D-Link 2Voice + 4SW VoIP Router DVG-1402S User manual

Check Your Package Contents
Thesearetheitemsincludedwithyourpurchase:
If any of the below items are missing, please contact your reseller.
BeforeYouBegin
Youmusthaveatleastthefollowing:
• Asubscriptionwiththebundledserviceproviderincludedinthispackage
• AComputerwithaCD-ROMdriveandanEthernetportrunningaWindows,Mac,orLinux
basedOS(forinitialsetup)
• Ethernetbasedbroadbandmodem
DVG-1402S
ThisproductcanbesetupusingInternet
Explorer or Netscape Navigator, 6.x or
above, with Javascript enabled Broadband Phone
Service VoIP Router
©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of
their respective holders. Software and specifications subject to change without notice. DVG-1402S.09232004
DVG-1402S Broadband Phone Service VoIP Router
12V DC Power Adapter
CAT5 Ethernet Cable (Blue)
Using a power supply
with a different voltage
rating will damage this
productandvoidthewarranty.
Phone Cord (Black)
CD-ROM

2
HardwareOverview
Front Panel
Power LED Indicates the unit is powered on.
Status/Alarm The Status LED will flash whenperforming a self-test/booting up or
is registering with the service provider. The Status LED will flash
green slowly when the system is connected with the service. The
Alarm LED will light solid red if the self-test or bootup fails. The
AlarmLED willflashred slowlywhenthe system is readybutcannot
receive an acknowledgement from the service.
Prov This LED flashes when the device has established a connection
and received authorization from your service provider.
WAN LED
When a connection is established the 10 or 100 LED will light up
solid. The LED will blink to indictate activity. If the 10 or 100 LED
does not light up when a cable is connected, verify the cable
connections and make sure your devices are powered on.
LAN LEDs When a connection is established the 10 or 100 LED will light up
solid on the appropriate port. The LEDs will blink to indictate
activity. If the 10 or 100 LED does not light up when a cable is
connected, verify the cable connections and make sure your
devices are powered on.
Phone LEDs This LED displays the VoIP status and Hook/Ringing activityonthe
phone port that is used to connect your normal telephone(s).
MWI: Lights to indicate a voicemail is waiting.
Hook/Ring: If a phone connected to a phone port is off the hook
or in use, this LED will light solid. When a phone is ringing, the
indicator will blink.

3
Phone Ports Connect to your phones using standard phone cabling.
LAN Port Connect to your Ethernet enabled computers using Ethernet
cabling.
WAN Port Connects to your broadband modem using an Ethernet cable.
Reset This is used to reset the unit to the factory default settings.
Power
Connector The power adapter attaches here.
Rear Panel
HardwareOverview(continued)
Using a power supply with a different voltage rating will damage
this product and void the warranty.

4
Connecting the DVG-1402S directly to a
Modem and Computer
a.Turn off your Computer.
b. DisconnectthepowertoyourCable/DSLModem(Unplugorturnoffthepowerswitch).
c. UnplugtheexistingEthernetcablethatisconnectedtoyourCable/DSLModem’sLANor
Ethernetport. Leavetheother end ofthis cable attachedtoyour PC.
d. Plug the Ethernet cable connector that you just
removed from the modem into one of the four LAN
portson the backoftheDVG-1402S. Theotherend
remains attached to the PC.
If your computer connects directly to a DSL or Cable modem and does not connect to a
router, follow the steps below to install your DVG-1402S. For any other configuration,
please refer to the user manual located on the CD-ROM.After the steps are completed,
your setup should look similar to the diagram below.

5
e. Attach one end of the Ethernet Cable (blue) provided in this package to the LAN or
EthernetPort onthe Cable/DSL Modem.
f. Attachthe otherend of the providedEthernet Cable
to the WAN Port of the DVG-1402S.
g. Attachoneendoftheprovidedphonecable(black)toastandardanalogtelephone.
h. Attachtheotherendofthephonecabletothephone
portlabeled1ontherearpaneloftheDVG-1402S.
i. Reconnectthe powertothe Cable/DSL Modem(Plug in orturnon thepowerswitch).
j. ConnectthePowerAdaptertothePowerConnecter
onthe DVG-1402S.
k. Connect the other end of the PowerAdapter to an
available electrical outlet (Wall Socket or Surge
Protector).
l. Restart your PC.
Hardware configuration is complete! If your VoIP service is already activated, you can
makephone callsnow.
Connecting the DVG-1402S directly to a
Modem and a Computer (continued)
• If your ISP registers your computer’s MAC address, see the section labeled MAC
CloningforCableConnectionsintheusermanualontheCD-ROM.
•PPPoE Users, please continueto thenextpageforadditional configuration steps.

6
PPPoE Configuration
Open your Web browser
andtypehttp://192.168.15.1
into the URL address box.
PresstheEnterorReturnkey.
ClickLogin to the web-based
management module.
ClickConfigureWAN/LANAccess.
ClickConfigure WANPort.
Some Internet Service providers use PPPoE as their method of connecting clients.
If you have a PPPoE connection, you must follow the steps below to complete the
configuration of your hardware. If you are unsure of your connection type or do
not know your username and password, please check with your Internet Service
Provider.

7
PPPoE Configuration (continued)
Select PPPoE from
thepull-downmenu.
Enter your User Name and
Authentication Password and
ConfirmPassword.
Click Save.
Select Save changes
andrebootsystemnow.
Click Save.
Once the unit reboots you will
be returned to the main screen.
Check to see if the status LED
lightgoesfrom blinkinggreen to
solidgreen onthe front panelof
theDVG-1402S.
The information found on the
Device Information page is
necessary for VoIP service
registration.

D-LinkD-Link
D-LinkD-Link
D-Link®®
®®
®TT
TT
Techniechni
echniechni
echnical Supportcal Support
cal Supportcal Support
cal Support
You can find software updates and user documentation on the D-Link website.
D-Link provides free technical support for customers within the United States and within
Canada for the duration of the warranty period on this product.
U.S. and Canadian customers can contact D-Link Technical Support through our website
or by phone.
Tech Support for customers within the United States:
D-Link Technical Support over the Telephone:
[phone]
24 hours a day, seven days a week.
D-Link Technical Support over the Internet:
http://support.dlink.com
email:[email protected]
Tech Support for customers within Canada:
D-Link Technical Support over the Telephone:
[phone]
Monday to Friday 7:30am to 12:00am EST
D-Link Technical Support over the Internet:
http://support.dlink.ca
email:[email protected]
For Technical Support regarding
yourphoneservice,pleasecontact
the service provider.
If you experience any hardware problems with the DVG-1402S, please
contact D-Link Technical Support.
