Cub Cadet 979 User manual

PRINTED IN U.S.A.
FORM NO.
770-10089C.fm
(11/01)
21” Self-Propelled
Mower
Model Number
979
OPERATOR’S MANUAL
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
CUB CADET LLC P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-
covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting
applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator.
In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have
similar laws.Federal laws apply on federal lands. A sparkarrester forthemuffler is availablethrough your nearest engine authorized
service dealer or contact the service department, P.O. Box 368023 Cleveland, Ohio 44136-9722.

2
TABLE OF CONTENTS
Content Page
Important Safe Operation Practices...................................................................3
Slope Gauge......................................................................................................6
Assembling Your Lawn Mower...........................................................................7
Know Your Lawn Mower....................................................................................8
Operating Your Lawn Mower .............................................................................9
Making Adjustments ..........................................................................................11
Maintaining Your Lawn Mower...........................................................................12
Troubleshooting.................................................................................................16
Parts List............................................................................................................18
FINDING MODEL NUMBER
This Operator’s Manual is an important part of your new lawn mower. It will help you assemble, prepare and
maintain the unit for best performance. Please read and understand what it says.
Before you start assembling your new equipment, please locate the model plate on the
equipment and copy the information from it in the space provided below. The information on the
model plate is very important if you need help from our Customer Support Department or an
authorized dealer.
• You can locate the model number by looking down at the rear of the deck. A sample model plate is
explained below. For future reference, please copy the model number and the serial number of the
equipment in the space below.
ENGINE INFORMATION
The engine manufacturer is responsible for all engine-related issues with regards to performance, power-
rating, specifications, warranty and service. Please refer to the engine manufacturer’s Owner’s/Operator’s
Manual packed separately with your unit for more information.
CALLING CUSTOMER SUPPORT
If you have difficulty assembling this product or have any questions regarding the controls, operation or
maintenance of this unit, please call the Customer Dealer Referral Line.
Call 1-877-282-8684 to reach the Customer Dealer Referral Line. Please have your unit’s
model number and serial number ready when you call. See previous section to locate this
information. You may be asked to enter the serial number in order to process your call.
Copy the model number here:
Copy the serial number here:
For more details about your unit, visit our website at www.cubcadet.com

3
SECTION 1: IMPORTANT SAFE OPERATION PRACTICES
WARNING: This symbol points out important safety instructions which, if not followed, could
endanger the personal safety and/or property of yourself and others. Read and follow all instructions in
this manual before attempting to operate this machine. Failure to comply with these instructions may
result in personal injury. When you see this symbol - heed its warning.
WARNING: Engine Exhaust, some ofits constituents, and certain vehicle
components containor emit chemicals known to State of California to cause cancer
and birth defects orother reproductive harm.
DANGER:This machine was built to be operated according to the rules for safe operation in this
manual. As with any type of power equipment, carelessness or error on the part of the operator can
result in serious injury. This machine is capable of amputating hands and feet and throwing objects.
Failure to observe the following safety instructions could result in serious injury or death.
General Operation
1. Read this operator’s manual carefully in itsentirety
before attempting to assemble this machine. Read,
understand, and follow all instructions onthe machine
and in the manual(s) before operation. Be completely
familiarwith the controls and the proper use ofthis
machine before operating it. Keep this manual in a safe
place for future and regular reference and for ordering
replacement parts.
2. This machine is a precision piece of power equipment,
nota plaything. Therefore,exercise extremecautionat all
times. Your unit hasbeen designed to perform one job: to
mow grass. Do not use it for any other purpose.
3. Never allow children under 14 years old to operate this
machine. Children 14 years old and overshould readand
understand the operation instructions and safety rules in
this manual and should be trained andsupervised by a
parent. Only responsible individuals who are familiar with
theserulesof safe operation shouldbe allowed to use
this machine.
4. Thoroughly inspect the area where theequipmentis to
be used.Remove all stones, sticks,wire,bones, toysand
other foreign objects which could be tripped over or
picked up and thrown by the blade. Thrown objectscan
cause serious personal injury. Plan yourmowing pattern
to avoid discharge of material toward roads, sidewalks,
bystanders and the like. Also, avoid dischargingmaterial
against a wallor obstruction which may cause
discharged material to ricochet back toward the operator.
5. To helpavoid blade contactor a thrown object injury, stay
in the operator zone behind thehandlesand keep
children, bystanders, helpers and pets at least 75 feet
from the mower while it is in operation. Stop machine if
anyone enters the area.
6. Always wear safety glasses or safety goggles during
operation and while performing an adjustment orrepair to
protect your eyes. Thrown objects which ricochet can
cause serious injury to the eyes.
7. Wear sturdy, rough-soled work shoes and close-fitting
slacks and shirts. Shirts and pants that cover the arms
and legs and steel-toed shoes are recommended. Never
operate this machine in bare feet, sandals, slippery or
light weight (e.g. canvas) shoes.
8. Do not puthands orfeetnear rotating parts orunder the
cutting deck. Contactwith the blade can amputate hands
and feet.
9. A missing or damaged discharge cover can cause blade
contact or thrown object injuries.
10. Many injuries occur asa resultof the mower being pulled
over the foot during afall caused by slipping or tripping.
Do nothold on to themowerif you are falling; releasethe
handle immediately.
11. Never pull the mowerback toward you while you are
walking. If you mustback the moweraway from a wall or
obstruction first look down and behind to avoid tripping
and then followthese steps:
a. Step back from the mower to fully extend your
arms.
b. Be sure you are well balanced with sure footing.
c. Pullthe mower backslowly,no more than half way
toward you.
d. Repeatthese steps as needed.
12. Do not operate the mowerwhile under the influence of
alcohol or drugs.
13. Do not engage the self-propelled mechanism on units so
equipped while starting engine.
14. The blade control handle is a safety device. Never
attempt to bypassitsoperation. Doing so makes the
safety device inoperative and may result in personal
injury through contact with the rotating blade. The blade
control handle must operate easily in both directions and
automatically return to the disengaged position when
released.
15. Never operate the mower in wet grass. Always be sure of
your footing. A slip andfall can cause seriouspersonal
injury. If youfeel you are losing yourfooting, release the
bladecontrol handle immediatelyand the blade will stop
rotating within threeseconds.
16. Mow only in daylight or in good artificial light. Walk, never
run.
17. Stop the blade when crossing gravel drives,walks or
roads.
18. If the equipment should start to vibrate abnormally,stop
the engine and check immediately forthe cause.
Vibration is generally a warning of trouble.
19. Shut the engine off and wait until the blade comes to a
complete stop before removing the grass catcher or

