger.
• Stainless-steel condensing secondary heat exchanger.
INSTALLATION FLEXIBILITY
• 4-way multipoise design for upflow, downflow or horizontal
installation, with unique vent elbow for 12 different venting options,
including optional venting through-the-cabinet downflow venting
capability.
• On-board NFC antenna makes setup a tap away when using the
Bryant service technician app
• Factory-configured ready for upflow applications.
• Ideal height 35” (889 mm) cabinet: short enough for taller coils, but
still allows enough room for service.
• Direct-vent/sealed combustion, single-pipe venting or ventilated
combustion air.
APPLICATIONS
• Approved for Twinning applications with accessory kit (42060M17,
048080M17, 060080M21, 60100M21, 60120M24 models, only).
• Approved for Manufactured Housing/Mobile Home applications with
MH accessory kit.
• Convertible to propane with gas conversion accessory kit.
CERTIFICATIONS
• All sizes meet ENERGY STAR® South regional standards.
• Cabinet air leakage less than 2.0% at 1.0 in. w.c. and cabinet air
leakage less than 1.4% at 0.5 in. w.c. when tested in accordance with
ASHRAE standard 193.
• All sizes can be installed in California air quality management
districts with a 40 ng/J NOx emissions limit.
A200350
912SE
Up to 92.1% AFUE, Single-Stage, Multi 18-Speed
ECM, Condensing Gas Furnace
WARNING
!
CARBON MONOXIDE POISONING AND FIRE
HAZARD
Failure to follow this warning could result in personal injury, death,
and/or property damage.
This furnace is not designed for use in recreation vehicles or outdoors.
This furnace is designed for use in manufactured (Mobile) homes when
an optional Mobile Home accessory kit is installed.
Failure to follow this warning could result in personal injury, death,
and/or property damage.

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
2
DIMENSIONAL DATA
A210796
Dimensions
FURNACE SIZE A B C D SHIP WT.
LB (KG)
CABINET WIDTH OUTLET WIDTH BOTTOM INLET WIDTH AIR INTAKE
36040M14 14-3/16 (361) 12-1/2 (319) 12-9/16 (322) 7-1/8 (181) 122 (55)
36040M17 17-1/2 (445) 15-7/8 (403) 16 (406) 8-3/4 (222) 123 (56)
36060M14 14-3/16 (361) 12-1/2 (319) 12-9/16 (322) 7-1/8 (181) 128 (58)
42060M17 17-1/2 (445) 15-7/8 (403) 16 (406) 8-3/4 (222) 136 (62)
48080M17 17-1/2 (445) 15-7/8 (403) 16 (406) 8-3/4 (222) 144 (65)
60080M21 21 (533) 19-3/8 (492) 19-1/2 (495) 10-1/2 (267) 153 (69)
60100M21 21 (533) 19-3/8 (492) 19-1/2 (495) 10-1/2 (267) 160 (73)
66100M21 21 (533) 19-3/8 (492) 19-1/2 (495) 10-1/2 (267) 165 (75)
60120M24 24-1/2 (622) 22-7/8 (581) 23 (584) 12-1/4 (311) 180 (82)
NOTE: ALL DIMENSIONS IN INCH (MM)
SD5663-4 REV. -

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
3
MODEL NUMBER NOMENCLATURE
A220582
FURNACE COMPONENTS
A190145
For California Residents:
If installed with a manufactured (mobile) home conversion kit in
SCAQMD: This furnace does not meet the SCAQMD Rule 1111 14 ng/J
NOx emission limit, and thus is subject to a mitigation fee of up to $450.
This furnace is not eligible for the Clean Air Furnace Rebate Program:
www.CleanAirFurnaceRebate.com
MINIMUM CLEARANCES TO COMBUSTIBLE
MATERIALS
The furnace should be sized to provide 100 percent of the design heating
load requirement plus any margin that occurs because of furnace model
size capacity increments. None of the furnace model sizes can be used if
the heating load is 20,000 BTU or lower. Use Air Conditioning
Contractors of America (Manual J and S); American Society of Heating,
Refrigerating, and Air-Conditioning Engineers; or other approved
engineering method to calculate heating load estimates and select the
furnace. Excessive oversizing of the furnace may cause the furnace
and/or vent to fail prematurely, customer discomfort and/or vent
freezing.
Failure to follow these guidelines is considered faulty installation and/or
misapplication of the furnace; and resulting failure, damage, or repairs
may impact warranty coverage.
1
Heat
Exchanger
9
2
Tier/NOx
8
3
AFUE/NOx
7
4
Heating Stages
M
5
Major
Series
B
6, 7
Cooling
Capacity (CFM)
42
8 - 10
Heat Input
060
11
Motor Type
C
12 - 13
Width
17
14
Voltage
(1-phase)
A
15
Un-used
-
16
Minor
Series
A
|| | ||| | | ||||
-
A
B
C
---
14 = 14.2"
17 = 17.5"
21 = 21.0"
24 = 24.5"
C = Constant Airflow
Variable- Speed
(VCA) ECM
V = Variable-Speed
(VCT) PWM
M = Multi 18-Speed
Constant Torque
(MCT) ECM
026 = 26,000 BTU/h
040 = 40,000 BTU/h
060 = 60,000 BTU/h
---
A = 110V/60Hz
B = 230V/50Hz
A
B
C
D
---
8 = 80%
9 = 90+%
0 = Base
1 = Legacy Line
2 = Preferred
3 = Ultra Low Nox
8 = Evolution
0 = 80%
1 = 80% Low NOx
(Not Ultra Low
NOx)
2 = 92%
5 = 95%
6 = 96%
7 = 97%
8 = 98%
24 = 800 CFM
30 = 1000 CFM
36 = 1200 CFM
42 = 1400 CFM
48 = 1600 CFM
60 = 2000 CFM
66 = 2200 CFM
M = Modulating
T = Two Stage
S = Single Stage
C = Single Stage
Communicating
RATING PLATE NOT SHOWN
(LOCATED ON BLOWER DOOR)
GAS VALVE
MAIN LIMIT SWITCH
(BEHIND GAS VALVE)
ELECTRICAL JUNCTION
BOX (IF REQUIRED,
LOCATION MAY VARY)
OPERATING INSTRUCTIONS
NOT SHOWN (LOCATED ON
MAIN FURNACE DOOR, SEE
OPERATING INSTRUCTIONS
INSIDE DOOR FIGURE).
FURNACE
CONTROL
BOARD
MANUAL RESET
ROLLOUT SWITCH
FLAME
SENSOR
MANUAL RESET
ROLLOUT SWITCH
GAS BURNER
HOT SURFACE
IGNITER
INDUCER MOTOR
ASSEMBLY
BLOWER AND
MOTOR
BLOWER DOOR
SAFETY SWITCH
POSITION CLEARANCE
Rear 0 (0 mm)
Front (Combustion air openings in
furnace and in structure) 1 in. (25 mm)
Required for service*
*. Consult your local building codes
24 in. (610 mm)†
†. Recommended
All Sides of Supply Plenum*1 in. (25 mm)
Sides 0 (0 mm)
Vent 0 (0 mm)
Top of Furnace 1 in. (25 mm)

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
4
SPECIFICATIONS
FURNACE SIZE 36040M14 36040M17 36060M14 42060M17 48080M17 60080M21 60100M21 66100M21 60120M24
HEATING AND CAPACITY AND EFFICIENCY
Input BTUh*
*. Gas input ratings are certified for elevations to 2000 ft. (610 M). In USA, For elevations above 2000 ft (610 M), reduce ratings 4 percent for each 1000 ft (305 M) above sea
level. Refer to National Fuel Gas Code NFPA 54/ANSI Z223.1 Table F.4 or furnace installation instructions.
