Commtiva N700 User manual

Table of Contents
i
Chapter 1: Getting Started.................................................................... 1
1.1 The device.................................................................................................... 1
Front............................................................................................................ 1
Back ............................................................................................................ 1
Top .............................................................................................................. 1
Down ........................................................................................................... 2
Side ............................................................................................................. 2
1.2 Accessories ................................................................................................. 2
1.3 Installing SIM Card and Memory Card....................................................... 3
SIM card & memory card ............................................................................ 3
1.4 Charging Battery ......................................................................................... 4
1.5 Using Headset ............................................................................................. 4
1.6 Turning the Device On or Off ..................................................................... 4
1.7 Unlocking Home Screen ............................................................................. 5
1.8 Turning Sound On or Off ............................................................................ 5
Chapter 2: The Basics........................................................................... 6
2.1 Home Screen ............................................................................................... 6
Status Bar Icons.......................................................................................... 6
Shortcut Menu............................................................................................. 8
Application Drawer .................................................................................... 10
Extended Home screen............................................................................. 10
Using Widgets ........................................................................................... 11
Setting wallpaper....................................................................................... 11
2.2 Adjusting Volume...................................................................................... 12
Chapter 3: Entering Information ........................................................ 13
3.1 On-Screen Keyboard................................................................................. 13
Using on-screen keyboard ........................................................................ 13
Setting Input Method ................................................................................. 14
Changing Input Method............................................................................. 14
Configuring device keyboard settings ....................................................... 14
3.2 SWYPE KEY - THE FIRST TIME USER..................................................... 15
The Info Pane............................................................................................ 15
3.3 SWYPE BASICS - THE 4 THINGS YOU NEED TO KNOW....................... 16
Swyping a Word ........................................................................................ 16
Swyping Double letters ............................................................................. 16
Capitalization............................................................................................. 17
Corrections................................................................................................ 18
Chapter 4: Using Internet ................................................................... 19
4.1 Connecting to Internet .............................................................................. 19
Wi-Fi.......................................................................................................... 19
Mobile Network ......................................................................................... 21
Starting a Data Connection ....................................................................... 22
Quick search on this device and web........................................................ 22
Chapter 5: Using Bluetooth................................................................ 23

Table of Contents
ii
5.1 Connecting to Bluetooth Devices............................................................ 23
Chapter 6: Multimedia Applications .................................................. 24
6.1 Videos......................................................................................................... 24
Recording video ........................................................................................ 24
Reviewing a video ..................................................................................... 24
Configuring camcorder settings ................................................................ 25
6.2 Viewing Videos .......................................................................................... 26
To playback videos ................................................................................... 26
6.3 Using Music Player ................................................................................... 26
Music Screen ............................................................................................ 26
Playing Music ............................................................................................ 27
Changing Playback options....................................................................... 28
Creating a Playlist ..................................................................................... 28
Chapter 7: Programs........................................................................... 29
7.1 Antix Games .............................................................................................. 30
Purchase Antix Games titles ..................................................................... 30
7.2 Camcorder ................................................................................................. 30
7.3 CopilotSetup .............................................................................................. 31
7.4 Documents To Go ..................................................................................... 32
Word To Go®Viewer................................................................................. 32
Sheet To Go®Viewer................................................................................ 32
Slideshow To Go®Viewer......................................................................... 33
PDF To Go®Lite ....................................................................................... 33
7.5 File Browser............................................................................................... 34
Managing files and folders ........................................................................ 34
7.6 Gallery ........................................................................................................ 34
7.7 GoSpoken Bookstore................................................................................ 35
7.8 Market......................................................................................................... 35
7.9 Music .......................................................................................................... 36
7.10 Note Pad................................................................................................... 36
7.11 Rss Reader............................................................................................... 38
7.12 Settings .................................................................................................... 39
7.13 SIM Toolkit ............................................................................................... 39
7.14 Talk ........................................................................................................... 39
7.15 Videos....................................................................................................... 40
7.16 Voice Dialer.............................................................................................. 40
7.17 Voice Note................................................................................................ 40
7.18 YouTube ................................................................................................... 41
Chapter 8: Managing Your Phone...................................................... 42
8.1 Device Settings.......................................................................................... 42
Wireless & networks.................................................................................. 42
Call settings............................................................................................... 42
Sound........................................................................................................ 42
Display ...................................................................................................... 43
Location & Security ................................................................................... 43