4
unclogging the chute. The cutting blade continues to
rotate for a few seconds aftertheengine isshut off. Never
placeanypart of the body in the blade area until you are
sure the blade has stopped rotating.
20. Never operate mower without proper trail shield,
discharge cover, grass catcher, blade control handle or
othersafety protective devices in place and working.
Never operate mower with damaged safety devices.
Failure todo so, can resultin personal injury.
21. Muffler and engine become hot and can cause a burn. Do
not touch.
22. Only use parts and accessories made forthis machine by
the manufacturer. Failure to do so,can result in personal
injury.
23. If situations occur which are not covered in this manual,
use care and good judgment. Contact your dealer for
assistance. Telephone [phone] for the name of
your nearest dealer.
SlopeOperation
Slopesare a majorfactor related to slip and fall accidents
which can result in severe injury. Operation on slopes
requires extra caution. If you feel uneasy on a slope, do not
mow it. For your safety, use the slope gauge included as part
of this manual to measure slopes before operating this unit on
a sloped or hilly area. Ifthe slope isgreater than15 degrees,
do not mow it.
Do:
1. Mow acrosstheface ofslopes; neverup and down.
Exerciseextremecaution when changing direction on
slopes.
2. Watch for holes, ruts, rocks, hidden objects, or bumps
whichcan causeyou to slip or trip.Tallgrass can hide
obstacles.
3. Always be sure of your footing. A slip and fall can cause
serious personalinjury. If youfeel you are losing your
balance, release the blade control handle immediately,
and the blade will stop rotating within3 seconds.
Do Not:
1. Do notmow neardrop-offs, ditches or embankments,you
couldlose your footing or balance.
2. Do notmow slopesgreater than15degreesas shown on
the slope gauge.
3. Do not mow onwet grass.Unstable footing could cause
slipping.
Children
Tragic accidents can occur if the operator is not alert to the
presence of children.Children areoftenattracted to the
mower and the mowing activity. They do not understand the
dangers. Never assume that children will remain where you
last saw them.
1. Keep children out of the mowingarea and underthe
watchful care of a responsible adult other than the
operator.
2. Be alert and turn mower off if a child enters the area.
3. Before and while moving backwards, lookbehind and
down for small children.
4. Use extreme care when approaching blind corners,
doorways, shrubs, trees, or other objects that may
obscure your vision of a child whomay run into the
mower.
5. Keep children away from hot or runningengines.They
can suffer burns from a hot muffler.
6. Never allow children under 14 years old to operate a
power mower. Children 14 years old and over should
read and understand the operation instructionsand
safety rules in this manualand should be trained and
supervised by a parent.
Service
Safe Handling Of Gasoline:
1. To avoidpersonal injury or propertydamage use extreme
care in handling gasoline. Gasoline is extremely
flammableand the vapors are explosive. Serious
personal injury can occur when gasoline is spilled on
yourself or your clothes which can ignite.
2. Wash your skin and change clothes immediately.
3. Use onlyan approved gasoline container.
4. Never fillcontainers inside avehicle or on a truck or
trailer bed with a plastic liner. Always place containers on
the ground away from your vehicle before filling.
5. When practical, remove gas-powered equipment from
the truck or trailer and refuelit onthe ground. If this is not
possible, then refuel such equipment on atrailer with a
portable container, ratherthan from a gasoline dispenser
nozzle.
6. Keep the nozzle in contact with the rim ofthe fuel tankor
container opening at all times until fuelingis complete. Do
not use a nozzle lock-open device.
7. Extinguish all cigarettes, cigars, pipes and other sources
of ignition.
8. Never fuel machine indoorsbecause flammablevapors
will accumulate in the area.
9. Never remove gas cap or add fuel while the engine is hot
or running. Allow engine to cool at least two minutes
before refueling.
10. Never over fill fuel tank. Fill tank to no more than ½ inch
below bottom of filler neck to provide space for fuel
expansion.
11. Replace gasoline cap and tighten securely.
12. If gasolineis spilled, wipe itoff theengine and equipment.
Move unit to another area. Wait 5 minutes before starting
the engine.
13. Never store the machine or fuelcontainer insidewhere
there is an open flame,spark orpilot light ason a water
heater, space heater, furnace ,clothes dryer or other gas
appliances.
14. To reduce fire hazard, keep mower free of grass, leaves,
or other debris build-up. Clean up oil orfuelspillage and
remove any fuel soaked debris.
15. Allow amower to cool at least 5 minutes before storing.
General Service:
1. Never run an engine indoors or in apoorly ventilated
area. Engine exhaust contains carbon monoxide, an
odorless and deadly gas.
2. Before cleaning, repairing, or inspecting, make certain
the blade and all moving parts have stopped. Disconnect
the sparkplug wireand ground against theengine to
prevent unintended starting.

