Dalsa Calibir GXM640 User manual

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir™GXM640
IR Camera User’s Manual
March 23, 2020
P/N: IR-GMZG-USER0
www.teledynedalsa.com
Teledyne DALSA, a business unit of Teledyne Digital Imaging Inc.

Notice
© 2016-2020 Teledyne Digital Imaging Inc.
All information provided in this manual is believed to be accurate and reliable. No
responsibility is assumed by Teledyne DALSA for its use. Teledyne DALSA reserves the right
to make changes to this information without notice. Reproduction of this manual in whole
or in part, by any means, is prohibited without prior permission having been obtained from
Teledyne DALSA.
All other trademarks or intellectual property mentioned herein belong to their respective
owners.
About Teledyne DALSA
Teledyne DALSA, a business unit of Teledyne Digital Imaging Inc., is an international high-
performance semiconductor and electronics company that designs, develops, manufactures,
and markets digital imaging products and solutions, in addition to providing wafer foundry
services.
Teledyne DALSA offers the widest range of machine vision components in the world. From
industry-leading image sensors through powerful and sophisticated cameras, frame
grabbers, vision processors and software to easy-to-use vision appliances and custom vision
modules.

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir GXM640 IR Camera User's Manual
Contents 3
Contents
FIGURES........................................................................................................7
TABLES..........................................................................................................8
CALIBIR GXM640 OVERVIEW ........................................................................9
DESCRIPTION ................................................................................................9
Key Features .........................................................................................9
Teledyne DALSA Development Software.................................................. 10
MODEL PART NUMBERS ................................................................................... 10
Calibir GXM640 Part Numbers ................................................................ 10
EXPORT CONTROLS........................................................................................ 11
GXM640 SPECIFICATIONS .............................................................................. 12
GXM640 EMI, SHOCK AND VIBRATION CERTIFICATIONS........................................... 13
GIGEVISION INTERFACE ................................................................................. 14
GigE Vision Sapera Application Description .............................................. 14
GIGENETWORK ADAPTER OVERVIEW .................................................................. 15
PAUSE Frame Support .......................................................................... 15
COMPUTER REQUIREMENTS FOR CALIBIR GXM640 .................................................. 15
Host PC System ................................................................................... 15
Software Requirements......................................................................... 16
Ethernet Switch Requirements for Calibir GXM640.................................... 17
Ethernet to Fiber-Optic Interface Requirements........................................ 18
INTRODUCTION TO MICROBOLOMETERS.....................................................19
Emissivity............................................................................................ 20
QUICK START GUIDE ...................................................................................22
CONNECTING THE CALIBIR GXM640 GIGEVISION CAMERA ....................................... 22
Calibir GXM640 Power Specifications....................................................... 22
Steps For Camera Startup ..................................................................... 22
Calibir GXM640 Connectors ................................................................... 23
Preventing Operational Faults due to ESD................................................ 24
Calibir IP Configuration Sequence........................................................... 25
CAMERA CONNECTION SETUP ............................................................................ 26
Displaying Images................................................................................ 27
CONTROLLING CALIBIR USING THE SAPERA LT API .................................................. 30
FEATURES AND CONFIGURATION OPTIONS ................................................32
HEAT SINKS ................................................................................................ 33
ADJUSTING THE LENS FOCUS ............................................................................ 33
LED INDICATORS.......................................................................................... 34
Calibir GXM640 LED States.................................................................... 34
FIXED PATTERN NOISE CORRECTION ................................................................... 35
Target Mode ........................................................................................ 35
Saving Fixed Pattern Noise Calibration .................................................... 36
Performing Manual FPN Correction With External Shutter .......................... 36
FPN Correction Using Triggered Acquisition.............................................. 38