40,000 40,000 60,000 60,000 80,000 80,000 100,000 100,000 120,000
Output Capacity (BTUh)†)
†. Capacity in accordance with U.S. Government DOE test procedures.
37,000 37,000 56,000 56,000 75,000 75,000 93,000 93,000 111,000
Certified Temperature Rise Range
- °F (°C)
35-65
(19-36)
35-65
(19-36)
35-65
(19-36)
40-70
(22-39)
40-70
(22-39)
35-65
(19-36)
40-70
(22-39)
40-70
(22-39)
45-75
(25-42)
AFUE 92.1%
AIRFLOW CAPACITY AND BLOWER DATA
Rated Certified
External Static
Pressure
Heating 0.10 0.10 0.12 0.12 0.15 0.15 0.20 0.20 0.20
Cooling 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
Airflow CFM @
Rated ESP (CFM)‡
‡. Airflow shown is for bottom only return-air supply for the as-shipped speed tap. For air delivery above 1800 CFM, see Air Delivery table for other options. A filter is required
for each return-air supply. An airflow reduction of up to 7 percent may occur when using the factory-specified 4-5/16-in. (110 mm) wide, high efficiency media filter.
Heating 730 760 1090 935 1320 1390 1620 1600 1830
Cooling 195-1090 140-1100 320-1285 200-1340 270-1790 275-1890 295-1870 295-2220 355-1930
Direct Drive Motor HP 1/2 1/2 1/2 1/2 3/4 3/4 3/4 1 3/4
Motor Full Load Amps 6.7 6.7 6.7 6.7 8.8 8.8 8.8 11.7 8.8
Heating Blower Control (Htg
OFF-Delay) Adjustable: 90, 120 (factory-set), 150, 180 seconds
Cooling Blower Control (Clg
OFF-Delay) Adjustable: 90 (factory-set), 5, 30 seconds
Blower Wheel Diameter x Width -
In. (mm)
11x7
(279x178)
11x8
(279x203)
11x7
(279x178)
11x8
(279x203)
11x8
(279x203)
11x10
(279x254
11x10
(279x254
11x10
(279x254
11x11
(279x279
Air Filtration System Field Supplied Filter
Filter used for Certified Watt Data 325531-40**
**. See Accessory List for part numbers available.
ELECTRICAL DATA
Unit Volts-Hertz-Phase 115-60-1
Operating Voltage
Range Min-Max 104-127
Maximum Unit Amps 7.4 7.4 7.5 7.5 11.0 11.0 11.1 13.8 11.1
Unit Ampacity 10.2 10.2 10.3 10.3 14.7 14.7 14.8 18.2 14.8
Maximum Wire Length (Measure 1
way in Ft/M) 36/11.1 36/11.1 36/11.0 36/11.0 25/7.7 25/7.7 25/7.6 31/9.6 25/7.6
Minimum Wire Size AWG 14 14 14 14 14 14 14 12 14
Max. Fuse/Ckt Bkr
Size
(Time-Delay Type
Recommended)
Amps 15 15 15 15 15 15 15 20 15
Transformer Capacity (24 VAC
output) 40VA
External Control
Power Available
Heating 12VA
Cooling 35VA
GAS CONTROLS
Burners 223344556
Gas Connection Size 1/2 in. NPT
Gas Valve
(Redundant) Mfr White Rodgers™
Min. inlet pressure (in.w.c.) 4.5 (Natural Gas)
Max. inlet pressure (in.w.c.) 13.6 (Natural Gas)
Ignition Device Silicon Nitride
Factory installed orifice Size 44
CONNECTIONS
Communication System None
Thermostat Connections G, C, W, Y, R
Accessory Connections EAC-1 (115 VAC); HUM (24 VAC); 1-STG AC (via Y)

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
5
AIR DELIVERY - CFM
Air Delivery - CFM (with filter)
Unit Size Airflow
Setting
Default
Setting
External Static Pressure (in. w.c.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
36040M14
1 Cont. Fan 435 370 310 255 195 120 - - - -
2 480 420 365 310 260 200 135 - - -
3 525 470 415 365 315 265 210 145 - -
4 550 500 445 395 350 305 255 200 135 -
5 615 570 520 470 425 385 345 300 245 195
6 665 620 575 525 480 440 400 365 320 275
7 705 665 625 580 535 495 455 420 380 345
8 Heat 730 690 650 600 560 520 480 445 405 370
9 775 735 695 655 610 570 535 495 460 425
10 800 765 725 690 645 605 565 535 495 465
11 850 815 775 740 700 660 625 590 555 525
12 900 870 835 800 765 725 690 655 620 590
13 955 920 890 855 825 785 750 715 685 650
14 995 965 930 900 865 835 800 765 730 700
15 1040 1010 980 950 920 890 855 825 790 760
16 1085 1055 1025 1000 970 940 910 875 845 810
17 1135 1110 1080 1050 1025 990 965 935 905 870
18 Cooling 1215 1190 1160 1130 1090 1055 1020 985 940 900
36040M17
1 Cont. Fan 400 335 270 210 140 - - - - -
2 485 425 365 310 265 200 140 - - -
3 530 475 415 360 320 270 210 150 - -
4 585 530 480 425 375 340 295 235 185 145
5 620 570 520 470 420 380 345 295 245 195
6 660 610 565 515 470 420 385 350 300 255
7 705 660 615 570 525 480 435 405 370 325
8 730 685 640 595 550 505 460 430 400 360
9 Heat 760 720 675 630 590 550 500 465 435 405
10 800 760 720 680 635 595 555 510 480 450
11 850 810 770 730 695 655 615 575 535 505
12 900 865 830 795 755 720 680 645 605 570
13 960 930 895 860 825 790 755 720 685 650
14 1010 980 945 910 875 840 810 780 745 710
15 1060 1025 995 965 930 895 865 835 800 765
16 1110 1080 1050 1020 985 955 925 895 865 835
17 1165 1135 1105 1080 1045 1020 990 960 930 900
18 Cooling 1225 1195 1165 1135 1100 1060 1020 985 945 910
36060M14
1 Cont. Fan 585 515 445 380 320 260 195 145 - -
2 630 570 510 440 380 330 270 205 160 -
3 695 635 580 520 460 405 355 300 240 180
4 735 685 630 575 510 460 410 360 310 250
5 780 725 675 620 565 510 455 410 365 315
6 800 755 700 650 600 540 490 440 400 355
7 875 830 785 735 690 640 585 540 495 450
8 935 890 845 805 760 715 665 615 570 525
9 990 950 910 865 820 780 735 690 640 600
10 1025 980 940 900 860 820 775 730 685 640
11 1045 1005 965 925 880 840 800 760 710 670
12 Heat 1100 1065 1025 990 950 910 870 835 790 745
13 1160 1120 1085 1050 1010 975 935 900 860 820
14 1195 1160 1120 1085 1050 1015 975 940 905 870
