Cleyver ODWCAM90 User manual

ODWCAM90
User Manual

Desktop HD Video Camera User Manual
1
Attentions
This manual briefly introduces the camera functions, installation and operation.Please read carefully
before application.
1,Application instructions
To prevent damages to this camera or any products connected to it, this product can only be used within the
specified range:
1) Do not expose the camera to rain or moisture;
2) To prevent the risk of electric shock, do not disassemble the camera,only qualified technical personnel to
perform installation and maintenance;
3) Do not use the camera in situations which is excess of the specified temperature, humidity or power
specifications;
4) When cleaning the camera lens, wipe with a soft and dry cloth. If with too much dust, wipe gently with a mild
detergent. Do not use strong or corrosive detergent, so as not to scratch the lens, affecting the image effect;
2,Electric Safety
This product must be installed in strict compliance with local electrical safety standards.
3,Caution to transport
Avoid heavy pressure, severe vibration, soaking damage to the product in transportation, storage and installation.
4,Careful of installation
The camera body is made of organic material, please do keep way from corrosive liquid, gas or solid material.
5,Do not disassemble discretionarily.
We are not responsible for any damage caused by unauthorized disassembling.
6,Magnetic field interference
The electromagnetic field at a specific frequency may affect the camera image.This product is a Class A product. In
household environment it may cause radio interference, users need to take appropriate measures.

Desktop HD Video Camera User Manual
2
Content
1.Fast Installation Explanation ......................................................................................................................................3
1.1. Product Interfaces..................................................................................................................................3
1.2. Usage of the Product..............................................................................................................................3
2. Product Introduction.................................................................................................................................................4
2.1. Product Introduction..............................................................................................................................4
2.2. Product Features....................................................................................................................................4
2.3.Technical parameter................................................................................................................................5
3.Maintenance and Troubleshooting............................................................................................................................5
3.1. Camera Maintenance.............................................................................................................................6
3.2. Troubleshooting .....................................................................................................................................6

Desktop HD Video Camera User Manual
3
1.Fast Installation Explanation
1.1. Product Interfaces
Picture 1.1 Interfaces Explanation
1,Lens（fixed） 3,Audio IN（built in pick-up）5,Screw hole for bracket
2,LED indicator 4,USB2.0 cable outlet hole（no plug） 6,Fixation clamp
The USB 2.0 port available for plug and play, it can output video and power the camera.
1.2. Usage of the Product
1）Product fixation: Fix the device on LCD screen, the top of laptop,directly on desk or on tripod.
2）Camera USB cable connect with computer, video conference terminal or other USB input device.
3）Open the video software,select video device to get video output.

Desktop HD Video Camera User Manual
4
2. Product Introduction
2.1. Product Introduction
Product dimension as picture below：
Pic. 2.1 Dimension
Accessory: Check and confirm all accessories are provided when opening the package:
User Manual x 1
Warranty Card x 1
2.2. Product Features
This series camera offers perfect functions and superior performance.The features include advanced ISP
processing algorithms to provide vivid images with a strong sense of depth, high resolution,and fantastic color
rendition. It works stably and reliably and the operation and maintenance is easy and convenient.

Desktop HD Video Camera User Manual
5
Features
Wide FOV: ODWCAM90 adopts 80° non-distorted lens or 109°large wide angle lens for option, to present an open
vision;
Superb High-definition Image：employs 1/2.9 inch2.07 megapixel high quality CMOS sensor. Resolution is up to
1920x1080 with frame rate up to 30fps.
Low Noise and High SNR:Low Noise CMOS effectively ensure high SNR of camera video.
Multiple Video Compression: Support H.264/265, MJPEG, YUV video compression, to made video play smoothly.
Stereo sound：Built-in pick-up to present clear stereo sound effect, no need to connect external device.
USB2.0 interface: Plug and play function is better for power supply and upgrading;
Multiple installation：Easy to install on any device, say, LCD screen, laptop,table or tripod.
Wide Application: personal video conferencing, live video conference, collaboration meeting etc
Convenient to operate：No need to download driving device, see as below:
2.3.Technical Specification
Camera Model
ODWCAM90
Camera Parameter
Sensor
1/2.9 inch high quality HD CMOS sensor
Effective Pixels
16: 9 2.07 megapixels
Video Format
950x540/160x90/320x180/432x240/640x360/800x448/800x600/864x480960X720//102
4X576/1280X720/1600X896/1600X896/1600X896/1600X896/1600X896/1600X896/16
00X896/1920X1080/2304X1296/2304X1536/272X144/368X208/384X216/480X272/62
4X352/912X512/424X240/480X270/484X480/640X480/352X288/320X240/176X144/1
60X120/P30
View Angle
88°
（D）/ 80° （H）/ 50°（V）
Focal Length
3.24mm
Minimum Illumination
0.5Lux(F1.8, AGC ON)
Focus
Auto
Aperture
Fixed
Backlight contrast
On/off
Exposure
Exposure parameter could be adjusted; support auto exposure
Video Adjustment
Brightness,Color,Saturation,Contrast,White balance mode, Gain, Anti-flicker,Low
brightness compensation etc
SNR
>50dB
Input/Output Interface
Video Interfaces
USB2.0(power supply, upgrading available)
Video Compression
Format
H.264,265,YUV,MJPEG
Audio Input Interface
Built in omnidirectional high sensitive digital pickup
Other Parameter
Input Voltage
5V
Input Current
500mA
（M ax.）
Power consumption
2.5W
Store
Temperature,Humidity
-10
℃～ +60℃、20% ～95%
Working Temperature,Hu
midity
-10
℃～ +50℃、20% ～80%
Dimension
（W XHXD）
112mm*65mm*93mm
Weight (appx.)
0.25kg
Application
Indoor
Accessory
User Manual,Warranty card

Desktop HD Video Camera User Manual
6
3.Maintenance and Troubleshooting
3.1. Camera Maintenance
1)If camera is not used for long time,please turn off power adapter switch and AC plug.
2)Use soft cloth or tissue to clean the camera cover.
3)Use soft cloth to clean the lens; Use neuter cleanser if bad smeared. Do NOT use strong or corrosive
cleanser or corrosive cleanser avoiding scuffing.
3.2. Troubleshooting
1）No video output
Solutions：
a. Check if the camera USB Cable well connected, if USB Port is normal, if Power indication light is on.
b. Please disconnect the camera with computer and re-connect by USB to check if it works.
c. Please check if the video software choose the right device.
2）Video on and off
Solutions:
a. Check if the camera USB Cable well connected, if USB Port is normal, if Power indication light is on.
b. Please disconnect the camera with computer and re-connect by USB to check if it works.
Copyright Notice:
All the contents of this manual and the copyright ownership belong to our company. Without the approval of the
Company, no one can imitate, copy, reproduce or translate arbitrarily. This manual does not have any form of
warranty, express or other imply. Specifications and information of this manual mentioned is just for informational
purposes,and the content will be updated at any time without notice.
Copyright can not be reproduced.