4Contents
Calibir GXM640 IR Camera User's Manual
Automatic FPN Calibration ..................................................................... 39
Related GigE Vision Features ................................................................. 39
OVERLAYS .................................................................................................. 40
Related GigE Vision Features ................................................................. 41
FALSE COLOR MAPPING................................................................................... 42
Related GigE Vision Features ................................................................. 42
METADATA.................................................................................................. 43
Related GigE Vision Features ................................................................. 45
PIXEL POLARITY............................................................................................ 46
Related GigE Vision Features ................................................................. 46
DEFECTIVE PIXEL CORRECTION .......................................................................... 47
Related GigE Vision Features ................................................................. 48
MEDIAN FILTER ............................................................................................ 49
Related GigE Vision Features ................................................................. 49
CONTRAST ENHANCEMENT................................................................................ 50
Contrast Mode ..................................................................................... 50
Related GigE Vision Features ................................................................. 59
CAMERA SYNCHRONIZATION ............................................................................. 60
Slave Configuration with External Input Frame Trigger.............................. 61
Slave Configuration with PTP Trigger ...................................................... 61
Master Configuration with Output Pulses ................................................. 62
Related GigE Vision Features ................................................................. 62
EXTERNAL TRIGGER ....................................................................................... 63
SENSOR READOUT ALIGNMENT MODE .................................................................. 65
Related GigE Vision Features ................................................................. 67
PRECISION TIME PROTOCOL ............................................................................. 68
Hardware Considerations....................................................................... 68
PTP Synchronization ............................................................................. 68
PTP Configuration Features.................................................................... 69
Related GigE Vision Features ................................................................. 69
INTERNAL TEST PATTERN GENERATOR.................................................................. 70
Calibir Test Patterns ............................................................................. 70
Related GigE Vision Features ................................................................. 71
TEMPERATURE SENSORS.................................................................................. 71
Related GigE Vision Features ................................................................. 71
ERROR LOG FILE........................................................................................... 72
Related GigE Vision Features ................................................................. 72
OPERATIONAL REFERENCE..........................................................................73
USING A CALIBIR GXM640 CAMERA WITH SAPERA API ............................................ 73
Network and Computer Overview ........................................................... 73
Installing Sapera LT.............................................................................. 74
Camera Firmware Updates .................................................................... 74
Firmware via Linux or Third Party Tools................................................... 74
GigE Server Verification ........................................................................ 75
GigE Server Status ............................................................................... 75
Optimizing the Network Adapter used with Calibir .................................... 76
Quick Test with CamExpert (Windows).................................................... 76
About the Device User ID ...................................................................... 77
USING CAMEXPERT WITH CALIBIR CAMERAS .......................................................... 78
CAMERA INFORMATION CATEGORY ...................................................................... 81
Camera Information Feature Descriptions................................................ 81
Power-up Configuration Dialog............................................................... 84

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir GXM640 IR Camera User's Manual
Contents 5
IMAGE FORMAT CONTROLS CATEGORY ................................................................. 85
Image Format Controls Feature Descriptions ........................................... 85
FPN CORRECTION CATEGORY............................................................................ 87
FPN Correction Feature Descriptions ....................................................... 88
CONTRAST /BRIGHTNESS CATEGORY .................................................................. 90
Contrast / Brightness Feature Descriptions .............................................. 91
IMAGE PROCESSING CATEGORY ......................................................................... 92
Image Processing Feature Descriptions ................................................... 93
OVERLAY CONTROL CATEGORY .......................................................................... 95
Overlay Feature Descriptions ................................................................. 95
ACQUISITION CONTROL CATEGORY ..................................................................... 97
Acquisition Control Feature Descriptions.................................................. 98
Features that Cannot be Changed During a Transfer ................................. 99
TRIGGER CONTROL FEATURES CATEGORY ............................................................ 100
Trigger Controls Feature Descriptions ................................................... 100
Examples using Timestamp Modulo Event for Acquisitions ....................... 102
I/O CONTROLS CATEGORY ............................................................................. 106
I/O Controls Feature Descriptions......................................................... 106
EVENT CONTROL CATEGORY ........................................................................... 108
Event Control Feature Descriptions....................................................... 109
Overview of Precision Time Protocol Mode (IEEE 1588) ........................... 115
USER SET CONTROL CATEGORY ....................................................................... 117
User Set Control Feature Descriptions................................................... 117
METADATA CONTROLS CATEGORY ..................................................................... 118
Metadata Controls Feature Descriptions ................................................ 118
GIGEVISION TRANSPORT LAYER CATEGORY ........................................................ 119
GIGEVISION HOST CONTROL CATEGORY............................................................ 122
FILE ACCESS CONTROL CATEGORY.................................................................... 122
TECHNICAL SPECIFICATIONS....................................................................125
MECHANICAL SPECIFICATIONS......................................................................... 125
Calibir GXM640 with M25 Lens Mount ................................................... 125
ADDITIONAL NOTES ON CALIBIR IDENTIFICATION AND MECHANICAL ............................ 126
CONNECTORS ............................................................................................ 126
10-pin I/O Connector Details ............................................................... 126
Input Signal Electrical Specifications ..................................................... 127
Power over Ethernet (PoE) Support ...................................................... 131
Output Signals Electrical Specifications ................................................. 131
EC &FCC DECLARATIONS OF CONFORMITY ......................................................... 136
ADDITIONAL REFERENCE INFORMATION .............................................................. 137
I/O Mating Connector Sources ............................................................. 137
Cable Assembly G3-AIOC-BLUNT2M...................................................... 138
Cable Assembly G3-AIOC-BRKOUT2M ................................................... 139
RUGGEDIZED RJ45 ETHERNET CABLES .............................................................. 140
SENSOR HANDLING INSTRUCTIONS ................................................................... 141
Cleaning the Sensor Window ............................................................... 141
Electrostatic Discharge and the Sensor ................................................. 141
TROUBLESHOOTING ..................................................................................142
OVERVIEW ................................................................................................ 142
QUICK RECOVERY GUIDE ............................................................................... 142
GENERAL TROUBLESHOOTING FOR CALIBIR GXM640 ............................................. 144
Error Log File..................................................................................... 144

