CamFive EMB HT1501 User manual

HT1501 / HT1502
INSTALLATION
MANUAL

2
Unboxing
Pág.
Pág.
Pág.
Pág. Pág.
Mounting the Base
Mounting the Worktable
Installing
the thread Rack
Installing
the thread Rack
3
4
6
12 14

3
Unboxing
On all four sides of the
crate there are bolts as
seen below that need
to be removed prior to
unboxing your new 1501
embroidery.
Once all bolts
are removed,
two people are
required in order
to lift the box
o of the base
and then the
machine can be
unwrapped.
2
1

4
Mounting the Base
The 1501 embroidery
machine comes
with a base,
and a worktable
that needs to be
mounted prior to
using the machine.
The parts should
look like this:
In order to
mount the base
you will need
the following to
secure the base
properly:
1
2

5
Prompt the two
sides with wheels
and use the
bigger piece for
the bottom of
the base. Once
the bottom of the
base is secured
and tightened, you
are able to use
the two smaller
parts for the sides
of the base as
shown below:
The finished
base should
look like this:
3
4

6
Mounting the Worktable
If you require
the worktable,
in order to mount
it you need to
use the following
parts to complete
the table:
1
Worktable x1
Table Locks x8

7
2
Table Lock Plates x6
Screws x44
Once the plates
and table locks
are screwed into
the worktable,
the final
outcome should
look like this:

8
3
Now with the
assistance of
another person,
you must lift the
machine onto the
base, remember
to place the
four black round
washers prior
to mounting
the machine
and secure the
machine to the
base with these
bolts:
The Washers will
looks like this
and it is fastened
through the
bottom once the
machine is placed
on the base.

9
4
In order to
place the
worktable onto
the embroidery
machine, you
must first
remove the hat
hoop if it is on:
Once the
screw
is loose,
twsit and
pull the
hat hoop
o

10
5
7
6
Now slide the
table with the
nose towards
the machine, flat
surface on top
and table locks on
the bottom.
Fasten
the table
in the
bottom:
Then use
the following
screws in order
to screw the
table in place:

11
8
The
machine
should
now look
like this:

12
Installing the thread Rack
There is a
box that has
the following
parts below, in
that box you
will find the
components
for the thread
rack:
Find the
four metal
poles, and
fasten
them to the
top of the
machine:
1
2

13
Once all four
poles are
installed onto
the top of
the machine,
unscrew the
bolts from the
top of each
pole, and place
the thread rack
on top
Secure thread rack with bolts
removed from the pole:
3
4
The machine should now look like this:
5

14
Threading
The thread tube
should already
be clipped on the
bottom like this:
Now make sure that
the thread tube is
connected on top the
same way, and when
putting the thread
through the hole make
sure that the thread
lies behind the metal
plate like this:
1
2

15
Now the
order of the
thread from
right to left is
as follows:
31
1,2
1,2,3
Then it repeats itself. That is the order of holes that each
needle thread has to go through in the thread rack, in the end
it should look like this:
And like this:

16
Now it’s
time to
put all the
thread on
the thread
holders:
Now, tie the
thread coming
from the
hose onto the
respective
thread that is
on the holder
4
5
*the colors don’t have to be the same, it can be placed however you
need them to be

17
Pull the thread
from the front
all the way until
the knot you
tied comes all
the way through
and cut the
thread in order
to place the
thread through
the needle:
6

18
Once the
thread is
through
the needle,
pull the
thread
under the
stepper:
Make sure
the thread
is behind
the small
hook that
is on top of
the stepper:
7
8

19
9
10
Repeat the
steps until all
needles are
threaded.
Finally, use the
power cord to
connect the
embroidery
machine in the
back, turn the
switch on the
side, and you are
ready to begin.
