DVD HOME THEATER
SYSTEM
(Front TV only)
–If Equipped
The available DVD home theater
system operates from 120-volt AC
household current only, so you must
have either the shoreline connected, the
generator running, or the inverter turned
on (if equipped).
The TV is connected to the home
theater system, which plays through
theaterspeakersintheloungeareaofthe
coach.
Set TV Video Input
• Turn TV and DVD player ON.
• Press
FUNCTION
button on front
of TV or
remote and
select HDMI1
input. 
TV screen will
display DVD player logo when
correct input is selected.
Play DVD with Theater
Sound
• Insert DVD into player. DVD will
begin to load automatically. TV
screen will typically show
“READING” or “LOADING”.
• DVD may load
directly to main
title/menu screen
oritmaybegintoplaypreviews.You
may be able to skip previews if
desired by pressing the PRESET+
button until you see the main menu
screen.
• When main menu
screen appears, use
arrow buttons on
remote to select
desiredentryorpress
the center button on remote (or
“Play” button on DVD player) to
begin playing feature.
• Volume is adjusted with remote (or
volume buttons on DVD player).
TV Sound Through Home
Theater Speakers
When watching TV programs alone,
the TV normally playssound through its
ownbuilt-instereospeakers.Ifyouwish
to connect TV stereo soundoutput to the
home theater speakers for a richer sound
quality, follow these steps:
• Turn TV and DVD player ON.
• Press FUNCTION button on DVD
playerorremotetosetDVDplayerto
TV CABLE.
• UseTVMenubuttontoset TVaudio
output to “Variable Audio Output”.
This routes TV stereo sound output
through home theater system.
> Audio (turn speaker Off)
> Setup (change to Variable)
• Select TV channels and adjust
volumewithremoteforeithertheTV
or DVD.
NOTE: Turn the volume level up
significantly on the DVD player
when using the home theater as
an amp for the TV through the
stereo system.
DVD PLAYER - FRONT
BUNK SWING-OUT TV
(Without Home Theater)
–If Equipped
The DVD player is connected to the
TV and plays through the TV stereo
speakers or the deluxe sound rear radio
speakers in the lounge area of the coach.
Provide 12V Power
The TV and DVD player operate on
12-volt DC current.
Continued—

Audio-Video System
Basic Operation
Guide
Part No. 161501-14-018
1401130301
Copyright 2013 Winnebago Industries, Inc.
All rights reserved.
200-Series Class-C
NOTE: See your InfoCase for specific
operating guides for audio and
video components.
• Turn on the 12-volt
master power (TV)
switch (located on the
video cabinet near the
TV).
NOTE: When the TV is
not in use, the TV master power
switch should be turned off to avoid
drain on the 12-volt house battery.
Set TV Sound Output
• Use the TV Menu button to set TV
audio output to Variable Audio
Output.(SeeTVowner’smanualfor
instructions.) This will connect TV
stereo sound output to the deluxe
speakers in the lounge area.
• Volume is adjusted with the TV
remote or volume buttons.
Set TV Video Input
• Turn TV and DVD player ON.
• Press the SOURCE or INPUT
button on the TV or TV remote to
select “INPUT 1” or “AV1”.
• TheTVscreenwill
display the DVD
player logo when
the correct input is
selected.
Play DVD
• Insert DVD into player. DVD will
begin to load automatically. TV
screen will typically show
“READING” or “LOADING”.
• The DVD may load directly to the
main title/menu screen or it may
begin to play previews. You may be
able to skip previews if desired by
pressing the NEXT button until you
see the main menu screen.
• When the main menu screen
appears, use the arrow buttons on
theDVDremotetoselectthedesired
entry or press the ENTER or PLAY
buttons on the remote (or “Play”
button on DVD player) to begin
playing the feature.
• Volume is adjusted with the DVD
remote (or volume buttons on DVD
player).
MENU
ENTER
NEXT
ENTER
T/F
ENTER
PLAY/
PAUSE
