CROMMELINS™ COMPACTORS

Thank you for your selection of a CROMMELINS™ Compactor.

This Operation Manual explains its use, installation, checking and maintenance.

We highly recommend that you retain this manual for ready reference regarding

proper handling of the CROMMELINS™ Compactor.

Spare Parts & Service

Phone: 1300 554 524

Freecall Fax: 1800 636 281

spareparts@crommelins.com.au

www.crommelins.com.au

WA Metro 9350 5588

WA Regional 1800 655 588

East Coast 1300 650 659

[email protected]

OPERATION & INSTRUCTION MANUAL

2

Thank you very much for purchasing a CROMMELINS™ COMPACTOR.

This manual covers operation and maintenance of the CROMMELINS™ COMPACTOR.

This CROMMELINS™ COMPACTOR can be used in the mining, construction, hire industries

and general use.

Please take a moment to familiarise yourself with the proper operation and maintenance

procedures in order to maximise the safe and efficient use of this product.

Keep this owner’s manual at hand, so that you can refer to it at anytime.

Due to constant efforts to improve our products, certain procedures and specifications

are subject to change without notice.

When ordering spare parts please have handy your products model number and serial

number. Record these numbers in the boxes below for future reference.

Please fill in the following blanks after checking the production number and serial

number on your product. (The location of these numbers, vary depending on product).

CONTENTS

Introduction & Contents ...................................................................................... 2

Safety ................................................................................................................. 3

Pre Start-up Checking .......................................................................................... 4

Hints of Operation ............................................................................................. 5

Shutdown & Warranty ....................................................................................... 6

Maintenance, Belt Setting & Storage ................................................................ 7

Specifications Charts ......................................................................................... 8-9

Trouble Shooting ................................................................................................ 10

CC60R Exploded Drawing & Parts List ................................................................. 11

CC70R Exploded Drawing & Parts List ................................................................. 12

CC90R Exploded Drawing & Parts List ................................................................. 13

CC92R Exploded Drawing & Parts List ................................................................. 14

Notes .................................................................................................................... 15

SERIAL NO.

MODEL NO.

3

SAFETY

This manual contains important information on how to use the following compactor

models CC60R, CC70R, CC70RD, CC90R and CC92R properly and safely. Please read through

this manual before you attempt to operate this product.

Ensure safe operation, this compactor is designed to give safe and dependable service if

operated according to the instructions.

Always make a pre-operation inspection before starting the engine. (For more

information read engine operational manual)

Stay AWAY from base plate during operation.

Do not place flammable objects near the unit.

Children and pets must keep away from the area of operation at all times.

Never allow anyone to operate the unit without proper instructions.

Must know how to stop the engine quickly and understand the operation of all controls.

Be careful with the operating place and ventilation, avoid operating the machine in a

closed room, tunnel, or other badly ventilated places, since its exhaust contains deadly

poisonous carbon monoxide. If the machine is unavoidably operated in such a place,

discharge the exhaust outside the room by a suitable means.

Mufflers and other hot parts are dangerous. Do not touch them with hands or any other

body parts.

Observe the following cautions when transporting. Close fuel tank cap securely and

close fuel tap tightly during transportation. Drain petrol or diesel from fuel tank before

transporting over a long distance or on rough roads.

Stop engine without fail before replenishing fuel tank. Never replenish fuel while the

engine is running or remains hot otherwise spilled or evaporated fuel is liable to catch

fire from the engine spark or muffler heat. Wipe off spilled fuel before starting engine.

To prevent injury wear the following protective clothing: Gloves, hard hat, work boots, ear

plugs, safety goggles and any other protective items required by job conditions.

4

PRE START-UP CHECKING

•Consult engine manual for detailed starting information.

•Check all bolts and screws for tightness. Loose bolts and screws may cause damage to

the unit.

•Make sure that all dirt, mud, etc., are thoroughly removed from areas such as cooling air

inlet of engine, carburettor, and air cleaner.

