DeLaval FMC-IP1 User manual

DeLaval farm monitoring
camera FMC-IP1
Custom Print
© DeLaval 2021. All rights reserved. is a registered trademark of Tetra Laval Holdings &
Printout from Memo+ 2021-11-30 Finance S. A. and DeLaval is a registered trade/serv-
ice mark of DeLaval Holding AB.

Safety precautions.............................................................................................................................. 5
nDeLaval farm monitoring camera FMC-IP1
1 Foreword........................................................................................................................... 5
2 Disclaimer......................................................................................................................... 5
3 Note to operator................................................................................................................ 5
4 Safety regulations............................................................................................................. 5
5 Label descriptions............................................................................................................. 6
6 Regulatory compliance...................................................................................................... 7
6.1 FCC/ISED(IC) statement.................................................................................. 7
7 Warranty............................................................................................................................ 8
General description............................................................................................................................. 9
nDeLaval farm monitoring camera FMC-IP1
1 Introduction....................................................................................................................... 9
1.1 Parts of the camera......................................................................................... 10
2 Technical data................................................................................................................. 11
3 Function of the FMC-IP1................................................................................................. 12
4 Reset button.................................................................................................................... 13
5 Memory card................................................................................................................... 14
6 Software.......................................................................................................................... 14
6.1 Software functions.......................................................................................... 14
6.2 PC software functions..................................................................................... 15
6.3 Application functions....................................................................................... 15
7 GPL code statement ...................................................................................................... 15
Installation.......................................................................................................................................... 16
nDeLaval farm monitoring camera FMC-IP1
1 Installing the software..................................................................................................... 16
2 Connecting the camera to a network.............................................................................. 16
3 Adding a camera to the PC software.............................................................................. 18
4 Adding a camera to the iOS application.......................................................................... 20
5 Adding a camera to the Android application................................................................... 21
6 Inserting a memory card................................................................................................. 22
Operation............................................................................................................................................ 23
nDeLaval farm monitoring camera FMC-IP1
1 Using the PC software.................................................................................................... 23
1.1 Viewing a video feed....................................................................................... 23
1.2 Viewing multiple video feeds........................................................................... 25
1.3 Taking a photograph....................................................................................... 26
1.4 Viewing a photograph..................................................................................... 27
1.5 Recording a video........................................................................................... 30
1.6 Viewing a recorded video................................................................................ 30
1.7 Camera software............................................................................................. 33
2 Using the iOS application................................................................................................ 38
DeLaval farm monitoring camera FMC-IP1
Table of contents
© DeLaval 2021.
2021-11-30 3 (49)

2.1 Viewing a video feed....................................................................................... 38
2.2 Taking a photograph....................................................................................... 39
2.3 Viewing a photograph..................................................................................... 39
2.4 Viewing an event............................................................................................. 39
2.5 Playing a video................................................................................................ 39
2.6 Camera settings.............................................................................................. 40
3 Using the Android application......................................................................................... 42
3.1 Viewing a video feed....................................................................................... 42
3.2 Taking a photograph....................................................................................... 42
3.3 Viewing a photograph..................................................................................... 43
3.4 Camera settings.............................................................................................. 43
Troubleshooting................................................................................................................................ 46
nDeLaval farm monitoring camera FMC-IP1
1 Troubleshooting table...................................................................................................... 46
DeLaval farm monitoring camera FMC-IP1
Table of contents
© DeLaval 2021.
2021-11-30 4 (49)

Safety precautions
DeLaval farm monitoring camera
FMC-IP1
1 Foreword
The safety and operational instructions must be
observed by any person involved with the use
or operation of this equipment. Under no cir-
cumstances must the equipment be used if it is
damaged or if the operation of the equipment is
not completely understood.
2 Disclaimer
The information, instructions and parts listed
are applicable and current on the date when
issued. DeLaval reserves the right to make
changes without notice.
3 Note to operator
It is the operator's responsibility to see that any
person involved with the use or operation of this
equipment follows all safety and operational
instructions. Under no circumstances should
this equipment be used if the equipment is
faulty or the operator does not completely
understand the operation of the equipment.
4 Safety regulations
Danger!
Do not leave plastic packaging
material near children to avoid the
risk of suffocation.
DeLaval farm monitoring camera FMC-IP1
Safety precautions
© DeLaval 2021.
2021-11-30 5 (49)