6Contents
Calibir GXM640 IR Camera User's Manual
Power Failure During a Firmware Update–Now What? ............................. 144
Power supply problems: ...................................................................... 144
Camera is functional, but image has no contents.................................... 144
CALIBIR GXM640 TROUBLESHOOTING .............................................................. 144
GigE Server Status ............................................................................. 144
Problem Type Summary ...................................................................... 145
Acquisition Error without Timeout Messages .......................................... 147
Cabling and Communication Problems: ................................................. 148
Verifying Network Parameters.............................................................. 149
CONTACT INFORMATION...........................................................................150
SALES INFORMATION.................................................................................... 150
TECHNICAL SUPPORT.................................................................................... 150

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir GXM640 IR Camera User's Manual
Contents 7
Figures
Figure 1: GigE Application Architecture .................................................................. 14
Figure 2: Calibir GXM640–Rear View..................................................................... 23
Figure 3: Lens Lockdown Screws........................................................................... 33
Figure 4: Calibir GXM640 LED Startup Sequence ..................................................... 34
Figure 5: FPN Compensation Mode ........................................................................ 36
Figure 6: Performing FPN Correction ...................................................................... 36
Figure 7: Faulty FPN Calibration ............................................................................ 37
Figure 8: Overlays............................................................................................... 41
Figure 9: Fire Color Map....................................................................................... 42
Figure 10: Fire Color Map Range Overlay ............................................................... 42
Figure 11: Pixel Polarity ....................................................................................... 46
Figure 12: Defective Pixel Map .............................................................................. 47
Figure 13: File Access Control ............................................................................... 48
Figure 14: Median Filter ....................................................................................... 49
Figure 15: Contrast Enhancement Mapping 16-Bit to 8-bit........................................ 50
Figure 16: Dynamic Adaptive Image Enhancement .................................................. 51
Figure 17: Contrast Enhancement Maximum Gain ................................................... 53
Figure 18: Fixed Adaptive Image Enhancement....................................................... 54
Figure 19: Fixed Adaptive Brightness Setting .......................................................... 55
Figure 20: Fixed Adaptive Brightness Setting Example ............................................. 55
Figure 21: External Trigger Wave Diagram: Free-Running ........................................ 66
Figure 22: External Trigger Wave Diagram: Frame-On-Demand ................................ 67
Figure 23: Horizontal Ramp Test Pattern ................................................................ 70
Figure 24: Vertical Ramp Test Pattern.................................................................... 70
Figure 25: Diagonal Ramp Test Pattern .................................................................. 70
Figure 26: File Access Control Dialog ..................................................................... 71
Figure 27: File Access Control Dialog ..................................................................... 72
Figure 28: GigE Server Tray Icon .......................................................................... 75
Figure 29: GigE Pop-up Menu ............................................................................... 75
Figure 30: GigE Vision Device Status ..................................................................... 76
Figure 31: Sapera CamExpert ............................................................................... 77
Figure 32: Sapera CamExpert GUI Layout .............................................................. 79
Figure 33: CamExpert Camera Information Category ............................................... 81
Figure 34: Power-up Configuration Dialog .............................................................. 84
Figure 35: CamExpert Image Format Controls ........................................................ 85
Figure 36: CamExpert FPN Correction Category ...................................................... 87
Figure 37: CamExpert Contrast / Brightness Category ............................................. 90
Figure 38: CamExpert Image Processing Category................................................... 92
Figure 39: CamExpert Overlay Category ................................................................ 95
Figure 40: CamExpert Acquisition Control............................................................... 97
Figure 41: CamExpert Trigger Control Features Category ........................................100
Figure 42: CamExpert I/O Controls Category .........................................................106
Figure 43: CamExpert Event Control Category .......................................................108
Figure 44: CamExpert User Set Control Category ...................................................117
Figure 45: CamExpert Metadata Controls ..............................................................118
Figure 46: CamExpert GigE Vision Transport Layer Category ...................................119
Figure 47: CamExpert File Access Control Category ................................................122
Figure 48: CamExpert File Access Control Category ................................................124
Figure 49: Calibir GXM640 with M25 Lens Mount (mm units) ...................................125
Figure 50: Cable Assembly G3-AIOC-BLUNT2M ......................................................138

