1.0 OPERATING CONDITIONS
1.1 GENERAL INFORMATIONS
Our appliances are disigned and optimised in order to obtain high performance. This appliance must not be used by
people with limited physical, mental or sensory abilities or without experience and knowledge of it, unless instructed in
its use by those responsible for thir safety.
1.2 OPERATING CONDITIONS
Do not store pressurised spray botles bearing the wording “flammable”. Risk of explosion! The
appliance must only be used within the temperature range specified by the manufacturer.
English
Deutsch
2.0 SPECIFICATIONS
The appliance conforms to European directives as
given in detail on the attached certificate of EC
conformity.
The data are featured on the CE plate inside the
appliance.
Model
Voltage
Total
Total current
Yield (Kg)
Yield (Kg)
Yield (Kg/h)
Power
demand
+65°/+3°C
+65°/-18°C
-10°C/-18°C
W5T
230V/50 Hz
886W
4.9A
14
10
10
W6T
230V/50 Hz
1088W
6.0A
18
14
15
França is
W7T
230V/50 Hz
1096W
6.1A
25
18
20
W10T
400V 3N/50 Hz
3345W
6.2A
40
28
35
W14T
400V 3N/50 Hz
3440W
6.6A
55
35
50
W20T
400V 3N/50 Hz
5590W
16.4A
80
55
-
400V 3N/50 Hz
6480W
19.0A
115
75
-
W20K
400V 3N/50 Hz
5590W
16.4A
80
55
-
400V 3N/50 Hz
6480W
19.0A
115
75
-
W40K
400V 3N/50 Hz
6480W
19.0A
120
80
-
400V 3N/50 Hz
8310W
24.4A
200
140
-
Русский
24

3.0 INSTALLATION
3.1 INTRODUCTION
The appliance must be used solely for the purpose it was specifically designed for, i.e. for storing food within the
temperature range stated by the manufacturer. Understand that any other use shall be considered improper.
The Manufacturer declines all responsibility in the event of improper use of the appliance.
Installation must be carried out by specialized technical personnel only.
3.2 DAMAGE CHECK
Check all parts of the appliance for damage and that the standard-issue accessories inside are as expected.
3.3 CLEANING
Remove the PVC film covering the inside and outside of the appliance. Clean the compartment inside using a sponge
damp with lukewarm water.
3.4 WORKING CONDITIONS
Make sure the room in which the appliance is installed meets the following conditions:
Room temperature in the range +5°C to +43°C.
Positioning away from sources of heat and in a well ventilated area.
Italiano
English
3.5 LEVELLING
Move the appliance into its final position and adjust the screw-type feet until you have the unit perfectly level.
Keep the unit at least 10 cm from the wall for a proper ventilation of the technical compartment.
3.6 PUTTING INTO OPERATION
Before connecting to the power mains, make sure:
Voltage and frequency are in conformity with the working conditions featured on the CE plate inside the appliance: maximum tolerance is
±10% of the rated value.
The power supply circuit meets regulations in force.
The electrical system is fitted with a residual current circuit breaker (automatic cutout).
Earthing is compulsory.
If the appliance is going to be switched off for a length of time, it is best to disconnect its power cord.
The manufacturer cannot be held responsible for damage or injury resulting from failure to earth the appliance
or inefficient earthing thereof, incorrect installation, tampering, poor maintenance and incompetent use, or
resulting from failure to comply with electrical safety standards in force in the
country where the appliance is used.
25
Deutsch
Français
Русский

4.0
CONTROL PANEL
Italiano
English
Deutsch
Français
Русский
26

On/Off. To switch the instrument off. Start/Stop
View needle temperature
Switch to time-based cycle
Decrease
Increase
Select hard blast chilling cycle
Select soft blast chilling cycle
Select blast freezing cycle
Select sterilization (optional)
Manual defrosting
Select programs