5
3. Check the blade and engine mounting bolts at frequent
intervals for proper tightness. Also, visually inspect blade
for damage (e.g., bent, cracked, worn) Replace blade
withthe original equipmentmanufacture’s (O.E.M.) blade
only, listed in this manual. “Use of parts which do not
meet the original equipment specifications maylead to
improper performanceand compromise safety!”
4. Mower blades are sharpand can cut. Wrap theblade or
wear gloves, and use extra caution when servicing them.
5. Keep allnuts,bolts, and screws tight to besure the
equipment is in safe working condition.
6. Never tamper with safety devices.Check their proper
operation regularly.
7. Afterstrikinga foreign object,stopthe engine,disconnect
the spark plug wireand ground against the engine.
Thoroughly inspect the mower for any damage. Repair
the damage before starting and operating the mower.
8. Never attempt to make a wheel or cutting height
adjustment while the engine is running.
9. Grass catcher components, discharge cover, and trail
shield aresubjectto wearand damage which could
expose moving parts or allow objects to be thrown. For
safety protection, frequently check components and
replace immediately with original equipment
manufacturer’s (O.E.M.) parts only, listed in this manual.
“Use of parts which do not meet the original equipment
specifications may lead to improper performanceand
compromise safety!”
10. Do not change the engine governor setting or overspeed
the engine. The governor controls themaximumsafe
operating speed ofthe engine.
11. Maintain or replace safety and instruction labels,as
necessary.
12. Observe proper disposal laws and regulations. Improper
disposal of fluids and materialscan harm the
environment.
WARNING - YOUR RESPONSIBILITY: Restrict theuse of this power machine topersonswho read,
understand and follow the warningsand instructions in this manualand on the machine.
NOTE: Not all safety labels shown may apply to your lawn mower.

6
SECTION 2: SLOPE GAUGE Use this page as a guide to determine slopes where you may not operate safely. Do not operate your lawn mower on such slopes.
15°
SIGHT AND HOLD THIS LEVEL WITH A VERTICAL TREE
A POWER POLE
A CORNER OF A BUILDING
OR A FENCE POST
FOLDONDOTTEDLINE,REPRESENTINGA15°SLOPE
WARNING
Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). A riding mower could
overturn and cause serious injury. If operating a walk-behind mower on such a slope, it is extremely difficult to maintain your footing
and you could slip, resulting in serious injury.
Operate RIDING mowers up and down slopes, never across the face of slopes.
Operate WALK-BEHIND mowers across the face of slopes, never up and down slopes.

7
SECTION 3: ASSEMBLING YOUR LAWN MOWER
IMPORTANT: This unit is shipped without gasoline or oil
in the engine. Be certain to service engine with gasoline
and oil as instructed in the separate engine manual
before operating your mower.
NOTE: Reference to right or left hand side of the mower
is observed from the operating position.
Removing Unit From Carton
•Remove staples, break glue on top flaps, or cut
tape at carton end and peel along top flap to open
carton.
•Remove loose parts if included with unit (i.e.,
operator’s manual, oil, etc.)
•Cut along corners, laycarton down flat, andremove
packing material.
•Roll or slide unit out of carton and check carton
thoroughly for loose parts.
Loose Parts in Carton
•Grass Bag
•Grass Bag Adapter
•Side Discharge Chute
•Hardware Pack
Disconnecting Spark Plug Wire
•Before setting up your lawn mower, disconnect the
spark plug wire from the spark plug and ground
against the engine. See Figure 1.
Figure 1
Setting Up Your Lawn Mower
•Remove grass bag and other loose parts from unit
and set it aside.
•Lift up and pull back on the upper handle to raise
the handle into the operating position. Make
certain the lower handle is seated securely into the
handle mounting brackets. Tighten the wing nuts
on each side of the handle (carriage bolts must be
seated properly into the handle). See Figure 2.
NOTE: Your mower is shipped with the handle in the
higher height position. If you wish to lower the height of
the handle, refer to the Adjustment Section at this time.
Figure 2
•Remove the hairpin clips from the outer hole in the
weld pins on the handle mounting brackets. Using a
pair of pliers, squeeze one leg of the lower handle
against the handle mounting bracket. Insert the
hairpin clip into the inner hole on the weld pin.
Repeat on other side. See Figure 3.
•After moving the hairpin clip, insertthe carriage bolt
from hardware pack in the upper hole on the handle
mounting bracket and secure with plastic wing nut
from the hardware pack. Repeat on other side.
Figure 3
•Fasten the cables to the lower handle with the two
cable ties found on the lower handle. Be sure to
insert the post on the cable ties into the holes
provided on the lower handle. These holes may be
found on either the inside oroutside of the handles.
Pull the cable ties tight and trim off the excess.
See Figure 4.
Figure 4
Spark
Plug
Spark Plug
Wire
Handle Assembly
Handle Mounting
Bracket
Wing Nut
Handle Mounting
Bracket
Lower
Handle
Hairpin
Clip
Inner Hole
Carriage Bolt
Wing Nut
Cable Tie
Lower
Handle

