Currys ESSENTIALS CUF48W13 User manual

INSTRUCTION MANUAL
UNDERCOUNTER FREEZER
CUF48W13
CUF48W13_IB_RC_151218_grace.indd 1 18/12/15 5:03 pm

CUF48W13_IB_RC_151218_grace.indd 2 18/12/15 5:03 pm

Contents
Safety Warnings............................................................................................................................................. 4
Unpacking...................................................................................................................................................... 6
Installation ..................................................................................................................................................... 7
Location............................................................................................................................................................................................ 7
Levelling the Unit.......................................................................................................................................................................... 7
Installing the Spacers .................................................................................................................................................................. 7
Free Space Requirements.......................................................................................................................................................... 7
Reversing the Door Swing......................................................................................................................................................... 8
Cleaning Before Use...................................................................................................................................................................11
Before Using Your Unit..............................................................................................................................................................11
Product Overview........................................................................................................................................ 12
Operation ..................................................................................................................................................... 13
Switching On Your Unit ............................................................................................................................................................13
Adjusting the Temperature .....................................................................................................................................................13
Fast Freezing.................................................................................................................................................................................13
Noises Inside the Unit! ..............................................................................................................................................................13
Preparations for Freezing.........................................................................................................................................................14
Defrosting Frozen Food............................................................................................................................................................14
Cleaning ....................................................................................................................................................... 15
Defrosting......................................................................................................................................................................................15
Cleaning the Interior and the Exterior of the Unit..........................................................................................................15
Maintenance ................................................................................................................................................ 16
Care When Handling / Moving the Unit .............................................................................................................................16
Servicing ........................................................................................................................................................................................16
Switching O for Long Periods of Time ..............................................................................................................................16
Condensation...............................................................................................................................................................................16
Disposal........................................................................................................................................................ 16
Specications............................................................................................................................................... 17
CUF48W13_IB_RC_151218_grace.indd 3 18/12/15 5:03 pm

4
Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
- farm houses and by clients in hotels, motels and other residential type
environment;
- bed and breakfast type environment;
- catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection from
the mains supply.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualied technician in order to avoid a hazard.
• Choose a location for your unit away from heat sources such as radiators
or res as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure that they do not play with the
unit.
• If your unit is tted with a lock to prevent children being trapped inside,
keep the key out of reach and not in the vicinity of the unit.
• Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
CUF48W13_IB_RC_151218_grace.indd 4 18/12/15 5:03 pm

5
• Do not store bottles or glass containers in the freezer compartment.
Contents can expand when frozen (zzy drinks) which may break the
bottle and damage your freezer compartment. (If applicable)
WARNING
• Keep ventilation openings in the unit enclosure or in the built-in
structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a very
environmental-friendly gas but is also combustible. Take care when
transporting or moving the unit to ensure that the refrigeration
circuit is not damaged. In the event of damage avoid naked ames
or ignition sources and ventilate the room in which the unit is
placed for a few minutes.)
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.
CUF48W13_IB_RC_151218_grace.indd 5 18/12/15 5:03 pm

6
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Main Unit Lower Freezer DrawerUpper Freezer Drawers x2
Rear Spacer x 2
Thank you for purchasing your new Currys Undercounter Freezer.
We recommend that you spend some time reading this instruction manual in order that you
fully understand all the operational features it offers. You will also find some hints and tips to
help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future
reference.
Instruction Manual
Instruction
Manual
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
CUF48W13_IB_RC_151218_grace.indd 6 18/12/15 5:03 pm

INSTALLATION
7
Installation
Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 32°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is suitable for use in a garage or
outbuilding. Do not drape the unit with any covering.
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
Installing the Spacers
Screw the spacers to the left and right side
of the unit’s rear part.
Free Space Requirements
When installing the unit, ensure that 25 mm
of free space is left at both sides, 50 mm at
the rear of the unit and 25 mm at the top
of the unit. The door can be opened to the
right or the left, depending on which best
suits the location. Please ensure there is
adequate space for the door to fully open to
160°.
Max. 160°
Y mm
X mm
screw
CUF48W13_IB_RC_151218_grace.indd 7 18/12/15 5:03 pm

INSTALLATION
8
1. Remove the top right hinge cover.
Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
• Ensure the unit is unplugged and empty.
• To take the door off it is necessary to tilt the unit backwards. You should rest the unit on
something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
• If you want to have the door swing reversed, we recommend that you contact a qualified
technician. You should only try to reverse the door yourself if you believe that you are
qualified to do so.
If the appliance is placed under a continuous worktop, the appliance lid (if applicable) may
be removed and a ventilation grille of at least 200 cm2(available from DIY shops or specialist
retailers) should be installed to the worktop above the rear of the appliance to increase
ventilation.
Benefits of increased ventilation:
• Loweredpowerconsumption  • Improvedcoolingperformance
• Reducerunningcosts  • Prolongproductlifespan
min. 200 cm2
CUF48W13_IB_RC_151218_grace.indd 8 18/12/15 5:03 pm

INSTALLATION
9
2. Undo the screws. Then remove the hinge
bracket.
3. Remove the top left screw cover.
unscrew
4. Move the core cover from left side to
right side. And then lift the door and
place it on a padded surface to prevent it
from scratching.
5. Remove the screws and bottom hinge.
Then remove the adjustable feet from
both side.
Unscrew
CUF48W13_IB_RC_151218_grace.indd 9 18/12/15 5:03 pm

INSTALLATION
10
6. Unscrew and remove the bottom hinge
pin, turn the bracket over and replace it.
Unscrew
Screw
7. Refit the bracket fitting the bottom hinge
pin. Replace both adjustable feet. Transfer
the door to the proper position.
Screw
8. Place the door back on. Ensure the door
is aligned horizontally and vertically
so that the seals are closed on all sides
before finally tightening the top hinge.
9. Insert the hinge bracket and screw it to
the top of the unit.
10. Use a spanner to tighten it if necessary.
