D-Link DSL-G604T User manual

DSL-G604T
Wireless ADSL Router
User’s Guide
(May 2005)
DSLG604TEUA1

DSL-G604T Wireless ADSL Router Manual
FCC Warning
This equipment has been tested and found to comply ith the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
hen the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance ith this user’s guide, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in hich case the user ill be required to correct the interference at his o n expense.
CE Mar Warning
This is a Class A product. In a domestic environment, this product may cause radio interference in hich case
the user may be required to take adequate measures.
Warnung!
Dies ist ein Produkt der Klasse A. Im Wohnbereich kann dieses Produkt Funkstoerungen verursachen. In diesem
Fall kann vom Benutzer verlangt erden, angemessene Massnahmen zu ergreifen.
Precaución!
Este es un producto de Clase A. En un entorno doméstico, puede causar interferencias de radio, en cuyo case,
puede requerirse al usuario para que adopte las medidas adecuadas.
Attention!
Ceci est un produit de classe A. Dans un environnement domestique, ce produit pourrait causer des interférences
radio, auquel cas l`utilisateur devrait prendre les mesures adéquates.
Attenzione!
Il presente prodotto appartiene alla classe A. Se utilizzato in ambiente domestico il prodotto
può causare interferenze radio, nel cui caso è possibile che l`utente debba assumere
provvedimenti adeguati.
ii

DSL-G604T Wireless ADSL Router Manual
Warranty and Registration for all Countries and
Regions Ex ept USA
Wichtige Sicherheitshinweise
1. Bitte lesen Sie sich diese Hinweise sorgfältig durch.
2. Heben Sie diese Anleitung für den spätern Gebrauch auf.
3. Vor edem Reinigen ist das Gerät vom Stromnetz zu trennen. Vervenden Sie keine Flüssig- oder Aerosolreiniger. Am besten
dient ein angefeuchtetes Tuch zur Reinigung.
4. Um eine Beschädigung des Gerätes zu vermeiden sollten Sie nur Zubehörteile verwenden, die vom Hersteller zugelassen sind.
5. Das Gerät is vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sichern Stand zu achten. Ein Kippen oder Fallen könnte Verletzungen hervorrufen.
Verwenden Sie nur sichere Standorte und beachten Sie die Aufstellhinweise des Herstellers.
7. Die Belüftungsöffnungen dienen zur Luftzirkulation die das Gerät vor Überhitzung schützt. Sorgen Sie dafür, daß diese
Öffnungen nicht abgedeckt werden.
8. Beachten Sie beim Anschluß an das Stromnetz die Anschlußwerte.
9. Die Netzanschlußsteckdose muß aus Gründen der elektrischen Sicherheit einen Schutzleiterkontakt haben.
10. Verlegen Sie die Netzanschlußleitung so, daß niemand darüber fallen kann. Es sollete auch nichts auf der Leitung abgestellt
werden.
11. Alle Hinweise und Warnungen die sich am Geräten befinden sind zu beachten.
12. Wird das Gerät über einen längeren Zeitraum nicht benutzt, sollten Sie es vom Stromnetz trennen. Somit wird im Falle einer
Überspannung eine Beschädigung vermieden.
13. Durch die Lüftungsöffnungen dürfen niemals Gegenstände oder Flüssigkeiten in das Gerät gelangen. Dies könnte einen
Brand bzw. Elektrischen Schlag auslösen.
14. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit nur von authorisiertem
Servicepersonal geöffnet werden.
15. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer qualifizierten Servicestelle zu
überprüfen:
a. Netzkabel oder Netzstecker sint beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung ensprechend funktioniert oder Sie mit Hilfe dieser Anleitung
keine Verbesserung erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
16. Bei Reparaturen dürfen nur Orginalersatzteile bzw. den Orginalteilen entsprechende Teile verwendet werden. Der Einsatz von
ungeeigneten Ersatzteilen kann eine weitere Beschädigung hervorrufen.
17. Wenden Sie sich mit allen Fragen die Service und Repartur betreffen an Ihren Servicepartner. Somit stellen Sie die
Betriebssicherheit des Gerätes sicher.
18. Zum Netzanschluß dieses Gerätes ist eine geprüfte Leitung zu verwenden, Für einen Nennstrom bis 6A und einem
Gerätegewicht grőßer 3kg ist eine Leitung nicht leichter als H05VV-F, 3G, 0.75mm2 einzusetzen.
WARRANTIES EXCLUSIVE
IF THE D-LINK PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE REMEDY SHALL BE, AT D-
LINK'S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN
LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR
OTHERWISE, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. D-LINK NEITHER
ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE
SALE, INSTALLATION MAINTENANCE OR USE OF D-LINK'S PRODUCTS.
D-LINK SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED
DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY THE CUSTOMER'S OR ANY THIRD PERSON'S MISUSE,
NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR, OR ANY OTHER CAUSE BEYOND
THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING OR OTHER HAZARD.
LIMITATION OF LIABILITY
IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOSS OF PROFITS, COST OF COVER
OR OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING OUT THE INSTALLATION, MAINTENANCE, USE,
PERFORMANCE, FAILURE OR INTERRUPTION OF A D- LINK PRODUCT, HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY. THIS LIMITATION WILL APPLY EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
IF YOU PURCHASED A D-LINK PRODUCT IN THE UNITED STATES, SOME STATES DO NOT ALLOW THE LIMITATION OR
EXCLUSION OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION MAY NOT APPLY TO
YOU.
Limited Warranty
Hardware:
D-Link warrants each of its hardware products to be free from defects in workmanship and materials under normal use and service
for a period commencing on the date of purchase from D-Link or its Authorized Reseller and extending for the length of time
stipulated by the Authorized Reseller or D-Link Branch Office nearest to the place of purchase.
iii