Caution!
Do not cover the power adaptors or
place them on heat sensitive mate-
rials.
Caution!
Do not lift the equipment by the
antennas.
Note! Do not use the equipment to supervise
other people without their permission. Follow
local regulations in connection with supervision.
5 Label descriptions
A Product name
B Model
C Voltage, current, power
D CE marking
E Waste Electrical & Electronic Equip-
ment (WEEE)
F Enclosure class of the electrical box
281677
Fig. 1: Type plate.
281678
Fig. 2: FCC/IC label
DeLaval farm monitoring camera FMC-IP1
Safety precautions
© DeLaval 2021.
2021-11-30 6 (49)

6 Regulatory compliance
6.1 FCC/ISED(IC) statement
This device complies with part 15 of the FCC
(Federal Communications Commission) Rules
and RSS-210 of the IC (Industry Canada)
Rules. Operation is subject to the following two
conditions:
nThis device may not cause harmful interfer-
ence.
nThis device must accept any interference
received, including interferences that may
cause undesired operation.
Le présentappareilestconforme aux CNR d'In-
dustrie Canada applicables aux appareils radio-
exempts de licence. L'exploitationestautorisée
aux deux conditions suivantes:
nL'appareilnedoit pas produire de brouillage.
nL'utilisateur de l'appareildoit accepter tout
brouillageradioélectriquesubi, mêmesi le
brouillageest susceptible d'encompromettre
le fonctionnement.
Note! Changes or modifications to the equip-
ment not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasona-
ble protection against harmful interference in a
residential installation. This equipment gener-
ates, uses and can radiate radio frequency
energy and, if not installed and used in accord-
ance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interfer-
ence to radio or television reception, which can
be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
nReorient or relocate the receiving antenna.
nIncrease the separation between the equip-
ment and receiver.
DeLaval farm monitoring camera FMC-IP1
Safety precautions
© DeLaval 2021.
2021-11-30 7 (49)

nConnect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
nConsult the dealer or an experienced
radio/TV technician for help.
This device complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. The antenna used for this trans-
mitter must be installed to provide a separation
distance of at least 20 cm from all persons and
must not be co-located or operating in conjunc-
tion with any other antenna or transmitter.
For more information on regulatory compliance,
see
http://www.delavalcorporate.com/sustainability/
our-operations/regulatory-Compliance/.
7 Warranty
The warranty period for the DeLaval farm moni-
toring camera FMC-IP1 is three years.
The requirement for approved warranty claim:
nAdd the UID code in AWACS.
Note! Already treated warranty issues are not
opened up again.
Note! DeLaval will not take any responsibility
for damage resulting from faulty installation,
operation or for improper or inadequate care
and maintenance.
Note! Modification may create risks not covered
by the original construction. Do not make any
modifications which has not been approved by
DeLaval.
DeLaval farm monitoring camera FMC-IP1
Safety precautions
© DeLaval 2021.
2021-11-30 8 (49)

General description
DeLaval farm monitoring camera
FMC-IP1
1 Introduction
DeLaval farm monitoring camera FMC-IP1 is a
HD supervision camera system for barns,
stables or outdoor areas especially made for
tough barn environment. The camera software
provides a real time view, several areas can be
monitored at the same time.
The FMC-IP1 kit includes:
nWireless IP camera FMC-IP1
n12 V outdoor power adaptor
nPower adaptor cable
n5 dBi omnidirectional antenna
nY-cable for router and camera connection
n10 metres extension cable
n1 metre Ethernet cable
nScrews
nPlugs
nQuick guide
DeLaval farm monitoring camera FMC-IP1
General description
© DeLaval 2021.
2021-11-30 9 (49)

1.1 Parts of the camera
243601
Fig. 3: Parts of the camera.
A: Camera foot
B: Infrared LED
C: Reset button
D: Day/night sensor
E: Lens
F: Protective hood
G: Antenna
H: Microphone
J: Power connection; polarity: positive - centre,
negative - sleeve
DeLaval farm monitoring camera FMC-IP1
General description
© DeLaval 2021.
2021-11-30 10 (49)

