Currys C510WM14 User manual

INSTRUCTION MANUAL
5KG WASHING MACHINE
C510WM14 / C510WMS14
C510WM14_S14_IB.indd 1 10/02/2014 16:35

Contents
Unpacking.................................................................................................................................... 5
Installing Your Washing Machine ............................................................................................... 6
Choosing the Right Location for Your Washing Machine ........................................................................ 6
Removing the Transit Bolts......................................................................................................... 7
Hose and Cable Lengths...................................................................................................................................... 8
Water Supply Hose................................................................................................................................................. 9
Water Drain Hose.................................................................................................................................................... 9
Moving the Washing Machine from One Location to Another............................................................10
Connecting to the Mains Supply ....................................................................................................................10
Product Overview...................................................................................................................... 11
The unit ....................................................................................................................................................................11
Control Panel .........................................................................................................................................................12
Function Buttons ..................................................................................................................................................12
Child Lock................................................................................................................................................................12
Preparation ................................................................................................................................ 13
Preparing Laundry ...............................................................................................................................................13
Adding Detergent and Softener .....................................................................................................................13
Which Detergent to Use.....................................................................................................................................14
Selecting the Program........................................................................................................................................15
Wash Setting .............................................................................................................................. 16
Standard Washing ................................................................................................................................................16
Changing Programs.............................................................................................................................................16
Removing Washing (Once program is nished)........................................................................................16
Maintenance - Cleaning the Washing Machine....................................................................... 17
Maintenance Wash...............................................................................................................................................17
Cleaning the Drum...............................................................................................................................................17
Cleaning the Exterior of your Washing Machine.......................................................................................17
Cleaning the Detergent Drawer......................................................................................................................17
Cleaning the Drain Pump Filter.......................................................................................................................18
Cleaning the Filter Net of the Water Supply Hose ....................................................................................18
Cleaning the Door Seal and Window ............................................................................................................18
Troubleshooting ........................................................................................................................ 19
Specications............................................................................................................................. 20
Product Fiche ............................................................................................................................. 21
C510WM14_S14_IB.indd 2 10/02/2014 16:35

3
Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING!
• If you will not be using the washing machine for a while such as when you
go on holiday, turn off the water supply to the washing machine. This is
particularly important if there is no drainage around the washing machine.
If the water is left on, water pressure may build up and cause a leak.
General Use
• This washing machine is for household (domestic) use only.
• Do not install your washing machine anywhere that is damp or exposed to the
weather. If you do, it may cause an electric shock, fire, failure or deterioration.
• Keep flammable substances well away from the washing machine. They may
cause an explosion or a fire.
• Before you start using the washing machine, turn the tap on to check that the
hose is properly connected. If it’s not, there may be a water leak.
Power Source and Cable
• Make sure your home voltage matches the voltage displayed on the washing
machine. If you are not sure, contact an electrician.
• Use a dedicated earthed mains socket, rated at a minimum of 10 Amp
230V AC. If the washing machine is plugged in with other appliances, it may
overheat and cause a fire.
• Do not use a mains plug adaptor or extension cable. It may overheat and
cause a fire.
• Make sure the mains plug is pushed firmly into the socket. A loose connection
may overheat and cause electrical shock or a fire.
• The mains plug must remain accessible to allow disconnection or an all pole
switch must be incorporated in the fixed wiring in accordance with the wiring
rules.
• Check the mains lead and mains plug for any damage. If the mains cable
is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• Unplug the mains lead when cleaning the washing machine.
• Do not touch the mains lead or mains plug with wet hands. It may cause an
electric shock.
C510WM14_S14_IB.indd 3 10/02/2014 16:35