5.0 DESCRIPTION OF CYCLES
5.1 NOTIONS ON BLAST CHILLING/BLAST FREEZING CYCLES
Soft Hard Freezing
Italiano
Soft blast chilling is employed to cool
the product quickly to a core temperature
of +3°C with a constant air tempera-
ture of -2°C
Ideal for delicate, lightweight and thin
products: food tem-perature is lowered
quickly but without damaging the
outside. The food can be stored for 5/6
days.
Whether dealing with products that are
cold or at room tem-perature, or products
that have just been cooked, blast chill-
ing time from +65°C to +3°C must not
exceed 90 minutes.
Hard blast chilling is employed to cool
the product quickly to a core temperature
of +3°C with negative air temperature
during the first stage (-35°C) and
positive temperature during the
second stage (0°C). Ideal for products
that are dense, have a high fat con-tent,
come in large portions or are hard to
cool. The food can be stored for 5/6
days.
Whether dealing with products that are
cold or at room tem-perature, or products
that have just been cooked, blast chill-
ing time from +65°C to +3°C must not
exceed 90 minutes.
Blast freezing is employed to freeze the
product quickly to a core temperature of
-18° with an air temperature of -38°C
Ideal for increasing storage life of food
(weeks or a few months), quick blast
freezing preserves the product's original
visual, aromatic and flavour properties,
and stops macro crystals forming,
keeping quality and texture intact.
Whether dealing with products that are
cold or at room temperature, or products
that have just been cooked, blast chilling
time from +65°C to - 18°C must not
exceed 240 minutes.
English
Deutsch
5.2 BLAST CHILLING/BLAST FREEZING MODES
One of two modes can be selected for the blast chilling/blast freezing cycle:
Temperature-based using the
Time-based using the timer
needle probe
5.3 HOLDING
At the end of the blast chilling/blast freezing cycle, the appliance automatically switches to holding mode, which
continues indefinitely and is only stopped using the manual stop command.
Do not use the blast chiller/blast freezer as a normal storage unit.
The chilled/frozen product should be kept in a suitable appliance (refrigerator/freezer).
Holding temperature at end of cycle
Soft: +3°C Hard: +3°C Blast Freezing: -20°C
27
Français
Русский

Italiano
English
Deutsch
Français
Русский
6.0 OPERATIONS
6.1 SWITCHING ON/OFF
Once you have turned on the appliance's power, the control panel (3.0) automatically runs a lamp test. The LEDs and
displays come on for a few seconds, after which the display switches "OFF" (control panel is off but still powered).
Switching on
Hold button down for a few seconds: the appliance goes into standby. During this phase, the machine stands by to
receive a command.
Display DY1 gives the temperature inside the appliance.
Display DY2 reads "---".
Switching off
Hold button down for a few seconds: the appliance switches "OFF".
Display DY1 reads "OFF".
Display DY2 stays off.
6.2 BLAST CHILLING/BLAST FREEZING
See points 7.0 and 8.0 for details.
6.3 OPENING THE DOOR WHILE A CYCLE IS RUNNING
If the door is opened while a blast chilling/blast freezing cycle is running, the "]-[" code will flash up intermittently on
display DY2 and, at the same time, a buzzer will sound. The compressor and fans inside stop and only restart once the
door is closed.
The blast chilling/blast freezing cycle cannot be started with the door open. If the door stays open for
longer than 30 seconds during the blast chilling/blast freezing cycle, the blast chilling
cycle is stopped.
6.4 PUMP DOWN
Pump-down is a system designed to protect the compressor and its job is to avoid excessive working pressures
during start-up.
Stopping the compressor
When button is pressed to stop a blast chilling, blast freezing or holding cycle manually, the compressor keeps
working for 5more seconds.
6.5 TEMPERATURE SENSOR AND NEEDLE PROBE READINGS
While a temperature-based cycle is running, DY1 indicates the value measured by the needle probe. You can
view compartment sensor temperature by pressing the button relating to the cycle selected: , or .
The value is put up on DY1 for 5seconds.
While a time-based cycle is running, DY1 indicates the value measured by the compartment sensor. You can view
needle probe temperature by pressing button . The value is put up on DY1 for 5seconds.
6.6 HEATED NEEDLE PROBE (Optional extra)
The heated needle probe (optional extra) has a device that heats its tip, making it easier to pull out of frozen products.
Holding button down for 5seconds at the end of a blast freezing cycle turns on heating so that the probe can be easily
removed from the frozen product. Heating only comes on if the door is open.
6.7 AUTOMATIC DEFROSTING
During operation, frost forms on the surface of the evaporator: this is normal but it reduces evaporator efficiency. The
purpose of defrosting is to restore full efficiency. Defrosting is performed automatically:
28