DSL-G604T Wireless ADSL Router Manual
This Warranty applies on the condition that the product Registration Card is filled out and returned to a D-Link office within ninety
(90) days of purchase. A list of D-Link offices is provided at the back of this manual, together with a copy of the Registration Card.
If the product proves defective within the applicable warranty period, D-Link will provide repair or replacement of the product.
D-Link shall have the sole discretion whether to repair or replace, and replacement product may be new or reconditioned.
Replacement product shall be of equivalent or better specifications, relative to the defective product, but need not be identical. Any
product or part repaired by D-Link pursuant to this warranty shall have a warranty period of not less than 90 days, from date of
such repair, irrespective of any earlier expiration of original warranty period. When D-Link provides replacement, then the defective
product becomes the property of D-Link.
Warranty service may be obtained by contacting a D-Link office within the applicable warranty period, and requesting a Return
Material Authorization (RMA) number. If a Registration Card for the product in question has not been returned to D-Link, then a
proof of purchase (such as a copy of the dated purchase invoice) must be provided. If Purchaser's circumstances require special
handling of warranty correction, then at the time of requesting RMA number, Purchaser may also propose special procedure as may
be suitable to the case.
After an RMA number is issued, the defective product must be packaged securely in the original or other suitable shipping package
to ensure that it will not be damaged in transit, and the RMA number must be prominently marked on the outside of the package.
The package must be mailed or otherwise shipped to D-Link with all costs of mailing/shipping/insurance prepaid. D-Link shall
never be responsible for any software, firmware, information, or memory data of Purchaser contained in, stored on, or integrated
with any product returned to D-Link pursuant to this warranty.
Any package returned to D-Link without an RMA number will be re ected and shipped back to Purchaser at Purchaser's expense,
and D-Link reserves the right in such a case to levy a reasonable handling charge in addition mailing or shipping costs.
Software:
Warranty service for software products may be obtained by contacting a D-Link office within the applicable warranty period. A list
of D-Link offices is provided at the back of this manual, together with a copy of the Registration Card. If a Registration Card for the
product in question has not been returned to a D-Link office, then a proof of purchase (such as a copy of the dated purchase
invoice) must be provided when requesting warranty service. The term "purchase" in this software warranty refers to the purchase
transaction and resulting license to use such software.
D-Link warrants that its software products will perform in substantial conformance with the applicable product documentation
provided by D-Link with such software product, for a period of ninety (90) days from the date of purchase from D-Link or its
Authorized Reseller. D-Link warrants the magnetic media, on which D-Link provides its software product, against failure during
the same warranty period. This warranty applies to purchased software, and to replacement software provided by D-Link pursuant
to this warranty, but shall not apply to any update or replacement which may be provided for download via the Internet, or to any
update which may otherwise be provided free of charge.
D-Link's sole obligation under this soft are arranty shall be to replace any defective soft are product ith product hich substantially conforms to D-Link's
applicable product documentation. Purchaser assumes responsibility for the selection of appropriate application and system/platform soft are and associated
reference materials. D-Link makes no arranty that its soft are products ill ork in combination ith any hard are, or any application or system/platform
soft are product provided by any third party, excepting only such products as are expressly represented, in D-Link's applicable product documentation as being
compatible. D-Link's obligation under this arranty shall be a reasonable effort to provide compatibility, but D-Link shall have no obligation to provide
compatibility hen there is fault in the third-party hard are or soft are. D-Link makes no arranty that operation of its soft are products ill be uninterrupted
or absolutely error-free, and no arranty that all defects in the soft are product, ithin or ithout the scope of D-Link's applicable product documentation, ill
be corrected.
Warranty and Registration Information for USA Only
Sub ect to the terms and conditions set forth herein, D-Link Systems, Inc. (“D-Link”) provides this Limited warranty for its product
only to the person or entity that originally purchased the product from:
D-Link or its authorized reseller or distributor and
Products purchased and delivered within the fifty states of the United States, the District of Columbia, U.S. Possessions
or Protectorates, and U.S. Military Installations, addresses with an APO or FPO.
Limited Warranty: D-Link warrants that the hardware portion of the D-Link products described below will be free from material
defects in workmanship and materials from the date of original retail purchase of the product, for the period set forth below
applicable to the product type (“Warranty Period”), except as otherwise stated herein.
5-Year Limited Warranty for the Product(s) is defined as follows:
Hardware (excluding power supplies and fans) Five (5) Years
Power Supplies and Fans Three (3) Year
Spare parts and spare kits Ninety (90) days
D-Link’s sole obligation shall be to repair or replace the defective Hardware during the Warranty Period at no charge to the original
owner or to refund at D-Link’s sole discretion. Such repair or replacement will be rendered by D-Link at an Authorized D-Link
Service Office. The replacement Hardware need not be new or have an identical make, model or part. D-Link may in its sole
discretion replace the defective Hardware (or any part thereof) with any reconditioned product that D-Link reasonably determines is
substantially equivalent (or superior) in all material respects to the defective Hardware. Repaired or replacement Hardware will be
warranted for the remainder of the original Warranty Period from the date of original retail purchase. If a material defect is
incapable of correction, or if D-Link determines in its sole discretion that it is not practical to repair or replace the defective
Hardware, the price paid by the original purchaser for the defective Hardware will be refunded by D-Link upon return to D-Link of
the defective Hardware. All Hardware (or part thereof) that is replaced by D-Link, or for which the purchase price is refunded, shall
become the property of D-Link upon replacement or refund.
Limited Software Warranty: D-Link warrants that the software portion of the product (“Software”) will substantially conform to
D-Link’s then current functional specifications for the Software, as set forth in the applicable documentation, from the date of
original retail purchase of the Software for a period of ninety (90) days (“Warranty Period”), provided that the Software is properly
iv

