deconta D 110L User manual

Instruction manual
Water treatment boiler system
D 110 L
Manufacturer: deconta GmbH
Im Geer 20, D - 46419 Isselburg
Description: Water management D 110 L
Type-No.: 503
Serial-No.: ..........

Instruction manual
Water treatment boiler system D 110 L
Seite 2
Table of contents
on page
1Basic safety advice 3
2Transport und storage 4
3 Volume of delivery 5
4 Technical description 5
5 Technical data 7
6 Initial operation 8
7 Maintenance and care 10
8 Circuit diagram 13
9 Declaration of conformity 14

Instruction manual
Water treatment boiler system D 110 L
Seite 3
1 Basic safety advice
The handling of the appliance technology is only allowed for instructed staff. The exact
knowledge of the guide book is an important condition for the staff before handling the
machine.
Please keep the instruction manual close to hand and available for everybody.
deconta has to engage you as the user to follow the guide book and to employ this
engineered technology only in accordance with the regulations and not in a inappropriate
way! In the event of non-observance, deconta assumes no liability.
To ensure safety during operation of the unit, the following must be strictly observed:
Do not use in potentially explosive areas.
Necessary repairs and maintenance may only be performed by authorized staff.
For all repair and maintenance work, the device is to be completely disconnected
from power supply
The safety and protective equipment is to be kept in perfect function.
Attached safety guidelines are to be kept in a readable state and are to be
followed.
Generally applicable legal and other binding regulations for accident prevention
and handling of hazardous substances must be observed.
In order not to restrict safety, any changes on the machine are prohibited.

Instruction manual
Water treatment boiler system D 110 L
Seite 4
2 Transport und storage
2.1 Delivery
The unit is delivered on a pallet. To prevent effects of weather or damages, the unit is
wrapped in a plastic film.
Transport damages have to be documented at once during the handing over of the
carrier or another supplier. Please note the possible damages additionally on the way bill.
2.2 Transport
The Transport has to be handled with care to avoid damages due to faulty handling or
imprudence.
In winter and at risk of frost, you have to empty the whole device (pumps, filter housings,
tank.) preliminary to the transport.
Attention: Transport of the machine (also change of location) only with a drained device.
2.3 Storage
In order to avoid damages, the installation has to be kept in a dry area with no access for
unauthorized persons.
Because of risk of frost in winter you have to observe the following:
Empty water pipes, filter housing and tank
Place the water treatment system in a place protected against frost.
Advice for the draining of the tank: In order to drain, move the ball valve.

Instruction manual
Water treatment boiler system D 110 L
Seite 5
3 Volume of delivery
The volume of delivery of a water treatment boiler system, unless no other agreements
have been made, consists of:
Water treatment system D110l
Filter set
Instruction manual
Return delivery after termination of rental period
We have to insist on following conditions for the return delivery in order to protect our
clients and in accordance with the rules for hazardous materials transportation:
As listed above
Well cleaned (ready for use)
Without binder remains
Without damages
Without filter
4 Technical description
4.1 Use according to regulations
During asbestos sanitation works within closed rooms, you have to exclude that the
asbestos fibres leave the sanitation area uncontrolled and endanger the human health
and the environment. For this reason, personnel must leave the sanitation area through a
lock system and take a shower while leaving.
The deconta water treatment assumes the heating of the shower water and takes over
the filtering of the contaminated sewage water.
4.2 Unit description
This is an electric warm water storage for the heating of shower water. The tank can be
filled optionally via the filling port (bucket) or automatically over a connected fresh water
hose. The water is heated to shower temperature (factory-adjusted approx. 37°C) by an
electric heating rod. The produced shower water is pumped out via an internal pump and
filtered.

Instruction manual
Water treatment boiler system D 110 L
Seite 6
4.3 Effectiveness of the waste water filtration
Test: Filter separation winding candle 1 Micrometer
Diameter in Micrometer
1
2345678 9 10 11 12 13 14 15 16 17
0
10
20
30
40
50
60
70
80
90
100
0,77 0,97 1,22 1,54 1,93 2,44 3,07 3,87 4,87 6,14 7,74 9,75 12,3 15,5 19,5 24,6 30,9
Meas. Point Diameter %
Effectiveness
1 0,77 84,3
2 0,97 90,4
3 1,22 93,5
4 1,54 95,0
5 1,93 96,2
6 2,44 97,4
7 3,07 98,5
8 3,87 99,7
9 4,87 99,8
10 6,14 100,0
11 7,74 100,0
12 9,75 100,0
13 12,28 100,0
14 15,47 100,0
15 19,49 100,0
16 24,56 100,0
17 30,94 100,0