Table of Contents
iii
Applications............................................................................................... 44
Accounts & sync........................................................................................ 44
Privacy ...................................................................................................... 44
SD card & phone storage.......................................................................... 44
Search....................................................................................................... 44
Language & keyboard ............................................................................... 45
Voice input & output .................................................................................. 45
Date & time ............................................................................................... 45
About phone.............................................................................................. 45
8.2 Changing Basic Settings .......................................................................... 45
Date and Time........................................................................................... 45
Setting Alarms........................................................................................... 46
Display Settings ........................................................................................ 47
Ring Settings............................................................................................. 47
8.3 Using Wireless & networks ...................................................................... 48
Using this device as a storage device....................................................... 48
Using this device as a modem .................................................................. 49
Using this device as a Wi-Fi access point................................................. 49
8.4 Protecting Your Phone ............................................................................. 50
Enable or Disable SIM card PIN ............................................................... 50
Enabling Screen Lock Protection .............................................................. 50
8.5 Resetting the Device ................................................................................. 50
Chapter 9: Using PC Tools Application ............................................ 51
9.1 Using PC Tools Application ..................................................................... 51
Installing driver .......................................................................................... 51
Using this device to sync with a computer ................................................ 52
Safety Information................................................................................................... 53
Specifications.......................................................................................................... 57

Chapter 1: Getting Started
1
Chapter 1: Getting Started
1.1 The device
Front
Back
Top
Return
Home:
• Return to Home screen.
• Press and hold to bring
up recent activities.
Touch screen
Menu:
• Press to view menu
options.
Browser
3 Megapixels camcorder:
See “6.1 Videos” on page 24.
Volume: Press left volume
button to decrease volume
or right to increase volume.
Micro SD card
slot
SIM card slot

Chapter 1: Getting Started
2
Down
NOTE: Battery can be charged while connecting to a computer.
Side
1.2 Accessories
Your package comes with the following items. If any of them is missing, please
contact your retailer.
• Smartphone
• AC adapter
• Adapter wall plug
• mini USB cable
• Headset
• Pouch
• Quick Start Guide
• CopilotLive Guide
• SD card with pre-loaded content (inserted in SD slot)
Reset MIC
Headset jack:
Use headset for hands-free
conversation or listening to
music.
mini USB port:
• Connect USB cable to PC as a
modem/USB mass storage.
• Connect USB cable and AC
adapter to charge battery.
Power:
• Press and hold for 5
seconds to turn
device on or off.
• To save battery,
quick press to
temporarily turn
screen on or off.
Speakers

Chapter 1: Getting Started
3
1.3 Installing SIM Card and Memory
Card
SIM card & memory card
SIM card contains phone number, memory storage,
and network service details. You will need a microSD®
card to store photos, music, videos and other data.
To install SIM card/microSD card
1. Open card cover.
2. Insert SIM card/micro SD card as shown. Make sure
the gold contacts are facing up.
3. Close card cover.
To remove SIM card
1. Open card cover.
2. Push to eject SIM card from the slot.
3. Close card cover.
To remove memory card
1. For safety removal, tap Application Drawer > Settings > SD card, USB Mass
storage & phone storage > Unmount SD card.
2. Open card cover.
3. Push to eject micro SD card from the slot.
NOTE: Do not remove memory card while the device is turned on. Suddenly removal
of memory card may cause data loss or unpredictable system hang up.

Chapter 1: Getting Started
4
1.4 Charging Battery
The device inside of package is only partially charged. To fully charge battery, charge
it for 2 hours.
To charge battery
1. Connect one end of the AC adaptor to mini
USB connector of the device as shown.
2. Plug the other end of the AC adaptor to the
wall outlet to start charging.
3.
When battery is charging, red LED is activated;
the icon is also displayed on the status bar.
When battery is fully charged, red LED
disappears and green LED is activated; if the
device is turned on, the icon is also displayed
on the status bar.
NOTE:
• Battery can be charged when device connects to computer through USB
cable.
• Battery life may vary depending on user usage.
1.5 Using Headset
For hands-free conversation or listening to music, plug one headset to headset jack.
NOTE:
• When using headset, your ability to hear outside sounds may be limited. Do
not use headset if it will endanger you.
• Do not set volume to maximum with headset as it may damage your
hearing.
1.6 Turning the Device On or Off
After installing SIM card and charging battery, device is ready to turn on.
To turn on the device
Press and hold power button until the device vibrates.
To turn off the device
1. Press and hold power button for 5 seconds.
2. A pop-up window appears, tap Power off.