-At the end of each blast chilling/blast freezing cycle.
-At 6-hour intervals during holding.
The purpose of the evaporator sensor is to produce the utmost efficiency and shorten defrosting times by measuring the
end-of-defrosting temperature.
6.8 MANUAL DEFROSTING
This mode should be used only when further defrosting is required in addition to that performed
automatically by the appliance.
Shortcut commands while in standby mode
Make sure the appliance is working (6.1).
Hold button down for 5seconds.
The led by the button comes on, and goes off when cycle ends.
The defrosting cycle stops automatically. How long it takes depends on how much frost there is on the evaporator
coil.
Once defrosting has finished, the appliance resumes normal operation.
7.0 TEMPERATURE-BASED BLAST CHILLING/BLAST FREEZING
Italiano
English
7.1 TEMPERATURE-BASED SOFT BLAST CHILLING
The temperature-based soft blast chilling cycle is controlled by the needle probe.
Shortcut commands while in standby mode
1
Soft blast chilling
2
Start
Detailed commands sequence:
1. Make sure the appliance is in standby mode (6.1).
2. Insert the needle probe in the product to be chilled (10.0).
3. Press button to select the soft blast chilling cycle.
The led button comes on.
Display DY1 gives the setpoint of the air in the compartment (-2°C).
Display DY2 reads “---”.
4. Press button to start the soft blast chilling cycle.
The led button comes on.
The compressor only starts working 5seconds after key is pressed (pump-down 6.4).
DY1 gives needle probe temperature, and DY2 the cycle time remaining, counting down from 90 minutes.
If you press button while the cycle is running, you can view the time elapsed since it started.
5. A buzzer sounds to advise that the blast chilling cycle has finished.
6. At the end of the cycle, holding mode starts and continues indefinitely at a holding temperature of +3°C.
The led button flashes.
If you press button during holding time, you can view the time of the cycle just completed to see how long
it took.
The holding stage must last only as long as strictly necessary.
7. To exit holding mode, press button .
The led button goes off.
The compressor stops 5seconds after button is pressed (pump-down 6.4).
29
Deutsch
Français
Русский

Italiano
English
Deutsch
Français
Русский
Important
Countdown starts when core temperature measured by the needle probe drops below +65°C.
When a soft blast chilling cycle is started, the compressor works non-stop until air temperature in the
compartment reaches -2°C. After this, it can cycle on and off to keep this temperature constant and prevent
frost from forming.
The blast chilling cycle ends when the product's core temperature measured by the needle probe reaches +3°C. The
cycle cannot last more than 90 minutes.
7.2 TEMPERATURE -BASED HARD BLAST CHILLING
The temperature-based hard blast chilling cycle is controlled by the needle probe.
Shortcut commands while in standby mode
1
Hard blast chilling
2
Start
Detailed commands sequence:
1. Make sure the appliance is in standby mode (6.1).
2. Insert the needle probe in the product to be chilled (10.0).
3. Press button to select the hard blast chilling cycle.
The led button comes on.
Display DY1 gives the setpoint of the air in the compartment (-35°C).
Display DY2 reads “---”.
4. Press button to start the hard blast chilling cycle.
The led button comes on.
The compressor only starts working 5seconds after key is pressed (pump-down 6.4).
DY1 gives needle probe temperature, and DY2 the cycle time remaining, counting down from 90 minutes.
If you press button while the cycle is running, you can view the time elapsed since it started.
5. A buzzer sounds to advise that the blast chilling cycle has finished.
6. At the end of the cycle, holding mode starts and continues indefinitely at a holding temperature of +3°C.
The led button flashes.
If you press button during holding time, you can view the time of the cycle just completed to see how long
it took.
The holding stage must last only as long as strictly necessary.
7. To exit holding mode, press button .
The led button goes off.
The compressor stops 5seconds after button is pressed (pump-down 6.4).
Important
Countdown starts when core temperature measured by the needle probe drops below +65°C.
When a hard blast chilling cycle is started, the compressor works non-stop until air temperature in the
compartment reaches -35°C. After this, it can cycle on and off to keep a constant temperature of -2°C, preventing
the formation of frost.
The blast chilling cycle ends when the product's core temperature measured by the needle probe reaches +3°C. The
cycle cannot last more than 90 minutes.
7.3 TEMPERATURE -BASED BLAST FREEZING
The temperature-based blast freezing cycle is controlled by the needle probe.
30

