DAKtel DTG8000 Owner's manual
www.daktelholdings.com
DaktelHoldingsLimited
7ElishaCohenStreet75908,Israel
C.R#514884923
3G GPS elderly tracker
DTG8000
Quick User Installation
DTG8000 is a dual core 3G/WCDMA, 2-Way Voice Communicator & Tracker
Package contained:
1x GSM Communicator
1x Lanyard cord
1X Belt clip
1x USB Charger
1x USB cable
1x Power adapter
Before first use: (make sure the device is OFF)
1. Open the 4 small screws on the back side door and lift the back door
2. Lift the SIM card metal house by unlocking it (push to the left side)
3. Insert the SIM card: (Using MICRO SIM card type)
1. Replace the micro SIM card and lock it back
4. Close the back side door
5. Press and old the side button for 3 seconds till the blue LED light
6. The blue LED will start flashing fast and will look for the network, once a
successful connection to the network achieved, the blue LED will flash slowly
(every 5 seconds). After successful network connection, press (single press)
on the side buttons: you will hear the announcement: “Device Is Connected”
7. Charge the device at least 14 hrs before first use
Remark:
If you open the device BEFORE inserting the SIM card, the a voice will be
heard: “NO SIM CARD”
If you insert the SIM card when the device is OPEN, please turn the device
OFF and ON before use
When turning the device ON in the first time, make sure you are outside for
the satellite reception
www.daktelholdings.com
DaktelHoldingsLimited
7ElishaCohenStreet75908,Israel
C.R#514884923
Opening and closing the device: (turn ON / OFF)
Press and hold the side button for 3 seconds till the blue LED light. The blue
LED will start blinking fast searching for the network. Once the device connect
OK to the network, the blue LED will flash slowly (once every 5 seconds).
To close the device (turn OFF), press and hold the side button for 10-12
seconds till the device will vibrate (indication that the device is turned OFF).
The LEDS will be turn OFF as well:
LEDS indication:
Top GREEN led
Will light when the device is in use
Top RED led
Will light when the device in charging and when low battery
Side BLUE led
Will flash fast (every 0.5 sec) when there is no connection to the network
Will flash slow (every 5 sec) when the device connect to the network
Will stop flash when the device in sleep mode status and the front leds will
flash instead
Front RED led (x 3 led)
Will flash slow (every 5 sec) is standby mode (in sleep mode)
Will flash fast ( every 0.5 sec) in incoming call
Will light when in use
Headset socket:
In DTG8000 the headset socket is not activated! Please DO NOT touch the silicon
headset, it is glowed.
Activate the voice command: (for device connection status)
When the device is ON, by single press on the side button, a voice command will be
heard announcing the device status:
“Device is connected”
“Device is not connected”
SMS Commands for general settings:
Remarks:
9999 (4 digits) is the default setting code. You can replace it with your own
4 digits code (ud=sing the below SMS commands)
Please press SEND after every command for activate
A confirmation of the successful command will be shown in your SMS box.
