Conker NS12 User manual

12” RUGGED WINDOWS TABLET
CONKER NS12
[phone] | www.weareconker.com
Conker NS12
From Automotive to Engineering, Manufacturing to Logistics, the NS12 is the ideal
Business Rugged mobile device. It’s IP rating means it will withstand your working
environment, whilst it large, tough screen allows it to be used as a mobile computer.

[phone] | www.weareconker.com
OS Windows 10 Pro or LTSB Audio Waterproof, built-in microphone
and speaker
CPU Intel Cherrytrail 28350
For NS12.M3: Intel Core M3-7Y30
Display 12.2” IPS
Resolution 1920 x 1200
IP Rating IP65 Touch Capacitive Multi-touch with
toughened glass
Drop Test 1m Dimensions/
Weight
320 x 216 x 23 mm/ 1.5kg
Battery 12,600 mAh
For NS12.M3: 6,500 mAh + 1,000 mAh
hot swappable battery
Camera 5.0 MP rear camera with ash
2.0 MP front camera
Wireless
Connectivity
Wi-Fi: 802.11 a/b/g/n Dual band, supports
WI-FI hotspot
Bluetooth: 4.0 LE/ 4.2 LE (NS12.M3)
3G
GPS: uBlox
NFC (optional): 13.56MHz
Tethering and casting
Ports USB: 3 USB ports, 1 Micro USB
port
Micro SD: up to 64GB
SIM: Micro SIM
Dc-in 5V/3A
For NS12.M3: 12V/4A
HDMI: Mini
Other: RJ45 ethernet port, 2
COM ports
Docking: 4 pin pogo
Memory 4GB memory
64GB storage
For NS12.M3:
4GB memory
128GB storage
Other Features Optional 2D barcode scanner
Device Specications

HOW TO USE YOUR NS12 RUGGED DEVICE
1. Front camera
2. Light sensor/ notification light
3. Power
4. Volume control
5. Programable ****
6. ****
7. DC in
8. RJ45
9. USB 2.0
10. USB 2.0 or USB 3.0 (M3 only)
11. Mini HDMI
12. Micro USB or USB-C (M3 version)
13. Audio jack
14. Docking Port
15. USB 2.0
16. 9 pin Serial Port
17. 9 pin Serial Port
18. Lanyard Port
19. Barcode scanning window
20. Back camera
21. Barcode trigger
22. Battery Lock

INSTALLING SIM AND MEMORY CARD
Power off the phone before changing
the SIM or Memory Card
Always use the right size of SIM card
The battery is secured in place by a
sliding lock as shown below. Slide it
to the left and release the battery as
shown in the following diagrams
You have now reached the SIM and SD
card slots. Insert the SIM and memory
cards in the respective holders
Please take care to observe the cor-
rect orientation of the SIM card as per
the picture below.
Now re-install the battery and make
sure the sliding lock is secured in place

To contact Conker Support:
01279 295830
[e-mail]
Conker
Calf Pens
Hatfield Park Farm
Takeley
CM22 6NG
GET IN TOUCH

Thank you for purchasing a
CE Marking and European Economic Area
Tablet Technologies hereby declares that this equipment is in compliance with Direcve 2011/65/EU and 1999/5/EC or
2014/53/EU. The following standards have been applied and tested. Conformity is limited to the essenal requirements of the
R&TTE.
For your safety
To reduce the potenal risk of injury and or damage to equipment or property, always observe the following safety precauns.
WARNING
Do not aempt to repair or modify the product as this could cause harm and will void any warranty.
Do not expose your skin to the product or AC adaptor when using the product for prolonged periods.
Do not puncture the product or baery.
Use only the specied baery (supplied).
Use only the specied AC adaptor (supplied).
Ensure all port and interface covers are closed before exposing the product directly to water or elevated levels of moisture or dust.
Packaging and accessories are choking hazards and should be kept out of reach of children.
Do not operate the product while driving.
Do not expose the AC Adaptor to water and donot use Adaptor when faulty.
Prolonged use of headphones can lead to a loss of hearing.
CAUTION
Do not operate the product if it shows any visible signs of damage.
To prevent injury or harm, avoid looking directly at the ash or where applicable, the laser barcode scanner.
Do not expose the product to extreme temperatures for a prolonged period. Do not expose the product directly to your skin in extreme
temperature environments.
Baery
DANGER
The baery is for use solely with the specied product. Do not use it with any other products.
Do not use the baery if it becomes noceably damaged or deformed.
Do not crush, bend, deform, puncture, shred, throw, or apply high pressure to the baery.
Only charge the baery with the supplied charger or cradle.
Do not subject the baery to an open ame or expose it to excessive heat.
Contents can combust under pressure.
If the electrolyte from the baery comes into contact with the eyes, skin, or clothing, rinse thoroughly with cold water and seek medical
advice.