Shortcut commands while in standby mode
1
Blast freezing
2
Start
Detailed commands sequence:
1. Make sure the appliance is in standby mode (6.1).
2. Insert the needle probe in the product to be chilled (10.0).
3. Press button to select the blast freezing cycle.
The led button comes on.
Display DY1 gives the setpoint of the air in the compartment (-38°C).
Display DY2 reads “---”.
4. Press button to start the blast freezing cycle.
The led button comes on.
The compressor only starts working 5 seconds after key is pressed (pump-down 6.4)
DY1 gives needle probe temperature, and DY2 the cycle time remaining, counting down from 240 minutes.
If you press button while the cycle is running, you can view the time elapsed since it started.
5. A buzzer sounds to advise that the blast chilling cycle has finished.
6. At the end of the cycle, holding mode starts and continues indefinitely at a holding temperature of -20°C.
The led button flashes.
If you press button during holding time, you can view the time of the cycle just completed to see how long
it took.
The holding stage must last only as long as strictly necessary.
7. To exit holding mode, press button .
The led button goes off.
The compressor stops 5seconds after button is pressed (pump-down 6.4).
Important
Countdown starts when core temperature measured by the needle probe drops below +65°C.
When a blast freezing cycle is started, the compressor works non-stop until air temperature in the
compartment reaches -38°C. After this, it can cycle on and off to keep this temperature constant.
The blast freezing cycle ends when the product's core temperature measured by the needle probe reaches -18°C. The
cycle cannot last more than 240 minutes.
8.0 TIME-BASED BLAST CHILLING/BLAST FREEZING
Italiano
English
Deutsch
Français
8.1 TIME-BASED SOFT BLAST CHILLING
The time-based soft blast chilling cycle is controlled by the timer.
Shortcut commands while in standby mode
1
2
3
Soft blast chilling
Time-based cycle
Detailed commands sequence:
1. Make sure the appliance is in standby mode (6.1).
2. Press button to select the soft blast chilling cycle.
The led button comes on.
Display DY1 gives the setpoint of the air in the compartment (-2°C).
Start
31
Русский

Italiano
English
Deutsch
Display DY2 reads “---”.
3. Press button to select a time-based cycle.
4. Use buttons and to set the desired cycle time.
5. Press button to start the soft blast chilling cycle.
The led button comes on.
The compressor only starts working 5seconds after key is pressed (pump-down 6.4).
DY1 gives room probe temperature, DY2 the cycle time remaining.
If you press button while the cycle is running, you can view the time elapsed since it started.
6. A buzzer sounds to advise that the blast chilling cycle has finished.
7. At the end of the cycle, holding mode starts and continues indefinitely at a holding temperature of +3°C.
The led button flashes.
If you press button during holding time, you can view the time of the cycle just completed to see how long
it took.
The holding stage must last only as long as strictly necessary.
8. To exit holding mode, press button .
The led button goes off.
The compressor stops 5seconds after button is pressed (pump-down 6.4).
Important
When a soft blast chilling cycle is started, the compressor works non-stop until air temperature in the
compartment reaches -2°C. After this, it can cycle on and off to keep this temperature constant and prevent
frost from forming.
The blast chilling cycle ends when the timer completes the countdown.
8.2 TIME -BASED HARD BLAST CHILLING
The time-based hard blast chilling cycle is controlled by the timer.
Shortcut commands while in standby mode
1
Hard blast chilling 2
Time-based cycle
3
Start
Français
Русский
Detailed commands sequence:
1. Make sure the appliance is in standby mode (6.1).
2. Press button to select the hard blast chilling cycle.
The led button comes on.
Display DY1 gives the setpoint of the air in the compartment (-35°C).
Display DY2 reads “---”.
3. Press button to select a time-based cycle.
4. Use buttons and to set the desired cycle time.
5. Press button to start the hard blast chilling cycle.
The led button comes on.
The compressor only starts working 5seconds after key is pressed (pump-down 6.4).
DY1 gives room probe temperature, DY2 the cycle time remaining.
If you press button while the cycle is running, you can view the time elapsed since it started.
6. A buzzer sounds to advise that the blast chilling cycle has finished.
7. At the end of the cycle, holding mode starts and continues indefinitely at a holding temperature of +3°C.
The led button flashes.
32