DSL-G604T Wireless ADSL Router Manual
installed on approved hardware and operated as contemplated in its documentation. D-Link further warrants that, during the
Warranty Period, the magnetic media on which D-Link delivers the Software will be free of physical defects. D-Link’s sole obligation
shall be to replace the non-conforming Software (or defective media) with software that substantially conforms to D-Link’s
functional specifications for the Software or to refund at D-Link’s sole discretion. Except as otherwise agreed by D-Link in writing,
the replacement Software is provided only to the original licensee, and is sub ect to the terms and conditions of the license granted
by D-Link for the Software. Software will be warranted for the remainder of the original Warranty Period from the date or original
retail purchase. If a material non-conformance is incapable of correction, or if D-Link determines in its sole discretion that it is not
practical to replace the non-conforming Software, the price paid by the original licensee for the non-conforming Software will be
refunded by D-Link; provided that the non-conforming Software (and all copies thereof) is first returned to D-Link. The license
granted respecting any Software for which a refund is given automatically terminates.
Non-Applicability of Warranty: The Limited Warranty provided hereunder for hardware and software of D-Link's products, will
not be applied to and does not cover any product purchased through the inventory clearance or liquidation sale or other sales in
which D-Link, the sellers, or the liquidators expressly disclaim their warranty obligation pertaining to the product and in that case,
the product is being sold "As-Is" without any warranty whatsoever including, without limitation, the Limited Warranty as described
herein, notwithstanding anything stated herein to the contrary.
Submitting A Claim: Any claim under this limited warranty must be submitted in writing before the end of the Warranty Period to
an Authorized D-Link Service Office.
The customer must submit as part of the claim a written description of the Hardware defect or Software nonconformance
in sufficient detail to allow D-Link to confirm the same.
The original product owner must obtain a Return Material Authorization (“RMA”) number from the Authorized D-Link
Service Office and, if requested, provide written proof of purchase of the product (such as a copy of the dated purchase
invoice for the product) before the warranty service is provided.
After an RMA number is issued, the defective product must be packaged securely in the original or other suitable
shipping package to ensure that it will not be damaged in transit, and the RMA number must be prominently marked on
the outside of the package. Do not include any manuals or accessories in the shipping package. D-Link will only replace
the defective portion of the Product and will not ship back any accessories.
The customer is responsible for all shipping charges to D-Link. No Charge on Delivery (“COD”) is allowed. Products sent
COD will either be re ected by D-Link or become the property of D-Link. Products should be fully insured by the
customer and shipped to D-Link Systems, Inc., 53 Discovery Drive, Irvine, CA 92618. D-Link will not be held responsible
for any packages that are lost in transit to D-Link. The repaired or replaced packages will be shipped via UPS Ground or
any common carrier selected by D-Link, with shipping charges prepaid. Expedited shipping is available if shipping
charges are prepaid by the customer.
D-Link may re ect or return any product that is not packaged and shipped in strict compliance with the foregoing requirements, or
for which an RMA number is not visible from the outside of the package. The product owner agrees to pay D-Link’s reasonable
handling and return shipping charges for any product that is not packaged and shipped in accordance with the foregoing
requirements, or that is determined by D-Link not to be defective or non-conforming.
What Is Not Covered: This limited warranty provided by D-Link does not cover: Products, if in D-Link’s udgment, have been
sub ected to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty installation, lack of reasonable care,
repair or service in any way that is not contemplated in the documentation for the product, or if the model or serial number has
been altered, tampered with, defaced or removed; Initial installation, installation and removal of the product for repair, and
shipping costs; Operational ad ustments covered in the operating manual for the product, and normal maintenance; Damage that
occurs in shipment, due to act of God, failures due to power surge, and cosmetic damage; Any hardware, software, firmware or
other products or services provided by anyone other than D-Link; Products that have been purchased from inventory clearance or
liquidation sales or other sales in which D-Link, the sellers, or the liquidators expressly disclaim their warranty obligation
pertaining to the product. Repair by anyone other than D-Link or an Authorized D-Link Service Office will void this Warranty.
isclaimer of Other Warranties: EXCEPT FOR THE LIMITED WARRANTY SPECIFIED HEREIN, THE PRODUCT IS PROVIDED
“AS-IS” WITHOUT ANY WARRANTY OF ANY KIND WHATSOEVER INCLUDING, WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT. IF ANY IMPLIED WARRANTY CANNOT
BE DISCLAIMED IN ANY TERRITORY WHERE A PRODUCT IS SOLD, THE DURATION OF SUCH IMPLIED WARRANTY SHALL BE
LIMITED TO NINETY (90) DAYS. EXCEPT AS EXPRESSLY COVERED UNDER THE LIMITED WARRANTY PROVIDED HEREIN, THE
ENTIRE RISK AS TO THE QUALITY, SELECTION AND PERFORMANCE OF THE PRODUCT IS WITH THE PURCHASER OF THE
PRODUCT.
Limitation of Liability: TO THE MAXIMUM EXTENT PERMITTED BY LAW, D-LINK IS NOT LIABLE UNDER ANY CONTRACT,
NEGLIGENCE, STRICT LIABILITY OR OTHER LEGAL OR EQUITABLE THEORY FOR ANY LOSS OF USE OF THE PRODUCT,
INCONVENIENCE OR DAMAGES OF ANY CHARACTER, WHETHER DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
(INCLUDING, BUT NOT LIMITED TO, DAMAGES FOR LOSS OF GOODWILL, LOSS OF REVENUE OR PROFIT, WORK STOPPAGE,
COMPUTER FAILURE OR MALFUNCTION, FAILURE OF OTHER EQUIPMENT OR COMPUTER PROGRAMS TO WHICH D-LINK’S
PRODUCT IS CONNECTED WITH, LOSS OF INFORMATION OR DATA CONTAINED IN, STORED ON, OR INTEGRATED WITH ANY
PRODUCT RETURNED TO D-LINK FOR WARRANTY SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO
WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS
REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NON-CONFORMING PRODUCT. THE MAXIMUM LIABILITY OF D-
LINK UNDER THIS WARRANTY IS LIMITED TO THE PURCHASE PRICE OF THE PRODUCT COVERED BY THE WARRANTY. THE
FOREGOING EXPRESS WRITTEN WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ANY OTHER
WARRANTIES OR REMEDIES, EXPRESS, IMPLIED OR STATUTORY.
Governing Law: This Limited Warranty shall be governed by the laws of the state of California. Some states do not allow exclusion
or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the foregoing
limitations and exclusions may not apply. This limited warranty provides specific legal rights and the product owner may also have
other rights which vary from state to state.
Notice of IEEE802.11a 5Ghz radio usage in the European Community
At the time of riting this addendum, some countries such as Italy, Greece, Portugal and Spain hasn’t allo ed operation of radio
devices in the 5Ghz bands, although operation of 2.4Ghz radio devices are allo ed. Please check ith your local authority to
confirm.
This device is restricted to indoor use hen operated in the European Community using channels in the 5.15-5.35 GHz band to
reduce the potential for interference.
Usage Notes:
To remain in conformance ith European National spectrum usage regulations, frequency and channel limitations ill be applied on
the products according to the country here the equipment ill be deployed.
This device is restricted from functioning in Ad-hoc mode while operating in 5Ghz. Ad-hoc mode is direct peer-to-peer
communication bet een t o client devices ithout an Access Point.
v