Figure 51: Cable Assembly G3-AIOC-BLUNT2M Mechanical Drawing .........................138
Figure 52: Cable Assembly G3-AIOC-BRKOUT2M....................................................139
Figure 53: Cable Assembly G3-AIOC-BRKOUT2M Mechanical Drawing .......................139
Figure 54: Ruggedized RJ45 Ethernet cable with Thumbscrews ................................140
Figure 55: Random Bad Data or Noise Example .....................................................147
Tables
Table 1: Teledyne DALSA Development Software .............................................................. 10
Table 2: Calibir GXM640 Series Specifications ................................................................... 12
Table 3: Calibir GXM640 NETD and Scene Range Specifications (at ambient temperature 25°C)
................................................................................................................................... 12
Table 4: GXM 640 EMI, Shock and Vibration Certifications .................................................. 13
Table 5: Emissivity Values for Common Materials .............................................................. 21
Table 6: Calibir GXM640 Power Specifications ................................................................... 22
Table 7: Bit Range for 16-Bit Image Display ..................................................................... 28
Table 8: Image Display Using Different 8-Bit Ranges ......................................................... 28
Table 9: Calibir GXM640 LED States ................................................................................ 34
Table 10: Image Enhancement Dynamic Adaptive Contrast Examples .................................. 52
Table 11: Sample 16-Bit Image ...................................................................................... 56
Table 12: Static Contrast Mode Example .......................................................................... 57
Table 13: Maximum Gain Off Example ............................................................................. 58
Table 14: Maximum Gain Setting Examples ...................................................................... 58
Table 15: Maximum Gain Setting 0.5 Example .................................................................. 59
Table 16: GigE Server Tray Icon States............................................................................ 75
Table 17: CamExpert Display Pane Control Buttons ........................................................... 78
Table 18: Camera Information Feature Descriptions .......................................................... 81
Table 19: Image Format Controls Feature Descriptions ...................................................... 85
Table 20: Image Processing Feature Descriptions .............................................................. 88
Table 21: Contrast / Brightness Feature Descriptions......................................................... 91
Table 22: Image Processing Feature Descriptions .............................................................. 93
Table 23: Overlay Feature Descriptions ............................................................................ 95
Table 24: Acquisition Control Feature Descriptions ............................................................ 98
Table 25: Trigger Control Controls Feature Descriptions ....................................................100
Table 26: I/O Controls Feature Descriptions ....................................................................106
Table 27: Event Control Feature Descriptions...................................................................109
Table 28: User Set Control Feature Descriptions...............................................................117
Table 29: Metadata Controls Feature Descriptions ............................................................118
Table 30: GigE Vision Transport Layer Feature Descriptions...............................................120
Table 31: File Access Control Feature Descriptions ...........................................................123
Table 32: Samtec 10-Pin Connector Pin Assignment .........................................................126
Table 33: GigE Server Tray Icon States...........................................................................144

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir GXM640 IR Camera User's Manual
Calibir GXM640 Overview 9
Calibir GXM640 Overview
Description
The Calibir GXM Series cameras are small form factor long wave infrared cameras. The
GXM Series cameras are based on Teledyne DALSA detector technology.
The Calibir GXM640 camera features an internal mechanical shutter; this allows the
camera to recalibrate itself upon demand during operation. This ensures uniform image
output regardless of the camera’s thermal environment. Note that factory calibration of
the Calibir cameras allows them to operate for a long period of time before shutter may
need to be activated.
This manual describes features available for the Calibir GXM640 firmware release 2.41.
Key Features
640x480 VGA resolution
17 μm square pixels
29mm x 36mm x 59mm
Gigabit Ethernet (GigE) interconnection to a computer via standard 1000BASE-T
compliant cables
Visual camera multicolor status LED on back plate
General purpose opto-coupled input allows frame acquisition using an external
trigger
General purpose opto-coupled output (user, count, alarm or timer driven
triggering)
Counter function available based on general purpose opto-coupled input
Defective pixel replacement
Adaptive contrast enhancement
Digital zoom (1x, 2x, 4x, 8x or 16x)
Supports image time-stamp based on 1EEE1588-2008 Precision Time Protocol
for synchronization between multiple cameras
Built-in pseudo-color for enhanced visualization
Image metadata supported
Application development with the freely available Sapera™ LT software libraries
Internal mechanical shutter for remote recalibration
Made in Canada
Camera features can be controlled using a GigE Vision compliant software API, such as
Teledyne DALSA’s Sapera LT SDK. Within the Sapera LT SDK, we currently offer a generic
GigE Vision driver that supports all Teledyne DALSA GigE Vision cameras, including all
future Calibir GigE Vision cameras.
The Sapera LT initial version that supports this driver is Sapera LT v7.30. We strongly
recommend using v8.41 or greater for an improved user experience. Sapera LT is
available for download from the Teledyne DALSA website:
http://www.teledynedalsa.com/imaging/support/downloads/sdks/