8
NOTE: Make certain the drive cable is routed around
the outside and above the lower handle so it does not
interfere with attaching the grass bag.
•The rope guide, which is connected to the support
rod, is located on the right side of lower handle.
See Figure 5.
•With the spark plug wire disconnected and
grounded, hold the blade control handle against the
upper handle, and pull the starter rope out of the
engine. Release the blade control handle. Slip the
starter rope into the rope guide. Figure 5
SECTION 4: KNOW YOUR LAWN MOWER
Read this operator’s manual and safety rules before
operating your lawn mower. Compare the illustrations
in Figure 6 with your lawn mower to familiarize yourself
with the location of various controls and adjustments.
Save this manual for future reference.
WARNING: The operation of any lawn
mower can result in foreign objects being
thrown into the eyes, which can damage
your eyes severely. Always wear safety
glasses while operating the mower, or
while performing any adjustments or
repairs on it.
Recoil Starter
The recoil starter is attached to the right lower handle.
Stand behind the unit and pull the recoil starter to start
the unit. See Figure 6.
Blade Control Handle
The blade control handle is located on the upper handle
of the mower. The blade control handle must be
depressed in order to operate the unit. Release blade
control handle to stop engine and blade. See Figure 6.
WARNING: This blade control mechanism
is a safety device. Never attempt to bypass
its operations.
Cutting Height Adjustment Lever
The cutting height adjustment lever is located above
the left rear wheel. To adjust the cutting height, refer to
the Adjustment Section in this manual. See Figure 6.
Drive Clutch Control
The drive clutch control is located on the upper handle.
Squeeze the drive control to engage the drive system.
Release the clutch control to disengage the drive
system. Release the clutch control to slow down when
approaching an obstacle, making a turn, or stopping.
See Figure 6.
Shift Lever
The shift lever is located on the drive clutch control
housing on the upper handle. This lever is used to
select the forward speed of the mower. When changing
speed selection, release the drive clutch control. See
Figure 6.
NOTE: Move the shift lever only when the engine is
running. Changing the shift lever setting with the
engine off can cause damage to the mower.
Grass Bag
The grass bag is equipped with a bag-fill indicator to
add convenience to your work. While the mower is
running, air will flow through the bag and into the “sail.”
If the grass catcher is empty, air flows through easily
pushing the sail up. If the grass catcher is full, air does
not flow through it allowing the sail to fall. So the
position of the sail acts as a bag-fill indicator signifying
when to empty the grass bag. See Figure 6.
Engine Controls
See the separate engine manual for the location and
function of the controls on the engine.
Figure 6
Starter
Rope
Rope
Guide
Lower
Handle
Support
Rod
Blade Control
Handle
Recoil
Starter
Cutting Height
Adjustment Lever
Discharge
Chute
Mulching
Plug
Drive Clutch
Control
Shift Lever
Grass Bag

9
SECTION 5: OPERATING YOUR LAWN MOWER
WARNING: Keep hands and feet away
from chute area on the cutting deck. The
operation of any lawn mower can result in
foreign objects being thrown into the
eyes, which can result in severe eye
damage. Always wear safety glasses or
eye shields.
NOTE: For shipping purposes your mower is set with
the wheels in a low cutting height position. For best
results raise the cutting position until it is determine
which height is best for your lawn. See the adjustment
section for details.
Gas and Oil Fill-Up
Service the engine with gasoline and oil as instructed in
the separate engine manual packed with your mower.
Read instructions carefully.
WARNING: Never fill fuel tank indoors with
engine running or until the engine has
been allowed to cool for at least two
minutes after running.
Before Starting Your Mower
•Attach spark plug wire to spark plug. Make certain
the metal cap on the end of the spark plug wire is
fastened securely over the metal tip on the spark
plug.
•Check for proper drive clutch operation using the
NEUTRAL ADJUSTMENT TEST.
Neutral Adjustment Test
To perform the neutral adjustment test answer the
following questions.
•With the drive clutch control released, push mower
forward and pull it backward. Does it move freely?
•Squeeze the drive clutch control and pull the
mower backward. Do the rear wheels lock?
•Is the drive clutch control cable free of kinks or
sharp bends?
•If you answered “yes”to all three questions, your
mower passed the test and you can start your
mower.
•If you answered “no”to any of the three questions,
you will have to adjust the drive clutch control as
instructed in the ADJUSTMENT SECTION.
Starting Engine
•Prime engine as instructed in the separate engine
manual packed with your unit.
•Your lawn mower is equipped with a constant
speed throttle, which isset at full throttle for best
performance.
•Stand behind the mower and squeeze the blade
control handle against the upper handle.
•Grasp recoil starter handle and pull rope out slowly
untilengine reaches the start of compression cycle
(rope will pull slightly harder at this point). Let the
rope rewind slowly. Pull rope with a rapid,
continuous, full arm stroke. Keeping a firm grip on
the starter handle, let the rope return to the starter
slowly.
Stopping Engine
•Release blade control handle to stop the engine
and the blade.
•Disconnect spark plug wire and ground it to the
post on the engine.
Using Your Lawn Mower
Be sure that the lawn is clear ofstones, sticks,wire, or
other objects which could damage the lawn mower or
Towards Better Mower Performance
1. Pour fresh, clean gasoline into the mower’s gas
tank until the tank is full. Do not use gasoline
that is more than 30 days old.
2. Make sure to connect the mower’s spark plug
wire before trying to start the engine.
3. Add engine oil to the oil fill on the mower engine.
Check the dipstick and add more if necessary.
Remember that the oil level has to touch the fill
line.
4. Locate the primer decal near the primer bulb on
the engine, and read its instruction. Using your
thumb, press the primer bulb slowly as many
times as the decal advises.
5. Hold control handle down and pull rope firmly to
start the engine.
6. Set cutting height adjustment lever to middle
setting and mow a single pass on your lawn;
then adjust to desired height for a closer cut.
7. To mulch insert the mulch plug/cover on the
mower.
8. Before storing the lawn mower for the winter,
use stabilizer-treated fuel and run the tank dry.
9. Thirty days before start of the new season,
check the air filter, spark plug and blade on the
lawn mower, and replace if needed.

