CDA CI327 Quick start guide

CI327
Integrated washing machine
Installation, use and maintenance

2
Contents:
3 Important information
5 - 6 Safety warnings
7 Recommendations
8 Before first use
10 Detergents and additives
11 Eco note and loading the washing machine
12 Control panel and programmes
13 Programme table
14 Programme details
16 Starting a wash programme & features
21 Choice of detergent
22 Care and maintenance
23 Cleaning the filter
25 Detergent drawer
26 - 28 Practical (cleaning) information
29 Display and failure codes
30 Troubleshooting
32 Installation (including transit bolt information)
33 Levelling
34 Connecting to the mains water supply
34 Drainage connection
35 Electrical information
37 Fitting the appliance
38 Fitting the furniture door
41 Final installation checks
42 Technical specifications
42 International washing symbols
43 Warranty and service

3
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic use. Any other use could be dangerous and
may lead to premature failure of the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note that
CDA reserve the right to invalidate the guarantee supplied with this
product following incorrect installation or misuse of the appliance.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel. Do
not use the appliance if the plug, the mains cord or the appliance
itself is damaged. If the mains cord is damaged, you must have it
replaced by the manufacturer, or an authorised service centre or
similarly qualified person in order to avoid a hazard.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
EU Declarations of Conformity:
This appliance meets the requirements of all applicable EU directives
with the corresponding harmonised standards which provide for CE
marking.

4
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.

5
Safety warnings
• If the plug or cord is damaged, do not connect the appliance to the
mains power supply. If the cord is damaged it should be replaced
by the manufacturer or appointed service agent in order to avoid a
hazard. If the appliance is damaged, contact your retailer.
• To remove the plug from the socket, pull on the body of the plug,
not the cable.
• Do not plug the appliance in to the mains power supply with wet or
damp hands, or when the sockets are wet or damp.
• Never touch the appliance with wet hands or feet.
• Never open the detergent drawer when a programme is running.
• Never force the appliance door open when a programme is running.
• Since the appliance can reach high temperatures while running, do
not touch the drain hose or drained water during draining.
• In case of any failure, first unplug the appliance and close the
water tap.
• Repair on this appliance should only be undertaken by suitably
qualified personnel.
• Keep the packing materials away from children to prevent risk
of injury.
• Do not let children play with the washing machine.
• Keep pets away from the appliance.
• The appliance should not be installed on carpeted surfaces as this
can block the air ventilation on the base.

6
Warnings
To avoid the risk of fire, electric shocks, injury or damage when using
your washing machine, please take the following precautions:
• Please read all the instructions before using the washing machine.
• Do not wash items that have previously been cleaned, washed,
soaked or treated with petrol, solvents for dry cleaning, other
inflammable substances or explosives, as they produce fumes that
could catch fire or explode.
• Do not add petrol, solvents for dry cleaning or other inflammable or
explosive substances to the wash water as they produce fumes that
could catch fire or explode.
• Do not repair or replace any part of the washing machine or try
to carry out any type of servicing unless it is recommended in the
maintenance instructions in the manual.
• Do not climb onto the machine or stand on the open porthole door.
• Do not use an extension lead or adaptor to connect your washing
machine to the mains supply.
• Follow the washing instructions recommended by the manufacturer
of the garment to be washed.
• Do not turn your washing machine on until you are sure that:
It has been installed in accordance with the installation instructions.
All the water, drainage, mains electricity and earth connections
meet the local regulations and/or other applicable
regulations.
Important: Ensure that the transit bolts have been removed prior
to using the machine (see page 32).

7
Recommendations
• Residues of detergent or softener left in the detergent drawer for
long periods will dry and stick to the detergent drawer. To prevent
this put the detergent and softener into the detergent drawer just
before washing.
• It is recommended that the pre-wash programme should only be
used for very dirty clothes.
• Do not exceed the maximum loading capacity.
• When the machine is not in use, keep the water tap closed.
• The appliance is not intended for use by people (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised
to ensure that they do not play with the appliance.
• If the appliance is not to be used for prolonged periods of time,
unplug the appliance, close the water tap and leave the door ajar
to keep the inside of the machine dry and to prevent unpleasant
odours from developing.
• As a result of the quality control procedures during production, a
certain amount of water may remain in the appliance. This is normal
and does not signify a fault.
• Do not remove the rating plate. The information on it is important.
• This appliance should not be installed in locations where
the ambient temperature may fall below 0°C. Use in ambient
temperatures below 0°C may damage the machine.
• The most energy and water ecient wash programmes are
generally those that run at a low temperature and for a long time.
• Loading the washing machine to the full capacity indicated by the
manufacturer for the respective wash programmes will save energy
and water

