Corsynth T-MIXER C114 User manual

USER MANUAL
C114 T-Mixer

c114 t-mIXER
1
HTTP://WWW.CORSYNTH.COM
The C114 T-Mixer is a four channel transistor based mixer.
The design is based on the classic Moog CP3 mixer but
adapted to modern modular signal levels. The CP3 mixer was
a key factor in the classic Moog modular sound.
The C114 can be used as a clean mixer but when it shines is
when is pushed out of its “comfort zone”. The C114 will start
to add harmonics to the input signal and the distortion can
go from a subtle effect to a hard clipping distortion.
The mixer has two outputs , one normal and the other one
inverted and each output has different distortion
characteristics.
The C114 can be used with audio and CV signals.
C114 T-Mixer main characteristics :
- transistor based mixer
- 4 channels
- 2 mixer outputs (one inverted)
C114 T-MIXER

c114 T-MIXER
2
HTTP://WWW.CORSYNTH.COM
C114 T-MIXER
Front Panel
Channel 1 level
Mixer input 1
Mixer input 3
Mixer input 2
Mixer input 4
Inverted mixer output
Mixer output
Channel 2 level
Channel 3 level
Channel 4 level

c114 T-MIXER
3
HTTP://WWW.CORSYNTH.COM
CONTROL DESCRIPTION
Channel 1 Level
This knob sets the level for the mixer channel 1 . A signal of
+/-5V will be at unity gain ( input equal to the output) where the
dial line gets thicker. From that point the mixer will add distor-
tion to the incoming signal.
Channel 2 Level
This knob sets the level for the mixer channel 2 . A signal of
+/-5V will be at unity gain ( input equal to the output) where the
dial line gets thicker. From that point the mixer will add distor-
tion to the incoming signal.
Channel 3 Level
This knob sets the level for the mixer channel 3 . A signal of
+/-5V will be at unity gain ( input equal to the output) where the
dial line gets thicker. From that point the mixer will add distor-
tion to the incoming signal.
Channel 4 Level
This knob sets the level for the mixer channel 4 . A signal of
+/-5V will be at unity gain ( input equal to the output) where the
dial line gets thicker. From that point the mixer will add distor-
tion to the incoming signal.

c114 t-mixer
4
HTTP://WWW.CORSYNTH.COM
OUT
INPUT 1
Mixer input 1. It accepts audio and CV signals.
INPUT 2
Mixer input 2. It accepts audio and CV signals.
INPUT 2
INPUT 3
Mixer input 3. It accepts audio and CV signals.
INPUT 3
INPUT 4
Mixer input 4. It accepts audio and CV signals.
INPUT 4
OUT
Mixer output. The mixer will start to distort if the sum of the input
signals exceeds 10Vpp. (+/-5V)
OUT
INV OUT
Inverted mixer output. This output inverts de polarity of the inco-
ming singal.
INV OUT

c114 t-mixer
5
HTTP://WWW.CORSYNTH.COM
TRIMMERS AND POWER CONNECTORS
Module Format : 5U, MU format ( Synthesizers.com, Moog )
Module Width : 1 MU ( Moog unit )
Module Depth : 52 mm ( 2,05 inches )
Power : +15V35@mA , -15V34@mA
Power connectors : MU, MOTM ( 4 pin )
TECHNICAL DATA
+15V+5V-15VN/C GND
MU
GND +15V-15V GND
MOTM
IMPORTANT !!!!
This module has two power connectors
(MU and MOTM).
Only one is needed to power the
module. (MU or MOTM).
Never connect both at the
same time.
MU
power connector
MOTM
power connector
DC offset

c114 t-mixer
6
HTTP://WWW.CORSYNTH.COM
MODULAR LEVEL
MIN MAX
MODULAR SYNTHS