15 1215 1180 1150 1115 1080 1045 1005 970 935 900
16 1285 1250 1220 1185 1150 1120 1085 1050 1015 980
17 1345 1315 1285 1255 1220 1190 1155 1125 1090 1060
18 Cooling 1405 1375 1345 1315 1285 1255 1220 1190 1160 1125
42060M17
1 Cont. Fan 530 440 350 270 200 125 - - - -
2 610 530 450 365 295 235 170 - - -
3 645 570 495 410 335 280 220 155 - -
4 680 610 530 455 380 320 265 205 140 -
5 730 665 590 520 440 375 325 270 215 150
6 790 725 660 595 520 455 390 345 290 240
7 845 785 725 665 600 530 465 410 365 320
8 900 840 785 725 665 600 535 480 425 385
9 Heat 965 910 860 805 750 690 620 565 505 460
10 1010 960 910 860 805 750 695 625 570 520
11 1065 1015 970 920 870 820 765 710 650 595
12 1135 1085 1040 995 950 900 850 795 740 685
13 1195 1150 1105 1060 1015 970 925 880 825 770
14 1250 1205 1160 1120 1080 1035 995 950 905 850
15 1320 1275 1235 1195 1155 1110 1070 1030 985 940
16 1380 1335 1295 1260 1220 1180 1140 1100 1060 1020
17 1440 1400 1360 1325 1290 1250 1215 1175 1135 1100
18 Cooling 1485 1450 1410 1375 1340 1300 1265 1230 1190 1155

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
6
48080M17
1 Cont. Fan 595 510 425 345 270 195 125 - - -
2 655 580 500 425 345 280 215 145 - -
3 740 670 600 525 460 390 325 265 205 145
4 810 750 685 620 555 495 425 365 310 255
5 880 820 765 705 640 580 525 460 400 350
6 945 890 835 780 720 660 605 555 490 435
7 1005 950 900 845 795 735 680 630 580 520
8 1080 1030 980 930 880 830 780 725 680 630
9 1150 1105 1055 1010 965 915 870 820 770 725
10 1235 1190 1145 1100 1060 1015 970 925 880 835
11 Heat 1345 1300 1260 1220 1180 1140 1100 1060 1020 975
12 1390 1345 1305 1265 1230 1190 1150 1115 1075 1030
13 1475 1435 1395 1360 1320 1285 1250 1215 1175 1140
14 1560 1520 1485 1445 1410 1380 1345 1310 1275 1240
15 1630 1595 1560 1525 1495 1460 1425 1400 1365 1335
16 1720 1685 1655 1620 1585 1555 1525 1500 1470 1440
17 Cooling 1805 1770 1740 1710 1680 1650 1620 1595 1570 1545
18 1910 1885 1850 1820 1790 1750 1710 1670 1630 1590
60080M21
1 Cont. Fan 660 555 460 370 275 190 - - - -
2 720 630 535 450 360 275 195 120 - -
3 780 690 605 520 440 355 275 200 125 -
4 860 780 695 615 535 460 385 315 240 170
5 940 860 780 705 630 560 490 415 350 280
6 1025 955 880 810 740 670 600 540 470 405
7 1110 1040 975 905 840 770 710 645 590 525
8 1190 1125 1060 995 935 870 810 745 685 635
9 1285 1220 1160 1100 1045 985 920 865 805 750
10 1355 1295 1235 1180 1120 1065 1010 955 895 840
11 Heat 1420 1365 1310 1255 1200 1145 1090 1040 985 930
12 1530 1480 1425 1375 1325 1275 1220 1170 1120 1070
13 1610 1555 1505 1460 1410 1360 1310 1265 1215 1165
14 1695 1645 1595 1550 1505 1460 1410 1365 1320 1275
15 1780 1730 1685 1640 1595 1550 1510 1465 1425 1380
16 1860 1815 1770 1730 1685 1645 1600 1560 1520 1480
17 1945 1905 1865 1820 1780 1745 1710 1670 1635 1595
18 Cooling 2050 2010 1970 1930 1890 1845 1795 1745 1690 1635
60100M21
1 Cont. Fan 740 640 545 455 375 295 215 140 - -
2 830 740 650 565 480 410 335 260 190 -
3 905 825 740 655 575 505 440 375 300 235
4 975 900 820 740 665 585 525 465 400 335
5 1045 975 900 820 750 675 605 550 490 430
6 1130 1065 995 925 850 780 715 650 595 540
7 1210 1145 1080 1015 945 880 815 750 690 640
8 1285 1225 1165 1105 1040 975 910 850 790 730
9 1355 1300 1240 1185 1125 1060 1000 940 880 820
10 1435 1380 1330 1275 1225 1165 1105 1045 990 935
11 1535 1480 1430 1380 1330 1280 1225 1170 1115 1060
12 1610 1560 1510 1460 1415 1365 1315 1260 1210 1160
13 Heat 1665 1620 1570 1525 1480 1430 1385 1335 1280 1235
14 1695 1650 1600 1555 1510 1465 1420 1370 1320 1270
15 1780 1735 1690 1650 1605 1560 1515 1470 1425 1380
16 1870 1830 1790 1745 1705 1665 1625 1585 1540 1500
17 1965 1925 1880 1845 1805 1770 1730 1695 1655 1615
18 Cooling 2060 2020 1980 1945 1905 1870 1820 1765 1710 1655
66100M21
1 Cont. Fan 675 565 465 375 295 200 115 - - -
2 855 770 675 595 515 440 370 295 220 150
3 950 870 785 705 630 555 490 425 360 285
4 1070 995 920 845 770 700 630 570 510 455
5 1145 1075 1005 930 860 795 730 665 605 550
6 1240 1175 1115 1045 975 910 850 790 725 670
7 1330 1270 1210 1150 1085 1020 960 900 845 785
8 1435 1380 1325 1270 1210 1150 1095 1035 980 925
9 1535 1485 1430 1380 1325 1270 1215 1160 1105 1050
10 Heat 1645 1600 1550 1500 1450 1400 1345 1295 1240 1190
11 1735 1685 1640 1590 1550 1500 1450 1400 1350 1300
12 1835 1790 1745 1700 1655 1610 1565 1520 1470 1420
13 1930 1885 1845 1800 1755 1715 1670 1625 1585 1535
14 2045 2005 1965 1925 1880 1840 1805 1760 1720 1675
15 2160 2120 2080 2040 2000 1960 1920 1885 1845 1805
16 Cooling 2195 2155 2120 2080 2040 2005 1965 1930 1890 1850
17 2265 2225 2185 2145 2110 2070 2035 2000 1960 1925
18 2370 2335 2295 2260 2220 2165 2110 2050 1990 1935
Air Delivery - CFM (with filter) (Continued)
Unit Size Airflow
Setting
Default
Setting
External Static Pressure (in. w.c.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
7
NOTE:
1. A filter is required for each return-air inlet. Airflow performance included 3/4-in. (19 mm) washable filter media such as contained in a factory - authorized accessory filter rack. See
accessory list. To determine airflow performance without this filter, assume an additional 0.1 in. w.c. available external static pressure.
