DVD HOME THEATER SYSTEM
(with 27” Front TV only)
–If Equipped
The available DVD home theater system
operates from 120-volt AC household
current only, so you must have either the
shoreline connected, the generator running,
or the inverter turned on (if equipped).
The TV is connected to the Home
Theater System which playsthrough theater
speakers in the lounge area of the coach.
Set TV Video Input
• Turn TV and DVD player On
• Press INPUT
button on front
of TV and select
“VIDEO 1”
input.TV screen
will display
DVD player
logo when
correct input is
selected.
Play DVD with Theater Sound
• InsertDVDinto player.DVDwill begin
to ‘load’ automatically. TV screen will
typically show “READING” or
“LOADING.”
• DVD may load directly to
main title/menu screen or it
may begin to play previews.
You may be able to skip
previews if desired by pressing the
‘Next’ button until you see the main
menu screen.
• When main
menu screen
appears, use
arrow buttons on
remote to select
desired entry or
press ENTER or
PLAYbuttonson
remote(or‘Play’
button on DVD player) tobegin playing
feature.
• Volume is adjusted with remote (or
volume buttons on DVD player).
TV Sound through Theater Speakers
When watching TV programs alone, the
TV normally plays sound through its own
built-in stereo speakers. If you wish to
connect TV stereo sound output to the home
theater speakers for a richer sound quality,
follow these steps:
• Follow DVD Home Theater steps for
power and TV input setup.
• Turn TV and DVD player On.
• Press FUNCTION button on DVD
player or remote to set DVD player to
“AV IN.”
• Use TV Menu button to set TV audio
output to ‘Variable Audio Output.’ (See
TV owner’s manual.) This routes TV
stereo sound output through home
theater system.
• Select TV channels and adjust volume
with remote for either the TV or DVD.
DVD PLAYER
(with 27” Front TV or 20” Side TV)
–If Equipped
The DVD player operates from 120-volt
AC household current only, so you must
have either the shoreline connected, the
generator running, or the inverter turned on
(if equipped).
The DVD player is connected to the TV
which plays through the TV stereo speakers.
Set TV Video Input
• Turn On both TV
and DVD player
• Press TV/VIDEO
or INPUT button
onremote or front
of TV and select
“Video 1” input
on TV.
TV screen will
display DVD
player logo when
correct input is selected.
Continued—

Audio-Video System
Basic Operation
Guide
Part No. 161501-08-013
0801070129 January 2007
Copyright 2007 Winnebago Industries, Inc.
All rights reserved.
200-Series Class-C
NOTE: See your InfoCase for specific
operating guides for audio and
video components.
Play DVD
• Follow DVD Home Theater steps to
play DVD. Controls are similar.
• Volume is adjusted with remote for
either the TV or DVD.
12-VOLT DVD PLAYER
(with 13” Side 12V TV only)
–If Equipped
The 12-volt, slot-load DVD player is
connected to the TV which plays through
the TV stereo speakers.
Provide 12V Power
The TV and DVD player operate on 12-
volt DC current.
• Turn on 12-Volt master
power switch, located on
theunderside of the video
cabinet.
NOTE: When TV or DVD
are not in use, power
switch should be turned
off to avoid drain on 12-Volt house
battery.
Set TV Video Input
• Turn TV and DVD player On
• Press the TV/
VIDEO or
INPUT button
on the TV
remote to
select “INPUT
1.”
The TV screen
willdisplaythe
DVDplayerlogowhenthecorrectinput
is selected.
Play DVD
• InsertDVDintoplayer.DVDwillbegin
to ‘load’ automatically. TV screen will
typically show “READING” or
“LOADING.”
• TheDVDmayloaddirectlyto themain
title/menuscreenoritmaybegintoplay
previews. You may be able to skip
previews if desired by pressing the
‘Next Track’ button until you see the
main menu screen.
• When the main
menu screen
appears,use the
arrow buttons
ontheremoteto
select the
desired entry or
press the ENTER or Play button on the
remote or DVD player tobegin playing
the feature.
• Volumeisadjusted using theremotefor
either the TV or DVD.
