Cipherlab Rs50 User manual

RS50 Mobile Computer

Android™ 6.0, Marshmallow

Version 1.00

- 2 -

RS50 Mobile Computer

The software contains proprietary information of its owner; it is provided under a license

agreement containing restrictions on use and disclosure and is also protected by copyright

law. Reverse engineering of the software is prohibited.

Due to continued product development, this information may change without notice. The

information and intellectual property contained herein is confidential between the owner

and the client and remains the exclusive property of the owner. If having any problems in

the documentation, please report them to us in writing. The owner does not warrant that

this document is error-free.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted

in any form or by any means, electronic, mechanical, photocopying, recording or otherwise

without the prior written permission of the owner.

For product consultancy and technical support, please contact the local sales representative.

Also, visit our website for more information.

All brand, logo, product and service, and trademark names are the property of their

registered owners.

Google, Google Play, Android and other marks are trademarks of Google Inc.

The editorial use of these names is for identification as well as to the benefit of the owners,

with no intention of infringement.

CIPHERLAB logo is a registered trademark of CIPHERLAB CO., LTD.. All other brands,

products and services, and trademark names are the property of their registered owners.

The editorial use of these names is for identification as well as to the benefit of the owners,

with no intention of infringement.

CIPHERLAB CO., LTD.

Website: http://www.CipherLab.com

- 3 -

Important Notices

IMPORTANT NOTICES

FOR USA

FCC ID: Q3N-RS50

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communication. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired

operation.

FCC Caution:

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna

or transmitter.

Find the certificate information from:

Setup About Phone Regulatory information

Tested to Comply with FCC Standards

FOR HOME OR OFFICE USE

- 4 -

RS50 Mobile Computer

FOR PRODUCT WITH LASER

This laser component emits FDA / IEC Class 2 laser light at

the exit port. Do NOT STARE INTO BEAM DIRECTLY.

Do not aim the beam at the eyes.

Any adjustments or performance excluding those specified herein

may result in hazardous laser light exposure.

ENVIRONMENT

Operate the mobile computer at ambient temperatures from -20°C to 50°C and with

humidity range from 10% to 90%.

Store the device at ambient temperatures from -30°C to 70°C and with humidity range

from 5% to 95%.

Charge the device at ambient temperatures from 0°C to 35°C.

This device is built with a dust-proof and splash-proof structure that conforms to

protection class IP67.

SPECIFIC ABSORPTION RATE (SAR) INFORMATION

The product complies with the FCC / Canada portable RF exposure limit set forth for an

uncontrolled environment and are safe for intended operation as described in this manual.

The further RF exposure reduction can be achieved if the products can be kept as far as

possible from the user body or set the device to lower output power if such function is

available.

FCC SAR Value (Standard limit is 1.6 W/Kg)

USA (1g): Max. 1.54 W/Kg

A minimum separation distance of 0.5 cm must be maintained between the user’s body and

the device, including the antenna during body-worn operation to comply with the RF

exposure requirements in Europe.

To compliance with RF Exposure requirements in Europe, third-party belt-clips, holsters or

similar accessories used by this device should not contain any metallic components. The use

of accessories that do not satisfy these requirements may not comply with RF exposure

requirements, and should be avoided.

CE SAR Value (Standard limit is 2 W/Kg)

EU (10g): Max. 1.6 W/Kg

- 5 -

Important Notices

SAFETY PRECAUTIONS

Warning statement:

A pleine puissance, l’écoute prolongée du baladeur peut endommager l’oreille de

l’utilisateur.

To prevent possible hearing damage, do not listen at high volume levels for long

periods.

For people’s safety

Do not listen at high volume levels for long periods to prevent possible hearing

damage.

Do not operate this device while walking, cycling or car driving.

For the equipment

Do not use any batteries or charging devices which are not originally sold or

manufactured by CIPHERLAB CO., LTD.

Do not replace the battery with an incorrect type, to avoid the risk of heat generation,

fire, or explosion.

Do not disassemble, incinerate or short circuit the battery.

Do not touch the contact pins of the battery pack.

Do not expose the mobile computer or battery to any flammable sources.

Do not expose the mobile computer to extreme temperatures or soak it in water.

Do not use any pointed or sharp objects against the screen surface.

Do not use the styluses which are not supplied or approved by CIPHERLAB CO., LTD.,

to prevent possible scratches to the touch screen.

Water residue on the touch screen may cause abnormal behaviors or the fall of its

sensitivity levels.

On the surface of the terminal and the barcode reading window, the fog or water drops

caused by low temperatures may influence barcode reading.

Do not use bleaches or cleaners to clean the device. Use a clean, wet cloth instead.

