Command Alcon TrackIt RDT-A7.0 Quick guide

RDT-A7.0
Version: 2.0
Hardware Installation &
Configuration
03/04/19

RDT-A7.0 Installation Guide
2
RDT-A7.0 System Installation Guide
This guide provides instructions for installing the Command Alkon Incorporated Ruggedized Driver
Tablet (RDT)-A7.0 system in vehicles using TrackIt. When the RDT-A7.0 is combined with the
OBC317, the system provides functionality for comprehensive data and tracking features with
wireless communication and ruggedized tablet display.
As of 2018, the OBC and RDT-A7.0 system will not be distributed, though support will
continue for existing configurations. Instead, the Engine Data Controller (EDC) and
Android tablets will be the primary equipment distributed to customers.
Refer to the OBC317 Installation Guide if you have not yet installed the OBC unit.
Overview
This installation guide includes the following steps:
1. Assemble the required components for the installation. Installation will vary depending on the
combination of hardware options you receive.
2. Install the RDT-A7.0 system. Proper installation is key for ensuring the unit functions correctly
and maintains safety standards.
3. Connect the OBC to the RDT-A7.0. Once the RDT-A7.0 is installed, it will need to be
configured with the OBC to begin receiving engine data and communicating with dispatch.

RDT-A7.0 Installation Guide
3
Hardware Requirements
The following section provides the components needed to install the RDT-A7.0 system. Because the
RDT-A7.0 only connects via wireless network, the OBC317 is a requirement for the installation. See
the instructions for installing the OBC and then continue this installation guide for information about
installing the RDT-A7.0 with the OBC.
RDT-A7.0 system hardware components
Before beginning the installation, ensure one type of the following components are included with the
unit.
Component RDT-A7.0
Description Wifi-ready mobile data terminal.
Component RDT.PWR (Option 1)
Description RDT power cable
Meant to connect the RDT-A7.0 to the
OBC

RDT-A7.0 Installation Guide
4
Component PWR.001 (Option 2)
Description RDT power cable
Meant for systems without the OBC
Component RAM-B-138U or RAM-B-101U
Description RAM mount and mounting dock
Required tools & equipment
Two 0.7 x 14 mm machine screws
Wire cutters
Phillips screw driver(s) or power screwdriver
Wire connectors
Fasteners for the RAM mount

RDT-A7.0 Installation Guide
5
Install the RDT-A7.0
Installing the RDT-A7.0 includes the following steps:
1. Mounting the RDT-A7.0
2. Connecting the RDT-A7.0 to the OBC
Mounting the RDT-A7.0
Before fastening the RAM mount to the vehicle dash and installing the RDT-A7.0, refer to
our Installation Warnings.
Because securing the mount to a vehicle's dashboard is subject to many variables and installers are
expected to have previous experience with this process, these instructions do not include specific
steps. However, see the tips below for additional information.
Helpful tips
Before securing the mount to the dashboard, find the optimal spot for the
RDT-A7.0 and mount to be positioned. The best location will be one that
does not allow the unit to block the driver's view of the road or interfere
with the safe and standard operation of the vehicle. Keep in mind the
mount is adjustable.
To get an accurate estimation of how the tablet dock and mount will be
positioned, it might be helpful to attach the RDT-A7.0to the mount
temporarily. If this is done, unscrew the mount and RDT-A7.0 before
installing the mount on the dashboard for ease of installation.
Screwing the mount into the dashboard will require drilling through the
dashboard or dash plate first to establish screw-in points for the mount.
Use proper equipment, safety, and sense to avoid damaging any wiring or
equipment in and around the dashboard. (Continued)

RDT-A7.0 Installation Guide
6
Because all vehicles differ, the screws and washers required for securing
the mount to the vehicle's dash are not included with the kit, and the
installer will need to choose screws and washers that best fit the vehicle
and mount.

RDT-A7.0 Installation Guide
7
Connect the RDT-A7.0 to the OBC
The RDT-A7.0 and OBC will need to be connected via cable and wifi.
To connect the RDT-A7.0 to the OBC
1. Ensure the 44 D-Sub High Density Connector (HD-44) that is part of the
OBCPIGOCTO is connected to the OBC device.
2. Attach the RDT.PWR cable on one end to the OBCPIGOCTO cable via
the black connector.
3. Connect the other end of the RDT.PWR cable to the back of the RDT-
A7.0.
Connecting RDT-A7.0 to the OBCPIGOCTOcable will allow the RDT-A7.0 to
draw power from the vehicle.

RDT-A7.0 Installation Guide
8
To connect the RDT-A7.0 with the OBC
The OBC device is assigned to the vehicle, but the Android tablet is not linked to
a vehicle until the driver logs into the tablet. Therefore, the Android tablet will not
attempt to connect to the OBC until the user attempts to log in.
On login, the RDT-A7.0 will attempt to connect to the OBC device via wifi. The
first attempt to connect to the OBC wifi hotspot can take up to 20 seconds. Once
connected, future connections will occur more quickly, usually in less than 10
seconds.
The tablet can pair with a different OBC if the driver switches between
trucks, but they must log out and then log in when they get to the new
truck. The tablet will attempt to pair with the OBC device only during
login.