If you press button during holding time, you can view the time of the cycle just completed to see how long
it took.
The holding stage must last only as long as strictly necessary.
8. To exit holding mode, press button .
The led button goes off.
The compressor stops 5seconds after button is pressed (pump-down 6.4).
Important
When a hard blast chilling cycle is started, the compressor works non-stop until air temperature in the
compartment reaches -35°C. After this, it can cycle on and off to keep a constant temperature of -2°C, preventing
the formation of frost.
The blast chilling cycle ends when the timer completes the countdown.
8.3 TIME -BASED BLAST FREEZING
The time-based blast freezing cycle is controlled by the timer.
Shortcut commands while in standby mode
1
Blast freezing
2
Time-based cycle3
Start
Italiano
English
Detailed commands sequence:
1. Make sure the appliance is in standby mode (6.1).
2. Press button to select the blast freezing cycle.
The led button comes on.
Display DY1 gives the setpoint of the air in the compartment (-38°C).
Display DY2 reads “---”.
3. Press button to select a time-based cycle.
4. Use buttons and to set the desired cycle time.
5. Press button to start the blast freezing cycle.
The led button comes on.
The compressor only starts working 5seconds after key is pressed (pump-down 6.4).
DY1 gives room probe temperature, DY2 the cycle time remaining.
If you press button while the cycle is running, you can view the time elapsed since it started.
6. A buzzer sounds to advise that the blast chilling cycle has finished.
7. At the end of the cycle, holding mode starts and continues indefinitely at a holding temperature of -20°C.
The led button flashes.
If you press button during holding time, you can view the time of the cycle just completed to see how long
it took.
The holding stage must last only as long as strictly necessary.
8. To exit holding mode, press button .
The led button goes off.
The compressor stops 5seconds after button is pressed (pump-down 6.4).
Important
When a blast freezing cycle is started, the compressor works non-stop until air temperature in the
compartment reaches -38°C. After this, it can cycle on and off to keep this temperature constant.
The blast freezing cycle ends when the timer completes the countdown.
33
Deutsch
Français
Русский

Italiano
English
9.0 PROGRAMS
9.1 CREATING A NEW PROGRAM
If the product comes in small portions, the needle probe cannot be used and, moreover, cooling is quick and will take
much less than the maximum time. In such cases, it is a good idea to store a program with a predefined time.
Using the programs feature, you can store up to 99 customized blast chilling/blast freezing cycles, with a time preset by
the user for each.
Shortcut commands while in standby mode
1
Soft blast chilling
1
Hard blast chilling
1
Blast freezing
2
Time-based cycle
Deutsch
Français
Русский
3
Select time
3
Select time
4 Save
Detailed commands sequence:
1. Make sure the appliance is in standby mode (6.1).
2. Select a soft or hard blast chilling cycle or blast freezing cycle by pressing button , or
respectively.
3. Press button to select a time-based cycle.
4. Use buttons and to set the desired cycle time.
5. Hold button down for 5seconds to enter the program menu.
DY1 reads «P1»; DY2 shows the default cycle time or «P1» if it has already been saved before.
6. Use buttons and to select the number of the available program.
Led , or lights to indicate the kind of cycle the program refers to.
7. Hold button down for 5seconds to store cycle in the memory.
9.2 CALLING UP AN EXISTING PROGRAM
Shortcut commands while in standby mode
1 Programs
2
Select program
2
Select program
3 Start
34

Detailed commands sequence:
1. Make sure the appliance is in standby mode (6.1).
2. Press button to call up an existing program.
DY1 reads “P1”.
3. Use buttons and to select the number of the available program.
4. Press button to start the blast chilling/blast freezing cycle.
Italiano
10.0 HACCP ELECTRONIC RECORDER (optional)
The electronic recorder is connected directly to the main control panel. It is used to record and produce a paper
printout of temperature and time data relating to the blast chilling and blast freezing cycles.
Maximum roll dimensions: carta termica 58×Ø30 mm.
Print width: 48 mm.
Number of dots per line: 384.
Print density: 8 punti per mm.
Serial communication: RS485.
Switching on/off
1. To switch the instrument on/off, press the button.
Manual paper feed
1. To feed the paper through manually, press the button.
Replacing paper
1. Switch the instrument off using the button.
The led button comes on.
2. Open the front using the button.
3. Insert the roll of paper under the roller.
4. Hold the button down until the roller starts pulling the roll of paper.
5. Position the roll of paper in the relevant slot.
6. Close the front.
Print test
1. Switch off the instrument.
2. Press the button.
3. Switch the instrument on.
11.0 OPERATING TIPS AND WARNINGS
Pre-cooling
1
Soft blast chilling
2
Start
English
Deutsch
Français
Before blast chilling/blast freezing, it is best to pre-cool the compartment by running a temperature-based soft cycle.
Avoid opening the doors while a blast chilling/blast freezing cycle is running.
35
Русский