DSL-G604T Wireless ADSL Router Manual
Access points ill support DFS (Dynamic Frequency Selection) and TPC (Transmit Po er Control) functionality as required hen
operating in 5Ghz ithin the EU.
Allowable 02.11a Frequencies and Channels Countries
5.15-5.25 GHz
(Channels 36, 40, 44, 48)
Liechtenstein, Hungary, S itzerland
5.15-5.25 Ghz & 5.725-5.875 Ghz
(Channels 36, 40, 44, 48, 149, 153, 157, 161, 165, 169)
Austria
5.15-5.35 GHz
(Channels 36, 40, 44, 48, 52, 56, 60, 64)
France, Slovak
5.15-5.35 & 5.47-5.725 GHz
(Channels 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124,
128, 132, 136, 140)
Denmark, Germany, Iceland, Finland, Netherlands, Nor ay, Poland,
S eden, Slovenia, Luxembourg, U.K., Ireland
5.15-5.35 Ghz & 5.725-5.875 Ghz
(Channels 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165, 169)
Czech Republic
IEEE 02.11b 2.4Ghz operation Countries
2.4-2.4835 Ghz Rest of EU Community
2.4465-2.4835 Ghz
(Channels 10,11,12,13)
France
European Community Declaration of Conformity:
English Hereby, D-Link Corporation declares that this Wireless LAN device is in compliance ith the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Finnish Valmistaja D-Link Corporation vakuuttaa täten että Wireless LAN device tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten
ja sitä koskevien direktiivin muiden ehtojen mukainen.
Dutch Hierbij verklaart D-Link Corporation dat het toestel Wireless LAN device in overeenstemming is met de essentiële eisen en de andere
relevante bepalingen van richtlijn 1999/5/EG
Bij deze verklaart D-Link Corporation dat deze Wireless LAN device voldoet aan de essentiële eisen en aan de overige relevante
bepalingen van Richtlijn 1999/5/EC.
French Par la présente D-Link Corporation déclare que l'appareil Wireless LAN device est conforme aux exigences essentielles et aux autres
dispositions pertinentes de la directive 1999/5/CE
Par la présente, D-Link Corporation déclare que ce Wireless LAN device est conforme aux exigences essentielles et aux autres dispositions
de la directive 1999/5/CE qui lui sont applicables
S edish Härmed intygar D-Link Corporation att denna Wireless LAN device står I överensstämmelse med de väsentliga egenskapskrav och övriga
relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Danish Undertegnede D-Link Corporation erklærer herved, at følgende udstyr Wireless LAN device overholder de væsentlige krav og øvrige
relevante krav i direktiv 1999/5/EF
German Hiermit erklärt D-Link Corporation dass sich dieser/diese/dieses Wireless LAN device in Übereinstimmung mit den grundlegenden
Anforderungen und den anderen relevanten Vorschriften der Richtlinie 1999/5/EG befindet". (BMWi)
Hiermit erklärt D-Link Corporation die Übereinstimmung des Gerätes Wireless LAN device mit den grundlegenden Anforderungen und
den anderen relevanten Festlegungen der Richtlinie 1999/5/EG. (Wien)
Greek ΜΕ ΤΗΝ ΠΑΡΟΥ ΑD-Link Corporation ΔΗΛΩΝΕΙ ΟΤΙ Wireless LAN device ΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟ ΤΙ ΟΥ ΙΩΔΕΙ
ΑΠΑΙΤΗ ΕΙ ΚΑΙ ΤΙ ΛΟΙΠΕ ΧΕΤΙΚΕ ΔΙΑΤΑΞΕΙ ΤΗ ΟΔΗΓΙΑ 1999/5/ΕΚ
Italian Con la presente D-Link Corporation dichiara che questo Wireless LAN device è conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
Spanish Por medio de la presente D-Link Corporation declara que el Wireless LAN device cumple con los requisitos esenciales y cualesquiera otras
disposiciones aplicables o exigibles de la Directiva 1999/5/CE
Portuguese D-Link Corporation declara que este Wireless LAN device está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
AVERTISSEMENT AUX UTILISATEURS
L’utilisation des bandes de fréquences des 2.4GHz et 5GHz pour les RLAN est réglementée par l’ART (Autorité de Régulation des
Télécoms).
BANDE DE FREQUENCES DES 2.4GHZ
vi

DSL-G604T Wireless ADSL Router Manual
La décision N° 02-100 en date du 31 octobre 2002 autorise l’utilisation d’une partie de la bande de fréquences 2400-24 3,5 MHz pour
les réseaux locaux radioéléctriques (RLAN) comme suit :
L’utilisation de la bande 2400-2446,5 MHz est autorisée à l’intérieur des bâtiments avec une puissance isotrope rayonnée équivalente (PIRE)
limitée à 10 mW et que l’utilisation de la bande 2446,5-2483,5 MHz est autorisée à l’intérieur des bâtiments avec une PIRE limitée à 100 mW.
L’utilisation en extérieur est soumise à demande d’autorisation sur la bande de fréquences de 2446,5-2483,5 MHz avec une puissance limitée à
100mW.
Dans certains départements, dont la liste est publiée par l'Autorité de régulation des télécommunications, l'utilisation de la totalité de la bande
2400- 2483,5 MHz est autorisée à l'intérieur des bâtiments avec une puissance isotrope rayonnée équivalente maximale de 100 mW.
Dans ces mêmes départements, l'utilisation de la bande 2400-2454 MHz est autorisée à l'extérieur des bâtiments avec une puissance isotrope
rayonnée équivalente maximale de 100 mW et l'utilisation de la bande 2454-2483,5 MHz est autorisée à l'extérieur des bâtiments avec une
puissance isotrope rayonnée équivalente maximale de 10 mW.
L’Autorité poursuit les négociations avec le ministère de la Défense en vue de l’ouverture de la totalité de la bande 2400-2483,5 MHz en
intérieur et en extérieur avec une PIRE de 100 mW. Cette ouverture est acquise d'ores et déjà dans certains départements d'Outre-mer.
En installant et utilisant les produits réseaux sans fils de la gamme proposée par D-Link, vous vous engagez donc à respecter cette
réglementation.
Pour tour information complémentaire et les dernières informations concernant l’évolution de la réglementation française, nous
vous conseillons de consulter le site de l’ART : www.art-telecom.fr.
BANDE DE FREQUENCES DES 5GHZ
L’Autorité de Régulation des Télécommunications (ART) autorise l’utilisation d’une partie de la bande de fréquences des 5GHz pour les
réseaux locaux radioélectriques (RLAN) intégrant des solutions 802.11a supportant les fonctions DFS (Dynamic Frequency Selection) et
TPC (Transmit Po er Control).
Seule la bande 5150-5350MHz est autorisée en France pour une utilisation intérieure avec une puissance limitée à 200 mW en mode
infrastructure.
En installant et en utilisant les produits réseaux sans fil 802.11a de la gamme D-Link commercialisée en France, vous vous engagez à
respecter cette réglementation.
Pour tour information complémentaire et les dernières informations concernant l’évolution de la réglementation française, nous
vous conseillons de consulter le site de l’ART : www.art-telecom.fr.
AVVERTIMENTI PER GLI UTILIZZATORI
L’utilizzo della banda di frequenza dei 2.4 GHz per applicazioni di tipo Radio LAN sul mercato Italiano, è
regolamentato dal Ministero delle Comunicazioni secondo il Nuovo Piano Nazionale Gestioni Frequenze relativo al
D.M. dell’8 Luglio 2002 e dalle relative modifiche come dal Decreto del Ministero delle Comunicazioni del 20
Febbraio 2003 (nota 158).
Viene definito come Radio Local Area Network (di seguito denominate “Radio LAN” o “R-LAN”) un sistema di
comunicazioni in rete locale mediante radiofrequenze che utilizza apparati a corto raggio secondo le caratteristiche
di armonizzazione e tecniche previste dal vigente Piano nazionale di ripartizione delle frequenze, nelle seguenti
bande di frequenza: 2.400,0 – 2.483,5 MHz (brevemente banda a 2.4 GHz).
I sistemi Radio LAN sono regolati da apposite normative. Principalmente valgono le normative F.C.C. per gli U.S.A.,
il Canada, e gli altri paesi aderenti alle F.C.C., come gli ex paesi U.R.S.S.; mentre le norme E.T.S. 300T-328-2 e
correlate, emanate dall'organo Europeo E.T.S.I., valgono per i paesi dell'Unione Europea, Giappone e per i paesi
aderenti a queste normative.
La normativa tecnica ETS 300T-328-2 impone di non irradiare con una potenza E.I.R.P. superiore ai 100 mW
(equivalente a 20 dBm).
In linea di principio inoltre impone agli apparati Radio LAN, di non trasmettere con una potenza elettrica effettiva
superiore ai 50 mW (equivalente a 17 dBm); questo perché l'antenna a dipolo più semplice, che di solito li
accompagna, ha generalmente un guadagno in trasmissione pari a circa 2.5 dBi, che fa si che la potenza E.I.R.P.
trasmessa salga a circa 80 mW (per la precisione 19.2 dBm).
Per questo motivo su tutto il territorio dell'Unione Europea, ed anche in Italia, è assolutamente vietato utilizzare
antenne che abbiano un guadagno in trasmissione elevato (in linea di massima diciamo superiore ai 5 dBi), tale da
portare la potenza trasmessa E.I.R.P. oltre i 100 mW (equivalente a 20 dBm).
Nel caso in cui invece sia possibile regolare il livello di potenza trasmessa dagli Access Point, viene data la
possibilità di utilizzare antenne ad alto guadagno attenendosi strettamente ad una serie di istruzioni di seguito
riportate che consentono questo utilizzo rimanendo comunque all’interno della potenza massima trasmessa E.I.R.P.
pari e non superiore a 100mW (20dBm).
CALCOLO DELLA POTENZA E.I.R.P. IN EMISSIONE
La formula di calcolo per ottenere l’E.I.R.P. effettivo è la seguente:
E.I.R.P. (dBm) = Ptx (dBm) + Gtx (dBi) dove
Ptx = Potenza trasmessa al connettore dell’antenna di trasmissione
Gtx = Guadagno dell’antenna di trasmissione
vii