2 Technical data
DeLaval farm monitoring camera FMC-IP1
Maximum resolution 1280 x 720
pixel
Maximum frame rate 30 fps
Type of equipment 2.4 GHz wire-
less trans-
ceiver
Maximum radiated power 20 dBm
Viewing angle 90°
Transmitting frequency 2.412-2.462
GHz
Image sensor 6.35 mm
(1/4") CMOS
Minimum illumination 1.0 Lux (0 Lux
in night vision
mode)
Infrared night range 12 m
Power supply DC 12 V
Operating temperature -20 to +60°C
(-4 to +
140°F)
Storage temperature -20 to +60°C
(-4 t o +
140°F)
IP-classification camera IP66
IP-classification adapter IP44
(87473204
Adapter US/
CAN)
Wireless technology IEEE802.11b/
g/n
Security WEP (64/128
bit), WPA-
PSK
(AES/TKI P),
WPA2- PSK
(AES/TKIP)
SD card support 16 Mb-128 Gb
(SDXX
microSD)
Weight 334 g
DeLaval farm monitoring camera FMC-IP1
General description
© DeLaval 2021.
2021-11-30 11 (49)

Dimensions Ø 51 x 105
mm
Simultaneous viewers 16
Power consumption (infrared
off - 200 mA)
2.4 W
Power consumption (infrared
on - 400 mA)
4.8 W
3 Function of the FMC-IP1
The camera transmits signals wirelessly
through Wi-Fi. The video feed from the camera
can be viewed using the associated software.
The number of cameras that can be used at the
same time depends on the bandwidth of the
internet connection.
Note! Maximum number of cameras is 100 in
the software.
The camera needs to be placed within Wi-Fi
range, see Fig. 4; all obstacles between the
cameras and the router will affect the quality of
the video feed.
DeLaval farm monitoring camera FMC-IP1
General description
© DeLaval 2021.
2021-11-30 12 (49)

243743
Fig. 4: FMC-IP1 system overview.
A: Wi-Fi range
B: Calving box
C: Smart device
D: Milking equipment
E: Router/Access point
F: Barn overview
G: Outdoor area
H: Garage
J: Computer
4 Reset button
The camera can be reset by pushing the button
at the back of the camera for 10 seconds. This
will also reset the password.
DeLaval farm monitoring camera FMC-IP1
General description
© DeLaval 2021.
2021-11-30 13 (49)

5 Memory card
The camera can be equipped with a micro SD
memory card. The memory card is necessary
for using the motion detection recordings in the
iOS and Android application.
The micro SD memory card has a storage
capacity of 16 MB to 128 GB . 1 GB equals
approximately 68 minutes of recorded material.
This means a total storage of 145 hours or 6
days.
Some memory cards may need formatting
before operation.
6 Software
The video feed can be viewed via PC software,
Android or iOS applications.
The FMC-IP1 software is available for PC or a
smart device and can be downloaded for free
from the following locations:
nwww.delavalfmc.com/FMC-IP1 - PC
nGoogle Play - Android
nApple Store - iOS
System requirements for PC
Operating system Windows 2000 or later version
Processor Intel Pentium III, 1 GHz or higher
Memory 256 MB RAM or higher
Web browser Internet Explorer 5.5 or later; Mozilla Firefox;
Google Chrome
Note! The DeLaval FMC application is not sup-
ported by Macintosh computers.
6.1 Software functions
The software can be used to take photographs
and record videos from the video feed of the
camera. The motion detection function notifies
the user on unexpected movements in the
monitored area. The software can be set to
send a push notification or to send an e-mail
DeLaval farm monitoring camera FMC-IP1
General description
© DeLaval 2021.
2021-11-30 14 (49)

notification every time the motion detection
alarm goes off. The e-mail notification function
requires a receiving e-mail account and a send-
ing e-mail account. The sending and receiving
accounts can not be the same, a Gmail account
is recommended for the sending e-mail
account.
6.2 PC software functions
nReal time video feed
nMultiple real time video feed
nTaking photographs
nViewing photographs
nRecording videos
nViewing videos
nScheduled recording
nMotion detection
6.3 Application functions
nReal time video feed
nTaking photographs
nViewing photographs
nMotion detection
7 GPL code statement
The software included in this product is licensed
under the GPL. The complete source code is
obtained for a period of three years after the
last shipment of this product for a nominal cost
to cover shipping and media charges. This offer
is valid for anyone who has received this infor-
mation. Please direct all inquiries to:
DeLaval International AB
P.O. Box 39
SE-14721 Tumba
Sweden
DeLaval farm monitoring camera FMC-IP1
General description
© DeLaval 2021.
2021-11-30 15 (49)