2. Adjust the blower airflow settings as necessary for the proper air temperature rise for each installation.
3. Airflows over 1800 CFM require bottom return, two-side return, or bottom and side return. A minimum filter size of 20” x 25” (508 x 635 mm) is required.
4. For upflow applications, air entering from one side into both the side of the furnace and a return air base counts as a side and bottom return
5. The -- entry indicates unstable operating conditions
TYPICAL WIRING SCHEMATIC
A190079
FURNACE CONTROL BOARD
A210192
60120M24
1 Cont. Fan 770 665 545 445 355 275 185 - - -
2 830 725 615 515 425 345 265 180 130 -
3 915 815 725 615 525 445 370 295 220 165
4 990 895 810 710 620 540 465 395 325 255
5 1085 1000 915 835 740 655 580 510 445 380
6 1170 1095 1010 935 855 765 690 620 555 490
7 1235 1160 1080 1005 935 850 770 700 635 570
8 1330 1260 1190 1115 1050 980 900 820 755 695
9 1405 1335 1270 1200 1135 1070 1000 920 850 790
10 1490 1425 1365 1295 1235 1170 1110 1040 965 900
11 1585 1525 1470 1405 1340 1285 1230 1170 1105 1030
12 1665 1605 1550 1495 1435 1375 1320 1270 1210 1145
13 1750 1700 1645 1595 1535 1480 1425 1375 1320 1270
14 1835 1785 1740 1685 1630 1575 1525 1475 1430 1385
15 Heat 1880 1830 1780 1730 1680 1625 1575 1530 1480 1435
16 1920 1875 1825 1775 1730 1675 1625 1580 1535 1490
17 1995 1945 1900 1855 1810 1760 1715 1670 1625 1585
18 Cooling 2115 2065 2020 1975 1930 1875 1815 1750 1690 1630
Air Delivery - CFM (with filter) (Continued)
Unit Size Airflow
Setting
Default
Setting
External Static Pressure (in. w.c.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Airflow Settings
Default Airflow Settings*
*. Setting #1 is the default setting for Constant Fan
Designated Airflow Settings
Unit Size Heating Cooling Heating Const. Fan
36040M14 8 18 (5-8) (1-4)
36040M17 9 18 (4-9) (1-1)
36060M14 12 18 (6-14) (1-6)
42060M17 9 18 (7-14) (1-8)
48080M17 11 17 (8-14) (1-8)
60080M21 11 18 (7-14) (1-8)
60100M21 13 18 (7-16) (1-7)
66100M21 10 16 (7-12) (1-8)
60120M24 15 18 (12-16) (1-1)
115-V FIELD-
SUPPLIED
DISCONNECT
AUXILIARY
J-BOX
24-V
TERMINAL
BLOCK
THREE-WIRE
HEATING-ONLY
FIVE WIRE
NOTE 1
NOTE 2
FIELD-SUPPLIED
DISCONNECT
CONDENSING
UNIT
TWO
WIRE
FURNACE
C
O
N
T
R
O
L
R
G
COM
WCR GY
GND
GND
FIELD 24-V WIRING
FIELD 115-, 208/230-, 460-V WIRING
FACTORY 24-V WIRING
FACTORY 115-V WIRING
208/230- OR
460-V
THREE
PHASE
208/230-V
SINGLE
PHASE
BLOWER DOOR SWITCH
WHT
BLK
WHT
BLK
NOTES: Connect Y-terminal in furnace as shown for proper blower operation.
Some thermostats require a "C" terminal connection as shown.
If any of the original wire, as supplied, must be replaced, use
same type or equivalent wire.
W
Y
GND
THERMOSTAT
TERMINALS
1.
2.
3.

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
8
MAXIMUM ALLOWABLE EXPOSED VENT LENGTH
Maximum Allowable Exposed Vent Lengths in Unconditioned Space Insulation Table - Ft.
Maximum Allowable Exposed Vent Length in Unconditioned Space - Meters
Winter
Design
Temp °F
Unit Size
40,000* BTUH
*. Not all model families have this size.
60,000 BTUH
Uninsulated 3/8-in.
Insulation
1/2-in.
Insulation Uninsulated 3/8-in. Insulation 1/2-in. Insulation
Pipe Dia.
in. 1 ½ 2 2 ½ 1 ½ 2 2 ½ 1 ½ 2 2 ½ 1 ½ 2 2 ½ 3 1 ½ 2 2 ½ 3 1 ½ 2 2 ½ 3
20 20 20 20 20 50 45 20 60 50 20 30 30 25 20 75 65 60 20 85 75 65
0 10 5 5 20 25 20 20 30 25 15 15 10 10 20 40 30 25 20 45 40 30
-20 5 20 15 10 20 20 15 10 5 20 25 20 15 20 30 25 20
-40 15 10 5 15 15 10 5 20 15 15 10 20 20 15 10
Winter
Design
Temp °F
Unit Size 80,000 BTUH
Uninsulated 3/8-in. Insulation 1/2-in. Insulation
Pipe Dia. in. 1 ½ 2 2 ½ 3 4 1 ½ 2 2 ½ 3 4 1 ½ 2 2 ½ 3 4
20 15 40 40 35 30 15 50 90 75 65 15 50 70 70 70
0 15 20 15 10 5 15 50 45 35 30 15 50 50 40 35
-20 15 10 5 15 35 30 20 15 15 40 30 25 15
-40 10 5 15 25 20 15 5 15 30 25 20 10
Winter
Design
Temp °F
Unit Size 100,000 BTUH
120,000 BTUH
Uninsulated 3/8-in. Insulation 1/2-in. Insulation Uninsulated 3/8-in. Insulation 1/2-in. Insulation
Pipe Dia.
in. 2 2 ½ 3 4 2 2 ½ 3 4 2 2 ½ 3 4 2 ½ 3 4 2 ½ 3 4 2 ½ 3 4
20 20 50 40 35 20 80 95 80 20 80 105 90 10 50 40 10 75 95 10 75 105
0 20 20 15 10 20 55 45 35 20 65 55 45 10 20 15 10 55 45 10 65 50
-20 15 10 5 20 35 30 20 20 45 35 25 10 10 10 35 25 10 45 30
-40 10 5 20 25 20 10 20 30 25 15 10 5 10 25 15 10 30 20
Winter
Design
Temp °C
Unit
Size
40,000* BTUH
*. Not all model families have this size.
60,000 BTUH
Uninsulated 3/8-in.
Insulation
1/2-in.