DSL-G604T Wireless ADSL Router Manual
Il valore ottenuto dalla somma, NON deve superare quanto espresso dalla normativa ovvero 20dBm. Nel caso in cui
si voglia convertire il risultato ottenuto in mW, utilizzare la semplice tabella di conversione di seguito riportata.
INSTALLAZIONE ED UTILIZZO DI SITEMI RADIO LAN AD USO PRIVATO
Come riportato nel D.P.R. n° 447/01 Art. 6 – Punto B (Libero uso) del 5 Ottobre 2001:
“Sono di libero uso le apparecchiature che impiegano frequenze di tipo collettivo, senza alcuna protezione, per
collegamenti a brevissima distanza con apparati a corto raggio, compresi quelli rispondenti alla raccomandazione
CEPT-ERC/REC 70-03, tra le quali rientrano in particolare:
b) Reti locali di tipo radiolan e hiperlan nell’ambito del fondo, ai sensi dell’articolo 183, comma secondo, del
decreto del Presidente della Repubblica n. 156 del 1973; sono disciplinate ai sensi dell’articolo 5 le reti
hiperlan operanti obbligatoriamente in ambienti chiusi o con vincoli specifici
…
Per “fondo” pubblico o privato, si intende un ambiente sia interno che esterno ben circoscritto e delimitato.
Per “fondo privato” possiamo, per esempio, fare riferimento a uffici, capannoni industriali, abitazioni, aree all’aperto
private che non attraversano il suolo pubblico o il passaggio di pubblico dominio/demanio.
Per “fondo pubblico” possiamo, per esempio, fare riferimento a tutti quei luoghi appartenenti allo Stato o alle
amministrazioni centrali e locali quali strade, autostrade, strade ferrate, spiagge, porti, fiumi etc.
E’ comunque necessario fare 2 specifiche distinzioni:
Utilizzo di sistemi Radio LAN ad uso rivato con installazioni indoor o outdoor su fondo/suolo rivato:
E’ possibile utilizzare liberamente sistemi Radio LAN purché vengano rispettate le normative vigenti soprattutto per
quanto riguarda l’emissione massima in potenza come sopra riportato.
Utilizzo di sistemi Radio LAN ad uso rivato con installazioni outdoor con attraversamento di fondo/suolo
ubblico:
Come specificato nel D.P.R. n° 447/01 Art. 5 – Punto 2.2 del 5 Ottobre 2001, è necessario richiedere
un’autorizzazione generale al “Ministero delle Comunicazioni Direzione generale per le concessioni e le
autorizzazioni” per l’installazione di sistemi Radio LAN ad uso privato con installazioni outdoor con attraversamento
di suolo pubblico.
Per richiedere l’autorizzazione generale, fare riferimento all’allegato C presente all’interno del D.P.R. n° 447/01 in
qualità di canovaccio per la stesura della richiesta.
Per ulteriori informazioni e delucidazioni, fare riferimento al D.P.R. n° 447/01 del 5 Ottobre 2001.
INSTALLAZIONE ED UTILIZZO DI SITEMI RADIO LAN AD USO PUBBLICO
A fronte dell’ultimo decreto relativo all’accesso ad Internet senza fili in regime di autorizzazione generale e uso pubblico
rilasciato dal Ministero delle Comunicazioni in data 28 Maggio 2003, sono stati rivisti i parametri relativi all’installazione ed
all’utilizzo dei sistemi Radio LAN ad uso pubblico.
Per completezza di informazioni, suggeriamo di fare riferimento al decreto in questione disponibile sul sito del Ministero
delle Comunicazioni al link http://www.comunicazioni.it/it/index.php?IdNews=39
ACCESSO ALLE FONTI DI INFORMAZIONE
Per tutte le informazioni complementari, a supporto di questa informativa e concernenti all’evoluzione della normativa
wireless sul territorio italiano, vi preghiamo di fare riferimento al sito Internet del Ministero delle Comunicazioni
http://www.comunicazioni.it
viii