10 Calibir GXM640 Overview
Calibir GXM640 IR Camera User's Manual
Teledyne DALSA Development Software
Table 1: Teledyne DALSA Development Software
Teledyne DALSA Software Platform for Microsoft Windows
Sapera LT version 8.41 or greater (for Windows)
includes Sapera Network Imaging Package and GigE
Vision Imaging Driver, Sapera Runtime and CamExpert.
Provides everything you will need to develop imaging
applications
Sapera documentation in compiled HTML help, and
Adobe Acrobat® (PDF)
Available for download:
http://www.teledynedalsa.com/imaging/support/
Sapera Processing Imaging Development Library
(available for Windows or Linux - sold separately):
Contact Teledyne DALSA Sales
Teledyne DALSA Software Platform for Linux
GigE Vision Framework (for both X86 or Arm type processor)
Contact Teledyne DALSA Sales
Model Part Numbers
The following tables lists the available part numbers, where:
EFL = Effective Focal Length
HFOV = Horizontal Field of View
VFOV = Vertical Field of View
Calibir GXM640 Part Numbers
Part #
Lens
Mount
EFL
(mm)
Aperture
(1/f)
HFOV
(degrees)
VFOV
(degrees)
Minimum
working
distance
(approx. 1)
Lens
Weight
(grams)
Total
Weight
(grams)
Length
with
lens
IR-
GMZG-
4100000
M25
No lens
67.2
-
IR-
GMZG-
4101000
M25
7.5
1.2
90.8
65.1
1 m
35
102.2
73 mm
IR-
GMZG-
4102000
M25
8.5
1.2
73.2
54.4
0.4 m
34
101.1
75 mm
IR-
GMZG-
4103000
M25
14.2
1.2
42.1
31.9
1.3 m
25
92.1
69 mm
IR-
GMZG-
4104000
M25
19
1.0
32.4
24.4
2.4 m
31.2
98.4
74 mm
IR-
GMZG-
4104500
M25
25
1.2
24.2
18.4
2 m
4
71.2
80 mm
IR-
GMZG-
4105000
M25
35
1.1
16.9
12.9
5 m
45.9
113.1
82 mm
1. Smaller working distances are possible but optical performance may be affected.
For ordering information, contact your Teledyne DALSA sales representative. For
Teledyne DALSA sales office details, see the Contact Information section.

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir GXM640 IR Camera User's Manual
Calibir GXM640 Overview 11
Export Controls
The Calibir GXM cameras are currently classified as a "Dual Use" item under Group 1 (1-
6.A.3.B.4.B) of the Canada Export Control List and Category 6 (6.A.3.B.4) under the
Wassennaar Arrangement on Export Control for Conventional Arms and Dual-Use Goods
and Technologies. As such, the Camera is subject to export control –export authorization
is required to export the Camera from Canada, whether on a permanent or temporary
basis.

12 Calibir GXM640 Overview
Calibir GXM640 IR Camera User's Manual
GXM640 Specifications
The Calibir GXM Series camera has the following specifications:
Table 2: Calibir GXM640 Series Specifications
Mechanical Interface
Camera with M25 Lens Mount (W x H x L)
29mm x 36mm x 59mm (with lens mount)
Mass (without lens)
67.2g
Power connector
via Samtec 10-pin connector (or optionally using Power-
over-Ethernet)
Electrical Interface
Input Voltage
12/24V DC (min 9V, max 57V)
Power Consumption, for different power
supply configurations:
Typ
Maximum
(typically due to shutter activation)
12 V
2.8 W
4.4 W
24 V
2.8 W
4.4W
Power over Ethernet (48V)
3.5 W
4.8 W
Environmental Conditions
Operating Temperature (Ambient)
-35°C to 60°C1
Operating Relative Humidity
maximum 80% non-condensing
Storage Temperature2
-40°C to +80°C
Storage Relative Humidity1
maximum 80% non-condensing
Sensor Information
Spectral Response
8-14μm (LWIR)
Pixel Pitch
17μm
Focal Plane Array
640x480 (VGA)
Camera Information
Boot time
7.5s ± 1s (from power-up to detection by Sapera LT library
running on Windows using Persistent IP address)
Internal mechanical shutter activation time
<100ms to change from open/closed position
Table 3: Calibir GXM640 NETD and Scene Range Specifications (at ambient temperature 25°C)
NETD3
Scene Range (°C)
<50 mK
-25 to 200
1. Extended or limited operating temperature ranges are available; contact Teledyne DALSA for more
information.
2. To avoid possible damage, when storing cameras, ensure that the sensor is not exposed to air; use a
lens cap or lens to cover the sensor.
3. Camera NETD measures the actual noise in output images, using an f/1.0 lens, with processing.
WARNING: These sensors are sensitive to over-exposure to hot objects; the sensors
are considered “sun-safe” in the sense that pixels will not break if over exposed for
short periods; however, long exposure to hot bodies (like the sun) will eventually
create ghost-like artifacts. These artifacts can be made to disappear by recalibrating
the FPN compensation (see Fixed Pattern Noise Correction).
WARNING: For cameras not equipped with a lens, do not touch the internal
mechanical shutter; any physical contact to the shutter may render it unusable.