Installation
DeLaval farm monitoring camera
FMC-IP1
1 Installing the software
1. Turn on the PC or smart device.
2. Download the software FMC-IP1
nfrom www.delavalfmc.com/FMC-IP1
for PC
nfrom AppStore for iOS
nfrom Google Play for Android.
3. Follow the instructions on the screen to
install the software.
4. Add the camera to the software.
PC
Ä Chapter 3 "Adding a camera to the
PC software" on page 18
iOS Ä Chapter 4 "Adding a camera to the
iOS application" on page 20
Android Ä Chapter 5 "Adding a camera to
the Android application" on page 21.
2 Connecting the camera to a
network
Note! Make sure that the camera is located
within the Wi-Fi range and the signal is strong
enough.
Note! Make sure that the router is connected to
the Internet.
The camera is pre-configured to automatically
connect to a DeLaval router. If a DeLaval router
is available follow steps 8-10.
DeLaval farm monitoring camera FMC-IP1
Installation
© DeLaval 2021.
2021-11-30 16 (49)

1. Change the power adaptor cable to the
"Y" cable, see Fig. 5.
2. Connect the network cable to the "Y"
cable and to the router.
3. Plug the power adaptor connected to the
camera into the power socket, see Fig. 6.
4. Open the camera settings and connect
the camera to the Wi-Fi network.
nFor PC see Ä Chapter 1.7.3 "Setting
the camera properties" on page 37.
nFor iOS see
Ä Chapter 2.6.2 "Chang-
ing the camera net-
work" on page 40.
nFor Android see Ä Chapter 3.4 "Cam-
era settings" on page 43.
5. Disconnect the network cable from the
camera.
6. Detach the "Y" cable from the camera.
7. Plug in the power adaptor cable to the
camera.
8. Fasten the antenna on to the camera.
9. Fasten the camera in a suitable position
with the included screws in the camera
foot.
10.Plug in the power adaptor to the power
socket, see Fig. 7.
243508
Fig. 5: Changing the power adapter cable.
243511
Fig. 6: Connecting the network cable.
243501
Fig. 7: Camera with antenna and power cable.
DeLaval farm monitoring camera FMC-IP1
Installation
© DeLaval 2021.
2021-11-30 17 (49)

3 Adding a camera to the PC soft-
ware
1. Open the PC software, see Fig. 8.
2. Click the "Camera" icon in the menu bar,
see A in Fig. 8.
ðThe "Camera" icon becomes red.
3. Click the "Add camera" icon in the field of
installed cameras (B).
244160
Fig. 8: PC software screen.
4. Enter the camera "UID" code, see A in
Fig. 9.
DeLaval farm monitoring camera FMC-IP1
Installation
© DeLaval 2021.
2021-11-30 18 (49)

Note! The "UID" code can be found on
the quick guide or on the camera.
5. Enter "admin" as default password, see B
in Fig. 9.
Note! It is recommended to change the
camera password to prevent unauthorized
access. To change the camera password
follow steps 7-10 in Ä Chapter 1.7.3 "Set-
ting the camera properties" on page 37.
6. Enter a suitable name for the camera, see
C in Fig. 9.
7. Click the green "Check" icon to confirm.
Note! For adding more cameras repeat the
above procedure.
243431
Fig. 9: " UID " code screen.
DeLaval farm monitoring camera FMC-IP1
Installation
© DeLaval 2021.
2021-11-30 19 (49)

4 Adding a camera to the iOS
application
1. Tap the "Add Camera" icon, see G in
Fig. 10.
2. Enter a suitable name for the camera.
3. Enter the camera "UID" code.
Note! The "UID" code can be found on
the quick guide or on the camera.
4. Enter "admin" as default password.
Note! It is recommended to change the
camera password to prevent unauthorized
access. To change the camera password
see Ä Chapter 2.6.1 "Changing the cam-
era password" on page 40.
5. Tap "Save" to confirm.
245444
Fig. 10: iOS application screen.
A: Camera list
B: Delete camera
C: Installed cameras
D: Camera list
E: Event
F: Play
H: Information
DeLaval farm monitoring camera FMC-IP1
Installation
© DeLaval 2021.
2021-11-30 20 (49)