Instruction manual
Water treatment boiler system D 110 L
Seite 7
5 Technical Data
Power connection: Schuko plug 230V / 50Hz / 9 A
Tank capacity: 110 Liter
Heizstab: 230V / 2000Watt
Heatup phase (37°C) with full tank: approx. 2 h
Pumps: 12 V / 6,5 A
Self-priming and dry run safe
Flow rate max.: 10,6 l/min
Fresh water supply: automatic via fresh water connection or manually
via filling port
Hose connection: System Geka
Filter system: 2-stufig, 10“ Pre- and fine filter
Dimensions (LxWxH): 730 x 620 x 1040 mm
Weight: 45 kg
technical changes reserved

Instruction manual
Water treatment boiler system D 110 L
Seite 8
6 Initial operation
Establish hose connections
Shower water connection => shower top
Sewage suction connection => floor tub shower
Sewage water => canalisation
Optionally connect hose to fresh water supply or fill tank manually via filling port
Connect to power supply
Adjust temperature at heating rod (the heating rod works at all switch settings of
the function switch, but not before a sensor-controlled minimum fill level is
reached)
At use of the automatic fresh water supply, the max. fill level is controlled by a float
switch
the unit is now ready-to-operate
Fine filter
Filling port
Pre filter
Fresh water supply
shower – and
sewagepump
Tank drainage
Function switch
Shower water connection
wewage water suction port
Sewage
Heating rod with
thermostat

Instruction manual
Water treatment boiler system D 110 L
Seite 9
Switch setting / function switch
Middle position: heating rod operative
Left position: sewage filtering pump and heating rod operative
Right position: Shower water pump, sewage pump and heating rod operative
Safety advice:
During works on the device always disconnect the plug!
Operate the device only with mains which are secured with fault current protection
switch!
Never operate the device without water! In case of frost risk, empty the device by
opening the stopcock!
Do not change the adjustment of the temperature in the pre-mixing unit! CAUTION!
Danger of scalding

Instruction manual
Water treatment boiler system D 110 L
Seite 10
7 Maintenance and care
7.1 Maintenance
Only undertake the maintenance works under the observance of all relevant safety
precautions, the filter is contaminated!
7.2 Daily maintenance
Check hoses on tightness and continuous flow
Visual check if pre filters are dirty
7.3 Filter change
Attention:
Filter change only if the device is switched off
Demount dirty filters only in wet shape to avoid contamination
Use only approved filters
It is prohibited to use damaged filter candles
Filter change:
Loose the nut
Take out the filter and dispose of it
Insert the new filter candles
Tighten the nut
The suction hoses, pumps, filter housings and filter are contaminated after the first
use. Repairs and maintenance have to be executed only under the observance of
all relevant safety measures. All the filters mentioned have to be disposed of
according to the legal terms.

Instruction manual
Water treatment boiler system D 110 L
Seite 11
7.4 Cleaning sewage pump
Remove cover plate
Remove hoses
Remvoe fastening screws of pressure switch.
ATTENTION: Do not alter the middle adjusting screw!
Remove fastening screws of pump head and take off the head
Cover plate
Hose
Hose
Fastening screw
Adjusting screw

Instruction manual
Water treatment boiler system D 110 L
Seite 12
Take out valve plate and clean front and back
Valve plate

Instruction manual
Water treatment boiler system D 110 L
Seite 13
8 Circuit diagram

Instruction manual
Water treatment boiler system D 110 L
Seite 14
9 Declaration of conformity
EU Declaration of conformity
deconta GmbH
Im Geer 20
D-46419 Isselburg
Product: Water treatment Typ: 503
The design of the unit complies with the EU-Maschine directive 2006/42/EG
following regulations: EU-Low voltage directive 2006/95/EG
Applied harmonised standards: EN 292, EN 60335-1
Applied national standards: DIN VDE 0701, DIN VDE 0702
A.Evers, Leitung Entwicklung Isselburg, 23.02.2011
The copyright of this instruction manual remains the property of deconta. This instruction
manual is destined for the field service and survey personnel. It contains instructions and
drafts of technical nature which must not be used completely or in extracts for the
purpose of competition. It may not be distributed among others.
For more information, please visit our website www.deconta.com.