4
• Check the mains plug regularly for dirt. If dirt accumulates on the mains plug,
it could cause a fire. To prevent this, unplug the cable and clean the mains plug
with a dry rag.
• If you disconnect the mains plug, hold onto the mains plug not the cable.
Pulling the cable may damage it causing an electric shock or a fire.
To Prevent Injury / Damage
• When opening and closing the door ensure you keep fingers away from the
door hinge.
• Do not wash, rinse or spin water-proof sheets or clothing. These may cause
vibration or washing machine failure during spin-drying, which could lead to
injury, damage to the washing machine or damage due to water leaking.
• Be careful when draining hot water or any detergent from the washing
machine.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children without
supervision.
• Children should be supervised to ensure that they do not play with the
appliance.
• Do not put too much laundry or detergent into the washing machine. It may
cause issues with the washing machine or laundry.
• The appliance is to be connected to the water mains using the new hose-set
supplied. Old hose-sets should not be reused.
• The ventilation openings in the base of the washing machine must not be
obstructed by a carpet.
• Do not dismantle, repair or modify the washing machine. The washing
machine could malfunction and cause a fire or injury.
• Keep small parts found in the accessories bag away from children and babies.
• Make sure children and pets do not climb in the appliance.
C510WM14_S14_IB.indd 4 10/02/2014 16:35

5
The Main Unit
Cover Cap x 4
Liquid detergent guide x1
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Water Supply Hose x 1
200
150
100
• Water is poured into the washing machine to perform an inspection at the time of shipment
from the factory, so there may be drops of water or condensation in the washing machine. This is
not an indication of a malfunction.
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OR REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.
C510WM14_S14_IB.indd 5 10/02/2014 16:35

INSTALLATION
6
Additional space (50mm) is required for the rear of the washing machine. This is to allow
enough space for the water hose and drain hose.
Installing Your Washing Machine
Please read and follow the instructions carefully.
• In addition to the instructions mentioned here, special regulations may apply with regards to the
relevant water and power supply companies. If in doubt, have the washing machine connected by
a qualified technician.
• The washing machine is heavy - caution when lifting it. Do not lift by projecting components (e.g.
washing machine door).
• Warning: Frozen hoses may tear/burst. Do not install washing machine in outdoor areas or where
there is a risk of frost.
• Place hoses and cables in such a way that there is no risk of them becoming trapped or kinked.
Choosing the Right Location for Your Washing Machine
• Make sure there’s enough space for your washing machine.
• Install your washing machine on a flat, stable surface to avoid excessive vibration and noise.

Sloping
surface
Unstable Bumpy
surface
• When moving, start by tilting the washing machine backwards.
• One person should stand behind it, holding the rear of the top panel. The other person should grip
the bottom feet at the front.
• Check that you have all the required accessories for installation.
• If in doubt entrust the installation of the washing machine to a qualified technician or service
agent.
Two or more people are required to carry
the washing machine.
C510WM14_S14_IB.indd 6 10/02/2014 16:35

INSTALLATION
7
Removing the Transit Bolts
To remove the transit bolts:
1. Ensure the unit is fully disconnected from the mains power by unplugging it from the mains.
2. Unscrew the four (4) transit bolts.
3. They are located at the rear side of the washing machine. Use a spanner (not included) to loosen
the four (4) transit bolts, then pull out the bolts horizontally. Ensure the plastic bolt guides (if any)
are also removed.
4. Snap in the plastic caps to cover the transit bolt holes.
Keep the four (4) transit bolts in a safe place,
in case you need to move the washing machine.
Do not run the washing machine without removing the bolts, as this can cause excessive vibrations.
Four (4) transit bolts keep the interior of the washing machine in place while it is being moved.
They must be removed before installation. Use a 10mm spanner (not included) and follow the
instructions.
1
2
3
4
C510WM14_S14_IB.indd 7 10/02/2014 16:35