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir GXM640 IR Camera User's Manual
Calibir GXM640 Overview 13
GXM640 EMI, Shock and Vibration Certifications
Table 4: GXM 640 EMI, Shock and Vibration Certifications
Test Name / Standard
Limit / Test Level
Measurement of conducted emissions
CISPR 11: 2015 A1: 2016 A2: 2019
Group1, Class A
Measurement of radiated emissions
CISPR 11: 2015 A1: 2016 A2: 2019
Group1, Class A
Measurement of conducted emissions - LAN port
CISPR 32: 2015
Class A
Measurement of conducted emissions
FCC Part 15: 2018, Subpart B
Class A
Measurement of radiated emissions
FCC Part 15: 2018, Subpart B
Class A
Radiated electromagnetic field immunity –radio frequencies
IEC 61000-4-3: 2006 A1 : 2007 A2 : 2010
Scan 10 V/m 80-1000 MHz
3 V/m 1.4-2.7 GHz
Spot 3 V/m 1.8, 2.6, 3.5 and 5 GHz
Conducted immunity
IEC 61000-4-6: 2013
10 V power
10 V I/O
Electrostatic discharge immunity
IEC 61000-4-2: 2008
±4 kV contact
±8 kV air
Electrostatic fast transient immunity
IEC 61000-4-4: 2012
±2 kV power
±1 kV I/O
Surge immunity
IEC 61000-4-5: 2014 A1: 2017
±1 kV L - L
±2 kV L - Ground
Magnetic field immunity
IEC 61000-4-8: 2009
30 A/m / 50 Hz
Voltage dips, short interruptions and voltage variation immunity
IEC 61000-4-11: 2004 A1: 2017
0% - 1 cycle
40% - 10 cycles
70% - 25 cycles
0% - 250 cycles
RoHS
Compliancy as per European directive 2011/65/EC
For an image of Calibir certificates see the section EC & FCC Declarations of Conformity.
Vibration & Shock Tests
Test Levels (while operating)
Test Parameters
Random vibrations
Level 1: 2 grms 60 min.
Level 2: 4 grms 45 min.
Level 3: 6 grms 30 min.
Level 4: 7.7 grms 60 min
Level 5: 15 grms 30 min
Level 6: 20 grms 30 min
Frequency range: 20 to 2000 Hz
Directions: X, Y, and Z axis
Shocks
Level 1: 20 g / 11 ms
Level 2: 30 g / 11 ms
Level 3: 40 g / 6 ms
Shape: half-sine
Number: 6 shocks (+) and 6 shocks (-)
Directions: ±X, ±Y, and ±Z axis
Thermal Shock
-35oC - 65 oC (+ 3 oC)
50 cycles
Additional information concerning test conditions and methodologies is available on request.

14 Calibir GXM640 Overview
Calibir GXM640 IR Camera User's Manual
GigE Vision Interface
Calibir GXM640 cameras comply with the GigE Vision and GenICam standard protocols.
GigE Vision Sapera Application Description
Calibir cameras are 100% compliant with the GigE Vision 1.1
specification which defines the communication interface protocol used
by any GigE Vision device. The device description and capabilities are
contained in an XML file. For more information see:
https://www.visiononline.org/vision-standards-details.cfm
Calibir cameras implement a superset of the GenICam™ specification
which defines device capabilities. This description takes the form of an
XML device description file respecting the syntax defined by the
GenApi module of the GenICam™ specification. For more information
see www.genicam.org.
The Teledyne DALSA GigE Vision Module provides a license free development platform
for Teledyne DALSA GigE hardware or Sapera vision applications. Additionally supported
are Sapera GigE Vision applications for third party hardware with the purchase of a GigE
Vision Module license, or the Sapera processing SDK with a valid license.
The GigE Vision Compliant XML device description file is embedded within Calibir
firmware allowing GigE Vision Compliant applications access to Calibir capabilities and
controls immediately after connection.
User’s Sapera
Application
Sapera LT SDK
GigE Vision
Module
GigE Server Sapera Network
Imaging Driver
CamExpert
Ethernet Network Interface Card
Network
Configuration Tool Images
Control
GVSP
GigE Vision
Stream
Protocol
GVCP
GigE Vision
Control
Protocol
single GigE Vision
Camera
Sapera LT
smart DHCP
Server (optional)
Sapera Network
Imaging Module
Alternatively via a switch
To multiple GigE
Vision Cameras
Figure 1: GigE Application Architecture