10
the engine. Such objects could be accidently thrown by
the mower in any direction and cause serious personal
injury to the operator and others.
For best results, do not cut wet grass because it tends
to stick to the underside of the mower, preventing
proper discharge of grass clippings, and could cause
you to slip and fall. New grass, thick grass, or wet grass
may require a narrower cut.
For a healthier lawn, never cut off more than one-third
of the total length of the grass. Your lawn should be cut
in the fall as long as there is growth. This mower is
designed to be operated at full throttle to give you the
best cut and do the most effective job of mowing or
mulching.
WARNING: If you strike a foreign object,
stop the engine. Remove wire from the
spark plug, thoroughly inspect the mower
for any damage, and repair the damage
before restarting and operating the
mower. Extensive vibration of the mower
during operation is an indication of
damage. The unit should be promptly
inspected and repaired.
Mulching
For effective mulching, do not cut wet grass because it
tends to stick to the underside of the deck, preventing
proper mulching of grass clippings. New or thick grass
may require a narrower cut. The ground speed should
be adjusted to the condition of the lawn. If mowing has
been delayed and the grass has been allowed to grow
in excess of 4”, mulching is not recommended. Mow
using the grass bag to reduce the grass height to 3 1/4”
maximum before mulching.
Attaching The Grass Bag
•Remove three wing nuts holding the mulching
baffle or side discharge chute in place and remove
from unit. See Figure 7.
Figure 7
•Replace with grass bag adapter, while making
sure the front lip of adapter goes under the edge of
the deck. Secure with wing nuts previously
removed.
•Lift chute door on the grass bag adapter and slide
grass bag onto the adapter. See Figure 8.
NOTE: The chute door has been designed to move the
starter rope out of the way of the bag when the chute
door is opened.
Figure 8
Attaching Side Discharge Chute
•Remove mulching baffle or grass bag adapter from
unit by disconnecting wing nuts.
•Attach side discharge chute to unit and secure with
the three wing nuts. See Figure 9.
Figure 9
Emptying the Grass Bag
•While holding thegrass bag by both the rear handle
and the lower handle, lift the grass bag straight up
off the adapter. The chute door will move the rope
out of the way of the bag.
•Continue to hold the lower handle and raise the
rear of the grass bag up toward your chest. The
grass bag will open and the grass clippings will
disperse.
•When replacing the grass bag, be sure the top of
the bag rests on the wire support between the
handles.
Grass Bag
Adapter
Wing
Nuts
Grass
Bag
Chute
Door
Side Discharge
Chute

11
SECTION 6: MAKING ADJUSTMENTS
WARNING: Do not at any time make any
adjustments without first stopping engine
and disconnecting spark plug wire.
Cutting Height Adjustment
Your mower is shipped with the cutting height in the
lowest position. The cutting height adjustment lever is
located above the left rear wheel. To adjust the cutting
height, pull the lever out and away from the mower and
then move it forward or backward to select a new
cutting height. See Figure 10.
NOTE: For rough or uneven lawns, move the height
adjustment lever to a higher position. This will help stop
scalping.
Figure 10
Handle Height Adjustment
Your mower is shipped with the handle in the higher
height position. To lower the height proceed as follows:
•Remove the starter rope from the rope guide.
•Remove the upper handle by removing the hand
knobs and carriage bolts. Lay the upper handle out
of the way, being careful not to bend or kink the
cables.
•Remove the hairpin clips from the weld pins on the
handle brackets and remove the wing nuts and
carriage bolts from the upper hole on the handle
mounting bracket. Press out on the legs of the
lower handle and remove lower handle from the
mower.
•Turn lower handle around so the notch on the
bottom of the lower handle is facing forward.
See Figure 11.
•Reassemble, placing the bottom holes in the
handle over the weld pins in the handle mounting
bracket.
•Place the hairpin clips in the inner holes in the weld
pins and insert the carriage bolts the upper hole on
the handle mounting bracket and secure with
plastic wing nuts.
•Reassemble the upper handle to the lower handle.
•Attach the starter rope as instructed in the
Assembly Section.
Figure 11
Drive Clutch Control Adjustment
The adjustment wheel is located in the drive clutch
control handle housing and is used to tighten or loosen
the drive belt. You will have to adjust the drive clutch
control if any of the following happens:
•The mower does not propel itself with the drive
clutch engaged.
•The mower’s drive wheels hesitate with the drive
clutch engaged.
To resolve the above problems, rotate the adjustment
wheel with your fingers. Clockwise to tighten the cable
and counter-clockwise to loosen the cable.
See Figure 12.
Figure 12
NOTE: For some people the drive clutch control may
not be in a comfortable position. You can adjust the
handle out by tightening the adjustment wheel.
Shift Lever Cable Adjustment
Periodic adjustment of the six speed shift cable may be
Cutting Height
Adjustment Lever
Lower
Higher
Notch
Lower Handle
Adjustment
Bottom View
Wheel
Drive Clutch
Control
Upper
Handle