Insulation Uninsulated 3/8-in. Insulation 1/2-in. Insulation
Pipe
Dia. mm 38 51 64 38 51 64 38 51 64 38 51 64 76 38 51 64 76 38 51 64 76
-7 6.1 6.1 6.1 6.1 15.2 13.7 6.1 18.3 15.2 6.1 9.1 9.1 7.6 6.1 22.9 19.8 18.3 6.1 25.9 22.9 19.8
-18 3.0 1.5 1.5 6.1 7.6 6.1 6.1 9.1 7.6 4.6 4.6 3.0 3.0 6.1 12.2 9.1 7.6 6.1 13.7 12.2 9.1
-29 1.5 6.1 4.6 3.0 6.1 6.1 4.6 3.0 1.5 6.1 7.6 6.1 4.6 6.1 9.1 7.6 6.1
-40 4.6 3.0 1.5 4.6 4.6 3.0 1.5 6.1 4.6 4.6 3.0 6.1 6.1 4.6 3.0
Winter
Design
Temp °C
Unit
Size
80,000 BTUH
Uninsulated 3/8-in. Insulation 1/2-in. Insulation
Pipe
Dia. mm 38 51 64 76 102 38 51 64 76 102 38 51 64 76 102
-7 4.6 12.2 12.2 10.7 9.1 4.6 15.2 27.4 22.9 19.8 4.6 15.2 21.3 21.3 21.3
-18 4.6 6.1 4.6 3.0 1.5 4.6 15.2 13.7 10.7 9.1 4.6 15.2 15.2 12.2 10.7
-29 4.6 3.0 1.5 4.6 10.7 9.1 6.1 4.6 4.6 12.2 9.1 7.6 4.6
-40 3.0 1.5 4.6 7.6 6.1 4.6 1.5 4.6 9.1 7.6 6.1 3.0
Winter
Design
Temp
°C
Unit
Size
100,000 BTUH 120,000 BTUH
Uninsulated 3/8-in. Insulation 1/2-in. Insulation Uninsulated 3/8-in.
Insulation
1/2-in.
Insulation
Pipe
Dia.
mm
51 64 76 102 51 64 76 102 51 64 76 102 64 76 102 64 76 102 64 76 102
-7 6.1 15.2 12.2 10.7 6.1 24.4 28.9 24.4 6.1 24.4 32.0 27.4 3.0 15.2 12.2 3.0 22.9 28.9 3.0 22.9 32.0
-18 6.1 6.1 4.6 3.0 6.1 16.8 13.7 10.7 6.1 19.8 16.7 13.7 3.0 6.1 4.6 3.0 16.8 13.7 3.0 19.8 15.2
-29 4.6 3.0 1.5 6.1 10.7 9.1 6.1 6.1 13.7 10.7 7.6 3.0 3.0 3.0 10.7 7.6 3.0 13.7 9.1
-40 3.0 1.5 6.1 7.6 6.1 3.0 6.1 9.1 7.6 4.6 3.0 1.5 3.0 7.6 4.6 3.0 9.1 6.1

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
9
Maximum Equivalent Vent Length - Ft. (M)
NOTE: Maximum Equivalent Vent Length (MEVL) includes standard and concentric vent termination and does NOT include elbows. Use Deductions
from Maximum Equivalent Vent Length to determine allowable vent length for each application.
1. 40K Inducer Outlet Restrictor disk (P/N 337683-401; 1.25-in. (32 mm) Dia.) shipped in the loose parts bag or available through Replacement Components required under 10-ft. (3 M)
TEVL in all orientations. Required for installations from 0 - 2000 ft. (0 to 610 M) above sea level. Failure to use an outlet restrictor may result in flame disturbances or flame sense
lock-out.
2. 60K Inducer Outlet Restrictor disk (P/N 3337683-401; .25-in. (32 mm) Dia. available through Replacement Components) required for less than 5-ft. (1.5 M) TEVL in downflow and
horizontal orientations only. Required for installations from 0 - 2000 ft. (0 to 610 M) above sea level.
3. 120K Inducer Outlet Restrictor disk (P/N 337683-402; 1.50-in. (38 mm) Dia. available through Replacement Components) required for less than 5-ft. (1.5 M) TEVL in downflow and
horizontal orientations only. Required for installations from 0 - 2000 ft. (0 to 610 M) above sea level.
A13110
Deductions from Maximum Equivalent Vent Length - Ft. (M)
NOTE:
1. Use only the smallest diameter pipe possible for venting. Over-sizing may cause flame disturbance or excessive vent terminal icing or freeze-up.
2. NA - Not allowed. Pressure switch will not close, or flame disturbance may result.
3. Vent sizing for Canadian installations over 4500 ft (1370 M) above sea level are subject to acceptance by local authorities having jurisdiction.
4. Size both the combustion air and vent pipe independently, then use the larger size for both pipes.
5. Assume the two 45_ elbows equal one 90_ elbow. Wide radius elbows are desirable and may be required in some cases.
6. Elbow and pipe sections within the furnace casing and at the vent termination should not be included in vent length or elbow count.
7. The minimum pipe length is 5 ft. (2 M) linear feet (meters) for all applications.
8. Use 3-in. (76 mm) diameter vent termination kit for installations requiring 4-in. (102 mm) diameter pipe
Unit Size 40,000 1 60,000 280,000 100,000 3120,000
Altitude
(feet)
Pipe Dia.
(in) 1 ½22 ½1 ½22 ½31 ½22 ½3 4 2 2 ½3 4 2 ½3 4
0-2000 20 85 185 20 100 175 200 15 55 130 175 200 20 80 175 200 10 75 185
2001-3000 15 80 175 95 165 185
10
49 125 165 185 15 75 165 185 70 175
3001-4000
70
160 16 90 155 175 115 155 175 155 175 5 65 165
4001-4500
10
155
15
85 150 170 44 110 150 165
10
70 170
N/A
60 160 4501-5000 145 80 145 165 145 160 65 150 165
5001-6000 60 130 75 140 155 41 100 135 150 140 155 155
6001-7000 555 120 13 70 130 145
N/A
38 90 125 140 60 135 145 50 140
7001-8000 50 110 10 65 120 135 36 120 125
N/A
55 125 135 46 130
8001-9000 N/A 30 95 5 60 115 125 33 80 110 115 50 115 125 43 120
9001-10000 25 85 N/A 55 105 115 30 75 100 105 45 100 115 39 115
Maximum Equivalent Vent Length - Meters
Unit Size 40,000 160,000 280,000 100,000 3120,000
Altitude
(meters)
Pipe Dia.