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir GXM640 IR Camera User's Manual
Calibir GXM640 Overview 15
GigE Network Adapter Overview
Calibir connects to a computer’s Gigabit Network Adapter (or NIC, for Network Interface
Card). If the computer is already connected to a network, the computer requires a second
network adapter, either onboard or an additional PCIe NIC adapter.
In general automatic IP configuration assignment (LLA/DHCP) is sufficient for most
Calibir GigE installations. Please refer to the Teledyne DALSA Network Imaging
Package manual for information on the Teledyne DALSA Network Configuration tool
and network optimization for GigE Vision cameras and devices.
PAUSE Frame Support
The Calibir supports the Gigabit Ethernet PAUSE Frame feature as per IEEE 802.3x.
PAUSE Frame is the Ethernet flow control mechanism to manage network traffic within
an Ethernet switch when multiple cameras are simultaneously used. This requires that
the flow control option in the NIC property settings and the Ethernet switch settings must
be enabled. Refer to the Teledyne DALSA Network Imaging manual.
Computer Requirements for Calibir GXM640
The following information is a guide to computer and networking equipment required to
support the Calibir GXM640 camera at maximum performance. The Calibir camera series
complies with the current IPv4 Internet Protocol, therefore current Gigabit Ethernet
(GigE) equipment should provide trouble free performance.
Host PC System
Operating Systems:
Windows 7, 8.0, 8.1, 10 (either 32-bit or 64-bit for all) are supported.
Linux supported by Teledyne DALSA GigE-V Framework; for supported kernels and
platforms refer to the GigE-V Framework documentation.
Network Adapters For GigE Camera Version
GigE network adapter (either add on card or on motherboard). The Intel PRO/1000
MT adapter is an example of a high performance NIC. Typically a system will need
an Ethernet GigE adapter to supplement the single NIC on the motherboard.
PCI Express adapters will outperform PCI adapters.
Laptop Information for GigE Camera Version
Older laptop computers with built in GigE network adapters may still not be able
to stream full frame rates from Calibir. Thorough testing is required with any
laptop computer to determine the maximum frame rate possible (refer to the
Teledyne DALSA Network Imaging Package user's manual).

16 Calibir GXM640 Overview
Calibir GXM640 IR Camera User's Manual
Software Requirements
Camera features can be controlled using a GigE Vision compliant software API, such as
Teledyne DALSA’s Sapera LT SDK. The Sapera LT software suite includes the CamExpert
tool that allows for quick configuration and evaluation of all Teledyne DALSA products.
As such, it is recommended that users install the latest version of Sapera LT on the host
computer for evaluation and development.
Note that while other software tools and SDK’s support acquiring images
from GigE cameras, Teledyne DALSA cannot provide support for their
specific configurations.
The current release version of Sapera LT is available for download here:
http://www.teledynedalsa.com/imaging/products/software/sapera/lt/download/.
To install the Sapera Network Imaging Package, it is recommended that the installation
be started locally instead of from a network location.
During the installation process, you are prompted to choose the Sapera LT acquisition
components to install. Select either the All acquisition components or the GigE Vision
cameras and the Sapera Network Imaging Package option. This will install the GigE
Vision Network Imaging Package on your system.
When upgrading from a previous version this dialog is not displayed and the same
directory structure and component configuration are used.

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir GXM640 IR Camera User's Manual
Calibir GXM640 Overview 17
While CamExpert can be used for evaluating a camera, an application typically uses the
Sapera LT API to configure the camera’s parameters and acquire images. Sample
applications are provided along with source code, to speed up application development.
By default they are installed under the directory:
C:\Program Files\Teledyne DALSA\Sapera\Demos\
Of particular interest is the GigE Camera Demo (available in pre-compiled form, with
C++ and C# source projects). This project provides everything needed to acquire images
from the camera. It can be easily modified to write required values to parameters (called
‘features’ in GenICam). For example, in C++ it can be implemented as:
m_AcqDevice->SetFeatureValue("PixelFormat", "Mono16");
Ethernet Switch Requirements for Calibir GXM640
When there is more than one device on the same network or a camera-to-PC separation
greater than 100 meters, an Ethernet switch is required. Since the Calibir GXM640
cameras comply with the Internet Protocol, they should work with all standard Ethernet
switches. However, switches offer a range of functions and performance grades, so care
must be taken to choose the right switch for a particular application.
IEEE 802.3x Pause Frame Flow Control
Ethernet Switches supporting Full-duplex IEEE 802.3x Pause Frame Flow Control must
be used in situations where multiple cameras may be triggered simultaneously. In such
a case the NIC maximum bandwidth would be exceeded if there was no mechanism to
temporarily hold back data from cameras. Calibir cameras support the IEEE 802.3x pause
frame flow control protocol automatically so that images from many cameras can be
transmitted through the switch to the NIC efficiently, without data loss. As a working
example, one such switch tested at Teledyne DALSA is the NETGEAR GS716T.
Even if a given Ethernet switch supports Flow Control, often this feature is
disabled in the switch configuration to provide best compatibility with older
equipments. Please refer to the switch’s documentation.
IEEE 1588 / PTP Transparent Mode
GigE switches which support PTP Transparent mode will help reduce the variability of
timestamp adjustments when cameras are synchronized with PTP/IEEE1588, but aren’t
required.
Important: The maximum frame rate possible from a large number of Calibir
cameras which are simultaneously triggered will depend on the Calibir model,
frame size, and network details. Each imaging system should be tested for data
rate limits.