BATTERY

Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries

according to the instructions.

The main battery may not be charged to full for shipment. Charge the main battery to

full before using the mobile computer for the first time.

Main battery: The main battery powers the mobile computer to work. It takes

approximately 4 hours to charge an empty main battery to full. The charging LED

above the screen will light up in red while charging and will turn green when charging

is complete.

When the main battery is removed, RTC retention will be maintained for at least 30

minutes.

Backup battery: The backup battery is mounted on the main board. Its role is to

temporarily keep the mobile computer in suspension when the main battery is drained

out so data in DRAM will be retained. The backup battery takes approximately 3.5

hours to charge to full by the main battery or power adapter.

It is recommended to charge the battery at room temperature (18°C to 25°C) for

optimal performance.

Battery charging stops when ambient temperature drops below 0°C or exceeds 35°C.

- 6 -

RS50 Mobile Computer

In order to prevent system from shutting down after the battery is drained out, keep a

fresh battery for replacement at all times, or connect the mobile computer to an

external power.

If there are drippings or dust on the device or battery pack, wipe them away with a soft

clean cloth before battery replacement.

Turn off the power before battery replacement.

If you want to put away the mobile computer for a period of time, remove the battery

pack from the mobile computer’s battery compartment. Store the mobile computer

and battery pack separately.

Recycle batteries in a proper way for the green-environment issue.

SCANNER

Scan a 1D barcode

1) Open ReaderConfig and tap Scan Test on the menu bar.

2) Aim the scanning window at the barcode to read. Move the device, having the barcode

located in the center of the scanning area.

3) Press any of the two side triggers. The scanning light beams to read the printed barcodes.

The buzzer beeps after scanning. The scanning light goes off once the data is decoded,

or when the decode timeout period has passed.

Scan a 2D barcode

1) Open ReaderConfig and tap Scan Test on the menu bar.

2) Aim the scanning window at the barcode to read. Move the device, having the barcode

located in the center of the scanning area.

3) Press any of the two side triggers. The scanning light beams to read the printed barcodes.

The buzzer beeps after scanning. The scanning light goes off once the data is decoded,

or when the decode timeout period has passed. USA and Canada e-label

- 7 -

Important Notices

CONNECTION

Via Bluetooth or WLAN

Connection may fail when the mobile computer is around other wireless machines or

power cables as the radio frequencies of those may cause interferences.

If communication fails, move the devices much closer to each other, and try to

communicate again

After turning on, Bluetooth power is sustained even when the mobile computer is

suspended. However, if the power mode is switched to Airplane Mode, Bluetooth power

will be turned off regardless of the settings.

To a charging cradle

Do not insert the mobile computer to a charging cradle if water or drippings are staying

on the device.

The LED indicator on a charging cradle shows the status of battery charging only; the

status of terminal charging is shown on the device itself.

Not Charging could be the result of battery damage, battery’s failure to touch the

connector or AC plug coming off.

Charging error could be due to high battery temperature.

CARE & MAINTENANCE

This mobile computer is intended for industrial use. The mobile computer is rated IP67,

however, damage may be done to the mobile computer if it is exposed to extreme

temperatures or soaked in water.

When the body of the mobile computer gets dirty, use a clean, wet cloth to wipe off

dust and debris. DO NOT use bleaches or cleaners.

Use a clean, non-abrasive, lint-free cloth to wipe dust off the LCD touch screen. DO

NOT use any pointed or sharp objects against the surface. Always keep the LCD dry.

If you want to put away the mobile computer for a period of time, download the

collected data to a host computer, and then remove the battery pack from the mobile

computer’s battery compartment. Store the mobile computer and battery pack

separately.

If you encounter malfunction on the mobile computer, write down the specific scenario

and consult your local sales representative.

- 8 -

RS50 Mobile Computer

E-LABEL

- 9 -

Important Notices

EUROPE - EU DECLARATION OF CONFORMITY

- 10 -

RS50 Mobile Computer

- 11 -

Release Notes

RELEASE NOTES

Version

Date

Notes

1.0 Jun. 07, 2017 Initial release

IMPORTANT NOTICES.....................................................................................................................- 3 -

For USA .......................................................................................................................................... - 3 -

For Product with Laser .................................................................................................................. - 4 -

Environment .................................................................................................................................. - 4 -

Specific Absorption Rate (SAR) information ................................................................................ - 4 -

Safety Precautions ........................................................................................................................ - 5 -

Battery....................................................................................................................................... - 5 -

Scanner..................................................................................................................................... - 6 -

Connection................................................................................................................................ - 7 -

Care & Maintenance ................................................................................................................ - 7 -

e-label ............................................................................................................................................ - 8 -