Chapter 1: Getting Started
5
3. Select OK to confirm.
To set the device to Sleep mode
To set the device to sleep mode, press power button briefly.
This turns display off.
To turn display on, press again power button briefly.
1.7 Unlocking Home Screen
To unlock home screen
1. Press power button or front buttons briefly to turn on display from Sleep mode.
2. Tap and swipe upwards to unlock home screen.
1.8 Turning Sound On or Off
To enable/disable sound
1. Press power button or front buttons briefly to turn on display from Sleep mode.
2. Tap and swipe downwards to turn sound off.
3. To turn on sound, repeat the steps above.

Chapter 2: The Basics
6
Chapter 2: The Basics
2.1 Home Screen
From Home screen, you can quickly access common features and view notifications
of missed calls, received messages, battery and connection status.
Status Bar Icons
Status bar icons indicate different types of information. Tap status bar and scroll down
to view ongoing phone activities or notifications easily. To close the window, press
.
Shortcut Menu
Tap an icon to access
the function.
Application Drawer
Tap to view the
applications and
device settings.
Status bar
• Displays status and notification icons and
clock.
• Message, appointment, task, and connection
notifications are also displayed here.
Internet
Phone
Email
Tap to view emails.
Aldiko
Tap to view
documents or
downloaded
ebooks.
Music
Tap to play audio
files.
Browser
Tap to browse web
pages.

Chapter 2: The Basics
7
Icons on status bar indicates the following information:
Signal strength icon
Text message icon
Bluetooth icon
USB connection
icon Wi-fi icon
Notification icon
Battery icon
Network icon
Volume icon
The following icons may appear on
volume icon area.
To adjust volume, see “2.2 Adjusting
Volume” on page 12.
Battery icon
The following icons may appear on
battery icon area:
To charge battery, see “1.4 Charging
Battery” on page 4.
Icon Description
Sound is off.
Device is vibrated.
Speakerphone is on.
Phone is muted.
Icon Description
Battery is full.
Battery is low.
Battery is charging.
Phone Network icon
The following icons may appear on phone network icon area.
Icon Description
No network signal
Maximum signal strength. Fewer
bars indicate lower signal
strength.
GPRS network is in use.
Call is in progress.
Call is on hold.
No SIM card is inserted.
Icon Description

Chapter 2: The Basics
8
Shortcut Menu
To easily access menu, tap item on Home screen. By default, the following
applications are displayed:
Icon Menu Item Description
Browser Tap to browse web pages.
Music Tap to play audio files.
Aldiko Tap to view documents or downloaded ebooks.
Email Tap to view emails.
Connection icon
The following icons may appear on
connection icon area.
Notification icon
The following icons may appear on
notification icon area.
Icon Description
WiFi is connected.
Bluetooth connection is on.
GPRS data connection is
activated.
HSDPA data connection is
activated.
Device is connected to PC via
USB connector.
File has been downloaded.
Icon Description
New text message notification
New WAP Push notification
New email notification
New Google mail notification
Alarm
Task notification
Missed call notification

Chapter 2: The Basics
9
Customizing Shortcut menu
To add a shortcut:
1. Tap Menu > Add > Shortcuts.
2. Tap Applications to display a list of applications.
3. Tap to add the items appearing on Home screen.
To remove a shortcut:
1. Tap and hold one desired shortcut icon. The icon enlarges.
2. appears on right of Home screen.
3. Drag the icon to to delete. The shortcut icon is then removed.

Chapter 2: The Basics
10
Application Drawer
Application Drawer contains all applications and settings. On Home screen, tap to
display menu.
Extended Home screen
Swipe your finger to left or right across Home screen.
The two left and two right extensions to Home screen provide more space for icons,
widgets, shortcuts, and other items.
• Swipe your finger to
up or down to
access more
applications in this
device.
• Tap an icon to open
the application.