18 Calibir GXM640 Overview
Calibir GXM640 IR Camera User's Manual
Ethernet to Fiber-Optic Interface Requirements
In cases of camera-to-PC separations of more than 100 meters but an Ethernet switch
is not desired, a fiber-optic media converter can be used. The FlexPoint GX from
Omnitron Systems (www.omnitron-systems.com) converts GigE to fiber transmission
and vice versa. It supports multimode (MM) fiber over distances of up to 220 m (720 ft.)
and single-mode (SM) fiber up to 65 km (40 mi.) with SC, MT-RJ, or LC connector types.
Important: The inclusion in this manual of GigE to fiber-optic converters does not
guarantee they will meet specific application requirements or performance. The user
must evaluate any supplemental Ethernet equipment.

The information contained in this document is not subject to Export Control Regulation in Canada.
Calibir GXM640 IR Camera User's Manual
Introduction to Microbolometers 19
Introduction to Microbolometers
A microbolometer is an uncooled thermal sensor used as a detector in an infrared
camera. Calibir GXM640 cameras are sensitive to thermal energy at long wave infrared
(LWIR) wavelengths ranging from 8 μm to 14 μm (infrared wavelengths span from 710
nm –1 millimeter). The Calibir GXM640 uses IR filtering lens that only allow these specific
wavelengths to pass to the detector.
All objects emit electromagnetic radiation and the amount of radiation emitted at each
wavelength depends on the temperature of the object. Hot objects emit at short
wavelengths and cold objects emit more at long wavelengths.
Infrared radiation strikes the detector material, heating it, and thus changing its
electrical resistance. This resistance change is measured and an analog-to-digital
converts the signal into a 16-bit value which is used to create an image. Unlike a
traditional image sensor, there is no exposure time to fill a pixel well with photons; the
microbolometer sensor is constantly exposed to incoming radiation and the readout
circuit samples the pixel values to create the frame. When in free-running mode, the
Calibir GXM640 reads frames at 30fps (this rate can be lowered by skipping frames or
using one of the frame trigger modes).

The information contained in this document is not subject to Export Control Regulation in Canada.
20 Introduction to Microbolometers
Calibir GXM640 IR Camera User's Manual
The IR absorbing material is thermally isolated by suspending it within a vacuum,
however it is still sensitive to changes in the camera body temperature.
When the camera operating temperature changes, the Calibir GXM640 shutterless
operation automatically compensates for the corresponding responsivity changes in the
microbolometer pixel array (non-uniformity correction (NUC)). The NUC is factory
calibrated across the working temperature range of the camera in free-running mode at
30fps.
However, if the thermo-mechanical environment of the camera changes from the factory
calibration environment (for example, one side is exposed to heat or surface mounting
conditions) the sensor fixed pattern noise (FPN) correction can be enabled to correct for
these differences. If the camera temperature changes, or improved image quality is
required, FPN correction can be recalculated to ensure optimal response.
Emissivity
Emissivity is a measure of a material’s ability to emit infrared energy. It is measured on
a scale from 0.00 to 1.00. Typically, the closer a material’s emissivity rating is to 1.00
(that is. 100%), the more that material tends to absorb reflected or ambient infrared
energy and emit only its own infrared radiation. Most organic materials (for example,
plants and animals), have an emissivity rating of 0.95.
Substances with very low emissivity ratings, like highly polished metals, tend to be very
reflective of ambient infrared energy and less effective at emitting their own
electromagnetic waves. For example, an object with an emissivity of 0.5, half the image
pixel value is the result of the ambient temperature of the surrounding environment
being reflected. Therefore an understanding of target environments containing objects
with emissivities of less than 0.7 is required to accurately analyze image scenes.