12
required due to normal wear on the cable. Adjustment
is needed if all six speeds do not work.
The adjustable cable bracket is located on the left side
of the mower beside the engine. See Figure 14.
•Start engine and place speed control lever in the
sixth speed position. See Figure 13.
Figure 13
•Stop engine and disconnect spark plug wire and
ground it against engine.
•Loosen hex nut which secures the adjustable cable
bracket. See Figure 14.
•Push back on the adjustable cable bracket and
tighten hex nut.
Figure 14
Engine Adjustments
See the separate engine manual packed with your unit
for adjustments to the engine.
SECTION 7: MAINTAINING YOUR LAWN MOWER
General Recommendations
•Always observe safety rules when performing any
maintenance.
•The warranty on this lawn mower does not cover
items that have been subjected to operator abuse
or negligence. To receive full value from the
warranty, operator must maintain the lawn mower
as instructed in this manual.
•Changing of engine governed speed will void
engine warranty.
•Some adjustments will have to be made
periodically to maintain your unit properly. All
adjustments in the Making Adjustments section of
this manual should be checked at least once each
season.
Bottom View
Speed Control
Lever
Upper
Handle
Hex Nut
Adjustable Cable
PUSH
Bracket
Customer Responsibilities
MAINTENANCE
SCHEDULE
PRODUCT
ENGINE
SERVICE
DATES
Aftereachuse
Every25hours
Every50hours
Beforestorage
Every100hours
Onceaseason
Lubricate Wheels
Clean Deck
Blade Care
Change Oil
Clean Engine
Replace Air Filter
Check Spark Plug
Check Spark Arrester (if any)
Lubricate Blade Control
Check Oil

13
•Periodically check allfasteners and make sure
these are tight.
•Follow the maintenance schedule under Customer
Responsibilities to get quality performance from
your lawn mower.
Lubrication
WARNING: Always stop engine and
disconnect spark plug wire before
cleaning, lubricating or doing any kind of
service work on the lawn mower.
Blade Control: Lubricate the pivot points on the blade
control handle at least once a season with light oil. The
blade control must operate freelyin both directions.
See Figure 15.
Wheels: Lubricate the wheels at least once a season
with light oil (or motor oil). If the wheels are removed for
any reason, lubricate the surface of the axle bolt and
inner surface of the wheel with light oil. See Figure 15.
Engine: Follow the separate engine manual packed
with you unit for lubrication instructions.
Figure 15
Maintenance
NOTE: When tipping the unit, empty the fuel tank and
keep the air cleaner side of engine up. Never tip the
mower more than 90 degrees and do not leave the
mower tipped for any length of time. Oil can drain into
the upper part of the engine causing a starting problem.
Engine
Refer to the separate engine manual for all engine
maintenance instructions.
•Maintain engine oil as instructed in the separate
engine manual packed with your unit.
•Service air cleaner every 25 hours under normal
conditions. Poor engine performance and flooding
usually indicate that the air cleaner should be
serviced. To service the air cleaner, refer to the
separate engine manual packed with your unit.
•The spark plug should be cleaned and the gap
reset once a season. Spark plug replacement is
recommended at the start of each mowing season.
•Clean the engine regularly with a cloth or brush.
Keep the cooling system (blower housing area)
clean to permit proper air circulation which is
essential to engine performance and life. Be certain
to remove all grass, dirt, and combustible debris
from muffler area.
Deck
The underside of the mower deck should be cleaned
after each use to prevent a buildup of grass clippings,
leaves, dirt, or other matter. If this debris is allowed to
accumulate, it will invite rust and corrosion, and may
prevent proper mulching, discharge, or bagging. The
deck may be cleaned by tilting the mower and scraping
clean with a suitable tool (make certain the spark plug
wire is disconnected).
IMPORTANT: We do not recommend the use of a
pressure washer or garden hose to clean your unit.
Cutting Blade Removal, Replacement, and Sharpening
•When removing the cutting blade for sharpening or
replacement, protect your hands with a pair of
heavy gloves or use a heavy rag to hold the blade.
•Remove the bolt and the blade bell support which
hold the blade and the blade adapter to the engine
crankshaft. See Figure 16.
•Remove the blade and the adapter from the
crankshaft.
WARNING: Periodically inspect the blade
adapter for cracks, especially if you strike
a foreign object. Replace when necessary.
Figure 16
When sharpening the blade, follow the original angle of
grind as a guide. It is extremely important that each
cutting edge receives an equal amount ofgrinding to
prevent an unbalanced blade. An unbalanced blade will
cause excessive vibration when rotating at high
Lubricate
Blade
Hex Bolt
Blade Bell
Adapter
Support

14
speeds. It may cause damage to the mower, and could
break causing personal injury.
The blade can be tested by balancing it on a round
shaft screwdriver. Remove metal from the heavy side
until it balances evenly. It is recommended that the
blade always be removed from the adapter when
testing for balance. Before reinstalling the blade and
the blade adapter to the unit, lubricate the engine
crankshaft and the inner surface of the blade adapter
with light oil.
•Be sure to install the blade with the side of the
blade marked “Bottom”(or with part number) facing
the ground when the mower is in the operating
position.
•Slide the blade adapter onto the engine crankshaft.
•Place the blade on the adapter. Be certain the
blade is aligned and seated on the blade adapter
flanges.
•Place blade bell support on blade. Make sure the
notches on the blade bell support are aligned with
small holes in the blade.
•Replace hex bolt and tighten to torque: 450 in. lbs.
min., 600 in. lbs. max.
NOTE: To ensure safe operation of your mower, the
blade bolt must be checked periodically for correct
torque.
Drive Belt Removal and Replacement
•Disconnect the spark plug wire and ground it
against the engine.
•Drain the fuel tank or place a piece of plastic
beneath the cap to prevent gasoline leakage.
•Place shift lever in the first position and tip the
mower on its side with air filter facing up.
•Remove the center bolt which secures the blade to
the crankshaft followed by blade bell support,
blade, and blade adapter.
•Move the cutting height adjustment to the highest
position.
•Remove the three hex screws holding the baffle to
the deck and pivot baffle towards the rear of the
mower. See Figure 17.
Figure 17
•Remove the hex bolt from the rear of unit holding
the transmission to the mower housing.
See Figure 18.
Figure 18
•Tilt the transmission forward and loosen the idler
pulley bolt and lock nut half a turn. See Figure 19.
•Using a pair of pliers, pull back and rotate belt
keeper bracket from the slot on the idler pulley.
•Slide the belt out from between the belt keeper
bracket and the idler pulley.
Figure 19
•Squeeze the belt together and push it forward,
while pressing the control arm inward towards the
deck and remove the six speed cable from the slot.
See Figure 20.
•Pivot the control arm down away from the pulley
and belt.
•Lift off the lower pulley assembly and remove the
old belt from around the crankshaft. See Figure 20.
Baffle
Cutting Height
Adjustment Hex Bolt
Transmission
Belt Keeper
Bracket
Idler Pulley
Belt
Idler Pulley
Bracket
Transmission
Pulley
Bolt and
Locknut