TABLE OF CONTENTS
About This User’s Guide.....................................................................................................................................11
Before You Start..................................................................................................................................................11
Installation Requirements....................................................................................................................................11
INTRODUCTION........................................................................................................13
Router Description and Operation.......................................................................................................................13
Front Panel..........................................................................................................................................................16
Rear Panel ...........................................................................................................................................................17
Wireless LAN Basics..........................................................................................................................................17
About 802.11g Wireless......................................................................................................................................18
HARDWARE INSTALLATION...................................................................................20
Location...............................................................................................................................................................20
Net ork Connection ...........................................................................................................................................20
Choosing the Best Location for Wireless Operation...........................................................................................22
Po er On Router.................................................................................................................................................23
Factory Reset Button...........................................................................................................................................23
CONFIGURING THE ROUTER FOR THE FIRST TIME............................................24
Configuring IP Settings on Your Computer........................................................................................................24
Configure IP Settings..........................................................................................................................................25
ACCESSING THE CONFIGURATION MANAGER...................................................27
Configure the Router ith the Configuration Wizard.........................................................................................28
HOME........................................................................................................................46
Wireless...............................................................................................................................................................46
WAN Configuration............................................................................................................................................47
LAN Configuration.............................................................................................................................................56
DHCP..................................................................................................................................................................57
DNS.....................................................................................................................................................................59
Dynamic DNS.....................................................................................................................................................60
ADVANCED CONFIGURATION................................................................................62
UPnP....................................................................................................................................................................62
Virtual Server......................................................................................................................................................64
LAN Clients........................................................................................................................................................65
SNMP .................................................................................................................................................................68
Filters...................................................................................................................................................................70
Bridge Filters.......................................................................................................................................................72
Routing ...............................................................................................................................................................74
DMZ....................................................................................................................................................................76
Fire all................................................................................................................................................................78
RIP.......................................................................................................................................................................81
PPP......................................................................................................................................................................83
ADSL...................................................................................................................................................................85
ATM VCC...........................................................................................................................................................86
Wireless Management.........................................................................................................................................88
Wireless Performance..........................................................................................................................................91
TOOLS.......................................................................................................................93
Admin..................................................................................................................................................................93
Time.....................................................................................................................................................................94

Remote Log.........................................................................................................................................................95
System.................................................................................................................................................................97
Firm are.............................................................................................................................................................98
Miscellaneous......................................................................................................................................................99
Test....................................................................................................................................................................100
STATUS...................................................................................................................102
Device Info........................................................................................................................................................102
DHCP Clients....................................................................................................................................................103
Log.....................................................................................................................................................................104
Statistics.............................................................................................................................................................106
ADSL ................................................................................................................................................................107
HELP........................................................................................................................109
TECHNICAL SPECIFICATIONS.............................................................................110
IP ADDRESS SETUP..............................................................................................112
IP CONCEPTS.........................................................................................................115
MICROFILTERS AND SPLITTERS.........................................................................119

DSL-G604T Wireless ADSL Router Manual
About This User’s Guide
This manual provides instructions on ho to install the DSL-G604T ADSL Router and use it to
connect a computer or Ethernet LAN to the Internet.
Before You Start
Please read and make sure you understand all the prerequisites for proper installation of your ne
Router. Have all the necessary information and equipment on hand before beginning the installation.
Installation Overview
The procedure to install the Router can be described in general terms in the follo ing steps:
1. Gather information and equipment needed to install the device. Before you begin the actual installation make sure
you have all the necessary information and equipment.
2. Install the hard are, that is, connect the cables (Ethernet and telephone) to the device and connect the po er
adapter.
3. Check the IP settings on your computer and change them if necessary so the computer can access the eb-based
soft are built into the Router.
4. Use the eb-based management soft are to configure the device to suit the requirements of your ADSL account.
Installation Requirements
Information you will need from your ADSL servi e provider:
Username
This is the Username that is used to log on
to your ADSL service provider’s network. It is
commonly in the form  [email protected]m.
Record your info
here.
Password
This is the assword that is used, in
conjunction with the Username above, to log
on to your ADSL service provider’s network.
Connection
Protocol
This is the method that your ADSL service
provider uses to send and receive data
between the Internet and your computer.
VPI
This is the Virtual ath Identifier (VPI). It is
used in conjunction with the Virtual Channel
Identifier (VCI) below, to identify the data
path between your ADSL service provider’s
network and your computer.
VCI
This is the Virtual Channel Identifier (VCI). It
is used in conjunction with the V I above to
identify the data path between your ADSL
service provider’s network and your
computer.
11

DSL-G604T Wireless ADSL Router Manual
Information you will need about your DSL-G604T ADSL Router:
Username
This is the Username you will be prompted
to enter when you access the DSL-G604T’s
configuration screens using a Web browser.
The default Username is admin.
Record your info
here.
Password
This is the assword you will be prompted to
enter when you access the DSL-G604T’s
configuration screens using a Web browser.
The default assword is admin.
LAN IP address
for the DSL-G604T
This is the I address you will enter into the
Address field of your Web browser to
access the DSL-G604T’s configuration
screens using a Web Browser. The default
I address is 192.168.1.1.
LAN Subnet Mas
for the DSL-G604T
This is the subnet mask used by the DSL-
G604T, and will be used throughout your
LAN. The default subnet mask is
255.255.255.0.
Information you will need about your LAN or omputer:
Ethernet NIC
If your computer has an Ethernet NIC, you
can connect the DSL-G604T to this Ethernet
port using an Ethernet cable. You can also
use the Ethernet port on the DSL-G604T to
connect to other Ethernet devices, such as a
Wireless Access oint.
Record your info
here.
DHCP Client
status
Your DSL-G604T ADSL Router is
configured, by default, to be a DHC server.
This means that it can assign an I address,
subnet mask, and a default gateway address
to computers on your LAN. The range of I
addresses the DSL-G604T will assign are
from 192.168.1.2 to 192.168.1.254. Your
computer (or computers) needs to be
configured to Obtain an IP address
automatically (that is, they need to be
configured as DHC clients.)
It is recommended that your collect and record this information here, or in some other secure place, in
case you have to re-configure your ADSL connection in the future.
Once you have the above information, you are ready to setup and configure your DSL-G604T ADSL
Router.
12