Chapter 2: The Basics
11
Using Widgets
You may add and customize Widgets on Home screen.
1. From Home Screen, tap Menu > Add > Widgets.
A gallery list of all available widgets is displayed.
2. Tap to select one widget appearing on Home screen.
To remove widgets:
1. From Home screen, tap and hold a desired widget. The widget enlarges.
2. appears at right of Home screen.
3. Drag the widget to to delete. The widget is then removed.
Setting wallpaper
You can customize wallpaper of Home screen with default wallpaper or with pictures
taken by this device.
Set wallpaper from Pictures
1. From Home Screen, tap Menu > Wallpaper.
2. Select wallpaper from is displayed on screen.
3. Tap Gallery.
4. Tap to select pictures taken from phone camera or saved on your SD card.
5. You will see thumbnail images of all pictures. Tap to select one picture you to use
as wallpaper.

Chapter 2: The Basics
12
6. Drag finger to select the crop area and tap inside the box to crop the image.
7. Tap Save and the cropped image set as wallpaper on Home screen.
Set wallpaper from Wallpaper gallery
1. From Home Screen, tap Menu > Wallpaper.
2. Select wallpaper from is displayed on screen.
3. Tap Wallpapers.
4. All system wallpapers are displayed. Swipe your finger left or right to view all
available wallpapers.
5. Tap to preview one wallpaper.
6. Tap Set wallpaper to apply.
2.2 Adjusting Volume
This device features three types of volume which can be adjusted separately:
•Media volume: Volume for music and videos.
•Ringtone volume: Volume for incoming calls and notifications.
•Alarm volume: Volume for an alarm.
To adjust ringtone volume
1. Tap Application Drawer > Settings > Sound.
2. In Sound settings submenu, tap Volume and
volume slider appears.
3. To adjust ringtone volume, do either of the
following:
a. Drag volume slider to adjust volume.
b. Press volume button. Slide volume button up or
down to adjust volume.
NOTE: When the device is set to silent mode, all sounds are turned off except
for media and alarm.
4. Tap OK to exit menu.
To adjust alarm volume
1. Tap Application Drawer > Settings > Sound.
2. In Sound settings submenu, tap volume to show volume slider.
3. Drag volume slider to adjust volume.
To adjust media volume
To adjust media volume, repeat same steps as alarm
volume.
Volume slider
Volume slider

Chapter 3: Entering Information
13
Chapter 3: Entering
Information
3.1 On-Screen Keyboard
On-screen keyboard appears in portrait mode when an application requires text input,
such as messaging, and writing emails. Keyboard input method is activated by
default.
Using on-screen keyboard
Tap and hold input field to display on-screen keyboard.
• Use on-screen keyboard as a computer keyboard.
• Tap keys to enter characters.
• To toggle between upper and lower case letter display, tap .
• To display numeric and symbols keyboard, tap . Tap to toggle back.

Chapter 3: Entering Information
14
Setting Input Method
This device supports several text input methods, select one preferred method.
1. Tap Application Drawer > Settings > Language & keyboard.
2. In Text settings submenu, a list of input methods is displayed. Select and check
one option.
Changing Input Method
1. Press and hold on any text-field in program. For example, in Messaging, tap and
hold field “To:”. Input Method Screen pops up.
2. Select one of available Input Methods to use.
Configuring device keyboard settings
You can make use of keyboard aids to help you when input text with device keyboard.
1. Tap Application Drawer > Settings > Language & keyboard.
2. Tap Swype.

Chapter 3: Entering Information
15
3.2 SWYPE KEY - THE FIRST TIME
USER
If a user is unfamiliar with Swype their typical behavior will be to start tapping in words
letter-by-letter. One of the context sensitive tips we have incorporated is that after the
first 3 or 4 words are tapped in (that are in Swype’s database, so that they could
indeed have been Swyped), we indicate to the user via the flashing “Info Pane” icon
that there is a tip waiting for them.
If the user taps the Swype key with the flashing Info Pane – they are told how to
Swype.
The Info Pane
The Info Pane, accessed by a tap-hold on the Swype key, provides access to several
key components. Primarily, it is a quick entry to any tips that have previously been
triggered by the user’s actions indicating that they don’t yet understand something
about Swype. However, in addition to Quick Tips it also allows the user to access the
following functions:
•Help
•Tutorial
• Options
The Initial Tips Window