•Check V-belt tightness. The normal slack should be approximately 10-15mm (1/2”) when

the belts are forcibly depressed in the middle position between two pulleys. To set belt

tightness; refer to Belt Setting at page 3.

•Check fuel level and refill as required.

•Check engine oil level. If engine oil level is low, refill it with the correct engine oil as

stated in the engine manual.

CAUTION! –Make sure nobody is in the vicinity of the compactor when starting the engine;

it might move suddenly with force.

STARTING (PETROL UNITS)

STEP 1 –Open engine fuel cock.

STEP 2 –Set throttle lever to starting position.

STEP 3 –For cold engine starting, close carburettor choke lever.

STEP 4 –Set engine switch to “ON”.

STEP 5 –Pull recoil starter.

IMPORTANT: Do not pull recoil starter rope to the end as it may cause damage. When the

rope is pulled out, release the rope slowly. Do not let the rope snap back.

STEP 6 –After engine starts, open the choke halfway and warm up the engine for 2-3

minutes with low speed position. The warm up procedure should particularly be

followed during cold weather.

STARTING (DIESEL UNITS)

STEP 1 –Set speed control to low speed.

STEP 2 –Pull recoil starter rope until resistance is felt.

STEP 3 –Bracing foot against engine, pull recoil starter rope with both hands.

IMPORTANT: Do not pull recoil starter rope to the end as it may cause damage. When the

rope is pulled out, release the rope slowly. Do not let the rope snap back.

5

HINTS OF OPERATION

During uphill compaction, it may be necessary to swing the handle over and pull the

machine slightly.

When compacting on a sloping terrain, the machine may tend to slide sideways. The

operator must steer toward the rise causing the machine to travel at an angle.

When operating the machine in wet or damp soil, it may occasionally be required to

clean the bottom of the base plate. Mud accumulation on the base plate will slow the

machine down and prevent efficient soil compaction.

When operating this compactor on asphalt surface, it is recommended that light oil or

kerosene be applied to the bottom of the base plate to prevent asphalt sticking and/or

accumulation.

Operating the machine on a fully compacted, hard, or non-yielding surface will cause it

to bounce and damage exciter bearings, and will greatly reduce the life of the

machine. Reduce engine speed to eliminate bounce.

When transporting the unit ensure the fuel tap is turned “OFF” to prevent flooding.

6

SHUTDOWN –PETROL UNIT

STEP 1 –Move throttle lever to low speed position quickly and run engine for 2-3 minutes

at low speed.

STEP 2 –Turn of the stop switch, the engine stops completely.

STEP 3 –Close engine fuel cock.

STEP 4 –Cover the machine after the muffler has cooled off and keep the compactor in a

dry place.

EMERGENCY SHUTDOWN: Move throttle lever to OFF and press engine stop button.

SHUTDOWN –DIESEL UNIT

STEP 1 –Move throttle lever to low speed position quickly and run engine for 2-3 minutes

at low speed.

STEP 2 –Move the throttle lever to the stop position.

STEP 3 –Cover the machine after the muffler has cooled off and keep the compactor in a

dry place.

WARRANTY

Consult the CROMMELINS Machinery warranty leaflet (supplied with your new product)

for full details and a list of service dealers for this product, also available online at

www.crommelins.com.au.

7

MAINTENANCE

CAUTION!

FLAMMABLE LIQUID. When performing maintenance, stop engine and do not smoke in

adjacent area.

HIGH TEMPERATURE. Allow machine and engine to cool down before performing

maintenance. Contact with hot components can cause serious injury.

MOVING PARTS. Make sure engine is shutdown before maintenance. Contact with moving

parts can cause serious injury.

Daily Service

•Check air cleaner element and clean as necessary.

•Check engine oil levels.

•Check for any loose fasteners.

•Check belt tension.

Weekly Service (every 50 hours of operation)

•Refer to engine service manual.

