Citronic CD-S2 User manual

Citronic Limited CD-S2 Owners Manual
Page 2 of 8
Table Of Contents
Table Of Contents 2
ABOUT CITRONIC 3
WARNING 3
Important Safety Information 4
Your Serial Number 4
Illustration 5
Features and Functions 6
1. Stop 6
2. Eject 6
3. LCD Display 6
4. SGL/CTN 6
5. Cue Indicator 6
6. Cue 6
7. Play/Pause Indicator 6
8. Play/Pause 6
9. LOOP IN Indicator 6
10. LOOP IN 6
11. LOOP OUT 6
12. Scan Reverse 6
13. Scan Forward 6
14. Backward Skip 6
15. Forward Skip 6
16. LOOP OUT Indicator 6
17. Time Select 6
18. Pitch Bend 6
19. Pitch Fader 6
20. Pitch Select 6
21. Pitch 6
22. Pitch Indicator 6
23. Pitch Select Indicator 6
24. Audio Out 6
25. Digital Output 6
26. Fader Start 6
27. Voltage Selector 7
28. AC In 7
29. Power 7
Technical Information 7
Guarantee Of Satisfaction 7
CE Markings 7

Citronic Limited CD-S2 Owners Manual
Page 3 of 8
ABOUT CITRONIC
Thank you for choosing Citronic and the CD-S2 Single
Top Loading CD Player. You have joined a discerning
group of DJ’s and operators who value design integrity,
quality and state of the art facilities.
Established in Melksham, Wiltshire in 1972, Citronic
occupies prestigious purpose built factory headquarters.
The award winning product range covers professional
audio mixers, amplifiers and signal processing.
Each unit is manufactured to the highest possible
standards and all have an enviable reputation for
reliability and value for money – the noted hallmark of
Citronic products.
Substantial investment has been made in high
technology CAD systems, manufacturing control and
testing techniques. This sophisticated computerisation
coupled with an extensive research and development
program, enables the company to offer an exceptional
degree of manufacturing excellence and quality
assurance.
Citronic has always listened carefully to the customer
and places tremendous emphasis on market research.
This ensures that the exacting requirements of the DJ
are complimented without compromise, throughout the
entire product range. This unique approach, coupled with
a strong input from a highly qualified engineering team,
ensures that Citronic maintains its position as a
respected leader, in the industry’s development.
Citronic has a distribution network throughout Europe,
Asia and the Americas.
Enjoy your new purchase.
WARNING
In order to obtain the best service from the unit we
STRONGLY recommend that you read this manual
before you apply any power.

Citronic Limited CD-S2 Owners Manual
Page 4 of 8
Important Safety Information
Warnings
All the safety and operating instructions should be read
before the appliance is operated.
To prevent fire or shock hazard, do not expose this
appliance to rain or moisture.
To reduce the risk of electric shock, do not remove the
cover (or back). There are no serviceable parts inside.
Always refer servicing to qualified service personnel.
Cautionary Notes:
Handle the power supply cord carefully. Do not damage
or deform the power supply cord. If it is damaged or
deformed, it may cause electric shock or malfunction
when used. When removing from wall outlet, be sure to
remove by holding the plug attachment and not by pulling
the cord.
In order to prevent electric shock; do not open the top
cover. If a problem occurs, contact your dealer.
Do not place metal objects or spill liquid inside the CD
Player. Electric shock or malfunction may result.
Any use of the controls, or any adjustment, or the
performance of any procedure other than those specified
herein may result in serious damage to your health.
The CD Player should not be opened or repaired by
anyone except properly qualified service personnel.
Double insulated - when servicing, use only identical
replacement parts.
Your Serial Number
Please, record and retain serial number of your CD-S2
CD Player shown on the rating label.
My Serial Number Is:
_______________________