DSL-G604T Wireless ADSL Router Manual
1
Introduction
This section provides a brief description of the Router, its associated technologies and a list of Router
features.
What is ADSL?
Asymmetric Digital Subscriber Line (ADSL) is an access technology that utilizes ordinary copper
telephone lines to enable broadband high-speed digital data transmission and interactive multimedia
applications for business and residential customers. For ADSL services, it is not necessary to install
expensive ne cabling or condition the line in any ay.
ADSL greatly increases the signal carrying capacity of copper telephone lines ithout interfering ith
regular telephone services. For the ADSL user, this means faster do nloads and more reliable
connectivity. ADSL devices make it possible to enjoy benefits such as high-speed Internet access
ithout experiencing any loss of quality or disruption of voice/fax telephone capabilities.
ADSL provides a dedicated service over a single telephone line operating at speeds of up to 8 Mbps
do nstream and up to 640 Kbps upstream, depending on local telephone line conditions. A secure
point-to-point connection is established bet een the user and the central office of the service provider.
D-Link ADSL devices incorporate the recommendations of the ADSL Forum regarding framing, data
format, and upper layer protocols.
Router Description and Operation
The DSL-G604T ADSL Router is designed to provide a simple, cost-effective and secure ADSL
Internet connection for your small- to medium-sized private net ork. The DSL-G604T combines the
benefits of high-speed ADSL connection technology and TCP/IP routing ith a conventional Ethernet
interface in one compact and convenient package. ADSL connection technology enables many
interactive multi-media applications such as video conferencing and collaborative computing.
The Router is easy to install and use. The DSL-G604T connects to an Ethernet LAN via a standard
Ethernet 10BASE-T interface using RJ-45 connectors. The ADSL connection is made using ordinary
t isted-pair telephone line ith standard RJ-11 connectors. This arrangement means that several PCs
can be net orked and connected to the Internet using a single WAN interface and IP address.
Low Pass Filters
Since ADSL and telephone services share the same copper iring to carry their respective signals, a
filtering mechanism may be necessary to avoid mutual interference. A lo pass filter device can be
installed for each telephone that shares the line ith the ADSL line. These filters are easy to install
passive devices that connect to the ADSL device and/or telephone using standard telephone cable. Ask
your service provider for more information about the use of lo pass filters ith your installation.
Appendix B provides illustrated examples of ho to install t o common styles of lo pass filters.
Operating Systems
The DSL-G604T uses an HTML-based eb interface for setup and management. The eb
configuration manager may be accessed using any operating system capable of running eb bro ser
soft are, including Windo s 98 SE, Windo s ME, Windo s 2000, and Windo s XP.
13

DSL-G604T Wireless ADSL Router Manual
Web Browser
Any common eb bro ser can be used to configure the Router using the eb configuration
management soft are. The program is designed to ork best ith more recently released bro sers
such as Mozilla, Firefox, Opera, Microsoft Internet Explorer® version 5.0, Netscape Navigator®
version 4.7, or later versions. The eb bro ser must have JavaScript enabled. JavaScript is enabled by
default on many bro sers. Make sure JavaScript has not been disabled by other soft are (such as
virus protection or eb user security packages) that may be running on your computer.
Ethernet Port (NIC Adapter)
Any computer that uses the Router must be able to connect to it through the Ethernet port on the
Router. This connection is an Ethernet connection and therefore requires that your computer be
equipped ith an Ethernet port as ell. Most notebook computers are no sold ith an Ethernet port
already installed. Like ise, most fully assembled desktop computers come ith an Ethernet NIC
adapter as standard equipment. If your computer does not have an Ethernet port, you must install an
Ethernet NIC adapter before you can use the Router. If you must install an adapter, follo the
installation instructions that come ith the Ethernet NIC adapter.
Additional Software
It may be necessary to install soft are on your computer that enables the computer to access the
Internet. Additional soft are must be installed if you are using hat is called a “bridged” connection.
For a bridged connection, the information needed to make and maintain the Internet connection is
stored on your computer, not in the Router. This type of connection is similar to the arrangement used
for analog dial-up modems, but the connection speed is much faster. Various terms are to describe a
bridged ADSL connection including the term “RFC 1483 Bridge” hich is used in this guide.
About Bridged Ethernet Connections (RFC 1483)
Using this method, the DSL-G604T acts as a transparent bridge, and is invisible to other devices on
both the WAN and LAN side of the bridge. It is therefore necessary to provide some means of
acquiring global IP settings for your account.
All connections to the Internet require a unique global IP address. For bridged connections, the global
IP settings must reside in a TCP/IP enabled device on the LAN side of the bridge, such as a PC, server
or fire all hard are. The IP address can be assigned in a number of ays. Your net ork service
provider ill give you instructions about any additional connection soft are or NIC configuration that
may be required.
Account Information (User Name and Password)
Most users ill need to supply a user name and pass ord used to access the service provider’s
net ork (and ultimately, the Internet). This information is stored either in the Router’s memory or on
your computer depending on the type of ADSL connection you have.
ACCOUNT INFORMATION ( Connections Only)
User Name:
assword:
Router Features
The D-Link DSL-G604T ADSL Router provides the follo ing features:
Data rates up to 24 Mbps for do nstream and 1Mbps for upstream
Friendly eb-based graphical user interface for configuration and management
Supports up to eight simultaneous virtual connections for a single ADSL account
14

DSL-G604T Wireless ADSL Router Manual
Supports T1.413 issue 2, G.dmt and G.lite for the ADSL standard
Supports G.dmt.bis and G.lite.bis for the ADSL2 standard
Supports g.992.5 for the ADSL standard
Auto-handshake and rate adaptation for different ADSL flavors
Widest range of DSLAM interoperability
Built-in MIBs for SNMP management
Upgradeable firm are through HTTP
Pac ing List
Open the shipping carton and carefully remove all items. In addition to this User's Guide, ascertain
that you have:
One DSL-G604T ADSL Router
One t isted-pair telephone cable used for ADSL connection
One CAT-5 Ethernet cable
One AC po er adapter suitable for your electric service
This Manual on CD ROM
One Quick Installation Guide
15

DSL-G604T Wireless ADSL Router Manual
Front Panel
Place the Router in a location that permits an easy vie of the LED indicators on the front panel.The
LED indicators on the front panel include the Power, Status, ADSL Link/Act, WLAN Link/Act, and
Ethernet Link/Act indicators.
Power
Steady green light indicates
the unit is powered on. When
the device is powered off this
remains dark.
Status
Lights steady green during
power on self-test ( OST).
Once the connection status
has been settled, the light will
blink green. If the indicator
lights steady green after the
OST, the system has failed
and the device should be
rebooted.
ADSL (Lin /Act)
Steady green light indicates a
valid ADSL connection. This
will light after the ADSL
negotiation process has been
settled. A blinking green light
indicates activity on the WAN
(ADSL) interface.
WLAN (Lin /Act)
Steady green light indicates a
wireless connection. A
blinking green light indicates
activity on the WLAN
interface.
Ethernet (Lin /Act)
1 - 4
A solid green light indicates a
valid link on startup. This light
will blink when there is activity
currently passing through the
Ethernet ports.
16

