USER AND INSTALLATION MANUAL

2cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
GENERAL WARNINGS
•Read the warnings contained in
this manual carefully.
•Once the unit is installed,
describe its operation to the
user and give them this
manual. The manual is an
integral part of the product and
must be kept in a safe,
accessible place for future
reference.
•Installation and maintenance
must be performed by a
registered technician, in
accordance with current
standards and the
manufacturer's instructions.
Tampering with the sealed
adjustment devices is
prohibited.
•Improper installation or lack of
appropriate maintenance may
result in property damage or
injury. The manufacturer will
not be liable for damage
caused by improper installation
or use or, in any case, for
failure to comply with the
instructions.
•Before performing any cleaning
or maintenance operations,
unplug the unit from the mains
power supply using the power
switch or another cut-off
device.
•In the event of a malfunction or
improper operation, unplug the
unit and have it repaired by
qualified personnel. Only
contact registered
technicians. The unit must only
be repaired, and its
components replaced, by
registered technicians using
original replacement parts.
Otherwise the safety of the unit
may be compromised.
•This unit may only be used for
the purpose for which it was
expressly designed. Any other
use must be considered
inappropriate, and therefore
hazardous.
•The packing materials are a
potential source of danger, and
must be kept out of reach of
children.
•The unit can be used by
children aged at least 8 years
and by persons with reduced
physical, sensory or mental
capabilities, or lacking

cod. 3541S050 - Rev. 01 - 07/20193
EN
CPA
experience or the necessary
knowledge, only if under
supervision or they have
received instructions on its safe
use and the related risks.
Children must not play with the
unit. Cleaning and
maintenance intended to be
done by the user can be carried
out by children aged at least 8
years only if under supervision..
•Dispose of the unit and its
accessories in accordance with
current standards.
•The images contained in this
manual are a simplified
representation of the
1 USER'S MANUAL
................................................. 36
1.1Introduction
........................................................ 36
1.2Control panel
...................................................... 36
1.3Turning the heater on and off
.............................. 36
1.4Settings
............................................................... 36
1.5Faults
.................................................................. 372
INSTALLATION
MANUAL..................................... 37
2.1General information
............................................ 37
2.2Location
.............................................................. 37
2.3Assembling the heater
........................................ 38
product. Such representations may in- •APPLIANCE INTENDED
FOR Includeude slight, insignificant differences STIC USE;
NOT VALID FOR INDUwith respect to the product supplied.
STRIAL USE.
This symbol means “Caution,” and is displayed next to
safety warnings. Carefully observe such warnings to
avoid hazardous situations, property damage, and
injury to people and animals.
Important information involving no risk of injury or property damage is indicated by this
symbol.
The CE marking certifies that products meet the fundamental requirements
of the applicable European directives. The declaration of conformity can be
requested from the manufacturer.
The unit is suitable for operation in a partially protected with temperatures from -5°C
to +60°C.

4cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
2.4Hydraulic connections
......................................... 39
2.5Gas connection
................................................... 40
2.6Air and flue gas ducts
......................................... 40 3 SERVICE AND
MAINTENANCE ........................... 41
3.1ADJUSTMENTS.........................................
......... 41
3.2COMMISSIONING
.............................................. 42
3.3MAINTENANCE
.................................................. 42
3.4REPLACING THE BATTERIES
.......................... 43
4 TECHNICAL DATA AND CHARACTERISTICS ....
44
4.1Dimensions and connections
.............................. 44
4.2Overview and main components
........................ 45
4.3Hydraulic circuit
.................................................. 46
4.4Technical data table
............................................ 47
4.5Wiring diagram
.................................................... 49
1 USER'S MANUAL
1.1 Introduction
The new CPA is a high-performance, low-
emission heater for domestic hot water
production, powered by natural gas or LPG
and equipped with a compact, WATER-
COOLED, battery-powered burner with
electronic ignition, designed for indoor
installation.
1.2 Control panel
fig. 1 - Control panel
1 DHW temperature
indication at the outlet
from the boiler
2 Battery charge
indication. Fixed
symbol: Very low
battery; change as
soon as possible.
When flashing,
the battery is dead and
must be replaced.
3 Burner power
adjustment
4 Temperature
adjustment
5 Burner on indication
1.3 Turning the heater on and off
When the unitis working,
the temperature near the
peephole may be high.
Avoid contact as there
may be risk of burns.
Preliminary checks and operations
1 Make sure the hot water taps are
closed.
2Open the gas supply cock to the heater,
located at the gas connection to the unit.
3Check that the 1.5 V batteries are properly
installed with the correct polarity (+/-). To
replace the batteries, see (3.4 Replacing
the batteries).
4Alsoverify that the batteries are
sufficiently charged for heater
operation.
1.3.1 Turning the unit on
Turn the knob to the required water heating
level. The unit will begin operating every time
hot water is drawn.
fig. 2 - Turning the unit on
1.3.2 Turning the unit off
The burner goes off automatically when hot
water is no longer demanded.