EUROPE - EU Declaration of Conformity ...................................................................................... - 9 -

RELEASE NOTES ......................................................................................................................... - 11 -

CONTENTS ...................................................................................................................................... 13

INTRODUCTION ............................................................................................................................... 16

Features...........................................................................................................................................17

Inside the Package..........................................................................................................................17

Accessories......................................................................................................................................17

Related Documentation..................................................................................................................17

QUICK START .................................................................................................................................. 18

1.1. Overview.................................................................................................................19

1.1.1. Installing Battery....................................................................................................21

1.1.2. Installing SIM Card, SAM Card and Memory Card ...............................................23

1.1.3. Power On/Off Mobile Computer ...........................................................................25

1.1.4. Homescreen Selection ..........................................................................................26

1.1.5. Using Hardware Buttons .......................................................................................27

1.1.6. Connecting Headset ..............................................................................................27

1.2. Charging & Communication ..................................................................................28

1.2.1. Charge Mobile Computer ......................................................................................28

1.2.2. Wired Data Transmission......................................................................................32

1.2.3 Using Wireless Networks.......................................................................................33

USING THE RS50 MOBILE COMPUTER ........................................................................................... 34

2.1. Battery ....................................................................................................................35

2.1.1. Battery Status Indicators.......................................................................................36

2.1.2. Monitor Battery Level ............................................................................................38

2.1.3. Replace Main Battery ............................................................................................42

2.1.4. Power Management ..............................................................................................43

2.2. Memory ..................................................................................................................44

2.2.1. Check Memory Usage............................................................................................45

CONTENTS

RS50 Mobile Computer

2.2.2. Manage Storage Space.........................................................................................46

2.3. Touch Screen .........................................................................................................53

2.3.1. Screen Brightness .................................................................................................53

2.3.2. Screen rotation ......................................................................................................54

2.3.3. Screen Timeout Settings.......................................................................................56

2.3.4. Text Size .................................................................................................................57

2.4. Notifications...........................................................................................................58

2.4.1. Status LED .............................................................................................................58

2.4.2. Audio.......................................................................................................................59

2.4.3. Sounds and Vibration............................................................................................60

2.5. Date and Time .......................................................................................................62

2.5.1. Set Date, Time and Time Zone .............................................................................62

2.6. Language & Keyboard Input .................................................................................64

2.6.1. Change Display Language.....................................................................................64

2.6.2. On-screen Keyboard..............................................................................................65

2.7. Sound and Volume ................................................................................................72

2.8. Programmable Keys ..............................................................................................73

2.9. Data Capture..........................................................................................................79

2.9.1. Barcode Reader.....................................................................................................79

2.9.2. Digital Camera .......................................................................................................79

BASIC OPERATION .......................................................................................................................... 80

3.1. Home Screen .........................................................................................................81

3.1.1. Customize Home Screen.......................................................................................83

3.2. Status Bar ..............................................................................................................90

3.2.1. Icons on Status Bar ...............................................................................................90

3.2.2. Open Quick Setting Menu .....................................................................................92

3.2.3. Open Notifications Drawer....................................................................................93

3.3. Manage Applications.............................................................................................95

3.3.1. Application Menu...................................................................................................95

3.3.2. Current Applications ..............................................................................................97

3.4. Suspend & Lock.....................................................................................................98

3.4.1. Suspend Device.....................................................................................................98

3.4.2. Lock Device............................................................................................................98

3.5. OS Update ............................................................................................................100

3.6. Back up Your Data...............................................................................................102

3.7. Reset to Factory Default......................................................................................103

WIRELESS RADIOS........................................................................................................................105

4.1. Use Wireless Wide Area Network .......................................................................106

4.1.1. Share WWAN Data...............................................................................................108

4.1.2. Data Connection Settings ...................................................................................113

4.1.3. SIM Card Settings................................................................................................114

4.2. Use Wireless Local Area Network (Wi-Fi) ...........................................................115

4.2.1. Connect to Wi-Fi Network....................................................................................115

4.2.2. Manually Add Wi-Fi Network ...............................................................................116

4.2.3. Advanced Wi-Fi Settings......................................................................................117

4.2.4. Configure Proxy Server ........................................................................................118

4.2.5. Use Static IP Address ..........................................................................................118

4.2.6. Connect With Wi-Fi Protected Setup (WPS) .......................................................118

CONTENTS

4.2.7. Modify Wi-Fi Network...........................................................................................119

4.2.8. Disconnect Wi-Fi Network ...................................................................................119

4.3. Use Bluetooth ......................................................................................................120

4.3.1. Bluetooth Profiles ................................................................................................120

4.3.2. Turn On Bluetooth ...............................................................................................121