www.daktelholdings.com
DaktelHoldingsLimited
7ElishaCohenStreet75908,Israel
C.R#514884923
When using the APP, the commands will be shown on the APP screen (in
Android VERSION) and in your SMS box in IOS version
In the below commands, the X stand for the number/s or character/s to be insert
SET (device settings)
Commands Description Command Remarks
SOS
Setting the
SOS numbers
SET9999#PHONE1#XXX#
SET9999#PHONE2#XXX#
SET9999#PHONE3#XXX#
SET9999#PHONE4#XXX#
SET9999#PHONE5#XXX#
SET9999#PHONE6#XXX#
SET9999#PHONE7#XXX#
SET9999#PHONE8#XXX#
1. Total 8 SOS numbers can be
stored to the device (PHONE1-8)
2. When SOS is triggered, each
SOS number will dialed 3 times
3. To activate the SOS call, single
press on the main SOS button, it
will follow with SOS ring sound
4. To cancel SOS call, press and
hold 3 seconds till the cancel
sound been heard
5. Once an SOS call triggered, call
party will receive automatically
SOS message and position (GPS)
by direct link to Google map
M1-M2
Setting the
direct
memories
SET9999#M1#XXX#
SET9999#M2#XXX#
1. There are 2 direct memories (M1-
M2)
2. By single press you can activate
the call and it will follow with
calling sound
3. To cancel the call, single press
again and it will follow with cancel
sound
SOS
Message
Call party
received
message when
SOS call
activated
SET9999#SOSMSG1#XXX#
SET9999#SOSMSG2#XXX#
SET9999#SOSMSG3#XXX#
SET9999#SOSMSG4#XXX#
SET9999#SOSMSG5#XXX#
1. Total 5 SOS messages can
be stored
2. can select any message to
different SOS number
Enable
AGPS
Feature
activate when
GPS signal is
not available
SET9999#AGPS#X#
0: GPS
Can open AGPS if GPS is not
available. AGPS read device location
by nearest GSM antennas
Number
Number
Message
0,1or2
www.daktelholdings.com
DaktelHoldingsLimited
7ElishaCohenStreet75908,Israel
C.R#514884923
1: User Plane
2: Control Plane
Periodic
System
Check
Monitoring the
device from a
distance
Operate from the APP only
Device will report it connection every
certain time set (from 1-7 days)
Melodies
Melodies
profile
SET9999#RING#X#
Total 8 ringing melodies from 1-8
Ring type
4 different ring
type for user
convince
SET9999#SCENE#X#
0 = Ring only
1 = Ring & Vibration
2 = Vibration only
3 = Mute
Below selection::
only ring tone
ring + vibration
only vibration
only silent mode
Volume
Volume
SET9999#VOL#X#
Can set the volume from 1-5
GEO FENCE
A border in
GPS mode
allowing to
monitor the
device in a
certain defined
area (from 0 -
1000 meter
radios)
Operate from the APP
Operate from the APP
Fall detection
Detect a fall
SET9999#SWFALL#X#
1 = Enable
0 = Disable
Fall detection default setting is
OFF
Fall detection feature detect your
fall in fast movement and impact
Once a fall detected, the device
will make alarm sound for 10
seconds before dialing the SOS
number/s. the user can still cancel
the alarm if it is not needed to dial
the SOS number/s
By using the fall detection feature,
it is under the user full
responsibility
0or1
0‐3
1‐8
1‐5
www.daktelholdings.com
DaktelHoldingsLimited
7ElishaCohenStreet75908,Israel
C.R#514884923
ECI
(Auto
answer)
Monitoring the
device from a
distance
SET9999#SWECI#X#
1 = Enable
0 = Disable
Will open the device automatically in
SPK mode after 1-2 ring
ECI
password
change
CANCELLED.
FEATURE IS NOW IN
AUTOMATIC ANSWER
AFTER 1-2 RINGS
Language
Support total 6
languages:
SET9999#LANG#X#
0 = English
1 = Dutch
2 = French
3 = German
4 = Portuguese
5 = Spanish
Languages for the voice prompt
announcements:
1. Low battery
2. SOS announcement
Low battery
Low battery
alert and
dialing
SET9999#BATTPHONE#XXX#
When low battery alert is set, you can
define also the number that the
device will call when device in low
battery state
System code
SMS
command 4
digit code
SET9999#SMSPW#XXXX#
Default code is four nine (9999). You
can select any 4 digits code
GET (getting info from the device)
Commands Description Command Remarks
GPS
Device GPS
GET9999#GPSINFO#
Locate the device.
