Crosley C32HDHB User manual

Proper use guarantees
product life.
Before using the product, be advised
that you read this owner’s manual well
and try to operate it.
INSTRUCTION MANUAL
LCD TELEVISION
C32HDHB
C37HDHB
C42HDHB
C42FHDHB

WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPARATUS TO RAIN OR MOISTURE AND OBJECTS FILLED WITH LIQUIDS, SUCH
AS VASES, SHOULD NOT BE PLACED ON THIS APPARATUS.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulat-
ed “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and servic-
ing instructions in the literature accompanying the appliance.
Caution

Caution
2
NOTE :
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause interference to radio
communications. However, there is no guarantee that interference will not occur in a partic-
ular installation.
If this equipment does cause interference to radio or television reception which can be
determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult authorized service centers for help.
- Only shielded interface cable should be used.
Finally, any changes or modifications to the equipment by the user not
expressly approved by the grantee or manufacturer could void the users
authority to operate such equipment,
FCC RF INTERFERENCE STATEMENT

IMPORTANT SAFETY
INSTRUCTIONS
3
Please read the following safeguards for your TV and retain for future reference.
Always follow all warnings and instructions marked on the television.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. DISCONNECTING DEVICE FROM MAINS - Main plug is the disconnecting device. The plug
must remain readily operable.

IMPORTANT SAFETY
INSTRUCTIONS
4
16. Wall or Ceiling Mounting
When mounting the product on a wall or ceiling, be sure to install the product using the
designated mounting tool according to the method recommended by the manufacturer.
17. Attachments and Equipment
Never add any attachment and/or equipment without approval of the manufacturer as such additions
may result in the risk of fire, electric shock or other personal injury.
18. Power Source
This TV should be operated only from the type of power source indicated on the marking label. If you
are not sure of the type of power supplied to your home, consult your appliance dealer or local power
company.
19. Power Lines
An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from touching such power lines or
circuits as contact with them might be fatal.
20. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of fire or
electric shock.
21. Object and Liquid Entry
Never push objects of any kind into this TV through openings as they may touch dangerous voltage
points or short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or
into the TV.
22. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the TV, be
sure the antenna or cable system is grounded so as to provide
some protection against voltage surges and built-up static charges.
Section 810 of the National Electric Code, ANSI /NFPA No. 70-1984,
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead in wire to an antenna
discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
23. Safety Check
Upon completion of any service or repair to the TV, ask the service technician to perform safety checks
to determine that the TV is in safe operating condition.

Warning
5
This section must be read carefully and followed by the user prior to the operation of the product.
The manual states important instructions for the user's own safety, and the proper operation of the product.
In case of an accident, please unplug the unit from the outlet immediately.
Hold the plug when unplugging the unit
from the outlet. The cord may cause fire or
electric shock if damaged.
Do not cause the product to lean or put it in an
unstable place since it may cause a serious
injury to a person, as well as damage to the
product if it falls.
Do not put any object that contains water -
such as flowerpot - near to the unit.
The water may penetrate into the unit, and be
a cause of fire or hazardous electric shock.
To reduce the risk of electric shock, do not
remove cover or back. No user -serviceable
parts inside. Refer to qualified service
personnel for repair.
Do not put on or use the product near water and
moisture-such as in a bathroom, washbowl, etc.
It may be a cause of fire and electric shock
hazards.
To prevent fire and damages to the product,
unplug the unit from the outlet during lightning
storm, or when it is left unattended and unused
for a long period of time.
Do not let children hang on or climb on the
product since it may be a cause of serious
injury.
Slots and openings in the case are provided for
ventilation to ensure reliable operation of the
product. Never put in any item-such as a coin,
paper, match- through these openings since it
may touch dangerous voltage points that could
result in fire or shock hazard.