4.3.3. Change Bluetooth Name.....................................................................................122

4.3.4. Pair Bluetooth Devices ........................................................................................123

4.3.5. Unpair Bluetooth Device .....................................................................................123

4.4. Use Near Field Communications ........................................................................124

USING THE PHONE........................................................................................................................126

5.1. SIM Card Management .......................................................................................127

5.2. Phone Application................................................................................................128

5.2.1. Phone Interface ...................................................................................................128

5.2.2. Place Call..............................................................................................................129

5.2.3. During A Call.........................................................................................................130

5.2.4. Receive Incoming Call .........................................................................................132

5.2.5. Check Missed Calls .............................................................................................133

5.2.6. Call History ...........................................................................................................134

5.2.7. Make Multi-Party Calls.........................................................................................135

5.3. Audio Modes ........................................................................................................136

5.4. In-call Volume ......................................................................................................136

USING READER CONFIGURATION UTILITY ....................................................................................137

6.1. Configuring Reader..............................................................................................138

6.1.1. General Settings ..................................................................................................139

6.1.2. Symbology ............................................................................................................146

6.1.3. Miscellaneous......................................................................................................149

6.1.4. Reader Config Option Menu................................................................................150

6.2. Read Printed Barcodes .......................................................................................157

SPECIFICATIONS ...........................................................................................................................159

Platform, Processor & Memory.....................................................................................................159

Communication & Data Capture ..................................................................................................160

Electrical Characteristics ..............................................................................................................161

Physical Characteristics................................................................................................................161

Environmental Characteristics .....................................................................................................162

Programming Support...................................................................................................................163

APPENDIX I....................................................................................................................................164

Scan Engine Settings ....................................................................................................................164

Symbologies Supported...........................................................................................................164

APPENDIX II...................................................................................................................................166

2D Imager ......................................................................................................................................166

Symbology Settings..................................................................................................................166

APPENDIX III..................................................................................................................................177

Open Source License ....................................................................................................................177

RS50 Mobile Computer

INTRODUCTION

The RS50 mobile computer, powered by Android™ 6.0 Marshmallow, is light-weight, easy

to use, providing powerful and handy tools for the purpose of delivering flexibility in

customization.

Specifically designed to work as an industrial PDA, it provides rich options of data collection,

voice and data communication, long-lasting working hours, and so on. Its large color

capacitive display guarantees ease in reading in all lighting conditions. Integrated with

Bluetooth v4.1, v2.1+EDR, 802.11a/b/g/n/ac technologies, the mobile computer also

includes a GSM/GPRS/EDGE/WCDMA/HSPA/HSPA+/LTE CAT 6 module to gain greater

speeds and optimal mobility. In particular, an integrated GPS receiver is made available for

use with third-party location-based applications.

This manual serves to guide you through how to install, configure, and operate the mobile

computer. The Care & Maintenance section is specifically crucial for those who are in charge

of taking care of the mobile computer.

We recommend you to keep one copy of the manual at hand for quick reference or

maintenance purposes. To avoid any improper disposal or operation, please read the

manual thoroughly before use.

Introduction

FEATURES

Built tough to survive drop test and sealed against moisture/dust to industrial standard

IP65/IP67.

Android™ 6.0 Marshmallow operating system with a powerful Cortex 1.3 GHz

Quad-Core processor

16GB eMMC flash memory to store OS and software programs

2GB LPDDR3 SDRAM to store and run programs, as well as store program data

One expansion slot for microSDHC card up to 32GB and microSDXC card up to 2TB.

Built-in 8.0 Megapixel rear camera with white LED for flash and auto focus.

One side trigger for scanning

Total wireless solution — connectivity includes Bluetooth v4.1 and v2.1+EDR, 802.11

a/b/g/n/ac, GSM/GPRS/EDGE/WCDMA/HSPA/HSPA+/LTE CAT6.

A 4.7” color transmissive display with 720x1280 pixels to deliver excellent visibility in

all lighting conditions

Configurable feedback indicators including speaker and vibrator

Built-in scan engine setting tool Reader Configuration which serves out-of-the-box

keyboard wedge functionality

Accessories and peripherals include Snap-on Charging Cable and Charging Cradle

(both are capable of USB Charging and Data Transfer)

INSIDE THE PACKAGE

The following items are included in the kit package. Save the box and packaging material for

future use in case you need to store or ship the mobile computer.

RS50 Mobile Computer

Rechargeable Li-ion battery pack

Hand Strap

Micro USB Charging and Data Transfer Cable

Snap-on Charging Cable

AC Power Adaptor

Quick Start Guide

ACCESSORIES

Handbelt

Charging cradle

CipherLab RS50 User manual