DSL-G604T Wireless ADSL Router Manual
Rear Panel
Connect the AC po er adapter cord and net ork cables on the rear panel. The po er s itch and reset
button are also located on the back of the device. Connect the antennas to the antenna posts.
All cable connections to the Router are made at the rear panel. The po er s itch and factory reset
button is located here as ell.
Wireless LAN Basics
Some basic understanding of 802.11g ireless technology and terminology is useful hen you are
setting up the Router or any ireless access point. If you are not familiar ith ireless net orks
please take a fe minutes to learn the basics.
Radio Transmission
Wireless LAN or WLAN devices use electromagnetic aves ithin a broad, unlicensed range of the
radio spectrum to transmit and receive radio signals. When a ireless access point is present, it
becomes a base station for the WLAN nodes in its broadcast range. WLAN nodes transmit digital data
17
Ethernet ports
Use the Ethernet
ports to connect
the Router to
your Ethernet
LAN or Ethernet
devices
Antenna
For wireless
operation, mount
the antenna on
the threaded
antenna post
Power Insert
Use the adapter
shipped with the
Router to connect
to power source
Reset button
To manually
reset, depress
button with the
power on for a
few seconds
ADSL Port
Use the ADSL
cable to
connect to the
your telephone
line (RJ-11
port)

DSL-G604T Wireless ADSL Router Manual
using FM (frequency modulation) radio signals. WLAN devices generate a carrier ave and modulate
this signal using various techniques. Digital data is superimposed onto the carrier signal. This radio
signal carries data to WLAN devices ithin range of the transmitting device. The antennae of WLAN
devices listen for and receive the signal. The signal is demodulated and the transmitted data extracted.
The transmission method used by the access point is called Direct Sequence Spread Spectrum (DSSS)
and operates in a range of the radio spectrum bet een 2.4GHz and 2.5GHz for transmission. See the
technical specifications for more details on ireless operation.
Range
Range should not be a problem in most homes or small offices. If you experience lo or no signal
strength in some areas, consider positioning the Router in a location bet een the WLAN devices that
maintains a roughly equal straight-line distance to all devices that need to access the Router through
the ireless interface. Adding more 802.11g access points to rooms here the signal is eak can
improve signal strength. Read the section about placement of the Router titled Location in the next
chapter, Hard are Installation, for more information.
SSID
Wireless net orks use an SSID (Service Set Identifier) to allo ireless devices to roam ithin the
range of the net ork. Wireless devices that ish to communicate ith each other must use the same
SSID. Several access points can be set up using the same SSID so that ireless stations can move
from one location to another ithout losing connection to the ireless net ork.
The DSL-G604T operates in Infrastructure mode. It controls net ork access on the ireless interface
in its broadcast area. It ill allo access to the ireless net ork to devices using the correct SSID
after a negotiation process takes place. By default he DSL-G604T broadcasts its SSID so that any
ireless station in range can learn the SSID and ask permission to associate ith it. Many ireless
adapters are able to survey or scan the ireless environment for access points. An access point in
Infrastructure mode allo s ireless devices to survey that net ork and select an access point ith
hich to associate. You may disable SSID broadcasting in the eb manager’s ireless menu.
Wireless Security
Various security options are available on the DSL-G604T including open or WEP, WPA, and WPA-
PSK. Authentication may use an open system or a shared key. For details on these methods and ho
to use them, please read the ireless LAN configuration information in chapters 3 (Basic Router
Configuration) and 4 (Advanced Router Configuration) belo .
About 802.11g Wireless
Today's 11-megabits-per-second 802.11b ireless net orks are fine for broadband Internet access
( hich typically tops out at about 1 mbps) but rather slo for large internal file transfers or streaming
video. Ho ever, 54-mbps, corporate-oriented 802.11a is expensive--and because its radio uses the 5-
GHz band and 802.11b uses the 2.4-GHz band, upgrading to an 802.11a net ork means either
scrapping 802.11b gear or buying even-pricier hard are that can support both standards.
But 802.11g promises the same speed as 802.11a and the ability to coexist ith 802.11b equipment on
one net ork, since it too uses the 2.4-GHz band.
802.11g is an extension to 802.11b, the basis of many ireless LANs in existence today. 802.11g ill
broaden 802.11b's data rates to 54 Mbps ithin the 2.4 GHz band using OFDM (orthogonal frequency
division multiplexing) technology. Because of back ard compatibility, an 802.11b radio card ill
interface directly ith an 802.11g access point (and vice versa) at 11 Mbps or lo er depending on
range. You should be able to upgrade the ne er 802.11b access points to be 802.11g compliant via
relatively easy firm are upgrades.
18

DSL-G604T Wireless ADSL Router Manual
Similar to 802.11b, 802.11g operates in the 2.4GHz band, and the transmitted signal uses
approximately 30MHz, hich is one third of the band. This limits the number of non-overlapping
802.11g access points to three, hich is the same as 802.11b.
19

DSL-G604T Wireless ADSL Router Manual
2
Hardware Installation
The DSL-G604T functions on t o separate net orks, as an Ethernet LAN and as an ADSL WAN.
When deciding here to put the Router, the user must take into account the fact that it is connected to
these three net orks ith three types of media. Ethernet cables connect the Router to computers and
net ork devices, and the ADSL line connects it to a all socket. In addition, the device must be near
an AC outlet for po er. Ho to accommodate these ired connections is often not a complicated
matter, ho ever, the added dimension of ireless communication does complicate the decision of
Router placement.
Location
The Router can be placed on a shelf or desktop and ideally you should be able to see the LED
indicators on the front if you need to vie them for troubleshooting.
Networ Connection
Complete the connection to the net ork through the ADSL port and the Ethernet port on the back of
the Router.
Connect ADSL Line
Use the ADSL cable included ith the Router to connect it to a telephone all socket. Plug one end of
the cable into the ADSL port (RJ-11 receptacle) on the rear panel of the Router and insert the other
end into the RJ-11 all socket. If you are using a lo pass filter device, follo the instructions
included ith the device or given to you by your service provider. The ADSL connection represents
the WAN interface. It is the physical link to the ISP’s net ork backbone and ultimately to the Internet.
Connect Router to Ethernet
The Router may be connected to any 10/100BASE-TX Ethernet LAN. Any connection to an Ethernet
concentrating device such as a s itch or hub must operate at a speed of 10/100 Mbps only. When
connecting the Router to any Ethernet device that is capable of operating at speeds higher than
10Mbps, be sure that the device has auto-negotiation (NWay) enabled for the connecting port.
Use standard t isted-pair cable ith RJ-45 connectors. The RJ-45 port on the Router is a crossed port
(MDI-X). Follo standard Ethernet guidelines hen deciding hat type of cable to use to make this
connection. When connecting the Router directly to a PC or server use a normal straight-through
cable. You should use a crossed cable hen connecting the Router to a normal (MDI-X) port on a
s itch or hub. Use a normal straight-through cable hen connecting it to an uplink (MDI-II) port on a
hub or s itch.
The rules governing Ethernet cable lengths apply to the LAN to Router connection. Be sure that the
cable connecting the LAN to the Router does not exceed 100 meters.
Hub or Switch to Router Connection
Connect the Router to an uplink port (MDI-II) on an Ethernet hub or s itch ith a straight-through
cable as sho n in the diagram belo :
20