(mm) 38 51 64 38 51 64 76 38 51 64 76 102 51 64 76 102 64 76 102
0-610 6.0 25.9 56.3 6.0 30.4 53.3 60.9 4.5 16.7 39.6 53.3 60.9 6.0 24.3 53.3 60.9 3.0 22.8 56.3
611-914 4.5 24.3 53.3 28.9 50.2 56.3
3.0
14.9 38.1 50.2 56.3 4.5 22.8 50.2 56.3 21.3 53.3
915-1219
21.3
48.7 4.8 27.4 47.2 53.3 35.0 47.2 53.3 47.2 53.3 1.5 19.8 50.2
1220-1370
3.0
47.2
4.5
25.9 45.7 51.8 13.4 33.5 45.7 50.2
3.0
21.3 51.8
NA
18.2 48.7 1371-1524 44.1 24.3 44.1 50.2 44.1 48.7 19.8 45.7 50.2
1525-1829 18.2 39.6 22.8 42.6 47.2 12.4 30.4 41.1 45.7 42.6 47.2 47.2
1830-2134 1.5 16.7 36.5 3.9 21.3 39.6 44.1
NA
11.5 27.4 38.1 42.6 18.2 41.1 44.1 15.2 42.6
2135-2438 15.2 33.5 3.0 19.8 36.5 41.1 10.9 36.5 38.1
NA
16.7 38.1 41.1 14.0 39.6
2439-2743 N/A 9.1 28.9 1.5 18.2 35.0 38.1 10.0 24.3 33.5 35.0 15.2 35.0 38.1 13.1 36.5
2744-3048 7.6 25.9 NA 16.7 32.0 35.0 9.1 22.8 30.4 32.0 13.7 30.4 35.0 11.8 35.0
Pipe Diameter (in): 1-1/2 2 2-1/2 3 4
Mitered 90º Elbow 8 (2.4) 8 (2.4) 8 (2.4) 8 (2.4) 8 (2.4)
Medium Radius 90º Elbow 5 (1.5) 5 (1.5) 5 (1.5) 5 (1.5) 5 (1.5)
Long Radius 90º Elbow 3 (0.9) 3 (0.9) 3 (0.9) 3 (0.9) 3 (0.9)
Mitered 45º Elbow 4 (1.2) 4 (1.2) 4 (1.2) 4 (1.2) 4 (1.2)
Medium Radius 45º Elbow 2.5 (0.8) 2.5 (0.8) 2.5 (0.8) 2.5 (0.8) 2.5 (0.8)
Long Radius 45º Elbow 1.5 (0.5) 1.5 (0.5) 1.5 (0.5) 1.5 (0.5) 1.5 (0.5)
Tee 16 (4.9) 16 (4.9) 16 (4.9) 16 (4.9) 16 (4.9)
Concentric Vent Termination NA 0 (0.0) NA 0 (0.0) NA
Standard Vent Termination 0 (0.0) 0 (0.0) 0 (0.0) 0 (0.0) 0 (0.0)
Long Medium Mitered
Concentric
Standard 2-in., 3-in., or
optional 4-in. termination.
ELBOW CONFIGURATIONS VENT TERMINAL CONFIGURATIONS

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
10
Venting System Length Calculations
The Total Equivalent Vent Length (TEVL) for EACH combustion air or vent pipe equals the length of the venting system, plus the equivalent length of
elbows used in the venting system from Deductions from Maximum Equivalent Vent Length - Ft. (M) Table.
Standard vent terminations or factory accessory concentric vent terminations count for zero deduction.
See vent system manufacturer’s data for equivalent lengths of flexible vent pipe or other termination systems. DO NOT ASSUME that one foot of
flexible vent pipe equals one foot of straight PVC/ABS DWV vent pipe.
Compare the Total Equivalent Vent Length to the Maximum Equivalent Vent Lengths in Maximum Equivalent Vent Length Table.
Example 1
A direct-vent 60,000 BTUH furnace installed at 2100 ft. (640M). Venting system includes FOR EACH PIPE:
70 feet (22 M) of vent pipe, 65 feet (20 M) of combustion air inlet pipe, (3) 90º long-radius elbows, (2) 45º long-radius elbows, and a factory accessory
concentric vent kit.
Can this application use 2” (50 mm ND) PVC/ABS DWV vent piping?
Example 2
A direct-vent 60,000 BTUH furnace installed at 2100 ft. (640M). Venting system includes FOR EACH PIPE:
100 feet (30 M) of vent pipe, 95 feet (29 M) of combustion air inlet pipe, (3) 90º long-radius elbows, and a polypropylene concentric vent kit. Also
includes 20 feet (6.1 M) of flexible polypropylene vent pipe, included within the 100 feet (30 M) of vent pipe.
VERIFY FROM POLYPROPYLENE VENT MANUFACTURER’S INSTRUCTIONS for the multiplier correction for flexible vent pipe.
Can this application use 60mm o.d. (2”) polypropylene vent piping? If not, what size piping can be used?
Measure the required linear length of air inlet and vent
pipe; insert the longest of the two here 70 ft. (22 M)
Use length of the longer of the vent
or air inlet piping system
Add equiv length of (3) 90º long-radius elbows
(use the highest number of elbows for either the vent or
inlet pipe)
3 x 3 ft.
(0.9 M) =9 ft. (2.7 M)
From Deductions from Maximum Equivalent
Vent Length - Ft. (M) Table.
Add equiv length of (2) 45º long-radius elbows
(use the highest number of elbows for either the vent or
inlet pipe)
2 x 1.5 ft.
(0.5 M) =3 ft. (0.9 M)
From Deductions from Maximum Equivalent
Vent Length - Ft. (M) Table.
Add equiv length of factory concentric vent term 0 ft. From Deductions from Maximum Equivalent
Vent Length - Ft. (M) Table.
Add correction for flexible vent pipe, if any 0 ft. From Vent Manufacturer’s
instructions; zero for PVC/ABS DWV
Total Equivalent Vent Length (TEVL) 82 ft.
(25 M) Add all of the above lines
Maximum Equivalent Vent Length (MEVL) 95 ft.
(29 M)
For 2” pipe from Maximum Equivalent Vent
Length Table.
Is TEVL less than MEVL? YES Therefore, 2” pipe MAY be used
Measure the required linear length of RIGID air inlet and vent pipe; insert the longest of the
two here: 100 ft. Of rigid pipe - 20 ft. Of flexible pipe = 80 ft. (24 M)
Use length of the longer of the vent
or air inlet piping system
Add equiv length of (3) 90º long-radius elbows (use the
highest number of elbows for either the vent or inlet pipe) 3 x 5 ft. (1.5 M) =15 ft. (4.6 M)
Example from polypropylene vent
manufacturer’s instructions, Verify from vent
manufacturer’s instructions.
Add equiv length of 45º long-radius elbows
(use the highest number of elbows for either the vent or
inlet pipe)
0 x = 0 ft.
(0 M)
Add equiv length of factory concentric vent term 9 x 3.3 ft
(0.9 M) =30 ft. (9 M)
Add correction for flexible vent pipe, if any 2* x 20 ft.
(6.1 M) =40 ft. (12.2 M)
* VERIFY FROM VENT MANUFACTURER’S INSTRUCTIONS; For example only, assume 1 meter of flexible 60mm (2”) or 80mm (3”) polypropylene
pipe equals 2.0 meters (6.5 ft.) of PVC/ABS pipe.
Total Equivalent Vent Length (TEVL) 165 ft.
(50 M) Add all of the above lines
Maximum Equivalent Vent Length (MEVL) 95 ft.
(29 M)
For 2” pipe from Maximum Equivalent Vent
Length Table.