0or1
0‐5
Number
4digitcode
www.daktelholdings.com
DaktelHoldingsLimited
7ElishaCohenStreet75908,Israel
C.R#514884923
location A link to Google map will receive
SOS
SOS number’s
stored
GET9999#PHONE1#
Return confirmation:
+PHONE1=XXXXXX#
SOS Message
SOS message
stored
GET9999#SOSMSG1#
Return confirmation:
+SOSMSG1=XXXXXX#
M1-M2
M1-M2 number’s
stored
GET9999#M1#
Return confirmation:
+M1=XXXXXX#
Low battery
Low battery
number stored
GET9999#BATTPHONE#
Return confirmation:
+BATTPHONE=XXXXXX#
Fall detection
Fall detection
status (enable or
disable)
GET9999#SWFALL#
1 = Enable
0 = Disable
Return confirmation:
+SWFALL=-X#
Melodies
Melody type set
GET9999#RING#
Return confirmation
+RING=-X#
www.daktelholdings.com
DaktelHoldingsLimited
7ElishaCohenStreet75908,Israel
C.R#514884923
Ring type Ring type set GET9999#SCENE#
Return confirmation:
+RING=X#
Volume
Volume set
GET9999#VOL#
Return confirmation:
+VOL=X#
AGPS
APGS status
(enable /
disable)
GET9999#AGPS#X#
Return confirmation:
+AGPS=X#
0: GPS
1: User Plane
2: Control Plane
Auto answer
Auto answer
status (ON/OFF)
GET9999#SWECI#
Return confirmation:
+SWECI=X#
1 = Enable
0 = Disable
Language
Voice prompt
Language used
GET9999#LANG#
Return confirmation:
+LANG=X#
0 = English
1 = Dutch
2 = French
3 = German
4 = Portuguese
5 = Spanish
GEO FENCE
Operate from the
APP
Operate from the APP
Operate from the APP
System code
System SMS
code set
GET9999#SMSPW#
Return confirmation:
+SMSPW=XXXX#
The APP:
A dedicated APP for smart phone, both Android and IOS (Apple)
Please download the APP and install it in your smart phone
www.daktelholdings.com
DaktelHoldingsLimited
7ElishaCohenStreet75908,Israel
C.R#514884923
APP user instruction inside the APP
Remark:
Android version fully support the SMS commands (SET & GET) on the APP
IOS version support SET on the APP, however GET commands received in your
SMS box
Additional:
Checking the device is OK
When the device is OFF (close), by single press on the side button and the device
LEDS will flash t times
IP65:
The device stands in IP65 classification. Meaning dust protection and water
protection in the shower
Low battery:
When battery in low capacity, a voice announcement will be heard to charge the unit
If the unit wasn’t charge in 10min, the low battery number will be dial (once it is SET)
Standby time:
Approx 72hrs
Talk time:
Approx 3hrs
SW Upgrade:
Please contact us for the SW upgrade instruction
SW upgrade is done from time to time to ensure better performances
SW upgrade can be done locally with the charger & the USB cable and it takes only
30 seconds
Technical support & general info and more:
DECLARATIONOFCONFORMITY
Herby，HuizhouQiaoxingTelecommunicationIndustryCo.,Ltd.declaresthatthis3GGPS
elderlytrackerproductincompliancewiththeessentialrequirementsandother
relevantprovisionsofDirective1999/5/EC.AcopyoftheDeclarationofConformity
www.daktelholdings.comWebsite:canbefoundan
FCC RF Exposure Information and Statement
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This smartphone meets the government’s requirements for exposure to radio waves. The
guidelines are based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure the safety of all persons
regardless of age or health.
FCC RF Exposure information and Statement the SAR limit of USA (FCC) is 1.6W/kg averaged
over one gram of tissue. Device type DTG8000 (FCC ID: 2AGUO-DTG8000) has also been tested
against this SAR limit. SAR information on this and other pad can be viewed on-line at
http://www.fcc.gov/oet/ea/fccid/. This device was tested for typical body-worn operations with the
back of the handset kept 0 mm from the body ,To keep the device at least 0 mm away from your
body to make sure the RF exposure level compliant or lower to the reported level.
.The use of belt clips, holsters and similar accessories may contain metallic components in its
assembly. The use of accessories that do satisfy these requirements comply with FCC RF exposure
requirements.
changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Table of contents