BELT SETTING

STEP 1 –Loosen engine base bolt (underneath engine) to allow engine-base movement.

STEP 2 –Insert V-belt into clutch pulley and reducer pulley one at a time.

STEP 3 –Adjust the engine position by moving engine-base to ensure v-belts are tight

enough.

IMPORTANT: Normal slack should be approximately 10-15mm (1/2”) when the belts are

forcibly depressed in the middle position between rotor pulley and clutch pulley.

Tighten all engine bolts and cover V-belt and pulley with belt cover, tighten cover bolts.

STORAGE

•Ensure fuel tank tap is turned off.

•Make sure that the engine is completely cooled off before storage.

•Clean up oil and dust accumulation on rubber parts.

•Clean the base plate and wipe on a light coat of oil to prevent rust formation.

•Cover the machine and store it in a dry place.

For Long-term Storage

Remove fuel from the fuel tank. Also remove fuel remaining in the fuel line and

chamber of the carburettor. To drain fuel from the chamber of the carburettor, remove

the drain plug provided at the chamber and remove fuel.

8

PLATE COMPACTOR SPECIFICATION CHART

MODEL

CC60R

CC70R

CC70RD

Weight (kg)

58kg

82kg

98kg

Engine Make

Subaru

Engine

3.5hp EY15

6.0hp EX17

4.8hp DY23

Engine Features

Side Valve, Recoil

Start

OHC

OHV

Fuel Type

Petrol

Diesel

Fuel Tank

2.8L

3.6L

3.2L

Noise Level db@7m

67db

66db

Manufacturers Warranty

2 yrs

Engine Warranty

3 yrs

Centrifugal Force (kn)

12kn

18kn

Plate/Shoe Size (LxW mm)

520L x 360Wmm

610L x 460Wmm

9

PLATE COMPACTOR SPECIFICATION CHART

MODEL

CC90R

CC92R

Weight (kg)

84kg

102kg

Engine Make

Subaru

Engine

5.0hp EY20

6.0hp EX17

Engine Features

Side Valve, Recoil

Start

OHC

Fuel Type

Petrol

Fuel Tank

3.8L

3.6L

Noise Level db@7m

69db

66db

Manufacturers Warranty

2 yrs

Engine Warranty

3 yrs

Centrifugal Force (kn)

16.5kn

20kn

Plate/Shoe Size (LxW mm)

540L x 500Wmm

590L x 500Wmm

10

TROUBLE SHOOTING GUIDE

If the compactor malfunctions immediately shut the machine down. Following are some

simple trouble shooting tips:

PROBLEM

CAUSE

SOLUTION

Engine won’t start, or

stops suddenly

1. No fuel in engine

2. Engine switch being

set to “OFF”

3. Spark plug carbonised

4. Fuel strainer clogged

5. Carburettor blocked

1. Refill Fuel

2. Turn the engine switch to

“ON”

3. Clean spark plug or replace it

with a new one

4. Clean fuel strainer

5. Dismantle and clean

carburettor

Engine runs but the

machine does not

produce any vibration

1. Air cleaner element

clogged

2. Lake of engine power

3. Centrifugal clutch is

slipping

4. Improper v-belt

tension, or excessive

wear of v-belt

1. Dismantle the cleaner

element and clean the

element with proper solvent

(see engine manual)

2. Refer to engine manual

3. Dismantle the clutch

assembly and clean the shoe

and drum with proper solvent

4. Adjust the tension or replace

the belt with new one

IF THE FAULT PERSISTS, CONTACT YOUR LOCAL DEALER.

11

CC60R EXPLODED DRAWING & SPARE PARTS LIST

12

CC70R EXPLODED DRAWING & SPARE PARTS LIST

13

CC90R EXPLODED DRAWING & SPARE PARTS LIST

14

CC92R EXPLODED DRAWING & SPARE PARTS LIST

15

NOTES

.................................................................................................................................................