8
Before first use
When your washing machine has been correctly installed, we
recommend that you pre-clean the machine.
This is to check that the installation, the connections and the drainage
are all correct, and to thoroughly clean the inside of the washing
machine before any wash programmes are run.
Prior to pre-cleaning you should ensure the transit bolts have been
removed.
• Select the Cotton 90ºC programme (programme M) and add a
normal dose of detergent into the detergent dispenser.
• Press the “Start / Pause” button.
Preparing garments for washing
• Wash lightly soiled garments using a short programme.
• Use a programme without prewash for medium-soiled garments.
• Wash heavily soiled garments using a long programme with
prewash.
• Wash white and coloured loads separately.
• We recommend that small garments are placed in a wash bag.
• We recommend using the delicate programmes for sensitive fabrics.
• Separate clothes according to their types (cotton, synthetic,
sensitive, woollen, etc.), required washing temperatures and level of
dirtiness.
• Since new coloured clothes may shed dye on the first wash, wash
them separately.
• Remove any foreign objects found on the items to be washed, for
example curtain hooks and wires.

9
• Fasten all zips and buttons.
• Turn garments, such as knitted fabrics, inside out.
• Before placing the clothes in the drum, make sure all the pockets
are empty. Any small objects may block the drain pump.
• We recommend loading the washing machine to its full capacity for
best water and energy eciency.
• Whenever possible, we recommend that you wash garments of
dierent sizes within the same wash programme. This improves
the washing action and also aids the correct distribution of the
garments in the drum when spin-drying, and the washing machine
will therefore be quieter.

10
Detergents and
additives
Your washing machine’s detergent
dispenser has three sections as
shown in figure 1.
Add the required amount of
detergent and fabric softener
into the specific sections of the
detergent dispenser before
starting the wash programme.
The detergent dispenser is
designed to allow the use of liquid detergents rather than adding
them to the drum. You should only insert liquid detergent into the
main wash detergent compartment and ensure that concentrated
liquid detergent is diluted with an equal quantity of water before use.
• Liquid detergent should not be used on programmes with a
prewash stage or when using the delay timer.
• For wash loads that require pre-washing, add ¼ of the required
powder detergent into the prewash section, and the remainder to
the main detergent section.
• Do not exceed the “MAX” level in the fabric softener section and
ensure that concentrated fabric softeners are diluted before use
for best washing results and to help prevent clogging.
• Remember that the amount of detergent to be used will always
depend on:
1 Prewash
2 Main wash
Fabric Softener
Fig. 1

11
• The amount of clothes to be washed.
• How heavily the clothes are soiled.
• The hardness of the water (Information on water hardness in your
area can be obtained from your local water board).
We recommend the use of a decalcifying product if the water
hardness is high in your area.
Eco note
The use of more detergent than necessary will not improve your
washing results. Many brands of detergent (and fabric softener/
conditioner) contain phosphates which escape sewage treatment
and can cause excessive algae growth in waterways. This in turn
can pollute drinking water and cause marine life ‘dead zones’
which are underwater environments deprived of oxygen that
are subsequently unable to support life. Please consider the
environment and try to source an environmentally friendly brand.
Loading the washing machine
- Open the door.
- Remove any foreign objects from the appliance
- Add the items to be washed separately, ensuring they are loaded
evenly.
- When closing the door, ensure that no item is trapped between the
door and the door seal.
- Close the door securely, otherwise the programme will not start.

