Coban GPS102B User manual

1
GSM/GPRS/GPS TRACKER
MANUAL
Preface
Thank you for purchasing the tracker. This manual shows how to operate the
device smoothly and correctly. Make sure to read this manual carefully before
using this product. Please note that specification and information are subject to
changes without prior notice in this manual. Any change will be integrated in
the latest release. The manufacturer assumes no responsibility for any errors
or omissions in this document.

2
1. Summary
Working Based on existing GSM/GPRS network and GPS satellites, this
product can locate and monitor any remote targets by SMS or internet.
Specifications
Content
Specs
Dim.
63mm x 46mm x 21mm
Weight
41g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GSM chip
MT6261
GPS chip
Ublox 7020
GPS sensitivity
-159dBm
GPS accuracy
5m
Time To First Fix
Cold status 45s
Warm status 35s
Hot status 1s
Work voltage
5V
Storage Temp.
-40°C to +85°C
Operation Temp.
-20°C to +55°C
Humidity
5%--95% non-condensing
Main functions
·GSM quad-band frequency;
·Real time tracking by SMS/GPRS
·Low battery alarm;
·Geo-fence alarm ;
·move alarm
·SOS alarm ;

3
·Monitor (optional)
·Vibration alarm (optional)
·Add Smart sleep save power Mode
·Add GPX history route record, can check record in Google map
·Add AGPS function,receive GPS signals faster
·Add built-in storage memory
·Add WATERPROOF and dust proof
·patented product
2.Led indicator status
LED INDICATOR STATUS
MEANING
RED LED continuously work
Charging
RED LED not lit
Fully charged
Green LED Flashing
Success get GSM signal
Green LED continuously lit
Searching GSM signal
3. Notices:
1).GPS tracking can be worked outdoor. Must have mobile phone gsm signal
and have GPS signal, can block GPS satellite signal when there are metal
or building above the GPS tracker
2).Please make sure GSM SIM card(2G GSM network or compatibility 2G
GSM network) supports making calls, sending messages, GPRS
network.have money
3).make sure the SIM card has opened the call shows and turned off the call
transfer.
4).Please insert the SIM card correctly. Cancel the PIN code
5).Do not assembly and disassembly device at will.

4
Choose a SIM card
Quick using
3.1 Put the SIM card into the as picture shows.
3.2 Product testing, need to be closed shell and screw ,then charge the battery
in time to keep it working normally.
3.3 take the device to outdoor and the front of device towards sky ,move device
to receive gps signal. Because indoor has no gps signal
3.4 Use mobile phone call the device and hang up or sending message
“smslink123456” to sim card in tracker ,tracker Will reply positioning
information

5
Picture (1) have gps signal Picture (2) no gps signal
Pic(1)： Replied real-time tracking information under GPS satellites signal.
Lat:22.67533 lon:114.03913 Positioning of the latitude and longitude
values.
Spd：000.1 This refers to the device moving speed. The unit is km/h.
T:06/14/17 09:14 real-tracking time, the Default is London time. You can
set a time zone by sms command
Google Link: This is the link to the Google map showing the position of the
device.
Pic( 2) ：Replied last time position information. Now is LBS position
information. no gps signal
smcc:27a4 1223: Real-time LBS data.
Time:08/00/00 LBS positioning time.
If you receive positioning information is picture 2, please go out the outdoor
and Walk around with gps tracker,for receive The satellite signal
4.Command instruction
NOTE:
1)Device default password:123456)
2)use of mobile phones send messages to the tracker about all set command

6
3) The “+” in the command, please don’t type “+”, space means press
the space keyboard on your cell phone
4)After admin number setting, all alarm message will send authorization number
other cell-phone number send command will not reply
5) If you want standby time longer, pls don't open move alarm, and platform for
real-time location tracking.etc
4.1 Admin number setting:( support 5pcs admin number)
Command: admin123456+space+ phone number（This phone number is your
own mobile phone number , not the mobile number in tracker .）
Reply：admin ok
E.g：admin123456 13725556021
Note: support 5pcs admin number , Set the first authorization number,then use use
the first authorization number to set other authorization number,
If the authorization number forget or lost, you can send reset123456 to Restore the
factory Settings
Admin number Canceling:
Command ：noadmin123456 13725556021
Reply：noadmin ok
4.2 move Alarm setting (It works only in getting gps signal, the scope is a
circle that radius 200meters)
Command：move123456
Reply：move ok

7
E.g：
move alarm Canceling:
Command：nomove123456
Reply：nomove ok
4.3 Low battery alarm
When GPS device battery is Less than 30%, it will send SMS:low
battery+Ge-info alarm, at 3 minutes interval.
Canceling low battery alarm: send“low battery” to the tracker.
4.4. SOS help setting
Long Press the SOS button for 3 seconds, the tracker will send SMS “SOS
HELP!+lat./long.” to all the authorized numbers
E.g:
Canceling sos setting ：Command:“ help me“
E.g:

8
4.5 Monitor setting(option, The default do not have this function)
The default mode is “tracker” (Tracker mode).
Send SMS “monitor+password” to the unit,switch to “monitor” mode.then use
your mobile call the device sim card, Can listen to the voices around device
E.g:
Monitor Canceling Send SMS “tracker123456” to the unit, switch to “tracker” mode
4.6. Set Vibration alarm(option, The default not have this function)
Command ：“shock+password” to the device,it will start effective
After 5mins of static ,when the sensor is triggered ,and will send send Vibrate
alarm+latitude&longitude”
canceling Vibration alarm:
Command: “noshock+password”
Reply:noshock ok

9
4.7 Terminal (local) Time Setting (factory setting GMT 0)
Command：time+space+zone123456+space+ local time zone
Reply：time ok!
E.g：
NOTE:( 1 is east 1, - 1 is west 1, 30 is half the time zone)
4.8 Reset device
Command：reset123456
Reply：reset ok
4.9 Change the password
Command: password123456 888888
Reply :password OK
Note: 123456 is the old password(default ),888888 is the new password,it
must the 6 digits Arabic numerals
5.0 State Checking
Send SMS:”check+password” to the tracker device, it will reply the recent
status via SMS as: GSM: 100% GPS: OK/NO GPRS: ON/OFF battery: 100%.
Remark: GPS NO, only mean there are no GPS position request.
5.1 change IMEI number
Command: imei123456+space +new imei number
E.G: setimei123456 352887076633221

10
5.2 Add GPX history route record
First you have to insert TF card in the device
Send SMS: “ gpx+password” to tracker,it will reply : “ gpx ok” ,
then send SMS: “t001m***n+password” ,it will reply : “ tn ok”
Cancel gpx function ; send SMS : notn+password” it will reply: notn ok”
then send SMS: nogpx+password ,it will reply nogpx ok. Then auto enter
SMS mode.
Check the gpx data in google earth map :
Take out the TF card from device and connect with computer, copy the GPX file
to computer,then open the google earth map,then use goolge earth map open
the gpx file,you will see the route in the map.(you can download google earth
map app in the network )
NOTE: after set succeed GPX function,call device will not reply the google
link ,and stop send data to server.
6 .If you need real-time tracking by APP or website ,pls Operating as
follows
NOTE:If you need platform position, please use phone send “ gprs123456” to
device
6.1:Support Android & IOS APP tracking
If you need real-time tracking by APP ,please scan APP on web platform
OR Download “dagps”
1).scan QR code---open with browser--- choose Android or
Iphone---Download-- installation app

11
6.2: support Website tracking
Open www.gps110.org
Use tracker ID login, default password 123456.
PC login APP login
6.3Geo-fence setting
Point APP fence and Set the diameter of 200 metres, Choose a location as
center ,in outdoor(device out of the safety area will alarm)

12
7:support Website tracking
Open www.gps110.org
Use tracker ID login, default password 123456.
NOTE:If you insert the correct SIM card and send “GPRS123456”, device in
outdoor, still not online.Please set the APN commands
If set the first step,device online in platefrom, no need set apn commands
After set GPRS mode, every 2min upload data to server by default,you can
change upload time interval
8.Set GPS online in platform
SMS1: “GPRS123456”
SMS2: APN123456+space+Apn name
(APN name pls ask the sim card company ,for example tell you the apn name
is ABC,so send APN123456 ABC)
(If have the APN user name and password, need plus APN user name and
password behind the APN name)
Eg: APN123456+space+APN name+space+ APN user name+space+
APNpassword
9. If use the other platform, start on line tracker
(Use the default platform, don't need to operate 7)
in advance Using mobile phone send SMS commands to device and set online
platform (please set DNS and port,set apn)
SMS1: adminip123456 +space+ip+space+port
or adminip123456+space +DNS+space+ port
E.g: adminip123456 www.gps110.org 7018(www.gps110.org is DNS,7018
is port)
SMS2: APN123456+space+Apn name
(APN name pls ask the sim card company ,for example tell you the apn name
is ABC,so send APN123456 ABC)
If have the APN user name and password, need plus APN user name and
password
behind the APN name)
Eg:APN123456+space+APNname+space+APNuser name+space+
APNpassword
If device online in platform, no need set apn commands

13
8. FAQ and processing methods.
FAQ
Instructions/Solutions
Fail to turn it on
Please check if battery and USB cable is charged
No GSM signal
Please check if SIM card installed correctly.
Please check if SIM card is 2G GSM network.
Don’t turn on the PIN code
no calls can be diverted
Please check if voltage of the power is normal

Please check if voltage of the power is normal
电源电压是否正常
No GPS
A more open view of the sky is recommended to make
sure the device can receive the GPS signal normally.in
outdoor,or take device to walk around
No reply to SMS
command
Password wrong or the format is wrong. restore factory
settings send “reset123456”
No reply to calling &
No alarm message
Authorized / admin phone number is incorrect or has not
setup
SMS position OK,
cannot use the APP
and web platform
Pls check if APN is correctly set. And pls find out the
correct APN content of the SIM card.
Platform position is
difference from the
actual position.
No uploading position time or no GPS signal: call the
device phone number and receive the position message.
If it shows like Pic 2, pls make sure the device can
receive the GPS signal normally.in outdoor,and take
device to walk around