Baery Informaon
CAUTION. Use only approved baeries. Risk of explosion if baery is charged with an incompable charger, exposed to heat
>60C or replaced by an incorrect type.
European Baery Direcve 2006/66/EC
Dispose of baeries separately and responsibly. All waste baeries are classid as hazardous waste and should be disposed of
at a baery recycling centre.
Our rechargeable baery packs are designed and constructed to the highest standards within the industry. However, there are limitans
to how long a baery can operate or be stored before needing replacement. Many factors aect the actual life cycle of a baery pack, such
as heat, cold, harsh environmental condins and severe drops. Baeries are considered chemical products. As such, baery performance
will deteriorate over me if stored for a long period of me without being used. When baeries are stored over six (6) months, some
irreversible deterioran in overall baery quality may occur. Store baeries at half of full charge in a dry, cool place, removed from the
equipment to prevent loss of capacity, rusng of metallic parts and electrolyte leakage. When storing baeries for one year or longer, the
charge level should be veried at least once a year and charged to half of full charge.
Replace the baery when a signicant loss of run me is detected. Standard warranty period for all baeries is one year from order
fullment, regardless if included as part of a mobile computer with a longer warranty duran or ongoing maintenance contract. The cycle
life of baeries will vary according to the charge and discharge condins, the temperature and other usage condins. When used in
accordance with the IEC charge and discharge specicans the typical cycle life of a baery is between 300 and 400 cycles at room
temperature. Individual results may vary.
Lithium baeries do not suer from “baery memory” therefore you do not need to fully charge to 100% or fully discharge to 0%. Complete
discharge of baeries should always be avoided. Shallow discharge is preferable, i.e. recharge at 20% if possible.
Baery Safety Guidelines
The area in which the units are charged should be clear of debris and combusble materials or chemicals.
Improper baery use may result in a , explosion, or other hazard.
To charge the mobile device baery, the baery and charger temperatures must be between 0°C and +40°C (+32°F to +104°F).
Do not use incompable baeries and chargers. Use of an incompable baery or charger may present a risk of , explosion,
leakage, or other hazard. If you have any quesns about the compability of a baery or a charger, contact Tablet
Technologies support.
For devices that uize a USB port as a charging source, the device shall only be connected to products that bear the USB-IF
logo or have completed the USB-IF compliance programme.
Do not disassemble or open, crush, bend or deform, puncture, or shred.
Severe impact fromdropping any baery-operated device on a hard surface could cause the baery to overheat.
Do not short circuit a baery or allow metallic or conducve objects to contact the baery terminals.
Do not modify or remanufacture, aempt to insert foreign objects into the baery, immerse or expose to water or other
liquids, or expose to , explosion, or other hazard.
Do not leave or store the equipment in or near areas that might get very hot, such as in a parked vehicle or near a radiator or
other heat source.
Do not place baery into a microwave oven or dryer.
Baery usage by children should be supervised.
Please follow local regulans to promptly dispose of used re-chargeable baeries.
Do not dispose of baeries in .
Seek medical advice immediately if a baery has been swallowed.
In the event of a baery leak, donot allow the liquid to come in contact with the skin or eyes. If contact has been made, wash
the aected area with large amounts of water and seek medical advice immediately.
If you suspect damage to your equipment or baery, contact Tablet Technologies support to arrange for inspecn.
Class 2 Laser Product – Honeywell N4300 1D Laser Barcode Scanner
Safety Standards:
EN 60950-1:2005/Am1:2009,
IEC 60950-1:2006/A11:2009/A1:2010/A12:2011
Laser Safety Statement
This device has been tested in accordance with and complies with IEC 60825-1 ed2.0.
LASERLIGHT, DO NOT STARE INTO BEAM, CLASS 2 LASER PRODUCT,1.0 mW MAX OUTPUT: 650nm.
Engine Laser Beam:
Wavelength 650 nm
Max power output 1mW
The laser diode is considered an embedded laser. Intrabeam viewing of the laser shall beprevented.