Is TEVL less than MEVL? NO Therefore, 60mm (2”) pipe may NOT be
used; try 80mm (3”)
Maximum Equivalent Vent Length (MEVL) 185 ft.
(57 M)
For 3” pipe from Maximum Equivalent Vent
Length Table.
Is TEVL less than MEVL? YES Therefore, 80mm (3”) pipe MAY be used

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
11
RETURN AIR TEMPERATURE
This furnace is designed for continuous return-air minimum temperature
of 60_F (15_C) db or intermittent operation down to 55_F (13_C) db
such as when used with a night setback thermometer. Return-air
temperature must not exceed 80_F (27_C) db. Failure to follow these
return air limits may affect reliability of heat exchangers, motors and
controls.
A10490
COMBUSTION-AIR PIPE FOR NON-DIRECT
(1-PIPE) VENT APPLICATION
A12376
NOTE: See Installation Instructions for specific venting configurations.
DOWNFLOW SUBBASE
A97427
A88207
Downflow Subbase
A88202
One base fits all furnace sizes. The base is designed to be installed
between the furnace and a combustible floor when no coil box is used or
when a coil box other than a Bryant cased coil is used. It is CSA design
certified for use with Bryant branded furnaces when installed in
downflow applications.
Concentric Vent Kit
A93086
A concentric vent kit allows vent and combustion-air pipes to terminate
through a single exit in a roof or side wall. One pipe runs inside the other
allowing venting through the inner pipe and combustion air to be drawn
in through the outer pipe.
60
80 / 27˚
C
/ 16˚C
SUPPLY AIR
FIELD-SUPPLIED
2-IN. (51 mm) DIA.
PVC PIPE
FIELD-SUPPLIED
2-IN. (51 mm) DIA.
MITERED RADIUS
PVC 90°ELBOW
12” (300 mm) MINIMUM
C
A
1
1
/
4-IN. TYP
PLENUM
OPENING
FACTORY-SUPPLIED
FIELD-INSTALLED
INSULATION
LOCATING
TAB
LOCATING
TAB
1234
4321
B
D
DIMENSIONS (IN. / MM)
FURNACE
CASING
WIDTH
FURNACE IN DOWNFLOW APPLICATION
PLENUM OPENING*
*. The plenum should be constructed 1/4-in. (6 mm) smaller in width and depth than the plenum dimensions shown above.
FLOOR OPENING HOLE NO. FOR
WIDTH
ADJUSTMENT
A B C D
14-3/16 (360) Furnace with or without Cased Coil Assembly or
Coil Box 11-3/16 (322) 19 (483) 13-7/16 (341) 20-5/8 (600) 4
17-1/2 (445) Furnace with or without Cased Coil Assembly or
Coil Box 15-1/8 (384) 19 (483) 16-3/4 (426) 20-5/8 (600) 3
21 (533) Furnace with or without Cased Coil Assembly or
Coil Box 18-5/8 (396) 19 (483) 20-1/4 (514) 20-5/8 (600) 2
24-1/2 (622) Furnace with or without Cased Coil Assembly or
Coil Box 22-1/8 (562) 19 (483) 23-3/4 (603) 20-5/8 (600) 1

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
12
MEDIA FILTER CABINET (OPTIONAL
ACCESSORY)
A12428
ACCESSORIES
Media Filter
Cabinet AB
16" (406mm)
20" (508mm)
24" (610mm)
17" (432mm)
Furnace Side
Centerline Screw Slots
23-3/4”
23-3/8”
23-5/8"
5
34
Duct Side
Opening
Opening with Flanges Bent
24-1/4”
25-5/8"
B Opening
A
"
(600mm)
(594mm)
(603mm)
(146mm)
(651mm)
(616mm)
23-1/8”
(588mm)
16" (406mm)
20" (508mm)
24" (610mm)
21" (533mm)
25" (635mm)
NOTE: Media cabinet is matched to the bottom opening on furnace. May also be used for side return.
PART NUMBER DESCRIPTION 36040M14 36040M17 36060M14 42060M17
P908-0001*
*. Purchased through Replacement Components
Condensate Neutralizer Kit X X X X
92-1003*Gas Valve Tower Port Adapter Kit X X X X
ACG1425NCB*External Filter Rack, 14-1/2 x 25” X - X -
ACG1625NCF*External Filter Rack, 16 x 25” - X - X
325531-402*Washable filter, 3/4” x 16” x 25” XXXX
KGADA0101ALL Coil Adapter Kits - No Offset X X X X
KGADA0201ALL Coil Adapter Kits - Single Offset X X X X
KGADA0301ALL Coil Adapter Kits - Double Offset X X X X
KGARP0301B14 Return Air Base (Upflow Applications) 14” wide X - X -
KGARP0301B17 Return Air Base (Upflow Applications) 17-1/2” wide - X - X
KGADC0101BVC Vent Kit - Through the Cabinet X X X X
KGAVT0701CVT Vent Terminal - Concentric - 2” (51 mm)
See Venting Tables
KGAVT0801CVT Vent Terminal - Concentric - 3” (76 mm)
KGAVT0101BRA Vent Terminal Bracket - 2” (51 mm)
KGAVT0201BRA Vent Terminal Bracket - 3” (76 mm)
KGAAC0101RVC Vent Kit - Rubber Coupling
KGAHT0101CFP Freeze Protect Kit - Condensate Drain Line Tape X X X X
KGAHT0201CFP Freeze Protect Kit - Condensate Trap with Heat Pad X X X X
KGAAD0110PVC CPVC to PVC Drain Adapters - 1/2” CPVC to 3/4” PVC X X X X
KGACK0101HCK Horizontal Trap Grommet - Direct Vent All 2-Pipe Horizontal
KGAET0201ETK External Trap Kit X X X X
KGASB0201ALL Downflow Furnace Base Kit for Combustible Floors X X X X
KGAAD0101MEC IAQ Device Duct Adapters 20.0-in. IAQ to 16 in. Side Return 20”x25” IAQ Devices
KGAAD0201MEC IAQ Device Duct Adapters 24.0-in. IAQ to 16 in. Side Return 24”x25” IAQ Devices
AGAGC9NPS01C*Gas Conversion Kit - Nat to LP†
†. Factory-authorized and field installed. Fuel conversion kits are CSA recognized.
X = Accessory
XXXX
AGAGC9PNS01C*Gas Conversion Kit - LP to Nat†XXXX
AGAGCAMHC01A Manufactured Home Kit - Gas Conversion†XXXX
AGATWNDTE01B Twinning Kit - (MCT) ECM Motor - - - X

912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
13
ACCESSORIES (continued)
ACCESSORIES (continued)
Bryant has a wide variety of thermostats for your system, please visit www.Bryant.com to see all thermostat and IAQ products.
