Comica CVM-AX1 User manual

CVM-AX1
3.5mm Dual-Groups Audio Mixer
USER MANUAL

Foreword
Thanks for purchasing COMICA CVM-AX1 3.5mm Dual-Groups Audio Mixer.
The Comica CVM-AX1 is a 3.5mm Dual-Groups Audio Mixer for shooting videos
with any camera and camcorder . It is designed with support positive & passive
mic, real-time monitoring, dual gain-control knobs functions etc. It provides a
compact audio mixing solution.
Please read this manual carefully before using. This product has been precisely
calibrated at the factory, do not assemble and disassemble parts by yourself.
. Dual 3.5mm Mics(2-Groups) Audio Mixer
. Support both Positive and Passive Mic
. Support Real-time Monitoring
. Dual Gain-Control Knobs
. Mono/Stereo Output Switch
. Designed with Working Status Indicator
. Driven by AAA Battery
. Three Cold Shoes for Flexible Use
. Aluminum Alloy Material
Dual Mics
Audio Mixer
Dual Gain-Control
Knobs
Mono/Stereo
Output Switch
Real-time
Monitoring
Support Positive &
Passive Mic
Driven by
AAA Battery
Three Cold-shoes
for Flexible Use
Aluminum Alloy
Material
Working Status
Indicator
Main Features
1

Notice
Mono and stereo inputs cannot be used simultaneously.
Please do not put the device beside the heat or interference source.
Please avoid falling, collision or pounding during usage.
Don’t expose the device in rain or moist environment .
Package Contents
Audio Mixer
3.5mm Audio Output Cable
Cold Shoe Mount
User Manual
Warranty Card
1
1 2
3 4 5
2
3
4
5
CVM-AX1
3.5mm Dual-Groups Audio Mixer
USER MANUAL
2

Components and Instruction
Audio Mixer
Cold Shoe Interface
LINE/MIC/3V Switch
Mono Input Jack(Right)
Stereo Input Jack
Mono Input Jack(Left)
AAA Battery Holder
Gain-Control Knob
1
2
3
4
5
6
7
Audio Output Jack
Real-time Monitoring Jack
3/8 Screw Hole
1/4 Screw Hole
Mono/Stereo Switch
Power Indicator Light
Power Switch
8
9
10
11
12
13
14
677
1
1
1
2
8910 11 12 13 14
3452
3

Installation and Usage
1. Mount the cold shoe mount to the audio mixer
2. Fix the audio mixer to the camera with the cold shoe mount
4

3. Connect audio mixer’s Audio Output Jack(OUT) and camera Audio
Input Jack with a audio cable
5

4. Mount mics to the cold-shoe Interfaces of audio mixer
6

5. Connect the mic and audio mixer
7

For stereo mic, connect it to the stereo input jack ('S')
For mono mic, connect it to the corresponding 'L' / 'R' input jack
Before using, you need to set the "LINE/MIC/3V switch" to the
corresponding position according to the microphone type
LINE/MIC/3V Switch LINE/MIC/3V Switch
a. If you are using LINE IN input, set the switch to the “LINE”;
b. If you are using a positive microphone(Microphone with internal
battery-powered), set the switch to the “MIC”;
c. If you are using a passive microphone(Microphone without internal
battery-powered), set the switch to the “3V”
8

6.Set Mono/Stereo switch
7. To ensure the recording quality, please turn Gain-Control Knob of
the left and right to the proper volume position to get the best audio
effect
Mono/Stereo switch
Gain-Control Knob Gain-Control Knob
a. When uses only one mic or one channel, select ‘M’ and the output is mono
b. When uses two mics or two channels simultaneously, you can optionally
switch to 'M' (Mono Mode) or 'S' (Stereo Mode) according to your needs
9

Real-time Monitoring Jack
Power Switch
Indicator light
8.Power on, the indicator light up, and recording starts
9.If you want to check the audio, you can plug headphone cable into
the Real-time Monitoring Jack to monitor audio
10

Tech Parameters
Input
Output
Battery
Dimension
Weight
Working Temperature
Mono x 2(L/R); Stereo x 1(S)
3.5mm Port Output;Headphone Output
1.5V AAA x 2
95 x 55 x 49mm
225g
0℃~ +50℃
11

用户使用手册
3.5MM双路音频麦克风混音器
CVM-AX1

前 言
产品主要功能
感谢您购买科唛COMICA CVM-AX1 3.5MM双路音频麦克风混音器。
此产品可搭配相机、摄像机进行音频录制。它设计有支持主动/被动式麦克风、实
时监听、双音量调节、单/双声道转换、工作状态指示灯、AAA电池供电、多冷靴
接口等功能，全铝合金材质制作，功能十分强大，能带给您更好的音质效果。
使用前请认真阅读此使用说明书，本产品在出厂时已进行精密校准，请勿自行组
装拆卸零部件，否则不予保修！
.双路3.5mm麦克风音频合二为一
.支持主动式/被动式麦克风
.实时监听
.双音量调节旋钮
.单声道/立体声音频输出
.状态指示灯设计
.AAA电池供电
.底部&两侧冷靴接口设计
.全金属制造
双路麦克风
合二为一
双音量
调节旋钮
单声道
立体声可选
实时监听 支持主/被动式
麦克风
状态指示灯 AAA电池
供电
冷靴接口 全金属制造
1

注意事项
单声道和立体声输入不能同时工作
使用时请远离热源或干扰源
使用时请避免掉落，碰撞或重击
请勿在下雨或潮湿环境环境中使用，否则会有短路的危险
包装清单
混音器
3.5mm音频输出线
冷靴座
说明书
保修卡
1
2
3
4
5
1 2
345
CVM-AX1
3.5mm Dual-Groups Audio Mixer
USER MANUAL
2

部件介绍及说明
混音器主体
冷靴接口
LINE/MIC/3V开关
单声道输入孔（右）
立体声输入孔
单声道输入孔（左）
AAA电池仓
音量控制旋钮
1
2
3
4
5
6
7
音频输出孔
监听孔
3/8螺孔
1/4螺孔
单声道/立体声开关
指示灯
电源开关
8
9
10
11
12
13
14
677
1
1
1
2
8910 11 12 13 14
3452
3

安装与使用
1.将冷靴座安装至混音器
2.将混音器通过冷靴座固定至相机
4