15
Figure 20
•Place the new belt over the transmission pulley.
Start the belt in the pulley groove and rotate the
pulley until the belt is seated in the transmission
pulley. Refer to Figure 20.
•Place the belt between the idler pulley and the belt
keeper bracket.
•Using pliers, rotate the belt keeper bracket so that it
snaps into slot on the idler bracket. Refer to
Figure 19.
•Tighten the idler pulley bolt and lock nut half a turn.
•Place the belt between the two pulley halves on the
crankshaft. Make sure to route the belt inside the
belt guard pin. See Figure 21.
Figure 21
IMPORTANT: When replacing the belt, do not disas-
semble the lower pulley assembly.
•Pinch both sides of the belt together so that the belt
is not in the pulley groove, and the lower pulley can
be pushed towards the engine. See Figure 22.
Figure 22
•Pivot the control arm back to its original position
and reinstall the six-speed cable into the slot.
See Figure 23.
•Check and make sure the belt is routed inside the
pulley halves and the belt guard pin.
Figure 23
•Reinstall the bolt securing transmission to rear
mower housing.
•Pivot the baffle back to its original position and
secure with three hex screws removed earlier.
•Lightly lubricate the inside of the blade adapter and
reinstall the spacer, wave washer, blade adapter
assembly, and blade in the correct order.
•Tighten the hex bolt to secure the blade to torque:
450-600 in. lbs.
Storing your Lawn Mower
The following steps should be taken to prepare your
lawn mower for storage.
•Clean and lubricatemower thoroughlyas described
in the lubrication instructions.
IMPORTANT: We do not recommend the use of a
pressure washer or garden hose to clean your unit.
Belt
Six-Speed
Control
Cable Slot
Arm
Belt
Lower
Crankshaft
Pulley Half
Belt
Belt
Tab
Guard Pin
Upper Pulley
Half
Lower Pulley
Half
Belt
Lower Pulley
Belt
Guard Pin
Half
Six-Speed
Cable Slot
Control
Arm

16
•Refer to engine manual for correct engine storage
instructions.
•Coat mower’s cutting blade with chassis grease to
prevent rusting.
•Store mower in a dry, clean area. Do not store next
to corrosive materials, such as fertilizer.
NOTE: When storing any type of power equipment in a
poorly ventilated or metal storage shed, care should be
taken to rust-proof the equipment. Using a light oil or
silicone, coat the equipment, especially cables and all
moving parts.
SECTION 8: TROUBLESHOOTING
NOTE: For repairs beyond the minor adjustments listed above, contact your nearest authorized service dealer.
Problem Cause Remedy
Engine fails to start 1. Blade control handle disengaged.
2. Sparkplug wire disconnected.
3. Fuel tank empty or stale fuel.
4. Blocked fuel line.
5. Faulty spark plug.
6. Engine flooded
1. Engage blade control handle.
2. Connect wire to spark plug.
3. Fill tank with clean, fresh gasoline.
4. Clean fuel line.
5. Clean, adjust gap, or replace.
6. Wait a few minutes to start engine.
Engine runs erratic 1. Spark plug wire loose.
2. Blocked fuel line or stale fuel.
3. Vent in gas plugged.
4. Water or dirt in fuel system.
5. Dirty air cleaner.
6. Carburetor out of adjustment.
1. Connect and tighten spark plug wire.
2. Clean fuel line; fill tank with clean, fresh
gasoline
3. Clear vent.
4. Drain fuel tank. Refill with fresh fuel.
5. Clean air cleaner.
6. Adjust carburetor.
Engine overheats 1. Engine oil level low.
2. Air flow restricted.
3. Carburetor not adjusted properly.
1. Fill crankcase with proper oil.
2. Remove blower housing and clean.
3. Adjust carburetor.
Occasionalskip(hesitates)
at high speed 1. Spark plug gap too close. 1. Adjust gap to .030”.
Idles poorly 1. Spark plug fouled, faulty or gap too
wide.
2. Carburetor improperly adjusted.
3. Dirty air cleaner.
1. Reset gap to .030”or replace spark
plug.
2. Adjust carburetor.
3. Clean air cleaner.
Excessive vibration 1. Cutting blade loose or unbalanced.
2. Bent cutting blade.
1. Tighten blade and adapter. Balance
blade.
2. Replace blade.
Mower will not mulch grass 1. Wet grass.
2. Excessively high grass.
3. Dull blade.
1. Do not mow when grass is wet; wait
until later to cut.
2. Mow once at a high cutting height, then
mow again at desired height or make a
narrower cutting path.
3. Sharpen or replace blade.
Uneven cut 1. Wheels not positioned correctly.
2. Dull blade.
1. Place all four wheels in same height
position.
2. Sharpen or replace blade.
Wheels will not propel 1. Belt not installed properly.
2. Debris clogging drive operation.
1. Check belt for proper pulley installation
and movement.
2. Clean out debris with engine off.