PART NUMBER DESCRIPTION 48080M17 60080M21 60100M21 66100M21 60120M24
P908-0001*
*. Purchased through Replacement Components
Condensate Neutralizer Kit X X X X X
92-1003*Gas Valve Tower Port Adapter Kit X X X X X
ACG1625NCF*External Filter Rack, 16 x 25” X - - - -
ACG2025NCJ*External Filter Rack, 20 x 25”*- X X X -
ACG2424NCL*External Filter Rack, 24-1/2 x 24”*----X
325531-402*Washable filter, 3/4” x 16” x 25” X - - - -
325531-403*Washable filter, 3/4” x 20” x 25” - X X X -
325531-404*Washable filter, 3/4” x 24” x 25” - - - - X
KGADA0101ALL Coil Adapter Kits - No Offset X X X X X
KGADA0201ALL Coil Adapter Kits - Single Offset X X X X X
KGADA0301ALL Coil Adapter Kits - Double Offset X X X X X
KGARP0301B17 Return Air Base (Upflow Applications) 17-1/2” wide X - - - -
KGARP0301B21 Return Air Base (Upflow Applications) 21” wide - X X X -
KGARP0301B24 Return Air Base (Upflow Applications) 24-1/2 wide - - - - X
KGAVT0701CVT Vent Terminal - Concentric - 2” (51 mm)
See Venting Tables
KGAVT0801CVT Vent Terminal - Concentric - 3” (76 mm)
KGAVT0101BRA Vent Terminal Bracket - 2” (51 mm)
KGAVT0201BRA Vent Terminal Bracket - 3” (76 mm)
KGADC0101BVC Vent Kit - Through the Cabinet for HZ left/right ONLY X X X X X
KGAAC0101RVC Polypropylene Inlet Air Pipe Coupling X X X X X
KGAHT0101CFP Freeze Protect Kit - Condensate Drain Line Tape X X X X X
KGAHT0201CFP Freeze Protect Kit - Condensate Trap with Heat Pad X X X X X
KGAAD0110PVC CPVC to PVC Drain Adapters - 1/2” CPVC to 3/4” PVC X X X X X
KGACK0101HCK Horizontal Trap Grommet - Direct Vent All 2-Pipe Horizontal
KGAET0201ETK External Trap Kit X X X X X
KGASB0201ALL Downflow Furnace Base Kit for Combustible Floors X X X X X
KGAAD0101MEC IAQ Device Duct Adapters 20” IAQ to 16” Side Return 20”x25” IAQ Devices
KGAAD0201MEC IAQ Device Duct Adapters 24” IAQ to 16” Side Return 24”x25” IAQ Devices
AGAGC9NPS01C*Gas Conversion Kit - Nat to LP†
†. Factory-authorized and field installed. Fuel conversion kits are CSA (formerly AGA/CGA) recognized.
X = Accessory
XXXXX
AGAGC9PNS01C*Gas Conversion Kit - LP to Nat†XXXXX
AGAGCAMHC01A Manufactured Home Kit - Gas Conversion†XXXXX
AGATWNDTE01B Twinning Kit - (MCT) ECM Motor X X X - X
KGAPC0101ECM Lower Amp Kit - X X X -
DESCRIPTION
Gas Orifice Kit - #42 (Nat Gas) LH32DB207
See Installation Instructions for model,
altitude, and heat value usages.
Gas Orifice Kit - #43 (Nat Gas) LH32DB202
Gas Orifice Kit - #44 (Nat Gas) LH32DB200
Gas Orifice Kit - #45 (Nat Gas) LH32DB205
Gas Orifice Kit - #46 (Nat Gas) LH32DB208
Gas Orifice Kit - #47 (Nat Gas) LH32DB078
Gas Orifice Kit - #48 (Nat Gas) LH32DB076
Gas Orifice Kit - #54 (LP) LH32DB203
Gas Orifice Kit - #55 (LP) LH32DB201
Gas Orifice Kit - #56 (LP) LH32DB206
Gas Orifice Kit - 1.25mm (LP) LH32DB209
Gas Orifice Kit - 1.30mm (LP) LH32DB210
DESCRIPTION ACCESSORY
HUMIDIFIER Model HUM
HEAT RECOVERY VENTILATOR Model HRV
ENERGY RECOVERY VENTILATOR Model ERV
UV LIGHTS Model UVL

© 2022 Carrier. All rights reserved.
A Carrier Company
Edition Date: 08/22 Catalog No:PDS912SE-01 REV A
Replaces: PDS912SE-01
912SE: Product Data
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
14
ACCESSORIES (continued)
DESCRIPTION ACCESSORY 14” 17” 21” 24”
Bryant Carbon Monoxide Alarm (10 pack) COALMBBNRB02-A10 X X X X
Bryant Evolution Air Purifier - 16x25 (407x635 mm) DGAPAXX1625 X X - -
Bryant Evolution Air Purifier - 20x25 (508x635 mm) DGAPAXX2025 - - X X
Bryant Evolution Air Purifier Repl. Filter- 16x25 (407x635 mm) PGAPXCAR1625A02 X X - -
Bryant Evolution Air Purifier Repl. Filter- 20x25 (508x635 mm) PGAPXCAR2025A02 - - X X
Cartridge Media Filter - 16” (407 mm) (MERV 11) FILXXCAR0116 X X - -
Cartridge Media Filter - 16” (407 mm) (MERV 8) FILXXCAR0016 X X - -
Cartridge Media Filter - 20” (508 mm) (MERV 8) FILXXCAR0020 - - X -
Cartridge Media Filter - 20” (508 mm) (MERV11) FILXXCAR0120 - - X -
Cartridge Media Filter - 24” (610 mm) (MERV 8) FILXXCAR0024 - - - X
Cartridge Media Filter - 24” (610 mm) (MERV11) FILXXCAR0124 - - - X
EZ Flex Cabinet Side or Bottom - 16” EZXCAB--0016 X X - -
EZ Flex Cabinet Side or Bottom - 20” EZXCAB--0020 - - X X
EZ Flex Replacement Filters 16” MERV 10 EXPXXFIL0016 X X - -
EZ Flex Replacement Filters 16” MERV 13 EXPXXFIL0316 X X - -
EZ Flex Replacement Filters 20” MERV 10 EXPXXFIL0020 - - X -
EZ Flex Replacement Filters 20” MERV 13 EXPXXFIL0320 - - X -
EZ Flex Replacement Filters 24” MERV 10 EXPXXFIL0024 - - - X
EZ Flex Replacement Filters 24” MERV 13 EXPXXFIL0324 - - - X
EZ-Flex Filter with End Caps - 16” (407 mm) (MERV 10) EXPXXUNV0016 X X - -
EZ-Flex Filter with End Caps - 16” (407 mm) (MERV 13) EXPXXUNV0316 X X - -
EZ-Flex Filter with End Caps - 20” (508 mm) (MERV 10) EXPXXUNV0020 - - X -
EZ-Flex Filter with End Caps - 20” (508 mm) (MERV 13) EXPXXUNV0320 - - X -
EZ-Flex Filter with End Caps - 24” (610 mm) (MERV 10) EXPXXUNV0024 - - - X
EZ-Flex Filter with End Caps - 24” (610 mm) (MERV 13) EXPXXUNV0324 - - - X
Media Filter Cabinet - 20” FILCABXL0020 - - X -
Media Filter Cabinet - 24” FILCABXL0024 - - - X
Media Filter Cabinet - 16” FILCABXL0016 X X - -