cod. 3541S050 - Rev. 01 - 07/20195
EN
CPA
To use the unit again, no action is required.
To completely shut off the unit, place the knob
in the () position.
fig. 3 - Turning the unit off
If the water heater will not be used for an
extended period of time, close the gas cock
supplying the unit.
If the unit will be inactive
for an extended period of
time during the winter, all
water should be
removed to avoid ice
damage.
1.4 Settings
1.4.1 Setting the burner power manually
Use the knob (3 fig. 1) to
selectthe heater power.
You may choose between the
minimum, maximum, and intermediate
positions, depending on the required heating
power.
If the knob is turned counterclockwise, the
unit will operate at maximum power. If the
temperature is too high, for example in the
summer, or if you need a reduced flow
of not very hot water,turn
the knob clockwise. This
reduces the power, and therefore the
gas consumption.
In the ●position, the unit
is turned off.
1.4.2 Setting the temperature
Turn the water temperature selector
clockwise to increase the temperature, or
counterclockwise to decrease it.
fig. 4 - Setting the temperature
1.5 Faults
Once the adjustments described above have
been made, the heater is ready to operate
automatically. When a hot water tap is
opened, an intermittent discharge is
generated on the ignition electrode to light the
burner. All electronic models have an
ionization electrode built into the burner
to monitor flame presence. If
a malfunction or lack of gas causes
the heater to turn off, close the hot water tap.
It is then necessary to eliminate the fault or
obstacle preventing the gas from reaching the
heater, e.g., inadvertent closing of the gas
cock, empty gas cylinder, etc. To reactivate
the heater, close and open the hot water tap.
If no hot water is produced after eliminating
the cause and opening the hot water tap,
repeat the process.
If the problem persists, call the technical
support center.
Table 1 - Faults
The
does
ignite
burner
not
Absence of
gas
Check
the
flow
of
gas
to the
heater,
and make
sure the
pipes
have been
purged.

6cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
Failure of the
ignition/detecti
on electrode
Check the
electrode
cable, and
make sure
it's
properly
connected
and free of
deposits.
Defective gas
valve
Check
and/or
change
the gas
valve.
Activation of
the
overtemperat
ure protection
Damaged or
badly positio
ned heating
sensor
Check that
the
heating
sensor
is properly
installed
and
operating
and/or
change it.
Activation of
the flue
gas
thermostat
(after this
operation, the
Flue gas ther
mostat con
tact open
Check the
thermostat
.
Cables di
sconnected
Check the
connection
s.
unit is reset
by turning on
the tap, and
the
thermostat
cools off).
Thermostat
obstructed or
incorrectly si-
zed
Check the
thermo
stat.
Probe
disconnected
Check the
con-
nection or
change
the probe.
2 INSTALLATION MANUAL
2.1 General information
The heater may only be
installed by an authorized
technician, in accordance
with all instructions
contained in this manual,
standard UNE 26, and local
installation and exhaust
regulations.
2.2 Location
Make sure the water heater chosen is the
most suitable:
•To adequately meet the system’s hot water
requirements.
•For the gas to be used (see water heater
dataplate).
•For the water supply pressure, necessary
for operation (see table of characteristics).

cod. 3541S050 - Rev. 01 - 07/20197
EN
CPA
Make sure the room where the unit is
installed meets all the requirements of the
Current Regulations. In particular, this unit
is an “open chamber” type and must only
be installed and operate in permanently
ventilated places. An insufficient supply of
combustion air will compromise normal
operation and the evacuation of fumes.
Also, the fumes forming under these
conditions are extremely harmful to health
if dispersed in the domestic environment.
Otherwise there may be risk of suffocation
and intoxication or explosions and fire..
Therefore the place of installation must be
free of dust, flammable materials or
objects or corrosive gases.
Position the water heater as close as possible
to the hot water taps, near the sink, but
NEVER above a cooktop. It must also
be situated as close as
possible to the flue or
the start of the flue gas
exhaust pipe.
If the unit is installed inside a cabinet
or joined laterally to other elements,
space must be allowed for removing
the casing and performing normal
maintenance activities.
fig. 5 - Minimum distances
A
On each
side
>2cm
B
-
>50cm
C
In front
>2cm
2.3 Assembling the heater
Before assembling the
heater, make sure the
water and gas
connections are properly
secured, identified, and
positioned. See the
dimensions and connections
in section 4.2.
•Fix the plugs and hooks on the wall, in a
central position vertical to the
appliance, as shown in
the figure below.
•Mark the position of the bottom screws
•Hang the water heater on the plugs+hooks
and tighten the screws for fixing
the unit to the wall.

8cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
•Connect the hot and cold water
flexible tubes,remembering to
check their tightness. To avoid circulation
problems, do not remove the
cold water inlet filter.
•Remove the unit from the packaging.
•Verify all documents.
•Remove the plugs from the water and gas
connections (seefig. 9).
•On the rating label, check the destination
country reference and the type of gas for
which the unit is supplied.
85
85
170
84
84
168
fig.
Dima di montaggio CPA 11
110
110
220
110
110
220
fig.
Dima di montaggio CPA 14
6938771373389
PMS
bar
tmax °C
l/min
D
PMW bar
Appr. nr.
Qn (Hi)
Pn
kW
kW
-
-
NOx
H
2
O
/
-
CPA 11
CL.1M
Ser.n. 1925G60005
B11BS
II2HM3+ (IT)
II2E+3+ (FR)
II2H3+ (ES - PT- GB)
2
H/2HM/2E+ G20/G230 20 mbar
21.1
18.9
8.1
6
(< 56 mg/kWh
)
19
3
V
=
MADE IN CHINA
I3+ (BE)
I2E+ (BE)
10
0085
65
7.0
11
min
max
0
W
IPX4D
Suitable for operation in a partially protected
place

cod. 3541S050 - Rev. 01 - 07/20199
EN
CPA
fig. 8 - Rating label
2.4 Hydraulic connections
Never support the water
heater by the water/gas
connections. Make the
connections in
accordance with the
dimensions and connections
shown in section 4.1.
There are labels on the unit identifying the
1/2” water inlet pipe (white) and the 3/4” gas
inlet pipe (yellow).
fig. 9 - Connection cards
If the water hardness is over 25ºFr
(1ºF=10ppm CaCO3), the water must
be treated to avoid possible deposits on
the unit. 2.4.1 Water flow rate adjustment
Legend
1- Minimum water flow
regulation screw.
2-Maximum water flow
adjustment screw. 3 -
Safety valve drain water.
2.5 Gas connection
Before making the
connection, check that
the unit has been
prepared to operate with
the right type of fuel, and
carefully clean the gas
pipes to remove any
residue that might hinder
correct operation. Make
this connection in
accordance with the
dimensions and connections
in section 4.1.
1Connect the corresponding gas inlet (see
section 4.2) in accordance with current
regulations in the country where the heater
is being installed.
2Connect using a rigid metal pipe
(connection to a gas supply network) or
a flexible, continuous stainless steel
pipe (LPG installation), adding a shut-off
valve between the installation and the unit
(AS CLOSE TO THE UNIT AS POSSIBLE).
3Once the connection to the gas network is
complete, check that all gas connections
are tight. For this purpose, a tightness test
must be performed. To avoid damage to
the unit due to excess pressure, leave the
gas inlet valve closed.
4Check that the supplied pressure and gas
delivery values are those indicated for the
unit's consumption. See the technical data
table (section 4.5).

10cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
In installations with an
approved flexible pipe
for LPG, pay special
attention to the
following.
•The pipe must comply with applicable
regulations.
•Avoid areas with heat emissions.
•Prevent the pipe from bending or being
pinched shut.
•The connections on both sides (gas valve
and other components) must comply with
the regulations of the country where the
heater is installed.
2.6 Air and flue gas ducts
The diameter of the pipe
connecting to the flue must
not be smaller than that of the pipe
connecting to the draft hood. After the draft
hood, there must be a vertical segment at
least half a meter long. The dimensions and
installation of the flues and the
tube connecting to them must
comply with current standards.
2.6.1 FUME EXHAUST SAFETY DEVICE
(fume thermostat)
•The water heater’s safety device ensures
the correct exhaust of flue gases;
THEREFORE DO NOT DEACTIVATE
IT OR CARRY OUT ANY OPERATION ON
IT.
•If the safety device cuts in when the water
heater is started, checkthe flue gas
outlet,checking the exhaust
with a cold mirror or with any suitable
and approved measuring device.
•In case of a fault, only use original
replacements, otherwise the safety device
may not work properly.
•Fume thermostat replacement must be
carried out by qualified technicians,
proceeding as follows:
- - Remove the faulty fume thermostat by
undoing the 2 fixing screws.
- - Install a new original thermostat.
- - Fix the fume thermostat in its place
without overtightening the screws.
- - Check its correct operation.
Remember to make an
air inlet opening in the
room where the water
heater is installed (as
required by the current
regulations).
If the above instructions
are not observed there
may be risk of
suffocation or poisoning
due to gas or fumes
escaping.
3 SERVICE AND MAINTENANCE
All of the adjustments, commissioning
operations and periodic checks described
below must be performed by an
authorized technician in compliance
with current regulations. FERROLI