Citronic Limited CD-S2 Owners Manual
Page 5 of 8
Illustration

Citronic Limited CD-S2 Owners Manual
Page 6 of 8
Features and Functions
1. Stop
Push this button to stop the CD and return to the
beginning.
2. Eject
Press this button to open the CD player and access
the CD.
3. LCD Display
This liquid crystal display (L.C.D.) indicates the track
numbers, time (minutes, seconds, frames), pitch
speed, also other modes as single play and
continuous play.
4. SGL/CTN
This button switches between single track play or
continuous track play.
5. Cue Indicator
This will be lit when a track is cued, once entering
play mode the indicator will switch off.
6. Cue
This function allows the CD to be played from a
setup point any number of times. Press the
PLAY/PAUSE button to pause a playing song, then
use the search button to locate the desired cue
point. Press PLAY/PAUSE to set the cue point and
CUE to return to the cue point
7. Play/Pause Indicator
This will flash when in pause mode. once play mode
is entered it will be lit continuously.
8. Play/Pause
Use this button to start playback. Press once to start
playback, once again to set the pause mode and
once more to resume playback.
9. LOOP IN Indicator
This will flash when a loop has been set.
10. LOOP IN
This button allows you to set a cue point without
stopping the playback. This button sets the
beginning of a loop.
11. LOOP OUT
This button is used to set the end of the loop. The
player will start to loop continuously until this button
is pressed again to exit. To enable reloop press
again.
12. Scan Reverse
This button when pressed will scan backwards
frame by frame on the current track selected. This
function has three scan speeds, hold the button for
a few seconds to change the scanning speed.
13. Scan Forward
This button when pressed will scan forwards frame
by frame on the current track selected. This function
has three scan speeds, hold the button for a few
seconds to change the scanning speed.
14. Backward Skip
Use this button to go back to the beginning of the
current track or select a previous track selection.
15. Forward Skip
Use this button to skip to the next track.
16. LOOP OUT Indicator
This will flash when an out cue has been set.
17. Time Select
Use this button to select the time display to read
either the time elapsed, time remaining or total time
remaining.
18. Pitch Bend
These buttons are used to temporarily alter the pitch
of the track to either slow down or speed up when
beat matching. Note: This function will note work if
the pitch slider is already at maximum pitch (±16%)
19. Pitch Fader
This is used to set the pitch of a track either slower
or faster than original.
20. Pitch Select
Press this button to select the pitch range required
±8%, ±12%, or ±16%.
21. Pitch
This button turns the pitch fader on and off. Allowing
you to lock the pitch at 0%
22. Pitch Indicator
When Lit this indicates the pitch is unlocked.
23. Pitch Select Indicator
When flashing this indicates the pitch range is ±8%,
when it is not lit the pitch range is ±12%, when lit
continuously it indicates the pitch range is at ±16%.
24. Audio Out
This stereo line output connects to the line input on
any DJ mixer.
25. Digital Output
This coaxial (S/P DIF) digital output connects to any
RCA S/P DIF input, as found on most standard
computer sound cards or CD Burners
26. Fader Start
Connects to any DJ Mixer equipped with fader start
input.

Citronic Limited CD-S2 Owners Manual
Page 7 of 8
27. Voltage Selector
Used to select the unit’s voltage according to the
local setting. Note: The voltage should be preset
correctly from the factory, however, make sure
before powering the unit.
28. AC In
This is the connection for the supplied power cable.
29. Power
This switch is used to power the unit on and off.
Technical Information
Power Source: AC 115/230V. 50/60Hz, 15W
Dimensions: 274 (D) x 216 (W), 87 (H) mm
Weight: 1.6kgs
Guarantee Of Satisfaction
CE Markings
This product is guaranteed to the original purchaser against defects in material and workmanship for one year from
the date of initial purchase. Activate this guarantee at the time of purchase by returning the Guarantee Card to the
address on the front page. Keep a copy of your sales receipt for proof of guarantee status, should it be necessary.
If a malfunction occurs, the dealer who supplied the unit will be happy to handle the repair. When returning a
unit, use the original factory carton – do not chance inadequate packing materials. Simply tape a note to the unit
describing the malfunction.
If your unit is out of guarantee, we recommend that you return it to an authorised Citronic dealer for repair or
service. Experienced personnel, supported by specialist testing equipment, will be able to find and correct the fault
in the most efficient and cost effective way
If you have need to contact us about the operation or servicing of your CD-S2 Top Loading Single CD Player
please write, telephone or e-mail to the address on the back page:-
EMC Conformity
The CD-S2 Top Loading Single CD Player has been tested to demonstrate compliance with the EMC 89/336/EEC
directive, under which the following harmonised standards apply:
I) EN55013 Electromagnetic Compatibility
II) EN61000-3-2 EME-010700
III) EN61000-3-3 EME-010700
Electrical Equipment Safety Regulations (1994)
The CD-S2 Top Loading Single CD Player has been designed and tested to demonstrate compliance the LVD
73/23/Eec directive, using the following standard.
I) EN60065 Safety requirements for mains operated electronic equipment for household and similar general
use.

Citronic Limited CD-S2 Owners Manual
Page 8 of 8
Citronic Limited
Halifax Road
Bowerhill
Melksham
Wiltshire
England
SN12 6UB
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.citronic.com