17
Notes

18
Model 979
1
2
3
4
5
6
7
8
9
10
11
12 13
14 15
16
17
18
19
20
21
27
31
32
33
34
35 36 37 38
39
40
41
42
43
44 45
46
47
48
49 45
51
5052
53
5456
55
57
57
58
59
60
61
62
63
64 65
66
67
33 69
70
71
72
73
74
75
76
77 78
79
80
81
82
83
84
85 86
87
68
28
93
29
88
89
90
91
92
30
94

19
Model 979
Ref.
No. Part No. Part Description
1. 647-0004 Control Handle
2. 731-0904A Upper Control Handle
3. 16864 6 Spd. Rack Cable Bracket
4. 731-0620 Control Lever
5. 713-0397 Gear Insert
6. 732-0627 Shift Lever Spring
7. 731-0924 6 Speed Shift Lever
8. 731-0905A Lower Control Housing
9. 710-1667A C Sunk Tap Screw#10 x .75Lg
10. 731-0906 Cable Mounting Cap
11. 746-0711A Drive Cable 51.0
12. 712-0324 Top Lock Nut 1/4-20
13. 746-0883 Control Housing
14. 710-1270 Oval C-Sunk Screw
15. 746-1131 Control Cable 46”
16. 749-0439D Upper Handle
17. 720-0241 Wing Nut
18. 736-0451 SaddleWasher.320 ID x .830OD
19. 710-1174 Carriage Bolt5/16-18 x 2.0
20. 726-0240 Cable Tie
21. 749-0907B Lower Handle
27. 731-1901 Trail Shield
28. 732-0842 Trail Shield Wire
29. 631-0066 Chute Assembly
30. 731-1832 Side Discharge Chute
31. 731-1833 Mulch Cover
32. 782-0078B Deck 21”
33. 712-0397 Wing Nut
34. 710-0703 Carriage Bolt 1/4-20 x .75
35. 746-0939 6 Speed Cable
36. 782-7574A Cable Adjustment Bracket
37. 736-0270 BellWasher .265 ID x .75 OD
38. 712-0287 Hex Nut 1/4-20
39. 710-0167 Carriage Screw 1/4-20 x .50
40. 712-0138 Hex Nut 1/4-28
41. 782-7575A Cable Mounting Bracket
42. 736-0329 Lock Washer 1/4
43. 756-0625 Roller Cable
44. 738-0924 Shoulder Screw .375 ID x 1/4-14
45. 714-0104 Cotter Pin
46. 736-0286 Bowed Washer
47. 782-0565 Single Lever Control Arm
48. 734-2010 Wheel 9 x 2
49. 712-0414 Top Lock Tab Weld Nut 1/4-20
50. 16855 Ratchet Pawl Plate
51. 10622B Plastic Spring Ratchet
52. 748-0381 Pawl RH
748-0188B Pawl LH
53. 738-0137A ShldScrew .340 ID x .285 OD
54. 748-0318 Wheel Rachet
55. 736-0270 Bell Washer .265 ID x .75 OD
56. 710-0751 Hex Cap Screw1/4-20x .620
57. 731-0982A Hubcap
58. 738-0102 ShoulderScrew .498 x 1.445
59. 736-0504 Wave Washer .510 ID x .750 OD
60. 734-2008A Wheel 8 x 2
61. 736-0105 Spring Washer .401 ID x.870 OD
62. 710-1348 Screw 1/4-14 x .500
63. 710-0896 Screw 1/4-14 x .625
64. 710-0654A Hex WasherScrew 3/8-16 x 1.0
65. 611-0064 Front Axle Assembly
66. 736-0204 Flat Washer .344 ID x .62 OD
67. 710-0703 Carriage Screw 1/4-20 x.75
68. 710-1242 Torx Screw
69. 741-0492A Block Bushing
70. 710-1241 Hex Washer Screw
71. 731-1829 Front Axle Cover
72. 754-0460 Belt 3/8 x 39.24
73. 656-0613 Pulley Assembly
74. 750-1071 Sleeve Spacer .88ID x 1.13 OD
75. 750-1070 Sleeve Spacer .88ID x 1.00 OD
76. 782-7597 Pivot Bracket
77. 710-0654A Screw 3/8-18 x 1.0
78. 782-7596 Control Arm
79. 732-0807 Torsion Spring
80. 711-1114 Pivot Shaft
81. 736-0526 Wave Washer 1.38 ID x .88 OD
82. 731-1828 Baffle
83. 710-0653 Screw 1/4-20 x 3.75
84. 753-0609 Blade Adapter Kit
85. 742-0741 21”Mulching Blade
86. 736-0524A Blade Bell Support
87. 710-1257 Hex Bolt3/8-24x 2.5
88. 731-1874 Chute Door
89. 732-0819 Torsion Spring
90. 726-0111 Push Cap
91. 747-0965 Pivot Rod
92. 731-1713B Discharge Chute
93. 720-0294 Grip
94. 682-3052 Handle Bracket Assembly - RH
682-3053 Handle Bracket Assembly - LH
Ref.
No. Part No. Part Description

20
Model 979
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
14
7
15
16
17
18
19
20
21
22
23
24 25
26
27 28
29
30
30 31
32
33
34
35 36
37 38
39 40
41
42
43
44
45
46
47 48
49
50
51
52
53
54
55
56
57
58
59
60
63
62
61