Warning
6
Do not put volatile substance-such as
benzene, naphtha- near the product since it
may cause a change in the product's color.
Do not view the TV too closely since it may
cause damage in your eyesight.
Refer servicing to qualified service
personnel for cleaning at least once a year
since dust inside the TV set may be a result
or fire and malfunctioning of the product.
The product should be situated away from
any heat source-such as radiators, heat
registers, stoves, or other products that
produce heat.
Do not put on any heavy item on the power
cord since it may result in fire or hazardous
electric shock if the cord is damaged.
Do not cover the top of the television set.
Ventilation will be prevented, and it may be
a cause of fire if the product is internally
overheated.
Unplug the power from the outlet and all the related
connections from the unit to prevent electric shock. At least
two people must work together to move the TV set when
transporting to prevent the TV from falling, and
consequently, any serious injury or damage.
Do not touch the power cord with
moisturized or wet hands when plugging to
or unplugging from the outlet since it may be
a cause of electric shock.
Please be advised of electric wires and cables when installing
the antenna. It may be a cause of hazardous electric shock and
fire if the antenna touches or falls on the electric wire; thus, it
must be installed firmly, and far away from the cables.
Do not spill water or drop the remote control
since it may be a cause of malfunctioning.
This section must be read carefully and followed by the user prior to the operation of the product.
The manual states important instructions for the user's own safety, and the proper operation of the product.
Please keep the user's manual in a safe place for future reference.
Do not expose the product to a dusty or
moisturized place since it may be a cause of
malfunctioning.

Table of
Contents
7
Installation and Maintenance
Stand Construction 9
Antenna Connection 11
Video Connection 14
Camcorder & Video Game Connection 15
DVD Player Connection 16
STB(Set Top Box) Connection 17
PC Connection 18
USB Connection 20
Cable TV Broadcasting Connection 21
Connect with the Dolby Digital AMP 22
Name of Each Part 23
Basic Guide
Functionsa of the Remote Control 25
Method To Use Basic Menu 27
To Watch TV 28
Setting Up TV Stations 30
Selection of TV/VIDEO Input Signal 34
Selection of Multimedia Input Signal 35
Selection of Media(USB) Input Signal 37
Application Guide
Picture Adjustment 38
Sound Adjustment 42
Features - Closed Caption 46
Features - Parental Control 48
Features - ETC 53
Time Setting 54
Channel Banner 57
Troubleshooting 59
Standard of Product 61

Supplied
Accessories
8
Make sure that the following accessories are provided with the product.
AC cord
AC cord Instruction manual
-
Remote control
Batteries
Cover Bottom
-When installing wall mount, set the cover
bottom as shown above
Cable holder
Wall Mounting Unit
(OPTIONAL)
1
23
The method of wire arrangement
1. Assemble the cable holder enclosed on the back
of TV. (PICTURE 1)
(ASSEMBLY METHOD: After you push the
"A"(prominence part of cable holder) in the
hole, rotate the cable holder clockwise as an
angle of 90°. You can separate in reverse order
of assembly.)
2. Open the cable holder. (PICTURE 2)
( you can open the cable holder then press and
push "B" part.)
3. After arranging cables with the cable holder,
lock "B" again. (PICTURE 3)

Stand
Construction
9
32” Stand Assy Construction
1. Insert the cover frame stand to the stand base 2. Insert the frame stand into the stand base
3. Assemble plate stand base and frame stand
with the 4 screws supplied.
4. Assemble TV set and stand with the 3 screws supplied.
ز
ز
ز
ز
ز
ز
ز
When attaching stand to TV set, be
sure to cover the surface to protect
from accidental damage.

Stand
Construction
10
37” Stand Assy Construction
1. Insert the TV set to the stand assy.
2. Assemble TV set and stand with screw 5EA.
ز
ز
ز
ز
ز
When attaching stand to TV set, be
sure to cover the surface to protect
from accidental damage.

Antenna
Connection
11
Indoor Antenna Connection
1. Connect the feeder cable of the antenna to the combining adapter.
WHEN THE IMAGE IS NOT CLEAR : Unclear screen image and bad reception may be a cause of wrong
antenna connection. Be sure to check its direction and place when
installing.
2. Connect the combining adapter to the antenna input at the left side of the TV set.
WHEN USING THE COMBINING ADAPTER : You may obtain the combining adapter at your closest
Service Center.
Combining adapter
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
INPUT
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITAL AUDIO
S-VIDEO
Antenna Input
REAR OF THE TV SET

Antenna
Connection
12
Antenna socket at the back of the TV set
ANT
ANT
Combining adapter
Antenna Connection
When a coaxial cable is used : Plug the coaxial cable to the antenna socket on the wall.
When a feeder cable is used : Plug the coaxial cable to the antenna socket on the wall.
Antenna socket at the back of the TV set

Antenna
Connection
13
Outdoor Antenna Connection
Outdoor Antenna connection-such as VHF or/and UHF-may be necessary for installation at private houses
Single Antenna Connection
Separate Antenna Connection.
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
INPUT
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITAL AUDIO
S-VIDEO
VHF Antenna
UHF Antenna
ANT
REAR OF THE TV SET
ANT