INSTALLATION
8
1
2
4
5
6
7
8
9
10
11
12
60˚C
40˚C
60˚C
40˚C
COTTON
1.
2.
3.
4.
5.
6.
7.
90°C
60° pre
40° eco
Quickwash
20° eco
90°C
60°
- cold
30°C
8.
9.
10.
11. 30°C
12.
Rinse
Spin
Drain
SYNTHETICS DELICATE
Program C510WM14
A+
WOOL
Hose and Cable Lengths
How to connect from the left side
~95cm
~145cm
~95cm
~140cm
~95cm
~150cm
min. 60cm
max. 100cm
How to connect from the right side
Levelling the Washing Machine
There are 4 levelling feet on the underside. They must be adjusted to make sure the washing machine
is level.
1. On each foot, loosen the lock ring by turning it clockwise.
2. Adjust all four feet by rotating each upwards or downwards.
3. Use a spirit level to ensure the washing machine is level.
4. Tighten each lock ring by turning them anti-clockwise (towards the washing machine body).
Ensure all four lock rings are tightened securely. Check the feet are still bolted to
the washing machine - if they’re unbolted, the washing machine will move around.
Foot
Locking Ring
C510WM14_S14_IB.indd 8 10/02/2014 16:35

INSTALLATION
9
Water Supply Hose
Points to remember
• Follow the instructions in this section to avoid water leaks.
• Don’t connect the hose to a combination tap.
• Don’t twist, squash, modify or cut the hose.
• Optimum water pressure in the main pipe is 0.1 MPa - 1.0 MPa. If the water pressure is set higher
than this, you will need to install a depressurising valve. Ensure the water flow amount and speed
from the tap is sufficient. If you’re unsure, ask a qualified technician to connect the hose.
• This unit must only be connected to cold water mains using the new water inlet hose provided.
• If your washing machine is delivered in freezing weather conditions, leave it at room temperature
for 24 hours after you’ve set it up before using it. This ensures there’s no ice blocking the appliance.
Connecting the Water Supply Hose
1. Connect the 90° end of the hose to the back of your
machine, it only needs to be hand tight. Check the
black washer is in place.
2. Connect the straight end of the hose to the
connector on the cold water supply, it only needs to
be hand tight. Check that the filter and black washer
are in place.
3. Open the tap slowly and check that there are no
leaks around the joint.
3/4”
min. 10 mm
3/4”
min. 10 mm
Plastic joint
• The joint is subject to water pressure.
• Use the hose set supplied with the appliance. Old hose sets should not be reused.
Water Drain Hose
Points to remember:
• Don’t twist, pull out or bend the drain hose.
• Your washing machine should be no more than 95cm from the drain outlet
(see the hose and cable lengths diagram).
Draining to a sink or wash-basin
• Secure the drain hose in position, so it can’t drop out of the basin.
• Don’t block the basin’s drain outlet, and make sure that the drainage
through it is sufficient.
• Don’t let the tip of the drain hose dip into the drained water, as this can
cause the water to flow back into the washing machine.
• Don’t extend the length of the drain hose.
The drain hose should not be submerged in water and should be
securely fixed and leak-free. If the drain hose is placed on the ground
or if the pipe is at a height of less than 60cm, the washing machine
will continuously drain while being filled (self-siphoning).
U-Shape Holder
(not supplied)
Draining to a wash-basin
Draining to a drain hose
C510WM14_S14_IB.indd 9 10/02/2014 16:35

INSTALLATION
10
Connecting to the Mains Supply
For your safety:
• Do not use a mains plug adapter or extension cable.
• If the mains cable or mains plug are damaged, stop using them and call a qualified technician for
assistance.
• The mains cord of your washing machine is equipped with an Earthed plug. This plug must always
be inserted to an earthed socket capable of supplying 13 Amps. If you don’t have such a socket and
fuses in your house, please call a qualified electrician.
Moving the Washing Machine from One Location to Another
Ensure the transit bolts are fixed in place prior to moving the washing machine.
Before you move the washing machine:
• Shut off the tap and run the washing machine to drain the water. Drain any remaining water from
the pump hose.
• Disconnect the unit from the mains.
• Depressurise the water supply hose and remove it.
• Replace the transit bolts (in the reverse order in which you removed them (please see the Moving
and Installing section for details).
C510WM14_S14_IB.indd 10 10/02/2014 16:35