cod. 3541S050 - Rev. 01 - 07/201911
EN
CPA
declines all liability for property damage or injuries caused by unauthorized persons
tampering with the unit.
3.1 ADJUSTMENTS
3.1.1 Gas conversion
Conversion of the unit to a
type of gas other than the
factory setting must be
performed by an authorized
technician, using original
components and in
compliance with current
regulations in the country
where the unit will be used.
The unit can operate with methane gas, LPG or Propa-fig.14
- ne-Air. It is factory-set for one of the
two types of gas, as indicated on the packaging
and technical data plate. To operate the unit with
another type of gas, a conversion kit must be
used.

12cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
fig. 12 - fig.
16 -
3.2 COMMISSIONING
Commissioning of the
heater must be
performed by a trained,
specialized technician.
Checks that must be
performed during the
first ignition, after
maintenance operations
that require unplugging
the unit, and after any
operations on the unit's
safety devices or
components.
3.2.1 Before igniting the heater
•Carefully verify the tightness of the gas
installation using a soap and water solution
to check for leaks in the connections.
•Fill the hydraulic system and make sure no
air is present in the unit or system.
•Check that there are no water leaks in the
system or unit.
•Make sure the grounding and connection to
the electrical network are adequate.
•Check that the gas pressure is correct.
•Make sure there are no
flammable liquids or
materials near the heater.
•To avoid damaging the connections, do not
place the heater on the floor with
the connections facingdown.
If the above instructions
are not observed there
may be risk of
suffocation or poisoning
due to gas or fumes
escaping; danger of fire
or explosion. Also, there
may be risk of flooding the
room.
3.2.2 Checks during operation
•Lightthe unit.
•Make sure the fuel and water
systems are tight.
•Check the efficiency of the
air and flue gas ducts while
the heater is operating.
•Make sure the gas valve
modulates correctly.
•Verify that the heater ignites
easily. Turn it on and
off several times to make sure.
•Check that the fuel consumption
is as indicated.
3.3 MAINTENANCE
3.3.1 Periodic checks
In order for the unit to operate correctly, an
authorized technician must perform an
annual inspection, checking that:
•The control and safety devices (gas valve,
etc.) operate correctly.
•The exhaust vent is perfectly
efficient.
•The air and flue gas ducts and
terminal are free of
obstacles and leaks.
•The burner and exchanger are free of dirt
and deposits. Do not use chemicals or steel
brushes to clean them.

cod. 3541S050 - Rev. 01 - 07/201913
EN
CPA
•The electrode is free of deposits and
properly positioned.
fig. 17 - Electrode position
•The gas and water systems are perfectly
tight.
•The gas delivery and operating pressure
values are as indicated on the tables.
A soft, damp cloth may be used to clean the
casing and exterior parts of the heater, using
soapy water if necessary. Do not use
abrasive detergents or solvents.
3.3.2 Opening the casing To open
the casing:
fig. 18 - Opening the casing

14cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
3.4 REPLACING THE BATTERIES
To change the batteries,
proceed as described in fig.
19.

cod. 3541S050 - Rev. 01 - 07/201915
EN
CPA
4 TECHNICAL DATA AND CHARACTERISTICS
4.1 Dimensions and connections

16cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
4.2 Overview and main

cod. 3541S050 - Rev. 01 - 07/201917
EN
CPA
components
fig. 24 - Overview CPA 11
fig. 26 -
Hydraulic circuit
4 Combustion chamber
assembly
5 Gruppo bruciatori
6 Exhausthood
7 Copper heat exchanger
8 Solenoid valve
12Hot water
temperature sensor
13Battery pack
14Pulser
15DHW temperature
sensor
4.3 Hydraulic
circuit
1 Gas inlet
2 Cold water inlet
3 Hot water outlet
9 Induction
electrode
10Ignition
electrode
11Flue gas
sensor

18cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
4.4 Technical data table
Data
Units
CPA 6
CPA 11
CPA 14
Product identification codes
G20
GCA1HKKF
GCL1MKKA
GCI1PKKF
Product identification codes
G31
GCA1HLKF
GCL1MLKA
GCI1PLKF
Countries of destination
ES - PT - IT - FR - BE
Gas category
II2H3+ (ES-PT-GB) / II2HM3+ (IT) / II2E+3+ (FR) / I2E+ (BE)
/ I3+ (BE)
Maximum heat capacity
kW
11.8
21.1
26.8
Q
Minimum heat capacity
kW
6.3
8.1
10.7
Q
Maximum heat capacity
kW
10.4
18.9
23.8
Minimum heat capacity
kW
5.4
7.0
9.3
Performance at max. power
%
87
87
87
Burner injectors G20
n. x Ø
14 x 0.82
24 x 0.85
28 x 0.85
Gas supply pressure G20
mbar
20
20
20
Maximum gas delivery G20
m3/h
1.25
2.23
2.84
Minimum gas delivery G20
m3/h
0.67
0.86
1.13
Burner injectors G230
n. x Ø
14 x 0.95
24 x 0.95
28 x 0.95
Gas supply pressure G230
mbar
20
20
20
Maximum gas delivery G230
m3/h
0.97
1.73
2.20
Minimum gas delivery G230
m3/h
0.52
0.66
0.88
Burner injectors G31/G30
n. x Ø
8 x 0,49 / 6 x 0,47
18 x 0.49 / 6 x
0.47
16 x 0.49 / 12 x
0.47
Gas supply pressure G31/G30
mbar
37
37
37
Max. gas delivery G31/G30
m3/h
0.92
1.64
2.08
Min. gas delivery G31/G30
m3/h
0.49
0.63
0.83
NOx emission class
-
6 (<56 mg/kWh)
NOx
Max. operating pressure
bar
10
10
10
PMS
Min. operating pressure
bar
0.2
0.2
0.2
DHW delivery ∆25º
l/min
6.0
10.8
13.6
DHW delivery ∆30º
l/min
5.0
9
11.4
Degree of protection
IP
X4D
Supply voltage
V/Hz
3V =
Absorbed electrical power
W
/
/
/
Empty weight
Kg
8.5
9.50
13.50
Type of unit
B11BS
ErP product fiche (Models NG)

cod. 3541S050 - Rev. 01 - 07/201919
EN
CPA
Trademark: COINTRA
Type: Conventional water heater
Item
Symbol
Unit
Value
CPA 6
GCA1HKKF
CPA 11
GCL1MKKA
CPA 14
GCI1PKKF
Declared load profile
XS
M
M
Water heating energy efficiency
class (from A+ to F)
A
A
A
Daily electricity consumption
Qelec
kWh
0,000
0,000
0,000
Annual electricity consumption
AEC
kWh
0
0
0
Water heating energy efficiency
NWh
%
58
76
74
Daily fuel consumption
Qfuel
kWh
2,874
8,185
8,562
Annual fuel consumption
AFC
GJ
2
6
6
Thermostat temperature settings of the water
heater, as placed on the market
MAX
MAX
MAX
Sound power level
LWA
dB
57
58
59
Emissions of nitrogen oxides
NOx
mg/kWh
52
37
42
ErP product fiche (Models LPG)
Trademark: COINTRA
Type: Conventional water heater
Item
Symbol
Unit
Valore
CPA 6
GCA1HLKF
CPA 11
GCL1MLKA
CPA 14
GCI1PLKF
Declared load profile
XS
M
M
Water heating energy efficiency
class (from A+ to F)
A
A
A
Daily electricity consumption
Qelec
kWh
0,000
0,000
0,000
Annual electricity consumption
AEC
kWh
0
0
0
Water heating energy efficiency
NWh
%
58
76
74
Daily fuel consumption
Qfuel
kWh
2,874
8,185
8,562
Annual fuel consumption
AFC
GJ
2
6
6
Thermostat temperature settings of the water
heater, as placed on the market
MAX
MAX
MAX
Sound power level
LWA
dB
57
58
59
Emissions of nitrogen oxides
NOx
mg/kWh
37
58
62

20cod. 3541S050 - Rev. 01 - 07/2019
EN
CPA
4.5 Wiring diagram
fig. 27 -
Key
8 Gas valve
9 Detection electrode
10Ignition electrode
11DHW temperature sensor
12Safety thermostat
13Contact fume thermostat
15Batteries
16Electronic controller
17Flow switch