12
Control panel
A Programme selector dial B Display
C Delay timer button D Temperature selection button
E Spin speed button F Additional functions button
G On/o button H Start/pause button
Programmes
Fig. 2
A
B
C D E F
G
H
Fig. 3

13
Programme listing
The table below shows the extra functions and temperatures available
for each wash programme.
Extra Rinse
Programme
Default
Tempera-
ture [°C]
Max spin
speed
[RPM]
Max
load
[KG]
Additional functions available Detergent drawer
Time
[h:min]
Energy
con-
sump-
tion
[WH]
Water
con-
sump-
tion [L]
Number
of
rinses
Delay
Extra
rinse
Pre-
wash
Pre-
wash
Main
wash
Fabric
sof-
tener
Rapid 15’
Cold water
800 2


00:15 30 34 2
Fast 45’
40° 800 2

00:45 700 34 2
Cotton 20°
20° 1000 3.5
 

01:01 95 43 2
Jeans
60° 1000 7

01:45 1250 64 2
Eco 40-60
- 1400 7


03:25 785 58 2
Cotton Intensive
40° 800 7


03:48 670 49 2
Rinse & Spin
- 1000 7
 
 
00:20 40 32 1
Spin
- 1000 7

  
00:12 35 0 -
Anti-Allergy
60° 800 7

01:43 1198 64 2
Wool
40° 600 2
 

01:07 650 34 3
Delicate
30° 600 2.5
 

00:50 220 37 2
Mixed
40° 800 7

01:20 808 70 2
Synthetic
40° 1200 3.5

03:18 765 43 2
Sport
40° 800 3.5

01:11 450 43 2
Cotton
40° 1400 7   
03:49 1085 64 2
MyChoice
- - - - - -
- - - - - - -
Use detergent if necessary
Detergent required, without which washing will be ineective

Do not use detergent or fabric softener
Note: The temperatures and times listed above are
an estimate and may dier from actual wash cyle
time depending on water pressure, load size etc.
The time is automaticlaly updated during the wash
cycle. Displaying the time for an extended time or
abrubt changes are normal.

14
Programme details
Rapid 15 min
This programme is best suited for light loads with light soiling on a 15
minute cycle. This programme includes all wash cycles of main wash,
rinse and spin
Fast 45 min
This programme is best suited for light loads with light soiling on a 5
minute cycle
Cotton 20
This programme can be used for daily washing where there is very
light soiling and only a low temperature is required. The default
temperature is 20°C
Jeans
This programme is best suited to washing jeans. The default
temperature is 60°C
Eco 40 - 60
This programme is used to wash normally soiled cotton fabrics which
can be washed at 40°C or 60°C on the same cycle
Cotton Intensive
This programme can be used for daily washing. The wash cycle is
long and intensive and is best suited for cotton articles such as bed
sheets, pillow cases etc
Rinse and Spin
This programme rinses the load and then spins it

15
Spin
Spin only programme. Soap water or rinse water is drained out before
spinning commences
Anti Allergy
This program is designed for washing clothes for people with
sensitive skin
Wool
This programme is suited for woolen items that are clearly labelled as
machine washable. Select the appropriate temperature according to
the garment’s label(s). Also, ensure you use the correct detergents/
additives
Delicate
This programme is suited for delicate garments. The intensity of the
wash and drum rotation speed is gentler than other main cycles
Mixed
This programme is suited for mixed fabric loads that require a more
intense cleaning cycle. Ensure label warnings on garments are
conformed to
Synthetic
This programme is suited for slightly delicate garments and mixed
loads. The default temperature is 40°C
Sport
This programme is suited for sportswear with a fair level of soiling

16
Cotton
This programme can be used for daily washing, the wash cycle is long
and intensive. The default temperature is 40°C
MyChoice
Press the ‘Spin speed button’ for approximately 3 seconds for the
machine to remember the cycle/setup of your choice (if you have
customised temperature, spin speed etc.). The default MyChoice
cycle is Cotton. Once you have created and/or saved a cycle as per
the above steps, this will be the MyChoice cycle thenceforth
Starting a wash programme & features
• Turn the ‘Programme selector dial’ to the required programme.
• Select the required spin speed using the ‘Spin speed button’.
• Select the wash temperature using the ‘Temperature selection
button’.
• Select any required extra options, as detailed on the following
pages.
• Press the ‘Start / pause’ button.
When a wash programme is in progress, the programme can be
paused by pressing the ‘Start / pause’ button at any time. To resume
the programme, press the ‘Start / pause’ button again.
Programme selection
To select a programme, turn the ‘Programme selector dial’ to the
required programme, as detailed in the programme listing on page