Video
Connection
14
INPUT
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITAL AUDIO
S-VIDEO
USB
R-AUDIO-L VIDEO
AV2
INPUT
Note : • If your AV device has both Video OUT terminal and S-Video OUT terminal, S-Video connection is
recommended for better picture quality.
• If S-Video and RCA jack are connected at the same time, the TV set will only detect the S-Video
mode.
Connecting with an External Source
You may connect S-Video1(Rear of the TV) input to enjoy clearer and brighter picture images. You can
make the connection with the AV1 or AV2 input.
REAR AND SIDE OF THE TV SET

Camcorder & Video
Game Connection
15
Note : • If your AV device has both Video OUT terminal and S-Video OUT terminal, S-Video connection is
recommended for better picture quality.
• If S-Video and RCA jack are connected at the same time, the TV set will only detect the S-Video
mode.
Watching the Camcorder Recording or Video Game on TV
1. You can use either the S-video or the RCA connector.
2. These connectors connect to AV1/2 or S-Video1 as shown below.
3. Turn on the TV set and camcorder/video game.
4. Press "INPUT" and then You can see input menu. Select AV1, AV2 or S-Video1 mode by pressing
"" and “OK” key.
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
INPUT
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITAL AUDIO
S-VIDEO
USB
R-AUDIO-L VIDEO
AV2
INPUT
REAR AND SIDE OF THE TV SET

DVD player
connection
16
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
INPUT
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITAL AUDIO
S-VIDEO
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
INPUT
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITALAUDIO
S-VIDEO
USB
R-AUDIO-L VIDEO
AV2
INPUT
REAR OF THE TV SET
REAR AND SIDE OF THE TV SET
Note : When you connect with the component, please check the color of cable between DVD and TV set.
Note :
• If your AV device has both Video OUT terminal and S-Video OUT terminal, S-Video connection is
recommended for better picture quality.
• If S-Video and RCA jack are connected at the same time, the TV set will only detect the S-Video
mode.
When connecting with a component cable
When connecting with a S-VHS cable and RCA cable

STB(Set Top Box)
Connection
17
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
INPUT
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITAL AUDIO
S-VIDEO
REAR OF THE TV SET
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
INPUT
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITAL AUDIO
S-VIDEO
Set Top Box
REAR OF THE TV SET
When connecting with a HDMI cable
When connecting with a component cable

PC
Connection
18
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
INPUT
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITAL AUDIO
S-VIDEO
1. Adjust PC resolution to available resolution in LCD TV.
2. Connect the PC and TV set using the D-Sub and Audio cable like below the picture.
3. Turn on the PC and TV set.
4. Press "INPUT" and then You can see input menu. Select PC mode by pressing " " or "OK" key.
VIDEO L-AUDIO-R
MONITOR
VIDEO L-AUDIO-R
OUT
AV1
ANT
HDMI
1
HDMI
2
INPUT
PC
PC/HDMI 1
AUDIO
Y Pb Pr L-AUDIO-R
COMP 1 COMP 2
SERVICE
OPTICAL
DIGITAL AUDIO
S-VIDEO
1. Adjust PC resolution to available resolution in LCD TV.
2. Connect the PC and TV set using the HDMI and Audio cable like below the picture.
3. Turn on the PC and TV set.
4. Press "INPUT" and then You can see input menu. Select PC mode by pressing " " or "OK" key.
REAR OF THE TV SET
REAR OF THE TV SET
When connecting with PC(D-Sub) cable.
When connecting with a HDMI cable.
Note : If the graphic card of the PC only support DVI signal, you must connect the Audio cable as shown above.

PC
Connection
19
PC CONNECTION NOTES:
1) If there is a [Vertical Frequency] setting menu in the [Screen] Menu of the PC, adjust the frequency to 60Hz.
2) If the PC resolution is too high, it may be hard to read letters. Select a suitable resolution.
3) HDMI input port receives only Digital Signal.
4) Depending on the graphic card when you plug & unplug the HDMI connection, the screen may not display
correctly.
Restart the computer if this happens.
Note :
1. When you connect with component, PC (D-Sub), and HDMI, you must check the input resolution of
external devices.
2. So if this mode is used at PC mode, the screen can be enlarged.