Italiano
English
Core temperature probe
To achieve best operation, the needle probe must be positioned in the centre of the
product.
Make sure the probe tip does not poke through the product or touch the pan.
Do not insert the probe into food at temperatures exceeding 100 ° C to avoid
damaging the sensor. Leave the first diluting the product for a few minutes in
ambient.
Arranging products on pans
Use shallow pans so that the product surface has better contact with the air.
Arrange the products not overlapping on each other.
Filling the unit
Leave at least a 2cm gap between one pan and the next so as to allow
sufficient airflow.
Do not cover containers with lids of any kind.
Distributing pans
When the unit is being partially filled, spread the pans out evenly so that they use the
full height.
Do not leave hot products inside the compartment without running the cycle.
Deutsch
Français
Cycle di sterilization UV
1 Sterilization UV
Before you start the sterilization cycle, connect the lamp to the socket on the dashboard, put it inside the
compartment to be sterilized, close the door and start the cycle with the appropriate button.
Don’t open the door during the sterilization cycle as UV rays generated by the lamp can be harmful to the skin.
Defrost with remote system
1 Defrost
In models with remote system we suggest to make a manual defrost after each chilling/freezing cycle. To
make efficient defrost make sure that the deviance is in standby, open the door and press the appropriate button.
The appliance features a tray at the bottom to catch water produced by defrosting.
Empty the water out of it at regular intervals.
Русский
36

12.0 ALARMS
Each visual alarm warning is associated with an audible warning.
You can silence the buzzer by pressing button .
“E0” flashing; compartment sensor error.
Tells you that compartment sensor is faulty or is not connected properly.
If the alarm occurs during a blast chilling/blast freezing cycle, the cycle is stopped and the control panel goes into “standby”.
If the alarm occurs during a holding stage, the compressor cycles on and off, at preset time intervals, to ensure products are preserved
properly until the problem is solved.
No blast chilling/blast freezing cycle can be started.
Remedies:
-Check the integrity of the probe and the connection to the power board.
-Replace the sensor type PTC.
“E1” flashing evaporator probe error.
Tells you that evaporator probe is faulty or is not connected properly.
The defrost will always have the maximum set.
The fan is only active while the compressor.
Remedies:
-Check the integrity of the probe and the connection to the power board.
-Replace the sensor type PTC.
“E3” flashing; needle probe error.
Tells you that needle probe is faulty or is not connected properly.
A temperature-based blast chilling/blast freezing cycle cannot be started with “E3” alarm active, but a time-based blast chilling/blast freezing
cycle can be started even with “E3” alarm active.
Remedies:
-Check the integrity of the probe and the connection to the power board.
-Replace the sensor type PTC.
“]-[”flashing; door open.
Warns that the door has been opened while a blast chilling/blast freezing cycle is running.
Compressor and fans stop.
“HP” flashing; high pressure.
Reports excessive pressure in refrigerating circuit.
Compressor and fans stop.
No blast chilling/blast freezing cycle can be started.
Remedies:
-Not to introduce the product with too high temperature above 100 ° C, allow for venting in a few minutes before to
insert in the blast chieller.
-Ensure that there is sufficient space between the back and blast the wall (at least 15-20 cm) prevent backflow
of air cooling.
-Check the cleanliness of the grid on the front of the condenser unit, which may remove impurities with a vacuum
cleaner/brush.
If alarm persists, contact assistance department.
Italiano
English
Deutsch
Français
“rES” flashing; reset.
Tells you that the power supply has been cut out during a blast chilling/freezing cycle.
When the power supply problem will be solved, the machine will resume the cycle showing “rES” on display
Push button to clear “rES”.
37
Русский

13.0 CONNECTION DIAGRAM
Italiano
English
Deutsch
1-3
230 V power supply
4-5-6
Not used
10-11
Compressor management output
9-11
Pump-down solenoid valve management output
8-11
Evaporator fan management output
7-11
Defrost management output
12-13-14
UV lamp management output (optional)
15-19
Low pressure alarm digital input (not used)
Franç ais
16-19
Compressor thermal cutout alarm digital input (not used)
17-19
Door microswitch digital input
18-19
High pressure alarm digital input
20-21
PTC input (not used)
20-22
Core probe PTC input
23-24
Evaporator sensor PTC input
23-25
Compartment sensor PTC input
A-B
Heated probe input (optional)
C-D
12V~40VA power supply (optional)
The expansion board is only fitted in the event the appliance features the heated needle probe.
Русски й
38