17
13 and also on the detergent dispenser. The display will show the
programme duration.
Spin speed selection
Each selected programme has its own preset spin speed, as shown in
the programme listing on page 13.
If you press the ‘Spin speed button’ the currently set spin speed will
show on the display. You can reduce this or switch it o completely
if required by pressing the ‘Spin speed button’ a number of times. If
you miss the speed you want you can come back round to it again by
pressing a few more times.
A programme without final spin is used to prevent creasing when
washing special fabrics.
Wash temperature selection
Each selected programme has its own preset wash temperature, as
shown in the programme listing on page 13.
If you press the ‘Temperature selection button’ the currently set
temperature will show on the display. You can change the wash
temperature if required by pressing the ‘Temperature selection button’
a number of times. If you miss the temperature you want you can
come back round to it again by pressing a few more times.
Extra functions
Extra functions can be selected once the programme has been set.
To select any extra function, press the additional functions button.
The programme table on page 13 shows the functions available for
each programme. The programme time shown on the display will
reduce or increase, according to the extra functions selected.

18
Delay timer
A delay of up to 24 hours can be added to the end time in half hour
increments to allow the wash programme to finish at a convenient
time. The delay time is to the end of the wash programme not the start
of the programme.
The ‘Delay Timer’ function is not available for the ‘Spin’ programme.
To set the delay timer:
• Press the ‘Delay timer button’ (written ‘start delay’).
• Pressing the ‘Delay timer button’ again increases the delay by 30
minutes for each press, up to the maximum of 24 hours.
• Once the required time delay is shown on the display, the washing
machine will set after approximately three seconds delay.
Extra rinse
This function adds an extra rinse cycle to the programme, which is
ideal for large loads and garments belonging to people with sensitive
skin. Please note: this function will increase the water consumption.
Press the ‘Additional functions button’ once to select the extra rinse,
the display will show an indicator next to the extra rinse writing.
Pre-wash
The prewash function prolongs the washing time by about 20
minutes. The main wash is then preceded by an additional wash cycle
at a temperature of 30°C. This function is recommended for heavily
soiled laundry. Before starting the prewash function, detergent must
be put in the detergent dispenser.
Start / Pause
Press the ‘Start / pause button’ to start the selected wash programme
running, the indicator light stays on. If this is pressed again while
the machine is running a programme the washer will pause and the
indicator light will flash.

19
Child lock
The child lock function ensures that the programme will not be
aected if any buttons are pressed accidentally.
The child lock function should be activated after the wash programme
has been selected together with any extra functions.
To activate the child lock, press and hold ‘Temperature selection’ and
‘Spin speed’ buttons together for approximately 3 seconds.
The display will show the symbol when the child lock is active
To deactivate the child lock, press and hold ‘Temperature selection’
and ‘Spin speed’ buttons together again for approximately 3 seconds.
Power cuts
If there is a power cut, when the electricity comes back on the
washing programme will continue to run from where it stopped.
Switching the sound signal on/o
To activiate this function, press and hold ‘Temperature selection’ for
about 3 seconds. A sound will be heard to confirm the activation. To
deactivate it simply press and hold the button again for 3 seconds.
Energy saving mode
About 10 minutes after the end of a wash programme, the display
switches to energy saving mode. Instead of ‘End’ the display will
blink ‘ : ‘. The energy saving mode will also activate after about 10
minutes of the standby button being pressed if a programme has not
been selected.

20
EN60456 testing details
Energy label program settings:
1. “Cotton+ 40°C+Intensive + Max speed”
2. “Cotton+ 60°C+Intensive + Max speed”
The standard 40° and 60° cotton programmes are suitable to clean
normally soiled cotton laundry and they are the most ecient
programmes in terms of combined energy and water consumption.
The actual water temperature may dier from the declared cycle
temperature.
Note: The wash cycle times that are quoted and shown by the LED
display, are intended as a guide only. Please note that factors external
to the machine, e.g. the temperature of your water supply, your
water pressure etc. can aect the time it takes for the wash cycle to
complete.
7
3.5
3.5 4:30
4:30
4:40 B
-
-
0.67 49
42
42
0.59
0.51
